Embedding and Parsing Combined for Efﬁcient Language Design

Gergely D

evai, D

aniel Lesk

o and M

e Tejfel

Faculty of Informatics, E

otv

os Lor

and University, P

azm

any P. stny. 1/C, Budapest, Hungary

Keywords:

Domain Speciﬁc Languages, Embedding, Concrete Syntax.

Abstract:

One way to develop domain speciﬁc languages is to deﬁne their concrete syntax and create support for it

using classical compiler technology (maybe with the support of language workbenches). A different way is

to create an embedded language, which is implemented as a special library written in a host language. The

ﬁrst approach is usually too costly in the ﬁrst phase of the language design when the language evolves and

changes quickly. Embedded languages are more lightweight and support the language experiments better. On

the other hand, they are not that convenient for the end-users as the standalone languages. This paper presents

the lessons learnt from a DSL development research project in industry-university cooperation, that combined

the advantages of the two approaches: the ﬂexibility of embedding in the design phase and the convenience of

a standalone language in the ﬁnal product.

1 INTRODUCTION

In special hardware or software domains the general

purpose programming languages may not be expres-

sive or efﬁcient enough. This is why domain speciﬁc

languages (DSLs) are getting more and more impor-

tant. However, using classical compiler technology

makes the development of new DSLs hard. The new

language usually changes quickly and the amount of

the language constructs increases rapidly in the early

period of the project. Continuous adaptation of the

parser, the type checker and the back-end of the com-

piler is not an easy job.

Language embedding is a technique that facilitates

this development process. In this case a general pur-

pose language is chosen, which is called the host lan-

guage, and its parser and type checker are reused for

the purposes of the DSL. In fact, an embedded lan-

guage is a special kind of library written in the host

language. The DSL programs in this setup are pro-

grams in the host language that extensively use this

library. The library is implemented in such a way

that its users have the impression that they are using a

DSL, even if they are producing a valid host language

program.

In this paper we use the so called deep embedding

technique. Implementation of a deeply embedded lan-

guage consists of

• data types to represent the AST,

• front-end: a set of functions and helper data types

which provide an interface to build ASTs,

• back-end: interpreter or compiler that inputs the

AST and executes the DSL program or generates

target code.

Not all general purpose programming languages

are equally suitable to be host languages. Flexible and

minimalistic syntax, higher order functions, monads,

expressive type system are useful features in this re-

spect. For this reason Haskell and Scala are widely

used as host languages. On the other hand, these are

not mainstream languages. As our experience from a

previous project (D

evai et al., 2010; Axelsson et al.,

2010) shows, using a host language being unfamiliar

to the majority of the programmers makes it harder

to make the embedded DSL accepted in an industrial

environment. In addition to this, error reporting and

debugging are hard to solve in an embedded language.

For these reasons we have decided to create a stan-

dalone DSL as the ﬁnal product of our current project.

However, we did not want to go without the ﬂexibility

provided by embedding in the language design phase.

This paper presents the experiment to combine the ad-

vantages of these two approaches.

This paper is based on a university research

project initiated by Ericsson. The goal of the project

is to develop a novel domain speciﬁc language that

is specialized in the IP routing domain as well as the

special hardware used by Ericsson for IP routing pur-

poses.

This paper does not introduce the DSL created by

244

Dévai G., Leskó D. and Tejfel M..

Embedding and Parsing Combined for Efﬁcient Language Design.

DOI: 10.5220/0004591802440250

In Proceedings of the 8th International Joint Conference on Software Technologies (ICSOFT-EA-2013), pages 244-250

ISBN: 978-989-8565-68-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

this project for two reasons. First, the language, be-

ing the result of an industry-university cooperation,

is not publicly available at the moment. Second, the

results presented in this paper concern the language

development methodology used by the project. This

methodology is general, and the concrete language it

was applied to is irrelevant.

The most important lessons learnt from the exper-

iment are the following. It was more effective to use

an embedded version of the domain speciﬁc language

for language experiments than deﬁning concrete syn-

tax ﬁrst, because embedding provided us with ﬂexi-

bility so that we were able to concentrate on language

design issues instead of technical problems. The way

we used the host language features in early case stud-

ies was a good source of ideas for the standalone lan-

guage design. Furthermore, it was possible to reuse

the majority of the embedded language implementa-

tion in the ﬁnal product, keeping the overhead of cre-

ating two front-ends low.

The paper is organized as follows. Section 2 intro-

duces the architecture of the compiler. Then in sec-

tion 3 we analyze the implementation activities us-

ing statistics from the version control system used.

Section 4 presents related work, while section 5 con-

cludes.

2 COMPILER ARCHITECTURE

The architecture of the software is depicted in ﬁgure

1. There are two main dataﬂows as possible compi-

lation processes: embedded compilation (dashed) and

standalone compilation (dotted).

The input of the embedded program compilation

is a Haskell program loaded in the Haskell interpreter.

What makes a Haskell program a DSL program is

that it heavily uses the language front-end that is pro-

vided by the embedded DSL implementation. This

front-end is a collection of helper data types and func-

tions that, on one hand, deﬁne how the embedded pro-

gram looks like (its ”syntax”), and, on the other hand,

builds up the internal representation of the program.

The internal representation is in fact the abstract syn-

tax tree (AST) of the program encoded as a Haskell

data structure.

The same AST is built by the other, standalone

compilation path. In this case the DSL program has

it’s own concrete syntax that is parsed. We will re-

fer to the result of the parsing as concrete syntax tree

(CST). This is a direct representation of the program

text and may be far from the internal representation.

For this reason the transformation from the CST to an

AST may not be completely trivial.

Once the AST is reached, the rest of the com-

pilation process (optimizations and code generation)

is identical in both the embedded and the standalone

version. As we will see in section 3, this part of the

compiler is much bigger both in size and complexity

than the small arrow on ﬁgure 1 might suggest.

Assembly

code

Internal

representation

Syntax tree

DSL program

embedded

in Haskell

DSL program

in concrete

syntax

Parser

Embedded

language

front-end

Figure 1: Compiler architecture.

The numbers on the ﬁgure show the basic steps of

the workﬂow to create a compiler with this architec-

ture. The ﬁrst step is to deﬁne the data types of the in-

ternal representation. This is the most important part

of the language design since these data types deﬁne

the basic constructs of the DSL. Our experience has

shown that it is easier to ﬁnd the right DSL constructs

by thinking of them in terms of the internal represen-

tation then experimenting with syntax proposals.

Once the internal representation (or at least a con-

sistent early version of it) is available, it is possible to

create embedded language front-end and code gener-

ation support in parallel. Implementation of the em-

bedded language front-end is a relatively easy task if

someone knows how to use the host language features

for language embedding purposes. Since the ﬁnal

goal is to have a standalone language, it is not worth

creating too ﬁne grained embedded language syntax.

The goal of the front-end is to enable easy-enough

case study implementation to test the DSL function-

ality.

Contrarily, the back-end implementation is more

complicated. If the internal representation is changed

during DSL design, the cost of back-end adaptation

may be high. Fortunately it is possible to break this

transformation up into several transformation steps

and start with the ones that are independent of the

DSL’s internal representation. In our case this part of

the development started with the module that pretty

prints assembly programs.

When the case studies implemented in the embed-

EmbeddingandParsingCombinedforEfficientLanguageDesign

245

ded language show that the DSL is mature enough,

it is time to plan its concrete syntax. Earlier experi-

ments with different front-end solutions provide valu-

able input to this design phase. When the structure of

the concrete syntax is ﬁxed, the data types represent-

ing the CST can be implemented. The ﬁnal two steps,

parser implementation and the transformation of the

CST to AST can be done in parallel.

3 DETAILED ANALYSIS

According to the architecture in section 2 we have

split the source code of the compiler as follows:

• Representation: The underlying data structures,

basically the building data types of the AST.

• Back-end: Transforms the AST to target code.

Mostly optimization and code generation.

• Embedded front-end: Functions of the embedded

Haskell front-end which constructs the AST.

• Standalone front-end: Lexer and parser to build

up the CST and the transformation from CST to

AST.

The following ﬁgures are based on a dataset ex-

tracted from our version control repository

. The

dataset contains information from 2012 late February

to the end of the year.

Figure 2 compares the code sizes (based on the

eLOC, effective lines of code metric) of the previ-

ously described four components. The overall size of

the project was almost 9000 eLOC

when we sum-

marized the results of the ﬁrst year.

51%

13%

29%

Back-end

Embedded front-end

Representation

Standalone front-end

Figure 2: Code size comparison by components.

No big surprise there, the back-end is without a

doubt the most heavyweight component of our lan-

guage. The second place goes to the standalone front-

end, partly due to the size of lexing and parsing

In this project we have been using Subversion.

Note that this project was entirely implemented in

Haskell, which allows much more concise code than the

mainstream imperative, object oriented languages.

codes

. The size of the embedded front-end is less

than the half of the standalone’s. The representation

is the smallest component by the means of code size,

which means that we successfully kept it simple.

Figure 3 shows the exact same dataset as ﬁgure 2

but it helps comparing the two front-ends with the

reused common components (back-end, representa-

tion).

58%

13%

29%

Common

Embedded only

Standalone only

Figure 3: Code size comparison for embedded / standalone.

The pie chart shows that by developing an embed-

ded language ﬁrst, we could postpone the develop-

ment of almost 30% of the complete project, while

the so-called extra code (not released, kept internally)

was only 13%.

Figure 4 presents how intense was the develop-

ment pace of the four components. The dataset is

based on the log of the version control system. Origi-

nally it contained approximately 1000 commits which

were related to at least one of the four major com-

ponents. Then we split the commits by ﬁles, which

resulted almost 3000 data-points, that we categorized

by the four components. This way each data-point

means one change set committed to one ﬁle.

It may seem strange that we spent the ﬁrst month

of development with the back-end, without having

any representation in place. This is because we ﬁrst

created a representation and pretty printer for the tar-

geted assembly language.

The work with the representation started at late

March and this was the most frequently changed com-

ponent over the next two-three months. It was hard to

ﬁnd a proper, easy-to-use and sustainable represen-

tation, but after the ﬁrst version was ready in early

April, it was possible to start the development of the

embedded front-end and the back-end.

The back-end and code generation parts were

mostly developed during the summer, while the em-

bedded front-end was slightly reworked in August and

We have been using the Parsec parser combinator li-

brary (Leijen and Meijer, 2001) of Haskell. Using context

free grammars instead would have resulted in similar code

size.

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

246

0.00

0.25

0.50

0.75

1.00

2012/03 2012/04 2012/05 2012/06 2012/07 2012/08 2012/09 2012/10 2012/11 2012/12 2013/01

Time

Density

Components

Back−end

Embedded front−end

Representation

Standalone front−end

Figure 4: Development timeline.

September, because the ﬁrst version was hard to use.

By October we almost ﬁnalized the core language

constructs, so it was time to start to design the stan-

dalone front-end and concrete, textual syntax. This

component was the most actively developed one till

the end of the year. At the end of October we had

a slight architecture modiﬁcation which explains the

small spike in the timeline. Approaching the year

end we were preparing the project for its ﬁrst release:

Every component was actively checked, documented

and cleaned.

4 RELATED WORK

Thomas Cleenewerck states that ”developing DSLs is

hard and costly, therefore their development is only

feasible for mature enough domains” (Cleenewerck,

2003). Our experience shows that if proper language

architecture and design methodology is in place, the

development of a new (not mature) DSL is feasible

in 12 months. The key factors for the success are to

start low cost language feature experiments as soon as

possible, then ﬁx the core language constructs based

on the results and ﬁnally expand the implementation

to a full-ﬂedged language and compiler.

Frag is a DSL development toolkit (Zdun, 2010),

which is itself a DSL embedded into Java. The main

goal of this toolkit is to support deferring architectural

decisions (like embedded vs. external, semantics, re-

lation to host language) in DSL software design. This

lets the language designers to make real architectural

decisions instead of ones motivated by technological

constraints or presumptions. In our case there were

no reason to postpone architectural decisions: It was

decided early in the project to have an external DSL

with a standalone compiler (see section 1). What we

needed instead was to postpone their realization and

keep the language implementation small and simple

in the ﬁrst few months to achieve fast and painless

experiment/development cycles.

Another approach to decrease the cost of DSL de-

sign is published by Bierhoff, Liongosari and Swami-

nathan (Bierhoff et al., 2006). They advocate in-

cremental DSL development, meaning that an initial

DSL is constructed ﬁrst based on a few case studies,

which is later incrementally extended with features

motivated by further case studies. This might be fruit-

ful for relatively established domains. In our case the

language design iterations were heavier then simple

extensions. We believe that creating a full ﬂedged ﬁrst

version of the language and then considerably rewrit-

ing it in the next iterations would have wasted more

development effort than the methodology we applied.

At the beginning of our project a set of separate

embedded language experiments were started, each

of them dedicated to independent language features.

These components were loosely coupled at that time,

therefore gluing them to form the ﬁrst working ver-

sion was a relatively simple task to do. This kind

of architecture is very similar to keyword based pro-

gramming (Cleenewerck, 2003), where the complete

DSL is formed by loosely coupled and independent

language components. Later on our components be-

came more and more tightly coupled due to the need

of proper error handling and reporting, type and con-

straint checking.

Languages like Java, Ruby, MetaOCml, Tem-

plate Haskell, C++, Scala are used or are tried to

be used as implementation languages for develop-

ing new DSLs (Sloane, 2009; Freeman and Pryce,

2006; Cunningham, 2008; Czarnecki et al., 2003).

These projects either used the embedded-only or the

standalone-only approach and they all reported prob-

lems and shortcomings. We claim that many of these

can be eliminated by combining the two approaches.

The Metaborg approach (Bravenboer and Visser,

EmbeddingandParsingCombinedforEfficientLanguageDesign

247

2004; Bravenboer et al., 2005) (and many similar

projects) extend the host language with DSL frag-

ments using their own syntax. The applications are

then developed using the mixed language and the

DSL fragments are usually compiled to the host lan-

guage. In our case the host language is only used for

metaprogramming on top of the DSL, the embedding

does not introduce concrete syntax and, ﬁnally, the

host language environment is never used to execute

the DSL programs.

David Wile has summarized several lessons learnt

about DSL development (Wile, 2004). His messages

are mostly about how to understand the domain and

express that knowledge in a DSL. Our current paper

adds complementary messages related to the language

implementation methodology.

Based on Spinellis’s design patterns for

DSLs (Spinellis, 2001), we can categorize our

project. The internally used embedded front-end is

a realization of a piggyback design pattern, where

the new DSL uses the capabilities of an existing lan-

guage. While the ﬁnal version of our language, which

employs a standalone front-end, is a source-to-source

transformation.

5 DISCUSSION AND

CONCLUSIONS

5.1 Lessons Learnt

This section summarizes the lessons learnt from the

detailed analysis presented in section 3.

Message 1: Do the language experiments using

an embedded DSL then deﬁne concrete syntax and

reuse the internal representation and back-end! Our

project started in January 2012 and in December the

same year we released the ﬁrst version of the language

and compiler for the industrial partner. Even if this

ﬁrst version was not a mature one, it was functional:

the hash table lookups of the multicast protocol was

successfully implemented in the language as a direct

transliteration from legacy code. Since state of the art

study and domain analysis took the ﬁrst quarter of the

year, we had only 9 months for design and implemen-

tation. We believe that using a less ﬂexible solution in

the language design phase would not have allowed us

to achieve the mentioned results.

Message 2: Design the language constructs by

creating their internal representation and think about

the syntax later! The temptation to think about the

new language in terms of concrete syntax is high. On

the other hand, our experience is that it is easier to

design the concepts in abstract notation. In our case

this abstract notation was the algebraic data types of

Haskell: The language concepts were represented by

the data types of the abstract syntax tree. When the

concepts and their semantics were clear there was still

large room for syntax related discussions

, however,

then it was possible to concentrate on the true task of

syntax (to have an easy to use and expressive nota-

tion) without mixing semantics related issues in the

discussion. This is analogous to model driven devel-

opment: It is easier to build the software architecture

as a model and think about the details of efﬁcient im-

plementation later.

Message 3: Use the ﬂexibility of embedding to be

able to concentrate on language design issues instead

of technical problems! Analysis of the compiler com-

ponents in section 3 shows that the embedded front-

end of the language is lightweight compared to the

front-end for the standalone language. This means

that embedding is better suited for the ever-changing

nature of the language in the design phase. It supports

the evolution of the language features by fast develop-

ment cycles and quick feedback on the ideas.

Message 4: No need for a full-ﬂedged embedded

language! Creating a good quality embedded lan-

guage is far from trivial. Using different services

of the host language (like monads and do notation,

operator precedence deﬁnition, overloading via type

classes in case of Haskell) to customize the appear-

ance of embedded language programs can easily be

more complex then writing a context free grammar.

Furthermore, advocates of embedded languages em-

phasize that part of the semantic analysis of the em-

bedded language can be solved by the host language

compiler. An example in case of Haskell is that the

internal representation of the DSL can be typed so

that mistyped DSL programs are automatically ruled

out by the Haskell compiler. These are complex tech-

niques, while this paper has stated so far that embed-

ding is lightweight and ﬂexible — is this a contra-

diction? The goal of the embedded language in our

project was to facilitate the language design process:

It was never published for the end-users. There was

no need for a mature, nicely polished embedded lan-

guage front-end. The only requirement was to have

an easy-to-use front-end for experimentation — and

this is easy to achieve. Similarly, there was no need to

make the Haskell compiler type check the DSL pro-

grams: the standalone language implementation can-

”Wadler’s Law: The emotional intensity of debate on a

language feature increases as one moves down the follow-

ing scale: Semantics, Syntax, Lexical syntax, Comments.”

(Philiph Wadler in the Haskell mailing list, February 1992,

see (Wadler, 1992).)

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

248

not reuse such a solution. Instead of this, type check-

ing was implemented as a usual semantic analyzer

function working on the internal representation. As a

result of all this, the embedded forntend in our project

in fact remained a light-weight component that was

easy to adapt during the evolution of the language.

Message 5: Carefully examine the case studies im-

plemented in the embedded language to identify the

host language features that are useful for the DSL!

These should be reimplemented in the standalone lan-

guage. An important feature of embedding is that the

host language can be used to generate and to general-

ize DSL programs. This is due to the meta language

nature of the host language on top of the embedded

one. Our case studies implemented in the embedded

language contain template DSL program fragments

(Haskell functions returning DSL programs) and the

instances of these templates (the functions called with

a given set of parameters). The parameter kinds (ex-

pressions, left values, types) used in the case studies

gave us ideas how to design the template features of

the standalone DSL. Another example is the scoping

rules of variables. Sometimes the scoping rules pro-

vided by Haskell were suitable for the DSL but not

always. Both cases provided us with valuable infor-

mation for the design of the standalone DSL’s scoping

rules.

Message 6: Plan enough time for the concrete

syntax support, which may be harder to implement

than expected! This is the direct consequence of the

previous item. The language features borrowed from

the host language (eg. meta programming, scoping

rules) have to be redesigned and reimplemented in

the standalone language front-end. Technically this

means that the concrete syntax tree is more feature

rich than the internal representation. For this rea-

son the correct implementation of the transformation

from the CST to the AST takes time. Another issue

is source location handling. Error messages have to

point to the problems by exact locations in the source

ﬁle. The infrastructure for this is not present in the

embedded language.

5.2 Plans and Reality

Our original project plan had the following check

points:

• By the end of March: State of the art study and

language feature ideas.

• By the end of June: Ideas are evaluated by sepa-

rate embedded language experiments in Haskell.

• By the end of August: The language with concrete

syntax is deﬁned.

• By the end of November: Prototype compiler is

ready.

• December was planned as buffer period.

While executing it, there were three important di-

verges from this plan that we recommend for consid-

eration.

First, the individual experiments to evaluate dif-

ferent language feature ideas were quickly converg-

ing to a joint embedded language. Project members

working on different tasks started to add the feature

they were experimenting with modularly to the exist-

ing code base instead of creating separate case stud-

ies.

Second, the deﬁnition of the language was delayed

by three months. This happened partly because it

was decided to ﬁnish the spontaneously emerged em-

bedded language including the back-end, and partly

because a major revision and extension to the lan-

guage became necessary to make it usable in practice.

As a result, the language concepts were more or less

ﬁxed (and implemented in the embedded language)

by September. Then started the design of the concrete

syntax which was ﬁxed in October. At ﬁrst glance this

seems to be an unmanageable delay. However, as we

have pointed out in this paper, it was then possible to

reuse a considerable part of the embedded language

implementation for the standalone compiler.

Third, we were hoping that, after deﬁning the con-

crete syntax, it will be enough to write the parser

which will trivially ﬁt into the existing compiler as an

alternative to the embedded language front-end. The

parser implementation was, in fact, straightforward.

On the other hand, it became clear that it cannot di-

rectly produce the internal representation of the em-

bedded language. Recall what section 5.1 tells about

the template features and scoping rules to understand

why did the transformation from the parsing result to

the internal representation take more time than ex-

pected. Therefore the buffer time in the plan was

completely consumed to make the whole infrastruc-

ture work.

In brief, we used much more time than planned to

design the language, but the compiler architecture of

section 2 yet made it possible to ﬁnish the project on

time.

5.3 Future

At the moment it is unclear what will happen to this

compiler architecture in the future when more lan-

guage features will be added.

Conclusions of this paper suggest that we continue

with the successful strategy and experiment with new

EmbeddingandParsingCombinedforEfficientLanguageDesign

249

language features by modifying, extending the em-

bedded language and, once the extensions are proved

to be useful and are stable enough, add them to the

standalone language.

On the other hand, this comes at a cost: The con-

sistency of the embedded and standalone language

front-ends have to be maintained. Whenever slight

changes are done in the internal representation, the

embedded language front-end has to be adapted. We

still do not know if this cost overwhelms the advan-

tage that the embedded language offers for the lan-

guage design.

Furthermore, since the standalone syntax is more

convenient than the embedded language front-end, it

might not be appealing to experiment with new lan-

guage concepts in the embedded language. It also

takes more effort to keep in mind two different vari-

ants of the same language.

Even if it turns out that it is not worth maintain-

ing the embedded language front-end and it gets re-

moved from the compiler one day, its important pos-

itive role in the design of the ﬁrst language version is

indisputable.

6 SUMMARY AND

ACKNOWLEDGEMENTS

This paper evaluates a language development method-

ology that starts the design and implementation with

an embedded language, then deﬁnes concrete syntax

and implements support for it. The main advantage of

the method is the ﬂexibility provided by the embed-

ded language combined by the advantages of a stan-

dalone language. We have demonstrated that most of

the embedded language implementation can be reused

for the standalone compiler.

We would like to thank the support of Ericsson

Hungary and the grant EITKIC 12-1-2012-0001 that

is supported by the Hungarian Government, managed

by the National Development Agency, and ﬁnanced

by the Research and Technology Innovation Fund.

REFERENCES

Axelsson, E., Claessen, K., D

evai, G., Horv

ath, Z., Keijzer,

K., Persson, A., Sheeran, M., Svenningsson, J., Vajda,

A., and et al. (2010). Feldspar: A domain speciﬁc

language for digital signal processing algorithms. In

IN: Proc. 8th ACM/IEEE International Conference on

Formal Methods and Models for Codesign. IEEE.

Bierhoff, K., Liongosari, E. S., and Swaminathan, K. S.

(2006). Incremental development of a domain-speciﬁc

language that supports multiple application styles. In

OOPSLA 6th Workshop on Domain Speciﬁc Model-

ing, pages 67–78.

Bravenboer, M., Groot, R. D., and Visser, E. (2005).

Metaborg in action: Examples of domain-speciﬁc lan-

guage embedding and assimilation using stratego/xt.

In In Participants Proceedings of the Summer School

on Generative and Transformational Techniques in

Software Engineering (GTTSE05. Springer Verlag.

Bravenboer, M. and Visser, E. (2004). Concrete syn-

tax for objects: domain-speciﬁc language embedding

and assimilation without restrictions. SIGPLAN Not.,

39(10):365–383.

Cleenewerck, T. (2003). Component-based dsl develop-

ment. In In Proceedings of GPCE03 Conference, Lec-

ture Notes in Computer Science 2830, pages 245–264.

Springer-Verlag.

Cunningham, H. C. (2008). A little language for surveys:

constructing an internal dsl in ruby. In Proceedings

of the 46th Annual Southeast Regional Conference on

XX, ACM-SE 46, pages 282–287, New York, NY,

USA. ACM.

Czarnecki, K., O’Donnell, J. T., Striegnitz, J., and Taha, W.

(2003). Dsl implementation in metaocaml, template

haskell, and c++. In Domain-Speciﬁc Program Gen-

eration, pages 51–72.

evai, G., Tejfel, M., Gera, Z., P

ali, G., Nagy, G., Horv

ath,

Z., Axelsson, E., Sheeran, M., Vajda, A., Lyckeg

ard,

B., and Persson, A. (2010). Efﬁcient code gener-

ation from the high-level domain-speciﬁc language

Feldspar for DSPs. In ODES-8: 8th Workshop on Op-

timizations for DSP and Embedded Systems.

Freeman, S. and Pryce, N. (2006). Evolving an Embedded

Domain-Speciﬁc Language in Java. In Companion

to the 21st ACM SIGPLAN Conference. OOPSLA’06,

pages 855–865, Portland, Oregon, USA.

Leijen, D. and Meijer, E. (2001). Parsec: Direct style

monadic parser combinators for the real world. Elec-

tronic Notes in Theoretical Computer Science, 41(1).

Sloane, A. M. (2009). Experiences with Domain-Speciﬁc

Language Embedding in Scala.

Spinellis, D. (2001). Notable design patterns for domain-

speciﬁc languages. J. Syst. Softw., 56(1):91–99.

Wadler, P. (1992). Wadler’s ”Law” on lan-

guage design. Haskell mailing list,

http://code.haskell.org/˜dons/haskell-1990-

2000/msg00737.html.

Wile, D. (2004). Lessons learned from real dsl experiments.

Sci. Comput. Program., 51(3):265–290.

Zdun, U. (2010). A dsl toolkit for deferring architectural

decisions in dsl-based software design. Information

and Software Technology, Vol.52(No. 7):733–748.

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

250
