Information Security in Business Intelligence based on

Cloud: A Survey of Key Issues and the Premises of a

Proposal

Elena Jaramillo, Manuel Munier and Philippe Aniorté

LIUPPA, Univ Pau & Pays Adour, Pau, France

Abstract. More sophisticated inter-organizational interactions have generated

changes in the way in which organizations make business. Advanced forms of

collaborations, such as Business Process as a Service (BPaaS), allow different

partners to leverage business intelligence within organizations. However, al-

though it presents powerfull economical and technical beneﬁts, it also arrises

some pitfalls about data security, especially when it is mediated by the cloud. In

this article

, current aspects which have been tackled in the literature related to

data risks and accountability are presented. In addition, some open issues are

also presented from the analysis of the existing methodologies and techniques

proposed in the literature. A ﬁnal point is made by proposing an approach, which

aims at preventive, detective and corrective accountability and data risk manage-

ment, based on usage control policies and model driven engineering.

1 Introduction

The growing needs of communication and business collaboration, attributed among oth-

ers to internationalization and free trade agreements, have generated deep changes in

the underlying information and communication technologies, thus causing a rapid de-

velopment in infrastructure and the emergence of new and novel architectures and pro-

gramming paradigms. Currently, Cloud Computing and Service Oriented Architectures

are frenzy and promising technologies, both implemented in order to leverage organi-

zational business goals, by facing complex and rapid enterprise challenges.

The genesis of cloud computing seems to be a natural evolution of IT technologies

regarding organizational needs. Beyond an economic decision, delegating the man-

agement of the physical machines and processing of application to a cloud provider

allow organizations to concentrate on what really matters: their business goals. Thus,

cloud computing allows companies an on-demand access to pool resources through the

Internet. Moreover, regarding the cloud computing stack, the layer representing the

Business Process as a Service (BPaaS) focuses on the outsource of business process

services from the cloud, a new interaction mechanisms that entails complex challenges

This work is supported by the Conseil Général des Landes (doctoral fellowship to E.J.)

http://www.landes.org/enseignement-superieur

Jaramillo E., Munier M. and Aniorté P..

Information Security in Business Intelligence based on Cloud: A Survey of Key Issues and the Premises of a Proposal.

DOI: 10.5220/0004589400890099

In Proceedings of the 10th International Workshop on Security in Information Systems (WOSIS-2013), pages 89-99

ISBN: 978-989-8565-64-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

that compel to "rethink" the information system architecture that supports such a com-

munication form. In this context, Service Oriented Architectures show up for allowing

system integration.

Taking into account the enterprise advantages of both SOA and the cloud, particu-

larly BPaaS, in the remaining of the article, we discuss the main issues that have been

commonly associated to inter-organizational interaction by means the cloud with re-

spect to information security. We present in Section 3 an overview, in which some

works related to inter-organizational workﬂow, quality of service and accountability

are described. Next, in Section 4 we propose some clues to better tackle some existing

open issues. Additionally, we also present a proposal that aims trustworthiness in the

inter-organizational service interaction by means the cloud. Finally, we conclude in

Section 5.

2 Business Process as a Service and the Cloud

In order to successfully accomplish cooperation among enterprises through the cloud,

two important issues highlight: standards and interoperability. Thus, interaction, out-

sourcing, data exchange and collaboration are requirements that are becoming more fre-

quent when performing business activities and as we presented in the previous section,

BPaaS and SOA are both technical approaches proposed for getting support to those

needs. To clarify both concepts, cloud computing uses the Internet to enable interac-

tions (among others in the form of BPaaS) between the cloud service user and cloud

service provider. On the other hand, SOA focuses on enterprise integration technolo-

gies to exchange information between systems. Although SOA and cloud computing

can exist independently, they can be treated as complementary activities thus leveraging

business goals in the form of BPaaS.

Considering their main constituents and characteristics, the following are advan-

tages widely reported in the literature of implementing a service oriented architecture:

– Reuse: each service should be implemented and deployed having in mind their

reutilization in order to develop business functionalities and expose it as a service

only once, to then be used several times by different clients.

– Loosely-coupled: this characteristic is twofold: services should be independent

and service implementation changes should remain transparent for service users.

– Integration: services should be able to cooperate (composed services) in order to

build more complex business processes.

– Simplicity and Platform Independent: service oriented technologies should rely

on standards in order to guarantee interoperability.

However, despite the optimistic growth and undeniable advantages of both cloud

computing and SOA, recent studies have shown a strong fear of companies and a feeling

of insecurity when delivering their information to a third party (cloud service provider).

In this way, their attracting advantages have been compensated by several issues that

have thus restrained the widely adoption of these models, namely:

– Due to the fact that business processes are orchestrated through several domains

and/or cloud providers, it is difﬁcult to detect faults and data breaches, and, in turn,

it is difﬁcult to establish a chain of accountability.

– The cloud user has no direct control over the process and data.

– Legal aspects and possible conﬂicts get involved in case of transborder data.

– The lack of standards between service providers can hamper interoperability.

– Cloud user’s fear that the data may be manipulated by another cloud user sharing

resources from the same provider.

In addition, traditional risks presented in distributed environments also appear: avail-

ability, integrity and conﬁdentiality. In general terms, issues related to data privacy, data

security and accountability, as evident in the aforementioned pitfalls, need several in-

terrelated study areas in order to create a solid framework. For that purpose, in this

article we consider some insights that show the strong relation among information se-

curity policies, and their social impacts, the changes in the organizational culture, the

legislation and the technical aspects that reﬂects all those features.

Relating to the legislation, in the interaction between cloud service users and cloud

service providers, public legislation is presented as a regulatory framework dealing

with national security policies that restrict and regulate data processing. Currently,

two major aspects continue to be interesting research topic by the community. The

ﬁrst one is linked to jurisdictional laws applicable in data transfers and accountability

about data protection and data lost . Recognizing the importance of protecting personal

information along the entire value chain, different countries have implemented poli-

cies to ensure and protect business operations as well as gain trust in their information

technologies. Within the European Union, Directive 95/46/EC, Directive 2010/87/EC,

Sopot Memorandum and the legislation documents issued by Article 29 of the Data

Protection Working Party [1,2,3,4,5] have been proposed in order to deﬁne the respon-

sibilities of each entity participating in the interaction process. Alternatively, in the US

legislation[6], the government plays an important role in data exchange, which grants

the right of accessing personal and commercial information. The second aspect, related

to legislation is the real implementation of the public politics inside an organization or

an information system. The cases of ChoicePoint Inc.

, Google

and SONY BMG

are some examples in which heavy ﬁnes were got by incorrect use to user’s private

information, in particular, those practices related to conﬁdentility.

On the other hand, as stated in [7], technology built without taking into consider-

ation a human impact is bound to fail. Decisions made from the whole information

gathering from different cloud sources, affect people in a direct or indirect way. Espe-

cially, now that the increase of social networks has changed the way in which people

expose personal information. Although it is an interesting research line that covers

technological strategies as well as preventive, detective and corrective regulations asso-

ciated to data protection, especially, personal data protection, it is out of the scope of

http://www.ftc.gov/os/caselist/choicepoint/0523069complaint.pdf

http://www.ftc.gov/os/caselist/1023136/110330googlebuzzagreeorder.pdf

http://www.ftc.gov/os/caselist/0823071/081211cmp0823071.pdf

our work because it is not directly related to the technical aspects of the BPaaS model.

However, interesting thoughts can be found in [8,9,10].

In the next section, we focus on the technological aspects such as architectures and

interaction models proposed in the literature aimed at data risks and trustworthiness.

3 Litterature Review

In this section we present different architectural models and technical solutions reported

in the literature to tackle data risks and trustworthiness. Due to the fact that those topics

are actively researched and they can be studied in several domains from different per-

spectives, we narrowed our survey to those covering aspects of BPaaS, namely: interor-

ganizational workﬂows through orchestration and choreographies, quality of service

and accountability.

3.1 Interorganizational Workﬂows

In [11] an interorganizational workﬂow is deﬁned as a cooperation of several, au-

tonomous and heterogeneous business processes, in order to achieve a common goal.

From a design perspective, workﬂows represent the coordination of several tasks to ac-

complish a business process. From an organizational point of view, it is an attracting

approach which enables to integrate services exposed in the cloud, to accomplish their

own business process, creating temporary Virtual Enterprises (VE)

[12]. However,

from a technological point of view it is hard to integrate workﬂows from different orga-

nizations since several issues emerge related to security and autonomy of each partner,

as well as managing of the VE.

In [13] an architectural model based on a "smart" UDDI (Universal, Description,

Discovery and Integration) is proposed to assemble heterogeneous SOA networks. This

central entity plays the role of a SOA network manager being able to know everything

about each service and the whole process by using information such as transport proto-

col rules, network routing rules, security information, QoS and SLA rules, and changes

in the management status. In that approach, privacy and data integrity is guaranteed by

implementing a message interceptor between the service user and the service provider.

Several works have been proposed in the same research line, which have some central

entity in their architecture. In [12] an interorganizational workﬂow management agent

takes responsibility for the creation and supervision of the workﬂow, and recovering

from exceptions. All those works are interesting approaches that present as main ad-

vantage having a general and uniﬁed knowledge of the state of the overall system but

two major concerns also arise; the ﬁrst relates on how to keep organizational auton-

omy of each party, and the second, and possibly more important, there is no agreed

knowledge about who is in charge of the management of the central entity.

Van Der Aalst’s work about inter-organizational workﬂows [14] tackles local au-

tonomy of the different parties but allowing high levels of interaction. The basis of his

A virtual enterprise is a temporary alliance of enterprises that come together to share skills

or core competencies and resources in order to better respond tobusiness opportunities, and

whose cooperation is supported by computer networks.

work is to allow individual parties to change their internal workﬂows without affecting

the cross-organizational process behavior. In order to do so, he proposes a three-step

methodology which consists in creating a public workﬂow (contract) which in a second

step is split up among the different domains (business partners) and in a ﬁnal step all

the public parts are replaced for private workﬂows. Similarly, based on the principle

that partners do not want to grant a public view on their internal processes, in [15]

an architecture that tackles control ﬂow and data ﬂow for web services orchestration

and choreography is proposed. It proposes the implementation of a workﬂow view in

which each partner offers different public views only exposing those elements of their

internals that are useful for another entity workﬂow.

Finally, the standard ISO 27010 [16] is a complete guide that covers methods, poli-

cies, processes and controls that have to be considered in inter-organizational data shar-

ing in complex scenarios. It aims to fulﬁll legal and contractual agreements.

3.2 Quality of Service

In the relation between the cloud service provider and the cloud service user, contracts

are the evidence which describe the terms of the interaction. Particularly, private con-

tracts should contain the responsibilities of the entities involved in the process, the

public law concerns, but also technical details about data protection, data security, and

functional and nonfunctional characteristics of the service. In [17] a methodological

approach that deﬁnes the Service Level Agreement (SLA) life-cycle is proposed. In

that work the ﬁve-step SLA life cycle comprises: contract deﬁnition, publishing and

discovering, negotiation, operationalization, and de-commissioning. In terms of data

protection, it is important to highlight that in the decommissioning step, transfer and

erasure of the service user’s data is an issue that needs to be clariﬁed in the contract.

In [18] Quality of Service (QoS) metrics are incorporated into business workﬂows. In

that work, authors analyze both qualitative and quantitative metrics and propose as qual-

ity of service metrics: ﬁdelity, reliability, task response time (delay time and process

time) and the cost associated to the workﬂow execution; all represented in a quantiﬁable

form. In [19] another approach based on a contracting workﬂow for multiple services

is proposed. That work focuses in particular on the negotiation process by proposing

eight negotiation patterns, which cover from a simple "implicit-accept" interaction to

alternating binding counter offer patterns, which, in theory, could include the negoti-

ation of SLA terms. However, the inclusion of QoS in the patterns are left for future

work.

Due mainly to an important characteristic of SLO: measurability, most of, or al-

most all of the SLA only include infrastructure QoS metrics in the agreements, which

gather [17]: hardware availability, power availability, data center network availabil-

ity, backbone network availability, service credit for unavailability, outage notiﬁcation

guarantee, Internet latency guarantee, packet loss guarantee, service level parameter

metric, function, measurement directive, SLO and penalties.

On the other hand, in order to facilitate the evaluation of the compliance of SLA

by implementing machine-readable contracts, several agreement modeling have been

proposed in the literature, i.e., SLANG, WSLA, WSOL and WS-Agreement.

For further information, [20] presents a comprehensive survey about agreements in

cross-organizational enterprises considering several evalution criteria: does it covers a

multiple architectural layer or a single layer, dependencies techniques, the life cycle it

covers and the speciﬁcation language used.

3.3 Accountability

Beyond legal aspects regarding the compliance and penalties of the contract, account-

ability aims for the compliance in terms of workﬂow executions and trustworthiness of

the entities which interact in the achievement of a composite business process. Several

authors [21,22] agree to deﬁne that a system is accountable if faults can be reliably de-

tected and each fault can be undeniably linked to one or more nodes. In this way, an

entity is trustworthy if accountability is guaranteed. Also, it can be established that for

accomplishing the two named characteristics, every particular action has to be associ-

ated to a node in the process. In turn, this implies that accountability involves aspects

such as knowing where information crosses, possible data transformation, and the rea-

son and purpose of the processing. For that purpose, techniques as logging, monitoring

and auditing have been proposed.

Ringelstein’s work [23] tackles monitor agreed-upon policies in distributed work-

ﬂows by retrieving information about who, why and how the data is processed. The

proposal consists of attaching logs, speciﬁed by RDF-based semantic formalism, to all

data instances in SOAP messages. That kind of metadata includes data type speciﬁ-

cation for entity identiﬁcation (who process the data), action activity (how to process

the data) and it includes an ontology to deﬁne the purpose of the processing (why pro-

cess the data). In [22] strong accountability is implemented in the design of the TSOA

(Trustworthy Service Oriented Architecture) system, which is able to identify misbe-

havior, the entity responsible for the fault and the evidence of the guilty party. The

logging in the cited work is done by modifying the original BPEL document by insert-

ing XML invoke messages before or after the data is transmitted to any entity, in this

way, it is possible to trace the data. Additionally, time information is included in order

to check QoS compliance. In the architecture of the system, a single accountability

service entity contains the BPEL script, SLA and WSDL for accomplishing monitor-

ing and auditing. A different approach in which every node maintains its own log to

detect incorrect executions is presented in [21]. In this approach logs contain informa-

tion about input and output messages by implemented tamper-evident logs, in addition,

trusted timestamping are also added, allowing SLA check compliance.

Accountability as seen from a holistic point of view, covering legal, socioeconomic,

regulatory and technical aspects is presented in [24]. That European project named

A4Cloud aims at four objects which tackles accountability developing tools that:

i enable cloud service providers to give their users appropriate control and trans-

parency over how their data is used,

ii enable cloud end users to make choices about how cloud service provider may be

use,

iii monitor and check compliance with user’s expectation, business policies and regu-

lations,

iv develop recommendations and guidelines for how to achieve accountability for the

use of data by cloud services.

Although, the project is in its early stages and not many publications are reported,

it seems to be a promising approach that tackles preventive, detective and corrective

control which allow to achieve accountability.

Despite not presenting a technical approach, several authors have also remarked the

relevance of trust and auditing data in the cloud [7,25], especially taking into account

the natural ﬂuid property of data.

4 Discussion and Open Issues

In light of the above literature review, it is not difﬁcult to see that accountability encom-

passes the other two aforementioned technical areas. Trust in a partner entity for data

transfer as an intermediate step in the building of a composed service in the cloud, does

not only attach importance to the technical aspects, it involves to know the use other

entities will give to that data, the purposes of the processing, the traceability of the data,

and the quality of the result data as well as the overall service. Additionally, all of these

issues imply to take into account legislation that governs data transfer, duties of parties

involved in the process, business goals and the social impact that creates the making

decision process in the case of incorrect results. By performing reverse engineering to

the previous section, we get back to the three technical aspects presented in the previ-

ous section beginning at accountability and relating it to the other areas, but this time

by highlighting some issues that need to be considered to achieve trustworthiness both

in the partners and the data.

With regards to trustworthiness (including data and partners), monitoring every step

of the process workﬂow and data workﬂow is a critical activity. According to the liter-

ature review, three major approaches can be identiﬁed, monitoring the action of every

partner (user-centric), monitoring the process, by for example, monitoring the work-

ﬂow (process-centric) or monitoring the data ﬂow itself (data-centric). Each of these

approaches has its advantages and drawbacks, however the logging seems to be a com-

mon denominator. Regardless the approach implemented, several issues need to be

considered:

i taking into account that penalties may be imputed to faulty entities, some of them

could prefer to hide their misperforming. Thus, checking that reliable information

is recorded in the log and insuring that the log is not modiﬁed, become a non-trivial

issue,

ii keeping privacy in the log is a relevant matter that affects the customers and the

entities business logic. This means, that not every single activity has to be record

in the log - due to the fact that some relevant business logic could be compromised,

which is crucial especially when the log is shared among all the participants,

iii based on a ﬁnal log feedback, careful attention needs to be paid to penalties espe-

cially in critical activities,

iv improved assessment tools need to be implemented to detect, based on the expected

results, in which speciﬁc node the data was corrupted,

v special security measures need to be implemented for logging by considering for

example if the log format is readable for humans or not, and in the case of sharing

log security, measures also need to be implemented to the entity that housed it, in

order to restrict that unauthorized users access the log. In this latter, access control

models offer an important support.

In the second place, as it was shown in some works presented previously, trust in a

partner also implies to be sure about its performance in such way that the service level

agreement is respected. As stated in [22], spreading business processes among several

administrative domains adds complexity to the process of failure detection, due to the

fact that each domain may have its own interests and priorities. Four major concerns

arise in this point:

i most of the existing works on service agreements focus on infrastructure quality of

service and service level agreements, thus leaving aside Business Level Agreements

(BLA), Business Service Level Agreements (BSLA) and Underpinning Contract

(UC) in the overall process [20]. The inclusion of that kind of approaches along

with machine readable techniques could help to agree organizational goals with

interorganizational processes.

ii a second aspect that has been already reported in [20] is the lack of a tool to sup-

port dependence on service quality objectives, therefore few works consider that a

parameter could be expressed in terms of measuring one or more characteristics.

iii as mentioned in the previous paragraph, the implementation of an access model

should be included in the SLA and should not be left it aside, and

iv lastly, but probably more important, it is necessary to clearly deﬁne what Quality of

Service means in light of an interorganizational composed service.

Finally, due to the fact that data trustworthiness involves the overall data ﬂow, the

design of the workﬂow affects the assessment of the accountability process as well as

the quality of service. The implications of an architectural decision about implementing

a centralized or distributed architecture for governing the workﬂow are tightly obvious.

In a centralized approach, it is possible to have a more complete and uniform view of

the system. However, it is also more susceptible to attacks, lack of availability of the

central entity, and compromises the internal logic of the different partner entities. On

the other hand, the implementation of a distributed architecture could emerge in a weak

information about the state of the system and the management of the interaction process

becomes more difﬁcult. Additionally, as a result of the penalties imposed by the breach

of the contract, the workﬂow should be able to adapt in order to remove and include

partners in the workﬂow process.

Although a solution which enables to cover all of the previous aspects is an ambi-

tious multidisciplinary approach, we aim to tackle accountability in composed services

in the cloud by implementing an usage control approach, which deﬁnes conditions, re-

strictions and obligations that have to be performed by both the cloud provider and the

cloud user before, during and after the interaction process. In this context, the support

in existing models such as OrBAC [26], which merges both an access control model

and an usage control model, will be extremly helpful. In the proposed approach quality

of service is deﬁned in terms of security policies that have to be fulﬁlled in order to

guarantee security goals. By using a MDE (Model Driven Engineering) approach three

different models will be deﬁned, i.e., an interaction model, a security model and a su-

pervision model. The target pursued by our approach is twofold, it allows to exploit the

well-known advantages of MDE approaches mainly automatic operations with models

such as transformation, waving and merging, but also auditing the traceability of the

data in order to verify if participants of the process have respected the security policies

or determinate if changes could be made in order to accomplish the business goals, if

so, metadata will be recorded for proper explanations.

5 Conclusions

In this article a survey of the aspects related to data risk in business processes composed

through the cloud was presented. Although in the literature several data risk in the

cloud have been identiﬁed, such as availability, integrity, conﬁdentiality, transparency,

isolation, intervenability, portability, insecure data deletion, insufﬁcient audit trails and

accountability, we particularly focus on thrustworthiness, both in partners and data,

both gained by an acoutability process. Enhancing the importance of providing more

transparency and control to processes mediated by the cloud and taking into account that

data is dynamic due to the complex responsibility chains, we thus propose an approach

based on preventive, detective and corrective accountability methods. Although this

work does not present relevant results, it offers a signiﬁcant analysis about issues that

have to be addressed when considering a solution based on cloud for composed business

processes, which we expect could be used as a basis for further discussions.

References

1. European Parliament and the Council of the European Union: Directive 95/46/EC of the

European Parliament and of the Council of 24 October 1995 on the protection of individuals

with regard to the processing of personal data and on the free movement of such data. Ofﬁcial

Journal of the European Union L 281 (1995) 0031–0050

2. European Parliament and the Council of the European Union: Directive 2010/87/EU on

standard contractual clauses for the transfer of personal data to processors established in

third countries under Directive 95/46/EC of the European Parliament and of the Council.

Ofﬁcial Journal of the European Union L 318 (2010) 0032–0035

3. European Parliament and the Council of the European Union: Directive 2002/58/EC of the

European Parliament and of the Council of 12 July 2002 concerning the processing of per-

sonal data and the protection of privacy in the electronic communications sector (Directive

on privacy and electronic communications). Ofﬁcial Journal of the European Union L 201

(2002) 0037–0047

4. International Working Group on Data Protection in Telecommunications: Working Paper

on Cloud Computing - Privacy and data protection issues - “Sopot Memorandum” - . 51st

Meeting, 23-24 April 2012, Sopot (Poland) (2012)

5. Lacey, D.: Inventing the future - the vision of the jericho forum. Inf. Secur. Tech. Rep. 10

(2005) 186–188

6. States, U.: Uniting and Strengthening America by Providing Appropriate Tools Required

to Intercept and Obstruct Terrorism (USA PATRIOT ACT) Act of 2001. U.S. Government

Printing Ofﬁce (2001)

7. Morrow, S.: Data Security in the Cloud. John Wiley & Sons, Inc. (2011)

8. Leimbach, Timo; Friedewald, Michael; Nentwich, Michael; Strauß, Stefan; Weber, Arnd;

Koenig, Rene; Hennen, Leonhard ;Skødt, Jakob Nielsen: Cloud computing – european

perspectives on impacts and potentials of cloud computing and social network sites (interim

report – phase i). Deliverable No.1; im Auftrag von: Science and Technology Options

Assessment (STOA), European Parliament (2012)

9. Timmermans, J., Ikonen, V., Stahl, B., Bozdag, E.: The ethics of cloud computing: A

conceptual review. In: Cloud Computing Technology and Science (CloudCom), 2010 IEEE

Second International Conference on. (2010) 614–620

10. Esteves, R., Rong, C.: Social impact of privacy in cloud computing. In: Cloud Comput-

ing Technology and Science (CloudCom), 2010 IEEE Second International Conference on.

(2010) 593–596

11. Lopes Cardoso, Henrique; Leitão, P., Oliveira, E.: An approach to inter-organizational work-

ﬂow management in an electronic institution. In: Proceedings of the 11th IFAC Symposium

on Information Control Problems in Manufacturing. (2006)

12. Leitão, P., Mendes, J.a.: Agent-based inter-organizational workﬂow management system.

In: Proceedings of the 3rd international conference on Industrial Applications of Holonic

and Multi-Agent Systems: Holonic and Multi-Agent Systems for Manufacturing. HoloMAS

’07, Berlin, Heidelberg, Springer-Verlag (2007) 71–80

13. Pulier, E., Taylor, H.: Understanding enterprise SOA. Manning Pubs Co Series. Manning

(2006)

14. Van Der Aalst, W.M.P.: Inheritance of interorganizational workﬂows: How to agree to

disagree without loosing control? Inf. Technol. and Management 4 (2003) 345–389

15. Eder, J., Kerschbaumer, N., Köpke, J., Pichler, H., Tahamtan, A.: View-based interorga-

nizational workﬂows. In: Proceedings of the 12th International Conference on Computer

Systems and Technologies. CompSysTech ’11, New York, NY, USA, ACM (2011) 1–10

16. ISO: ISO/IEC 27010:2012: Information technology - Security techniques - Information

security management for inter-sector and inter-organizational communications. Published,

International Organization for Standardization (ISO), Geneva, Switzerland (2012)

17. Bose, S., Pasala, A., Ramanujam A, D., Murthy, S., Malaiyandisamy, G. In: SLA Man-

agement in Cloud Computing: A Service Provider’s Perspective. John Wiley & Sons, Inc.

(2011) 413–436

18. Cardoso, J., Sheth, A., Miller, J.: Workﬂow quality of service (2002)

19. Van Dijk, A.: Contracting workﬂows and protocol patterns. In: Proceedings of the 2003

international conference on Business process management. BPM’03, Berlin, Heidelberg,

Springer-Verlag (2003) 152–167

20. Guidara, I., Chaari, T., Fakhfakh, K., Jmaiel, M.: A comprehensive survey on intra and

inter organizational agreements. In: Proceedings of the 2012 IEEE 21st International Work-

shop on Enabling Technologies: Infrastructure for Collaborative Enterprises. WETICE ’12,

Washington, DC, USA, IEEE Computer Society (2012) 411–416

21. Haeberlen, A.: A case for the accountable cloud. SIGOPS Oper. Syst. Rev. 44 (2010) 52–57

22. Yao, J., Chen, S., Wang, C., Levy, D., Zic, J.: Accountability as a service for the cloud. In:

Services Computing (SCC), 2010 IEEE International Conference on. (2010) 81–88

23. Ringelstein, C., Staab, S.: Logging in distributed workﬂows. In: PEAS. (2007)

24. Pearson, S., Tountopoulos, V., Catteddu, D., Sudholt, M., Molva, R., Reich, C., Fischer-

Hubner, S., Millard, C., Lotz, V., Jaatun, M., Leenes, R., Rong, C., Lopez, J.: Accountability

for cloud and other future internet services. In: Cloud Computing Technology and Science

(CloudCom), 2012 IEEE 4th International Conference on. (2012) 629–632

25. Rochwerger, B., Vázquez, C., Breitgand, D., Hadas, D., Villari, M., Massonet, P., Levy, E.,

Galis, A., Llorente, I. M., Montero, R. S., Wolfsthal, Y., Nagin, K., Larsson, L., Galán, F. In:

An Architecture for Federated Cloud Computing. John Wiley & Sons, Inc. (2011) 391–411

26. Elrakaiby, Y., Cuppens, F., Cuppens-Boulahia, N.: From contextual permission to dynamic

pre-obligation: An integrated approach. In: ARES. (2010) 70–78
