Semantic XML Filtering on Peer-to-Peer Networks using Distributed

Bloom Filters

Panagiotis Antonellis, Stavros Kontopoulos, Christos Makris, Yannis Plegas and Nikos Tsirakis

Department of Computer Engineering and Informatics, University of Patras, Patras, Greece

Keywords: XML Filtering, Distributed Processing, Peer-to-Peer Networks, Bloom Filters, Semantic Filtering, Word

Sense Disambiguation.

Abstract: Information filtering systems constitute a critical component in modern information seeking applications.

As the number of users grows and the information available becomes even bigger it is imperative to employ

scalable and efficient representation and filtering techniques. Typically the use of XML representation

entails the profile representation with the use of the XPath query language and the employment of efficient

heuristic techniques for constraining the complexity of the filtering mechanism. However, as the number of

XML documents exchanged daily grows rapidly, the need for distributed management is becoming vital. In

this paper we introduce the Distributed Bloom Filters and we propose a new distributed XML filtering

system for peer-to-peer (P2P) networks. The major advantage of Distributed Bloom Filters, in comparison

to the classical structure is their space efficiency and improved performance. The proposed system

efficiently filters the incoming XML documents using a virtual index created on top of the network. In

addition, the proposed system supports semantic disambiguation of both the stored user profiles and the

XML documents, thus providing better matching results.

1 INTRODUCTION & RELATED

WORK

Information filtering systems (Aguilera et al., 1999)

are systems that provide two main services:

document selection and document delivery. Lately,

there have appeared (Antonellis et al., 2009),

(Miliaraki and Koubarakis, 2010), (Ning and Liu,

2010) a number of systems that use XML

representations for both documents and user profiles

and that employ various filtering techniques to

match the XML representations of user documents

with the provided profiles. Among the growing

amount of objects shared by P2P applications there

is an increasing number of XML-documents that is

being shared among peers. There are a number of

search engines for P2P networks such as the DHT-

based systems of (Bender et al., 2005) and (Podnar

et al., 2007). However, none of these approaches

supports XML-Retrieval techniques.

In this work, we introduce the idea of Distributed

Bloom Filters, which utilize the fast lookups of

Bloom Filters (Bonomi et al., 2006a), (Bonomi et

al., 2006b), with the advantage of the distributed

storage which reduces the storage overhead in each

network peer and at the same time improves the

performance. Based on the Distributed Bloom

Filters, we present a new P2P system that supports

semantic filtering of the incoming XML documents.

The main contributions of our work are:

 Introduction of Distributed Bloom Filters and

efficient indexing using them.

 Efficient distribution of the user profiles in the

network's peers.

 Word disambiguation of the tags of the stored user

profiles and the incoming XML documents for

supporting semantic filtering.

2 DISTRIBUTED BLOOM

FILTER

Let BF be a Bloom Filter of m bits. In order to

reduce the space overhead per peer and also improve

the membership check performance, we introduce

the idea of Distributed Bloom Filter. The bloom

filter will be stored in p peers, so we cut the bit array

of the bloom filter in p segments with c bits each.

133

Antonellis P., Kontopoulos S., Makris C., Plegas Y. and Tsirakis N..

Semantic XML Filtering on Peer-to-Peer Networks using Distributed Bloom Filters.

DOI: 10.5220/0004363301330136

In Proceedings of the 9th International Conference on Web Information Systems and Technologies (WEBIST-2013), pages 133-136

ISBN: 978-989-8565-54-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Let





,,.., ,

Oooo On

, be the set of the objects

that are tested for membership by the bloom filter

data structure. Let

, ,...,

hh h

be the set of hashing

functions used by the bloom filter. For each object j

we define the ordered sequence

as:

(){(),(),...,()}

jj j j kj

HO hO hO hO .

We now split the result bit sequence of each hash

function h

into p segments and identify which

segments contain at least one bit set to 1. Based on

this, we define the following sequences:







ii i

ij p

p bits

hs O b b b 



 

, where



b is set to 1 if the





sequence sets at

least one bit of the



-th segment, otherwise is set to

0. From that set we can define the ordered

sequence:

  

{, ,, }

jjjkj

WhsOhsO hsO 

Next we apply a hashing function on













({ , ,, })

jjjkj

hash W hs O hs O hs O IDj

We use the IDj as an indexing value for an object

on a DHT based network. After inserting all the

objects into the Distributed Bloom Filter, the bit

sequence is split into p segments and distributed into

p different peers to reduce the space overhead and

also increase the speed efficiency. We call this new

data structure: M-DBF.

3 SEMANTIC XML FILTERING

ON P2P NETWORKS

We employ the Distributed Bloom Filter in order to

design a new distributed semantic XML Filtering

system, which can work on top of any DHT peer-to-

peer network. Moreover we enhance the whole

scheme by embedding semantic techniques based on

WordNet (Miller et al. 1990). The proposed system

works as follows:

 It clusters the user profiles using the k-Means

algorithm.

 It distributes the user profiles in the network's

peers based on the belonging cluster.

 It utilizes a multi-level index, following the

approach described in (Antonellis et al, 2009), based

on M-DBFs

 It performs word sense disambiguation of the tags

of the stored user profiles and incoming XML

documents.

3.1 Profile Clustering and Distribution

The clustering of the initial set of user profiles is

performed once in a central server, before

initializing our system. The utilized clustering

algorithm is the k-Means algorithm in conjunction

with the distance metric described in (Antonellis and

Makris, 2008b) for calculating the distance between

a pair of user profiles.

The underlying P2P network is divided into

neighbourhoods, with each neighbourhood storing

the user profiles of a single cluster, and with each

neighbourhood consisting of physical neighbour

peers. In order to optimize the filtering performance

as well as the update operations on the stored user

profiles, each neighbourhood is organized in a two-

level hierarchy, as described in the Section 3.2. For

every formed cluster, an M-DBF is constructed,

called Cluster MDBF, that stores all the distinct

paths contained in the user profiles of that cluster.

3.2 Distributed Indexing Scheme

The proposed system utilizes a distributed

hierarchical indexing system, as seen in figure 1.

Each network neighbourhood is consisted of

physically close nodes and it is responsible for

storing and handling the user profiles of a single

cluster.

Figure 1: Distributed Indexing Scheme.

The low-level peers of a neighbourhood

are

called leaf peers and are used for actually storing the

XML documents of the i-th cluster, while the top

level peers are called control peers and are used for

query routing through the current neighbourhood as

well as through different neighbourhoods in the

network.

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

134

A control peer is responsible for a subset of the

leaf peers in

, called its leaf subset peers and the

total number of control peers is much smaller than

the total number of leaf peers. The control peers of

each neighbourhood know all their leaf subset peers

and can redirect any query to all of them. On the

other hand, the leaf peers know only their control

peer as well all their sibling leaf peers. All the

control peers of the network are organized in a

multi-level indexing scheme inspired by VBI-tree

(Jagadish et al., 2006).

3.3 XML Document Filtering

The XML filtering process of the proposed system

utilizes the previously described indexing structure

to efficiently forward the incoming XML documents

to the appropriate control peers of the

neighbourhoods that are possible to match the

document. When an XML document is submitted to

a peer p

of the network, the peer p

is automatically

responsible for processing and filtering the

submitted document. Firstly, it checks its LBF to

see if the XML document is likely to match with any

of its user profiles. If so, it performs a full filtering

against all its stored user profiles using the XFIS

(Antonellis and Makris, 2008a) filtering algorithm

and stores the results in its cache. Then, it forwards

the XML document to its parent control peer for

further routing. The control peer uses the VBI-tree

to forward the XML document to any other control

peer which its M-DBF matches with the XML

document.

Every peer that matches any of its user profiles

with the incoming XML document propagates the

results back to the original peer, because this peer is

responsible for gathering the total filtering results.

3.4 Word Sense Disambiguation

In the proposed system, the textual information of

XML documents is semantically-enriched with the

support of WordNet (Miller et al, 1990). WordNet is

a lexical online ontology including over 110,000

concepts. The related concepts are grouped into sets

of synonyms which are called synsets. Each synset

represents a lexical concept and is described by a

short textual description the gloss. A synset

represents a lexical meaning, or sense, which can be

assigned to multiple terms.

Our main purpose is the word sense

disambiguation of the tags occurring in a given path,

and the assignment of unique senses to each tag.

That way, our system will be able to find related

user profiles with the incoming document, even

though they do not use exactly the same tags. Word

sense disambiguation (WSD) governs the process of

identifying which sense of a word is used, when the

word has multiple meanings. Initially, we identify all

the different senses of a term. The next step is the

selection of the most appropriate sense for the

respective term. The process which was followed

was a dictionary-based WSD and was handled using

the lexical knowledge base of WordNet. WordNet

provides the texts of the senses definitions (glosses)

and gives us the opportunity to adapt the assumption

that the most plausible sense to assign to a term with

multiple senses is the one that maximizes the

semantic relatedness among the senses.

The semantic similarity between two senses is

computed using two different approaches. The first

approach employs as similarity metric the Wu and

Palmer (Budanitsky and Hirst, 2006):

((,))

(, )

() ( )

depth LCA c c

similarity c c

depth c depth c





The second approach which is also used in

(Tagarelli et al., 2009) has been formalized in a

measure of semantic relatedness between word

senses based on the notion of extended gloss overlap

(Patwardhan et al., 2003), and has the merit of

considering phrasal matches and weighting them

more heavily than single word matches.

4 EXPERIMENTS

We have built a prototype P2P emulator to evaluate

the performance of our proposed filtering system

over large-scale networks.

4.1 Varying Number of Network Peers

In this experiment, we wanted to study the

relationship between the number of peers in the

network and the number of hops required for each

query to be processed. Thus, we created 8 clusters of

totally 1500000 user profiles which were distributed

in 50000, 100000, 200000 and 500000 peers in the

network. For each case we counted the average

number of hops for each query in the query set. The

experimental results are shown in

Table 1.

4.2 Semantic Disambiguation of XML

Tags

In this experiment, we evaluated the precision and

SemanticXMLFilteringonPeer-to-PeerNetworksusingDistributedBloomFilters

135

speed of the proposed semantic disambiguation

during XML filtering, in comparison with the

technique described in (Tagarelli et al., 2009). We

have used a set of 50000 and 100000 stored user

profiles and 45000 incoming XML documents for

testing. The results are displayed in

Table 2.

Table 1: Number of hops.

#Peers

#Total

hops

#Neighbou

r hops

#Routin

g hops

Perc.

50000 6834 5391 1443 13.6%

100000 10351 8280 2071 10.3%

200000 12179 9778 2401 6.1%

500000 14260 11323 2937 2.8%

Table 2: Precision and time of XML tag disambiguation

(A: our approach, B: Tagarelli's approach).

#Profiles Precision A Time A Precision B Time B

5000 85% 1291s 90% 1972s

10000 82% 2189s 88% 3281s

As we can easily observe, our approach performs

very well, achieving an average precision of about

84%. In addition, due to the simplicity of our

approach, the required time for the disambiguation is

much smaller (about 30% faster).

AKNOWLEDGEMENTS

This research has been co-financed by the European

Union (European Social Fund – ESF) and Greek

national funds through the Operational Program

"Education and Lifelong Learning" of the National

Strategic Reference Framework (NSRF) - Research

Funding Program: Thales. Investing in knowledge

society through the European Social Fund.

This research has been co-financed by the

European Union (European Social Fund-ESF) and

Greek national funds through the Operational

Program "Education and Lifelong Learning" of the

National Strategic Reference Framework (NSRF)-

Research Funding Program: Heracleitus II. Investing

in knowledge society through the European Social

Fund.

REFERENCES

Abiteboul, S., Manolescu, I., Polyzotis, N., Preda, N. and

Sun, C. XML processing in DHT networks.

ICDE,

2008.

Antonellis, P. and Makris, C. XFIS: An XML filtering

system based on string representation and matching.

International Journal on Web Engineering and

Technology (IJWET)

, 4(1), 70-94, 2008.

Antonellis, P. and Makris, C. XML Filtering Using

Dynamic Hierarchical Clustering of User Profiles.

DEXA, 537-551, 2008.

Antonellis, P., Makris, C. and Tsirakis, N. Utilizing XML

Clustering for Efficient XML Data Management on

P2P Networks.

DEXA, 68-82, 2009.

Aguilera, M. K., Strom, R.E., Stunnan, D. C., Astley, M.

and Chandra, T. D. Matching events in a content-

based subscription system.

PODC, 53–61, 1999.

Bender, M., Michel, S., Weikum, G. and Zimmer, C. The

MINERVA Project - Database Selection in the

Context of P2P Search.

BTW Conference, 2005.

Bonomi, F., Mitzenmacher, M., Panigrahy R., Singh S.

and Varghese G. An Improved Construction for

Counting Bloom Filters.

ESA, 684-695, 2006.

Bonomi, F., Mitzenmacher M., Panigrahy R., Singh S.

and Varghese G. Beyond bloom filters: from

approximate membership checks to approximate state

machines. SIGCOMM , 315-326, 2006.

Budanitsky, A. and Hirst, G. Evaluating WordNet-based

measures of lexical semantic relatedness. Association

for Computational Linguistics

, 32, 32-47, 2006.

Jagadish, H. V, Ooi, B. C., Vu, Q. H, Zhang, R. and Zhou.

A. VBI-Tree: a Peer-to-Peer Framework for

Supporting Multi-Dimensional Indexing Schemes.

ICDE, 2006.

Miliaraki, I. and Koubarakis, M. Distributed structural and

value XML filtering. 4th ACM International

Conference on Distributed Event-Based Systems

, 2–

13, 2010.

Miller, G. A., Beckwith, R., Fellbaum, C. D., Gross, D.

and Miller. K. WordNet: An online lexical database.

Int. J. Lexicograph, 3(4), 235-244, 1990.

Ning, B. and Liu, C. XM filtering with XPath expressions

containing parent and ancestor axes.

Information

Sciences

, Elsevier, 210 (Nov. 2010), 41-54, 2010.

Patwardhan, S., Banerjee, S., and Pedersen, T. Using

measures of semantic relatedness for word sense

disambiguation.

In Proceedings of the International

Conference on Intelligent Text Processing and

Computational Linguistics (CICLing)

. 241–257, 2003.

Podnar, I., Rajman, M., Luu, T., Klemm, F. and Aberer,

K. Scalable Peer-to-Peer Web Retrieval with Highly

Discriminative Keys.

ICDE, 2007.

Tagarelli, A. and Greco, S. Semantic clustering of xml

documents. ACM Transactions on Information

Systems,

28 (1), 1-56, 2010.

Tagarelli, A., Longo, M. and Greco S. Word Sense

Disambiguation for XML Structure Feature

Generation.

In Proceedings of the 6th European

Semantic Web Conference on The Semantic Web:

Research and Applications

, 2009.

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

136
