Pattern-based Mapping of OCL Speciﬁcations to JML Contracts

Ali Hamie

Computing Division, Brighton University, Brighton, U.K.

Keywords:

Constraint Pattern, OCL, JML, Contracts.

Abstract:

OCL is a formal notation to specify constraints on UML models that cannot otherwise be expressed using

diagrammatic notations such as class diagrams. The type of constraints that can be expressed using OCL

include class invariants and operation preconditions and postconditions. However, since OCL constraints

cannot be directly executed and checked at runtime by an implementation, constraints violations may not be

detected or noticed causing many potential development and maintenance problems. This paper describes an

approach for deriving a JML speciﬁcation for a java implementation (a contract) from a speciﬁcation written

in UML and augmented with OCL constraints. This facilitates the checking of OCL constraints at runtime by

translating them to JML executable assertions. The approach is based on the concept of constraint patterns

that enable the reuse of commonly occurring constraints within a given context in software modelling. Each

OCL constraint pattern would be mapped to a corresponding JML pattern that can be used in the translation

process. The result is a library of JML constraint patterns that provides a seamless transition from UML/OCL

designs to Java implementations.

1 INTRODUCTION

The Uniﬁed Modeling Language (UML) (OMG,

2006) has been widely accepted as the standard

object-oriented modelling language and is supported

by a large number of CASE tools. The Object Con-

straint Language (OCL) (Warmer and Kleppe, 2003)

is an integral part of UML, and was introduced to ex-

press additional constraints on models that diagrams

cannot convey by themselves. For example a UML

diagram such as class diagram cannot express all the

relevant constraints about the application being mod-

elled. So class models must typically be reﬁned

with textual constraints written in OCL. These con-

straints include invariants on classes, and precondi-

tions and postconditions of operations. The combina-

tion of UML/OCL in modelling results in more pre-

cise and abstract models. However, developing con-

straint speciﬁcations is not an easy task. Among other

things, one important aspect needs to be taken into

account: class diagrams can express complicated re-

lationships, including subtyping, reﬂexive relations,

or potentially inﬁnitely large instances, and constrain-

ing such facts requires dealing with this complexity.

In order to facilitate and simplify the development

of constraints, the concept of speciﬁcation patterns

has been introduced as constraint patterns in MDE

(Ackermann and Turowski, 2006; Wahler et al., 2006;

Davis and Bonnell, 2007). A constraint pattern cap-

tures and generalizes frequently used logical expres-

sions. It is a parameterizable constraint expression

that can be instantiated to solve a class of speciﬁca-

tion problems. At a more formal level, a constraint

pattern with respect to a meta-model can be deﬁned

as a function that maps a set of meta-model elements

to a constraint.

As a design notation, however, OCL is not ex-

ecutable and OCL constraints are not reiﬁed to im-

plementation artifacts. This could lead to develop-

ment and maintenance problems of constraints such

as inconsistency. One way to overcome some of these

problems is to map OCL constraints to source code in

a form that can be executed and checked at runtime.

Hamie (Hamie, 2004) has deﬁned rules for translating

OCL expressions and constraints to JML expressions

and assertions. This translation was reﬁned and im-

plemented in (Avila et al., 2008) by providing a JML

class libraries for OCL collection types that simpli-

ﬁes the translation. JML is a behavioural interface

speciﬁcation language that can be used to specify Java

classes and interfaces(Leavens et al., 2006), and a sig-

niﬁcant subset of it can be can be checked at runtime

(Cheon and Leavens, 2002). JML is very speciﬁc

to the programming language Java and thus handles

many low-level details. What makes JML suitable

193

Hamie A..

Pattern-based Mapping of OCL Speciﬁcations to JML Contracts.

DOI: 10.5220/0004698301930200

In Proceedings of the 2nd International Conference on Model-Driven Engineering and Software Development (MODELSWARD-2014), pages 193-200

ISBN: 978-989-758-007-9

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

for the translation is that it supports several language

and tool features, in particular, speciﬁcation only vari-

ables called model variables (Cheon et al., 2005) and

speciﬁcation reﬁnements.

Building on previous work, this paper proposes an

approach for translating a UML/OCL speciﬁcation to

a speciﬁcation for a Java implementation (a contract)

based on constraint patterns. The main components

of this approach are a set of JML constraint patterns

that can be used for the translation of OCL constraints

to JML assertions. Each OCL constraint pattern is

translated to a JML speciﬁcation pattern described as

a JML template. The use of constraint patterns makes

the translation intuitive and traceable. It is also ex-

pected that the use of patterns facilitate automation of

the translation.

In addition of being used for the translation of

constraints, the JML constraint patterns are inspired

by those patterns used in OCL, and as such they are

useful for simplifying the development of assertions

for Java classes and interfaces. This is important since

assertions are recognised as a practical programming

tool and are said to be more effective when derived

from formal speciﬁcations such as OCL constraints.

The remainder of the paper is organised as fol-

lows. In Section 2 we brieﬂy review OCL, speciﬁca-

tion patterns, and JML through a small example that

will be used throughout the paper. In Section 3 we de-

scribe a way for translating an OCL constraint pattern

to a JML pattern. In Section 4 we apply the approach

to some OCL constraint patterns and our running ex-

ample. Section 5 provides the conclusion and future

work.

2 BACKGROUND

2.1 Object Constraint Language

The Object Constraint Language (OCL)(Warmer and

Kleppe, 2003) is a textual, declarative notation that

can be used to specify constraints or rules that ap-

ply to UML models. OCL can play an important role

in model driven software engineering because UML

class diagrams are not precise enough to enable the

transformation of a UML model to complete code. In

fact, it is an important component of OMG’s standard

for model transformation for the model-driven archi-

tecture (Frankel, 2002).

A UML class diagram alone cannot express

all relevant constraints about an application. The

diagram in Figure 1, for example, is a UML class

diagram modelling a video rental store. There are

various additional constraints on the model that

VideoRentalStore

members

store

catalog

store

rentals

member

Rental

address: String

Title

name: String

noOfCopies : Integer

Member

name: String

id : Integer

age: Integer

Figure 1: A partial class model for video rental store.

cannot be expressed diagrammatically. For example,

a member can only rent one copy of a video title

at one particular time or the number of copies of

a title is greater than zero. It is very likely that a

system based only on diagrams alone will be incor-

rect. Such additional constraints can be precisely

described using the OCL which is based on predicate

logic and mathematical set theory. For example a

simple constraint stating that the number of copies of

a title is greater than zero can be expressed as follows.

context Title

inv : copiesGreaterZero : self.noOfCopies > 0

This constraint, called an invariant, states a fact

that should be always true in the model. The actual

invariant is represented as an OCL boolean expression

using the variable self that refers to an object of class

Title. copiesGreaterZero is the name of the invariant.

It is also possible to use OCL in order to specify

the behaviour of an operation. For example, the

following OCL constraints speciﬁes the behaviour

of an operation Title::addCopies(n : Integer) using

a pair of predicates describing a precondition and a

postcondition.

context Title::addCopies(n: Integer)

pre : n > 0

post : noOfCopies = noOfCopies@pre + n

The pre and postconditions state that if invoked

with parameter n greater than zero the operation sets

the new number of copies of the title by adding n to

the previous number of copies. In the postcondition,

the @pre annotation denotes the value of a property

at the precondition time.

OCL supports several primitives types such as In-

teger, Real, Boolean, and String and collection types

such as Collection, Set, OrderedSet, Bag, and Se-

quence (Warmer and Kleppe, 2003). These types are

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

194

equipped with various operations that can be used for

writing OCL constraints. For example the collection

operation size returns the number of elements con-

tained in a collection, and the forAll operation checks

whether an expression is true for all objects in a given

collection.

2.2 Speciﬁcation Patterns in OCL

Constraint patterns have been introduced in OCL to

simplify and speed up the development of constraints

and to ensure their consistency (Ackermann and Tur-

owski, 2006; Wahler et al., 2006; Davis and Bon-

nell, 2007). Common constraint expressions are gen-

eralised and captured as constraint patterns. These

patterns can then be instantiated in speciﬁc contexts

to generate the concrete constraints.

An example of a constraint pattern is the Attribute

Value Restriction pattern, which can be used to

restrict the attribute values of a class. It has three

parameters: property of type Property, denoting an

OCL property, operator and value of type OclExpres-

sion, denoting an OCL operator and an expression

respectively. This pattern is described in OCL by the

following template.

pattern AttributeValueRestriction(property: Property,

operator: OclExpression, value: OclExpression) =

self.property operator value

The Attribute Value Restriction pattern can be

applied by providing actual values for the formal

parameters. For instance, the constraint that each

member of the video store is over 18 can be stated as

the following invariant.

context Member

inv over18 : AttributeValueRestriction(age, >, 18)

The pattern has been applied in the context of

the class Member where the parameters property,

operator and value have been replaced by the values

age, > and 18 respectively. By unfolding the above

constraint one obtains the following invariant.

context Member

inv over18 : self.age > 18

A good tool can show an unfolded version of the

constraint on demand.

In (Wahler et al., 2006) an extensible library of el-

ementary constraint patterns was presented for OCL

modelling. The idea of elementary constraint patterns

is to identify a relevant set of atomic constraints that

covers frequently occurring restrictions on a model,

e.g. restrictions on attribute values or on relations

between objects. In addition to elementary con-

straint patterns, composite constraint patterns were in-

troduced in order to express complex properties by

combining an arbitrary number of other constraints.

The identiﬁed composite patterns include Negation,

If-Then-Else, Exists, Or, and And. Tool support for

speciﬁcation patterns is provided in the form of a set

of plug-ins for the MDE tool IBM Rational Software

Architect (RSA) that enable consistency-preserving

reﬁnement of UML class models with constraint pat-

terns (Wahler et al., 2006).

2.3 Java Contracts in JML

The Java Modeling Language (JML) (Leavens et al.,

2006) is a formal speciﬁcation language that can

be used to specify Java classes and interfaces. As

such JML provides an extended Design-by-Contract

concept to the programming language Java. The

Design-by-Contract (DBC) concept includes conven-

tional clauses for preconditions and postconditions of

methods as well as class invariants. JML speciﬁca-

tions or assertions can be added directly to source

code as a special kind of comments called annota-

tion comments, or they can live in separate speciﬁ-

cation ﬁles. These assertions are usually written in

a form that can be compiled, so that their violations

can be detected at runtime. In addition, JML pro-

vides clauses for specifying exceptions, and its ex-

tensions include model and ghost variables which de-

scribe speciﬁcations only data and therefore allow the

modelling of abstract state space. The relationship be-

tween the concrete state space and the abstract one

is achieved by the use of ’represents’ clauses in the

concrete classes and thus formulate a data reﬁnement

relation.

Figure 2 shows a sample Java code annotated with

JML speciﬁcation written in a Java source (.java)

ﬁle. The annotation comments in the source code

are indicated by //@ and /*@ ... @*/. It describes

the behaviour of class Title. The JML keyword

spec−public states that the private ﬁeld noOfCopies

is treated as public for speciﬁcation purpose; e.g., it

can be used in the speciﬁcations of public methods

such as addCopies. The example also shows the

speciﬁcation of the method addCopies. A method

speciﬁcation precedes the declaration of the method.

The requires clause speciﬁes the precondition, the

Pattern-basedMappingofOCLSpecificationstoJMLContracts

195

/ / F i l e : T i t l e . j a v a

p u b l ic c l a s s T i t l e {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t n oO fCo pie s ;

/ /@ p u b l i c i n v a r i a n t t h i s . n o O f Co p i e s >= 0 ;

/ ∗@ r e q u i r e s n >= 0 ;

@ a s s i g n a b l e no Of Co p ie s ;

@ e n s u r e s n oO f C o pi e s == \ o l d ( n oO f C o pi e s )+ n

@∗/

p u b l i c v o i d a d d Co p i e s ( i n t n ) {}

/ / t h e r e s t o f d e f i n i t i o n

}

Figure 2: Sample Java code with JML annotations.

assignable clause speciﬁes the frame condition, and

the ensures clause speciﬁes the postcondition. The

JML keyword old in the postcondition denotes the

pre-state value of its expression; it is mainly used in

the speciﬁcation of a method such as addCopies that

changes the state of an object.

JML is widely accepted and supported by a range

of tools covering the different levels of program ver-

iﬁcation from runtime checking (Iowa State JML

tools, via (Leavens et al., 2003)) to static checking

(ESC/Java2, (Cok and Kiniry, 2004)) to ’real’ inter-

active veriﬁcation (Loop project, (Jacobs and Poll,

2003)). Typically JML extensions are encapsulated in

specially formatted Java comments, so that any Java

tool can still handle the source code.

3 Mapping OCL Patterns to JML

A UML/OCL speciﬁcation can be mapped to JML by

identifying constructs in the Java program that match

the modelling elements of UML/OCL. These include

types, expressions, operations and classes.

The Types in OCL are directly mapped to Java

types, i.e. Java interfaces providing the required

methods. For certain integer subsets that ﬁt in Java

int range we will use that, otherwise we map them

also to interfaces that encapsulate JML

s \bigint.

Sets, relations, etc. can be mapped to JMLs model

classes, but we have to perform cast operations for

retrieving the original types since JML does not yet

support Java

s generics.

OCL expressions are rephrased as Java expres-

sions. Predicates in OCL are boolean expressions and

mapped to Java boolean expressions extended with

various forms of quantiﬁcations including universal

and existential quantiﬁcations.

In order to translate OCL constraint patterns to

JML patterns we make use of previous work done

on translating OCL into JML. For instance (Hamie,

2004) deﬁnes rules for mapping OCL expressions to

JML expressions. A library-based approach for trans-

lating OCL to JML is given in (Avila et al., 2008).

The latter approach aims at making the mapping eas-

ier by building a library of Java classes for the OCL

types and expressions. The current approach builds

on previous work and aims to make the translation

more intuitive and traceable.

3.1 Constraint Patterns in JML

The key idea of our approach is to introduce a set

of constraint patterns for JML corresponding to OCL

constraint patterns. That is the identiﬁed JML pat-

terns are directly inspired by OCL patterns. The se-

mantics of JML constraint patterns can be captured as

a JML template, i.e. a parameterizable JML expres-

sion. To be more speciﬁc, the template can be used

as macros because patterns are untyped. The syntax

of an JML template starts with the keyword pattern

followed by the name of the pattern and a set of typed

parameters in brackets. This is followed by an equals

sign and an arbitrary JML expression in which the

name of formal parameters can be used. This is sim-

ilar to the syntax of OCL templates. A JML pattern

can be deﬁned as a function that maps a set of meta-

model elements to a Java constraint. In the follow-

ing, we deﬁne the Singleton design pattern using the

template language, assuming that there is a method

getInstances that returns the set of instances of a

Java class.

pattern Singleton(element: Class) =

element.getInstances().size() == 1

JML templates can be used as ﬁrst-class lan-

guage elements of JML. When they are instantiated,

the formal parameters are replaced by the values of

the actual parameters. As an example, we instanti-

ate the Singleton pattern to constrain the number of

VideoRentalStore objects in a model state to one.

Note that in the following code the two listed invari-

ants of the class VideoRentalStore are semantically

equivalent.

p u b l i c c l a s s V i d e o R e n t a l S t o r e {

/ /@ i n v a r i a n t S i n g l e t o n ( V i d e o R e n t a l S t o r e ) ;

/ ∗@ i n v a r i a n t

@ V i d e o R e n t a l S t o r e . g e t I n s t a n c e s ( ) . s i z e ( )= = 1;

@∗/

}

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

196

The above example shows that constraint patterns

are concise means of hiding the syntactic and se-

mantic complexity of JML expressions and offering

a unique name and uniform interface to the program-

mer.

3.2 Translating OCL Patterns

The general form of an OCL constraint pattern is

given by the following template.

pattern patternName(p

: Type

, ..., p

: Type

) = patternBody

patternName stands for the name of the pattern,

, ..., p

is the list of parameters for the pattern of

types Type

, ..., Type

respectively, and patternBody

is the body of the pattern represented as an OCL ex-

pression built using the parameters and OCL opera-

tions. The types of parameters Type

, ..., Type

are

types from the UML/OCL metamodel.

The corresponding JML pattern is obtained from

the OCL pattern by mapping the types of parameters

to types in the JML metmodel, and by translating the

body of the pattern into a JML expression. If Type

is mapped to jmlType

(i = 1, .., n) and patternBody

is mapped to jmlpatternBody then the JML pattern is

given as follows.

pattern oclPatternName( p

: jmlType

, ..., p

: jmlType

) =

jmlpatternBody

Translating the body of the OCL pattern to a body

for the corresponding JML pattern can be achieved by

using the translation rules deﬁned in (Hamie, 2004;

Avila et al., 2008). This process can be applied to

each OCL constraint pattern. The diagram in Figure 3

can be interpreted as saying that there are two ways to

obtain a JML assertion from an OCL constraint. The

starting point is applying an OCL constraint pattern.

Unfolding the deﬁnition of the pattern we obtain the

OCL constraint which can be mapped to a JML as-

sertion using the mapping deﬁned in (Hamie, 2004).

The other way is not to unfold the OCL pattern but to

use the corresponding JML pattern to do the mapping.

Then the JML assertion can be obtained by unfolding

the deﬁnition of the JML pattern. Assuming appro-

priate mappings have been used, the two ways should

lead to semantically equivalent JML assertions.

4 APPLYING THE APPROACH

In this section we apply our approach to the video

rental store model. This will be based on some exist-

OCL − Pattern

−−−−→ JML − Pattern

instantiate



instantiate

OCL −Constraint

−−−−→ JML −Constraint

Figure 3: Constraint pattern mapping diagram.

ing OCL constraint patterns as introduced in (Wahler

et al., 2006).

4.1 Attribute Value Restriction

In background section (Section 2.1) on OCL, we in-

troduced the constraint copiesGreaterZero, which we

deﬁned as follows.

context Title

inv : copiesGreaterZero : self.noOfCopies > 0

This constraint represents a common kind of

constraint, namely simple value restrictions for

attributes. So the Attribute Value Restriction pattern

was introduced in order to restrict the values of

attributes for all instances of the attributes’ class.

This pattern was introduced in the background

section (Section 2.2) of speciﬁcation patterns, which

is deﬁned by the following OCL template.

pattern AttributeValueRestriction(property: Property,

operator: OclExpression, value: OclExpression) =

self.property operator value

Translating the Attribute Value Restriction pattern

to a JML pattern involves mapping the parameters

of the OCL pattern into parameters of the JML

pattern with appropriate types. This assumes we

have in place metamodels for both OCL and JML.

In this case property is mapped to a JML ﬁeld of

the same name and with type Field. The parameters

operator and value are mapped to JML expressions

with the same names of type JmlExpression. This

followed by mapping the body of the pattern which

an OCL expression. In this case the expression

self.property operator value is simply mapped to

this.property operator value. Therefore we

obtain the following JML pattern.

pattern oclAttributeValueRestriction(property: Field,

operator: JmlExpression, value: JmlExpression) =

this.property operator value

Pattern-basedMappingofOCLSpecificationstoJMLContracts

197

In section 2.2 we applied the Attribute Value Restric-

tion pattern in the context of the UML class Member

and obtained the following invariant.

context Member

inv over18 : AttributeValueRestriction(age, >, 18)

Before translating this constraint to a JML asser-

tion, we need to implement the class Member and

its attributes in Java. In this case we map Member

to a Java class with the same name and map the at-

tribute age to a Java ﬁeld age. The invariant of the

class Member is then translated by applying the cor-

responding JML pattern with actual parameters age,

> and 18. The class Member with the translated in-

variant is given as follows.

p u b l i c c l a s s Member {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t ag e ;

/ ∗@ p u b l i c i n v a r i a n t

o c l A t t r i b u t e V a l u e R e s t r i c t i o n ( age , >, 1 8 ) ;

@∗/

}

By unfolding the pattern deﬁnition, we obtain the fol-

lowing JML invariant:

p u b l i c c l a s s Member {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t ag e ;

/ /@ p u b l i c i n v a r i a n t t h i s . a g e > 18

}

4.2 Multiplicity Restriction

The multiplicities of properties (associations) can

only be roughly constrained in a diagrammatical way

in class models. However, there are situation where

the multiplicity of an association depends on the value

of an attribute. For example, an object of class Title

can have an arbitrary number of rentals which cannot

exceed the total number of copies for that title. So

there is a dependency between the association with

role name rentals and the attribute noOfCopies. Here

we are assuming that the model deals with current

rentals rather than past rentals. A constraint pattern

named Multiplicity Restriction is deﬁned in (Wahler

et al., 2006) to capture this kind of constraints. This

pattern is presented as an OCL template as follows.

pattern MultiplicityRestriction (navigation : Sequence(Property),

operator: OclExpression, value: OclExpression) =

self.navigation−>asSet()−>size() operator value

This pattern has three parameters: navigation, rep-

resented as a sequence of properties, thus allow-

ing the use of OCL navigation expressions such as

self.catalog.rentals, operator, and value, which can be

arbitrary OCL expressions. value can be the name of

an attribute or an arbitrary OCL expression. Since

self.navigation may result in a bag, the OCL operator

asSet() is used to convert the resulting collection into

a set.

Using the Multiplicity Restriction pattern, we can

deﬁne the constraint RentalsRestriction as follows.

context Title inv: RentalsRestriction :

MultiplicityRestriction(rentals, <=, noOfCopies)

This is done by replacing the parameters navigation,

operator and value by rentals, <=, and noOfCopies

respectively.

The Multiplicity Restriction pattern can

be translated to the following JML pattern.

pattern oclMultiplicityRestriction (navigation:List<Field>,

operator: JmlExpression, value: JmlExpression) =

this.navigation.uniqueSet().size() operator value

The expression this.navigation represents

the translation of the OCL navigation expression

self.navigation built from the sequence of proper-

ties given as a parameter. Since the result of

self.navigation is a bag, we used the Java method

uniqueSet to convert a bag into a set.

The translation of the multiplicity restriction in-

variant for rentals property is given in the following

code.

p u b l i c c l a s s T i t l e {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t no Of C o pi e s ;

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e Se t<Re n t a l> r e n t a l s ;

/ ∗@ p u b l i c i n v a r i a n t

o c l M u l t i p l i c i t y R e s t r i c t i o n ( r e n t a l s ,

<=, n o O f Co p i e s ) ;

@∗/

}

The implementation of the class Title uses JDK

set with its multiplicity expressed as a class invari-

ant. The translation in this particular case uses pro-

gram variables (i.e. the rentals ﬁeld) in the asser-

tion. One of the potential problems with this approach

is the maintenance of both OCL constraints and Java

programs. For example, changing the implementation

from sets to arrays will affect the whole JML asser-

tion. This might make it necessary to rewrite the JML

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

198

assertions in terms of the vocabulary of the new repre-

sentation, i.e. arrays. One way to overcome this prob-

lem is to use model ﬁelds (Cheon et al., 2005) which

are speciﬁcation only variables. That is they can be

referred to only in assertions, but not in program code.

The pattern-based approach is useful maintaining as-

sertions since changing the body of a pattern would

apply to every assertion deﬁned in terms of that pat-

tern.

By unfolding the above invariant we get:

p u b l i c c l a s s T i t l e {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t no Of C o pi e s ;

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e Se t<Re n t a l>r e n t a l s ;

/ ∗@ p u b l i c i n v a r i a n t

t h i s . r e n t a l s . s i z e ()<= n o O fC o p i es ;

@∗/

}

4.3 Unique Identiﬁcation

The Unique Identiﬁcation pattern is very frequent.

For example, in the video rental model it is required

that the id for members is unique. That is any

members m1 and m2 should be distinguishable by

their membership identities. In OCL such constraint

is expressed as follows.

context Member

inv UniqueID: Member.allInstances->isUnique(id)

This constraint can be generalized to composite pri-

mary keys by using the OCL tuple type.

The Unique Identiﬁer pattern (Wahler et al.,

2006) (referred to Semantic Key in (Ackermann and

Turowski, 2006)) captures the situation where an

attribute (or a group of attributes) of a class plays the

role of an identiﬁer for the class. That is the instances

of the class should differ in their values for that

attribute (group). The corresponding OCL template

is given as follows.

pattern UniqueIdentiﬁer (class: Class, property : Property) =

class.allInstances->isUnique(property)

This pattern has two parameters class which repre-

sents the context of the invariant, property, which

denotes a property that have to be unique for each

object of the context class. The body of the pattern

is deﬁned in terms of the operation allInstances,

which returns the set of existing instances of the

class, and the operation isUnique. This pattern can be

generalised to more than one property by using the

OCL tuple type.

The corresponding JML pattern can be deﬁned as

follows.

pattern oclUniqueIdentifier (class: Class, property: Field) =

(\forall class a1, a2; \created(a1) && \created(a2);

a1 != a2 ==> a1.property != a2.property)

The pattern Unique Identiﬁer takes a class and a

property as parameters. It asserts that for any two dis-

tinct created instances a1 and a2 of class class, their

values for property are different. The JML keyword

\created restricts the range of the quantiﬁcation to

created objects.

To make the correspondence between OCL and

JML simpler it is possible to introduce a primitive

quantiﬁer (\unique that asserts the uniqueness of a

property or ﬁeld. In that case the Unique Identiﬁer

pattern can be concisely stated as follows.

pattern oclUniqueIdentifier (class: Class, property: Field) =

(\unique class a; \created(a); property)

Applying the Unique Identiﬁer pattern in the con-

text of the class Member we get the following invari-

ant.

context Member

inv UniqueID: UniqueIdentiﬁer(Member, id)

The following code shows the translated invariant

in JML.

p u b l i c c l a s s Member {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t i d ;

/ ∗@ p u b l i c i n v a r i a n t

o c l U n i q u e I d e n t i f i e r ( Member , i d ) ;

@∗/

}

By unfolding the above invariant we obtain:

p u b l i c c l a s s Member {

/ ∗@ s p e c p u b l i c @∗/ p r i v a t e i n t i d ;

/ ∗@ p u b l i c i n v a r i a n t

( \ f o r a l l Member a1 , a2 ;

\ c r e a t e d ( a1 ) && \ c r e a t e d ( a2 ) ;

a1 != a2 ==> a1 . i d != a2 . i d ) ;

@∗/

}

Pattern-basedMappingofOCLSpecificationstoJMLContracts

199

Note that the translated JML pattern does not work

when the equality test is based on value equality be-

tween objects. This is the case when the type of

the ﬁeld is String where the equality test should be

based on the method equals rather than ==. One

way to have another version of the JML pattern that

uses equals, so that the mapping chooses the right

pattern based on the type of the property.

5 CONCLUSIONS

We proposed an approach to translating OCL con-

straints to JML assertions based on the concept of

constraint pattern. The main component of our ap-

proach is a set of JML constraint patterns implement-

ing OCL constraint patterns. The possible beneﬁts

of this approach is enhancing the quality of the trans-

lated assertions by expressing them in a more compact

way, and support automating the translation. With ap-

propriate tool support, the JML patterns can be used

stand alone to facilitate and simplify the development

of JML assertions. The pattern-based approach will

have to be evaluated with some real examples.

REFERENCES

Ackermann, J. and Turowski, K. (2006). A Library of OCL

Speciﬁcation Patterns for Behavioral Speciﬁcation of

Software Components. In Proceedings of the 18th in-

ternational conference on Advanced Information Sys-

tems Engineering, CAiSE’06, pages 255–269, Berlin,

Heidelberg. Springer-Verlag.

Avila, C., Flores, G., and Cheon, Y. (2008). A Library-

based Approach to Translating OCL Constraints to

JML Assertions for Runtime Checking. In Interna-

tional Conference on Software Engineering Research

and Practice, Las Vegas, Nevada, pages 403–408.

Cheon, Y. and Leavens, G. T. (2002). A Runtime Assertion

Checker for the Java Modeling Language (JML). In

Proceedings of the International Conference on Soft-

ware Engineering Research and Practice (SERP 02),

Las Vegas, pages 322–328. CSREA Press.

Cheon, Y., Leavens, G. T., Sitaraman, M., and Edwards,

S. (2005). Model Variables: Cleanly Supporting Ab-

straction in Design by Contract. Software-practice &

Experience, 35(6):583–599.

Cok, D. R. and Kiniry, J. R. (2004). ESC/Java2: Uniting

ESC/Java and JML - Progress and Issues in Building

and Using ESC/Java2. In Construction and Analysis

of Safe, Secure and Interoperable Smart Devices: In-

ternational Workshop, CASSIS 2004. SpringerVerlag.

Davis, J. P. and Bonnell, R. D. (2007). Propositional

Logic Constraint Patterns and Their Use in UML-

Based Conceptual Modeling and Analysis. IEEE

Trans. Knowl. Data Eng., pages 427–440.

Frankel, D. (2002). Model Driven Architecture: Applying

MDA to Enterprise Computing. John Wiley & Sons,

Inc., New York, NY, USA.

Hamie, A. (2004). Translating the Object Constraint Lan-

guage into the Java Modelling Language. In Proceed-

ings of the ACM Symposium on Applied Computing,

pages 1531–1535. ACM Press.

Jacobs, B. and Poll, E. (2003). Java Program Veriﬁcation

at Nijmegen: Developments and Perspective. In Ni-

jmegen Institute of Computing and Information Sci-

ences, pages 134–153. Springer.

Leavens, G. T., Baker, A. L., and Ruby, C. (2006). Prelim-

inary Design of JML: A Behavioral Interface Speciﬁ-

cation Language for Java. SIGSOFT, 31(3):1–38.

Leavens, G. T., Cheon, Y., Clifton, C., Ruby, C., and Cok,

D. R. (2003). How the design of JML accommo-

dates both runtime assertion checking and formal ver-

iﬁcation. In SCIENCE OF COMPUTER PROGRAM-

MING, pages 262–284.

OMG (2006). Uniﬁed Modeling Language Speciﬁcation

2.0: Infrastructure. OMG doc. smsc/06-02-06.

Wahler, M., Koehler, J., and Brucker, A. D. (2006). Model-

Driven Constraint Engineering. In MoDELS Workshp.

on OCL for (Meta-)Models in Multiple Application

Domains, pages 111–125.

Warmer, J. and Kleppe, A. (2003). The Object Constraint

Language: Getting Your Models Ready for MDA.

Addison-Wesley, Reading, MA.

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

200
