Personalized Semantic Resources

The SemComp Project Presentation and Preliminary Works

Alexandre Labadi

, St

ephane Ferrari

and Thibault Roy

GREYC, Caen, France

Noopsis, Caen, France

Keywords:

Personalized Semantic Resources, Componential Semantic, RDF.

Abstract:

This paper presents the computational aspects of the SemComp project, a multidisciplinary collaboration

aiming at observing how interacting with documents acts on knowledge acquisition. It is based on a model

for personalized semantic resources inspired from componential linguistics. The paper describes the advances

in both the computational model’s deﬁnition as well as its implementation in a Web oriented application.

Functionalities and technical choices are presented with regards to the expected experiments.

1 INTRODUCTION

In this paper, we present the SemComp project, an on-

going research project funded by the French Region

Basse Normandie. It aims to experiment a model for

semantic representation in the applicative context of

enhancing personal access to documents. The exper-

imentation will be realized through a Web-oriented

application, in teaching environments or for cultural

tourism purpose. SemComp is a multidisciplinary

collaborative project involving linguists, psycholo-

gists and computer scientists. We thus intend to reach

multiple goals: testing a new implementation of a lin-

guistic model where personal interpretation is central,

collecting data to observe how interacting with doc-

uments acts on lexical and semantic knowledge ac-

quisition, testing a method for personalized access to

information.

In section 2, we brieﬂy present the model for se-

mantic representation. It is a simpliﬁcation of a lin-

guistic approach to componential semantics for ap-

plicative purposes: casual Web users with or without

linguistic knowledge may use it. In section 3, we de-

tail some aspects of the implementation of Personal-

ized Semantic Resources (PSR in the following) using

Web semantic tools and standards. To conclude, we

present future works and evolution of the project.

2 SEMANTIC MODEL

SemComp stands for S

emantique Componentielle,

“Componential Semantics”.

2.1 Motivation

The model for semantic representation and, as a

consequence, for semantic analysis, is inspired by

the structural linguistic approach. It relies on the

main notions of the “Componential Semantics” and

the “Interpretative Semantics” as proposed in, e.g.,

(Greimas, 1966; Pottier, 1992; Rastier, 1987). These

notions are detailed in section 2.2.

In the last decade, NLP works based on a similar

approach have already been realized. In (Beust et al.,

2003), a componential model has been tested for se-

mantic analysis, and more speciﬁcally for metaphors

detection and interpretation in domain-speciﬁc cor-

pora. In (Roy and Ferrari, 2008), the same model as

well as graphical tools are used to provide a user with

a personal access to textual information. The appli-

cations were in both cases designed for experts rather

than casual Web users. Different other works, like

(Valette and Slodzian, 2008; Kanellos and Mauceri,

2008), also proposed the use of “Interpretative Se-

mantics” for information retrieval application.

In the SemComp project, we propose a modiﬁed,

simpliﬁed version of this model for its use by casual

Web users. Relaxing some constraints in the struc-

ture, we consider there are strong similarities with

some Web 2.0 tools such as folksonomies, tags and

social bookmarking.

164

Labadié A., Ferrari S. and Roy T..

Personalized Semantic Resources - The SemComp Project Presentation and Preliminary Works.

DOI: 10.5220/0004539501640169

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2013), pages 164-169

ISBN: 978-989-8565-81-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

2.2 Linguistic Model

emes. The central notion of the “Componential Se-

mantics” approach is to describe lexical units with se-

mantic features. These features, called “s

emes”, are

theoretically supposed to describe the possible inter-

pretations of a lexical unit.

Some s

emes are generic ones, representing parts

of meaning shared by the lexical unit and the ones

with close meaning. For instance, chair and sofa will

emes because they both can mean “a sort of

seat”. One may consider s

emes like /physical object/,

/crafted object/, /piece of furniture/, /seat/ to explain

these meanings.

Some s

emes are speciﬁc ones, used to distinguish

between close meanings. Chair could be differen-

tiated from sofa using a s

eme such as /seat without

arms/, while chair and sofa could themselves be dif-

ferentiated from stool using a s

eme such as /seat with-

out a back/.

Previous works such as in (Beust et al., 2003; Roy

and Ferrari, 2008) proposed to represent the speciﬁc

emes using attributes and values to code their dif-

ferential role: /seat’s back: yes/ for chair and sofa,

/seat’s back: no/ for stool; /seat’s arms: yes/ for

sofa, /seat’s arms: no/ for chair and stool. These

constraints are strong ones, requiring a high level of

expertise for describing a whole domain.

emes in SemComp: Free Semantic Features. In

the SemComp project, we propose to let the user de-

scribe the semantic features freely. We make the

hypothesis casual users will mostly describe generic

emes in order to retrieve documents related to their

hobbies and interests. The application in view (see

2.3) will allow a user to build queries using s

emes

rather than lexical (or graphical) units only. For casual

users, we make the assumption s

emes will be used as

tags for text classiﬁcation: rather than tagging texts,

users will tag words themselves.

Though, it will still be possible for an expert user

to propose sets of differential s

emes if necessary. In

the application, this will appear only as an advanced

functionality. With the previous examples, a user will

be able to build a differential set including the s

emes

/seat without a back/ and /seat with a back/, in or-

der to enhance the results of a query using the s

emes

/seat/ and /seat without a back/: the application will

automatically consider the s

eme /seat with a back/ as

irrelevant, though describing units with close mean-

ings.

Isotopies. The second central notion of the “Inter-

pretative Semantics” is the one of “isotopy” for con-

textual interpretation. An isotopy is the redundancy

of a s

eme in a textual zone. It is closely related to the

notion of topic. When using numerous s

emes to de-

scribe a domain, as for the experiment on metaphors

in (Beust et al., 2003), it has been proved isotopies

help activating or deactivating s

emes: in the context

of economic news, meteorological terms such as ther-

mometer and barometer can be interpreted as measur-

ing or prevision tools for stock markets, deactivating

emes speciﬁc to the meteorology (the units they use,

the phenomenon they measure, etc.). French linguists

propose the terms of actualisation (the action of acti-

vating a s

eme in a speciﬁc context) and virtualisation

(the action of deactivating a s

eme in a speciﬁc con-

text) to describe these interpretation processes.

2.3 Application in View

Based on this simpliﬁed linguistic model, we plan

to develop an application allowing users to create,

manipulate and use their personal points of view on

different domains for consulting documents. Differ-

ent psychological and NLP experimentations are ex-

pected in the SemComp project. The use of Per-

sonalized Semantic Resources (PSR in the following)

will be tested in the following applicative contexts :

(1) students consulting teachers on-line courses ; (2)

students consulting the Web for a class project ; (3)

tourists looking for cultural activities in Normandy.

Experiments (1) and (2) are scheduled in a short

term (1yr), while (3), requiring inclusion of other

NLP tools, is scheduled in a longer term (2yrs). In (1)

and (2), we expect to observe how students acquiring

new knowledge on a domain modify their PSR. In (3),

we intend to experiment on casual users, and include

sharing of PSR to test if this model can lead to real

Web applications.

In (1), the collection of documents is closed, lim-

ited to the documents provided by a teacher in the

scope of a course. In (2), the collection must ﬁrst be

retrieved from the Web, using a search engine, which

require to translate the user request from s

emes to

written forms. Next section presents the ﬁrst devel-

opments centered on the PSR, as well as more details

on the application functionalities which will be used

in the ﬁrst experiments (1) and (2).

3 PERSONALIZED SEMANTIC

RESOURCES (PSR)

Based on the model previously presented, we are cur-

rently developing a set of resources and an application

linked to it aiming to achieve three goals:

PersonalizedSemanticResources-TheSemCompProjectPresentationandPreliminaryWorks

165

1 to propose an exhaustive, yet ﬂexible, representa-

tion for PSR;

2 to allow model implementation in an applicative

context ;

3 to track how users build their semantic resources,

for experimentation purposes.

3.1 UML Model

The simpliﬁed class diagram (ﬁgure 1) can easily be

divided into three parts corresponding to our three

goals : the semantic resources (PSR), their connex-

ions with documents (applicative context) and the in-

teractions (tracked for experimentations).

The center of the diagram represents the seman-

tic resources a user can build. The heart of the model

is the lexical entry which is linked to multiple writ-

ten forms (at least one) which compose it. One of

the written forms is the lexical entry representative.

A lexical entry can be linked to one or more fea-

tures groups, each one representing a different mean-

ing. These groups are composed of semantic features

emes). The semantic features are not limited to tex-

tual representations and can be images, sounds, etc.

Features groups can be of different types, the most

basic one is a meaning of a lexical entry, but the

model allows to create other types of group to iden-

tify speciﬁc properties of some semantic features (for

instance a “differential set of s

emes” as illustrated in

the previous section). Following the same idea fea-

tures groups can be linked by pairs to represent lexical

or semantic relations (hyperonymy, synonymy, etc.).

Lastly, lexical entries, semantic features and features

groups are linked to a viewpoint of a speciﬁc user on

a domain.

The top (and right-top) of the class diagram is de-

voted to link the PSR model to documents. A query

can be composed by selecting different semantic fea-

tures. Features that can be activated or deactivated by

the user when she meets an occurrence of a written

form in a document. The main purpose here is to pro-

pose a model that allows a user to create queries us-

ing her own personalized semantic representation of

a domain (using semantic features to create and ex-

pand queries). But our model also allows to reorder

the returned collection of documents. By activating

and deactivating semantic features linked to words oc-

currences in the documents, the user will reﬁne her

search.

Lastly, the bottom of the class diagram allows us

to track each interaction the user has with her PSR.

This will be used in psycho-linguistic experiments to

uncover the building process of a semantic representa-

tion of a domain and its uses. Of course, the tracking

process will only take place during experiments and

users will be aware of it.

3.2 Application Expected

Functionalities

For Users. In addition to a user friendly manipula-

tion of our model, our application will allow the user

to use her own PSR to improve her Web or closed col-

lections of documents research. The user will be pre-

sented with the semantic features of her own PSR and

will compose queries with them. By expanding these

“S

eme formulated queries”, the application should re-

trieve documents closer to the user point of view on

a domain than a more classic approach. We also in-

tend to allow users to share parts of their PSR and to

expand their owns with parts shared by other users.

For Experimenters. As described in section 3 our

model allows to track the user interactions while she

is building and using her PSR. The ﬁnal application

should show us the whole process of building a PSR

by the user, in interaction with document browsing. It

should also allow us to navigate between every step of

this process: when tracking is active, the application

keeps everything in the RDF repository (see following

section for technical choices), archiving any modiﬁed

or deleted instance. We also intend to use graph sim-

ilarity measures to compare different users, domains,

etc.

3.3 Technological Choices,

Implementation and Preliminary

Results

We chose to use Web semantic tools and standards

to implement our PSR. We turned to RDF

, which

graph-like representation is closer to our model than

classical relational ones. Figure 2 is an example of

some semantic data organized as a multi-user PSR. It

show us two users sharing one domain, with common

and distinct semantic features, lexical entries and such

(these are simpliﬁed data for test and example pur-

poses). Purple triangles are classes from our model

and green labels are their implementation. In ﬁgure 2,

the aeronautics domain is linked to two points of view

from two different users (Alexandre and St

ephane).

Each point of view has lexical entries, semantic fea-

tures (aka. s

emes), written forms, etc.. For instance,

Boeing is the written form graphie 00002 represent-

ing the lexical entry lexie 00002. One of its mean-

ings (a plane) is described by the features group

W3C RDF reference site: http://www.w3.org/RDF/

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

166

Query

Archive : Boolean

Semantic Feature

Archive : Boolean

Group Type

Features Group

Archive : Boolean

User Domain

Archive : Boolean

Session

Trace : Boolean

Interaction

Creation date

Lexical Entry

Archive : Boolean

Written form

Session Boundary

Start : Boolean

CollectionDocument

Features Group Interaction

Archive : Boolean

Feature Interaction

Archive : Boolean

Query Interaction

Archive : Boolean

Lexical Entry Interaction

Archive : Boolean

Actualization Interaction

Archive : Boolean

Viewpoint

Shared : Boolean

Occurence

Position : Integer

<To contain

11..N

<To be composed of

<To be part of

1..N

To characterize>

To use>

1..N

To create>

To belong to>

To interact with>

1..2

<To interact with

1..2

<To interact with

1..2

<To interact with

1..2

<To interact with

1..2

Domain Interaction

Archive : Boolean

<To interact with

1..2

To describe>

Relation Interaction

Archive : Boolean

Groups Relation

Archive : Boolean

Type : String

<To interact with

1..2

<To compose

N 1..N

<To represent

0..1 1

Actualization

Archive : Boolean

To belong to>

Figure 1: PSR UML class diagram.

groupe semes 00004 entitled /L’avion Boeing/ (the

Boeing plane, it is a common metonymy in French

to use the name of the company for one of its planes).

This features group contains the two s

emes /vole/ (can

ﬂy) and /transporte/ (can carry). The meaning for

Boeing as a company is not described in this graph.

Some of these data are common to both points of

view, others are speciﬁc to one only. These test data

are the advanced form of the PSR, where users can

share parts of their PSR. The ﬁrst set of experiments

will not allow to share their PSR, and will only al-

low them to access their personal resources and some

common resources extracted from a dictionary. Re-

source sharing will come in a second experimental

phase

The prototype is currently implemented both as a

JAVA Web service and a front end Web application.

It is based on the open source RDF base OpenRDF

Sesame

. In due time, it should be integrated in a big-

ger Web framework including other NLP applications

interacting with each other. First, we intend to pro-

pose a simple Web interface to experiment directly

on the model. In a second time, as other NLP ap-

Scheduled in September 2013 in Caen University,

France, for online courses access and in Louis Liard high

school, Falaise, France, for Web access.

Scheduled in March 2014 for cultural tourism in the

Basse Normandie Region

OpenRDF Web site: http://www.openrdf.org/

plications will be integrated into our framework, we

should develop a more complete Web gateway offer-

ing extended services.

At the time we are writing these lines, the

model has been implemented and deployed in an

OpenRDF Sesame repository, the JAVA Web ser-

vice and the Web interface are currently being devel-

oped. The application prototype can be tested here:

https://semcomp.info.unicaen.fr/.

4 FUTURE WORKS

In this paper, we presented some aspects of the ongo-

ing SemComp project. It aims at observing how users

build their lexical and semantic knowledge while in-

teracting with documents. For this purpose, we pro-

posed a simpliﬁed model for Personalized Semantic

Resources based on the linguistic approach to Com-

ponential Semantics. The main idea is to associate

lexical entries with features called s

emes to represent

parts of their meaning or interpretation. We presented

the current implementation of this Personalized Se-

mantic Resources in a Web-oriented application us-

ing one of the latest Web semantic tools at our dis-

posal (RDF triple stores). We are currently develop-

ing the Web client interface to provide users with two

main functionalities : deﬁning their PSR, building re-

quests using s

emes to search information through doc-

PersonalizedSemanticResources-TheSemCompProjectPresentationandPreliminaryWorks

167

Figure 2: Part of the graph / PSR representation of the aeronautics domain for a pair of users.

uments.

In order to allow casual Web users to deﬁne their

PSR, the underlying linguistic notions are hidden in

this interface : the user is just asked to deﬁne her own

tags (the s

emes) and tag words she ﬁnds relevant for

her task the way she would tag relevant documents

in a Web2.0 application. The user can also build re-

quest using s

emes only to search a speciﬁc informa-

tion. A back-ofﬁce module is dedicated to the trans-

lation of such requests into lists of written forms to

query a search engine. A second back-ofﬁce module

validates and sorts the retrieved documents with re-

gards to the user’s PSR and the initial s

emes request.

We expect users will reﬁne their PSR while discover-

ing information relevant for their task in the retrieved

documents, e.g. new lexical entries or new meaning

features. In the psycho-linguistic experiments, the in-

teractions with both the PSR and the documents will

be tracked in order to observe the knowledge acquisi-

tion process.

The ﬁrst two experiments will involve students

searching the Web for a class project or accessing

their teacher’s online courses. In both cases, the users

are expected to acquire knowledge. A long-term ex-

periment is also expected. PSR would be integrated in

a larger “cultural tourism” NLP application for Web

users. It will help the user to ﬁnd which cultural

events are happening during her stay in a speciﬁc lo-

cation. This latter experiment aims to test the model

in a real application context, and not only for psycho-

linguistic experiment. We intend to use the PSR to

help the user describing her interests and to enhance

the matching between the found events and her inter-

ests.

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

168

REFERENCES

Beust, P., Ferrari, S., and Perlerin, V. (2003). Nlp model

and tools for detecting and interpreting metaphors in

domain-speciﬁc corpora. In Archer, D., Rayson, P.,

Wilson, A., and McEnery, T., editors, Proceedings of

the Corpus Linguistics 2003 conference, volume 16 of

UCREL technical papers, pages 114–123, Lancaster,

U.K.

Greimas, A. J. (1966). S

emantique structurale : recherche

et m

ethode. Larousse.

Kanellos, I. and Mauceri, C. (2008). Une conscience in-

terpr

etative face

a un univers de textes. arguments

en faveur d’une analyse de donn

ees interpr

etative.

Syntaxe & s

emantique, (9). Textes, documents

num

eriques, corpus. Pour une science des textes in-

strument

ee. Etudes publi

ees sous la direction de Math-

ieu Valette.

Pottier, B. (1992). S

emantique g

erale. Presses Universi-

taires de France.

Rastier, F. (1987). S

emantique interpr

etative. Presses Uni-

versitaires de France.

Roy, T. and Ferrari, S. (2008). User preferences for ac-

cess to textual information: Model, tools and experi-

ments. In Wallace, M., Angelides, M., and Mylonas,

P., editors, Advances in Semantic Media Adaptation

and Personalization, pages 285–306. Springer.

Valette, M. and Slodzian, M. (2008). S

emantique des textes

et recherche d’information. Revue franc¸aise de lin-

guistique appliqu

ee, XIII(1):119–133.

PersonalizedSemanticResources-TheSemCompProjectPresentationandPreliminaryWorks

169
