Database Anomalous Activities

Detection and Quantiﬁcation

Elisa Costante

, Sokratis Vavilis

, Sandro Etalle

, Jerry den Hartog

, Milan Petkovi´c

1,2

and Nicola Zannone

Eindhoven University of Technology, Den Dolech 2, Eindhoven, The Netherlands

Philips Research Europe, High Tech Campus 34, Eindhoven, The Netherlands

Keywords:

Data Misuse, Data Leakage, Database Activity Monitoring, Data Leakage Quantiﬁcation.

Abstract:

The disclosure of sensitive data to unauthorized entities is a critical issue for organizations. Timely detection

of data leakage is crucial to reduce possible damages. Therefore, breaches should be detected as early as

possible, e.g., when data are leaving the database. In this paper, we focus on data leakage detection by

monitoring database activities. We present a framework that automatically learns normal user behavior, in

terms of database activities, and detects anomalies as deviation from such behavior. In addition, our approach

explicitly indicates the root cause of an anomaly. Finally, the framework assesses the severity of data leakages

based on the sensitivity of the disclosed data.

1 INTRODUCTION

Data leakage, i.e. the (un)intentional distribution of

sensitive data to an unauthorized entity (Shabtai et al.,

2012), has a signiﬁcant impact on businesses in terms

of money, reputation or legal issues. Data and infor-

mation represent a core asset for many organizations

and thus they should be protected from unauthorized

disclosure.

Timely detection of data leakage is important to

reduce costs and comply with legislation. For in-

stance, the newEU data protection regulation imposes

strict breach notiﬁcation policies, requiring organiza-

tions to notify data protection authorities of a breach

within 24 hours (Information Age, 2012).

In this paper we focus on data leakage detection

by monitoring database activities in terms of SQL

transactions. Observing SQL activities enables for a

prompt reaction by allowing early detection of a leak-

age, i.e. when the information leaves the database.

In this paper we tackle three main problems. First,

despite the considerable amount of research in the

area (Fonseca et al., 2007; Kamra et al., 2007; Roich-

man and Gudes, 2008; Wu et al., 2009; Bockermann

et al., 2009; Mathew and Petropoulos, 2010; Gafny

et al., 2010; Santos et al., 2012), there are still sev-

eral problems with current SQL-based solutions for

database leakage detection. The main problem of

such solutions is their black-box approach: when a

potential leakage occurs, an alarm with a deviation

degree, an anomaly score, or a probability value is

raised. Unfortunately, these values are not sufﬁcient

to explain the root cause of a violation and offer lit-

tle help to seal the leakage. Second, current solutions

have a high false positive rate and their validation has

been limited to controlled environments: in a real sys-

tem (with thousands of transactions per minute) even

a 5% of false positive rate is unacceptable. Finally,

existing solutions are not able to distinguish leakages

based on the sensitivity of the data leaked.

The contribution of our solution is twofold:

• We propose a data-leakage detection model that i)

automatically learns normal behavior by observ-

ing database activities and ﬂags deviations from

such behavior as anomalies; and ii) explicitly in-

dicates the root cause of an anomaly, e.g. whether

the anomaly depends on the tables, data values or

data quantity accessed. The monitoring is done by

tapping into the communication with the database

server to observe which (SQL) queries users sub-

mit, and what data go back and forward.

• Once an anomaly is detected, we propose to quan-

tify the leakage based on the sensitivity of the data

involved. We use a data model to represent the se-

mantics of information and the relations between

different pieces of information. To quantify data

leakage, concepts and instances in the model are

603

Costante E., Vavilis S., Etalle S., den Hartog J., Petkovic M. and Zannone N..

Database Anomalous Activities - Detection and Quantiﬁcation.

DOI: 10.5220/0004612206030608

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 603-608

ISBN: 978-989-8565-73-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

annotated with sensitivity values representing the

cost of their unauthorized disclosure.

2 MOTIVATING SCENARIO

To protect data from unauthorized disclosure, ac-

cess control solutions are usually employed. Despite

this, incidents leaking sensitive information still hap-

pen. An example is the data breach happened at the

Samaritan Hospital, where two nurses illegitimately

accessed and modiﬁed medical records

. Access con-

trol is not enough to protect from data leakage either

because in some domains such as healthcare, certain

actions cannot be blocked (e.g., accessing patient’s

medical records in case of emergency), or because it

is not possible to specify ﬁne-grained access control

policies (e.g., not allow users to access more than a

certain amount of data records).

As an example, assume the information system of

a hospital is only accessed by its employees. In addi-

tion, doctors and nurses can access Electronic Health

Record (EHR) of all the patients of the hospital. No-

tice that, such an assumption is very common in hos-

pitals where data availability is crucial to emergen-

cies. Bob, a geriatrician at the hospital, could easily

engage in behaviors that can be classiﬁed as threats

(T ). For example, T

) Bob might look for EHR of

his colleagues to check if someone has AIDS; or T

)

he might know that a famous singer has been hos-

pitalized for a minor surgery, and look for his room

number to pay him a visit later; or T

) he might read

the EHRs of teenagers while, being a geriatrician, he

should only access EHRs of elderly patients.

Some threats, however, might be more serious

than others. For example, let assume that a doc-

tor usually accesses 20 EHRs per day. Suppose that

one day T

) the doctor reads 500 records contain-

ing the address of patients at the hospital, or T

) 100

records containing the disease suffered by the patients

(amongst which there are AIDS or mental disorder).

Both situations represent a threat because of the un-

usual number of records that has been accessed. How-

ever, the second threat should be considered more se-

vere because more sensitive data are at risk.

3 RELATED WORK

In this section we discuss the existing Data Leak-

age Prevention (DLP) solutions. First, we present an

http://www.timesunion.com/local/article/

Letters-warn-of-access-to-ﬁles-4340178.php

Table 1: General DLP Solutions Overview.

overview of solutions general to DLP, and then we

dive into solutions speciﬁc to Database Activity Mon-

itoring (DAM), the area where we place our contribu-

tion. Finally, we discuss the main limitations of the

available DAM solutions.

General DLP Solutions. Data leakage can happen

at a different location within an organization, e.g. at a

database level, at a network level or at workstation

level. DLP systems differ according to which part

of an organization perimeter they aim to protect from

leakages. Usually, data inside an organization can be

in three different states namely, data-in-use, data-in-

motion, and data-at-rest. Data-in-use are data cur-

rently in process, located at network endpoints such

as workstations, laptops and other devices; data-in-

motion are data moving through the network that may

leave the organization perimeter (e.g., data transmit-

ted over FTP or e-mail); data-at-rest are data resid-

ing in repositories such as database servers. Table 1

presents an overview of the existing DLP solutions

categorized with respect to data states. For example,

in (Carvalho and Cohen, 2007) the focus is essentially

on data-in-motion and speciﬁcally on the e-mail pro-

tocol.

DLP solutions can also differ for the approach

used to detect a leakage. The approaches that are

usually adopted are rule-based, behavior-based and

content-based. In the rule-based approach a set of

predeﬁned policies are used to deﬁne which oper-

ations are allowed or not. Such an approach is

used, e.g., in access control mechanisms and ﬁre-

walls, where a set of rules regulates the access to

resources and data. In the behavior-based approach

the permitted usage of data is deﬁned by observing

users’ behavior: DAM technologies apply this ap-

SECRYPT2013-InternationalConferenceonSecurityandCryptography

604

Table 2: Speciﬁc DAM Solutions Overview.

proach to detect leakage of data-at-rest. With re-

spect to data-in-motion, network behavior monitor-

ing, such as anomaly detection and extrusion detec-

tion systems (Koch, 2011), or Honeypots (Spitzner,

2003) can be used to detect unusual behavior. Fi-

nally, the content-based approach to DLP directly fo-

cuses on data values. Such an approach includes

the use of keywords, regular expressions, text clas-

siﬁcation (Hart et al., 2011), and information re-

trieval (Gessiou et al., 2011; G´omez-Hidalgo et al.,

2010) to detect the presence of sensitive data leaving

the organization perimeter.

Commercial DLP systems usually offer a more

holistic solution by integrating several of the afore-

mentioned approaches. For instance, MyDLP

(http://www.mydlp.com/), focuses on both data-in-

use and data-in-motion. In particular, MyDLP moni-

tors the network trafﬁc (data-in-motion) to detect data

leakage using content-based techniques. In addition,

it regulates the usage of data-in-use by controlling in-

put/output interfaces of workstations.

Speciﬁc DAM Solutions. DAM provides a solution

to detect unusual and unauthorized access to database

records at a very early stage. Several database activ-

ity monitoring tools are available both in the academic

and in the business sectors. Table 2 shows a compar-

ison between currently available solutions. The com-

parison is done over two dimensions: the approach

and features used to detect data leakages.

The approach to detect leakages can be of

three types: blacklisting, rule-based whitelisting and

behavior-based whitelisting. The blacklisting ap-

proach detect leakages based on unauthorized actions

deﬁned on the shape of well-known threats or unde-

sired behavior. In contrast, the whitelisting approach

detect leakages as deviations from authorized actions.

The ways authorized actions are deﬁned differs be-

tween rule-based and behavior-based whitelisting. In

the ﬁrst approach authorized actions have to be man-

ually speciﬁed in rules, while with the latter approach

the authorized actions are automatically learned by

observing user database activities.

Features can be deﬁned as the aspects of database

transactions taken into account while deﬁning rules

and policies (blacklisting and rule-based whitelist-

ing), or while learning normal behavior proﬁles

(behavior-based whitelisting). Features can be clas-

siﬁed into query-based (related to the syntax of the

SQL query), context-based (related to contextual in-

formation, e.g. where, from whom and when the SQL

query has been submitted), and result-set based (re-

lated to the data retrieved by a SQL query).

As shown in Table 2, most of the commercial so-

lutions (with the exclusion of FortiDB and Secure-

Sphere) use rules (black or white listing) to deﬁne

unauthorized behavior that may indicate data leakage.

In contrast, solutions originating from the academia

mostly use a behavior-based whitelisting. With this

approach three main steps are necessary to build a de-

tection system: i) deﬁne the features that represent a

normal behavior proﬁle; ii) learn proﬁles by observ-

DatabaseAnomalousActivities-DetectionandQuantification

605

ing database activities; and iii) detect anomalies by

catching deviations from such proﬁles. Existing so-

lutions applying this approach mainly differ for the

feature set used to proﬁle users, for the algorithms

used to learn normal behavior, and for the accuracy (in

terms of false positive rates) of the detection model.

For example, in (Kamra et al., 2007) normal proﬁles

are built using purely query-based features, i.e. the

table and columns accessed by a user role; when a

new query arrives, it is matched against the proﬁles.

In case a mismatch between the predicted role and the

actual role of the user performing the query exist, an

alarm is raised. Another query-based approach is the

one in (Fonseca et al., 2007), where normal behavior

proﬁles are built based on a graph of valid sequence of

queries. With this model if an attacker executes valid

queries but in an incorrect order (not in the paths of

the graph) an anomaly ﬂag is raised.

At the best of our knowledge the work in (Mathew

and Petropoulos, 2010) is the only one to build nor-

mal proﬁles by using result-set based features. Here,

the records retrieved by SQL queries are modeled in

such a way that it is possible to know what data val-

ues a user usually accesses. Note that also FortiDb

and SecureSphere use result-set based features such

as the number of record retrieved. However, in those

solutions the values of such features have to be de-

ﬁned a-priori and are not learned by observing users’

activities. Finally, Gafny et al. (2010) propose to

add context-based features such as who submitted the

query (userid), at what time (timestamp), and from

which location (IP address) to build behavior proﬁles.

Limitations. Existing approaches do not com-

pletely solve the problem of data leakage. For in-

stance, blacklisting approaches are not able to de-

tect certain types of leakage if they are not known in

advance. Whitelisting partially solves this problem

since, by deﬁning the normal behavior of users, it al-

lows the detection of both known and unknown types

of leakage. However, in the rule-based whitelisting,

an extensive knowledge of internal processes and au-

thorizations is required to deﬁne policies of autho-

rized actions. Behavior-based whitelisting does not

require such a knowledge and it is more time-effective

since authorized behavior is learned by observing

users’ interactions with the database. The main chal-

lenge with behavior-based whitelisting is to identify

the features for proﬁling the normal behavior that

leads to the best accuracy, i.e. reduces the number

of false positives.

With regard to the features, a more extended fea-

ture set would intuitively enable the construction of

more detailed user proﬁles, leading to better detec-

tion results. Indeed, a pure query-based approach

may leave undetected situation where a malicious

user performs a valid query, though accessing values

for which he should have no interest. For example,

with such approach the treats T

, T

, and T

intro-

duced in Section 2 would not be detected, since the

doctor is performing a valid query for his role.

Using result-set features partially solves the pre-

vious problem, allowing the detection of situations

where the SQL query is legitimate, but the data val-

ues accessed are anomalous. Therefore, it is able to

detect those threats, which are missed by only con-

sidering the query-based feature. However, looking

at data values in isolation is not sufﬁcient. Indeed,

it does not allows the detection and discrimination of

threats like T

and T

where the anomaly involves

not only the data values retrieved by a query, but also

their amount and sensitivity.

4 APPROACH

Based on literature review in Section 3, whitelist-

ing approaches are more suitable for database activ-

ity monitoring because they are able to detect both

known and unknown data leakage types. In addition,

especially in complex and dynamic environments, the

deﬁnition of authorization rules might require a large

amount of time and resources that the automatic self-

learning behavior-based approach can save.

For this reason, we propose a framework that uses

a behavior-based whitelisting approach to learn nor-

mal behavior proﬁles and to detect deviations from

such proﬁles as anomalies. Intuitively, if behavior

proﬁles are built by combining query, result-set and

context based features, it is possible to detect a wider

set of data leakage threats. To this end, our approach

builds proﬁles that encompass these different types of

features. In addition, our approach is white-box in

the sense that it allows the identiﬁcation of the root

causes of a data leakage and thus the quantiﬁcation of

its severity based on the sensitivity of the leaked in-

formation. This makes it possible to prioritize alarms

and therefore to reduce the impact of false positives.

Furthermore, we intend to perform the detection of

anomalies per set of and not per single query. This

way, we can detect situations where a single query

is not malicious, but n queries together are (e.g., T

might be carried out by several small queries instead

of a single one which might be more suspicious).

Figure 1 presents a general overviewof our frame-

work. Our solution is divided in two distinct phases:

learning and detection. During the learning phase,

users’ activities, in terms of SQL queries to the

SECRYPT2013-InternationalConferenceonSecurityandCryptography

606

Figure 1: Detection Framework Description.

database, are monitored for a certain period. Such

period should be long enough to capture normal

database access patterns of each user. The data col-

lected during this period are used to learn normal be-

havior proﬁles. Such proﬁles are ﬁne-grain and user-

based in the sense that they are able to model infor-

mation such as which user is accessing which tables

and columns, which values is retrieving, at what time

and from which location. Proﬁles are generated with

a learning algorithm that is able to deal with ﬂows of

large amount of data. Note that in this phase anoma-

lous behavior might be already part of the data col-

lected, e.g., a malicious user is already operating. To

deal with such situation we apply outlier detection

techniquesto highlight anomalous transactions before

the learning, to analyze and possibly discard them

from the learning.

Once proﬁles have been deﬁned, they are incorpo-

rated in a detection model and the detection phase can

take place. During detection, each new transaction of

a user u is analyzed and matched against his proﬁle.

If the transaction does not match the user’s proﬁle,

an anomaly alarm is raised. The alarm clearly states

why the transaction does not match the user proﬁle,

e.g. because he is accessing an unusual table, or at

unusual time, or accessing unusual amount of data.

Detected anomalies are then further analyzed and

labeled with a severity degree. The severity degree

depends on the sensitivity of the data involved in the

transaction. To measure the sensitivity we employ a

data model that is speciﬁc to the application domain.

The data model provides semantic information about

the relationships (e.g., data hierarchy, inference) be-

tween pieces of information. Finally, the data model

is annotated with the sensitivity, necessary for the

Figure 2: Data Model Example.

quantiﬁcation.

As an example of our quantiﬁcation approach we

use threat T

(Section 2). Figure 2 shows an ex-

ample of data model for healthcare domains. Blue

nodes represent the type of information (e.g., demo-

graphic or medical data), while green nodes represent

different instances of a certain type of information

(e.g., personal e-mail or paracetamol medication). We

make this distinction, as the sensitivity is deﬁned both

in terms of the information type and the value.

Each node in the model is annotated with a sen-

sitivity value which represents the cost of its disclo-

sure. Note that in cases where sensitivity is not ex-

plicitly deﬁned, it is propagated downwards through

the data hierarchy. For instance, prescription inher-

its the sensitivity of medical data. Dashed lines rep-

resent inference relationships between the instances,

along with the probability that the disclosure of a

piece of information makes it possible to infer another

piece of information. As an example, a patient treated

with Anti-RetroViral(ARV) is most probably infected

by the HIV virus. When the sensitivity of an instance

is not explicitly deﬁned, then it is calculated as the

DatabaseAnomalousActivities-DetectionandQuantification

607

weighted average of the sensitivities of all the inferred

instances. For example, the sensitivity of information

about Paracetamol is calculated as 34, while the sen-

sitivity of Tamiﬂu is explicitly set to 60. By utilizing

such annotated data model we i) map the data values

accessed by the anomalous query to the data model;

and ii) measure the severity of the anomaly.

Once an anomaly is detected and evaluated, it

has to be analyzed by a security ofﬁcer to determine

whether it is a real or a false alarm. In the ﬁrst case, he

can take the necessary actions, while in case of a false

alarm a feedback is sent back to the detection model,

so that the system can automatically learn from its

own mistakes and thus reduce the false positive rate.

Note that the proposed solution is not only use-

ful for leakage detection, but also for accountability

purposes. Moreover, the monitoring and analysis of

how data is actually accessed can help in discovering

access patterns that are allowed but undesired; in this

case security ofﬁcers might act on the access policies

to solve the problem.

5 CONCLUSIONS

Prompt detection of data leakages is essential to re-

duce the damages they can cause to an organization.

Data leakages can be detected by observing anomalies

in the way data is accessed within the organization

perimeter. Focusing the analysis on database activi-

ties improves the chances of detecting the leakage at

a very early stage. In this paper we proposed a DAM

solution to detect anomalous database activities and to

quantify them according to the sensitivity of the data

leaked.

Our aim is to further develop the proposed frame-

work, and to validate it by the means of extensivetests

on real data, coming from different operational envi-

ronments. The main goal of the validation phase is

to show that the system is able to detect a wide range

of data leakage attacks, while keeping a low rate of

false positive. We are testing our approach in collab-

oration with an industrial partner in the area of service

management. Preliminary results conﬁrm that our ap-

proach improves performance, in terms of false pos-

itive, if compared with other solutions on the same

dataset.

ACKNOWLEDGEMENTS

This work has been partially funded by the THeCS

project in the Dutch National COMMIT program.

REFERENCES

Bockermann, C., Apel, M., and Meier, M. (2009). Learning

SQL for database intrusion detection using context-

sensitive modelling. In Detection of Intrusions and

Malware, and Vulnerability Assessment, LNCS 5587,

pages 196–205. Springer.

Carvalho, V. R. and Cohen, W. W. (2007). Preventing infor-

mation leaks in email. In Proceedings of SIAM Inter-

national Conference on Data Mining.

Fonseca, J., Vieira, M., and Madeira, H. (2007). Integrated

intrusion detection in databases. In Dependable Com-

puting, LNCS 4746, pages 198–211. Springer.

Gafny, M., Shabtai, A., Rokach, L., and Elovici, Y. (2010).

Detecting data misuse by applying context-based data

linkage. In Proceedings of Workshop on Insider

Threats, pages 3–12. ACM.

Gessiou, E., Vu, Q. H., and Ioannidis, S. (2011). IRILD: an

Information Retrieval based method for Information

Leak Detection. In Proceedings of European Con-

ference on Computer Network Defense, pages 33–40.

IEEE.

G´omez-Hidalgo, J. M., Martın Abreu, J. M., Nieves, J., San-

tos, I., Brezo, F., and Bringas, P. G. (2010). Data leak

prevention through named entity recognition. In Pro-

ceedings of International Conference on Social Com-

puting, pages 1129–1134. IEEE.

Hart, M., Manadhata, P., and Johnson, R. (2011). Text clas-

siﬁcation for data loss prevention. In Privacy Enhanc-

ing Technologies, LNCS 6794, pages 18–37. Springer.

Information Age (2012). New EU data laws to include 24hr

breach notiﬁcation.

Kamra, A., Terzi, E., and Bertino, E. (2007). Detecting

anomalous access patterns in relational databases. The

VLDB Journal, 17(5):1063–1077.

Koch, R. (2011). Towards next-generation intrusion detec-

tion. In Proceedings of International Conference on

Cyber Conﬂict, pages 1–18. IEEE.

Mathew, S. and Petropoulos, M. (2010). A data-centric

approach to insider attack detection in database sys-

tems. In Recent Advances in Intrusion Detection,

LNCS 6307, pages 382–401. Springer.

Roichman, A. and Gudes, E. (2008). DIWeDa - Detect-

ing Intrusions in Web Databases. In Data and Appli-

cations Security XXII, LNCS 5094, pages 313–329.

Springer.

Santos, R., Bernardino, J., Vieira, M., and Rasteiro, D.

(2012). Securing Data Warehouses from Web-Based

Intrusions. In Web Information Systems Engineering,

LNCS 7651, pages 681–688. Springer.

Shabtai, A., Elovici, Y., and Rokach, L. (2012). A Survey

of Data Leakage Detection and Prevention Solutions.

SpringerBriefs in Computer Science. Springer.

Spitzner, L. (2003). Honeypots: Catching the insider threat.

In Proceedings of Computer Security Applications

Conference, pages 170–179. IEEE.

Wu, G., Osborn, S., and Jin, X. (2009). Database intrusion

detection using role proﬁling with role hierarchy. In

Secure Data Management, LNCS 5776, pages 33–48.

Springer.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

608
