Recovering RSA Private Keys on Implementations with Tampered LSBs

Constantinos Patsakis

Distributed Systems Group, School of Computer Science and Statistics, Trinity College, Dublin, Ireland

Keywords:

SAT Solvers, Partial Key Exposure, Integer Factorization, RSA, Public-key Cryptography.

Abstract:

The theoretical security that modern encryption algorithms are providing, leads researchers to new attack

scenarios which are more implementation centric. By discovering hardware or software ﬂaws that can recover

some information about the decryption key, cryptanalysts try to exploit this knowledge. Therefore, many

side channel attacks have appeared, illustrating that the concept of having secure code or even embedding

all cryptographic functions in hardware modules, in many cases in not adequate. The aim of this work is to

illustrate how partial information can be used to exploit the extracted information, leading to full reconstruction

of the private key of RSA, for some implementations of the algorithm where the LSB has been selected to ﬁt

several constraints. More precisely, we study the case where the LSB half of the primes is identical or when

there is a linear equation that mixes the LSB halves of the two primes.

1 INTRODUCTION

Encryption for centuries was a strictly and detained

art of the privileged. However, recent advances in

telecommunications and computer science havetrans-

formed it into a science, which is used by everyone

with a wide range of applications. It is important to

highlight that cryptography provides a layer in all the

applications that use it that people take for granted.

People when using an application are sure that their

information cannot be intercepted, altered or forged

by other entities, something that is provided by cryp-

tography. Simultaneously, the advances in the ﬁels

enable users to enjoy the beneﬁts, without needing to

come in direct contact with it or understand how it

works. Therefore, in most cases we can talk about

seamless integration of built-in cryptographic primi-

tives.

In many attack scenarios, the attacker can be con-

sidered to have physical access to the information sys-

tem. To justify the validity of such scenarios we have

to consider the extended use of portable and mobile

devices. Moreover, we have to take into considera-

tion the determination of attackers that want to attack

an information system and manage to enter the server

room. A measure to counter the impact of such at-

tacks on is to use encrypted partitions, this way, even

if the attacker can have physical access to the storage,

he will not be able to recover the stored information.

Breaking a modern encryption algorithm like AES-

128 can be considered infeasible, nevertheless if the

attacker can guess the ﬁrst 100 bits, then brute-forcing

the rest 28 bits can be considered a trivial task.

The question that rises is how could the attacker

ﬁnd these 100 bits and how feasible could this be.

The answer is the implementation of the algorithm.

If there are ﬂaws in the implementation of the algo-

rithm, the attacker may extract bits by measuring sev-

eral things like:

• How much time does it take the algorithm to en-

crypt/decrypt?

• How much power does the processor use?

• What is the pool of randomness that is being used

to create the keys?

Depending on the answers to these questions, the at-

tacker will use a different technique to extract as many

key bits as possible.

While in many cases we consider the attacker, as

the malicious entity, in many scenarios, this is the

exact opposite. The wide adoption of cryptography

has enabled both “good” users as well as malicious

ones to use it. Therefore, frequently malware is us-

ing encryption to to attack or to hide its trails. Ex-

tortion software use cryptographic algorithms to en-

crypt user’s ﬁles and afterwards demand monetary

exchanges to disclose the decryption key belong. In

other cases, computer viruses and backdoors, encrypt

the code of their body and their trafﬁc, making their

presence undetectable from antivirus programs.

453

Patsakis C..

Recovering RSA Private Keys on Implementations with Tampered LSBs.

DOI: 10.5220/0004534904530460

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 453-460

ISBN: 978-989-8565-73-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

In this context, it becomes essential, even for dig-

ital forensics, to study how to much information is

needed to reconstruct a decryption key out of some

information that is provided. This work is studying

the special case of RSA, highlighting that even if the

RSA problem or the problem of integer factorization

are very difﬁcult to be solved, having partial access

to random bits of the keys, leads to an easier problem

that can be solved much easier.

1.1 Contributions

The main contribution of this work is a set of fast real

world attacks on two implementations of RSA with

random known bits with high success rate. The ﬁrst

case that is studied is the LSBS-RSA, a special imple-

mentation of RSA for smartcards, where the primes

share their least signiﬁcant bits. Extending this attack,

we focus on RSA where there is a known linear rela-

tionship between the LSB halves of the two primes.

This work extends the results of (Patsakis, 2013) for

these use case, illustrating the powerful attacks that

can be launched using SAT solvers.

1.2 Structrure of this Work

The rest of the paper is organizedas follows. The next

section provides an overview of the previous work re-

garding RSA key reconstruction and partial key ex-

posure. The third section is presenting the results

from attacks using SAT solvers. More precisely, we

present the results for the general case of LSBS-RSA

and afterwards, we focus on the case where the pub-

lic exponent is equal to three. The following section

discusses these results, their signiﬁcance and feasibil-

ity. Finally, we end this work with some remarks and

ideas for future work.

2 RELATED WORK

2.1 SAT Solvers in Cryptanalysis

SAT solvers are programs that try to solve the boolean

satisﬁability problem, that is given a boolean formula

to ﬁnd whether there the variables can take true/false

values so that the given expression evaluates to true.

The problem is very well known to be a NP-complete,

actually, it was the ﬁrst one to be proved belonging in

this category, nevertheless, several instances can be

solved. The need for solutions in industrial problems,

led to the creation of SAT solvers, which nowadays

are very efﬁcient.

Massacci was the ﬁrst one to use them in crypt-

analysis, introducing logical cryptanalysis (Massacci,

1999) and later trying to attack DES(Massacci and

Marraro, 2000). The development of more efﬁ-

cient SAT solvers in the coming years, led sev-

eral researcher to explore the possibility of using

SAT solvers as a tool for cryptanalysis, leading

to more cryptanalytic-friendly versions like (Soos,

2010; Soos, 2009; Soos et al., 2009). Therefore, it

was a mater of time for SAT based attacks to emerge

like (Eibach et al., 2008; Golle and Wagner, 2007;

Mironov and Zhang, 2006; Morawiecki and Srebrny,

2010; Erickson et al., 2010; Homsirikamol et al.,

2012; De et al., 2007; Courtois et al., 2008; Mo-

hamed et al., 2011; Kamal and Youssef, 2010). How-

ever these attacks are focusing on symmetric key al-

gorithms and hash functions, for the case of public

key algorithm the main attacks can be found in (Fior-

ini et al., 2003; Dylkeyt et al., 2007; Faizullin et al.,

2009; Patsakis, 2013).

2.2 LSBS-RSA

RSA is the most widely used public keyencryptional-

gorithm, however, due its design, there are many cal-

culations that have to be made, hence, when it comes

to performance, it cannot be compared to any sym-

metric algorithm. Moreover, since these calculations

in many cases demand serious processing, deploying

it for mobile devices or for low processing devices

like smart-cards, is very difﬁcult.

In order to provide a more efﬁcient implementa-

tion Steinﬁeld and Zheng proposed the use of slightly

altered scheme for RSA in (Steinfeld and Zheng,

2001). Instead of just selecting two prime numbers

that meet the criteria of typical RSA, the researchers

proposed the selection of primes that have in com-

mon the α least signiﬁcant bits. This way, they en-

able fast and secure public-server-aided RSA decryp-

tion/signature generation. Even if one could claim

that this may create a new backdoor, specially us-

ing the BDF attack (Boneh et al., 1998), the authors

showed that this attack is not more powerful against

their proposedscheme. Nevertheless, several cryptan-

alytic attacks havealready been reported, highlighting

weak families of keys or improving the BDF attack

for this speciﬁc key generation procedure (Sun et al.,

2008b; Sun et al., 2008a; Zhao and Qi, 2007; Meng

and Bi, 2011).

According to their scheme, in the key generation,

we select two prime numbers which have α bits in

common and proceed generating n, e, φ(n) and d

as in common RSA. However, the public key key is



n,e,αd

pub



and the secret key is d

sec

, where:

SECRYPT2013-InternationalConferenceonSecurityandCryptography

454

sec

= (2

−2α

n/2−1

∑

i=2α

)

pub

= d −2

2α

sec

and d

represents the i−th bit of d. On input message

m the signature σ = H(m)

mod n is generated as fol-

lows:

1. The server computes:

≡ H(m)

pub

mod n

≡ H(m)

2α

mod n

and sends them to the client.

2. The client computes:

σ ≡ β

sec

mod n

which demands signiﬁcantly less computations.

In this case, we have one multiplication modulo

n and one exponentiation, which is half the size of

the original one.

2.3 Cold Boot Attacks

Cold boot attacks are a special category of attacks that

is being more and more studied the past few years.

The concept of the attack is that the attacker gains

physical access to a device that implements an en-

cryption algorithm. Using several ways, from clean-

ing air canisters to liquid nitrogen, the attacker can

quickly decrease the temperature of RAM many de-

grees below zero. He then closes the device and boots

up with special software that dumps the memory to

a storage device (hard disk, usb etc). This memory

dump contains the decryption key, or a corrupted ver-

sion of it. The reason is that RAM is not instantly

deleted, but it is gradually corrupted. Depending on

the manufacturer and the model of the DIMM bits are

either turning from 0 to 1 or the opposite. By freezing

the DIMM the attacker manages to delay the corrup-

tion, hence from the memory dump he can be sure that

if for example the degration is from 0 to 1, whenever

he sees a 0 the value is correct. The implications of

such attacks can be found in (Halderman et al., 2009).

2.4 RSA Key Reconstruction

The problem of RSA key reconstruction was ﬁrstly

studied by Rivest and Shamir. According to their ap-

proach, we can query a random oracle which can re-

ply with a yes or no to our questions. Based on that,

they built up an attack which recovers the RSA pri-

vate key given 2/3 of the LSBs of one of the primes

(Rivest and Shamir, 1985).

Later, Coppersmith provided a very well crafted

polynomial time algorithm, that can recover small

roots of polynomials modulo N, when the factoriza-

tion of N is unknown, based on LLL algorithm (Cop-

persmith, 1996). Using this theorem, it can be shown

that if the attacker knows 1/2 of the MSBs of one of

its primes, then he can factor n in polynomial time.

Afterwards, Boneh et al. showed that the above

result can be achieved if the attacker is given 1/2 of

the LSBs of one of its primes, or

logn

bits of d (Boneh

et al., 1998).

Heninger and Shacham in (Heninger and

Shacham, 2009), provided a methodology, that

reconstructs the RSA private key from random bits, if

one the following is disclosed:

• 27% of the bits of p, q, d, d

, and d

, or

• 42% of the bits of p, q, and d, or

• 57% of the bits of p and q.

The above methodologies however have a basic lim-

itation, we assume that the bits that have been dis-

closed are all correct. Even if one of them is wrong,

the attack will not be successful. Since in cold boot

attacks, some of the bits can be ﬂipped, Henecka et

al. studied a more close to reality scenario, how to re-

construction the RSA private key when all the bits are

given to the attacker, butwith some known probability

of error for the bits (Henecka et al., 2010). Maitra et

al. use lattices, so that given only knowledge of ran-

dom bits in the LSB halves of the primes, or blocks of

bits in the MSB halves of the primes, the attacker can

reconstruct the key (Maitra et al., 2010). Sarkar stud-

ied the case where the attacker is given a pattern in

the unknown corrupted version of d, so most of d is

considered known but only some contiguous blocks

are unknown (Sarkar, 2011). In another attack, the

attacker reconstructs the private key, using partial in-

formation with error for the MSBs of the secret pa-

rameters (Santanu et al., 2011).

In (Paterson et al., 2012), the researchers follow a

code theoretic approach, that enables them to launch a

series of attacks for a wide range of cold boot attacks

setups. More interestingly, they set the lower bounds

on how much information is needed to perform such

attacks efﬁciently and the success probability of their

attacks. Since the range of attacks that they cover is

wide, and covers setups that are not possible with the

current work, we only focus on the results on erasure

channels where they manage to recover the keys, for

the following cases:

• 33% of random bits of p, q and d with 34% suc-

cess rate in around 25.9 seconds

• 50% of random bits of p and q with 69% success

rate in around 7.23 seconds.

RecoveringRSAPrivateKeysonImplementationswithTamperedLSBs

455

3 THE SAT APPROACH FOR

RECONSTRUCTION

A novel approach for RSA key reconstruction was

proposed in (Patsakis, 2013). Even if in many cases

SAT solvers were proved to be at least inefﬁcient

for integer factorization problem, several tweaks as

well as the random known bits enable the attacker

to launch powerful attacks against RSA implemen-

tations where the public exponent is equal to three.

Their major issue was that they couldn’t take advan-

tage of the underlying algebraic structures, therefore,

they ended up doing random walks among possible

keys, which will ﬁnd the prime decomposition in

√

time.

Based on the Python implementation of Yuen and

Bebel (Yuen and Bebel, 2011), the prime decompo-

sition problem of the RSA modulo n is converted to

a SAT problem. Since this implementation is quite

generic, allowing the primes to be on range of 2 to

n/2, the author added the needed equations to make it

ﬁt more to the RSA case. Hence, the upper

logn

bits of

the primes are set to zero, the last signiﬁcant bits are 1

as well as the bits at position

logn

−1. Even if simplis-

tic, these tweaks drastically improve the performance

of the SAT solver, compared to the original one. For

the special case where e = 3, half of the bits of d (the

upper ones) are disclosed, therefore, the aforemen-

tioned information is supplied to the DIMACS ﬁle.

Finally, appending the known bits to the system, re-

sulted to a very powerful attack. More precisely, the

attacker can recover the private key in around 45 secs

with almost 98% success rate, given either 53-59% of

the bits of p and q or 38-44% of the bits of p, q and

In order to decrease the ﬁle size of the DIMACS

ﬁle, enable testing for keys beyond 1024 bits and

work on Lonsdale cluster

, where each core has 2GB

of RAM, several improvements had to be made on

the initial implementation. Therefore, the current im-

plementation is making the multiplication on integers

which are each of half size of the product, reducing

drastically the ﬁle size of the DIMACS ﬁle. As it be-

comes apparent from Table 1, the space requirements

have been reduced by a factor of around 4. For a key

of 1024 bits the measurements for the CNF conver-

sion of the problem are illustrated in Table 2. The

measurements of the aforementioned table clearly in-

dicate that the system is not trivial at all and that the

SAT solver is really managing to solve a problem that

demands lot of resources. Therefore, it cannot be re-

garded as a random or trivial incident.

http://www.tchpc.tcd.ie/resources/clusters/lonsdale

Table 1: Space requirements for creating systems of CNFs

before and now.

RSA key size Space needed before Now

128 bits 8.5MB 2MB

256 bits 36MB 8.2MB

384 bits 84MB 19MB

512 bits 150MB 36MB

768 bits 355MB 83MB

1024 bits 650MB 150MB

1536 bits 1.5 GB 355MB

2000 bits NA 617MB

Table 2: Typical measurements for a run of a 1024 RSA

key.

Measure Value

Variables 2904473

Clauses 6605492

Restarts 62

Conﬂicts 15632

Decisions 166656

Propagations 28649977

Conﬂict literals 405316

The conversion of the problem from algebraic to

CNF is quite straight forward. Each bit of the primes

is represented as a variable p

and q

and we try to

multiply these N/2 bit numbers as we would nor-

mally do for an embedded system. This means that

the multiplication is broken down to full adders and

half adders. The main difference is that the carries and

sums that are generated on each operation are stored

independently, therefore, they become new variables

to our system of equations, increasing the original

number of N/2 + N/2 = N variables at each opera-

tion.

4 EXPERIMENTAL RESULTS

Building on top of the results in (Patsakis, 2013), we

tried to focus on other implementations of RSA and

LSBS-RSA is one of them. For this case, we imple-

mented an attack where d is completely blinded, alter-

ing the key generation algorithm to create the proper

keysand appendedthe required CNFs to the DIMACS

ﬁle to make the lower bits common. In order, to de-

crease the processing time, the CNFs for the product

n = p × q were made for up to bit in position

logn

This created less constraints, therefore, less process-

ing time, however, the cost is more solution candi-

dates and probable false positives. This means that

the SAT solver returned a solution, but since it didn’t

SECRYPT2013-InternationalConferenceonSecurityandCryptography

456

meet all the necessary constraints, it was wrong. To

ﬁnd the proper solutions, which decompose n as a

product of primes, we checked the upper halves of the

solutions. If these are correct, then the decomposition

can be achieved using Coppersmith’s theorem.

Since the attack was quite successful, the attack

was generalized to other probable RSA implementa-

tions. Since on LSBS-RSA we have the last bits to

be equal, we generalized this assumption. Therefore

the attack focused on implementations where the LSB

halves of the two primes are related with a known lin-

ear equation. This means that previously we knew

that

= q

, ∀ i, 0 ≤ i <

log n

now we have that

+ q

= x

, ∀ i, 0 ≤ i <

log n

with known x

The experiments were made on Lonsdale cluster.

Each node has 8 cores and 16GB of RAM running on

64-bit Opteron processors clocked at 2.30GHz. Each

experiment was run on one of the cores. The cluster

is running on 2.6.18 64 bit kernel and the SAT solver

used was miniSAT2.

The experiments were made for RSA keys from

128 bits up to 1024 bits. The amount of random

known bits was 30%, 35%, 40% and 45%. In each

case all the bits of the primes were entered in a pool,

and only the regarding amount of bits was selected,

the rest of the bits were blinded. For each category

of the attack 500 tests were made. This means that

totally there where 2 ×4×5 ×500 = 20000 tests ex-

ecuted.

The results of the experiments are illustrated in

Tables 3 and 4 and Figures 1 and 2. It is obvious

that the success rate of the attack is very high and ad-

ditionally, the attacks can be launched within reason-

able time, less than 2.5 minutes. The amount of infor-

mation to launch these attacks is quite low. We should

note here that for the case of LSBS-RSA we have to-

tally, N/2 + N/4 = 3N/4 variables, from which we

know in some attacks the 30% thus:

0.3

0.75

= 40% of

the variables, if we want to compare it with full RSA.

However,the attack can still be launched successfully,

with high success rate, indicating that it can take ad-

vantage of the underlying structure better than other

methods.

It is obvious from the tables that the more infor-

mation is disclosed, the less time is needed to solve

the system, the more successful the attack becomes.

In order to choose the proper SAT solver, an ini-

tial experimentation was conducted. More precisely,

128 256 512 768 1024

100

120

140

160

Key size

Time Elapsed (in secs)

Figure 1: Summary of the results for all bit sizes for LSBS-

RSA.

128 256 512 768 1024

100

120

140

160

Key size

Time Elapsed (in secs)

Figure 2: Summary of the results for all bit sizes for RSA

with related LSB halves.

SATzilla

was downloaded, that contains all the ﬁnal-

ists of the 2012 SAT Challenge

. Each executable of

the competition was tested for some instances of the

1024 bit keys. Quite surprisingly, miniSAT outper-

formed all the other competitors, in many cases with

signiﬁcant difference, therefore, it was chosen for the

ﬁnal experiments.

http://www.cs.ubc.ca/labs/beta/Projects/SATzilla/

http://baldur.iti.kit.edu/SAT-Challenge-2012/results.html

RecoveringRSAPrivateKeysonImplementationswithTamperedLSBs

457

Table 3: Results for LSBS-RSA.

128 256 512 768 1024

mean success mean success mean success mean success mean success

30 4.83 96.75 40.27 99.99 95.8 99.99 158.55 99.99 162.3 100

35 1.83 96.75 20.99 99.98 59.35 99.98 111.02 99.99 141.64 100

40 0.68 100 21.28 100 53.9 99.99 113.65 99.99 157.32 100

45 0.34 99.99 7.84 100 47.75 99.99 90.79 99.99 142.52 100

Table 4: Results for RSA when the LSBs are related.

128 256 512 768 1024

mean success mean success mean success mean success mean success

30% 0.22 49.9 1.51 51.56 13.4 50.16 48.88 49.04 145.08 45.45

35% 0.18 66.14 1.43 60.52 12.78 60.49 50.84 59.62 134.83 59.35

40% 0.13 86.66 1.4 68.95 12.81 67.07 44.8 66.43 162.67 62.94

45% 0.11 95 0.9 88.13 11.49 65.32 54.49 75.69 168.33 70.99

5 DISCUSSION

The experimental results clearly indicate that the pro-

posed methodology can provide very powerful at-

tacks, outperforming (Heninger and Shacham, 2009)

and comparable to (Paterson et al., 2012). The pro-

vided information is signiﬁcantly decreased as the

prime bits are related. In any case, it should be

noted that the proposed approach to key reconstruc-

tion has very high success rate and reasonable time

needed to execute the experiments allowing compar-

isons in terms of efﬁciency with the two aforemen-

tioned works. It should be highlighted, that the above

results apply to a speciﬁc implementation of RSA and

exploit its features, illustrating that some presump-

tions that we make regarding what kind of access can

the attacker gain, may have huge impact in the secu-

rity of the implementation of a generally secure algo-

rithm. Further decrease in the amount of given infor-

mation, resulted to huge delays in the output or many

false positives, validating the information bounds of

the aforementioned works. Additionally, we have to

highlight the exponential tendency of the needed time

to launch the attack that is depicted in Figures 2, that

is not the same as in Figure 1. The average needed

time in this case is multiplied by a factor around 10,

when the bits of the key are doubled. Finally, even if

the needed time for the LSBS-RSA is in most cases

greater that the related LSBs, the success rate is al-

most 100%. The explanation for this is probably be-

cause the resulting system is more strict, due to the

constraints.

Since in this attack we are targeting towards the

upper part of the primes, one could argue that the

amount of the provided information, is given at the

Figure 3: Knowing bits of p and q that “ﬁt”.

upper halves of the primes with overwhelming prob-

ability. For example one could assume that the values

of the bits that are disclosed form the upper part of

the primes as in Figure 3. To make it more clear, let

and q

be bits of the two primes, then one could

recover in polynomial time all the missing bits, if

they could could ‘ ﬁt perfectly”. Since both are odd

primes the last bit is 1. If this is not given in q then

we correct it. Now if we know the second bit for q

but not for p then it can be easily calculated since

n mod 2

≡ p mod 2

×q mod 2

. Since we know the

value q mod 2

and p mod 2, the value of p mod 2

can be easily calculated. The above scenario can be

generalized showing that if we do not have informa-

tion for any of the primes in k positions, then we need

to brute force 2

values. Additionally, we deduce that

if we are given information in the same position for p

and q, we do not extract signiﬁcant information.

Firstly, we have to note that for the highest prob-

ability which is 40%, we expect 20% of the bits to

be on the upper half and 20% on the lower part.

Moreover, we expect 0.4

= 16% of collisions, that

is 8% on the upper part and 8% on the lower part.

Taking the above into consideration, we expect that

20%+ 20%−8% = 32% of the bits of the upper part

of the primes to be disclosed. Quantifying it, means

that for a key of 1024 bits, the SAT solver, if it was

just a brute force attack it would need 2

512×0.28

= 2

143

attempts. Deﬁnitely, this amount of calculation is be-

SECRYPT2013-InternationalConferenceonSecurityandCryptography

458

yond by any chance feasible and not comparable with

our experimental results.

More generally, let’s assume that 2ν bits of the to-

tal 2N bits of the primes have been disclosed. More-

over, we assume that brute forcing k bits is possible.

Let λ

and λ

be the bits of each of the two primes that

have been disclosed on the most signiﬁcant halves re-

spectively. Then the possibility of being able to brute

force the most signiﬁcant halves is:

∑

∈ [0,k]

+ k

≤ k

∑

,λ

∈ [0,

]

+ λ

= 2ν



−k



−k

 N

−λ

 N

−λ





2ν



From the above, we can safely deduce two major re-

sults. The ﬁrst is that only using the provided infor-

mation, it is extremely improbable to extract all the

needed upper halves. Moreover, the provided infor-

mation is extremely improbable to allow us to extract

the upper halves through brute force as well. Hence,

the SAT solvers manage to solve the provided equa-

tions very efﬁciently and do not perform just a brute

force attack, but take advantage of the generated equa-

tions very efﬁciently.

6 CONCLUSIONS

Even if we are facing one of the strongest problems in

mathematics, prime decomposition or more precisely

the RSA problem, additional information regarding

the implementation of the algorithm, may allow the

attacker to break speciﬁc instances. With the constant

increase of side channel attacks and the discovery of

leaks within the implementation of encryption algo-

rithms, several attacks have been deployed escalat-

ing small leaks to complete disclosure. Within this

context, this work illustrates how a small amount of

random known bits of the private key of speciﬁc im-

plementations of RSA, may lead to full disclosure of

the private key with the use of SAT solvers. The as-

sumption for LSBS-RSA that the algorithm is secure

because it is immune to the standard BDF attack, does

not mean by any chance that the algorithm or its im-

plementations can be considered secure as well. As it

is shown in this work, the same applies of course for

the case where the LSBs of the two primes are related

with an arbitrary linear equation.

The basic limitation of the attack is that it does not

apply to real-world cold boot attacks, where some of

the known bits could be wrong, something that is cov-

ered in (Paterson et al., 2012). Nevertheless, the time

needed to launch the attack as well as the amount of

information needed clearly indicate that for the same

attack scenarios, they are at least comparable in terms

of time and success rate. Baring in mind that the re-

search on this ﬁeld has recently started showing sig-

niﬁcant results, we should expect in the near future

the development of even more efﬁcient attacks and for

more algorithms. Finally, these attacks should force

everyone who is implementing cryptographic algo-

rithms to deploy them with more caution, trying to

detect all possible leaks of information.

ACKNOWLEDGEMENTS

All calculations were performedon the Lonsdale clus-

ter maintained by the Trinity Centre for High Perfor-

mance Computing. This cluster was funded through

grants from Science Foundation Ireland.

REFERENCES

Boneh, D., Durfee, G., and Frankel, Y. (1998). An attack

on rsa given a small fraction of the private key bits. In

ASIACRYPT, pages 25–34.

Coppersmith, D. (1996). Finding a small root of a univariate

modular equation. In EUROCRYPT, pages 155–165.

Courtois, N. T., Bard, G. V., and Wagner, D. (2008). Fast

software encryption. chapter Algebraic and Slide

Attacks on KeeLoq, pages 97–115. Springer-Verlag,

Berlin, Heidelberg.

De, D., Kumarasubramanian, A., and Venkatesan, R.

(2007). Inversion attacks on secure hash functions us-

ing sat solvers. In Proceedings of the 10th interna-

tional conference on Theory and applications of satis-

ﬁability testing, SAT’07, pages 377–382, Berlin, Hei-

delberg. Springer-Verlag.

Dylkeyt, V. I., Faizullin, R. T., and Khnykin, I. G. (2007).

Reducing the problem of asymmetric ciphers crypt-

analysis to solving satisﬁability problems.R In Pro-

ceedings of the XIII All-Russian Conference Mathe-

matical Methods in Pattern Recognition, pages 249–

251. MAKC press.

Eibach, T., Pilz, E., and V¨olkel, G. (2008). Attacking

bivium using sat solvers. In Proceedings of the 11th

international conference on Theory and applications

of satisﬁability testing, SAT’08, pages 63–76, Berlin,

Heidelberg. Springer-Verlag.

Erickson, J., Ding, J., and Christensen, C. (2010). Alge-

braic cryptanalysis of sms4: gr¨oebner basis attack and

sat attack compared. In Proceedings of the 12th inter-

national conference on Information security and cryp-

tology, ICISC’09, pages 73–86, Berlin, Heidelberg.

Springer-Verlag.

Faizullin, R. T., Khnykin, I. G., and Dylkeyt, V. I. (2009).

The sat solving method as applied to cryptographic

analysis of asymmetric ciphers. The Computing Re-

search Repository, abs/0907.1755.

RecoveringRSAPrivateKeysonImplementationswithTamperedLSBs

459

Fiorini, C., Martinelli, E., and Massacci, F. (2003). How to

fake an rsa signature by encoding modular root ﬁnd-

ing as a sat problem. Discrete Applied Mathematics,

130(2):101–127.

Golle, P. and Wagner, D. (2007). Cryptanalysis of a cog-

nitive authentication scheme (extended abstract). In

Proceedings of the 2007 IEEE Symposium on Secu-

rity and Privacy, SP ’07, pages 66–70, Washington,

DC, USA. IEEE Computer Society.

Halderman, J. A., Schoen, S. D., Heninger, N., Clarkson,

W., Paul, W., Calandrino, J. A., Feldman, A. J., Ap-

pelbaum, J., and Felten, E. W. (2009). Lest we re-

member: cold-boot attacks on encryption keys. Com-

munications of the ACM, 52(5):91–98.

Henecka, W., May, A., and Meurer, A. (2010). Correct-

ing errors in rsa private keys. In Proceedings of

the 30th annual conference on Advances in cryptol-

ogy, CRYPTO’10, pages 351–369, Berlin, Heidel-

berg. Springer-Verlag.

Heninger, N. and Shacham, H. (2009). Reconstructing rsa

private keys from random key bits. In In CRYPTO,

pages 1–17.

Homsirikamol, E., Morawiecki, P., Rogawski, M., and Sre-

brny, M. (2012). Security margin evaluation of sha-3

contest ﬁnalists through sat-based attacks. In Com-

puter Information Systems and Industrial Manage-

ment, volume 7564 of Lecture Notes in Computer Sci-

ence, pages 56–67. Springer Berlin Heidelberg.

Kamal, A. and Youssef, A. (2010). Applications of sat

solvers to aes key recovery from decayed key sched-

ule images. In Emerging Security Information Systems

and Technologies (SECURWARE), 2010 Fourth Inter-

national Conference on, pages 216 –220.

Maitra, S., Sarkar, S., and Sen Gupta, S. (2010). Fac-

toring rsa modulus using prime reconstruction from

random known bits. In Proceedings of the Third

international conference on Cryptology in Africa,

AFRICACRYPT’10, pages 82–99, Berlin, Heidel-

berg. Springer-Verlag.

Massacci, F. (1999). Using walk-sat and rel-sat for crypto-

graphic key search. In Proceedings of the Sixteenth In-

ternational Joint Conference on Artiﬁcial Intelligence,

IJCAI ’99, pages 290–295, San Francisco, CA, USA.

Morgan Kaufmann Publishers Inc.

Massacci, F. and Marraro, L. (2000). Logical cryptanalysis

as a sat problem. J. Autom. Reason., 24(1-2):165–203.

Meng, X. and Bi, J. (2011). Weak keys in rsa with primes

sharing least signiﬁcant bits. In Information Security

and Cryptology, pages 278–287. Springer.

Mironov, I. and Zhang, L. (2006). Applications of sat

solvers to cryptanalysis of hash functions. In Proceed-

ings of the 9th international conference on Theory and

Applications of Satisﬁability Testing, SAT’06, pages

102–115, Berlin, Heidelberg. Springer-Verlag.

Mohamed, M., Bulygin, S., and Buchmann, J. (2011). Us-

ing sat solving to improve differential fault analysis of

trivium. pages 62–71. Springer.

Morawiecki, P. and Srebrny, M. (2010). A sat-based

preimage analysis of reduced keccak hash func-

tions. http://eprint.iacr.org/2010/285. pawelm@wsh-

kielce.edu.pl 14742 received 13 May 2010.

Paterson, K., Polychroniadou, A., and Sibborn, D. (2012).

A coding-theoretic approach to recovering noisy rsa

keys. Advances in Cryptology–ASIACRYPT 2012,

pages 386–403.

Patsakis, C. (2013). Rsa private key reconstruction from

random bits using sat solvers. IACRCryptology ePrint

Archive, 2013:26.

Rivest, R. L. and Shamir, A. (1985). Efﬁcient factoring

based on partial information. In EUROCRYPT, pages

31–34.

Santanu, S., Sourav Sen, G., and Subhamoy, M. (2011). Re-

construction and Error Correction of RSA Secret Pa-

rameters from the MSB Side. In WCC 2011 - Work-

shop on coding and cryptography, pages 7–16, Paris,

France.

Sarkar, S. (2011). Partial key exposure: Generalized frame-

work to attack rsa. In Progress in Cryptology - IN-

DOCRYPT 2011, volume 7107 of Lecture Notes in

Computer Science, pages 76–92. Springer Berlin /

Heidelberg.

Soos, M. (2009). Cryptominisat - a sat solver for cryp-

tographic problems. http://planete.inrialpes.fr/∼soos/

CryptoMiniSat2/index.php.

Soos, M. (2010). Grain of Salt — an Automated Way

to Test Stream Ciphers through SAT Solvers. In

Tools’10: Proceedings of the Workshop on Tools for

Cryptanalysis 2010, pages 1–2, RHUL.

Soos, M., Nohl, K., and Castelluccia, C. (2009). Extending

sat solvers to cryptographic problems. In Proceedings

of the 12th International Conference on Theory and

Applications of Satisﬁability Testing, SAT ’09, pages

244–257, Berlin, Heidelberg. Springer-Verlag.

Steinfeld, R. and Zheng, Y. (2001). An advantage of low-

exponent rsa with modulus primes sharing least signif-

icant bits. Topics in Cryptology-CT-RSA 2001, pages

52–62.

Sun, H., Wu, M., Wang, H., and Guo, J. (2008a). On the

improvement of the bdf attack on lsbs-rsa. In Infor-

mation Security and Privacy, pages 84–97. Springer.

Sun, H.-M., Wu, M.-E., Steinfeld, R., Guo, J., and Wang,

H. (2008b). Cryptanalysis of short exponent rsa with

primes sharing least signiﬁcant bits. In Franklin, M.,

Hui, L., and Wong, D., editors, Cryptology and Net-

work Security, volume 5339 of Lecture Notes in Com-

puter Science, pages 49–63. Springer Berlin Heidel-

berg.

Yuen, H. and Bebel, J. (July 18, 2011). Toughsat. http://

toughsat.appspot.com.

Zhao, Y. and Qi, W. (2007). Small private-exponent attack

on rsa with primes sharing bits. Information Security,

pages 221–229.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

460
