Human Rating of Emotional Expressions

Scales vs. Preferences

Marco Pasch

, Andrea Kleinsmith

and Monica Landoni

Faculty of Informatics, University of Lugano, via Bufﬁ 13, 6900 Lugano, Switzerland

Department of Computer and Information Science and Engineering, University of Florida, FL 32611, Gainesville, U.S.A.

Keywords:

Perception, Emotions, Affect, Preference Rating, Scale Rating, Ground Truth Labeling.

Abstract:

Human ratings of emotional expressions are the foundation for building and training automatic affect recogni-

tion systems. We compare two rating schemes for labeling emotional expressions: likert scales and pair-wise

preferences. A statistical analysis shows that while there is a strong correlation between the two schemes,

there are also frequent mismatches. Our ﬁndings indicate that the schemes perform differently well per affect

label. We discuss reasons for this and outline planned future work based on the ﬁndings.

1 INTRODUCTION

When building automatic affect recognition systems

based on bodily manifestations of affect (such as fa-

cial expressions, posture, behavior, physiology) one

typically has to go through the following steps. First,

collecting data that contains such bodily manifesta-

tions. Then, establishing which particular affective

states can be observed in the data when it is consid-

ered that an inherently ”correct” affective label does

not exist, a process known as ground truth labeling.

With these labels one would search for the features

within the collected data that are key to the respective

affective states. These then form the basis for build-

ing a system that can automatically identify affective

states.

Establishing the ground truth is thus a key compo-

nent in the development process. Human perception

of emotions is often the benchmark that a system is

tested against; it is an important step for the creation

of affect recognition systems. Labels are often ob-

tained in two ways: self-report from the person who

portrayed an emotional expression or recruiting ob-

servers to rate images or sequences of affective ex-

pressions and assign a label to each sequence.

Our aim is to ﬁnd better rating schemes for ob-

taining ground truth labels. For this, we investigate

alternative methods for rating stimuli containing emo-

tional expressions. At the very least, this allows us to

assess the inﬂuences of particular schemes on the re-

sulting affect labels. Ideally, we can make recommen-

dations which labeling scheme works best given the

particular goals of a study or system to be developed.

In this initial study, we compare two rating schemes

for the labeling of a corpus of affective body pos-

tures: pairwise preference rating and rating on mul-

tiple scales. The hypothesis that the rating schemes

are tested against is:

. There is an inconsistency between reported pref-

erences and reported scale ratings.

The remainder of this paper is organized as follows:

Section 2 examines typical approaches for establish-

ing the ground truth. Section 3 describes the method

implemented in our study to compare ground truth la-

beling approaches. The results are reported in Section

4. A discussion and conclusions are presented in Sec-

tions 5 and 6, respectively.

2 GROUND TRUTH LABELING

Emotional expressions are usually elicited in two

ways: letting actors portray emotions that are not ac-

tually felt (acted) or recording the affective behav-

ior of people in various scenarios and who were not

instructed to portray particular behavior (non-acted).

Acted expressions are often exaggerated portrayals of

emotional states, whereas non-acted expressions are

generally subtler and more complex. Not surpris-

ingly, until recently automatic affect recognition sys-

tems were based on acted expressions, as these are

easier to detect (Zeng et al., 2009). Only recently

there has been a shift towards subtler naturally occur-

ring expressions.

240

Pasch M., Kleinsmith A. and Landoni M..

Human Rating of Emotional Expressions - Scales vs. Preferences.

DOI: 10.5220/0004727602400245

In Proceedings of the International Conference on Physiological Computing Systems (PhyCS-2014), pages 240-245

ISBN: 978-989-758-006-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

However, self-report may not be feasible and is of-

ten considered unreliable (Afzal and Robinson, 2009;

Kapoor et al., 2007). Yet, in particular since the

shift towards non-acted data, observer ratings are be-

coming more common for establishing the ground

truth (Kleinsmith and Bianchi-Berthouze, 2013). This

method may be particularly relevant when the aim of

the application into which the recognition software

will be integrated is to act as a human interaction part-

ner.

When establishing the ground truth using ob-

servers, what labeling model should be used? Two

options are pairwise preference ratings and rating

on multiple scales. Many studies in the Affective

Computing ﬁeld employ a forced-choice design, e.g.,

(Savva and Bianchi-Berthouze, 2012) and (Klein-

smith et al., 2011). In this design, observers are pre-

sented with a list of choices and are forced to choose

from that list. An advantage of a forced-choice design

over a free-form design is that it forces an absolute

match and eliminates the possibility of observers pro-

viding non-emotion labels, a known issue with free-

form designs (Russell, 1994). However, forcing an

absolute match is also a disadvantage, as the list may

not include all options considered applicable by the

observers. Similarly, concurrence of more than one

distinct emotional state can not be captured in a forced

choice design. Also, the intensity of a perceived emo-

tion is lost, which may be particularly problematic

when dealing with subtle emotional expressions.

Pairwise preference rating is used in artiﬁcial in-

telligence (F

urnkranz and H

ullermeier, 2005; Doyle,

2004) and machine learning (Yannakakis, 2009) ﬁelds

and may be considered an attempt to overcome the

limitation of a forced choice design. In pairwise

preference rating, observers are presented with pairs

of stimuli and asked to choose which stimulus best

represents a particular label. This process is re-

peated for all possible stimulus pairs. Because it does

not require the observers to determine an absolute

match, pairwise preference rating may help to reduce

the variability that exists between observers when a

forced choice design is used (Kleinsmith and Bianchi-

Berthouze, 2013).

Obtaining ratings for the same stimulus on mul-

tiple scales representing discrete emotion labels has

also been used in other emotion recognition research

(Liscombe et al., 2003). Observers were asked to rate

speech tokens on separate scales for 10 discrete emo-

tions. The authors conclude that by rating stimuli on

multiple emotion scales shows that their stimuli ex-

pressed several different emotions at the same time,

resulting in a better, more complete representation of

emotion.

3 METHOD

3.1 Participants

For this initial study, participants were recruited via

mailing lists from within the university community.

They were aware of the aims of the study and no com-

pensation was given. 12 participants took part in the

study.

3.2 Stimuli

As stimuli we use images from the UCLIC Database

of Affective Postures and Body Movements (Klein-

smith et al., 2006; Kleinsmith et al., 2011); these are

readily available online. The database consists of sep-

arate corpora of acted and non-acted whole body pos-

tures, of which we use the latter. The non-acted col-

lection consists of 105 postures that were obtained

from people playing physically active video games

and have been rated for four affective labels: con-

centrating, defeated, frustrated, and triumphant. The

postures are modeled on an abstract avatar seen from

a frontal perspective in front of neutral grey back-

ground.

In order to prevent study fatigue and to account

for the fact that the study was conducted online (as

was the original labeling for the database used), the

number of ratings the participants were required to

make was kept to a level sufﬁcient for carrying out

the study.

For this reason we only use a subset of 10 postures

from the UCLIC collection, chosen at random. Pair-

wise preference rating means that for n postures, n ∗

(n − 1)/2 pairs of postures have to be rated. For the

entire corpus this would result in 5460 pairs. Bringing

the number of stimuli down to 10 results in 45 pairs.

Figure 1 shows one of the 45 screens participants see

in the preferences condition. In a further attempt to

keep the number of ratings at a manageable level, we

let our participants rate a posture for all four labels

in one screen in the scale condition as can be seen in

Figure 2.

3.3 Procedure

Upon clicking on the link in the invitation email, par-

ticipants reached the welcome screen. Here they re-

ceived information about the study and that we ask

them to rate postures on 55 screens. The order of rat-

ing conditions was assigned randomly.

In the preference condition, participants saw two

postures next to each other. Below the posture im-

ages, they were asked: ”Which posture looks more

HumanRatingofEmotionalExpressions-Scalesvs.Preferences

241

Figure 1: Screenshot Preference condition.

Figure 2: Screenshot Scales condition.

PhyCS2014-InternationalConferenceonPhysiologicalComputingSystems

242

[blank] ?” four times; each time with the blank re-

placed by the four affective labels concentrating, de-

feated, frustrated, triumphant, respectively. With ra-

dio buttons they then indicated whether the posture on

the left or on the right better corresponded to the label

in question. Clicking a button labeled next brought

them to the next screen. The order of the pairs was

designed so that the same posture never appeared on

two consecutive screens.

In the scales condition, participants saw a single

posture and the instruction: ”Please rate the posture

for the following attributes:” Below, they saw four

likert scales for the four affective labels, each with

ﬁve options to rate the intensity of the particular at-

tribute: extremely, fairly, moderately, slightly, and not

at all.

After having rated the postures in both conditions,

participants saw a debrieﬁng screen, thanking them

for their participation and giving them the opportunity

to write any comments or thoughts they might have

had in a text ﬁeld.

4 RESULTS

The average time participants took to take part in the

survey was 26.8 minutes, with a median of 23.5 min-

utes. We ﬁrst check for order effects between the

group of participants that ﬁrst rated preferences and

the group that ﬁrst rated on scales. No signiﬁcant dif-

ferences can be found.

4.1 Comparison to existing Labels

The postures of the UCLIC Database of Affective

Postures and Body Movements have already been la-

beled with the most frequent label that were assigned

by raters when the data corpus was created. From the

postures chosen for the study, 2 out of 10 postures are

assigned different labels by our participants than la-

bels that were assigned in the initial rating.

4.2 H

Test Statistic

To measure the degree of agreement between scale

ratings and preference ratings we calculate the corre-

lation coefﬁcients between them. For this we follow

the statistical analysis procedure for pairwise pref-

erence data introduced by (Yannakakis and Hallam,

2007). This procedure has been previously applied for

the comparison of scale ratings and preference ratings

for self-report data in (Yannakakis and Hallam, 2011).

To make a comparison possible, pairwise preferences

are inferred from scale ratings. These are then com-

pared to the direct pairwise preferences.

Following (Yannakakis and Hallam, 2007), we ob-

tain the correlation coefﬁcients using

c(z) =

∑

i=1

(1)

where N is the number of pairs i to correlate and z

+1, if scale ratings and preference ratings and z

= −1

where there is no match. P-values of c(z) are obtained

from the binomial distribution.

We only take into account pairs where we can

infer a clear preference from the scale ratings. If,

e.g., a participant chose moderately for posture A and

slightly for posture B for the same affective label, we

can infer a preference for posture A in a pairwise com-

parison. This way, we do not assume a numerical ba-

sis of the scale. Also, we do not compare one partici-

pant’s scale ratings to another.

As can be seen in Table 1, the direct preference

ratings matched the preferences inferred from the

scale ratings for 74% of the data samples (1595 out

of 2160 possible matches). The number of incidents

where we can infer a preference from scale ratings

varies from 116 to 148 per participant, out of a pos-

sible total of 180 ratings (45 posture pairs x 4 af-

fect labels). In total we have 1595 incidents where

we can correlate between the preference rating con-

dition and the scale rating condition. Correlation co-

efﬁcients vary from .43 to .74 per participant and the

total agreement correlation coefﬁcient is .61. All cor-

relation coefﬁcients are highly statistically signiﬁcant,

ruling out the null hypothesis H

4.3 Agreement Rates Across Affect

Labels

Next, we take a closer look at the agreement rates be-

tween participants for each posture pair. We calculate

the difference in agreement rates between direct pref-

erence ratings and inferred preference ratings for each

posture pair where there is a clear preference inferred

from scale ratings. We split the differences in agree-

ment rates into three groups: scale rating has a lower

agreement rate as preference rating, scale rating has

the same agreement rate than preference rating, and

scale rating has a higher agreement rate than prefer-

ence rating.

Figure 3 shows the distribution of ratings for each

affect label across the three groups. We can see that

the labels frustrated and concentrated are rated more

often with lower agreement rates in the scales con-

dition than the preference condition. They are rated

least frequently when there are higher agreement rates

HumanRatingofEmotionalExpressions-Scalesvs.Preferences

243

Table 1: Number of matches between preference ratings

and inferred scale ratings, number of incidents where there

was a clear preference (out of 180 possible preferences

per participant), and correlation coefﬁcients between prefer-

ences and inferred scale ratings (all statistically signiﬁcant

at p<0.01).

Matches Incidents c(z)

P1 113 145 0.56 *

P2 110 146 0.51 *

P3 116 133 0.74 *

P4 94 116 0.62 *

P5 103 128 0.61 *

P6 110 135 0.63 *

P7 108 123 0.76 *

P8 125 144 0.74 *

P9 97 123 0.58 *

P10 106 148 0.43 *

P11 90 119 0.51 *

P12 111 135 0.64 *

Sum 1283 1595 0.61 *

in the scales condition. The label defeated is to a

lesser extent also rated more often with a lower agree-

ment for scales than for preferences. The label tri-

umphant on the other hand is only rated in a few in-

stances with a higher agreement rate for scales than

for preferences. In most instances, there is a higher

agreement rate for preferences than for scales. Where

the scale condition receives the same agreement rates

as the preference condition, all affect label appear

with similar frequency.

Figure 3: Distribution of ratings for an affect label across

participants that happen with a lower agreement rate for

scales than for preferences (SC<PR), an equally high

agreement rate for scales and preferences (SC=PR), and

higher agreement rate for scales and preferences (SC>PR).

5 DISCUSSION

Most signiﬁcant is the ﬁnding that while direct pref-

erences and preferences inferred form scale ratings

are well correlated, there are frequent mismatches.

The question remains, why is there a mismatch be-

tween scale ratings and preferences ratings from the

same raters on the same set of stimuli? One possi-

ble answer is indicated by our analysis of differences

between agreement rates for each affect label across

the two rating schemes. This revealed differences in

agreement rates. These are distributed unevenly, in

that some affect labels are more often rated with a

higher agreement rate in one scheme, and others are

rated more often with higher agreement rates in the

other scheme. It thus appears that the rating schemes

may be differently well suited for various affect la-

bels. With the limitation of our ﬁndings being based

on only one corpus of affective data we must be care-

ful to generalize this ﬁnding to other rating scenarios.

There are several other points worth noting. A

study taking all of them into account is beyond the

scope of the present paper, but our ﬁndings indicate

that such a study may be worthwhile.

Number of ratings. As pointed out above, there

were many more ratings in the preference scheme

than in the scale scheme. Where n stimuli are to be

rated, there have to be n ∗ (n − 1)/2 ratings. Our pos-

ture set is comparably small (n=10), still we already

had 45 ratings in the preference scheme as opposed

to 10 in the scale scheme. Rating a large number of

abstract postures quickly becomes a monotonous task

and in fact several participants reported that felt bored

towards the end of the study. Another comment was

that a participant felt increasingly insecure about pre-

vious ratings over the course of rating all stimuli.

Possible bias in experimental protocol. It is pos-

sible that our experimental protocol did favor prefer-

ence rating, as there had to be more ratings made than

for the scale ratings. One can argue that this leads to

more familiarity. It can be also argued that pairwise

preference rating is easier, because there are only two

options from which to choose. The scale ratings con-

sisted of 20 options.

Reliability of participants. In our present study

there is no redundancy in the stimuli. This makes

it impossible to assess the consistency and reliability

with which participants rate the stimuli and whether

there are differences for the rating conditions. A pos-

sible solution is given in (Kleinsmith et al., 2011),

where participants had to rate the same set of pos-

tures multiple times. In addition, this would lead to

increasing familiarity over time, thus addressing the

possible bias in the experimental protocol.

PhyCS2014-InternationalConferenceonPhysiologicalComputingSystems

244

6 CONCLUSIONS

We investigated differences between ratings of af-

fective stimuli expressed through preferences and

through scales. Our aim is to ﬁnd appropriate

schemes for rating affective stimuli in order to better

deﬁne ground truth labels for the training and testing

of automatic affect recognition systems.

Based on a corpus of abstract body postures, we

ﬁnd that while there is a strong correlation between

preference and scale ratings, there are also frequent

mismatches. We discuss reasons as indicated by our

ﬁndings, as well as other potential causes. We plan to

address these in future work. As we ﬁnd that different

rating conditions work better for different affect la-

bels, we believe it is worthwhile to investigate rating

schemes that make use of scales as well as preference

ratings. Preference rating quickly requires large num-

bers of ratings to be made. We believe that data min-

ing techniques can be helpful here. When a stimulus-

label combination is rated with a high-consistency

from a low number of raters it can be retired, leaving

more capacity of further raters to more disputed cases.

Ultimately, we envisage a protocol to assist assessors

to achieve higher levels of consistency and agreement

rates when rating affective stimuli for ground truth la-

beling.

REFERENCES

Afzal, S. and Robinson, P. (2009). Natural affect data: Col-

lection and annotation in a learning context. In Affec-

tive Computing and Intelligent Interaction and Work-

shops, 2009. ACII 2009. 3rd International Conference

on, pages 1–7.

Doyle, J. (2004). Prospects for preferences. Computational

Intelligence, 20(2):111–136.

urnkranz, J. and H

ullermeier, E. (2005). Preference learn-

ing. K

unstliche Intelligenz, 19(1):60–61.

Kapoor, A., Burleson, W., and Picard, R. W. (2007). Auto-

matic prediction of frustration. Int. J. Hum.-Comput.

Stud., 65(8):724–736.

Kleinsmith, A. and Bianchi-Berthouze, N. (2013). Affec-

tive body expression perception and recognition: A

survey. Affective Computing, IEEE Transactions on,

4(1):15–33.

Kleinsmith, A., Bianchi-Berthouze, N., and Steed, A.

(2011). Automatic recognition of non-acted affective

postures. Trans. Sys. Man Cyber. Part B, 41(4):1027–

1038.

Kleinsmith, A., De Silva, P. R., and Bianchi-Berthouze,

N. (2006). Cross-cultural differences in recogniz-

ing affect from body posture. Interact. Comput.,

18(6):1371–1389.

Liscombe, J., Venditti, J., and Hirschberg, J. (2003). Classi-

fying subject ratings of emotional speech using acous-

tic features. In Proceedings of Interspeech’2003 - Eu-

rospeech.

Russell, J. A. (1994). Is there universal recognition of emo-

tion from facial expression? a review of the cross-

cultural studies. Psychological Bulletin, 115:102–141.

Savva, N. and Bianchi-Berthouze, N. (2012). Auto-

matic recognition of affective body movement in a

video game scenario. In Camurri, A. and Costa,

C., editors, Intelligent Technologies for Interactive

Entertainment, volume 78 of Lecture Notes of the

Institute for Computer Sciences, Social Informatics

and Telecommunications Engineering, pages 149–

159. Springer Berlin Heidelberg.

Yannakakis, G. (2009). Preference learning for affective

modeling. In Affective Computing and Intelligent In-

teraction and Workshops, 2009. ACII 2009. 3rd Inter-

national Conference on, pages 1–6.

Yannakakis, G. and Hallam, J. (2011). Ranking vs. pref-

erence: A comparative study of self-reporting. In

D’Mello, S., Graesser, A., Schuller, B., and Martin,

J.-C., editors, Affective Computing and Intelligent In-

teraction, volume 6974 of Lecture Notes in Computer

Science, pages 437–446. Springer Berlin Heidelberg.

Yannakakis, G. N. and Hallam, J. (2007). Towards opti-

mizing entertainment in computer games. Appl. Artif.

Intell., 21(10):933–971.

Zeng, Z., Pantic, M., Roisman, G., and Huang, T. (2009).

A survey of affect recognition methods: Audio, vi-

sual, and spontaneous expressions. Pattern Analy-

sis and Machine Intelligence, IEEE Transactions on,

31(1):39–58.

HumanRatingofEmotionalExpressions-Scalesvs.Preferences

245
