Token-based Authentication for Smartphones

Manuel Koschuch

, Matthias Hudler

, Hubert Eigner

and Zsolt Saffer

Competence Centre for IT-Security, FH Campus Wien - University of Applied Science,

Favoritenstrasse 226, 1100, Vienna, Austria

FH Campus Wien - University of Applied Science, Favoritenstrasse 226, 1100, Vienna, Austria

Keywords:

Smartphone, Security, Token, Usability, Authentication, Challenge-response.

Abstract:

Due to short - but frequent - sessions of smartphone usage, the fast and easy usability of authentication

mechanisms in this special environment has a big impact on user acceptance. In this work we propose a

user-friendly alternative to common authentication methods (like PINs and patterns). The advantages of the

proposed method are its security, fastness, and easy usage, requiring minimal user interaction compared to

other authentication techniques currently used on smartphones. The mechanism described uses the presence

of a Bluetooth-connected hardware-token to authenticate the user and can easily be implemented on current

smartphones. It is based on an authentication protocol which meets the requirements on energy efﬁciency

and limited resources by optimizing the communication effort. A prototype was implemented on an Android

smartphone and an MSP430 based MCU. The token allows fast authentication without the need for addi-

tional user action. The entire authentication process can be completed in less than one second, the developed

software prototype requires no soft- or hardware modiﬁcations (like rooting) of the Android phone.

1 INTRODUCTION

Smartphones became more and more popular during

the last years. With built-in distribution platforms for

applications by third party developers, mobile devices

today are able to cover a broad spectrum of applica-

tion scenarios (Cozza et al., 2012). As a consequence

the amount of critical, personal and conﬁdential data

stored on smartphones is growing steadily and there-

fore its protection gets more important. An important

building block of the security measures available on

smartphones today is the user authentication.

Available authentication methods on current de-

vices suffer from not being secure, fast or easy to use

enough for the typical user, or are not secure when

used in insecure environments like public places with

a lot of potentially malicious observers.

Either the mechanisms require cumbersome inter-

action by the user (e.g. entering a long passphrase

each time the phone is unlocked) or are inherently un-

safe (e.g. authentication patterns, that can be recov-

ered by observing residues on the touchscreen (Aviv

et al., 2010) or by simply spying on the user when

unlocking the phone in public).

Token-based authentication, as proposed in this

paper, can provide a secure, fast, and user-friendly so-

lution to identify the user. Unlike the existing concept

of using the smartphone as an authentication token

(Thanh et al., 2009), we propose the token as a sepa-

rate piece of hardware to authenticate the user to the

smartphone.

The remainder of this paper is structured as fol-

lows:

Section 2 gives an overview of the special chal-

lenges when authentication is used in the context of

smartphones. Sections 3 and 4 then describe our pro-

posed solution, while Section 5 gives a preliminary

evaluation of its security. Finally, Section 6 gives an

overview of the actual implementation, while Section

7 provides some closing remarks.

2 AUTHENTICATION ON

SMARTPHONES

Smartphone usage differs in many ways from usage

of traditional devices like personal computers. As

a consequence, authentication methods on these de-

vices have to cover different requirements.

Smartphones are usually always-on devices. In

case of theft or loss a potential attacker acquires a

Koschuch M., Hudler M., Eigner H. and Saffer Z..

Token-based Authentication for Smartphones.

DOI: 10.5220/0004520000510056

In Proceedings of the 4th International Conference on Data Communication Networking, 10th International Conference on e-Business and 4th

International Conference on Optical Communication Systems (DCNET-2013), pages 51-56

ISBN: 978-989-8565-72-3

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

powered and operational device. To protect the crit-

ical data on the phone from unauthorized access, the

user has to authenticate herself to the phone before

usage, and it has to be locked afterwards.

On the other hand smartphone usage typically

consists of short but frequent sessions. As a conse-

quence, the chosen user authentication method has

a large impact on the usability of smartphones. For

many users, the speed and ease of use of the available

methods are important factors in deciding whether au-

thentication is enabled or not (D¨orﬂinger et al., 2010).

Finally, due to the high mobility of these devices,

they will often be used in insecure places with a great

number of potential observers. An easy and user-

friendly approach to authentication requires the secu-

rity of the authentication method to be independent of

the environment the phone is used in.

Based on the characteristics described above, the

following requirements for authentication on smart-

phones can be deﬁned:

• The user has to authenticate before each session

• A passing observer should learn next to nothing

about the secret used for authentication

• User effort has to be minimal, authentication

should be fast and secure

The authentication methods currently available on

smartphones are not able to meet all of these require-

ments.

The most common method is PIN/Password au-

thentication. It requires time-consuming user inter-

action (always typing in the password when unlock-

ing the phone), hence the typical user is very likely to

choose easy to type, short passwords/PINs, and is not

secure when used publicly in crowded places.

The alternative to the password-based approach,

graphical patterns, beneﬁt from faster input, but are

even easier to memorize by casual observers.

Biometric techniques like ﬁngerprint scanning or

facial recognition are still not widely deployed and

can usually be circumvented by using a simple photo-

graph or fake ﬁngerprints.

In contrast to these methods, the token-based au-

thentication approach described in the next section

covers all the requirements deﬁned above.

3 THE PROPOSED METHOD

The proposed method uses a hardware token to au-

thenticate the user to the smartphone. When the token

is in range, no additional user interaction is required.

A service running on the smartphone handles the au-

thentication process. Therefore an authentication pro-

tocol as described in the next section is required. The

protocol has to take the limited resources of the to-

ken hardware into account. It is important to keep the

authentication process as fast and secure as possible,

with respect to the low computational power of the

MCU and the limited amount of energy available to

the token.

If the token is out of range, or is unable to commu-

nicate with the smartphone, the proposed method falls

back to the most commonly used password/PIN ap-

proach. Since this rarely happens during normal op-

erating conditions, the password can be chosen long

and secure without unduly affecting usability.

A successful token-based authentication causes no

user interaction at all. On the downside, the user has

to carry an additional piece of hardware with him. In

practice the token functionality could for example be

integrated with a USB memory stick and attached to a

keyring, resulting in a negligible extra burden for the

user.

An attacker now either has to acquire both, the

smartphone and the hardware token, or guess/know

the password, which can be chosen to be long, com-

plicated and secure, since it only has to be entered

when the token is not present.

4 THE AUTHENTICATION

PROTOCOL

The authentication protocol described in this paper

belongs to the class of challenge-response protocols.

They allow one party to gain assurance of the iden-

tity of another (Menezes et al., 2001). For the ﬁrst

proof-of-concept we decided to implement our own

protocol, based on well-known primitives like Difﬁe-

Hellman, which also allows for periodic rekeying. As

future work we plan to also evaluate different exist-

ing challenge-response protocols for the suitability of

the constrained environment present in our usage sce-

nario. Our protocol consist of three phases:

Key Establishment. In this phase a shared secret is

generated. It is triggered by the user and is

based on the Difﬁe-Hellman key exchange proto-

col (Difﬁe and Hellman, 1976).

Authentication. This phase consists of a hash based

challenge-response protocol.

Rekeying. Periodical rekeying prevents brute force

attacks. After a given time or number of authenti-

cation attempts a new shared secret is generated.

DCNET2013-InternationalConferenceonDataCommunicationNetworking

4.1 Key Establishment

Before authentication can take place, the token and

the smartphone need to generate a shared secret. The

user triggers this action. He activates the key estab-

lishment function in the conﬁguration software on the

handset and then presses a button on the token. Now

a session key is established. This step should be exe-

cuted in a - more or less - secure environment, away

from potential eavesdroppers and men-in-the-middle.

It has to be performed only when agreeing on a new

secret or when pairing with a new device.

In the following we give a short summary of the

key establishment phase using the Difﬁe-Hellmann

protocol, where A → B denotes a message sent from

A to B. The token T and mobile phone M share a

prime p and a generator g.

Step 1: M and T each generate a random number

and r

. These are their respective secret keys.

Step 2: Each party computes its own A

and sends

this parameter to its partner.

M : A

= g

mod p

M → T : A

T : A

= g

mod p

T → M : A

Step 3: The authentication partners compute the

shared secret S from these parameters.

M : S = A

= g

∗r

mod p

T : S = A

= g

∗r

mod p

Step 4: Finally both parties generate the session

key K from the shared secret by hashing this value.

M, T : K = h(S)

Note that it would also be possible to add more en-

tropy to this key by using system parameters like

timestamps in the hash, with the tradeoff of increas-

ing the message size or requiring time synchroniza-

tion between the token and the smartphone.

4.2 Authentication

The authentication is performed by a challenge-

response protocol. Hashing is used to secure the

communication since hash algorithms are deemed

the most energy efﬁcient among cryptographic

algorithms, according to (Potlapally et al., 2006).

As communication has the biggest impact on power

consumption and no mutual authentication is needed,

the protocol only authenticates the token to the smart-

phone. This allows successful protocol execution by

using only two messages.

Step 1: M generates a nonce N and sends it to the

token T.

M → T : N

Step 2: T concatenates (denoted by |) the session

key K with N and generates the hash of the resulting

value. The calculated hash value H

is sent back to

T → M : H

= h(N|K)

Step 3: M calculates H

from the nonce and K

= h(N|K)) and compares it to the received H

If they are equal, T is authenticated successfully.

4.3 Rekeying

To weaken the possibility of brute force attacks,

the session key is subject to change after either a

pre-deﬁned time has elapsed or a given number of

messages has been sent. Each of the two parties

can initiate the rekeying process at any time. Note

that while the shared secret can also be changed by

performing the key establishment phase given in 4.1,

the main idea of the rekeying phase is to periodically

refresh the used key without active user interaction.

The steps of the rekeying phase can be summarized

as follows:

Step 1: Either M initiates the rekeying by sending

a start message to T or T starts on its own. In both

cases T generates a random number r

and sends it to

T → M : r

Step 2: M saves the old session key K as K

old

After this a new random number r

is generated. r

is used to calculate the new session key as the hash

value of r

and K

old

. Finally, r

and the hash value

of r

, r

and K

old

are sent to T.

M : K

old

= K

M : K = h(r

old

)

M → T : r

, H

= h(r

old

)

Step 3: T receives r

and the hash value and cal-

culates the hash value by itself. If this is equal to the

one received, the new session key K is generated.

T : K

old

= K

T : H

= h(r

old

)

= H

T : K = h(r

old

)

Token-basedAuthenticationforSmartphones

Step 4: M still does not know if the rekeying was

successful. This will be checked during the next au-

thentication attempt. After receiving the hash value

from the token, M calculates its own hash value with

the new session key (as detailed in 4.2, Step 3). If

these values match the authentication, rekeying was

successful. Otherwise M uses K

old

to calculate the

hash value. If this value matches, the rekeying has

failed and has to be restarted. If this value still does

not match, an error has occurred during the authenti-

cation process.

Note that this approach leaves room for a desyn-

chronization and/or DOS attack, as detailed in the fol-

lowing section.

5 SECURITY ANALYSIS

In (Mobahat, 2010) the author deﬁnes several security

threats for authentication. In this section the proposed

authentication protocol will be analyzed against these

issues.

5.1 Information Leakage

The messages sent do not contain information beside

the hashes of values containing the key and random

numbers. Due to the one-way characteristics of cryp-

tographic hash functions this is not a problem. The

token will answer on every request for the same nonce

N with the same hash as long as the key does not

change. This allows identifying a user by his token.

A possibility to prevent user identiﬁcation by at-

tackers would be mutual authentication. The smart-

phone has to authenticate itself to the token before an

answer is sent. This solution requires additional com-

munication effort.

5.2 Spooﬁng Attack

It is known that the Difﬁe-Hellman key exchange pro-

tocol is vulnerable to man-in-the-middle attacks. An

eavesdropper can intercept the secret while the shared

secret is established. This could be avoided by using

an authenticated key exchange protocol, but since this

explicit secret establishment only happens very infre-

quently and at the user’s request, it can be required

and therefore assumed that it happens in a secure en-

vironment under the user’s control.

During the authentication process itself a man-in-

the-middle can only act as relay station. He can in-

tercept messages and send them to the token/mobile

phone and will extend the authentication range this

way, thereby being able to unlock the phone without

having obtained the token. To thwart this attack the

token should be powered off when the secured device

is lost.

5.3 Replay Attack

Intercepted hashes can only be used for replay attacks

when the mobile phone reuses a nonce between two

rekeyings. To prevent brute force collection of hash

values there is a limit for the number of authentica-

tions performed with the same key. If this limit is

reached the rekeying process is initiated.

5.4 Forward Security

If the key setup is compromised and the initial key is

revealed, or the attacker gains a key from authentica-

tion messages, he will be able to obtain the actual key

as long as he receives every rekeying message until

then. If an old key is obtained from a hash value af-

ter a rekeying, the attacker is unable to make any use

of it. To secure the keys against brute force attacks,

the shared key has a limited lifetime and number of

authentication cycles.

5.5 Desynchronization

Desynchronization can stop the authentication or

rekeying, and may even completely prevent any fur-

ther authorizations. In this case, a new key establish-

ment phase as described in 4.1 is necessary. Usage of

the phone itself is not affected, since when authenti-

cation cannot be completed using the token method,

the phone simply asks the user for the passphrase.

5.6 DOS Attack

Denial of service attacks can be mounted against the

token and the mobile phone. The token can be cut

off the communication by interrupting the radio chan-

nel. Repeated authentication or rekeying requests can

have a signiﬁcant impact on battery lifetime. The bat-

tery usage of the mobile phone can be raised by fre-

quently requesting rekeying. These battery draining

attacks can be softened by limiting the number of re-

quest in a given time. If the token is not available

the user can still use a password or pin to unlock the

smartphone.

6 PROTOTYPE

The prototype was implemented on a smartphone run-

ning Android 2.3. As hardware base for the token

DCNET2013-InternationalConferenceonDataCommunicationNetworking

Figure 1: Interactions between the prototype’s components and the user.

the EZ430-RF2560 evaluation board (Texas Instru-

ments, 2012) from Texas Instruments was chosen.

The MSP430BF5190 MCU runs at up to 25 MHz and

has 16 KB RAM. The two partners communicate over

Bluetooth. Figure 1 shows the schematic layout of the

prototype components as well as their interaction with

each other and the user.

On the smartphone side a background service is

watching for unlock events. These events are trig-

gered by Android when the user unlocks the phone.

To prevent accessing the device before the authenti-

cation was successful, the Unlock-Activity is started.

If the user tries to leave this screen the phone will be

locked again. After successful authentication the un-

lock screen is closed and the smartphone is ready for

use. In case of authentication failure a user-deﬁned

password is set and the phone is locked. For pass-

word protection, the built-in Android password func-

tionality is used. Password authentication automati-

cally ends when the correct password is supplied.

Figure 2 shows the authentication process from

the user’s point of view. When the token is not

present, as seen on the top of the right side, the user is

asked to enter her password. If the token is in range,

as depicted at the bottom, the smartphone is unlocked

without requiring any further interaction.

SHA-256 was selected as hash function. On the

smartphone the standard Java security libraries were

used. On the token the MIRACL library (CertiVox,

2013) provides the functionality needed for hashing

and key generation. The prime p was chosen to be

1.024 bits long, g is the number 2, r

and r

consisted

of 256 bits each.

In terms of computing time, for every authenti-

cation both the token and the mobile phone have to

perform a single hash calculation. The token has to

Figure 2: Authentication process from user’s view.

receive and send a 256 bit message (receive the nonce

and send the hash-value), as does the mobile phone.

Rekeying is more costly, requiring two hash calcu-

lations on each side, but still only one 256 bit mes-

sage has to be sent and received by token and mobile

phone, respectively.

Key establishment ﬁnally is the most computa-

tionally intensive phase, but also the one that has to

performed most infrequently. It requires two modu-

lar exponentiations with a 1.204 bit long modulus on

each side, as well as the exchange of two 1.204 bit

long values.

In terms of running time, generation of the shared

secret with the Difﬁe-Hellman protocol takes about

120 million cycles. This gives a duration of 6 to 7

seconds, but since this step only has to performedvery

infrequently the impact on usability is negligible.

The calculation of the hash value takes about

Token-basedAuthenticationforSmartphones

400.000 cycles or 22 ms. A complete unlock action

including authentication can be performed in less than

a second which is usually much faster than using com-

mon methods like passwords or patterns, and, in con-

trast to these approaches, completely transparent to

the user.

7 CONCLUSION

The concept of token-based authentication for smart-

phones described in this work addresses the problem

of improving the security as well as the speed and us-

ability of authentication methods currently available

on smartphones. The implemented prototype proves

that user authentication can be performed secure, fast

and easy to use, without requiring root access to the

smartphone. The downside of this approach is the ad-

ditional hardware which the user has to carry around.

Future work is planned to investigate other available

challenge-response protocols for their security and

suitability to the given constrained environment.

The evaluation of the prototype shows that our

proof-of-concept is feasible in practice and that there

is even still a margin in terms of communication and

computational effort to improve upon our current pro-

posal.

Finding other secure authentication methods for

smartphones with a focus on usability still remains a

broad ﬁeld of research. The proposed solution has

been designed without relying on any authentication

mechanisms inherent in the wireless channel, so it can

be easily adapted to new, energy-efﬁcient technolo-

gies like Bluetooth 4.0, NFC or others.

REFERENCES

Aviv, A. J., Gibson, K., Mossop, E., Blaze, M., and Smith,

J. M. (2010). Smudge attacks on smartphone touch

screens. In Proceedings of the 4th USENIX confer-

ence on Offensive technologies, WOOT’10, pages 1–

7, Berkeley, CA, USA. USENIX Association.

CertiVox (2013). Certivox miracl crypto sdk.

http://certivox.com/index.php/solutions/

miracl-crypto-sdk/

Cozza, R., Milanesi, C., Zimmermann, A., Nguyen, T. H.,

Vergne, H. J. D. L., Shen, S., Gupta, A., Sato, A., Lu,

C., and Glenn, D. (2012). Market share: Mobile de-

vices by region and country, 4q11 and 2011. Technical

report, Gartner Report.

Difﬁe, W. and Hellman, M. (1976). New directions in cryp-

tography. Information Theory, IEEE Transactions on,

22(6):644 – 654.

D¨orﬂinger, T., Voth, A., Kr¨amer, J., and Fromm, R. (2010).

”my smartphone is a safe! ” the user’s point of view

regarding novel authentication methods and gradual

security levels on smartphones. In Security and Cryp-

tography (SECRYPT), Proceedings of the 2010 Inter-

national Conference on, pages 1 –10.

Menezes, A. J., van Oorschot, P. C., and Vanstone, S. A.

(2001). Handbook of Applied Cryptography. CRC

Press, 5th printing edition.

Mobahat, H. (2010). Authentication and lightweight cryp-

tography in low cost rﬁd. In Software Technology and

Engineering (ICSTE), 2010 2nd International Confer-

ence on, volume 2, pages V2–123 –V2–129.

Potlapally, N. R., Ravi, S., Raghunathan, A., and Jha, N. K.

(2006). A study of the energy consumption charac-

teristics of cryptographic algorithms and security pro-

tocols. Mobile Computing, IEEE Transactions on,

5(2):128 – 143.

Texas Instruments (2012). Texas instruments inc.: Msp430

+ cc2560 bluetooth platform.

http://www.ti.com/

lit/ml/swpt038/swpt038.pdf

Thanh, D. V., Jorstad, I., Jonvik, T., and Thuan, D. V.

(2009). Strong authentication with mobile phone as

security token. In Mobile Adhoc and Sensor Systems,

2009. MASS ’09. IEEE 6th International Conference

on, pages 777 –782.

DCNET2013-InternationalConferenceonDataCommunicationNetworking
