SPADE

A Test Framework for SOAP Analysis in Dynamic Environments

Morten Avlesen

, Skage Spjelkavik

, Bjørn Vik

, Frank T. Johnsen

and Trude H. Bloebaum

Høgskolen i Oslo og Akershus (HiOA), Oslo, Norway

Norwegian Defence Research Establishment (FFI), Kjeller, Norway

Keywords:

Web Services.

Abstract:

We have developed a SOAP Analysis in Dynamic Environments (SPADE) test framework for conducting

experiments with Web services communication optimizations. Our framework consists of a Web service and

a client, a proxy translator module, a network emulator module, and an analysis module. The Web service

and client pair is intended for evaluation, and its only task is to provide trafﬁc for testing. The translator

module translates the communication between the Web service and the client to other protocols. The network

emulator module simulates different network conditions. Finally, the analysis module is used to measure the

performance of the different protocols. The contribution of this paper is our easily extendable test framework

for evaluating Web services transport protocols (and compression algorithms).

1 INTRODUCTION

Web services technology comprises a set of program-

ming standards providing the means for machine-to-

machine communication (W3C Working Group Note,

2004). Although Web services can be seen as just

another middleware, vital differences exist. For in-

stance, where other types of middleware are typically

used within a local domain, Web services technol-

ogy is also used as a middleware to connect such

local domains over the Internet. Web services are

also breaking ground in relation to standardization

of middleware platforms with respect to language

(XML), interface (WSDL), and message exchange

(SOAP) (Taylor, 2005).

The most common transport binding for Web ser-

vices is to use HTTP over TCP, which is one of several

standardized transport bindings for SOAP messages

(UDP and SMTP bindings also exist). One of the

main reasons why the HTTP binding is the most com-

mon is the fact that the majority of tools available for

Web service development support only this binding.

This in turn means that in order to remain compati-

ble with other service implementations, it is usually

necessary to retain this transport binding as the com-

munication interface between services and clients.

Our goal was to develop a test framework for

SOAP Analysis in Dynamic Environments (SPADE)

with a conﬁgurable transport layer and compression

module that can be used to evaluate the performance

of different transport protocols used with Web ser-

vices under constrained network conditions. In this

paper we describe the framework.

The remainder of this paper is organized as fol-

lows: Section 2 discusses related work. Our SPADE

framework is presented in Section 3, and an example

of its use is given in Section 4. Section 5 concludes

the paper.

2 RELATED WORK

Werner et al. (Werner et al., 2005) point out that band-

width and latency are issues when using Web services.

One of the main reasons for latency can be attributed

to the transport protocol. Thus, in this paper we fo-

cus on transport protocols that we consider to be cur-

rently relevant and implement support for these in our

framework. However, the framework is modular so

implementing support for additional protocols is pos-

sible.

In addition to the basic protocol replacement func-

tionality, our framework also has a compression mod-

ule. Since XML compression is recommended (see

e.g., (Berger et al., 2003) and (Gehlen and Bergs,

2004)) when utilizing Web services in wireless net-

works, adding compression to the test framework al-

lows for additional test scenarios and experiments.

Our current implementation supports one type of

compression, GZIP, but it is possible to extend the

compression module with support for further com-

pression mechanisms.

129

Avlesen M., Spjelkavik S., Vik B., Johnsen F. and Bloebaum T..

SPADE - A Test Framework for SOAP Analysis in Dynamic Environments.

DOI: 10.5220/0004351101290132

In Proceedings of the 9th International Conference on Web Information Systems and Technologies (WEBIST-2013), pages 129-132

ISBN: 978-989-8565-54-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Web Service sideClient side

WS-client plugin

Proxy Network Emulator Proxy

Web Service

pcap

AnalysisACE (GUI)

ACE (GUI)

HTTP/SOAP

Protocol (SOAP) Protocol (SOAP)

HTTP/SOAP

SSH

Start

Remote configuration

Figure 1: SPADE framework overview.

3 TEST FRAMEWORK: DESIGN

AND IMPLEMENTATION

The SPADE framework was implemented in Java and

consists of the following components: A Web ser-

vice, a Web service client plugin, a request generator,

a proxy server supporting compression and different

transport protocols, a network emulator, a set of cap-

ture and analysis tools used to capture network trafﬁc,

and ﬁnally a Graphical User Interface (GUI) for gen-

erating requests and controlling the components. See

Figure 1 for a graphical representation of the SPADE

framework on a system level. The components are

described in detail below.

3.1 The Web Service

The Web service is hosted in a GlassFish application

server. The main purpose of this Web service is to ac-

cept requests and generate responses to accommodate

our need for network trafﬁc when testing the differ-

ent transport protocols. The Web service generates

variable payload data, dependent on what the client

requests. GlassFish communicates with the proxy on

the server side using SOAP over HTTP/TCP.

3.2 The Web Service Client Plugin

The Web service client used in our framework is a

simple client that contacts the Web service request-

ing a message of a given payload size. The client

has been implemented as a plugin using the Java Sim-

ple Plugin Framework. This makes it easy to extend

the system with other Web service/client pairs in the

future, and ensures the necessary separation of con-

cerns between the Web service client and the SPADE

framework. The client plugin communicates with the

proxy on the client side using SOAP over HTTP/TCP.

3.3 Request Generator

The RequestRun module automates tests by conﬁgur-

ing the network emulator, generating network trafﬁc,

and measuring the performance. The module starts

with the setup phase, in which everything is made

ready to start generating trafﬁc. First, the network em-

ulator is reset. The next step is to make the Web ser-

vice client plugin ready by retrieving the WSDL for

the Web service. The network emulator is then conﬁg-

ured in accordance with the current test scenario. Fi-

nally, the phase is ﬁnished by starting pcap for packet

capture.

The next phase is the request generation phase,

where bursts of requests are sent using the Web ser-

vice client plugin with a given interval in between.

When all requests are sent the application waits un-

til all responses are received, or times out. All of the

requests sent exist as separate threads, and act as sep-

arate clients.

The ﬁnal phase is the shut down phase where the

test environment is made ready for the next test run.

First, the application delays to make sure any remain-

ing protocol test trafﬁc is completed and queues are

emptied. Then, it stops the pcap capture, saves the

captured data to a ﬁle with a name containing the cur-

rent test run scenario, the proxy it is connected to, and

the current time. Finally, it resets the proxy, making

it ready for another test run.

3.4 The Proxy Server

The proxy server implements a request/response

model, and translates between different protocols, as

well as supporting compression. An overview of this

module is given in Figure 2.

Listener

Connection handler

Service side

connection

Client side

connection

Request

Response

Receive Send

Receive

Request

Response Send

Payload data

Accept new

connection

Create and run

new Handler

Requesting

application

Responding

service

Figure 2: An overview of the message ﬂow in the proxy

server.

This module provides two connections; one client

side connection that communicates with the origina-

tor of the request, and a service side connection that

communicates with the Web service.

The proxy contains a compression module that

can be conﬁgured to (de)compress data passing

through it using GZIP (the default is no compression).

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

130

Due to the modular design it is easy to extend the

framework with additional compression algorithms in

the future, allowing for experiments combining com-

pression and transport protocol optimization combi-

nations.

The listener and connections are transport proto-

col speciﬁc implementations, and the client side con-

nection and the listener communicate over the same

protocol. The connections and the listener are sepa-

rated as much as possible from the core proxy server,

and the connection handler only passes the payload

data between the two connections using send and re-

ceive commands. This structure allows for quick im-

plementation of support for additional protocols in

the future, as these implementations only need to

able to separate streams and receive and send pay-

load data over the corresponding stream. Currently,

the following four protocols are supported: 1) Trans-

mission Control Protocol (TCP) (Postel, 1981), 2)

User Datagram Protocol (UDP) (Postel, 1980), 3)

Stream Control Transmission Protocol (SCTP) (Stew-

art, 2007), and 4) Advanced Message Queuing Proto-

col (AMQP) (OASIS, 2012). For AMQP, we used the

RabbitMQ implementation in our framework.

3.5 Network Emulator and Remote

Conﬁguration

The netem tool provides functionality emulating

properties such as variable delay, loss, duplication,

bandwidth constraints, and packet reordering. Netem

is a part of Linux kernels since version 2.6, and ef-

fectively allows you to conﬁgure emulated links with

speciﬁc properties using a command line interface. In

our framework we installed Ubuntu 10.04 LTS on an

IBX-200 (IBX, 2012) and used that as our network

emulator. However, any machine that can run Linux

and has two network interfaces can be used for this

purpose.

In our framework, the network emulator running

on the IBX-200 node is remote controlled via SSH.

This is achieved by using the Java library sshj. The

remote control functions like a regular SSH session,

and is initiated by logging on to the IBX-200 using

public key authentication. An execute command is

then transferred to the IBX-200, starting the network

emulator scripts including the option set for the test

run.

3.6 Packet Capture and Analysis

To measure the protocol efﬁciency and bandwidth us-

age the SPADE framework captures network trafﬁc

on the client side of the system. The network trafﬁc

is captured using the Jnetpcap library to communicate

with the packet capture library pcap, which is a well

known open source tool used for capturing network

trafﬁc. The tool also provides basic ﬁltering options,

in order to reduce clutter and only capture the trafﬁc

type we are interested in.

Round-trip times (RTT) are not measured by pcap,

but are calculated in the RequestRun module of

SPADE. After the test run is complete, all the network

trafﬁc generated is saved to a ﬁle. The framework

then parses the dump ﬁle and calculates throughput

and protocol efﬁciency.

To make graphical representations of statistical

data produced, this component uses the GRAL library

to produce plots for throughput, packet sizes, time of

capture and RTT.

3.7 Graphical User Interface

The GUI was made as a tool to make it faster and

easier to set up and execute tests, and it includes the

following functionality:

• Editing the parameters of all the different modules

included in SPADE.

• Automatically setting parameters where this is

possible.

• Saving and loading test conﬁgurations.

• Queuing RequestRuns and automatically running

the queue.

• A client mode, where one SPADE instance can be

remote controlled from another SPADE instance.

Currently limited to transferring proxy conﬁgura-

tions.

• Choosing where to place the data ﬁles captured by

the pcap dumper.

The GUI is inspired by integrated developer envi-

ronments and has a workspace overview where you

create new components for the test environments.

Here, the most important components are the test sce-

narios and the proxy servers. There are panels show-

ing the information for each component, and panels

that allow you to edit these components. The experi-

ment queue containing the test scenarios waiting to be

started are contained in an area at bottom. The GUI

has support for saving and loading conﬁgurations in

order to reduce the workload associated with conﬁg-

uring a large amount of experiments and repeating

these multiple times. An overview of a typical setup

is given in Figure 3.

SPADE-ATestFrameworkforSOAPAnalysisinDynamicEnvironments

131

Table 1: Result matrix. RTT = Round-trip time, SR = success rate, EFF = efﬁciency.

UDP TCP AMQP SCTP

Link quality Payload RTT SR EFF RTT SR EFF RTT SR EFF RTT SR EFF

GPRS, 40 kbps

1 kbyte 88600 64% 94% 88928 28% 42% 124530 1% 9% 59544 18% 16%

10 kbyte 104177 2% 95% – 0 65% – 0 21% 94898 13% 41%

EGDE, 125 kbps

1 kbyte 25337 67% 94% 52791 83% 60% 51822 12% 38% 60130 98% 59%

10 kbyte 120557 1% 95% 152377 17% 85% 83590 8% 61% 134512 17% 68%

UMTS, 214 kbps

1 kbyte 8965 58% 95% 18055 81% 55% 39329 35% 46% 27877 99% 62%

10 kbyte 76703 1% 95% 123098 29% 87% 50163 7% 64% 132832 37% 81%

Sat.com. 1 Mbps

1 kbyte 2435 68% 94% 7912 89% 49% 63694 95% 64% 11761 100% 50%

10 kbyte 72672 4% 96% 136412 96% 89% 109935 92% 87% 115614 96% 93%

SPADE Module

Request

generation

Web

Service

client

Proxy

SPADE Module

Proxy

Web

Service

Glassfish

Application

Server

Network

emulation

Netem

HTTP

Configurable

protocol

Configurable

protocol

Figure 3: A typical test network setup.

4 EXAMPLE EVALUATION

Our SPADE framework was conﬁgured for experi-

ment series using corresponding proxy protocol pairs

across the emulated network. All proxies communi-

cated with the end-point (i.e., the client or service)

using HTTP, and amongst themselves using the spec-

iﬁed transport protocols over the different emulated

networks.

In total we ran 72 test runs, consisting of all the

combinations of four protocols, nine test scenarios,

and two different message sizes. The network traf-

ﬁc from these test runs was captured and saved, and

then analyzed. A subset of the results generated by

the framework are shown in Table 1. The complete

combined test run took between six and seven hours

from start to ﬁnish. This is a drawback when using

emulations – everything has to run in real-time. How-

ever, since SPADE can queue deﬁned experiment runs

there is no need for human intervention during the test

period.

5 CONCLUSIONS

We have discussed using compression and replacing

HTTP/TCP as the transport protocol for SOAP as

ways to optimize the resource usage. To support opti-

mization experiments we have developed an easily ex-

tendable test framework, SPADE, for evaluating Web

services using different transport protocols and com-

pression algorithms. We have presented the frame-

work, along with an example evaluation of Web ser-

vices using four different transport (TCP, UDP, SCTP,

and AMQP) showing how the framework can be used.

ACKNOWLEDGEMENTS

The work was funded and supervised by FFI. The

framework was implemented and tested at FFI’s lab

facilities by students Avlesen, Spjelkavik, and Vik

from HiOA. We would like to thank associate pro-

fessor Hilde Hemmer at HiOA for her effort as co-

supervisor during the development of this project.

REFERENCES

Berger, S., McFaddin, S., Narayanaswami, C., and Raghu-

nath, M. (2003). Web services on mobile devices —

implementation and experience. in proceedings of the

Fifth IEEE Workshop on Mobile Computing Systems

and Applications.

Gehlen, G. and Bergs, R. G. R. (2004). Performance of

mobile web service access using the wireless applica-

tion protocol (wap). in Proceedings of World Wireless

Congress. San Francisco, CA, USA.

IBX (2012). Ibx-200 data sheet. http://ﬁles.ieiworld.com/

ﬁles/ news/ 080923/ IBX-200-9102G4/ P2_IBX-200-

9102G4.pdf.

OASIS (2012). Oasis advanced message queuing protocol

(amqp) tc. https://www.oasis-open.org/committees/

tc_home.php?wg_abbrev=amqp.

Postel, J. (1980). STD 6: User Datagram Protocol.

Postel, J. (1981). STD 7: Transmission Control Protocol:

DARPA Internet Program Protocol Speciﬁcation.

Stewart, R. (2007). Stream Control Transmission Protocol.

RFC 4960 (Proposed Standard). Updated by RFCs

6096, 6335.

Taylor, I. J. (2005). From p2p to web services and grids.

ISBN1-85233-869-5, Springer-Verlag London Lim-

ited.

W3C Working Group Note (2004). Web services archi-

tecture. http://www.w3.org/TR/2004/NOTE-ws-arch-

20040211/, 11 February.

Werner, C., Buschmann, C., Jäcker, T., and Fischer, S.

(2005). Bandwidth and latency considerations for efﬁ-

cient SOAP messaging. International Journal of Web

Services Research, Vol. 3, Issue 1.

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

132
