Artificial Neural Networks, Multiple Linear Regression and Decision
Trees Applied to Labor Justice
Genival Pavanelli, Maria Teresinha Arns Steiner,
Alessandra Memari Pavanelli and Deise Maria Bertholdi Costa
Specialization Program in Numerical Methods in Engennering
PPGMNE,
Federal University of Paraná State UFPR, CP 1908 , Curitiba, Brazil
Keywords: Mathematical Programming, Artificial Neural Networks, Multiple Linear Regression, Decision Tree,
Principal Component Analysis, Encoding Attributes.
Abstract: This paper aims to predict the duration of lawsuits for labor users of the justice system. Thus, we intend to
provide forecasts of the duration of a labor lawsuit that gives subsidies to establish an agreement between
the parties involved in the processes. The proposed methodology consists in applying and comparing three
techniques of the Mathematical Programming area, Artificial Neural Networks (ANN), Multiple Linear
Regression (MLR) and Decision Trees in order to obtain the best possible performance for the forecast.
Therefore, we used the data from the Labor Forum of São José dos Pinhais, Paraná, Brazil, to do the training
of various ANNs, the MLR and the Decision Tree. In several simulations, the techniques were used directly
and in others, the Principal Component Analysis (PCA) and / or the coding of attributes were performed
before their use in order to further improve their performance. Thus, taking up new data (processes) for
which it is necessary to predict the duration of the lawsuit, it will be possible to make up conditions to
"diagnose" its length preliminarily at its course. The three techniques used were effective, showing results
consistent with an acceptable margin of error.
1 INTRODUCTION
This work presents a proposal of application of
techniques in the field of Operational Research, by
the labor courts. This proposal is to provide an
estimate of the duration of a labor lawsuit for users
of the Labor Forum of Sao Jose do Pinhais, PR,
Brazil.
In order to obtain such a prediction, we used
three methods: one from the area of artificial
intelligence, Artificial Neural Networks (ANN) and
two, from the Statistical Area, Multiple Linear
Regression (MLR) and Decision Tree. The purpose
of using these three methods already well known
among search sources is to make a comparison
between the final results and, thus, determine which
provides the best performance (highest percentage of
correct answers) and thus be used in future forecasts.
This paper is structured as follows: section 2
presents related work that also made use of
Operational Research techniques applied here.
Section 3 is a description of the problem, gathering
and processing of data. Section 4 presents the
methodology of the work, which describe the
concepts involving the techniques of ANNs,
Principal Component Analysis (PCA), MLR and
Decision Tree. Section 5 describes the
implementation of computational techniques and
analysis of results. Finally, section 6 presents the
conclusions obtained by analyzing the results of the
previous section.
2 RELATED WORK
There are in literature, many studies related to data
forecasting, in which various techniques in the field
of Operations Research and, more specifically,
Pattern Recognition, have been applied. It is
noteworthy that no studies were found related to
forecasting problems of the Labor Court, as
presented here. Among the studies reviewed in the
literature, may be mentioned those listed below.
In Baptistella, Cunico and Steiner (2009), the
443
Pavanelli G., Teresinha Arns Steiner M., Memari Pavanelli A. and Maria Bertholdi Costa D..
Artificial Neural Networks, Multiple Linear Regression and Decision Trees Applied to Labor Justice.
DOI: 10.5220/0004517504430450
In Proceedings of the 5th International Joint Conference on Computational Intelligence (NCTA-2013), pages 443-450
ISBN: 978-989-8565-77-8
Copyright
c
2013 SCITEPRESS (Science and Technology Publications, Lda.)
authors look for alternative techniques in order to
determine market values for properties in
Guarapuava, PR. It is proposed the use of ANNs and
for that, we collected 256 historical records
(patterns) of urban real estate in the city. Each of the
records was composed of 13 information
(attributes): neighborhood, sector, paving, drainage,
street lighting, land area, soil conditions,
topography, location, built up area, type, structure
and conservation. Several simulations have been
developed, with the worst results presenting an
accuracy of 78% and the best, 95%.
Still in property valuation, there is also the work
of Nguyen and Cripps (2001), which compares the
performance of ANNs with Multiple Regression
Analysis for the sale of family houses. Multiple
comparisons were made between the two models in
which were varied: the sample size of data, the
functional specification and the time prediction. In
the work of Bond; Seiler and Seiler (2002), the
authors examine the effect that the view of a lake
(Lake Erie, USA) has on the value of a house. In the
study the transaction prices of houses were taken
into account (market price). The results indicate that,
in addition to the variable view, which is
significantly more important than the others, also the
building area and the batch size are important.
Baesens et al. (2003) discuss three methods for
the extraction of rules from a neural network, in a
compared way: NeuroRule; Trepan and Nefclass. To
compare the performances of the methods discussed,
we used three real credit datasets: German Credit
(obtained from UCI repository), Bene 1 and Bene 2
(obtained from the two largest financial institutions
in the Benelux). The algorithms mentioned are also
compared with C4.5-tree algorithms, C4.5-rules and
Logistic Regression. The authors also show how the
extracted rules can be viewed as a decision table in
the form of a compact and intuitive graph, allowing
better reading and interpretation of results to credit
manager.
In Mota and Steiner (2007), the authors present a
methodology composed of Multivariate Analysis
techniques, to build a statistical model of Multiple
Linear Regression for property valuation. It is
applied, initially, the Cluster Analysis to the data of
each class of urban real estate (apartments, houses
and land) to obtain homogeneous groups within each
class, and in correspondence, are determined
discrimnants to allocate future items in these groups,
by the Quadratic discriminant Score Method. Then,
it is applied the PCA technique to solve the problem
of multicollinearity that may exist between the
variables of the model. With the scores of the
principal components it is adjusted a Multiple Linear
Regression model for each group of homogeneous
properties within each class. The methodology was
applied to a set of 119 buildings (44 apartments, 51
houses and 24 lots), the city of Campo Mourão, PR.
The model for each homogeneous group within each
class of property assessed had a proper fit to the data
and a predictive quite satisfactory.
Adamowicz (2000) uses pattern recognition
techniques, ANN and Linear Discriminant Analysis
of Fisher, with the goal of classifying companies as
solvent or insolvent. The data were provided by the
Southern Regional Development Bank (BRDE),
Curitiba branch, PR. Both techniques were efficient
in discriminating the companies, and the
performance of ANNs was slightly better than the
Linear Discriminant Analysis of Fisher.
Ambrosio (2002) presents a study that aims to
develop a computer system to assist radiologists in
the confirmation of diagnosis of interstitial lung
lesions. The data were obtained from the Hospital
das Clínicas of the Medicine University of Ribeirão
Preto (HCFMRP) using protocols generated by
experts. The system was developed using multilayer
ANNs as a pattern classifier. The training algorithm
is back-propagation with the sigmoidal activation
function. Several tests were performed for different
network configurations. It was clear that the use of
this tool is feasible, since once the network is trained
and the weights set, it is no longer necessary to
access the database. This makes the system faster
and computationally lighter. The research concludes
that the ANNs fulfill well their role as classifiers
standards.
Souza et al. (2003) used ANNs techniques with
three layers of neurons with the back-propagation
algorithm. The goal was to predict the content of
mechanically separated meat (CMS) in meat
products from the mineral content contained in
sausages formulated with different levels of chicken.
The technique proved to be very efficient during the
training and testing, however, the application of the
ANNs to commercial samples was inadequate,
because of the difference in the ingredients used in
the sausage of the training and the ingredients of the
commercial samples.
In Steiner, Carnieri and Stange (2009), it is
proposed the use of a Linear Programming Model
for Pattern Recognition of paper reels of good or
poor quality. Data were collected from 145 rolls of
paper (standard), 40 of good quality and 105 of low
quality. From each coil 18
attributes were
considered: tensile and tear tests of pulp, mechanical
pulp and thermo-mechanical pulp; amounts of these
IJCCI2013-InternationalJointConferenceonComputationalIntelligence
444
three folders; consistency and flow of pulp and
seven data press rolls of the paper machine. From
the PL model, it was built a second mathematical
model that makes use of the first, so as to ensure the
attainment of good quality coils at a minimum cost.
Biondi Neto et al. (2006) show in their work that
the determination of soil type, until then, could be
obtained using abacuses; the aim of the research was
to apply a computational method to classify the soil.
The technique used was again ANNs with
Levenberg-Marquardt method, which has resulted in
the classification of soil for each increment of depth.
All data were obtained from real situations. The
convergence time was quick, which facilitated the
completion of several tests.
Lu; Setiono and Liu (1995, 1996) reported in
their articles the algorithm called Neurorule that
makes the extraction of rules from a trained neural
network, obtaining rules of the type IF-THEN. The
performance of this approach is verified in both
articles in an issue of bank credit, and to facilitate
the extraction of such rules, the values of numeric
attributes were discretized by dividing them into
sub-intervals. After the discretization, the encoding
scheme "thermometer" was employed to obtain
binary representations of the intervals previously
defined obtaining thereby the inputs to the neural
network. The results obtained indicate that, using the
proposed approach, high quality rules can be
discovered from a data set.
Steiner et al (2007) use rules extraction
techniques such as Neurorule and WEKA software
to extract rules from a trained artificial neural
network. The ANN classifies companies as good or
bad credit borrowing. From the trained network the
authors conducted three types of tests for extracting
rules. In the first, the extraction of rules was made
directly from the original data, in the second test
patterns misclassified by the RN were discarded,
while in the third test, in addition to discarding
patterns misclassified by RN, attributes were coded
according to the encodings "thermometer" and
"dummy", making them binaries. The results were
quite satisfactory presenting accuracy above 80% for
the grant (or not) of bank credit.
And so, several other studies from different
research areas, making use of various techniques of
Pattern Recognition, especially ANNs, could be
cited here.
3 DESCRIPTION
OF THE PROBLEM
Currently, many countries have labor laws, but was
not always so. In Brazil, labor courts and labor law
emerged only after the nineteenth century, after
many struggles and demands from the working
classes. Only after the Revolution of 1930 the
Ministry of Labor was created, and the Labor Court
was provided by the 1934 Constitution. Currently
the Labor Court is structured in three levels of
jurisdiction:
First Level: Labor Courts;
Second Level: Regional Labor Courts;
Third Level: Superior Labor Court.
According to the Superior Labor Court (SLC), in
Brazil there are 24 Regional Labor Courts (RLC),
and as of 2003, about 270 new Labor Courts were
created in order to accelerate the legal procedures of
labor lawsuits (SLC, 2007). Only in the state of
Paraná, at the 9th Region of the RLC, there are 28
Justices distributed statewide (TRT, 2007). Of the 77
Labor Courts of the State of Paraná, São José dos
Pinhais (SJP) ranks second in number of labor
lawsuits. In 2006, the SJP Forum of Labor started
having a second Labor Court. Due to the increasing
number of labor lawsuits as a result of massive
industrialization in the municipality, it is necessary
agility in service of justice. Thus, the use of
mathematical tools for predicting the duration labor
lawsuits is of fundamental importance to this
optimization of time.
The process data (patterns), as well as the
attributes of each pattern, used for the development
of this work were obtained from the First Labor
Court Board of SJP, PR, Brazil. Aiming to
determine which attributes would be relevant in
determining the duration of a labor lawsuit, several
meetings were held with the titular judge of this
Forum. As a result of these meetings, we came to a
set of 10 attributes listed below.
a. Rite: which may be of labor (LR) or a
summary lawsuit (SL)
b. Service time: is the difference between the
date of admission and date of discharge, in months;
c. Salary of the Complainant: last salary
received;
d. Profession: function performed by the
complainant. This attribute was divided into two
parts: a sector that is also divided into commerce,
industry and service; and office position, which falls
into the direction and execution;
e. Process Goal: corresponds to the requests
ArtificialNeuralNetworks,MultipleLinearRegressionandDecisionTreesAppliedtoLaborJustice
445
made by the complainant. They can be: lack of
registration with professional portfolio, wage
differentials, severance, Art 477 fine, Art 467 fine,
overtime and reflexes, guarantee fund for length of
service, compensation for moral damages,
unemployment insurance, transportation payment,
health hazard allowance, night allowance and health
plan;
f. Agreement: when there is an agreement
between the parties;
g. Expertise: whether or not there is a need of
performing some kind of expertise, for example, a
medical examination or health hazard examination;
h. Regular feature: when one party (plaintiff or
claimed) does not agree with the sentence issued by
the judge and asks ordinary appeal to the SLC;
i. Review feature: when one party (plaintiff or
claimed) does not agree with the judgment of the
SLC and requires the Review feature;
j. Number of Hearings: refers to the number of
hearings necessary for the judge to issue the
sentence;
The 10 attributes listed above, used to predict the
duration of the process were collected from 100
cases generating the matrix intended for training and
testing of ANNs, as well as for applying the
technique of MLR and the construction of the
Decision Tree.
Most data was treated to correspond to one or
more binary coordinates (Lu; Setiono and Liu,
1996), (Baesens et al., 2003) of the inputs vector to
the techniques used, as mentioned in section 3.1, the
below.
3.1 Encoding of Attributes
In order to try to improve the performance of
techniques, each of the 10 attributes cited was
"treated" so as to correspond to one or more binary
coordinates (Lu et al., 1996), (Baesens et al., 2003)
depending on whether it was nominal or ordinal. We
used a "thermometer coding" for the ordinal
attributes and "dummy coding" (artificial) for
nominal attributes (Baesens et al., 2003), (Steiner
et
al., 2007).
Table 3.1 illustrates the "thermometer encoding"
for the ordinal attribute "Salary of the Complainant",
for example. This attribute is first discretized in the
values of 1 to 5; for example, the "Input 1 = 1", this
means that the original variable "Salary of the
Complainant "> 1340. Table 3.2 illustrates the
"dummy coding" for the nominal variable
"Agreement", for example.
Table 3.1: An example of "thermometer encoding" for
ordinal variables.
“Salary of the
Complainant”
SR(reais)
Cate
goric
Input
Input
1
Input
2
Input
3
Input
4
330
SR < 450
1 0 0 0 0
450 SR < 620 2 0 0 0 1
620 SR < 800 3 0 0 1 1
800 SR
1.340
4 0 1 1 1
SR 1.340 5 1 1 1 1
Table 3.2: An example of "dummy coding" for ordinal
variables.
Original Input
“Agreement”
Input
1
Agreement = Yes 0
Agreement = No 1
From the above-explained encoding the 10 attributes
provide 32 inputs to the ANN, therefore, the matrix
has 100 rows and 32 columns.
4 METHODOLOGY OF WORK
The methodology applied in this study sought,
through the use of ANNs, the MLR and Decision
Tree, comparatively recognize patterns in labor
lawsuits analyzed to predict the length of the labor
lawsuits users of the justice system, as already
mentioned.
Aiming to minimize the error of the techniques
applied, three different tests were carried out. In the
first test all attributes were coded as described in
section 3.1, so that each pattern would present an
input vector with 32 binary coordinates. In the
second test the coded data matrix (according to the
previous test) was submitted to PCA, in order to
evaluate the relative importance of the variables in
the sample data. In the third test the original ordinal
variables were not coded, in other words, the
attributes salary, service time and number of
audience have not been converted into binary
vectors and then the matrix was subjected to the
PCA, such that each pattern would present, for this
test, an input vector of 23 coordinates.
4.1 Artificial Neural Networks
The ANN implemented in this work, classified as
multiple layers network or feed-forward network,
was trained by back-propagation algorithm using the
sigmoidal transfer function, which generates output
between "0" and "1" for inputs between - e +, in
IJCCI2013-InternationalJointConferenceonComputationalIntelligence
446
all neurons. Network performance was verified
through the MSE (medium quadratic error), given
by equation (4.1).

n
ad
MSE
n
i
P
i
P
i
2
1
2
(4.1)
where n = number of patterns, d
i
is the desired
output (real value) for the default p e a
i
is the output
obtained by the network, for the default p.
4.2 Multiple Linear Regression
The second method used in this work, MLR has as
main objective to describe the relationship between a
response variable and one or more explanatory
variables. The most commonly used types of
regression are: Linear and Logistic, widely used in
various fields of knowledge.
According to Lima (2002), in 1845 the logistic
regression technique arose in order to solve
problems of population growth. This technique has
also been employed in the field of Biology in the
30s. However, its application in economic and social
problems appears only in the 60s. Recently, this
methodology has become mandatory in many
reference econometrics manuals. Logistic
Regression is a statistical technique widely used in
data analysis with responses belonging to the
interval [0, 1], with the goal of classifying patterns
into classes.
Linear Regression is widely used in many areas
of research, being a kind of technique that can
produce values of estimated response outside the
range [0, 1]. It is considered a classical regression
model. It is a technique used to study the
relationship between one dependent variable and
several independent variables. The goal can be
explanatory, i.e., demonstrate a mathematical
relationship that can indicate but not prove a cause
and effect relationship, or predictive, i.e., obtain a
relation that permits, through future observations of
the variables x, predict the corresponding value y.
Suppose you want to build a model that relates
the response variable y with p factors x
1
, x
2
,...,x
p
.
This model always includes an error range. There is
then:
ippiii
xxxy ...
21110
for i = 1,2,..,n where n is the number of
observations; p is the number of variables.
Using matrix notation:
XY
, where Y is
the response variable, X matrix model;
is the
vector of
parameters to be estimated; ε is the vector
of random errors.
nY
Y
Y
Y
2
1
npn
p
p
xx
xx
xx
X
1
221
112
1
1
1
p
1
0
n
2
1
4.3 Decision Trees
Decision trees are a very powerful technique, widely
used, based on a hierarchy of tests to some of the
variables involved in a problem of decision. The
knowledge gained from this technique is expressed
through rules, a fact that justifies its widespread use.
It can be used for two purposes: prediction
(example: find out if a customer will be a good
payer according to his/her characteristics) and
description (provide interesting information about
the relationships between predictive attributes and
class attribute in a database).
Its structure has the following characteristics:
Each internal node is a test on a predictive
attribute;
a branch starting from an internal node represents a
result for the test;
a leaf of the tree represents a class label.
To classify an unknown example it is just
necessary to forward it down the tree according to
the values of the attributes tested in successive
nodes, and when a leaf is reached the instance is
classified according to the class assigned to the leaf
(Witten and Frank, 2005).
4.4 Principal Component Analysis
Looking for further improvement of the obtained
results, in some of the tests it was applied the PCA,
which is able to identify patterns in data, in order to
express them pointing out the similarities and also
the existent differences. It is linked to the covariance
structure explanation through a few linear
combinations of the original variables.
Furthermore, through PCA the original size of
the database is reduced with linear combinations of
a set of variables that retain the maximum number of
information contained in the original variables, and
also facilitates the interpretation of the analyzes,
judging the importance of the original variables
chosen.
ArtificialNeuralNetworks,MultipleLinearRegressionandDecisionTreesAppliedtoLaborJustice
447
5 COMPUTING
IMPLEMENTATION
AND ACHIEVEMENT
OF RESULTS
As previously described in section 4, the methods
proposed in this paper, ANNs, MLR and Decision
Trees have been applied after collection and
processing (coding of attributes / implementing
PCA) of the cases examined, which were filed at the
Forum of Labor of SJP. All data obtained in each
lawsuit were used to compose the input matrices.
The training of the ANNs implemented in this work
is supervised, i.e. for each data input vector the
output is already known (Haykin, 2002). Thus, in
order to perform the training and testing of ANN it
was implemented a program using Visual Basic 6.0
Software.
To carry out the training of ANNs it was used, as
already mentioned, the back-propagation supervised
algorithm, with sigmoidal activation function, with
outputs in the range [-1, 1]. Due to these conditions
of the activation function, it was necessary to fit the
outputs in this interval. Thus, the length of processes
which range from 1 to 94 months, were divided by
94. It is noteworthy that the length of the process has
a uniform distribution.
For the assessment of the ANN, it was used the
hould out procedure, in other words, from all the
processes registered, 75% were used for the training
of the network and the remaining 25% were used in
the test. In the application of ANNs, four sets of
initial weights were used in all tests.
Figure 5.1, below, shows conceptual forms of
two learning curves, one in relation to the training
set and another in relation to the validation set. The
curves are distinctive, and the curve of training
(learning) monotonously decreases for an increasing
number of iterations. Since the validation curve
decreases to a minimum and then increases again as
the training proceeds.
Figure 5.1: Training Versus ANN Generalization
Capability - Source: Haykin (2002).
In all tests performed on ANNs, it was varied the
number of hidden layer neurons from "1" to "15",
remaining fixed the number of 50 iterations for each
of the topologies in order to find the lowest error in
the test group. The architecture that provided the
smallest error, returned to be trained, now varying
the number of iterations, until the moment when the
error in the test group reached the minimum. Thus,
the over-fitting of the network will be avoided, in
other words, the ANN would give better results for
the training group. However, it would lose the
ability to generalize, as illustrated in figure 5.1.
A nomenclature has been chosen for each
topology, in order to represent, in sequence, the
following characteristics of the ANN: number of
entries, the number of neurons in the hidden layer
and the number of iterations. For example, the
network "E32N3I40" is a network with "32" entries
"3" neurons in the hidden layer and was trained with
"40" iterations.
5.1 Results obtained
In predicting the length of a labor lawsuit, the third
test showed the best result, where ordinal attributes
were not coded and then the data were submitted to
PCA. Table 5.1 below shows the variation in the
number of neurons in ANNs for this test.
Table 5.1: Results of simulations varying the Number of
Neurons in Hidden Layer.
SIMU
LATION
TOPO-
LOGY
MSE Tr MSE Tes
1 E23N1I50 0,06968 0,14800
2 E23N2I50 0,05303 0,20287
3 E23N3I50 0,03189 0,16561
4 E23N4I50 0,03207 0,13947
5 E23N5I50 0,02686 0,36916
6 E23N6I50 0,02383 0,07108
7 E23N7I50 0,02294 0,08402
8 E23N8I50 0,03090 0,12042
9 E23N9I50 0,02282 0,25118
10 E23N10I50 0,02502 0,45144
11 E23N11I50 0,02375 0,14043
12 E23N12I50 0,02225 0,12329
13 E23N13I50 0,02485 0,11329
14 E23N14I50 0,02186 0,21053
According to table 5.1, it appears that the best
network topology is E23N6I50, which means, 23
neurons in the input layer, six in the hidden layer,
trained with 50 iterations. From this analysis, this
network has been trained, now varying the number
of iterations in order to obtain the lowest possible
IJCCI2013-InternationalJointConferenceonComputationalIntelligence
448
0
0,02
0,04
0,06
0,08
0,1
0,12
0,14
0 500 1000 1500
MSE
NumberofIterations
Group
Training
TestGroup
error.
From the results of table 5.2, we can see that the
simulation with 50 iterations provides the best
results (lower error rate in the test group).
Table 5.2: Results of simulations varying the number of
iterations.
SIMU
LATION
TOPO-
LOGY
MSE Tr MSE Tes
1 E23N6I10 0,05718 0,10532
2 E23N6I20 0,03792 0,08161
3 E23N6I30 0,03175 0,07455
4 E23N6I40 0,02738 0,07145
5 E23N6I50 0,02383 0,07108
6 E23N6I60 0,02134 0,07196
7 E23N6I70 0,01955 0,07333
8 E23N6I80 0,01819 0,07489
9 E23N6I90 0,01706 0,07653
10 E23N6I100 0,01609 0,07821
11 E23N6I200 0,01014 0,09270
12 E23N6I500 0,00573 0,11402
13 E23N6I1000 0,00409 0,12951
As expected, the error in the training group
decreased monotonously at the same time that the
number of iterations increases. In the test group the
error decreases reaching a minimum of 0.07108
when the network is being trained with 50 iterations.
When we increase this number it becomes very clear
that the error in this group begins to increase
characterizing the loss of generalization capability of
ANN from that moment. Such information can be
seen in Graph 5.1 below.
Graph 5.1: MSE Training group and test group.
The prediction made through the MLR technique,
used the same data sets (training and test) of ANNs,
as well as three types of tests in order to compare the
results.
The best result obtained with this technique was
also the third test. The vector of estimated
parameters obtained in the application of MLR that
describes the relationship between the response
variable (length of the procedure) and the
independent variables in this test is given by (5.2)
Length of the procedure = 1.0e-003*(0,2422 -
0,0009*Col_1 - 0,0001*Col_2 - 0,0005*Col_3 -
0,0005*Col_4 - 0,0001*Col_5 - 0,0002*Col_6 +
0,0002*Col_7- 0,0001*Col_8 + 0,0007*Col_9 -
0,0003*Col_10 -0,0001*Col_11 + 0,0001*Col_12 +
0,0005*Col_13 - 0,0002*Col_14 - 0,0002*Col_15 -
0,0003*Col_16 + 0,0001*Col_17- 0,0003*Col_18 +
0,0003*Col_19 + 0,0003*Col_20 -0,0001*Col_21 +
0,0001*Col_22 + 0,0009*Col_23) (5.2)
When applying the regression equation to the
same training and test sets used in RNAs the MSE
obtained (as described in equation 4.1) was equal to
0.0743 for the training set, while in test set error it
was of 0.1287.
The Decision Tree technique was applied from
the software WEKA (Waikato Environment for
Knowledge Analysis), which is free and has an open
code source, used for data mining. As in the MLR,
when applying the decision tree technique it was
used the same data sets and also the three types of
tests were carried out. This technique also showed
the best results in the 3rd test, where the average
quadratic error was of 0.0881.
6 CONCLUSIONS
The Forum of Labor SJP has increased considerably
the number of labor lawsuits. Given this fact, it is
necessary to use mathematical optimization tools
such as, from the area of Operational Research,
which might in some way assist the legal department
in its various procedures. In this work, these tools
were used in order to enable the "negotiation"
between the parties, by predicting the length of the
labor lawsuits’ proceedings.
The application presented here, related to
processes of the Labor Court, shows, once again, the
wide applicability of the techniques from the field of
Operational Research. The application discussed
here, aims to compare the techniques of ANNs,
MLR and Decision Tree to find the best prediction.
With data from 100 cases, which are the inputs to
the techniques, we sought to obtain, automatically, a
length forecast of the steps of the processes.
The ANNs were trained through the back-
propagation algorithm, by the elaboration of a
program using Visual Basic 6.0 software, varying
the possibility of encoding the attributes, the number
of neurons in the hidden layer, the set of initial
weights and the number of iterations. The best
ArtificialNeuralNetworks,MultipleLinearRegressionandDecisionTreesAppliedtoLaborJustice
449
response obtained showed an error of 0.07108 to an
ANN with 23 neurons in the input layer, six neurons
in the hidden layer, with 50 iterations (Table 5.2).
The MLR was performed using
STATIGRAPHICS Plus 5.1 Software. In tests with
this tool, the data sets used (training and testing)
were the same of the ANNs, in order to obtain
comparative parameters between the two
mathematical tools. The error obtained was equal to
0.0743 for the training set and 0.1287 for the test set.
The Decision Tree technique was applied via
WEKA software (Waikato Environment for
Knowledge Analysis), which is free and has an open
code source, used for data mining. We used the same
sets of data in order to compare the applied
techniques. With this tool the error obtained was
0.0881. With this tool the 3rd test also showed the
best result, considering a full MSE equal to 0.0881.
Although the techniques have shown satisfactory
results, the ANNs presented a superior performance
when compared to other methods, as it can observed
through the errors 0.07108 (ANNs), 0.1287 (MLR)
and 0.0881 (Decision Tree).
Thus, the best way to predict the length of the
processing of a new labor lawsuit, is to use ANN
"E23N6I50", Table 5.2, where the weights were
generated by the 3 third test (ordinal attributes
without encoding, and with PCA) . This way, when
it is desired to know the length of proceeding of a
new labor lawsuit, one must determine the principal
components of this case and then, using the topology
and network weights E23N6I50, obtain the required
number of months for this case.
It is worth mentioning that from time to time, in
accordance with the suggestion of specialists of the
area (labor judges), latest data (files) with known
and reliable answers should be included in the
database and methodology should be repeated,
always glimpsing the lowest possible error for that
prediction. With this, it is expected to obtain a more
dynamic and accurate judiciary system, as well as
greater satisfaction of its users.
REFERENCES
Adamowicz, E. C., 2000. Reconhecimento de Padrões na
Análise Econômico–Financeira de Empresas. Curitiba.
Dissertação de Mestrado, PPGMNE, UFPR.
Ambrósio, P. E., 2002 Redes Neurais Artificiais no Apoio
ao Diagnóstico Diferencial de Lesões Intersticiais
Pulmonares. Ribeirão Preto. Dissertação de Mestrado,
USP.
Baesens, B., Setiono, R., Mues, C. & Vanthienen, J., 2003.
Using Neural Network Rule Extraction and Decision
Tables for Credit-Risk Evalution. Management
Science, 49, 3, 312-329.
Baptistella, M., Cunico, L. H. B., Steiner, M. T. A., 2009.
O Uso de Redes Neurais na Engenharia de Avaliações:
Determinação dos Valores Venais de Imóveis
Urbanos. Revista de Ciências Exatas e Naturais, 9, 2,
215-229.
Biondi Neto, L., Sieira, A. C. C. F., Danziger B. R., Silva,
J. G. S., 2006. Neuro-CPT: Classificação de Solos
usando-se Redes Neurais Artificiais. Engevista, v. 8, p.
37-48.
Bond, M. T., Seiler, V. L., Seiler, M. J., 2002. Residencial
Real Estate Prices: a Room with a View. The Journal
of Real Estate Research, v. 23, n. 1, p. 129-137.
Haykin, S., 2002. Redes Neurais: Princípios e Prática.
Bookman, Porto Alegre, RS.
Lima, J. D., 2002. Análise Econômico–Financeira de
Empresa Sob a Ótica da Estatística Multivariada.
Curitiba. Dissertação de Mestrado, PPGMNE, UFPR.
Lu, H.; Setiono, R. & Liu, H., 1996. Effective Data
Mining Using Neural Networks. IEE Transactions on
Knowledge an Data Engineering, 8, 6, 957-961.
Nguyen, N., Cripps, A. 2001. Predicting Housing Value:
A Comparison of Multiple Regression Analysis and
Artificial Neural Networks. The Journal of Real Estate
Research, v. 22, n. 3, p. 313-336.
SLC - Superior Labor Court. (http://www.tst.gov.
br/) 16 february 2007.
Sousa, E. A., Teixeira, L. C. V., Mello, M. R. P. A.,
Torres, E. A. F. S., Moita Neto, J. M., 2003. Aplicação
de Redes Neurais para Avaliação do Teor de Carne
Mecanicamente Separada em Salsicha de Frango.
Ciência e Tecnologia de Alimentos, 23, 3, Campinas.
Steiner, M. T. A. 1995. Uma Metodologia Para o
Reconhecimento de Padrões Multivariados com
Resposta Dicotômica. Florianópolis. Tese de
Doutorado, Programa de Pós Graduação em
Engenharia de Produção, UFSC.
Steiner, M. T. A., Nievola, J. C., Soma, N. Y., Shimizu,
T., Steiner Neto, P. J., 2007. Extração de regras de
classificação a partir de redes neurais para auxílio à
tomada de decisão na concessão de crédito bancário.
Revista Pesquisa Operacional, 27, 407-426.
Steiner, M. T. A.; Mota, J. F., 2007. Estudando um Caso
de determinação do Preço de Venda de Imóveis
Urbanos utilizando Redes Neurais Artificiais e
Métodos Estatísticos Multivariados. X Encontro de
Modelagem Matemática, Nova Friburgo, RJ.
Steiner, M. T. A., Bráulio, S. N., Alves, V., 2008.
Métodos Estatísticos Multivariados aplicados à
Engenharia de Avaliações, Revista Gestão &
Produção, 15, 23-32.
Steiner, M. T. A., Carnieri, C., Stange, P., 2009.
Construção de um Modelo Matemático para o
Controle do Processo de Produção do Papel Industrial.
Pesquisa Operacional para o Desenvolvimento, 1, 1,
33-49.
TRT - Tribunal Regional do Trabalho. (http://www.trt9.
gov.br/> 07 october 2007.
Witten, I. H., Frank, E., 2005, Data Mining: Practical
Machine Learning Tools and Techniques, Morgan
Kaufmann Publishers, 2nd edition.
IJCCI2013-InternationalJointConferenceonComputationalIntelligence
450
