Semantic Anonymisation of Set-valued Data

Montserrat Batet, Arnau Erola, David Sánchez and Jordi Castellà-Roca

UNESCO Chair in Data Privacy, Departament d’Enginyeria Informàtica i Matemàtiques, Universitat Rovira i Virgili,

Av. Països Catalans, 26, 43007, Tarragona, Catalonia, Spain

Keywords: Data Semantics, Set-valued Data, Privacy, Microaggregation, Knowledge Bases.

Abstract: It is quite common that companies and organisations require of releasing and exchanging information

related to individuals. Due to the usual sensitive nature of these data, appropriate measures should be

applied to reduce the risk of re-identification of individuals while keeping as much data utility as possible.

Many anonymisation mechanisms have been developed up to present, even though most of them focus on

structured/relational databases containing numerical or categorical data. However, the anonymisation of

transactional data, also known as set-valued data, has received much less attention. The management and

transformation of these data presents additional challenges due to their variable cardinality and their usually

textual and unbounded nature. Current approaches focusing on set-valued data are based on the

generalisation of original values; however, this suffers from a high information loss derived from the

reduced granularity of the output values. To tackle this problem, in this paper we adapt a well-known

microaggregation anonymisation mechanism so that it can be applied to textual set-valued data. Moreover,

since the utility of textual data is closely related to their meaning, special care has been put in preserving

data semantics. To do so, appropriate semantic similarity and aggregation functions are proposed.

Experiments conducted on a real set-valued data set show that our proposal better preserves data utility in

comparison with non-semantic approaches.

1 INTRODUCTION

It is quite usual to find databases in which records

contain variable-length multi-valued attributes

describing an individual,

such as lists of

commodities bought by a customer (Terrovitis et al.,

2008), query logs performed by a user of a Web

search engine (He and Naughton, 2009), or

outcomes of a clinical record (He et al., 2008). Data

sets with these characteristics are usually referred as

set-valued data (Terrovitis et al., 2008). Due to their

sensitive nature, the publication of this kind of data

may compromise individuals’ privacy, especially

when adversaries have partial knowledge of

individuals’ actions.

To minimise the disclosure risk of published

data, anonymisation/masking methods have been

proposed (Domingo-Ferrer, 2008). These methods

perform transformations over potentially identifying

values thus reducing their level of specificity and/or

creating groups of indistinguishable individuals.

These transformations distort input data, making it

less specific or detailed. Since the utility of

anonymised data is closely related to the amount of

information loss caused by the transformation,

anonymisation methods should balance the trade-off

between information loss and disclosure risk

(Domingo-Ferrer, 2008).

Within the Statistical Disclosure Control (SDC)

community, authors have proposed many techniques

to anonymise structured/relational databases,

consisting of records with several univalued

attributes, each one corresponding to a different

feature of the described entity (Domingo-Ferrer,

2008; Herranz et al., 2010; Jing et al., 2011;

Martínez et al., 2012b; Matatov et al., 2010). In

these methods, identifying attributes are removed,

and quasi-identifier attributes (groups of attributes

that result in unique combinations of values) are

anonymised. Thus, the anonymisation process can

manage attribute values individually. Anonymisation

of quasi-identifiers is usually done with

microaggregation methods, which ensures that the

masked database fulfils the k-anonymity property

(Samarati and Sweeney, 1998; Sweeney, 2002)

while achieving some compromise between data

102

Batet M., Erola A., Sánchez D. and Castellà-Roca J..

Semantic Anonymisation of Set-valued Data.

DOI: 10.5220/0004811901020112

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 102-112

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

utility and disclosure risk (Domingo-Ferrer, 2008;

Herranz et al., 2010).

However, the application of these methods to set-

valued data faces additional problems. Unlike

relational databases, set-valued data sets do not

constitute well-defined sets of quasi-identifying

attributes, because several subsets of values of an

attribute could play the role of quasi-identifiers.

Moreover, the set of values of each individual may

have variable length and high dimensionality,

compared to the relatively few attributes and values

of relational records. Moreover, while attributes in

relational databases are commonly either numerical

or categorical, set-valued data sets are usually free

text (e.g. query logs or other transactional data). The

management of textual values add new challenges

that are not considered by methods focused on

numerical or categorical data.

In contrast to numerical data, which can be

compared and transformed by means of

mathematical operators, textual data require from

comparison and aggregation operators that consider

the meaning of words since, as acknowledged by

several authors (Martínez et al., 2012b; Torra, 2011),

the utility of textual data is closely related to the

preservation of their semantics. Since semantics are

an inherently human feature, the interpretation of

textual data requires the exploitation of some sort of

human-tailored machine-readable knowledge source,

such as taxonomies, folksonomies and ontologies

(Guarino, 1998). This allows mapping words to their

conceptual abstractions, analysing the latter

according to the semantic interrelations modelled in

the knowledge source.

Considering the above challenges, specific

anonymisation methods should be designed for

textual set-valued data (Terrovitis et al., 2008). As it

will be discussed in section 2, existing approaches

on the anonymisation of set-valued data are based on

generalising original values according to a

hierarchical structure, so that the masked data set

fulfils the k-anonymity property (He and Naughton,

2009; Terrovitis et al., 2008). These methods

implicitly consider data semantics. However, they

are affected by the large information loss resulting

from the need of generalising concepts to a common

abstraction, which causes a loss of granularity, and

is seriously hampered by the presence of outlying

values.

In order to not incur in such a high loss of

granularity, in this paper we present an

anonymisation method based on microaggregation

(an approach originally designed for uni-valued

attributes from relational databases), which can be

applied to set-valued data in a natural way to

preserve data semantics as much as possible. To do

so, we propose a set of semantic operators to

compare, sort and aggregate set-valued data from a

semantic perspective, by using ontologies as the

knowledge bases that guide the anonymisation

process. The proposed method has been evaluated

using a real set-valued data set consisting of search

queries extracted from the AOL files and a widely

used knowledge base.

The rest of the paper is organised as follows.

Section 2 surveys and reviews anonymisation

methods and approaches focusing on set-valued

data. Section 3 introduces the basis of data

anonymisation via microaggregation and details its

adaptation to the anonymisation of set-valued data

from a semantic perspective. Section 4 details the

evaluation of our approach with regards to the

preservation of data semantics. The final section

contains the conclusions and depicts some lines of

future research.

2 RELATED WORK

Anonymisation methods can be classified as

perturbative and non-perturbative (Hundepool et al.,

2012). The former distort original data while the

latter reduce data detail or suppress them partially to

fulfil the privacy criterion.

Microaggregation is a perturbative method that

was originally defined for numerical data (Defays

and Nanopoulos, 1993; Domingo-Ferrer and Mateo-

Sanz, 2002). By using this approach, records are

grouped and replaced by a prototypical record, so

that they become indistinguishable, from at least, k-1

other records, thereby achieving the k-anonymity

property (Samarati, 2001; Sweeney, 2002). There

have been some attempts to extend

microaggregation so as to be used with nominal

attributes. However, most of them ignore data

semantics. This is a drawback because, as mentioned

by several authors (Martínez et al., 2012b; Torra,

2011), the lack of a semantically-coherent analysis

compromises the utility of the anonymised results.

In (Torra, 2004), only ordinal categorical

attributes are addressed and the median is proposed

as aggregation operator. In (Domingo-Ferrer and

Torra, 2005), the equality/inequality predicate is

used to compare nominal attributes and the modal

value is proposed as an aggregation operator.

Non-perturbative methods based on attribute

value generalisations implicitly consider data

semantics (Li and Li, 2008; Samarati, 2001;

SemanticAnonymisationofSet-valuedData

103

Sweeney, 2002). These methods substitute attribute

values by more general ones obtained from a

hierarchical structure so that they also become

indistinguishable (i.e. k-anonymous). The

generalisations used to perform this substitution are

selected in order to minimise the amount of

information loss. These methods depend on the

suitability of the hierarchical structure with regard to

the input data and the granularity and level of detail

of the taxonomy to minimise the loss of information

resulting from value generalisations. For that reason,

ad-hoc hierarchical structures, named Value

Generalisation Hierarchies (VGH), are usually

defined for the input data set. However, VGHs offer

rough and overspecified knowledge sources in

comparison with fine-grained and general or domain

ontologies (Martínez et al., 2012b) and can be hardly

defined for dynamic and unbounded domains such

as query logs.

To the best of our knowledge, existing works on

anonymisation of set-valued data follow the non-

perturbative model based on value generalisations.

In (Terrovitis et al., 2008) the authors anonymise

textual set-valued data by proposing generalisations

of input values according to ad hoc constructed

VGHs, which iteratively generalise input values up

to a common node until they become k-anonymous.

He and Naughton (He and Naughton, 2009) adapted

the previous method by starting from the most

abstract generalisation and by specialising it

progressively. The algorithm starts by generalising

all items to the root of the hierarchy. Then, the

algorithm recursively splits the current partition into

sub-partitions until no further split is possible

without violating k-anonymity.

Although non-perturbative methods based on

generalisations take data semantics into account,

they are affected by the large information loss

resulting from concept generalisation, which

necessarily cause loss of granularity. This is

especially evident for heterogeneous data in which

the need to generalise outliers results in abstract

concepts (e.g. the root node of the ontology) and

high information loss (Martínez et al., 2012c). On

the contrary, perturbative methods based on

microaggregation do not incur in a loss of

granularity but scarcely consider data semantics.

To gain the benefits of both approaches and

minimise their shortcomings, in this work, we

propose an anonymisation method based on

microaggregation, which can be applied to set-

valued data sets while also considering the semantics

of textual values by relying on available

taxonomies/ontologies.

3 SEMANTIC PRESERVING

ANONYMISATION OF

SET-VALUED DATA

Microaggregation perturbs input data to generate k-

anonymous data sets. To that end, input records,

which are considered as standard records of

relational databases, are clustered into groups of, at

least, size k (data partition) and replaced by the

cluster centroid (data anonymisation). In this

manner, each record becomes indistinguishable

from, at least, k-1 other ones. To maximise the

utility of anonymised data, similar records should be

clustered together, so that the information loss

resulting from the replacement by their centroid can

be minimised.

Since optimal microaggregation is NP-hard

(Oganian and Domingo-Ferrer, 2001), several

heuristic algorithms have been proposed in the past.

One of the most popular is the MDAV (Maximum

Distance Average Vector) method (Domingo-Ferrer

and Mateo-Sanz, 2002), which was specifically

designed to minimise the information loss

(Domingo-Ferrer et al., 2006; Martínez et al.,

2012a). Consequently, we take the MDAV

algorithm as the base to design our anonymisation

method.

Algorithmically, MDAV performs the data

partition by calculating the centroid of the whole

data set and selecting the most distant record to it.

Then, a cluster is constructed with the k-1 least

distant records. After that, the most distant record to

the already clustered one is selected and a new

cluster is constructed. The process is repeated until

less than 2k records remain ungrouped. The rest of

records are grouped together in a last cluster. As a

result, all clusters will have k records, except for the

last one, which may have from k to 2k-1 records.

Data anonymisation is performed by replacing each

record of each cluster by the centroid of the cluster.

Figure 1 summarised this anonymisation process.

The m records to be anonymised are partitioned in

clusters of size k by the MDAV algorithm. Then, in

the data anonymisation stage, records are replaced

by the centroid of the cluster to which they belong,

thus obtaining a k-anonymous data set.

In the following section we present an adaptation

of the MDAV microaggregation algorithm to

support the anonymisation of textual set-valued data

that puts special efforts in preserving the semantics

of input data.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

104

3.1 Set-valued Data Partition

To produce a k-anonymous partition of input data,

MDAV relies on two basic functions that depend on

the type of data to be processed: a comparison

operator that measures the distance between records

to add new ones in a cluster, and an averaging

function to calculate the centroid used to guide the

clustering process.

MDAV have been originally designed to deal

with numerical data and structured databases with

uni-valued attributes. Due to the characteristics of

set-valued data and textual data, the adaptation of

MDAV to this kind of data is not trivial. Contrary to

numerical data that can be compared, averaged and

transformed by means of mathematical functions,

textual data require from operators that take their

semantics into account (Martínez et al., 2012a).

Moreover, as set-valued data have variable length,

the coherent comparison/aggregation of records with

different cardinalities is also challenging.

In this section, we propose a semantically-

grounded comparison measure and we describe a set

of averaging operators suitable for data with variable

length.

3.1.1 Comparing Set-valued Data

To enable a semantic interpretation of textual values

of items in the set, we first need to map them with

their formal semantics. Since textual data may refer

to one (e.g. a term, such as “iPhone”) or several

concepts (e.g. a list of terms, such as “AC charger

for an iPhone”), we first apply several morpho-

syntactic analyses to the input data: sentence

detection, tokenisation, part-of-speech (POS)

tagging and syntactic parsing). As a result, noun

phrases, which are the textual units which carry most

of the semantics of the discourse are detected (e.g.

AC charger, iPhone). Each noun phrase would refer

to an individual concept (Sánchez et al., 2013).

Thus, we map each noun phrase to a conceptual

abstraction (e.g. iPhone -> Smartphone) by

matching noun phrases and concept labels modelled

in a knowledge base, such as an ontology. Notice

that the core semantics of a noun phrase are carried

by the noun most on the right, which can be

qualified or specialised by adding new nous our

adjectives to the left. Thus, in such cases in which

the noun phrase is not found in the knowledge base

we iteratively discard the words most on the left of

the noun phrase until the result is found in the

ontology (e.g. a new iPhone -> new iPhone ->

iPhone).

Figure 1: Semantic anonymisation process.

Formally, let X={x

,…,x

} be the set of m

records represented by a unique multi-valued

attribute (see figure 1), and let x

={q

,...,q

} be the

items contained in the set-valued attribute of the

record x

. As a result of the conceptual mapping,

each record is represented by a set of concepts C

,…,c

} (e.g. C

={iPhone, AC charger }),

where each concept is taxonomically modelled in an

ontology (e.g. T(c

)= iPhone -> Smartphone ->

Handhelds -> Systems -> Computers). This

knowledge represents the basis that will enable a

semantically-coherent comparison between records.

First, we propose a measure that computes the

semantic distance between concepts by exploiting

the knowledge modelled in their taxonomical trees.

Several semantic measures can be found in the area

of computational linguistics to estimate the distance

between concepts modelled in a taxonomy. Notice

that the availability of large and fine grained

ontologies with a good coverage of analysed

concepts will certainly improve the similarity

accuracy. The most basic similarity measures

compute the length of the path that connects two

concepts through their taxonomical

specialisations/generalisations (Wu and Palmer,

1994). However, due to their simplicity, they omit

much of the taxonomical knowledge explicitly

modelled in the knowledge base, thus achieving a

relatively low accuracy (Sánchez et al., 2012). More

recent works (Batet et al., 2011; Sánchez et al.,

2012) significantly improve these basic methods by

evaluating all the taxonomical ancestors of the

SemanticAnonymisationofSet-valuedData

105

compared terms: they measure the distance between

concepts as a function of the amount of their shared

and non-shared taxonomical generalisations. These

methods consider more information than path-based

distances, which uses the path as an assessor of

distance but that does not give clues on potential

similarities of the compared concepts (given, for

example, by their number of shared ancestors). In

this work, we follow the same principles.

Given a pair of concepts c

, c

, we evaluate their

distance δ

, c

) according to the amount of non-

shared taxonomical generalisations in an ontology

O. Moreover, we can also presume that concept

pairs that have many generalisations in common are

less distant than those sharing a small amount of

generalisations. Hence, the semantic distance is

computed as the ratio between the amount of non-

shared concepts and the sum of shared and non-

shared concepts (1):

12 12

()

() () () ()

Tc Tc Tc Tc

T(c ) T(c )









(1)

Where T(c

)={c



O | c

generalises c

}  { c

}

represents the taxonomic generalisations of the

concept c

in the ontology O, including c

. Notice

that, by including the compared concepts in T, we

are able to distinguish different concepts that have

all their generalisations in common from two

identical concepts.



However, since data partition for

microaggregation-based anonymisation of set-valued

data requires comparing sets of concepts (instead of

individual pairs), the above measure has to be

extended. To do so, it is necessary to integrate

distance values between sets of different

cardinalities in a coherent manner. This can be done

by means of aggregation functions, which, for

example, are widely used in the area of

bioinformatics to compare the functional similarity

between gene products. In (Lord et al., 2003),

authors used the average of all pairwise similarities;

in (Sevilla et al., 2005), authors used the maximum

of the pairwise similarity; in (Couto et al., 2007;

Schlicker et al., 2006), authors used the composite

average, where each term of the first set is paired

only with the most similar term of the second set and

vice-versa. In this paper, we will consider the

following ones:

 Minimum: all concepts of x

are compared

with all concepts of x

, taking the minimum

distance value as the result of this comparison

(2):

() ()),(,

ix jx

Min x x s i j

cC c C

D CC MinMin cc



  



(2)

 Maximum: provides the maximum distance

value between all concept pairs (3):

() ()),(,

ix jx

Max x x s i j

cC c C

D CC MaxMax cc



  



(3)

 Average: computes the average distance

between all concepts of x

and all concepts of

(4):

||| |

()

|| |

sAvg x x











(4)

 Normalised sum of minimum: given a concept

of x

, we compare it against all concepts of

, taking the minimum distance value as the

result of this comparison. This states the

highest evidence of similarity between records

with respect to the feature c

|| | |

|| ||

,,)

|| |

(( )) (( )

()

sij sij

sMinSum x x

in c c Min c c











(5)

By repeating the process and adding the

distance value between each c

of x

against

, we obtain the aggregated distance from x

to x

. Note that this distance may be different

when evaluating it from x

to x

. Hence, the

final distance between x

and x

will be the

sum between the distances computed from x

to x

and from x

to x

. Finally, since different

records can be compared regardless of the

cardinality of their sets of items, we divide it

by the number of concepts of both records

(|C

| and |C

|) in order to obtain normalised

distance values between sets of items.

As an example, let us suppose that given two

records, x

and x

, we have obtained the

following concepts from their set of values

using an ontology:

C ={”Swimming” , “Mediterranean”},

C ={ “Windsurfing”, “Mediterranean”}.

And that their generalisations are the

following:

T(“Swimming”)= {“Sports”, “Water Sports”,

“Swimming” }

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

106

T(“Windsurfing”)={“Sports”, “Water

Sports”, “Windsurfing”}

T(“Mediterranean”)={“Regional”, “Europe”,

“Regions”, “Mediterranean”}

Hence, the distance between records is

computed as

sMinSum

(

) =

(((1×0.5)+(1×0)+(1×0.5)+(1×0))/(2+2)) = 0.25.

Notice that, for example, the semantic

distance between c

= “Swimming” and

=”Windsurfing” (eq. 1) is computed as

)=((4-2)/4)=0.5.

 Normalised sum of maximum: the same as

above but taking the maximum distance value

instead of the minimum. This states the

highest evidence of dissimilarity between

records with respect to the feature c

|| | |

|| ||

,,)

|| |

(( )) (( )

()

si j si j

sMaxSum x x

ax c c Max c c











(6)

In the next section, we generically refer to these

aggregation distances (eq. 2 to 6) as Ds(C

, C

3.1.2 Record Aggregation

As stated at the beginning of the section, MDAV

creates clusters by picking up the most distant record

to the data set centroid. Moreover, centroids are also

used at the data anonymisation stage since cluster

elements are replaced by cluster centroids to become

k-anonymous (see figure 1).

Numerically, the centroid of a group/data set is

understood as the value (or the set of values in our

case) that minimises the distance against all records

in the data set. When dealing with continuous-scale

numerical data, the centroid can be accurately

computed by averaging numerical values. However,

for textual data, the centroid must necessarily be

discretised. In this case, some authors (Domingo-

Ferrer and Torra, 2005) select the centroid of

textual/categorical data sets by picking up those who

appear the most (i.e. the mode). However, this

approximation omits the semantics of data.

Given the aggregated distances presented above

(eq. 2 to 6), we use them to discover the data

set/cluster centroid, which is selected as the record

that minimises the sum of distances to all other

records in a given data set or cluster:

 

mxri

xx C sxx

centroid C ,...,C arg min D C ,C















(7)

Where {C

,…,C

} corresponds to the set of

concepts that represent the set-valued attribute of the

records in the data set/cluster to evaluate, and

Ds(C

, C

) is the same aggregated distance as the

one used in the comparison of two sets of values (eq.

2 to 6).

3.2 Anonymising Set-valued Data

By using the above-proposed distance and centroid

calculus on the MDAV algorithm, records will be

grouped into d=m/k clusters of, at least, k records

(see figure 1). To fulfil the k-anonymity property,

the last step requires replacing all records of each

cluster by a representative, which usually

corresponds to the centroid of the cluster. Since this

centroid minimises the individual distances to all

records in the cluster, the information loss resulting

from this replacement will be minimised.

In a general microaggregation scenario, this

centroid corresponds exactly to the “central”

element of the cluster. However, in the textual set-

valued anonymisation context, this may lead to

undesirable consequences. Particularly, the fact that

elements in a cluster are replaced by the exact

centroid record may excessively expose her identity,

especially if an attacker has partial knowledge (e.g.

some items of her set of values are known (He and

Naughton, 2009).

To palliate this problem, in some works

(Terrovitis et al., 2008) the cluster representative is

synthetically built by replacing terms in clusters with

concepts that generalise all/some of them according

to a background taxonomy. Hence, anonymised

records would be composed by sets of concepts

rather than the original terms. This fact hampers the

utility of the anonymised records in some

environments in which original terms (instead of

their conceptual abstraction) are needed, such as

query formulation analysis (Bar-Ilan, 2007; Xiong

and Agichtein, 2007).

In this work, we have chosen an intermediate

solution that aims at retaining the semantic and

syntactical utility of records while, at the same time,

minimising the disclosure risk of the centroid record

by creating a synthetic record. On the one hand, our

cluster representative corresponds to the record that

constitutes the centroid of the cluster. Notice that

since we are working with sets of concepts

representing a record, this corresponds to the C

that

minimises the semantic distance to all other sets of

concepts (i.e. records) in the cluster, according to the

centroid calculus (see eq. 7). Next, instead of

recovering the concrete terms of the centroid record

SemanticAnonymisationofSet-valuedData

107

, we replace concepts in C

by suitable terms

picked from the original data set. Specifically, each

concept in C

is replaced by a term taken randomly

from those in the records from the whole input data

set that corresponds to that concept (e.g. if the

concept Smartphone appears in

, then, we may

retrieve suitable terms like “iPhone 3”, “Samsung

Galaxy S2” or “Nexus 4” if those are in the input

data set).

As a result of the above process, records of each

cluster are anonymised by replacing each one with a

synthetic record that semantically matches the

cluster centroid (i.e. it maintains the semantics of the

centroid) while protecting the privacy of the centroid

record (see figure 1). On the one hand, since

individual terms are picked randomly from different

records of the input data set, we minimise the chance

that cluster representatives contain exact

subsequences of terms of individual records, a

circumstance that may compromise its anonymity

(He and Naughton, 2009). On the other hand, since

selected terms match the concepts of the centroid

record, we also retain semantics accurately, as the

centroid record is the one that better represents the

semantic features of the records in the cluster and,

hence, the one that minimises the information loss

resulting from the anonymisation process. Moreover,

since concepts are randomly replaced by one of its

corresponding terms using a uniform distribution,

the distribution of individual terms found in the

input data for each concept will be likely

maintained, even though terms would not be

unequivocally associated to the original records.

Finally, since we are publishing real terms from the

input data set, anonymised data can still be useful

for tasks such as statistical analysis.

4 EVALUATION

In this section, we first introduce the measure used

to quantify the degree of semantic preservation of

the anonymised data set. Then, in section 4.2, we

describe the evaluation data set and, finally, in

section 4.3, the proposed method is evaluated from

two perspectives: (1) the suitability of a

semantically-grounded anonymisation, and (2) the

influence of the different aggregation measures used

to compute the distance between value sets.

4.1 Evaluation of Semantics

Preservation

To evaluate up to which point an anonymisation

method retains the utility of original data, that is,

preserves their semantic content, we measure the

information loss (L) between original and masked

records from a semantic perspective. To measure

information loss, we computed the well-known Sum

of Square Errors (SSE) between original and

masked records, which is the most usual measure

employed by privacy-preserving methods based on

microaggregation (Domingo-Ferrer and Mateo-Sanz,

2002; Domingo-Ferrer et al., 2006; Lin et al., 2010;

Martínez et al., 2012a; Torra and Miyamoto, 2004).

The SSE is defined as the sum of squares of attribute

distances between original records and their versions

in the anonymised data set. To measure the

aggregated set of all semantic distances that SSE

requires, we used the semantic distance D

sAvg

defined

in section 3.1.1 (see (4)). Thus, the higher the SEE

is, the higher the information loss will be. This is

due to the replacement of values and the lower

preservation of the data semantics.

Formally, given that X is the set of original

records and X

is the anonymised version, the

information loss of masked data against its non-

masked one is computed as (8):



sAvg x x

LDSSE X ,X C ,C













(8)

Notice that with a high information loss (i.e. a

high SSE), a lot of data uses are severely damaged

like, for example, subdomain analysis, that is,

analysis restricted to parts of the data set.

4.2 Evaluation Data Set

The evaluation has been performed using real set-

valued data which correspond to query logs

extracted from the AOL log files released in 2006.

From these, the query logs of 1,000 users have been

randomly taken. They contain about 56,000

individual queries. Even though personal identifiers

have been removed from published query logs,

queries themselves may enable identity disclosure

due to their specificity and personal nature (Barbaro

and Zeller, 2006). This fact together with its textual

nature, makes this data set suitable for testing our

set-valued anonymisation method.

Different k-anonymity degrees between 2 and 5

have been tested. These k-values produced between

500 and 200 clusters as a result of the aggregation

process.

As knowledge base, we use ODP (Open Directory

Project, 2010). ODP is a multilingual open content

directory of World Wide Web links. The purpose of

ODP is to list and categorise web sites. It uses an

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

108

ontology scheme to classify sites into different

subjects. ODP offers more than 1 million

taxonomically structured categories. Contrary to

other knowledge bases, ODP covers recently minted

terms and named entities, which are very usually

referred in web queries (Sánchez et al., 2013). This

helps to improve the recall of the query-category

matching process. In fact, despite the sensitivity of

named entities due to their high degree of

concreteness, they are, in essence, noun phrases that

can be associated to conceptual abstractions if they

are covered in an ontology such as ODP. In fact,

ODP has been extensively used in other works

dealing with AOL queries, such as (Sánchez et al.,

2013). Thus, no special treatment for named entities

is necessary.

4.3 Discussion

In this section, we discuss the suitability of the

semantically-grounded anonymisation of set-valued

data, and the influence of the different aggregation

measures presented in section 3.1.1.

In order to assess the improvement obtained by

considering data semantics and to put into context

the absolute information loss figures, we have also

implemented a simplified version of the semantic

aggregation distances defined in section 3.1.1, in

which no semantics are considered at all, which is

the usual scenario in related works on

microaggregation (see section 2). In this case,

neither the semantic distance between concepts



(see eq.1) nor ODP are used. The terms of the set

(i.e. queries) are treated as simple strings and

compared according to their equality/inequality

(Domingo-Ferrer and Torra, 2005). Hence, the

non-semantic distance



(see eq. 9) between

concepts c

and c

is used instead of



()

if c c













(9)

We named the non-semantic versions of the

aggregation distances as D

Min,

Max

Avg,

MinSum,

MaxSum

By analysing information loss (L) figures (see

Table 1), we observe that all aggregation measures

that do not consider the semantics of terms result in

a higher information loss than their semantic version

for all k-values. For example, the non-semantic

version of the normalised sum of minimum distance,

MinSum

, obtains L values of 817, 859, 879 and 891

for k=2, k=3, k=4 and k=5 respectively, while its

semantic version, D

sMinSum

, obtains values of 683,

733, 759, 781. This represents around a 16% of

improvement.

This is explained because, even though

terminological resemblance is an evidence of

semantic similarity, it poorly captures and evaluates

the meaning of terms. This is especially evident in

free text data in which the same terms may appear

with different morphological forms or when

synonymous words are used. Moreover, most terms

in the data set are unique, so that, few evidences of

similarity can be gathered to guide the partition and

aggregation process.

Our approach exploits ODP to retrieve categories

to which queries refer. Since ODP categories are

conceptualisations of textual queries, they enable a

semantically-coherent partition and aggregation of

query logs. Hence, the obtained improvement is the

result of considering the semantics of terms during

the comparison between queries, the centroid

selection, the cluster construction and the

anonymisation stages. Note also that the morpho-

syntactic analyses applied to identify noun phrases

(see section 3.1.1) and to map them to ontological

concepts (i.e. categories in ODP) also contribute to

improve the conceptual mapping recall and to

provide a better interpretation of data semantics.

Table 1: Information loss (L) of the evaluated aggregation

functions for different levels of k-anonymity with and

without considering the data semantics.

Aggregation

distance

k=2 k=3 k=4 k=5

sMin

699 759 783 799

Min

825 863 883 895

sMax

724 778 806 820

Max

824 860

884

895

sAv

639 692 724 745

Avg

768 804

829

845

sMinSu

683 733 759 781

MinSu

817 859 879

891

sMaxSu

716 780 819 838

MaxSu

822 858

884

893

Even though semantics of anonymised data are

better retained (i.e. information loss of anonymised

data is minimised), the fact that the aggregation is

made by randomly rearranging terms referring to the

same concepts of different records for the concepts

corresponding to the centroid record, contributes in

reducing the chance that cluster representatives

contain exact subsequences of terms of individual

records, while preserving the distribution of the

terms in the original data.

On the other hand, different information loss

figures are obtained according to the semantic

SemanticAnonymisationofSet-valuedData

109

aggregation distance. The worst results are obtained

by D

sMax

and D

sMaxSum

. The problem of these

aggregation distances is that they return the

maximum dissimilarity between two sets of values.

This goes against the notion of cluster cohesion

(which is what SSE measures) when arranging

records in clusters, and makes the process very

sensitive to the presence of outlying values.

By contrast D

sMin

and D

sMinSum

distances state the

highest evidence of similarity between records, and

thereby, provide notably better results. However,

sMin

is unable to assess the global distance between

two sets of values because it detects if two sets share

a value, but it is indifferent to the number of

unrelated terms and to what extend they are

different. This problem is clearly overcome by the

sMinSum

distance, which also considers the distance

between unrelated terms because, for each term of a

set, it takes into account the most similar term in the

other set.

The best results are however obtained by D

sAvg

because it accounts for similar and dissimilar terms.

This fact benefits data sets such as query logs with a

heterogeneous and unbounded nature. However, it

may not be the best option for data sets composed by

records with several shared or similar terms, such as

the measurement of the functional similarity

between gene products (Pesquita et al., 2009),

because similarity can be distorted by few different

terms. In that case, D

sMinSum

would likely obtain

better results.

5 CONCLUSIONS

This paper presents an anonymisation method for

set-valued data based on semantic microaggregation.

While most of the research on privacy protection of

set-valued data focuses on term generalisation,

which produce a high information loss due to the

loss of granularity of output values, our method has

been especially designed to preserve the data

semantics and, consequently, to improve data utility.

To achieve this goal, textual data are

semantically interpreted by extracting their

conceptualisations from an ontology. This enables to

aggregate set-valued data from a semantic

perspective by means of an adaptation of the MDAV

algorithm. Moreover, suitable semantic operators to

compare and average set-valued data have been

proposed for that purpose. Finally, synthetic records

that semantically match the cluster centroids are

generated by randomly picking values from different

records of the input data set. These records preserve

the meaning of the record that better represents the

semantics of the elements in the cluster.

The evaluation, carried out with a set of real

query logs extracted from the AOL data set and a

publicly available knowledge base (ODP), sustains

the practical suitability of our method.

As future work, we plan to test the behaviour of

the proposed method in other domains in which

textual transactional data are available (such as

electronic health-care records), exploiting domain-

specific knowledge bases (such as biomedical

terminologies like SNOMED-CT (Spackman,

2004)). Within scenarios with more restricted set-

valued data (e.g. lists of diseases) which can be

properly covered by available knowledge bases, we

plan to compare our method against non-

perturbative methods that extensively rely on those

knowledge bases to propose generalisations.

Moreover, we plan to combine multiple ontologies

in order to improve the recall of the conceptual

mapping of textual terms (Batet et al., 2013).

Finally, we plan to use application-oriented metrics

to measure the utility of the protected data in

specific tasks, such as query-log based profiling or

query refinement accuracy.

ACKNOWLEDGEMENTS

This work was partly supported by the European

Commission under FP7 project Inter-Trust, by the

Spanish Ministry of Science and Innovation

(through projects eAEGIS TSI2007-65406-C03-01,

ICWT TIN2012-32757, CO-PRIVACY TIN2011-

27076-C03-01, ARES-CONSOLIDER INGENIO

2010 CSD2007-00004, Audit Transparency Voting

Process IPT-430000-2010-31 and BallotNext IPT-

2012-0603-430000), by the Spanish Ministry of

Industry, Commerce and Tourism (through projects

eVerification2 TSI-020100-2011-39 and SeCloud

TSI-020302-2010-153) and by the Government of

Catalonia (under grant 2009 SGR 1135). The

authors are with the UNESCO Chair in Data

Privacy, but they are solely responsible for the views

expressed in this paper, which do not necessarily

reflect the position of UNESCO nor commit that

organisation.

REFERENCES

Bar-Ilan, J. (2007). Access to query logs - an academic

researcher’s point of view. Proc. of the Proceedings of

the Query Log Analysis: Social and Technological

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

110

Challenges Workshop at the 16th World Wide Web

Conference, WWW2007). Banff, Alberta, Canada.

Barbaro, M., & Zeller, T. (2006). A Face Is Exposed for

AOL Searcher No. 4417749. The New York Times.

Batet, M., Sánchez, D., & Valls, A. (2011). An ontology-

based measure to compute semantic similarity in

biomedicine. Journal of Biomedical Informatics, 44,

118-125.

Batet, M., Sánchez, D., Valls, A., & Gibert, K. (2013).

Semantic similarity estimation from multiple

ontologies. Applied Intelligence, 38(1), 29-44.

Couto, F. M., Silva, M. J., & Coutinho, P. M. (2007).

Measuring semantic similarity between Gene

Ontology terms. Data & Knowledge Engineering,

61(1), 137-152.

Defays, D., & Nanopoulos, P. (1993). Panels of

enterprises and confidentiality: the small aggregates

method. Proc. of the 92 Symposium On Design and

Analysis of Longitudinal Surveys (pp. 195-204).

Otawwa, Canada.

Domingo-Ferrer, J., & Mateo-Sanz, J. M. (2002). Practical

data-oriented microaggregation for statistical

disclosure control. IEEE Transactions on Knowledge

and Data Engineering, 14(1), 189–201.

Domingo-Ferrer, J., & Torra, V. (2005). Ordinal,

Continuous and Heterogeneous k-Anonymity Through

Microaggregation. Data Mining and Knowledge

Discovery, 11(2), 195-212.

Domingo-Ferrer, J., Martínez-Ballesté, A., Mateo-Sanz, J.

M., & Sebé, F. (2006). Efficient multivariate data-

oriented microaggregation. The VLDB Journal, 15(4),

355-369.

Domingo-Ferrer, J. (2008). A Survey of inference control

methods for privacy preserving data mining Privacy

preserving data mining: models and algorithms (Vol.

55-80).

Guarino, N. (1998). Formal Ontology in Information

Systems. In N. Guarino (Ed.), Proc. of the 1st

International Conference on Formal Ontology in

Information Systems, FOIS-98 (pp. 3-15). Trento,

Italy.

He, Y., & Naughton, J. F. (2009). Anonymization of

SetValued Data via TopDown, Local Generalization.

Proc. of the Thirtieth international conference on very

large data bases (VLDB'09) (pp. 934-945). Lyon,

France.

He, Z., Xu, X., & Deng, S. (2008). k-ANMI: A mutual

information based clustering algorithm for categorical

data. Information Fusion, 9(2), 223-233.

Herranz, J., Matwin, S., Nin, J., & Torra, V. (2010).

Classifying data from protected statistical datasets.

Computers & Security, 29(8), 875-890.

Hundepool, A., Domingo-Ferrer, J., Franconi, L.,

Giessing, S., Nordholt, E. S., Spicer, K., & Wolf, P.-P.

d. (2012). Statistical Disclosure Control: Wiley.

Jing, X., Zhang, N., & Das, G. (2011). ASAP: Eliminating

algorithm-based disclosure in privacy-preserving data

publishing. Information Systems, 36(5), 859-880.

Li, T., & Li, N. (2008). Towards optimal k-

anonymization. Data & Knowledge Engineering,

65(1), 22-39.

Lin, J. L., Wen, T. H., Hsieh, J. C., & Chang, P. C. (2010).

Density-based microaggregation for statistical

disclosure contro. Expert Systems with Applications,

37, 3256-3263.

Lord, P., Stevens, R., Brass, A., & Goble, C. (2003).

Investigating semantic similarity measures across the

Gene Ontology: the relationship between sequence and

annotation. Bioinformatics, 19(10), 1275-1283.

Martínez, S., Sánchez, D., & Valls, A. (2012a). Semantic

adaptive microaggregation of categorical microdata.

Computers & Security, 31(5), 653-672.

Martínez, S., Sánchez, D., Valls, A., & Batet, M. (2012b).

Privacy protection of textual attributes through a

semantic-based masking method. Information Fusion,

13(4), 304-314.

Martínez, S., Valls, A., & Sánchez, D. (2012c).

Semantically-grounded construction of centroids for

datasets with textual attributes. Knowledge based

systems., 35, 160-172.

Matatov, N., Rokach, L., & Maimon, O. (2010). Privacy-

preserving data mining: A feature set partitioning

approach. Information Sciences, 180(14), 2696–2720.

Oganian, A., & Domingo-Ferrer, J. (2001). On the

complexity of optimal microaggregation for statistical

disclosure control. Statistical Journal of the United

Nations Economic Commision for Europe, 18, 345-

353.

Open Directory Project (2010). http://www.dmoz.org,

Pesquita, C., Faria, D., Falcão, A. O., Lord, P., & Couto,

F. M. (2009). Semantic Similarity in Biomedical

Ontologies. PLoS Computational Biology, 5(7), 1-12.

Samarati, P., & Sweeney, L. (1998). Protecting privacy

when disclosing information: k-anonymity and its

enforcement through generalization and suppression.

Proc. of the Proceedings of the IEEE Symposium on

Research in Security and Privacy, S&P). Oakland,

CA.

Samarati, P. (2001). Protecting respondents' identities in

microdata release. IEEE Transactions on Knowledge

and Data Engineering, 13(6), 1010-1027.

Sánchez, D., Batet, M., Isern, D., & Valls, A. (2012).

Ontology-based semantic similarity: a new feature-

based approach. Expert Systems With Applications, 39,

7718-7728.

Sánchez, D., Castellà-Roca, J., & Viejo, A. (2013).

Knowledge-Based Scheme to Create Privacy-

Preserving but Semantically-Related Queries for Web

Search Engines. Information Sciences, 218, 17-30.

Schlicker, A., Domingues, F. S., Rahnenführer, J., &

Lengauer, T. (2006). A new measure for functional

similarity of gene products based on Gene Ontology.

BMC Bioinformatics, 7(3002).

Sevilla, J. L., Segura, V., Podhorski, A., Guruceaga, E.,

Mato, J. M., Martinez-Cruz, L. A., Corrales, F. J., &

Rubio, A. (2005). Correlation between gene

expression and GO semantic similarity. IEEE/ACM

Transactions on Computational Biology and

Bioinformatics, 2(4), 330-338.

SemanticAnonymisationofSet-valuedData

111

Spackman, K. A. (2004). SNOMED CT milestones:

endorsements are added to already-impressive

standards credentials. Healthcare Informatics, 21(9),

54-56.

Sweeney, L. (2002). k-anonymity: a model for protecting

privacy. International Journal of Uncertainty,

Fuzziness and Knowledge Based Systems, 10(5), 557-

570.

Terrovitis, M., Mamoulis, N., & Kalnis, P. (2008).

Privacy-preserving anonymization of set-valued data.

Proceedings of the VLDB Endowment, PVLDB, 1,

115-125.

Torra, V. (2004). Microaggregation for Categorical

Variables: A Median Based Approach. Proc. of the

Privacy in Statistical Databases (PSD 2004) (pp. 162-

174).

Torra, V., & Miyamoto, S. (2004). Evaluating Fuzzy

Clustering Algorithms for Microdata Protection. In J.

Domingo-Ferrer & V. Torra (Eds.), Privacy in

Statistical Databases (pp. 519-519).

Torra, V. (2011). Towards knowledge intensive data

privacy Proceedings of the 5th international workshop

on data privacy management, and 3rd international

workshop on autonomous spontaneous security,

DMP'10/SETOP'10. (Vol. LNCS 6514, pp. 1-7).

Athens, Greece: Springer-Verlag.

Wu, Z., & Palmer, M. (1994). Verb semantics and lexical

selection. Proc. of the 32nd annual Meeting of the

Association for Computational Linguistics (pp. 133-

138). Las Cruces, New Mexico.

Xiong, L., & Agichtein, E. (2007). Towards privacy-

preserving query log publishing. Proc. of the

Proceedings of the Query Log Analysis: Social and

Technological Challenges Workshop at the 16th

World Wide Web Conference, WWW2007). Banff,

Alberta, Canada.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

112
