Dynamic Proofs of Retrievability from Chameleon-Hashes

Stefan Rass

Institute of Applied Informatics, Alpen-Adria Universitaet Klagenfurt,

Universitaetsstrasse 65-67, 9020 Klagenfurt, Austria

Keywords:

Cloud Storage, Proofs of Retrievability, Data Availability, Security.

Abstract:

Proofs of retrievability (POR) are interactive protocols that allow a veriﬁer to check the consistent existence

and availability of data residing at a potentially untrusted storage provider, e.g., a cloud. While most POR

protocols strictly refer to static ﬁles, i.e., content that is read-only, dynamic PORs shall achieve the same

security guarantees (existence, consistency and the possibility to retrieve the data) for content that is subject

to an unlimited number of (legitimate) modiﬁcations. This work discusses how to construct such a dynamic

proof of retrievability from chameleon hashes (trapdoor commitments). Like standard POR constructions,

the presented scheme is sentinel-based and does audit queries via spot checking mechanism. Unlike previous

schemes, however, a-posteriori insertions of new sentinels throughout the lifetime of the ﬁle is supported. This

novel feature is apparently absent in any other POR scheme in the literature. Moreover, the system is designed

for compatibility with XML structured data ﬁles.

1 INTRODUCTION

Proofs of retrievability (POR) have been introduced

by (Juels and Kaliski, 2007) and (Lillibridge et al.,

2003) as a tool to verify the existence and consistency

of a remotely stored ﬁle. Having outsourced the ﬁle to

a remote storage server implies that the veriﬁer is no

longer in possession of the actual data, yet uses a POR

to verify that the stored information is still available

and intact. The main challenge for a POR is to achieve

this much more efﬁciently than the trivial approach of

downloading the whole ﬁle. With the rise of cloud

computing services, especially cloud storage, PORs

have received lot of interest over the last years. Most

POR protocols are designed to work with static ﬁles,

i.e., the ﬁle structure and contents are assumed to re-

main unchanged over the lifetime of the ﬁle and any

number of POR executions. Of much more practical

interest are POR protocols that allow for changes (up-

dates) to the stored ﬁle. These have evolved into their

own line of research, called dynamic proofs of retreiv-

ability. While the construction of static POR proto-

cols is rather straightforward, most known dynamic

POR variants are relatively complex and come with

strongly extended security models. This work shows

a construction that naturally ﬁts dynamic proofs of re-

trievability into the same security framework that ap-

plies for static PORs.

The terminology of the POR framework is

strongly aligned to the vocabulary of interactive proof

systems: we have the veriﬁer V , being the ﬁle owner

who has given the data to a server for storage. The

proof of retrievability is carried out between the ver-

iﬁer and the server, called the prover in this context.

This prover is as well the potential adversary. The

”proof” is established by specifying a knowledge ex-

traction algorithm, which unlike its abstract sibling

in the zero-knowledge paradigm, has a quite simple

physical interpretation for a POR: it is precisely the

algorithm that ”downloads” the data whose existence

has been assured a-priori by the interactive part of the

POR (challenge-response cycles).

1.1 Related Work

Besides static and dynamic POR variants, related pro-

tocols can broadly be classiﬁed into bounded- and

unbounded-use schemes, where the former allows

only a limited (large) number of veriﬁcations over the

lifetime of the ﬁle, as opposed to the latter. Bounded

use protocols are sometimes called keyless schemes

(e.g., (Juels and Kaliski, 2007)), where unbounded

use schemes are also known as keyed (e.g., (Shacham

and Waters, 2008; Xu and Chang, 2012), who in ad-

dition also provide protocols with public veriﬁabil-

ity). The work of (Paterson et al., 2012) establishes

a coding-theoretic foundation for static proofs of re-

trievability that uniﬁes keyed and keyless schemes on

296

Rass S..

Dynamic Proofs of Retrievability from Chameleon-Hashes.

DOI: 10.5220/0004505102960304

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 296-304

ISBN: 978-989-8565-73-0

Copyright

c

2013 SCITEPRESS (Science and Technology Publications, Lda.)

common grounds of error correcting encoding. In

fact, it is shown that under the general framework of

a challenge-response protocol which makes up part

of every POR, error-correcting codes can be deﬁned

from a given POR. Conversely, such codes appear as a

major building block of many known POR construc-

tions, and even induce parts of the adversary model,

if the attacker is considered as a noisy channel (Bow-

ers et al., 2009b). It must be emphasized that error-

correcting encoding appears more than advisable in

order to cope with noisy channels, even though those

are not part of the security and adversary model con-

sidered here. The construction in this work will not

explicitly rest on any particular error-correcting code

(ECC), besides applying an ECC for ﬁle storage and

to be consistent with the standard deﬁnition of a POR.

The POR construction described in the following

will be computationally secure. Unconditionally se-

cure schemes for static ﬁles have been given recently

(Dodis et al., 2009). Dynamic proofs of retrievabil-

ity have been studied in (Zheng and Xu, 2011) for

the ﬁrst time, and subsequently in (Cash et al., 2012;

Chen and Curtmola, 2012). The last reference adds

the requirement of robustness, which demands recov-

ery abilities from arbitrary amounts of corruptions

within the data. This is traditionally achieved by for-

ward error-correcting codes. Such best-practice secu-

rity precautions are considered as implicitly done in

the upcoming protocols, thus details are omitted for

the sake of compactness. Most closely related to this

work is (Wang et al., 2011), which as well employs

Merkle-trees to update the ﬁle contents, but uses el-

liptic curve cryptographic primitives to do this, which

is not required here.

Another closely related yet slightly weaker notion

is provable data possession (Ateniese et al., 2007),

which like POR comes in static and dynamic variants

(Ateniese et al., 2008; Erway et al., 2009). How-

ever, and as recognized in the last reference, prov-

ing the possession property is weaker than proving

the retrievability property, due to the extraction algo-

rithm that a POR protocol prescribes but a PDP pro-

tocol does not need (although many PDP protocols

do have a knowledge extractor prescribed implicitly

by their security model deﬁnitions). Other related no-

tions include proofs of storage (Ateniese et al., 2009)

and proofs of ownership (POW) (Halevi et al., 2011).

The latter may be viewed as a ”reverse” direction of

a POR, where it is the veriﬁer who ought to show the

server that a ﬁle has originally been in his possession.

For that reason, the security guarantees achieved by a

POW are weaker than those of a POR.

Finally, it is worth noting that PORs have become

a valuable building block in various recent cloud stor-

age architecture proposals. See (Bowers et al., 2009a;

Resch and Plank, 2011; Stefanov et al., 2012) to get

started.

1.2 Contributions

Two mainstream constructions for a POR are known:

using spot-checks or using homomorphy(cf. (Liu and

Chen, 2011)). In the ﬁrst variant, the veriﬁer embeds

sentinels in the ﬁle that he will later on challenge to

verify the integrity of the ﬁle. The POR details mostly

determine how to create and hide the sentinels in the

ﬁle, so that the prover cannot precompute correct re-

sponses in advance. An example scheme in this class

is (Juels and Kaliski, 2007), and those schemes are

mostly bounded-use. The second line of construction

uses homomorphic primitives (signatures, authentica-

tors, etc.) to have the prover process the entire ﬁle

content in order to correctly respond to a given chal-

lenge. Such schemes often use cryptographic keys

for the processing, and are thus often unbounded-use.

An example from this class is (Shacham and Waters,

2008).

The contribution in this work is the design of a

scheme that falls into neither of these classes. The

construction is essentially sentinel-based, but due to

the dynamic update support lets us introduce new

fresh sentinels over the lifetime of the ﬁle, hence a-

posterior increase the number of possible challenges.

It is therefore referred to as quasi-bounded use (al-

though it is not entirely keyless). Moreover, the

scheme is most straightforwardly suitable for XML

ﬁle storage, and unlike other dynamic POR construc-

tions, can align its data structure to the given ﬁle,

rather than the other way around (as usual for dy-

namic POR).

The Construction in Brief: as in most POR

schemes, the ﬁle owner (veriﬁer) embeds sentinel data

blocks in the ﬁle whose values are stored for sub-

sequent veriﬁcation by spot checking. The idea of

the proposed scheme is to do these spot checks via

requesting hash-values from the ﬁle host (prover),

whilst allowing the blocks to be modiﬁed without al-

tering the hash-values. This requires the veriﬁer’s

ability to ﬁnd hash-collisions, and hence the use of

chameleon-hashes. Combining the latter with a con-

ventional Merkle-hashtree construction then essen-

tially creates a dynamic POR, with the unusual capa-

bility of allowing for a-posteriori sentinel embedding

while the ﬁle resides at the storage provider already.

DynamicProofsofRetrievabilityfromChameleon-Hashes

297

2 DEFINITIONS

A function negl(t) is called negligible, if negl(t) <

1/|p(t)| for every polynomial p and sufﬁciently large

t. Concerning probabilities, we say that a value v is

overwhelming, if 1−v is negligible. The notation xky

denotes an encoding of two strings (or general data

items) x,y into a single string, from which a unique

extraction of x and y is possible (with additional error-

correction if needed). For a partitioning of a ﬁle F

into blocks as F = x

1

k···kx

n

, we refer to a single

block as a record (in alignment with database termi-

nology).

2.1 Structure of a POR

The structure of a POR, as used throughout this

work, is a slight extension (and simpliﬁcation) of

the original POR deﬁnition of (Juels and Kaliski,

2007). The changes concern mostly the addition of

the

update

procedure, and the omission of details

on error-correcting encoding (justiﬁcations follow in-

line).

Setup: this algorithm takes a security parameter

t ∈ N as input and initializes all cryptographic en-

gines (hash-functions, encryptions) by outputting

the respective public and secret parameters.

Encode: this algorithm takes a ﬁle F = x

1

k···kx

n

and encodes in a way that enables subsequent

challenge-response veriﬁcation cycles towards a

proof of retrievability. The process at some stage

involves error-correcting encoding to cover for

channel noise (in (Bowers et al., 2009b), the ad-

versary itself is viewed as a noisy channel, thus

making the encoding the central duty of a POR

protocol. However, this channel noise model may

be questioned to precisely capture an active at-

tacker that essentially does not act randomly).

Error-correctingencoding is assumed to happen at

the veriﬁer’s and/or prover’s side, and further de-

tails on this stage are omitted (although this aspect

is brieﬂy revisited later). The output of

Encode

consists of two data items F

∗

,β, where F

∗

is the

encoded ﬁle submitted to the prover for storage,

and β comprises all information locally stored at

the veriﬁer’s premises.

Challenge: this algorithm takes the current veri-

ﬁer’s information β and outputs a challenge c

i

and

an expected response r

i

.

Verify: the algorithm V

verify

checks a given chal-

lenge c against a response r. If successful, it out-

puts 1, and zero otherwise.

Update: this algorithm takes a record index i and

new record data ex

i

. It interacts with the prover to

replace the existing record x

i

with the new record

ex

i

, and outputs an updated version β

′

of the current

veriﬁer state β.

Extract: this algorithm takes the veriﬁer’s data β

to compute a sequence of challenges c

1

,...,c

n

,

from whose respective responses r

1

,...,r

n

the ﬁle

F

∗′

can be reconstructed (downloaded). This part

of a POR serves two purposes: ﬁrst (and obvi-

ously), we must have some way of accessing the

full lot of stored data from the prover. Second, and

inspired by the construction of interactive proof

systems,

extract

serves as a proof of knowledge

for the proverto demonstrate the possession of the

ﬁle. Notice that this function may as well execute

update queries.

2.2 Chameleon Hashes

A chameleon hash (a.k.a. trapdoor commitment) acts

as a normal hash-function, but allows for efﬁcient

construction of collisions if some secret trapdoor in-

formation is known. The structure will only be out-

lined and illustrated by an example. Full-ﬂedged def-

initions and security proofs are available in (Ateniese

and de Medeiros, 2005).

A chameleon-hash (in a simpliﬁed setting) con-

sists of the following algorithms:

KeyGen: a probabilistic algorithm that takes a secu-

rity parameter t and outputs a public/secret key-

pair (pk, sk).

Hashing: a deterministic algorithm CH that uses

the public-key pk to map a string x ∈ {0,1}

∗

and an auxiliary random value r to a hash

CH

pk

(m,r) ∈ {0, 1}

ℓ

of ﬁxed length ℓ (determined

by the security parameter t).

Forge: a deterministic algorithm that takes the se-

cret key sk, a pre-image (x,r) and its hash-value

CH

pk

(x,r) to produce a second pre-image (y, s)

such that CH

pk

(x,r) = CH

pk

(y,s).

In a full-ﬂedged deﬁnition (see (Ateniese and

de Medeiros, 2005)), the construction of collisions

is referred to as universal forgery, as opposed to the

additional requirement of instance forgery, in which

case we would be given two pre-images and ought to

compute a third one with the same hash. Moreover,all

of the above algorithms would additionally take some

auxiliary inputs. This technical degree of freedom is

not required in the following.

Security of a chameleon hash usually con-

cerns collision-resistance but as well semantic se-

curity, message-hiding and key-exposure freeness.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

298

The interested reader may consult (Ateniese and

de Medeiros, 2005) for details, since the only prop-

erty needed in the following is collision-resistance.

For any probabilistic algorithm A, a hash is said to

be collision-resistant, if the likelihood of A to output

a second pre-image upon given (x,r) and hash-valueh

is negligible in the security parameter. Formally, this

conditional probability is denoted as

Succ

CH

2

(A):= Pr[CH

pk

(y,s) = CH

pk

(x,r)

|(y,s) ← A(x,r, pk)],

where the explicit dependence on A is omitted when-

ever this is clear from the context.

An example construction has been given in (Ate-

niese and de Medeiros, 2005):

KeyGen: Pick two large primes p,q such that p =

u · q + 1, and select a generator element g of

the subgroup of squares of order q. Pick a ran-

dom secret key sk ∈ {1, 2,...,q− 1} and deﬁne

the public-key to be pk = g

sk

MOD p. Choose a

pre-image resistant cryptographic hash function

H : {0,1}

∗

→{0,1}

ℓ

with ℓ ≥ ⌈log

2

p⌉.

Hashing: Choose two random values ρ,δ ∈ Z

q

and

compute e := H(mkρ) and deﬁne the Chameleon

hash as

CH

pk

(m,ρ,δ) := ρ − (pk

e

g

δ

mod p) mod q.

Forge: Let C = CH

pk

(m,ρ,δ) be the known out-

put for which we seek another pre-image. Pick

an arbitrary value m

′

6= m and a random num-

ber k ∈ {1, 2, . . . , q − 1}. Compute the values

ρ

′

= C + (g

k

mod p) mod q, e

′

= H(m

′

kρ

′

) and

δ

′

≡ k − e

′

· sk (mod q). The sought collision is

found at (m

′

,ρ

′

,δ

′

), since

CH

pk

(m

′

,ρ

′

,δ

′

) = ρ

′

− (pk

e

′

g

δ

′

mod p) mod q

= C+

g

k

mod p

−

g

sk·e

′

g

δ

′

mod p

mod q

= C = CH

pk

(m,ρ,δ).

To ease notation, let us henceforth omit the explicit

mentioning of auxiliary randomizers along with the

hash input, and write CH

pk

(m) as a shorthand of

CH

pk

(m,ρ,δ), whenever the randomizers themselves

are of no particular interest.

It is essential for this example hash function, as

well as for the protocol presented in section 3, that

parts of the pre-image constructed by

Forge

can be

chosen freely. This makes the use of randomizers

along with the hash input inevitable.

2.3 Merkle-Hashtrees

Merkle-hashtrees are a widely studied and standard

hashing construction. It is worthwhile to brieﬂy re-

view the idea here, to draw attention to the particular

x

0

x

1

x

2

x

3

x

4

x

5

x

6

x

7

h

0

h

1

h

2

h

3

h

4

h

5

h

6

H

H

HH

HHHH

HHH H HHH

h

7

h

01

h

23

h

45

h

67

h

03

h

47

r

∗

Figure 1: Merkle-tree example.

fact that only O(logn) hashes are required to update

a given hash, if one out of n blocks of the data is re-

placed. This is important in the following.

Assume the data F to be partitioned into n records

as F = x

1

k···kx

n

. For brevity, let us assume that

n is a power of two. Hashing is done by assign-

ing the n blocks to a binary tree of height O(logn),

where each inner node u is assigned the hash-value

H(vkw), whenever v,w are child nodes of v (we asso-

ciate the name of a node with its attached data item

for simplicity). The root-hash is then computed re-

cursively, starting from the leaf nodes that have the

records x

1

,...,x

n

attached to them. Now, suppose that

a single record x

i

is replaced by ex

i

. Then, updating the

root-hash only requires updating the hashes along the

path from ex

i

to the root. For that matter, we require

the hashes of all sibling nodes along the path nodes,

which gives a total of O(logn) hashes for a consistent

change to the data and hash value. Figure 1 illustrates

this for the case of eight records. The labels h

ij

denote

hashes ranging over sets of blocks x

i

,x

i+1

,...,x

j

. As-

suming that we update x

3

, we need only the values

h

2

,h

01

and h

47

(shown bold) along the path from x

3

up to the root, to update the overall hash r

∗

.

2.4 Adversary and Security Model

The original game-based security model and deﬁni-

tion of (Juels and Kaliski, 2007) will be extended,

since the POR construction will explicitly support

modiﬁcations to the stored ﬁle. The adversary A is

composed from two probabilistic algorithms A

setup

and A

resp

. Algorithm A

setup

interacts with an hon-

est veriﬁer V to initialize the POR system, and set

up an archive storing a ﬁle F

∗

in ﬁrst place. To this

end, it is allowed to get challenges and updates from

V . The output of this phase is an archive F

∗

(held by

the prover) and public parameters for the POR proto-

col. In the second phase, A

resp

(as an oracle) responds

to further challenges and updates issued by the veri-

ﬁer, before V ﬁnishes the experiment by extracting

the ﬁle. We consider an attack as successful, if V

DynamicProofsofRetrievabilityfromChameleon-Hashes

299

extracts a ﬁle F 6= F

∗

. This model is formalized via

two experiments, taking a security parameter t for the

setup, and the system parameters α for the challenge-

response phase.

Oracles for the veriﬁer’s functions challenge, up-

date and verify are denoted as V

chal

, V

upd

and V

verify

.

Oracle access to all of the veriﬁer’s functions is abbre-

viated as A

V

. The symbol ←

R

denotes a uniformly

random draw.

Experiment Exp

A

setup

(t)

Experiment Exp

A

chal

(F

∗

,α)

κ ←

KeyGen

(t) action ←

R

{chal,upd}

(F

∗

,α) ← A

V

setup

c ← V

action

(α)

give α to V

r ← A

resp

(F

∗

,α)

output V

verify

(r,α)

Following the security model of (Juels and

Kaliski, 2007), a POR is considered as secure, if any

adversary succeeding in Exp

A

chal

(F

∗

,α) with over-

whelming probability (≥ 1− ζ) cannot trick the veri-

ﬁer into extracting something else than F

∗

. The suc-

cess rate in Exp

A

chal

(F

∗

,α) is denoted as

Succ

A

chal

(F

∗

,α) := Pr

h

Exp

A

chal

(F

∗

,α) = 1

i

.

Now, the security game is the following: the adver-

sary A is assumed to host the ﬁle F

∗

, created during

an execution of Exp

A

setup

(t). The veriﬁer V is given

oracle access to A

resp

and attempts to extract the ﬁle.

The attacker wins if V extracts F 6= F

∗

. The proba-

bility for this not to happen is denoted as

Succ

A

extract

(F

∗

,α) := Pr

h

F = F

∗

|F ←

extract

A

resp

(α)

i

.

Deﬁnition 2.1. We call a POR (ρ,λ)-valid, if for some

value ζ negligible in the security parameter t,

Pr

Succ

A

chal

(F

∗

,α) ≥ λ,

(F

∗

,α) ← Exp

A

setup

(t),

Succ

A

extract

(F

∗

,α) < 1− ζ F ← extract

A

resp

(α)

≤ ρ.

Intuitively, we seek a large value of λ and a small

value of ρ. In that case, with a large likelihood 1 −

ρ, either the ﬁle can be extracted with overwhelming

probability, or the attacker is discovered by virtue of

the challenge-response cycles.

3 THE CONSTRUCTION

The idea is closely related to how sanitizable sig-

natures are designed; using Merkle-hashtrees and

chameleon-hashes to construct a sentinel-based proof

of retrievability. Like the Juels-Kasiski scheme, the

protocol uses sentinels for spot checking, but unlike

this previous proposal, those are not embedded in the

ﬁle. Assume that the ﬁle is organizedin a binary hash-

tree, with leafs corresponding to data chunks, here-

after called records. Let the i-th such record be de-

noted by x

i

, so that the ﬁle is F = x

1

kx

2

k...kx

n

. For

simplicity, let us assume that n is a power of two (to

have the tree full) and think of the ﬁle F as an ordered

set of records. Moreover, assume that the veriﬁer has

selected a (secret) subset S ⊆ {1,2, . ..,n} for subse-

quent POR-challenges.

Encoding. Assume that the ﬁle is encoded in an

error-correcting fashion (see, e.g., (Juels and Kaliski,

2007) or (Bowers et al., 2009b) for detailed justiﬁ-

cations), yielding a sequence of blocks, which we

index by i ∈ S again. Notice that the ECC is ap-

plied separately to each partition x

1

,...,x

n

of the ﬁle,

in order to avoid invalidating parts of a code-word

via a legitimate update operation. The

encode

al-

gorithm chooses a challenge value c

i

for each i ∈ S

and computes the root hash along the tree with the

i-th record being concatenated with c

i

, i.e., it hashes

x

i

kc

i

in place of x

i

to compute the expected correct

response r

i

for the challenge c

i

on record i ∈ S. He

stores the list of all r

i

locally, along with the root-hash

r

∗

= CH

pk

(F) of the original ﬁle F. The ﬁle F is then

given (as is) to the prover (notice that no explicit sen-

tinel information is embodied, as all veriﬁcation data

is stored locally at the veriﬁer’s side).

Challenges. The

challenge

algorithm picks a ran-

dom record index(not necessarily one from S; reasons

will follow below) and submits the challenge (i,c

i

) to

the prover (where c

i

is random if i /∈ S). The prover re-

sponds by re-computing the hash tree using the mod-

iﬁed leaf x

i

kc

i

, and returns the data record x

i

and the

hash-values of all sibling node’s along the path from

x

i

up to the root.

Challenges on the same record cannot be used

more than once, in order to prevent the server from

learning correct responses to a particular record.

However, for the sake of detecting a corruption more

reliably, challenges should be repeated on differ-

ent records during the same audit, i.e., POR execu-

tion. Extensions towards multiple queries on the same

record are discussed in section 5.4.

Veriﬁcations. The

verify

algorithm uses the

prover’s provided hash-values to recompute the root

hash r

′

i

and accepts if either i /∈ S, or if i ∈ S and the

prover responds with r

′

i

= r

i

.

Updates. Observe that we cannot straightforwardly

replace a record x

i

by ex

i

, as this would instantly in-

SECRYPT2013-InternationalConferenceonSecurityandCryptography

300

validate all locally stored responses. Here comes the

chameleon hash into play: ﬁrst, the client queries the

proverby running

challenge

to submit the pair (i,λ),

where i is the record-index to be updated and λ is

the value to be concatenated. If i ∈ S, then λ = c

i

(the known challenge), otherwise λ can be chosen

randomly. The prover’s response will consist of the

”old” data item x

i

, and additional veriﬁcation infor-

mation (if a record in S is updated, then V can do a

veriﬁcation, or otherwise skip this intermediate step).

Then, in order not to invalidate other locally stored

responses, the client uses his secret key sk to compute

a collisions

CH

pk

(x

i

) = CH

pk

(ex

i

),

for the chameleon hash, so that all known root hashes

r

j

for all j ∈ S remain intact. Here, let us assume that

the collision ex

i

embodies the updated record contents,

along with properly constructed auxiliary randomiz-

ers attached inside ex

i

to enforce the hash-collision (the

example chameleon hash of section 2.2 permits this).

Embedding new sentinels: In case that the new

record ex

i

shall be challenged subsequently, the veri-

ﬁer concatenates another fresh challenge value ec

i

to

ex

i

, and computes the new root hash er

i

(by virtue of the

veriﬁcation information obtained previously for x

i

) as

the correct response to a potential future challenge.

All of this happens locally (so the prover does not

know about the existence of this new sentinel). No-

tice that the prover, although it knows that the hash-

values for the old and new record are identical, cannot

abandon the update, as the client may in future query

exactly this modiﬁed record.

The scheme is thus called quasi bounded-use, as

challenges that were consumed by

challenge

can be

refreshed by

update

.

Extraction. The extract algorithm simply requests

and error-corrects all records from the prover,and ver-

iﬁes the hash of the ﬁle in its current state against the

locally stored root hash r

∗

= CH

pk

(F). In case of

an adversary that does not respond deterministically

(i.e., a probabilistic attacker), the same technique as

in (Juels and Kaliski, 2007) can be applied: we ﬁrst

use the error-correcting encoding to correct as many

errors as possible. If this recovery fails, then a block

is requested multiple times, and a majority decoding

is done. The analysis as done in (Juels and Kaliski,

2007) applies here as well, thus making the majority

decoding work correctly, if a fraction strictly greater

than 1/2 can be retrieved correctly.

4 SECURITY AND EFFICIENCY

Unlike a security proof by reduction, the argument

will not rest on an algorithm that breaks some cryp-

tographic primitive using a breaking algorithm for the

here presented scheme. Instead, the proof of theorem

4.1 is ”direct”.

Theorem 4.1. The POR construction given in section

3 is (ρ,1− |S|/|F|)-valid for ρ being negligible in the

security parameter t.

Proof. Deﬁne the events

A :=

n

Succ

A

extract

(F

∗

,α) < 1− ζ

o

and

B :=

n

Succ

A

chal

(F

∗

,α) ≥ λ

o

,

both of which are conditional on [(F

∗

,α) ←

Exp

A

setup

(t)] ∧ [F ←

extract

A

resp

(α)]. We show that

the probability of ¬A∪¬B is overwhelming (≥ 1−ζ),

so that the likelihood Pr[A ∩B] is negligible (less

than ρ). We have Pr[¬A∪ ¬B] = Pr[¬A] + Pr[¬B] −

Pr[¬A∩ ¬B]. The event ¬A happens if and only if

the veriﬁer retrieves F = F

∗

with overwhelming prob-

ability. By construction, however,

extract

checks

the hash CH

pk

(F

∗

) against the known root hash r

∗

=

CH

pk

(F). The event of acceptance upon CH

pk

(F) =

CH

pk

(F

∗

) for a corrupted ﬁle F

∗

6= F is nothing else

than a hash-collision, whose occurrence is only negli-

gibly probable for a cryptographic hash (as well as a

Chameleon-hash, based on a collision-resistant hash).

It follows that Pr[¬A] ≥ 1− negl(t).

Concerning the event ¬B, the attacker can in any

case correctly respond to a fraction of at most λ =

1− |S|/|F| challenges (as the prover has no expected

responses stored for these blocks). So for this λ, we

have Pr[¬B] = 0.

By Skl˚ar’s theorem, Pr[¬A ∩ ¬B] is expressible as

Pr[¬A∩ ¬B] = C(Pr[¬A] , Pr[¬B]) for some copula-

function C(x, y) that satisﬁes the upper Fr´echet-

Hoeffding bound C(x,y) ≤ min{x,y}. Hence,

Pr[¬A∩ ¬B] = 0 because Pr[¬B] = 0 (intuitively and

less technically, the intersection of two sets cannot

be larger than either of the two). The proof is com-

plete, since Pr[¬A∪ ¬B] ≥ 1 − negl(t) + 0 − 0 and

thus Pr[A∩ B] = 1 − Pr[¬A∪ ¬B] ≤ negl(t).

Concerning efﬁciency, the ﬁle storage require-

ments are increasing with the number of updates.

Measuring the performance in absolute values (via

an implementation) is subject of currently ongo-

ing efforts (along with theoretical improvements as

sketched in the conclusion section below). Initially,

the ﬁle is stored as is, so that no overhead is needed

DynamicProofsofRetrievabilityfromChameleon-Hashes

301

Table 1: Complexity (excluding efforts for error correction).

computational cost for the

Operation veriﬁer prover

Encode O(nlogn) O(nlogn)

Challenge O(1) –

Response – O(logn)

Verify O(logn) –

Update O(1) O(1)

new sentinel O(logn) –

Extract O(nlogn) O(nlogn)

if the randomizer for the chameleon hash is computed

from the data itself (via a pseudorandom function for

example), unless explicitly stored with the ﬁle record.

However, the nature of the chameleon hash implies

that after k updates, we have a total lot of O(|F| + k)

bits stored at the veriﬁer’s side.

For a response to a challenge or an update, we

transmit all hashes along all sibling nodes on the

path before submitting the new data. This comes to

O(logn) bits for n records in the ﬁle and a binary

hash-tree (generalizations are discussed in the next

section).

The computational burden is determined by the

number of chameleon-hashes to be computed. Pre-

cisely, for a ﬁle with n records, the costs are listed in

table 1.

Extract

is here the most expensive opera-

tion for the veriﬁer, since V after having downloaded

the ﬁle via a sequence of n challenges recomputes

the whole hash-tree. The cost on both sides is thus

O(nlogn).

Freshness. Notice that although the chameleon

hash of an old and new record is the same, the

provider cannot simply refrain from updating the

record, as he must expect future queries on exactly

this updated record. In that case, if the old record

x has been queried with challenge c, then the new

record will be queried with some challenge ec, yield-

ing CH

pk

(xkc) 6= CH

pk

(xkec), unless this is a hash-

collision by coincidence.

An Example Parametrization. The chameleon-

hash used in this work is basically a variation of

Nyberg-Rueppel, which in turn is closely related to

the ElGamal signature scheme. Consequently, the

same security recommendations as for ElGamal ap-

ply to the parametrization of the chameleon hash

(see (Ateniese and de Medeiros, 2005) and (Menezes

et al., 1997) for comments). So, for the example, let a

hash-value and challenge have 256 bits each.

Suppose that we store a 2GB ﬁle, made up of

n = 2

27

blocks (e.g., unicode characters with 4 bytes).

Suppose that we wish to run one audit per day over

the next ﬁve years, without embedding new sen-

tinels. Then we ought to design the protocol to handle

5 × 365 = 1 825 veriﬁcations. If each audit consists

of 1 000 challenges, then there are 1 825 000 sen-

tinels with 2 × 256 bits (for the challenge-response

pair) to be stored at the client side. This makes a to-

tal of roughly 116.8 MBytes for the client (approx-

imately 5.4% of the total ﬁle size). The likelihood

for a single challenge to detect a corruption is thus

only 5.4%. However, making a 1 000 challenges per

audit, the likelihood to discover a corruption quickly

approaches 1.

5 EXTENSIONS

Several extensions to the scheme are imaginable and

partially straightforward.

5.1 Saving Random Coins

Observe that except for the leaf-level where the

Chameleon-hash is required, any standard crypto-

graphic hash-algorithm can be used for the inner

nodes in the Merkle-tree, so to save random coins that

would be required otherwise.

5.2 Application to XML Files

As being inherently tree-structured, the Merkle-

hashtree can be generalized to ℓ-ary trees in the ob-

vious way, so that the scheme remains unchanged ex-

cept for trivial modiﬁcations. However, the computa-

tional cost all grow by the branching factor (the max-

imal count of children of an inner node) ℓ of the tree.

5.3 Insertions and Deletions

Those are slightly more tricky and basically come at

the same cost as for these operations to be performed

on a humble array. More precisely, to insert a record

at a given position i, we may apply

update

to all n−i

successor records to shift them one place apart, so that

the new record can be inserted at the chosen position.

The removal of a record at position i can be done in

the same fashion or we mark the record as removed

by replacing the data with its hash-value (this would

correspond to a sanitization or redaction in editable

signature terminology ). In case that the hash-tree is

already full, it must be recomputed. Alternatives are

offered by ℓ-ary trees with designated free spaces in

between to insert new records, or if the data is orga-

nized in a skip-list rather than a tree.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

302

5.4 Multiple Queries on a Record

A simple way to avoid the prover learning what

records have been queried is to challenge a whole set

S

′

⊂ F of records at a time, where S

′

∩ S 6=

/

0. Any

data referring to a record in S

′

for which no stored

response is expected can be abandoned. In this way,

the prover is left with residual uncertainty about what

record has actually been queried. A more elegant

possibility is offered by private-information retrieval

(PIR; see (Gasarch, 2004) for a survey), yet the ad-

ditional computational and communication overhead

must be assured not to outweigh the cost for an entire

download via

extract

.

5.5 Fairness

An interesting additional security requirement in dy-

namic PORs has been introduced in (Zheng and

Xu, 2011), called fairness. In brief, this requires

that an honest prover cannot be accused successfully

by a malicious veriﬁer to have modiﬁed the stored

ﬁle. Similar notions appear in the context of sanitiz-

able signatures (signer- and sanitizier accountability).

However, we can keep the model and security deﬁni-

tions much simpler if we require all challenges and

update requests to be digitally signed by the veriﬁer,

including the originally submitted ﬁle via

encode

.

Arguments like the previous ones can then be settled

at the court by the prover showing the entire history

of updates and the original ﬁle signature. This es-

sentially relies on a versioning system that a good

storage should maintain anyway. Note that the sig-

nature can indeed remain intact without needing the

veriﬁer’s secret signature key, since the construction

can be extended to ﬁt into standard sanitizable signa-

ture schemes. This direction is left open for future

research.

6 CONCLUSIONS

This work presented a simple and partially generic

construction of dynamic proofs of retrievability from

chameleon-hashes (trapdoor commitments). The pro-

posed scheme is simple and most naturally used with

XML structured data that is stored at an untrusted

external server, e.g., a cloud storage provider. Un-

like standard proofs of retrievability schemes, the

construction in this work is neither bounded nor un-

bounded use, but allows for the introduction of new

sentinels for future integrity spot checks. This fea-

ture seemingly does not exist in any so-far existing

proof of retrievability scheme. In its present form, the

protocol is designed to allow for changes to the ﬁle,

but not to the structure as such, which is an interest-

ing open question for future research. Especially so,

since structural changes are so-far not supported by

any known POR protocol.

ACKNOWLEDGEMENTS

I thank the anonymous reviewers for their careful

reading, valuable comments and useful suggestions.

REFERENCES

Ateniese, G., Burns, R., Curtmola, R., Herring, J., Kissner,

L., Peterson, Z., and Song, D. (2007). Provable data

possession at untrusted stores. In Proceedings of the

14th ACM conference on Computer and communica-

tions security, CCS ’07, pages 598–609, New York,

NY, USA. ACM.

Ateniese, G. and de Medeiros, B. (2005). On the key ex-

posure problem in chameleon hashes. In Proceed-

ings of the 4th international conference on Security in

Communication Networks, SCN’04, pages 165–179,

Berlin, Heidelberg. Springer.

Ateniese, G., Di Pietro, R., Mancini, L. V., and Tsudik, G.

(2008). Scalable and efﬁcient provable data posses-

sion. In Proceedings of the 4th international confer-

ence on Security and privacy in communication ne-

towrks, SecureComm ’08, pages 9:1–9:10, New York,

NY, USA. ACM.

Ateniese, G., Kamara, S., and Katz, J. (2009). Proofs of

storage from homomorphic identiﬁcation protocols.

In Proceedings of the 15th International Conference

on the Theory and Application of Cryptology and In-

formation Security: Advances in Cryptology, ASI-

ACRYPT ’09, pages 319–333, Berlin, Heidelberg.

Springer-Verlag.

Bowers, K. D., Juels, A., and Oprea, A. (2009a). HAIL: a

high-availability and integrity layer for cloud storage.

In ACM Conference on Computer and Communica-

tions Security, pages 187–198.

Bowers, K. D., Juels, A., and Oprea, A. (2009b). Proofs

of retrievability: theory and implementation. In Pro-

ceedings of the 2009 ACM workshop on Cloud com-

puting security, CCSW ’09, pages 43–54, New York,

NY, USA. ACM. full version available from ePrint,

report 2008/175; http://eprint.iacr.org.

Cash, D., K¨upc¸¨u, A., and Wichs, D. (2012). Dynamic

proofs of retrievability via oblivious RAM. In IACR

Cryptology ePrint Archive. Report 2012/550.

Chen, B. and Curtmola, R. (2012). Robust dynamic prov-

able data possession. In ICDCS Workshops, pages

515–525. IEEE Computer Society.

Dodis, Y., Vadhan, S., and Wichs, D. (2009). Proofs of

retrievability via hardness ampliﬁcation. In Proceed-

ings of the 6th Conference on Theory of Cryptogra-

DynamicProofsofRetrievabilityfromChameleon-Hashes

303

phy, TCC ’09, pages 109–127, Berlin, Heidelberg.

Springer-Verlag.

Erway, C., K¨upc¸¨u, A., Papamanthou, C., and Tamassia, R.

(2009). Dynamic provable data possession. In Pro-

ceedings of the 16th ACM conference on Computer

and communications security, CCS ’09, pages 213–

222, New York, NY, USA. ACM.

Gasarch, W. (2004). A survey on private information re-

trieval. Bulletin of the EATCS, 82:72–107.

Halevi, S., Harnik, D., Pinkas, B., and Shulman-Peleg, A.

(2011). Proofs of ownership in remote storage sys-

tems. In Proceedings of the 18th ACM conference

on Computer and communications security, CCS ’11,

pages 491–500, New York, NY, USA. ACM.

Juels, A. and Kaliski, B. S. J. (2007). PORs: Proofs of

Retrievability for Large Files. In ACM Conference on

Computer and Communications Security, CCS 2007,

pages 584–597. ACM.

Lillibridge, M., Elnikety, S., Birrell, A., Burrows, M.,

and Isard, M. (2003). A cooperative internet backup

scheme. In Proceedings of the USENIX Annual Tech-

nical Conference, ATEC ’03, pages 29–41, Berkeley,

CA, USA. USENIX Association.

Liu, S. and Chen, K. (2011). Homomorphic linear authen-

tication schemes for proofs of retrievability. In Pro-

ceedings of the 2011 Third International Conference

on Intelligent Networking and Collaborative Systems,

INCOS ’11, pages 258–262, Washington, DC, USA.

IEEE Computer Society.

Menezes, A., van Oorschot, P. C., and Vanstone, S. (1997).

Handbook of applied Cryptography. CRC Press LLC.

Paterson, M. B., Stinson, D. R., and Upadhyay, J. (2012).

A coding theory foundation for the analysis of

general unconditionally secure proof-of-retrievability

schemes for cloud storage. CoRR, abs/1210.7756.

Resch, J. K. and Plank, J. S. (2011). AONT-RS: blend-

ing security and performance in dispersed storage sys-

tems. In Proceedings of the 9th USENIX conference

on File and storage technologies, FAST’11, pages 14–

14, Berkeley, CA, USA. USENIX Association.

Shacham, H. and Waters, B. (2008). Compact Proofs of Re-

trievability. In Advances in Cryptology - ASIACRYPT

2008, volume 5350 of LNCS, pages 90–107. Springer.

Stefanov, E., van Dijk, M., Juels, A., and Oprea, A. (2012).

Iris: a scalable cloud ﬁle system with efﬁcient in-

tegrity checks. In Proceedings of the 28th Annual

Computer Security Applications Conference, ACSAC

’12, pages 229–238, New York, NY, USA. ACM.

Wang, Q., Wang, C., Ren, K., Lou, W., and Li, J. (2011).

Enabling public auditability and data dynamics for

storage security in cloud computing. IEEE Transac-

tions on Parallel and Distributed Systems, 22(5):847–

859.

Xu, J. and Chang, E.-C. (2012). Towards efﬁcient proofs of

retrievability. In Proceedings of the 7th ACM Sympo-

sium on Information, Computer and Communications

Security, ASIACCS ’12, pages 79–80, New York, NY,

USA. ACM.

Zheng, Q. and Xu, S. (2011). Fair and dynamic proofs of

retrievability. In Proceedings of the ﬁrst ACM con-

ference on Data and application security and privacy,

CODASPY ’11, pages 237–248, New York, NY, USA.

ACM.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

304
