Addressing the Terms-of-Service Threat

Client-side Security and Policy Control for Free File Storage Services

Geir M. Køien and Vladimir A. Oleshchuk

University of Agder, Institute of ICT, Grimstad, Norway

Keywords:

Public Cloud Services Terms-of-Service, Producer-consumer Asymmetry, Conﬂicting-incentives, Content

Ownership, Security and Privacy, Trust, Policy Control, Reputation, Presentation Layer Manager.

Abstract:

In this paper we describe and identify the so-called terms-of-service (ToS) threat. This threat is concerned

with asymmetry in the power between a service producer (SP) and the service consumer (SC) and is expressed

in ToS which allows the SC to change the ToS at will. Our context is the free ﬁle synchronization services,

and we will analyze the relationships between the service producer and the service consumer. There are

pronounced control asymmetries and potential conﬂicts of interest between the parties, including user privacy

and content ownership control. Our proposal for addressing these problems hinges on a two pronged approach,

including deﬁning a service policy manager surveillance tool and a client side presentation manager to enforce

local security and privacy policies. Our Umbrella Architecture is still very much work in progress, but we are

optimistic about usefulness the approach.

1 INTRODUCTION

In this paper we investigate potential solutions to the

problem now known as the terms-of-service (ToS)

threat (Schneier, 2013). This threat emerges when

the terms of service is formulated such that it may be

changed unilaterally by the service producer. This can

cause conﬂicts as was highlighted by the resent In-

stagram debacle (Thomson, 2012), where Instagram

changed its terms of service to allow itself the right to

sell user photos. In this case Instagram was forced to

revise the change to its ToS after a public outcry, but

it turns out that many of the “free” internet services

do contain similar terms of service.

We speciﬁcally investigate the ToS threats that

may arise in the context of free ﬁle storage and syn-

chronization services. We analyse the power relation-

ships between the service producer and the service

consumer and we investigate the conﬂict of interests

inherent in these agreements using the Conﬂicting In-

centives Risk Analysis (CIRA) model (Rajbhandari

and Snekkenes, 2012).

We propose to address the ToS threat by a com-

bination of several measures in what we call the

Umbrella Architecture. The main part consists

of a client-side presentation layer security manager

(PLaSM) which will protect the user content. The

PLaSM will provide a set of security protection fea-

tures and these will be available at all times for the

user. These will as a minimum include ﬁle encryption

and ﬁle integrity services.

The other components are a policy monitoring

agent (PoMA) and a reputation manager (ReMa). The

PoMA will monitor the ToS and will alert the con-

sumer in case of changes and the reputation manager

will gather information about the reliability and trust-

worthiness of the SP. The PoMA and the ReMa may

also trigger actions, called strategies in CIRA par-

lance. These actions will then be carried out by the

PLaSM. The net result will be improved security and

privacy for user content stored by cloud ﬁle storage

services.

2 ANALYSIS OF THE

TERMS-OF-SERVICE THREAT

2.1 Background

Needless to say for a free service, but the offering

party obviously gets to dictate the premises of the

ToS. There is of course a larger societal context that

the SP must take into account, both with respect to

legal requirements and with respect to customer re-

actions. In (Braman and Roberts, 2003) the authors

562

M. Køien G. and A. Oleshchuk V..

Addressing the Terms-of-Service Threat - Client-side Security and Policy Control for Free File Storage Services.

DOI: 10.5220/0004520205620569

In Proceedings of the 3rd International Conference on Cloud Computing and Services Science (CloudSecGov-2013), pages 562-569

ISBN: 978-989-8565-52-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

discusses the legal aspects of ToS in the context of an

ISP. The paper is US centric, but the general conclu-

sions should hold in most jurisdictions.

The agreements are written in a language intended

for lawyers rather than laymen. Furthermore, the SC

generally has little speciﬁc knowledge about his/her

rights to start with. So, informally, we summarize the

ToS threat as the following:

• ToS statements are not very readable to the lay-

man (read: ToS are seldom read)

• ToS are subject to unilateral change by the SP

(and the notice could well go unnoticed)

• ToS regulate rights to the contents stored by the

SP, and this may seriously affect the SC content

ownership rights and SC privacy.

2.2 Security and Privacy Aspects

2.2.1 Accountability and Availability

Accountability is an important aspect for almost all

cloud based services. Big service producers like Ap-

ple, Google, Microsoft, Amazon, Dropbox etc. are

generally reputable organizations, and we may as-

sume that they will providereasonableservices and be

accountable for them. Smaller outﬁts may or may not

be reputable, and in the wake of a bankruptcy or sim-

ilar it will be anybodies guess as to how well behaved

they will be. However, the catch is playing by the

rules, which are those captured in the ToS. As demon-

strated by the Instagram case the companies exists in

a societal context, and this may prevent a company

from abusing their rights.

Availability is another important aspect. It is of

course purported to be a major beneﬁt of cloud stor-

age and for the ﬁle synchronization services one will

usually have local access to the data anyhow. In our

context we have decided not to pursue availability fur-

ther, but note that this aspect has been addressed in the

context of paid-for services (Bowers et al., 2009).

In our context we have decided not to address the

accountability and availability aspects directly. That

is, we assume that the required minimum of account-

ability and availability features are already present in

the provided services.

2.2.2 Privacy, Identiﬁcation, Authentication,

Integrity and Conﬁdentiality

The identiﬁcation used in most of the services is based

on email addresses. These are not particularly pri-

vacy sensitive, although we want to avoid unneces-

sary exposure. Identity privacy itself is a concern, al-

though not the primary privacy concern her. We note

that the authentication schemes for free service seems

not to be particularly strong, but with additional data

protection they may be adequate. This needs to be

veriﬁed. Otherwise, we note that privacy has many

facets and that one correspondingly must have a mul-

tifaceted approach when counteracting and mitigating

privacy problems (Oleshchuk and Køien, 2011).

In (Subashini and Kavitha, 2011) the authors out-

line a set of security issues in delivery models in cloud

computing. These issues are mostly concerned with

enterprises using paid-for cloud services, but we note

that many of the concerns are similar. Another paper

which investigates these issues is (Zhao et al., 2010)

and this paper is interesting in that it distinguishes

between different deployment models. With respect

to our case we note that the consumer will not have

much inﬂuence upon the chosen model, apart from

what can implement at the client side. Another in-

teresting paper is (Bernsmed et al., 2011) in which

there is an attempt at deﬁning service level agree-

ments (SLA) for cloud security. Our context is differ-

ent and so the consumer will not be able to negotiate

SLA arrangements, but is rather left with a ToS that

he/she cannot negotiate.

It should be evident that we need both data in-

tegrity and data conﬁdentiality. The SC needs to

ensure that the stored data isn’t manipulated against

his/her will and likewise the SC need assurance that

the stored data isn’t unduely exposed. Many, if not

most, of the free public ﬁle storage services do not

offer data conﬁdentiality services. Data integrity are

offered to the extent that this is directly supported by

the ﬁle systems used. The quality may be acceptable

for most uses, but fails to cover cases where the SP is

the source of the threat.

We also want access control for our data. The de-

fault should be that the SC is the only one with access.

Other parties may be granted full or partial access

by the SC. The service producers commonly provide

schemes to allow this kind of access control. The au-

thentication provided seems generally to rely on pass-

words and it seems only to be unilateral. We have not

assessed the strength of the schemes, but sufﬁce to say

that they are designed for “low grade” systems. That

is, they are probably fairly weak, but may still be sta-

tistically adequate for the givenpurpose. We therefore

propose to rely on the existing authentication and ac-

cess control scheme offered by the service producer,

but we do not exclude the possibility of enhancing it.

Requirements (partially fulﬁlled):

• Identity privacy (not addressed)

• Data conﬁdentiality (strong requirement)

• Data integrity (partially fulﬁlled)

AddressingtheTerms-of-ServiceThreat-Client-sideSecurityandPolicyControlforFreeFileStorageServices

563

• Consumer-Producer Authentication scheme

• Access control (acceptable)

To summarize, we must provide data conﬁdential-

ity and we ought to provide data integrity services.

When it comes to the scope of the protection it should

be evident that ﬁle data must be protected, but there

is also a strong case for protecting ﬁle system data,

particularly the ﬁle/directory names. One may pro-

vide enhanced access control, but there will be a cost

to doing this. One also improve the authentication,

but it may be the case that the access oriented authen-

tication is sufﬁcient when one consider a scheme in

which the data is explicitly protected independently

of the access procedures. The two last requirements

above will therefore largely be for the existence of an

adequate solution.

2.2.3 Trust Aspects of the Consumer-producer

Relationship

The legal/contractual relationship is deﬁned by the

ToS, but what about the trust aspects? There are

ways of assessing trust in an online context. We ap-

proaches such as the one laid out in (Pelechrinis et al.,

2011) with automated evaluation of Q&A sessions

over so-called online social networks (OSN). Repu-

tation is keyword here and there are formalized ap-

proaches that directly uses reputation in the model

(Jøsang, 2010). A survey of relevant proposals for

handling trust and reputation in an online context is

found in (Jøsang et al., 2007). Of course there are

many aspects to trust. In (Køien, 2011) the author

discusses this in the context of publicly available IoT

services, and while the cloud context is somewhat dif-

ferent from an IoT context, many of the same ideas of

trust in an IoT environment will also apply to cloud

services. This leads us to assume that trust in free

public cloud based services will largely be based on

reputation and association with well-known brands.

This is not the soundest basis one can have for secu-

rity, and so we must provide some means of enforce-

ment for the trust be warranted. Another survey paper

handling trust and trust management in an internet ap-

plication context is found in (Grandison and Sloman,

2000). The context is not speciﬁc to cloud services,

but the discussion is relevant in that it handles trust

and decision making for internet applications.

2.2.4 Control Aspects of the

Consumer-producer Relationship

Who has control in our Consumer-Producer relation-

ship? Given the asymmetry in power regarding the

ToS it should be clear that SP obviously has both ju-

risdictional control and operational control over the

service. That is, the control is there as long as the

consumer continues to use the service. There are sev-

eral free ﬁle storage services in the market and there is

therefore a certain amount of competition. The con-

sumer may have concrete needs, but he/she can nev-

ertheless choose between different alternatives. How-

ever, once we have actually made a choice there will

be transaction costs to switch to an alternative ser-

vice. We should add to this picture that many ser-

vices comes in bundles and as pre-installed software

on smart mobiles, tablet and laptops. So we may

conclude that he consumer has a great deal of power

to choose, but that the ability is impeded by imper-

fect knowledge, by default (pre-installed) solutions,

by technical inability to change conﬁguration and by

loss of convenience and cost optimizations.

2.3 The Conﬂicting Incentives

Approach

2.3.1 Conﬂicting Incentives Risk Analysis

The Conﬂicting Incentives Risk Analysis (CIRA)

(Rajbhandari and Snekkenes, 2012) is a method for

analysing risk under circumstances where it is hard

to assess incident probability. This may be the case

for infrequent events and generally for circumstances

where past history cannot be used to predict future

likelihoods. The CIRA method will instead assess the

motives and incentives of the different principals. To

do so the method draws on game theory, economics,

psychology and decision theory. When analysing the

ToS threat scenarios we may beneﬁt from using a sim-

ilar approach. Technical threats by external intruders

are of course still a major concern, but what if the mo-

tives and incentives of the principals are themselves a

main driver behind many of the threats?

2.3.2 The Utility Function and the Strategy

Concept

In CIRA one has deﬁned a risk owner and it deﬁnes

the perspective taken. To our end we deﬁne the SC

as the risk owner. The SP is the other principal en-

tity. Then we have the strategy concept. A strategy

is here some action that is intended to inﬂuence the

utility function. The strategy owner is the principal

that is in a position to execute the strategy. In our

case we want to deﬁne strategies that lower the threat

against stored content and the utility function must

correspond to these goals. That is, the utility function

must capture the requirements in section 2.2.2. Any

strategy that positively contribute to this end is seen as

desirable. There will be transaction costs to executing

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

564

a strategy and it is thus not obvious that one should

always execute a strategy, but even the awareness of

an available strategy may be beneﬁcial.

2.3.3 Mindset

We do’t speciﬁcally propose to apply the CIRA

method as as such, but we do advocate to have a

“Conﬂicting Incentives” mindset when analysing ToS

threats. That is, to keep in mind that the other prin-

cipal party will have different interests and that those

will govern it’s actions. The consumer had better ac-

count for this and carry out actions (strategies) to miti-

gate or prevent negative outcomes. The key to success

is to identify the appropriate utility function(s) and to

identify useful strategies that address dire threats and

unacceptable risks.

2.3.4 Content Ownership

A prudent question in all security is “What are the

assets?” In our context the parties will be the SP

and the SC and clearly the stored “contents” is an as-

set. Content ownership, copyrights etc. are potential

“conﬂicting incentives” areas. SC must therefore as-

sume that he/she must contribute something to SP in

the deal. One obvious contribution is information and

another is potential future loyalty. Of course, actual

“contents” may also be contributed. This can be a

win-win situation, like a consumer uploading content

to YouTube - where both parties win if the content is

widely shared.

The content in our case is exclusively provided by

the user (SC), but may be used or licence by the SP

(depending on ToS conditions). While there may be

win-win situations we also have the distinct possibil-

ity that the equation is unbalanced and that it can even

be a negative sum game (Burgess and Burgess, 1997).

The utility function may be hard to deﬁne, but in a

game theoretical sense we can only assume that the

function is such that at least one part will expect a

positive outcome (Binmore, 2007).

The “expect a positive outcome” part highlights

the fact that there is a distinct difference between real

and perceived utility. We shall not go into the psy-

chology of perception here, but sufﬁce to say that

emotional responses is important. In (Camerer, 2011)

one discusses how emotions and limited foresight af-

fects our perception of utility and ultimately our deci-

sion making.

3 TERMS-OF-SERVICE POLICY

CONTROL OPTIONS

ToS policies of most cloud service providers are pre-

sented in the form of long text in plain English that

most users will never read. However, reading and

understanding of such policies are crucial for secu-

rity and privacy for users of these services. Since

such policies may be a subject to change, the con-

tinuous monitoring of security and privacy related

changes is necessary and could be implemented as

a part of MaaS (Monitoring-as-a-Service) (Meng and

Liu, 2012). One possible approach can be based on

text analysis and meaning extraction with special fo-

cus on those parts of ToS policies that can potentially

inﬂuence users security and privacy. By timely iden-

tifying such threats, users could undertake necessary

measures to protect of both their security and privacy

as required by their own policy. Possible measures

could be, for example, to enforce encryption of down-

loaded content to guaranty conﬁdentiality; to enforce

encryptionor anonymizationof some parts of the con-

tent to provide privacy; to require distribution of data

among several independent service providers to in-

crease availability, etc. It is important for users to be

aware of treats that potentially may appear as result

changes in ToS policies. In that, there is a need for

formal representation of policies, for example in P3P

style, to simplify extraction of features that can be a

security and privacy threats for the users. However,

since ToS policies are usually written in plain English

we have to deal with natural language understanding.

Since it is generally a difﬁcult problem one cannot

expect a perfect solution. Our approach is to propose

a practical approach that will help users to monitor

changes of ToS but, in the end, will need human in-

volvement to make ﬁnal decision.

One notable feature of many ToSs is that many

of them permit the service provider to a) unilater-

ally change the ToS and b) to only inform the ser-

vice user by notiﬁcation on a webpage and possible

by an email. Thus, even the interested consumer may

not notice that there has been a change in the ToS.

Even uninterpreted notiﬁcation by the policy moni-

toring agent (PoMA) will therefore have value.

3.1 Case Study

Let us consider some example of ToS policies of some

well-known companies. Such policies are presented

in plain English and therefore a method for text anal-

ysis and meaning extraction should be developed. To

illustrate our idea we have extracted sentences con-

taining keywords grant, right to use, license to use

AddressingtheTerms-of-ServiceThreat-Client-sideSecurityandPolicyControlforFreeFileStorageServices

565

or to distribute in ToS policies of some popular cloud

service providers:

• From Linkedin: “ ...you grant LinkedIn a nonex-

clusive, irrevocable, worldwide, perpetual, unlim-

ited, assignable, sublicenseable, fully paid up and

royalty-free right to us to copy, prepare derivative

works of, improve, distribute, publish, remove,

retain, add, process, analyze, use and commer-

cialize, in any way now known or in the future

discovered, any information you provide, directly

or indirectly to LinkedIn, including, but not lim-

ited to, any user generated content, ideas, con-

cepts, techniques or data to the services, you sub-

mit to LinkedIn, without any further consent, no-

tice and/or compensation to you or to any third

parties ...“

• From Instagram: “ ...you hereby grant to In-

stagram a non-exclusive, fully paid and royalty-

free, transferable, sub-licensable, worldwide li-

cense to use the Content that you post on or

through the Service, subject to the Service’s Pri-

vacy Policy,...“

• From Evernote: “ ...you grant Evernote a license

to display, perform and distribute your Content

and to modify (for technical purposes, e.g., mak-

ing sure content is viewable on smart phones as

well as computers) and reproduce such Content to

enable Evernote to operate the Service. “

• From Facebook: “ ...you grant us a non-

exclusive, transferable, sub-licensable, royalty-

free, worldwide license to use any IP content that

you post on or in connection with Facebook (IP

License). “

• From Box: “ You hereby grant Box and its con-

tractors the right, to use, modify, adapt, repro-

duce, distribute, display and disclose Content

posted on the Service solely to the extent neces-

sary to provide the Service or as otherwise per-

mitted by these Terms. “

• From Comcast (and Plaxo): “ If you post any con-

tent to the Comcast Web Services, you hereby

grant Comcast and its licensees a worldwide,

royalty-free, non-exclusive right and license to

use, reproduce, publicly display, publicly per-

form, modify, sublicense, and distribute the con-

tent, on or in connection with the Comcast Web

Services or the promotion of the Comcast Web

Services, and incorporate it in other works, in

whole or in part, in any manner. “

• From Amazon: “ ...you grant Amazon a nonex-

clusive, royalty-free, perpetual, irrevocable, and

fully sublicensable right to use, reproduce, mod-

ify, adapt, publish, translate, create derivative

works from, distribute, and display such content

throughout the world in any media. “

The list of keywords can be easily expanded

and patterns for matching can be regular expres-

sion for example such as: {

grant | license |

right

}

to <company name>

or {

license to

{

use

| reproduce | modify |distribute

Just reading these few extracts provide users with

hints of potential threats to their security and privacy

from these services, that is an understanding that ser-

vice providers keep the right to use, distribute etc.

their content.

3.2 Monitoring Terms-of-Service

Policies

In order to be aware of possible security and pri-

vacy treats users have to be aware of changes in

ToS policies. Monitoring and detection of changes

should support two features: discovering of changes

in ToS policies and discovering of security and pri-

vacy related changes in ToS policies. The ﬁrst kind

of changes is easy to implement, since it means de-

tection of any changes in a text and does not require

understanding of these changes. The second feature

requires at least a rudimentary understanding of texts.

Some cloud-monitoring applications have already

been described in the literature, for example, SLA Vi-

olation Detection (Emeakaroha et al., July), Resource

Usage (Dhingra et al., 2012), etc. However, we could

not ﬁnd any policy monitoring applications.

In our approach, we propose to use monitoring

agent running locally on users computer and analyz-

ing changes of ToS policy each time user use the

service. The user register websites policy locations

in the agent database for each cloud service he/she

uses. Monitoring agent analyzes the policy text to

detect changes from last time the service was used.

The monitoring is based on the idea informally pre-

sented in the previous subsection. In case the change

is detected, the agent will identify new sentences, re-

moved sentences and modiﬁed sentences. By match-

ing patterns, the agent extracts sentences (containing

patterns) that may be potentially associated with se-

curity and privacy threats.

For example, pattern

license to

{

use

| reproduce | modify | sublicense

|distribute

} means that conﬁdentiality of

users data may be violated. If it is a storage service

and such feature is considered as violation of users

security policy an encryption of all data have to be

activated. An example of conﬁguration table for the

PoMA is shown at Figure 1.

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

566

ToS location Pattern Violation Action

http://instagram.com/ {grant|license|right} Privacy Encryption

about/legal/terms/

{use|reproduce|modify

|sublicense|distribute}

https://www.box.com/ Conﬁdentiality, Encryption

-””- Privacy

http://www.linkedin.com/static? Privacy No actions

key=user agreement& -””- available

trk=hb ft userag

Figure 1: Conﬁguration table for ToS monitoring agent.

4 CLOUD BASED STORAGE

SERVICES

4.1 File Storage and Synchronization

Services

There are several publicly available cloud-based ﬁle

storage services like Dropbox, Google Drive and Mi-

crosoft SkyDrive. Generally, the free services are re-

stricted in the amount of storage they offer. These ﬁle

storage services mirrors a directory tree at the target

computer. All ﬁles placed in the target directory will

be synchronized and a copy of the ﬁles will be stored

in the cloud by the service. The beauty the schemes is

that one may synchronize several computers this way.

Enterprises and businesses are understandably

concerned about storing their essential business data

in a public cloud storage facility. In the article “New

Approaches to Security and Availability for Cloud

Data” (Juels and Oprea, 2013) the authors discusses

these problems and proposes some solutions. The ten-

ants (consumers, SC) will have to be convinced that

security and availability is ensured or otherwise they

will tend to favour private clouds instead of public

clouds. The power balance between a paying tenant

(SC) and a public cloud service provider (SP) may

not be balanced, but SP clearly have an incentive to

accommodate the paying tenant. Our perspective is

a little different from that of (Juels and Oprea, 2013)

our scope for cases where the power balance is very

different. We also assume a model where the data is

mirrored at the tenants computers. Free services will

also have some kind of authentication and access con-

trol, but that is very often all that is provided. Use of

cryptography is clearly necessary to provide credible

security for data stored in a public cloud and availabil-

ity may dictate schemes similar to the RAID inspired

HAIL scheme proposed in (Juels and Oprea, 2013).

HAIL itself is an acronym for High-Availability and

Integrity Layer (Bowers et al., 2009). We do not con-

sider a HAIL-based approach here. Instead, we do

propose a model with basic security services imple-

mented at the presentation layer. Our scheme is in

concordance with Presentation layer in the Systems

Interconnection (OSI) Reference Model, and this also

means that the implementation is at the host (tenant)

and not at the SP.

4.2 An OSI “Presentation Layer”

Solution

The OSI reference model (ISO/IEC 7498-1, 1994) is

deﬁned by the International Organization for Stan-

dardization (ISO). The OSI RM is a way to describe

and characterize a communications stack in terms of

abstraction functions deﬁned at different layers. Each

layer serves the layer above it and is served by the

layer below. Layer 6 is the presentation layer and

it is primarily concerned with services such as data

representation, encryption and decryption, converting

machine dependent data to machine independent data

etc. For connectionless services (IP-based) recom-

mendation (ISO/IEC 9576-1, 1995) applies.

4.3 The Umbrella Architecture

Our proposal, which we call the Umbrella Archi-

tecture, is depicted in ﬁgure 2. The proposal com-

bines the services of the presentation layer security

manager (PLaSM) and the policy monitoring agent

(PoMA). In our scheme we have let there be a local

PoMA which communicates with a MaaS cloud ser-

vice to carry out the actual ToS monitoring. We op-

tionally also propose to have a reputation manager in

the system. The reputation manager will use methods

discussed in (Jøsang, 2010; Pelechrinis et al., 2011)

to extract information about the reliability and trust-

worthiness of the SP. The work in (Pelechrinis et al.,

2011) will need to be extended to achieve full “repu-

tation” handling. We do not further develop the repu-

tation manager concept in this paper.

4.3.1 Scope and Basic Architecture

We do not attempt to cater for all possible security

AddressingtheTerms-of-ServiceThreat-Client-sideSecurityandPolicyControlforFreeFileStorageServices

567

S E R V I C E C O N S U M E R

( l o c a l c o m p u t e r )

S E R V I C E P R O D U C E R

C l o u d - b a s e d s t o r a g e f a c i l i t y

S y n c h r o n i z a t i o n s e r v i c e s

L o c a l f i l e s t o r a g e

F i l e M a n a g e r

w i t h

P L a S M

F i l e S t o r g a g e

a n d

S y n c h r o n i z a t i o n

M a p p e d

s t o r a g e

P L a S M

s t o r a g e

L o c a l

P o M A

S E R V I C E P R O D U C E R

" M o n t o r i n g a s a S e r v i c e "

s e r v i c e

T o S m o n i t o r i n g

T o S m o n i t o r i n g s u b s c r i p t i o n

T o S n o t i f i c a t i o n

B a c k u p

s t o r a g e

R e p u t a t i o n

m a n a g e r

R e p u t a t i o n

N o t i f i c a t i o n

S o c i a l

N e t w o r k A

" R e p u t a t i o n " m o n i t o r i n g n t o t i f i c a t i o n

S o c i a l

N e t w o r k B

S o c i a l

N e t w o r k C

R e p u t a t i o n m o n i t o r i n g

Figure 2: The Umbrella Architecture Concept.

services. Instead, we attempt to deﬁne a light-weight

solution that may be implemented in web browsers

and ﬁle browser as a simple plug-in service.

• Simple AAA Service

• Data Integrity service

• Data Conﬁdentiality service

Services such as a “Time vault/Backup” and a “Cloud

withdrawal” should also be considered.

4.3.2 Service Resolution

Our model is based on a basic synchronized data

storage service. It is important that the new secu-

rity services ﬁt with this model. For instance, since

the synchronization is ﬁle based then the security

services should also be ﬁle based. Disk encryption

schemes, like for instance TrueCrypt (TrueCrypt De-

velopers Association, 2013), work by creating a huge

encrypted ﬁle and then presenting this a directory or

a disk volume. Such a scheme would force synchro-

nization of the entire “disk”, which in most cases re-

ally is not what one would like.

Our preliminary analysis indicates that the ser-

vice resolution should be “ﬁle based”. This should

include meta-information such as ﬁle names, which

may be sensitive, and even ﬁles sizes. Files may also

be padded up to speciﬁed block lengths, where the

block length could be set according to common ﬁle

system block lengths. We adopt the view that ﬁle-

names should be protected and that padding should

be used.

4.4 The Presentation Layer Security

Manager

We primarily foresee the presentation layer security

manager as a plug-in service to the “normal” ﬁle man-

ager, and it may be available in productivity software

(ofﬁce packages) and in web browsers. It may be

inspired by tools such as the HP ProtectTools (HP,

2010) or similar.

4.4.1 Identiﬁcation and Security Context Setup

One drawback to having a client-side solution is

to have to manage security at the client-side. The

PLaSM must authenticate SC and create a security

context so decipher/encipher the system information

and the ﬁles whenever needed. This adds complexity

and its own share of security management problems,

but should nevertheless be feasible. We propose that

the SC identity used is the same as used for the cloud

service itself. The password, or other security creden-

tial, should for obvious reasons not be similar to the

one used to access the cloud service. As of now the

choice of credentials and the actual security context

is left for further study, but sufﬁce to say that the cre-

dentials should be ﬂexible in use and not themselves

represent a security weakness.

4.4.2 Security Service Provisioning

We aim primarily at providing data conﬁdentiality

and data integrity. This should include concealment

of ﬁle/directory names and ﬁle length padding. Stan-

dard ﬁle encryption methods seems adequate here. As

a minimal solution for data integrity should be imple-

mented on a per-ﬁle basis, but one may also have ﬁle

system integrity built into the system. The integrity

solution should not implemented such that it itself

unduely increase the synchronization activity of the

cloud service.

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

568

5 CONCLUSIONS

In this paper we have deﬁned and addressed prob-

lems associated with the so-called ToS threat. The

ToS threat is not exclusive to cloud services, but is

highlighted by the ubiquitousness and proliferation of

cloud based services. The ToS threat is mostly seen

as a threat towards unpaid and publicly available ser-

vices, but the threat is in principle generic.

Our Umbrella Architecture is very much work-

in-progress. The concept seems sound enough, but

more analysis is needed both in terms of services to

be provided and the general usability of the concept.

Clearly, the effectiveness and the efﬁciency of the ap-

proach must be investigated too. The basic PLaSM

seems feasible and useful, but scalability with respect

to use on multiple platforms must be investigated.

The PoMA and ReMA seems in principle to be inter-

esting and reasonable schemes, but it must be veriﬁed

how useful and precise these schemes are in practice.

So we conclude optimistically that we consider

the Umbrella Architecture to be an interesting and

feasible approach, but that it is at a very early stage of

development. Only further study can determine how

practical and useful the architecture really is.

REFERENCES

Bernsmed, K., Jaatun, M., Meland, P., and Undheim, A.

(2011). Security slas for federated cloud services.

In Availability, Reliability and Security (ARES), 2011

Sixth International Conference on, pages 202–209.

Binmore, K. (2007). Playing for real: a text on game the-

ory. Oxford University Press, USA.

Bowers, K. D., Juels, A., and Oprea, A. (2009). Hail: a

high-availability and integrity layer for cloud storage.

In Proceedings of the 16th ACM conference on Com-

puter and communications security, CCS ’09, pages

187–198, New York, NY, USA. ACM.

Braman, S. and Roberts, S. (2003). Advantage isp: Terms of

service as media law. New media & society, 5(3):422–

448.

Burgess, H. and Burgess, G. M. (1997). Encyclopedia of

conﬂict resolution. Abc-Clio Santa B´arbaraˆ eCalifor-

nia California.

Camerer, C. F. (2011). Behavioral game theory: Exper-

iments in strategic interaction. Princeton University

Press.

Dhingra, M., Lakshmi, J., and Nandy, S. K. (2012). Re-

source usage monitoring in clouds. In Grid Comput-

ing (GRID), 2012 ACM/IEEE 13th International Con-

ference on, pages 184–191.

Emeakaroha, V., Ferreto, T., Netto, M., Brandic, I., and

De Rose, C. (July). Casvid: Application level mon-

itoring for sla violation detection in clouds. In Com-

puter Software and Applications Conference (COMP-

SAC), 2012 IEEE 36th Annual, pages 499–508.

Grandison, T. and Sloman, M. (2000). A survey of trust

in internet applications. Communications Surveys &

Tutorials, IEEE, 3(4):2–16.

HP (2010). HP ProtectTools Security Software; technical

white paper.

ISO/IEC 7498-1 (1994). Information technology – Open

Systems Interconnection – Basic Reference Model:

The Basic Model. In ISO/IEC 7498-1:1994. ISO,

Geneva, Switzerland.

ISO/IEC 9576-1 (1995). Information technology – Open

Systems Interconnection – Connectionless Presenta-

tion protocol: Protocol speciﬁcation. In ISO/IEC

7498-1:1994. ISO, Geneva, Switzerland.

Jøsang, A. (2010). Subjective logic. CA: University of Oslo.

Jøsang, A., Ismail, R., and Boyd, C. (2007). A survey of

trust and reputation systems for online service provi-

sion. Decision support systems, 43(2):618–644.

Juels, A. and Oprea, A. (2013). New approaches to secu-

rity and availability for cloud data. Commun. ACM,

56(2):64–73.

Køien, G. M. (2011). Reﬂections on trust in devices: An

informal survey of human trust in an internet-of-things

context. Wireless Personal Communications, 61:495–

510.

Meng, S. and Liu, L. (2012). Enhanced monitoring-as-a-

service for effective cloud management.

Oleshchuk, V. A.and Køien, G. M. (2011). Security and pri-

vacy in the cloud a long-term view. In Wireless Com-

munication, Vehicular Technology, Information The-

ory and Aerospace & Electronic Systems Technology

(Wireless VITAE), 2011 2nd International Conference

on, pages 1–5. IEEE.

Pelechrinis, K., Zadorozhny, V., and Oleshchuk, V. (2011).

Automatic evaluation of information provider reliabil-

ity and expertise. SIS-2011-04-TELE-001-Technical

report.

Rajbhandari, L. and Snekkenes, E. (2012). Intended ac-

tions: Risk is conﬂicting incentives. In Gollmann, D.

and Freiling, F., editors, Information Security, volume

7483 of Lecture Notes in Computer Science, pages

370–386. Springer Berlin Heidelberg.

Schneier, B. (2013). Terms of service as a security threat.

Subashini, S. and Kavitha, V. (2011). A survey on secu-

rity issues in service delivery models of cloud comput-

ing. Journal of Network and Computer Applications,

34(1):1 – 11.

Thomson, I. (2012). Instagram back-pedals in face of user

outrage.

TrueCrypt Developers Association (2013). Free open-

source disk encryption software.

Zhao, G., Rong, C., Jaatun, M., and Sandnes, F.-E. (2010).

Deployment models: Towards eliminating security

concerns from cloud computing. In High Perfor-

mance Computing and Simulation (HPCS), 2010 In-

ternational Conference on, pages 189–195.

AddressingtheTerms-of-ServiceThreat-Client-sideSecurityandPolicyControlforFreeFileStorageServices

569
