ScaBIA: Scalable Brain Image Analysis in the Cloud

Ali Gholami

, Gert Svensson

, Erwin Laure

, Matthias Eickhoff

and Götz Brasche

PDC and HPCViz, Royal Institute of Technology,Teknikringen 14, 10044, Stockholm, Sweden

Microsoft Research – Advanced Technology Labs (ATL) Europe, Ritterstrasse 23, 52072, Aachen, Germany

Keywords: Cloud Computing, SPM, Microsoft Azure, e-Science as a Service, Brain Imaging, FMRI.

Abstract: The use of cloud computing as a new paradigm has become a reality. Cloud computing leverages the use of

on-demand CPU power and storage resources while eliminating the cost of commodity hardware ownership.

Cloud computing is now gaining popularity among many different organizations and commercial sectors. In

this paper, we present the scalable brain image analysis (ScaBIA) architecture, a new model to run statistical

parametric analysis (SPM) jobs using cloud computing. SPM is one of the most popular toolkits in

neuroscience for running compute-intensive brain image analysis tasks. However, issues such as sharing

raw data and results, as well as scalability and performance are major bottlenecks in the “single PC”-

execution model. In this work, we describe a prototype using the generic worker (GW), an e-Science as a

service middleware, on top of Microsoft Azure to run and manage the SPM tasks. The functional prototype

shows that ScaBIA provides a scalable framework for multi-job submission and enables users to share data

securely using storage access keys across different organizations.

1 INTRODUCTION

Over the last twenty years, cloud computing has

emerged as a new business model leveraging the

high level abstraction of hardware and software

resources but with low capital costs and on-demand

scalability of resources to consumers. The economic

factors combined with the key characteristics such as

simplicity, elasticity and availability make cloud

services attractive to many users within a wide

variety of organizations. Nowadays, the market is

offering a large number of cloud-based services on a

global scale for organizations and companies around

the world to improve their efficiency and to reduce

costs (Hwang et al., 2011). Furthermore, many

enterprises and organizations are considering using

cloud storage to store their data as a result of the

data flood coming from their users or customers.

In this paper we apply cloud computing to the

functional analysis of 3D brain imaging data

acquired mainly from Magnetic Resonance (MR)

scanners  so-called fMRI analysis  and describe

the design of a prototype system for that task. The

problem at hand is to analyse which part of the brain

is activated when subjects perform certain tasks. To

find the activation pattern, a number of brain images

are taken in a time series for several subjects, both

when subjects are performing the task and when

they are not doing so. The prototype has been

developed based on an open source toolkit called

Statistical Parametric Mapping (SPM) which utilizes

MATLAB (SPM, 2011). We implemented our

prototype using the generic worker (GW) on top of

Microsoft Azure to bridge the gap between Platform

as a Service (PaaS) and Software as a Service (SaaS)

layers (

VENUS-C FP7 Project, 2010), since Microsoft

Windows is used as a de facto platform by many

brain imaging research groups and communities.

2 BACKGROUND

In this section we give an overview of the

neuroscience workflow involving SPM and describe

the VENUS-C cloud architecture with a focus on the

GW component used in our implementation.

2.1 SPM Overview

The goal of the functional analysis of brain images is

to find the parts of the brain that are activated when

people (subjects) perform certain tasks. Since the

signals that can be measured from the brain are

noisy and there is considerable variation between

329

Gholami A., Svensson G., Laure E., Eickhoff M. and Brasche G..

ScaBIA: Scalable Brain Image Analysis in the Cloud .

DOI: 10.5220/0004358003290336

In Proceedings of the 3rd International Conference on Cloud Computing and Services Science (CLOSER-2013), pages 329-336

ISBN: 978-989-8565-52-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

individuals, many subjects, and many images of

each subject’s brain, are required to get any

statistically significant results from the analysis.

There are also several parameters that need to be

varied during the analysis. This means that the

analysis normally has to be executed many times

with different hypotheses and parameters.

A typical study consists of hundreds to thousands

of 3D images of each subject; the resolution of a

single image is normally in the order of few

millimetres which gives an image size of several

MBytes. There are normally 10 to 100 subjects in

each study, and it usually takes over a day for a

single analysis on a normal PC. Hence there is a

need for scalable compute and storage resources.

A typical analysis of brain images generally

consists of several steps as shown in Figure 1:

 Re-align (compensate for subject head

movement),

 Co-register (align structural and functional

images),

 Normalize (transform to standard brain space),

 Segment (remove the scull bone etc. and leave

only the brain),

 Filter (remove noise by low-pass filter), and

 Apply statistic methods, which normally use the

General Linear Model (GLM).

Figure 1: A series of stages to do an fMRI data analysis

over N subjects (S

, S

, …, S

) each subject i containing n

images (IMGi,1, IMGi,2, …, IMGi,n).

After running all stages required for an analysis

described in Figure 1, users may try to make

inference using different parameters in their model

or do Bayesian analysis or several other methods on

the results. As an example, Figure 2 illustrates

results of the estimation stage  the last process in

Figure 1  to make an inference by a user in a

parametric approach.

Figure 2: Resulting activation map of an experiment.

In all of these steps, the analyses of different

subjects are independent (except for the GLM-step

in certain cases). In some steps, like filtering, the

analysis of each image is also independent. This

implies that it is possible to handle the subjects (and

in some cases also the corresponding images) in

parallel to speed up the analysis.

The toolkit that is used most for this kind of

analysis is SPM, which is an open source toolkit

based on MATLAB. The toolkit provides a

graphical user interface that allows the user to define

and execute MATLAB scripts to run all single steps

of the analysis. More advanced users can work

directly in MATLAB and define their own scripts.

One goal of the prototypic cloud-based

implementation described in this paper was to

maintain this flexibility.

By using cloud technology, we can speed up

individual analyses without having to invest in

computing hardware. Running each subject in

parallel speeds up the process by a factor that is

roughly the number of subjects in the study.

Moreover, by using the cloud, we can execute

several analyses at the same time with different

parameters. The above reasoning suggests that it is

more economical to purchase computing capacity on

demand, rather than building up a permanent

infrastructure that could cope with the peak

demands.

Most neuroscience laboratories in the world have

made little efforts to share data between researchers

in the same laboratory, let alone to share data

between different laboratories. Currently, many

researchers in the field store their fMRI data and

results on the local hard disk or network file system

(NFS) home directory that slows down the process

of sharing data among users corresponding to

different organizations. In addition local storage

restricts expanding the storage resources when data

volume increases. As a result of this, experiments

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

330

may be repeated unnecessarily. Although data

sharing was not the focus of this study, the prototype

we developed has shown that cloud technology is a

convenient way to simplify sharing of data in the

neuroscience field. Hence, users will not be

restricted to their organization’s boundary or

technological bottlenecks to access the fMRI storage

on-demand.

2.2 VENUS-C

Virtual Multidisciplinary EnviroNments USing

Cloud Infrastructures (VENUS-C) was a project

from July 2010 to June 2012 in the European

Commission’s 7th Framework Programme (

VENUS-

C FP7 project, 2010

). The project aimed to develop,

test and deploy an industry-quality, highly-scalable

and flexible cloud infrastructure for e-Science. The

overall goal was to empower the many researchers

who do not have access to supercomputers or big

grids, by making it easy to use cloud infrastructures.

For this to be feasible, the project had to minimize

the efforts that such researchers need to spend for

development and deployment in order to do

computations in the cloud, thereby also reducing the

costs for operating the cloud.

2.2.1 VENUS-C Architecture

In order to achieve the goals, the project collected

requirements from different scientific use cases and

as a result designed a platform that is capable of

supporting multiple programming models, such as

batch processing, workflow execution or even

Map/Reduce (Dean and Ghemawat, 2004) at the

same time.

Figure 3: VENUS-C architecture.

Figure 3 illustrates the generalized VENUS-C

architecture (VENUS-C Deliverable D6.1, 2011)

and shows the basic steps that a researcher must

perform in order to use VENUS-C. These steps are

independent of the programming model that is used.

Firstly the researcher uploads the locally available

data to the cloud storage. The next step is to submit

a job. So called dedicated Programming Model

Enactment Services (PMES) are provided for this

purpose. These services enable the researchers to

perform tasks such as managing jobs or scaling the

resources used in the cloud, while simultaneously

shielding the researchers from the underlying cloud

infrastructure and the specific implementations of

different infrastructures through open grid service

architecture  basic execution services (OGSA-BES)

compliant interfaces (Foster et al., 2007). OGSA-

BES is an open standard for basic execution services

and widely used in grid communities for submitting

jobs. The third step involves carrying out the

required computations. For this, the necessary

application and job specific data is transferred to the

compute node. After the computation has finished,

the fourth step consists of transferring the resulting

data to the cloud storage. In the fifth and final step,

the researcher can download the results from the

cloud to local facilities.

2.2.2 Generic Worker

The GW module (Generic Worker Complete

Documentation, 2012) has been developed in the

VENUS-C project. Following the general VENUS-C

architecture, the GW represents a reference

implementation for a batch processing programming

model and is available for public download.

The GW is basically a worker process (similar to

Windows Service or UNIX daemon processes) that

can be started on virtual machines (VMs) in the

cloud. Being able to run many VMs at the same time

with a GW worker process provides great horizontal

scaling capabilities and allows work items to be

distributed across the machines according to the

user’s requirements.

Figure 4: Simplified internal GW architecture.

Figure 4 shows how the GW is designed

internally. In a similar way to that described in the

ScaBIA:ScalableBrainImageAnalysisintheCloud

331

general VENUS-C architecture, the researcher

uploads applications and data to storage, which is

connected to the Internet so that the GW can also

access it. The GW design supports a broad selection

of different protocols and storage services. In

addition to the data and the application that should

be run, the GW also needs a description of this

application containing metadata about it. This

information allows the GW to understand

parameters like input and output files enabling a

proper execution of the application by the GW.

Jobs are submitted using the PMES. To make

this safe, different security mechanism  such as a

Security Token Service (STS) to validate, issue and

exchange security tokens based on the well-known

WS-Trust protocol (Djordjevic and Dimitrakos,

2005) and username / password  can be used. The

PMES stores all the incoming jobs in an internal job

queue based on a table (Job Index); an additional

table is used for the job details. The GW driver

processes continuously look for new jobs in this

queue. As soon as a driver process finds a job in the

queue, it will pull the job from the queue, and check

the application and data storage to find out if

everything that is needed is available, namely all the

required input data and the relevant application

binaries. If these are in place, the job can be

executed. The driver process that found the job

marks the job as being processed by that particular

driver in the “job details”-table (JDT), and starts

downloading the input data to the local hard disk of

the VM. If application or data are not yet available,

the job will be put back into the queue to wait for the

missing files. The driver process also checks

whether the application is already present on the VM

and, if necessary, the application will be downloaded

as well. Thus the GW process follows a data-driven

pull model, allowing simple workflows where jobs

rely on the output of other jobs.

Once the application is available, the driver

process retrieves information on how to call the

application and then launches it. After the

application terminates, the results are made

persistent by uploading them to the data storage.

Finally, the driver process uses the JDT to mark the

job as either completed or failed, depending on the

exit code of the application. Researchers who used

the PMES client-side notification will be notified

about this event. There are several notification-plug-

ins available e.g. sending mails or putting messages

in a queue for every event. Researchers can also

query the PMES to check the current state of a job.

2.3 Related Work

Several research groups made attempts to optimize

the execution time of SPM scripts, including

parallelizing it. For instance, Parallel SPM (PSMP)

is a package that has been developed using Message

Passing Interface (MPI) to provide parallelism in

SPM (PSPM and MPI, 2011). Beno is another

package that can be deployed on a local cluster to

run SPM single subject analyses in parallel. (Beno,

2011). However, it creates bottlenecks when parallel

nodes try to access the external storage. Both PSPM

and Beno rely on multi-CPU clusters to run a single

subject in parallel and do not address scalability

related to the number of subjects. While these efforts

provide increased efficiency for studies on local

infrastructures, they lack the resource scalability

provided by cloud infrastructures. By using cloud

infrastructures analysis can be scaled to computing

resources typically not available in local

environments. To the best of our knowledge, this

work is the first attempt to perform SPM analysis on

cloud infrastructures.

3 CLOUD BRAIN IMAGING

As we wanted to make it easy for researchers to use

the cloud, we aimed to design a system that would

not require the end user to be aware of the

complexity of cloud computing or of any

dependencies on GW libraries. It was important to

preserve the job execution style of SPM, so that

users could run their brain imaging jobs using the

MATLAB command line. Thus, in our architecture,

we opted for a user-friendly interface, with minimal

necessary dependencies on third party libraries (to

provide a secure communication channel between

the GW endpoint and the clients).

3.1 ScaBIA Architecture

To enable users to communicate with and submit

brain imaging tasks to the GW, we integrated three

main components into our prototype: an application

manager, a job manager and a data manager, as

illustrated in Figure 5. Client interaction is based on

STS to ensure that only authorized users are allowed

to register applications and submit jobs. We divided

the certificates into two different categories: one for

users, and the other for management purposes. In

principle, user certificates are used when invoking

commands to submit jobs to the GW end-points or

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

332

when establishing secure channels and encrypted

communication to the Azure cloud platform, e.g.

using management certificates for scaling the

number of VMs running at the same time (Generic

Worker Complete Documentation, 2012).

Figure 5: Architectural view of the ScaBIA system.

3.2 ScaBIA Components

Generally, the user requirements for execution of

cloud-based SPM can be divided into three major

areas. Users need to be able to prepare the execution

infrastructure without experiencing difficulties

caused by the cloud middleware. Secondly, the users

need to be able to execute their jobs and keep track

of all submissions. Finally users need to be able to

transfer and share data between the cloud storage

and their local hard disk securely over the Internet

without encountering cross-organizational

restrictions introduced by the network services.

3.2.1 Application Manager

Prior to accepting any requests from users, the cloud

environment has to set up any mandatory libraries

and software. To successfully install an application

in GW, the Application Manager (AM) packs all the

files that are necessary for running that application

into a compressed file. The AM then creates an

application description which defines the command

line execution format for the application. Next, the

AM uploads the application to the application

repository that is based on the Azure blob storage.

To do this, the AM has to serialize the application

description into an XML structure that is uploaded

to the application repository. Users need to

remember the location of both the application and of

the description for job submission purposes. The

AM archives different user pre-requisites (for

running a library-dependent job) into a single zip-

file and uploads it to the pre-defined cloud storage.

3.2.2 Job Manager

To submit SPM jobs, the user provides a job

description defining the arguments for the job and

their values, in addition to the SPM script created by

the user through the SPM GUI (which is the real job

that will is be executed). The Job Manager (JM)

compresses all the brain images, together with the

SPM scripts and job description, to submit to the

GW endpoint. The GW job description API

implements the job submission description language

(JSDL) that is a specification to define submission

aspects of jobs such as job name, resource

requirements and so on (Savva, 2005). There are

some scenarios where data, such as brain images, are

already stored in the data storage in the cloud and

there is no need to re-transfer the input data. For

instance, in a chain of SPM tasks, the results from

task N-1 will be used as input for a new task N. In

such scenarios, the user only needs to use the JM as

a job submitter and provide the location of the input

files within the data storage.

Furthermore, the JM provides functions to check

the status of submitted jobs and to terminate jobs in

any stage of execution. To check the status of jobs,

the JM periodically polls the GW with the job id

returned from the earlier job submission steps. Thus

the JM can notify the job owner when a job is

completed. Moreover, the JM is able to get the status

of a list of jobs, or of all the jobs in the job table that

belong to a specific user.

3.2.3 Data Manager

Each SPM job requires hundreds of granular images

that must be present for the job execution.

Therefore, we require an effective data transfer

solution and also have to be able to download results

with names that humans could read. The Data

Manager (DM) enables users to upload or download

data results from/to their local hard disk, and lets

them rename data in the data storage. An excellent

example can be a scenario where user completes the

analysis stages (Figure 1) and wishes to download

the results locally to visualize the results within the

SPM toolkit.

Furthermore, in a distributed environment, which

is typical for the research world since users are

scattered between different organizations, the DM

provides a useful facility for sharing brain images

between users and cloud applications. The DM acts

as a cross-boundary client enabling users to perform

create, read, update and delete (CRUD) operations.

External users who wish to access the brain imaging

ScaBIA:ScalableBrainImageAnalysisintheCloud

333

data can easily invoke the client independently of

their geographical locations.

Prior to any attempts by users to access the

storage, the data owner must grant access privileges

to the storage according to users storage access keys

through the Azure management portal. Azure

storage requires two sorts of access keys known as

primary and secondary storage keys to authenticate

users. The primary storage key is a mandatory 512-

bits symmetric key that will be used as the main

authentication key. The secondary storage key is

optional to have and it can be generated

independently from the primary key to act as backup

with similar access rights. A designated host with a

management certificate is allowed to add or remove

users belonging to different domains.

4 IMPLEMENTATION

The GW provides a Microsoft .NET API for

applications to implement all functionality that is

needed to execute SPM job successfully. We

integrated the GW and SDK assemblies (DLLs) into

the MATLAB R2011a environment. To relax the

licensing issues, we used the MATLAB Compiler

Runtime (MCR) Windows 64-bits version 7.15

associated with MATLAB R2011a (MCR, 2011).

4.1 Deploying the Generic Worker

As a preliminary step, we deployed SPM using GW

on top of Azure to facilitate deployment,

initialization, and invoking SPM stand-alone over

Azure without any modification of the SPM API.

The Windows Azure management portal provides

user interfaces to upload security credentials, along

with the GW and configurations. The GW is

provided in different deployable packages: extra

small, small, medium, large and extra-large. We

deployed a production-hosted service composed of

20 medium-sized dual core machines and 3.5

Gigabyte memory with a bandwidth of 200 Mbit/s

(Microsoft Windows Azure, 2012).

This hosted service also required an XML

service configuration file that defines how the hosted

service should run, for example, specifying the

number of running instances or user and

management certificate thumbprints, or other

information (such as the job submission to GW end-

points). We issued two self-signed OpenSSL

certificates, one for management and one for job

submission: both based on their distinguished

names. We added the thumbprint of these

certificates to the hosted service configuration file

and uploaded the certificates to the management

portal. The uploaded certificate contains both public

and private keys in a single file, with a protected

private key defined by the user’s secret.

4.2 Building the Application

GW instances search for the MCR and standalone

SPM dependencies during the initialization process.

Therefore, prior to running the GW instances, we

have to upload the MCR v7.15 and standalone SPM

for Microsoft Windows 64-bits platform (VENUS-C

Software and Document Resources, 2012).

We implemented a MATLAB function to act on

behalf of the user to compress the SPM

dependencies and to upload them to the application

repository using the following command line:

install_application(mcr_path,spm_path,

app_rep)

The first argument of this command is the location

of the MCR. The second and third arguments are the

SPM standalone location, and the name of the

application repository where the user pre-requisites

should be stored. After successful installation of the

application pre-requisites, the GW will load and

install the pre-requisites for all new VMs.

4.3 Job Submission

For job submission purposes, we developed two

MATLAB functions. The user enters these on the

command line to submit a job, either for a single

subject, or for several subjects to run in parallel to

ensure scalability for scenarios with a large number

of subjects. The signature of the function to submit

SPM jobs is as below:

submit_job(job_script,data_path,

output_name, flag)

This function needs the following arguments: the

real SPM script as the execution job, the path to the

brain images, the name to be used for the output

results, and a flag that is set in cases of multiple job

submission (where an SPM job will be iterated over

several subjects within different running GWs). To

clarify, the SPM job is a script where the user

creates an iteration of a set of instructions over a

number of brain images for a group of one or more

subjects. The second argument specifies the

directory path where the images from that subject

reside. Those images need to be uploaded with the

submission of the SPM job. This command adapts

the local file system names according to the GW

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

334

standard by eliminating the root directory and

replacing that with the current working path in GW.

Figure 6 illustrates the process of creating SPM

scripts by the user through the GUI and making

them compatible to run on Azure by JM, in respect

to the GW file addressing conventions.

Figure 6: Process of creating SPM scripts and making

them compatible with GW.

In order to store the result of the executions in

the cloud storage, the user should define a name in

the third argument that will be used for the output.

There are some cases that do not require uploading

of data when the clients submit jobs, for instance, in

a specific scenario where job n-1 produces results

that are required by the next job n as input. In such

cases, the user can pass an explicit

“no_data”-

signal in the flag argument. This notifies the

application to fetch the input data from the storage.

To fulfil other job management tasks, we

implemented the following functions to track the

status of submitted tasks, and to cancel a specific

submitted job on GW when required by user:

poll_status(id) and terminate_job(id)

The first function resolves a job identifier that is

returned from the

submit_job function and

periodically polls the status of a defined job. The

status could be: Pending, Running, Finished or

Cancelled. Furthermore, the client is also able to

terminate any job using its job identifier.

These two additional commands are very useful

when an SPM user needs to submit a large number

of jobs in parallel together on different running

instances of the GW. All the submitted jobs can

easily be tracked, and terminated instantly if needed,

using these commands.

4.4 Data Management

In order to upload, download or delete brain images

on the cloud storage, we developed a set of functions

to enable SPM users to run those functions from the

MATLAB command line. In the first step, the DM

acquires a container reference from the storage using

a GW API according to the container’s name:

GetContainerReference(container)

The argument of this function refers to the

container that the user provided to invoke the data

transfer functions. We also increased the default

time-out of the client (by setting the TimeSpan to a

reasonable value) so that large amounts of data

could be transferred successfully even if there were

delays in the underlying communication networks or

storage server timeouts.

To upload a file (that is, a set of brain images as

a single file) to a specific container, the client should

issue the command:

upload_subject(container, file_name,

local_path)

Moreover, to facilitate the distributed access of

data for a set of results, the client can query the

container that stores a particular file. For this

purpose, user needs the file name that is stored in the

container and the local path to save the result. The

user must define at least a 512-bits storage access

key as primary key, based on Azure management

portal in combination with the storage account name

to authorize user requests to storage services:

download_subject(container, file_name,

local_path)

SPM users can issue another command to

remove the storage contents associated with file

names in distinguished containers. We implemented

the following function with the same interaction

pattern, with upload/download provided by the GW

API:

delete_subject(container_name,

file_name)

5 CONCLUSIONS AND FUTURE

WORK

In conclusion, cloud computing as an enabling

technology helps eliminating the barriers such as

restricted resource scalability imposed on

researchers by the existing systems in the brain

imaging area. Our prototype demonstrated that cloud

computing, and specifically Microsoft Azure, can

ScaBIA:ScalableBrainImageAnalysisintheCloud

335

enable neuroscientists to exploit the benefits of

cloud computing. Users and organizations no longer

need to be concerned about hardware requirements

or storage capacities as the cloud provides scalability

on demand. Also, our implementation shows that it

is feasible to share data securely between users

belonging to different organizations.

However, while implementing our solution, we

faced compatibility issues with the GW SDK and the

MATLAB environment, and we had to adapt the

.NET API according to the SPM settings. We were

also interested in integrating the Cloud Data

Management Interface (CDMI) implementation

(Livenson and Laure, 2011) for transferring our data

to the cloud, but it was not feasible with our solution

since the CDMI implementation on Azure storage

services missed some features and the .NET CDMI

client library was not as functional as the Java

version. Therefore we had to opt for a solution that

transferred our granular files as a single unit to the

cloud storage.

As we mentioned earlier in section 2.1, each

SPM job is composed of several steps and in real life

it would be interesting to measure the overheads

associated with using Microsoft Azure for deploying

the SPM. For instance, a thorough performance

analysis could be carried out to compare the stage-

in/stage-out time for data, the length of time that

jobs stay in the queue before being run, and other

metrics such as the execution or completion time for

jobs. Also, it could be useful to run real SPM jobs in

different VMs with different memory capacities and

CPU cores to discover the limitations that our

prototype might pose in real life. The possibility of

designing parallel jobs through breaking the SPM

jobs into smaller tasks that can be run in parallel also

can be interesting to achieve better performance.

Finally, to empower users with browsing and data

management capabilities of the storage,

implementing a MATLAB GUI would be useful.

This feature will enable users to see contents of the

containers that belong to different research groups

for data sharing purposes.

ACKNOWLEDGEMENTS

We gratefully acknowledge the help of those who

organized, reviewed and provided motivation for

this paper, especially: Fredrik Ullén, Lars Forsberg,

Rita Almedia from Karolinska Institute and Åke

Edlund, Ilja Livenson from the Royal Institute of

Technology. Special thanks also to Genet

Edmondson for language comments. This research

was sponsored by the EU within the 7FP project

“VENUS-C” under grant agreement number

261565.

REFERENCES

Beno. Retrieved April 7, 2011, from http://phiwave.source

forge.net/howto_parallel/#Parallel_SPM_batch_script

ing_on.

Dean, J. and Ghemawat, S. (2004). MapReduce:

Simplified Data Processing on Large Clusters, Sixth

Symposium on Operating System Design and

Implementation, San Francisco, CA.

Djordjevic, I. and Dimitrakos, T. (2005). A Note On the

Anatomy of Federation, BT Technology Journal,

Volume 23, Issue 4.

Generic Worker Complete Documentation. Retrieved

June 4, 2012, from http://resources.venus-c.eu.

Foster, I. et al., (2007). OGSA Basic Execution Service,

Version 1.0, GFD-RP-R-P.108.

Hwang, K., Fox, G., and Dongarra, J. (2011). Distributed

and Cloud Computing: From Parallel Processing to

the Internet of Things, Morgan Kaufmann Publishers.

Livenson, I. and Laure, E. (2011). Towards Transparent

Integration of Heterogeneous Cloud Storage

Platforms, Proceedings of the Fourth International

Workshop on Data-Intensive Distributed Computing.

MCR (MATLAB Runtime Compiler). Retrieved October

24, 2011, from http://www.mathworks.com/products/

compiler.

Microsoft Windows Azure. Retrieved July 24, 2012, from

http://www.microsoft.com/windowsazure.

MPI (Message Passing Interface). Retrieved April 7, 2011,

from http://www.mcs.anl.gov/research/projects/mpi/.

PSPM (Parallelized SPM). Retrieved April 7, 2011, from

http://prdownloads.sourceforge.net/parallelspm/.

Savva, A. (Editor), (2005). Job Submission Description

Language (JSDL) Specification. Version 1.0.

SPM (Statistical Parametric Mapping). Retrieved April 7,

2011, from http://www.fil.ion.ucl.ac.uk/spm/.

VENUS-C Deliverable D6.1, (2011). Report on

Architecture, http://www.venus-c.eu.

VENUS-C FP7 Project, (2010). Grant Agreement No.

261565, http://www.venus-c.eu.

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

336
