Length of Phonemes in a Context of their Positions in Polish Sentences

Magdalena Igras, Bartosz Zi´ołko and Mariusz Zi´ołko

Department of Electronics, AGH University of Science and Technology,

al.Mickiewicza 30, 30-059 Krak´ow, Poland

Keywords:

Phoneme Statistics, Spoken Language Processing, Polish.

Abstract:

The paper presents statistical phonetic data of Polish collected from a corpus. Lengths of phonemes vary from

5 ms to 670 ms. Average durations of Polish phonemes are presented as well as an important anomaly of

longer phonemes in the end of sentences, which is the main topic of the paper. This observation can be used

in speech recognition for automatic insertation of dots and sentence modelling. Data of 45 speakers, 5130

sentences in total, were described and compared with the values taken from the phonetic literature.

1 INTRODUCTION

The linguistic knowledge and statistic parameters

are important part of speech technology applica-

tions. Phoneme durations could be used effectively

in speech modelling (Zi´ołko and Zi´ołko, 2011), for

both, text to speech (Febrer et al., 1998) and speech

to text systems (Linares et al., ; Pylkk¨onen and Ku-

rimo, 2004). The segmentation combined with recog-

nition could improve both processes, i.e. segmenta-

tion could be reset, if the recognised phoneme is of

much different duration than its expected statistical

length. Segmentation and acoustic modelling meth-

ods to locate phoneme boundaries in speech with un-

known content (Glass, 2003), (Zi´ołko et al., 2011)

were published.

Parameter of phoneme length is also often used in

prosodic models for systems of automatic detection of

punctuation and segmentation into sentences or topics

(Shriberg et al., 2000; Kol´aˇr et al., 2004; Baron et al.,

2002; Christensen et al., 2001) for other languages.

Shriberg and Stolcke (Shriberg et al., 2000) use phone

length normalization by phone speciﬁc values (means

and standard deviations) and suggested also normal-

ization of triphones duration.

It was observed that speakers usually tend to slow

down their speech toward the ends of utterance units.

Rate of speaking depends on individual characteris-

tics of a person, but typically the last phonemes in

a sentence are much longer (Demenko, 1999). Also

for automatic punctuation annotation in Czech (Kol´aˇr

et al., 2004) the phenomenon of preboundary length-

ening is applied (only for vowels) described by fol-

lowing parameters: average duration of vowels, du-

ration of the ﬁrst and last vowel and duration of the

longest and shortest vowel. The phenomenon was de-

scirbed for Hungarian (Hockey and Fagyal, 1999) and

Japanese (Shepherd, 2011) as well.

For Polish there are few published research on

phonemes length modelling in a sentence. Some

segmental features of vowels were investigated in

logatomes (Frackowiak-Richter, 1973). Demenko

(Demenko, 1999) described detailed analysis of cor-

relations between place in a phrase and phonemes du-

ration inﬂuenced by accent and intonational context.

The research showed that in Polish last and one be-

fore the last vowel in a sentence is lenghtened regard-

less of accent presence, but the effect of lenghtening

is stronger for accented syllables.

2 PHONEME SEGMENTATION

Constant-time segmentation, i.e. framing into 23.2

ms blocks (Young, 1996), is frequently used to di-

vide the speech signal for digital processing. This

method beneﬁts from simplicity of implementation

and results in an easy comparison of blocks, which

are of the same time duration. Anyway, the uniform

segmentation is perceptually unnatural, because the

duration of phonemes varies signiﬁcantly.

Human phonetic categorisation is very poor for

short segments (Morgan et al., 2005). Moreover,

boundary effects provide additional distortions (par-

tially reduced by applying the Hamming window),

and such short segments create many more bound-

aries than there are between phonemes in the acoustic

signals. The boundary effects can cause difﬁculties in

Igras M., Ziółko B. and Ziółko M..

Length of Phonemes in a Context of their Positions in Polish Sentences.

DOI: 10.5220/0004503500590064

In Proceedings of the 10th International Conference on Signal Processing and Multimedia Applications and 10th International Conference on Wireless

Information Networks and Systems (SIGMAP-2013), pages 59-64

ISBN: 978-989-8565-74-7

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

speech recognition systems.

Additional difﬁculties appear when two phonemes

are mixed in a single frame. Moreover, the contextual

connections between neighbouring phonemes make

frequency properties of the begining and the end of

phonemes extremely irregular. A smaller number of

boundaries means a smaller number of errors due to

the effects described above. Constant segmentation

therefore, while straightforward, risks losing valuable

information about the phonemes due to the merging

of different sounds into a single block. Moreover, the

complexity of individual phonemes cannot be repre-

sented in short frames.

The length of a phoneme can be also used as an

additional parameter in speech recognition improving

the accuracy of the whole process. The phoneme du-

rations can also help in locating ends of sentences.

The system has to know the expected duration of all

phonemes to achieve the greater efﬁciency.

A number of approaches have been suggested

(Zi´ołko et al., 2011; St¨ober and Hess, 1998; Gray-

den and Scordilis, 1994; Weinstein et al., 1975; Zue,

1985; Toledano et al., 2003) to ﬁnd phoneme bound-

aries from the time-varying speech signal properties.

These approaches utilise features derived from acous-

tic knowledge of the phonemes. For example, the

solution presented in (Grayden and Scordilis, 1994)

analyses different spectra subbands in the signal. Dis-

crete wavelet transform was also applied for phoneme

segmentation task (Zi´ołko et al., 2011). Phoneme

boundaries are extracted by comparing the fractions

of signal power in different subbands. Artiﬁcial neu-

ral networks (Suh and Lee, 1996) have also been

tested, but they require long training. Segmentation

can be applied by the segment models (Ostendorf

et al., 1996; Russell and Jackson, 2005) by searching

paths through sequences of frames of different lengths

instead of using traditional hidden Markov models.

The Toledano et al. (Toledano et al., 2003) approach

is based on spectral variation functions. Such meth-

ods need to be optimised for particular phoneme data

and cannot be performed in isolation from phoneme

recognition itself.

3 EXPERIMENTAL DATA

The statistics were collected from CORPORA, created

under supervision of Stefan Grocholewski in Institute

of Computer Science, Pozna´n University of Technol-

ogy (Grocholewski, 1997). Speech ﬁles in CORPORA

were recorded with the sampling frequency f

= 16

kHz.

The part of the database, which we used, con-

tains 114 short sentences, each spoken by 45 males,

females and children giving 5130 utterances totally.

Some part was hand segmented. The rest were seg-

mented by a dynamic programming algorithm which

was trained on hand segmented one and based on tran-

scriptions and manually checked afterwards.

4 STATISTICS COLLECTION

The phoneme duration statistics were collected from

MLF (Master Label Files) attached to CORPORA.

MLF is a standard solution, used for example in HTK

(Young et al., 2005). MLFs are deﬁned as index ﬁles

holding pointers to the actual label ﬁles which can ei-

ther be embedded in the same index ﬁle or stored any-

where else (Young, 1996).

The description starts with name of an audio ﬁle-

name. Phoneme transcriptions are given (starting

time, end time, a phoneme description) in following

lines. The format ends with a dot. A basic time unit

in this standard is 0.1 µs. The example of a part of an

MLF from CORPORA is as follows:

”*/jc1m1001.lab” 7900000 8550000 a

0 100000 sil 8600000 9600000 sz

150000 850000 l 9650000 10300000 o

900000 1500000 u 10350000 10900000 w

1550000 2200000 b 10950000 11650000 y

2250000 2950000 i 11700000 12750000 p

3000000 3950000 si 12800000 13350000 l

4000000 5350000 cz 13400000 15450000 a

5400000 6400000 a 15500000 17850000 s

6450000 7150000 r 17900000 17950000 sil

7200000 7850000 d .

5 PREBOUNDARY

LENGHTENING

For analysis of the phenomenon of lenghtening

phonemes in the end of sentence, we used 5130 sen-

tences from CORPORA. Then each phoneme length

was normalized by calculating ratio of phoneme

length divided by mean length of the phoneme in

the whole database. For each position i in each sen-

tence we computed the mean value (µ) and standard

deviation (σ) of the ratios dynamically, as the mean

of ratios from position i=1 to the current i-th posi-

tion. Then we veriﬁed, for which sentences the cur-

rent value of µ, µ+ σ, µ+ 2σ and µ+ 3σ was exceeded

by latest one, two, three or four phonemes in the sen-

tence. We checked also for which sentence the thresh-

olds were crossed before the end of the sentence.

SIGMAP2013-InternationalConferenceonSignalProcessingandMultimediaApplications

Table 1: Average duration of Polish phonemes (in brackets divided by sum of all average durations) with notations from

CORPORA (Grocholewski, 1997) and SAMPA (Demenko et al., 2003), standard deviations and ratio between deviation and

average, No - number of appearance, µ - average[ms](%), dev - standard deviation.

CORPORA SAMPA No µ[ms](%) dev

dev

example transcription

e e j∼ 963 181 (4.46) 64 0.35 ge¸´s ge∼s’

a o w∼ 2 293 171 (4.21) 59 0.35 cia¸˙za ts’ow∼Za

sz S 27 49 155 (3.82) 63 0.41 szyk SIk

s s 4 251 134 (3.30) 48 0.36 syk sIk

si s’ 2 117 131 (3.23) 49 0.37 ´swit s‘vit

a a 18 827 130 (3.20) 51 0.39 pat pat

c ts 2 514 129 (3.18) 44 0.34 cyk tsIk

ci ts’ 1 880 127 (3.13) 45 0.35 ´cma ts’ma

cz tS 1 670 126 (3.10) 43 0.34 czyn tSIn

f f 3 038 125 (3.08) 67 0.54 fan fan

zi z’ 1 449 118 (2.91) 36 0.31 ´zle z’le

e e 13 034 113 (2.78) 51 0.45 test test

drz dz’ 853 111 (2.73) 42 0.38 d˙zem dZem

rz Z 2 378 108 (2.66) 32 0.30 ˙zyto ZIto

z z 2 489 108 (2.66) 35 0.32 zbir zbir

dz dz 509 105 (2.59) 30 0.29 dzwo´n dzvon’

o o 10 844 105 (2.59) 37 0.35 pot pot

h x 2 383 102 (2.51) 46 0.45 hymn xImn

t t 5 874 102 (2.51) 56 0.55 test test

u u 5 444 101 (2.49) 46 0.46 puk puk

dzi dZ 1 229 100 (2.46) 29 0.29 d´zwig dz’vik

k k 4 879 98 (2.41) 49 0.5 kit kitk

i i 7 106 95 (2.34) 40 0.42 PIT pit

p p 3 191 94 (2.32) 42 0.45 pik pik

n n 8 254 94 (2.32) 42 0.45 nasz naS

y I 5 533 90 (2.22) 46 0.51 typ tIp

b b 3 103 88 (2.17) 28 0.32 bit bit

m m 6 201 87 (2.14) 34 0.39 mysz mIS

g g 2 542 84 (2.07) 29 0.35 gen gen

d d 3 690 84 (2.07) 30 0.36 dym dIm

N N 279 83 (2.04) 25 0.30 pe¸k peNk

w v 3 973 83 (2.04) 31 0.37 wilk vilk

j j 7 067 83 (2.04) 35 0.42 jak jak

l w 4 662 80 (1.97) 36 0.45 łyk wIk

ni n’ 3 106 78 (1.92) 35 0.45 ko´n kon’

r r 6 657 76 (1.87) 35 0.46 ryk rIk

l l 5 707 74 (1.82) 33 0.45 luk luk

5.1 Phonemes Duration

In total, 163 274 cases of Polish phonemes uttered

by 45 speakers were analyzed. The statistics of

phonemes durations are presented in Tab. 1, in de-

scending order of the mean duration.

CORPORA transcriptions are based on SAMPA

notation with 37 symbols. Letters e¸ and a¸ are phonet-

ically transcribed as e

and a in CORPORA. How-

ever, each of these letters should be actually repre-

sented by two phonemes: e¸ should be e j∼ and a¸

should be o w∼. We decided to keep them together

as they are in the corpus, because we are not able to

detect these extra boundaries precisely enough. This

is why e

and a are the longest in Tab. 1. Each of

them represents two phonemes, actually.

Then, we investigated probability distribution of

the proportions of the duration of phonemes (exam-

ple presented in Fig. 1) which appeared not to be

Gaussian because of many much longer phonemes.

The source of this anomaly is probably in longer

phonemes in the end of sentences. The visual presen-

tation of mean durations of phonemes from the whole

database with their standard deviations are presented

in Fig. 2.

LengthofPhonemesinaContextoftheirPositionsinPolishSentences

0 100 200 300 400 500 600 700

500

1000

1500

2000

2500

3000

3500

4000

Durations of phoneme "a" [ms]

No of appear.

0 50 100 150 200 250 300 350 400

200

400

600

800

1000

1200

Durations of phoneme "r" [ms]

No of appear.

0 50 100 150 200 250 300 350 400 450

100

150

200

250

No of appear.

Durations of phoneme "sz" [ms]

Figure 1: Probability distribution of the durations of exam-

ple phonemes.

l r nil_ j Nw d g mb y n p i kdziu h t dzo rz zdrze zi f czci c a si ssza_e_

100

150

200

250

Phonemes

Mean durations of phonemes and their standard deviations [ms]

Figure 2: Mean durations and their standard deviations of

phonemes from the whole database.

5.2 Phonemes Duration in Correlation

with the Position in the Sentence

The weighted average of phoneme duration in the

whole database was 104 ms. The average durations

vary from 74 ms to 181 ms. Duration of phonemes is

changeable and depends on speech ratio, type of ut-

terance, localisation in a syllable and accents (Wierz-

chowska, 1980). A ratio between durations of differ-

ent phonemes is quite constant. The longest ones are

and a . Then a, o and e are a bit shorter. Phonemes

i, y, u follow them. Next, n and m are average ones

with r a bit shorter. Phonemes l and l

are even shorter

and j is the shortest one. A general rule is that a dura-

tion is bigger for phones, for which a bigger number

of parts of vocal tract are necessary to be used (Wierz-

chowska, 1980).

It corresponds a bit to our results but not com-

pletely. Phonemes e

and a are indeed the longest

ones in both descriptions. We found that a and e are

long, as described in (Wierzchowska, 1980) but o is

average. We realised that i, u are expected to be quite

long (Wierzchowska, 1980) but in CORPORA they

are of average duration. Phoneme y is even shorter,

however, (Wierzchowska, 1980) claims it should be

long. Phonemes n and m are quite average as stated in

(Wierzchowska, 1980). Phoneme r was found by us

as a short phoneme what is in a contrast with (Wierz-

chowska, 1980). The experiment supports the opinion

from (Wierzchowska, 1980) that l, l

and j are short.

The standard deviations of our results are gener-

ally high. The ratio between standard deviation and

average duration vary and is between 0.29 and 0.68.

Phonemes t, f, y, k, r, u, e, h, l

, ni (CORPORA no-

tation) have relativelly high standard deviations. It

is probably a result of different ways of pronouncing

these phonemes by different people. The ratio of a

standard deviation to an average value is lowest for

phonemes dz, dzi, rz, N, zi, b, z, c.

There are some similar data in (Jassem, 1973).

However, it does not present a complete list of

phonemes durations. It givessome examples like that:

a transient can be up to 50 ms, t around 100 ms and

Table 2: The percentage of phonemes much longer than the

average for particular class according to its localisation in a

sentence (b.f. - before last).

Location in

sentences

Threshold µ+

0 σ 2σ 3σ

The last phoneme 89.5 67.6 37.2 9.5

The one b. l. 65.6 27.8 2.9 0.0

The second b. l. 66.2 29.7 0.2 0.0

The third b. l. 60.3 22.6 0.0 0.0

Any other 97.8 65.9 2.5 0

SIGMAP2013-InternationalConferenceonSignalProcessingandMultimediaApplications

0 0.5 1 1.5 2 2.5 3 3.5 4

100

200

300

400

500

600

No of appear.

Ratios of the last phoneme duration

Figure 3: Probability distribution of the proportions of

the last phoneme duration in the sentences to the mean

phoneme durations.

k r o ci o w y h s u m ni e rz a l m i

0.5

1.5

Ratios of phonemes durations

k r o ci o w y h s u m ni e rz a l m i

0.5

1.5

Ratios of phonemes durations

Figure 4: Example phoneme durations within a sentence

(blue squares) with a dynamic average of the ratio (red line

with standard deviations as column markers).

r usually 20 ms. Again, some of these values corre-

sponds to our results, like transient to a short pause

and phoneme t, but not all of them, like r, which is

one of the shortest in our list, but its duration is 63 ms

rather than 20 ms.

To ilustrate the tendency to lenghten phonemes in

l u b i ci cz a r d a sz o w y p l a_ s

0.5

1.5

Ratios of phonemes durations

l u b i ci cz a r d a sz o w y p l a_ s

0.5

1.5

Ratios of phonemes durations

Figure 5: Example phoneme durations within a sentence

(blue squares) with a dynamic average of the ratio (red line

with standard deviations as column markers).

the end of a sentence, the percentage of phonemes

much longer the average for particular class accord-

ing to its localisation in a sentence was computed (see

Table 2). It shows that for almost 90% of investi-

gated sentences, the last phoneme durations exceeds

the mean of antecedent phonemes ratios, while for

majority of the sentences - it crossed also µ+σ thresh-

old. Mean value of ratios of last phoneme duration in

reference to the mean duration of the phoneme in the

database was 1.35 (with standard deviation 0.42). Its

probability distribution is presented in Figure 3. Sev-

eral examples of sentences that illustrate the changes

of the relative durations and their dynamic mean were

presented in Fig. 4 and 5.

6 CONCLUSIONS

Statistics of phoneme durations in Polish were pre-

sented and compared with literature. The concept

of applying them for sentence modelling was consid-

ered and evaluated. Around 37% of sentence ends

LengthofPhonemesinaContextoftheirPositionsinPolishSentences

can be detected by analysis of phoneme length with

only around 2.5% rate of false detections because

phonemes in the sentence ends tend to be longer then

other ones.

ACKNOWLEDGEMENTS

The project was funded by the National Science

Centre allocated on the basis of a decision DEC-

2011/03/D/ST6/00914.

REFERENCES

Baron, D., Shriberg, E., and Stolcke, A. (2002). Auto-

matic punctuation and disﬂuency detection in multi-

party meetings using prosodic and lexical cues. pages

949–952.

Christensen, H., Gotoh, Y., and Renals, S. (2001). Punctua-

tion annotation using statistical prosody models. In in

Proc. ISCA Workshop on Prosody in Speech Recogni-

tion and Understanding, pages 35–40.

Demenko, G. (1999). Analiza cech suprasegmentalnych

je¸zyka polskiego na potrzeby technologii mowy [Eng.

Analysis of Polish Suprasegmentals for Suprasegmen-

tals for Speech Technology]. Seria Je¸zykoznawstwo

stosowane. Wyd. Naukowe Uniw. im. Adama Mick-

iewicza.

Demenko, G., Wypych, M., and Baranowska, E. (2003).

Implementation of grapheme-to-phoneme rules and

extended SAMPA alphabet in Polish text-to-speech

synthesis. Speech and Language Technology, PTFon,

Pozna´n, 7(17).

Febrer, A., Padrell, J., and Bonafonte, A. (1998). Mod-

eling phone duration: Application to catalan tts. In

Proceedings of the Third ESCA/COCOSDA Workshop

on Speech Synthesis. Jenolan Caves, Australia, pages

43–46.

Frackowiak-Richter, L. (1973). The duration of Polish vow-

els. Speech analysis and Synthesis III, PWN.

Glass, J. (2003). A probabilistic framework for segment-

based speech recognition. Computer Speech and Lan-

guage, 17:137–152.

Grayden, D. B. and Scordilis, M. S. (1994). Phonemic seg-

mentation of ﬂuent speech. Proceedings of ICASSP,

Adelaide, pages 73–76.

Grocholewski, S. (1997). CORPORA - speech database for

Polish diphones. Proceedings of Eurospeech.

Hockey, B. A. and Fagyal, Z. (1999). Phonemic length and

pre-boundary lengthening: An experimental investi-

gation on the use of durational cues in hungarian. Pro-

ceedings of the XIVth International Congress of Pho-

netics Sciences, San Francisco.

Jassem, W. (1973). Podstawy fonetyki akustycznej

(Eng. Rudiments of acoustic phonetics). Warszawa:

Pa´nstwowe Wydawnictwo Naukowe.

Kol´aˇr, J.,

Svec, J., and Psutka, J. (2004). Automatic punc-

tuation annotation in czech broadcast news speech.

pages 319–325, Saint-Petersburg. SPIIRAS.

Linares, G., Lecouteux, B., Matrouf, D., and Nocera, P.

Phone duration models for fast broadcast news tran-

scriptions.

Morgan, N., Zhu, Q., Stolcke, A., Sonmez, K., Sivadas,

S., Shinozaki, T., Ostendorf, M., Jain, P., Hermansky,

H., Ellis, D., Doddington, G., Chen, B., Cretin, O.,

Bourlard, H., and Athineos, M. (2005). Pushing the

envelope - aside. IEEE Signal Processing Magazine,

22:81–88.

Ostendorf, M., Digalakis, V. V., and Kimball, O. A. (1996).

From HMM’s to segment models: A uniﬁed view

of stochastic modeling for speech recognition. IEEE

Transactions on Speech and Audio Processing, 4:360–

378.

Pylkk¨onen, J. and Kurimo, M. (2004). Using phone du-

rations in ﬁnnish large vocabulary continuous speech

recognition.

Russell, M. and Jackson, P. J. B. (2005). A multiple-level

linear/linear segmental HMM with a formant-based

intermediate layer. Computer Speech and Language,

19:205–225.

Shepherd, M. (2011). The scope and effects of preboundary

prosodic lengthening in Japanese. In USC Working

Papers in Linguistics, pages 1–14.

Shriberg, E., Stolcke, A., Hakkani-T¨ur, D., and T¨ur, G.

(2000). Prosody-based automatic segmentation of

speech into sentences and topics.

St¨ober, K. and Hess, W. (1998). Additional use of phoneme

duration hypotheses in automatic speech segmenta-

tion. Proceedings of ICSLP, Sydney, pages 1595–

1598.

Suh, Y. and Lee, Y. (1996). Phoneme segmentation of con-

tinuous speech using multi-layer perceptron. In Pro-

ceedings of ICSLP, Philadelphia, pages 1297–1300.

Toledano, D., G´omez, L., and Grande, L. (2003). Automatic

phonetic segmentation. IEEE Transactions on Speech

and Audio Processing, 11(6):617–625.

Weinstein, C. J., McCandless, S. S., Mondshein, L. F., and

Zue, V. W. (1975). A system for acoustic-phonetic

analysis of continuous speech. IEEE Transactions on

Acoustics, Speech and Signal Processing, 23:54–67.

Wierzchowska, B. (1980). Fonetyka i fonologia je¸zyka

polskiego (Eng. Phonetics and phonology of Polish).

Zakład Narodowy im. Ossoli´nskich, Wrocław.

Young, S. (1996). Large vocabulary continuous speech

recognition: a review. IEEE Signal Processing Maga-

zine, 13(5):45–57.

Young, S., Evermann, G., Gales, M., Hain, T., Kershaw, D.,

Moore, G., Odell, J., Ollason, D., Povey, D., Valtchev,

V., and Woodland, P. (2005). HTK Book. Cambridge

University Engineering Department, UK.

Zi´ołko, B., Manandhar, S., Wilson, R. C., and Zi´ołko,

M. (2011). Phoneme segmentation based on wavelet

spectra analysis. Archives of Acoustics, 36(1).

Zi´ołko, B. and Zi´ołko, M. (2011). Time durations of

phonemes in polish language for speech and speaker

recognition. Lecture notes in artiﬁcial inteligence,

6562:105–114.

Zue, V. W. (1985). The use of speech knowledge in auto-

matic speech recognition. Proceedings of the IEEE,

73:1602–1615.

SIGMAP2013-InternationalConferenceonSignalProcessingandMultimediaApplications
