A Comparison of Approaches for Person Re-identification

Maria De Marsico

, Riccardo Distasi

, Stefano Ricciardi

, Daniel Riccio

Dipartimento di Informatica, Sapienza Università di Roma, Rome, Italy

Dipartimento di Studi e Ricerche Aziendali, Università di Salerno, Fisciano, Italy

Dipartimento di Ingegneria e Tecnologia dell’Informazione, Università di Napoli, Federico II, Napoli, Italy

Keywords: Re-identification, Biometrics, Multiple Cameras Networks, Persistent Tracking, People Tracking.

Abstract: Advanced surveillance applications often require to re-identify an individual. In the typical context of a

camera network, this means to recognize a subject acquired at one location among a feasible set of

candidates acquired at different locations and/or times. This task is especially challenging in applications

targeted at crowded environments. Face and gait are contactless biometrics which are particularly suited to

re-identification, but even “soft” biometrics have been considered to this aim. We present a review of

approaches to re-identification, with some characteristic examples in literature. The goal is to provide an

estimate of both the state-of-the-art and the potential of such techniques to further improve them and to

extend the applicability of re-identification systems.

1 INTRODUCTION

Discontinuous tracking of people across large sites,

that is the search of a person of interest in different

non-overlapping locations over different camera

views, is a crucial task known as people re-

identification. A more formal definition of the re-

identification paradigm can be summarized as

follow: given a probe set acquired at location X at

time T0, re-identification aims to match its items

with the subjects in a gallery set, collected at a

different location Y at time T1. Biometrics seems a

viable solution to solve this problem when human

subjects are to be tracked. It is widely accepted that

biometric recognition under controlled data

acquisition conditions is a relatively mature

technology, which has proved to be effective for the

actors of security agencies, public transports,

governments, and in independent technology

evaluation initiatives (Phillips et al., 2010).

However, the feasibility of biometric techniques

under uncontrolled data acquisition conditions still

raises considerable and often well-motivated

scepticism. Just for this reason, re-identifying people

moving across different sites covered with non-

overlapping cameras, could be the ideal scenario for

testing technology under uncontrolled data

acquisition conditions. As the image data (video) is

rather large, the challenge will be to develop fast

strategies for human biometric tagging. The

application scenarios provide an extremely

challenging video analysis task. Video streams will

be captured both indoor and outdoor, and the size of

people in the images (pixels on target) will range

from a few tens to several hundreds pixels. face and

gait biometrics are particularly promising for re-

identification, since they can operate at a distance

and do not require a detailed and/or high resolution

image of the subject and/or its biometric traits.

2 PERSON RE-IDENTIFICATION

One of the most critical challenges in facing the

person re-identification problem is to recognize the

same person viewed by disjoint, possibly non-

overlapping cameras, at different time instants and

locations. A thorough description of the main issues

and open challenges related to remote face

identification and face-based re-identification as

well, is presented in the work by Chellappa et al.

(2012) which analyzes the impact of each of the

main aspects characterizing unconstrained

applicative scenarios, like camera-subject distance,

camera resolution, illumination in outdoor

environments, pose variation, blur, occlusions and

weather artifacts. More recently, a suvery

specifically devoted to re-identification has been

189

De Marsico M., Distasi R., Ricciardi S. and Riccio D..

A Comparison of Approaches for Person Re-identiﬁcation.

DOI: 10.5220/0004815201890198

In Proceedings of the 3rd International Conference on Pattern Recognition Applications and Methods (ICPRAM-2014), pages 189-198

ISBN: 978-989-758-018-5

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

proposed by Vezzani et al. (2013). A re-

identification technique can be analyzed according

to a number of aspects: i) number of tracked

subjects; ii) granularity of extracted features

(segmented regions, blobs, key-points); iii) possible

overlap of camera fields of view; iv) use of

contextual information; v) efficiency and

effectiveness. In the following we group a number of

representative methods according to some relevant

criteria, taking into account that a single system may

fit more than one category. Table 1, located at the

end of this section, resumes all the contributions

cited in the subsections 2.1 to 2.6 with regards to

authors, methods and datasets used for experiments.

2.1 Single and Multi-target Tracking

across Disjoint Cameras

Both the method proposed in (Madden et al., 2007),

and the one proposed by Colombo et al. (2008) are

based on a single-person tracking, though exploiting

the analysis of very different features. The

appearance model proposed by the first one is based

on an Incremental Major Colour Spectrum

Histogram (IMCHSR). This is obtained by

combining an online k-means colour clustering

algorithm and the incremental use of frames. The

second performs a Gaussian Mixture Model (GMM)

segmentation on the video frames, and includes only

the foreground data in subsequent steps. The colour

constancy between cameras is then processed to

improve the quality of segmentation before

extracting several person descriptors; these are based

on appearance (mean colour, covariance, MPEG-7

dominant colour) and on spatio-temporal properties

(Kalman filter-based, topological) of the

observations. More recent techniques aim at tracking

more objects at the same time, to significantly

support video analytics functions, e.g., trajectory

recognition, actions and interactions between people

and objects. An especially critical aspect is due to

the lack of overlap in the camera fields of view,

which is usual in most real world applications,

where camera locations may even span a large

geographic area. As a consequence, acquisition

characteristics like illumination, color, or

atmospheric conditions, may significantly differ

among cameras. This increases the attention devoted

to such elements during video processing. In

particular, the need for color correction/mapping, for

features robust to distortions to characterize

persons/objects, often integrated by contextual

information, and of optimizations aiming at to

increase efficiency. The framework proposed by

Truong Congl et al. (2010) illustrates an example of

the typical strucrture of such architectures. The

proposed system consists of two main parts: the first

one implements an automatic process for silhouette

extraction based on the adaptive GMM in a joint

spatial-colorimetric feature space; the second part

implements a classification technique, which

exploits the discriminative characteristic of sparse

representation of signals to perform people re-

identification. In (Javed et al., 2005), the authors

focus on the problems implied by non-overlapping

multiple cameras systems, in particular the possibly

very different appearance of the same subject due to

different camera parameters or lighting conditions.

They show that brightness transfer functions from a

given camera to another camera lie in a low

dimensional subspace that can be learned during a

training phase and demonstrate that this subspace

can be used to compute appearance similarity. To

this aim they exploit the Maximum A Posteriori

(MAP) estimation framework using both location

and appearance cues. In (Javed et al., 2008), the

authors further extend this approach by observing

that in most cases people or vehicles tend to follow

the same paths, therefore propose a novel algorithm

using this conformity to establish correspondences.

By exploiting this property, the algorithm captures

the inter-camera relationships in the form of

multivariate probability density of space–time

variables using kernel density estimation. The

space–time and appearance models for object

tracking are learned in a training phase. Jeong and

Jaynes (2008) estimate the unknown color transfer

function between pairs of disjoint cameras by means

of a color calibration method. The developed model

operates on chromaticity samples to increase the

temporal stability of the transfer function between

any camera pair. Kuo et al. (2010) also address the

tracking problem for multiple non-overlapping

cameras. In addition, they introduce the association

of multi-target tracks by a discriminative appearance

affinity model learned on-line. Multiple Instance

Learning (MIL) boosting algorithm is adopted to

solve the labelling ambiguity during the learning

process at runtime. A multi-object correspondence

optimization framework is provided to solve the

“target handover” problem across cameras.

2.2 The Granularity of Features

An extremely important factor affecting re-

identification performance is the type and

granularity of the features which are extracted for

tracking. In a top-down perspective with respect to

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

190

granularity, one can classify the different methods

according to their basic elements: i) whole objects;

ii) segmented objects; iii) key-points; iv) biometric

traits. The last kind of elements can be considered as

the most fine-grained one, adding a semantic content

to the tracked object (face, person). Since it is also

strictly bound to the permanence of features used for

re-identification, it will be discussed separately.

2.2.1 Methods based on Whole Objects

Among the methods which compute feature vectors

starting from the whole detected object we can

mention the one proposed by Bak et al. (2010a). In

this approach, people are first detected and tracked

using Histograms of Oriented Gradations (HOG)

with a Sobel convolution kernel. The detection uses

15 cells in specific locations around a human

silhouette. Then two signatures are obtained from

data tracked through a few frames: one is based on

Haar-like features combined through a cascade using

information entropy as a feature reduction heurystic;

the other one is based on Dominant Color

Descriptors for the upper and lower part of the body,

combined using the AdaBoost scheme. The system

is set up with multiple cameras, and the signatures

are obtained at one camera and reused at the others.

The system performs color normalization across

cameras in order to handle color dissimilarities due

to differences in lighting or camera calibration. In

(Bak et al., 2010b), the color-normalized signatures

are obtained by computing covariance descriptors on

six regions of interest corresponding to fixed body

parts. The signatures are matched through a

multiresolution grid method. This is a pyramid

matching scheme using covariant matrix distance,

and modified to include spatial information, where

matches found at finer resolutions have more weight

than matches found at coarser resolutions. The

authors further refine this technique in (Bak et al.,

2011), where they propose a human appearance

signature, called Mean Riemannian Covariance Grid

(MRCG). The matrices are seen as tensors on a

Riemannan manifold (i.e., a non-Euclidean space

without the usual additive structure). The system

requires no “learning”, but the entrance of a new

subject requires updating of all the signatures in the

database. The MRCG is also adopted in (Corvée et

al.) as fusion technique to combine several clues,

mainly clothing characteristics, for short term re-

identification. People are detected by a simplified

Local Binary Pattern operator (SLBP) that extracts a

16-dimensional feature vector submitted to

Adaboost training. This method is especially suited

for low resolution images where fine features such

as iris or even face shots cannot be reliably assumed

to be available. The system can also withstand some

changes in clothing (such as unzipping a jacket).

Ayedi et al. (2012) also focus their attention on the

relevance of adequate descriptors for representation

and ultimately for re-identification purposes in the

context of camera networks. Uncontrolled settings

relative to the field of view (FOV) available to each

camera node require relative invariance.

2.2.2 Methods based on Segmented Objects

A first step towards a finer granularity of features for

tracking of objects is the introduction of texture

features, as proposed in (Berdugo et al., 2010). The

integration of textural features, alongside of the

conventional color features, and a probabilistic

model of a human, provides a measurable

improvement in the correct matching of similar

figures and therefore an increment in the re-

identification success rate. The metric exploited to

evaluate the correlation between two appearance

models is the Kullback-Leibler distance, matching

key frames from the trajectory path of the object,

rather than matching a single image. Farenzena et al.

(2010) exploit textural information by detecting the

presence of recurrent local motifs with high entropy.

They combine textures with the overall chromatic

content and the spatial arrangement of colours into

stable regions. The main idea is to extract features

that model three complementary aspects of the

human appearance. Some techniques, like the one

proposed in (Chien et al., 2006), partition the human

silhouette in regions from which local features are

extracted. The authors propose a multi-stage

algorithm based on a human-specific descriptor

referred as Human Color Structure Descriptor or

HSCD, representing the colors of body, legs, and

shoes of a human object at specific positions in a

compact 112 bits vector. The main aim of this

approach is the integration of fundamental tasks of

re-identification, namely segmentation, tracking and

description generation. Indeed, it is able to achieve

better performance than Scalable Color Descriptor

and Color Structure Descriptor while requiring a

reduced computation. Wang et al. (2007) also

exploit several statistics over image subregions

modelling, related to both shape and appearance

context. The descriptor of a given object is its

occurrence matrix resulting from a novel fast real-

time algorithm to find occurrence and co-

occurrence, which is based on integral computations

to increase the algorithm efficiency. Correspondence

AComparisonofApproachesforPersonRe-identification

191

between multiple cameras for visual surveillance

topic is addressed by Hu et al. (2006), by

introducing a technique based on principal axes of

people, where the people similarity match across

multiple cameras exploits the relationship between

“ground-points” detected in each view and the

intersections of the principal axes detected in

different views and transformed to the same view. In

the context of approaches using local features it is

also to consider methods based on the bag-of-

features. In (Gray and Tao, 2008) the bag-of-

features are used to provide a technique to perform

viewpoint invariant pedestrian recognition adopting

the Ensemble of Localized Features (ELF) as object

representation. The ELF model contains 200 color

and texture-based features processed by Schmid and

Gabor filters; an AdaBoost based function computes

similarity. The pedestrian recognition task requires

that the ELF model is supervised by a human

operator; on the other hand, it is effective and totally

automatic at discriminating between pedestrians

regardless of the viewpoint change. Doretto et al.

(2011) review and compare several aspects of

appearance-based techniques for person re-

identification and illustrate two local descriptors in

more depth: the histogram of oriented gradients in

log-color space (HOG log-RGB) and the HVS edgel

technique, along with a detailed description of the

salient edgel extraction algorithm. Organization of

this lower-level data relies on bounding box and

bag-of-features models. As for signature

computation, the paper describes a quick method to

compute co-occurrence matrices exploiting integral

image representation. Covered parts-based models

include interest point matching and model fitting.

2.2.3 Some Comparison of Local

Approaches

Given the high number of local features available, it

is crucial to analyse which ones can provide a good

support for person-reidentification. Bäuml and

Stiefelhagen (2011) compare several local features

for re-identification in image sequences. Assuming

that a tracker module provides a rough bounding box

around the picture of a person, features are

computed for all interest points lying within the

bounding box. The model applied is that of a bag of

features, meaning that spatial and temporal

information about the features is discarded. The

interest point detectors evaluated are Harris, Harris-

Laplace, Hessian-Laplace, Harris-affine, Hessian-

affine, and Fast-Hessian. The local descriptors used

are SIFT, Shape Context (SC) with Canny edge

detector, Gradient Location and Orientation

Histogram (GLOH), and SURF. Since video footage

is actually acquired rather than still images, feature

distances are fused with the sum rule across frames.

The experimental results indicate that no specific

point detector has a definite advantage over the

others. Among the descriptors, GLOH and SIFT

performed better than the other two. A further

interesting evaluation regards the comparative

analysis between local features and more articulated

and complex characterization tools, such as the

edgel deeply reviewed by Doretto et al. (2011). This

is the aim of the sudy by Gheissari et al. (2006),

where the authors compare two methods for people

re-ideinfication. The first one is based on points of

interest obtained via the Hessian affine invariant

operator, which has the advantage of generating

more data points where the information content is

high. The second method is a dynamic model for the

time-variant appearance of a subject based on edgel

extraction. The model is obtained from a

decomposable triangulated graph, fitted to the

images by a dynamic programming algorithm. The

approach based on points of interest uses local color

histograms for comparison and is computationally

lighter, but results do not persist over time due to the

changing appearance of subjects. The dynamic

model maps body parts from subject to subject so

that a correspondence can be established through

matching scores. The authors also propose a spatio-

temporal segmentation algorithm that is robust to

variations in appearance of clothes due to folds and

wrinkles. The two methods are compared along with

a baseline reference method based on the foreground

histogram of a crude bounding box. The dynamic

model is found to perform significantly better than

the other two, whose performance is similar at the

experimental resolution. According to the results of

these comparative studies, it appears that fusion of

information from different levels is more

advantageous that selection to improve the efficacy

of person re-identification techniques.. As a matter

of fact, Bazzani et al. (2010) propose an appearance-

based method based on a signature called HPE

(Histogram Plus Epitome), which incorporates both

local and global descriptors. The emphasis is on the

overall chromatic content, but there are additions

that account for local patches of color. The input is a

sequence of single-camera still images. The

background is eliminated by the STEL generative

model, then the HSV histograms of the foreground

undergo an unsupervised Gaussian clustering. The

HSV histogram is the first component of the

signature and accounts for global color distribution.

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

192

The signature has two more components (epitomes)

that describe the color patches present in the subject

at the global and local level. The experimental

results show the importance of accurate calibration

in the training set: increasing the number of images

used to compute the descriptors has significantly

diminishing returns. From one side it is possible to

select and combine more types of features. From the

other side, it is possible to work on the distance

measures adopted to compare such features. In

particular, it is possible to have such distance

dynamically adapt in time to the changing context

where it is used. This is the core idea of the work by

Zheng et al. (2011), whose aim is that of building a

learning system that can iteratively find an optimal

distance function that maximizes the probability of

having a true matching pair lie at a smaller distance

than a mismatching pair, with the maximization

performed over all possible matching and

mismatching pairs. Matching can use raw image

data or extracted features such as rough histograms.

The distance function used as a starting point for

learning include color histograms from horizontal

stripes of a person's image as well as texture

information extracted by Schmid and Gabor filters.

2.2.4 Methods based on Key-points

Going down along the granularity rank of the

features exploited for re-identification, we find the

techniques based on key-points produced by

transforms (e.g., Scale Invariant Feature Transform ̶

SIFT, Speeded Up Robust Features ̶ SURF).

Jungling and Arens (2010) adopt SIFT features for

person re-identification in infrared image sequences.

After a clustering stage where feature prototypes are

built, an Implicit Shape Model (ISM) records the

spatial occurrence of features in terms of object

center offsets. The person re-identification module

adopts a novel model that uses the general

appearance codebook applied for person detection as

an indexing structure for re-identification, and thus

is able to efficiently acquire and match models. To

this aim SIFT features collected during training are

integrated into the person instance model; the latter

is indexed by the codebook entries which activated

the feature during detection. The module for

matching models uses a two level strategy: the first

stage allows for fast discovery of promising models

based on matching of person signatures, while the

second one performs a detailed analysis of models

based on feature descriptors. Oliveira and Luiz

(2009) propose a different approach based on local

features. Interest points collected in a query image

are matched with those collected in each video

sequence used for each previously seen person. The

system exploits multiple networked cameras

featuring local processing, via an onboard processor

running Linux OS. This design may represent a

limitation and/or a complication, but it shows a good

accuracy in the re-identification even in presence of

cloth changes or occlusions. Hamdoun et al. (2008)

propose a method based on interest points given by

SURF (Hessian and Haar wavelets). The interest

points are extracted from video sequences as

opposed to single isolated frames. Query data are

also gathered from video sequences, yet shorter than

those in the learning phase. The metric in descriptor

space is the sum of absolute distances, and the

matching relies on best-bin-first search in a KD-tree

with all models. Query/model matching is performed

by multiple interest points voting for a particular

match. The variant of SURF used aims at maximum

time efficiency and only uses integer arithmetic.

2.3 Permanence of Biometric Features

An important aspect that many techniques described

so far do not consider is time. They are effective to

re-identify the same person in videos produced by

disjoint cameras, but in a reduced time window.

When the time elapse increases (i.e. more days) it is

not realistic to assume that a person wears the same

dresses, so that in this case many methods risk to be

completely ineffective. On the contrary, methods

based on biometric traits can also be applied in

contexts of this kind. For this reason such methods

are quickly spreading. In the context of person re-

identification, face appears to offer the best

compromise between concrete feasibility of the

systems and accuracy of the recognition: This is due

to the fact that the face surface is surely larger than

other physical biometric traits, e.g., the iris, and that

it requires a contact-less acquisition, differently

from, e.g., fingerprints. At the same time it

guarantees a reasonable accuracy even in under-

controlled conditions. It is to consider in any case

that face recognition in unconstrained settings,

including unstable data capture conditions, is very

challenging. As a matter of fact, many algorithms

perform well, when constrained face images are

acquired, but their performance degrades

significantly when the test images contain variations

that are not present in the training images. Chellapa

et al. (2012) highlight some of the key issues in

remote face recognition, and introduce a remote face

database which has been acquired in an

unconstrained outdoor maritime environment. The

problem of face re-identification by disjoint cameras

AComparisonofApproachesforPersonRe-identification

193

is deeply investigated in Bäuml et al. (2010). Face

detection is based on the modified consensus

transform and a subset of the frames is scanned for

different possible face orientations, accounting for

possible inter-subject occlusion. User feedback is

used to help the subject-specific classifier by

pointing out the best and the worst candidate

matches. Fisher et al. (2011) further extended this

work but readapt it to a different application, that is

a video retrieval framework, in which the system

finds occurrences of a query person in a set of TV

episodes. Because of either the limited resolution of

acquisition devices or the large distance of the target

from them, soft biometrics traits, like hair, skin and

cloth patches can significantly support the face re-

identification process, as proposed by Dantcheva

and Dugelay (2011). In this paper the main aim of

the authors is to address pose variations related to

the camera network of video-surveillance systems.

This is one of the typical challenges of face

recognition, and is complicated in this context by an

unattended acquisition procedure. The idea is to

mimic the way in which humans improve the

accuracy of frontal-to-side recognition by exploiting

simple and evident traits subdivided into trait-

instances, e.g. blond, brown, red and black for the

trait hair-color. The proposed algorithm analyzes

color and texture of the selected patches, then a

combined classifier is built to boost and combine all

considered traits. Results do not qualify this soft-

biometrics based approach as a candidate for robust

re-identification, but rather as a pruning system for

high security solutions for access control or as part

of a multi-biometrics systems. A further

(behavioural) biometrics which can be used for

person re-identification is gait analysis, since it can

work at a distance even at low resolutions and

without co-operation. Roy et al. (2012), propose a

hierarchical framework for re-identifying a non-

cooperative subject by combining gait with the

phase of motion in a spatiotemporal model. They use

three features: two for subject’s motion dynamics,

and the third is derived from the spatio-temporal

model of the camera network. By combining them,

the method can track subjects even if they change

speed, or stop for some time in the blind gap.

2.4 Overlapping Fields of View

Though often unaffordable for obvious practical

economy reasons, multiple overlapping cameras

canprovidebothmore robustdetection and3D

locationestimationofobjects,bycoveringobject

featuresfromalldirections.Whenthesystem

handles a model of the overlap, the overlapping

vision fields can also support a smooth switching

among cameras during tracking.In the work by Cai

and Aggarwal (1999) tracking continues from a

single camera view until the system predicts that the

active camera is going to loose a good view of the

subject of interest. At that time tracking switches to

the camera that is estimated to provide a better view

and that requires the least switching. Three basic

modules are involved: Single View Tracking (SVT),

Multiple View Transition Tracking (MVTT), and

Automatic Camera Switching (ACS). During SVT, a

Bayesian classifier locate the most likely match of

the subject in the next frame. MVTT involves both

spatial and temporal motion estimation. Finally,

ACS relies on a prediction algorithm. Mittal and

Davis (2003) propose a multi-camera person

tracking system based on a region-based stereo

algorithm that finds 3D points inside an object from

information about regions belonging to the object

obtained from two different views. Association

across frames exploits the color models of the

horizontal sections of the person , which can also be

used for reidentification over longer time intervals.

Gandhi and Trivedi (2007) develop the concept of

Panoramic Appearance Map (PAM) for person re-

identification in a multi-camera setup. Each person

is tracked in multiple cameras and the position on

the floor plan is determined using triangulation

among different views. Using the geometry of the

cameras and the person location, the system creates

a panoramic map centred at the person’s location. In

the map the horizontal axis represents the azimuth

angle and the vertical axis representing the height. If

the person is detected in more than one camera, the

floor position can be obtained by finding the

intersection of the corresponding rays. In order to

ensure an accurate projection, only the frames where

three or more cameras detect the object are used.

2.5 Example Use of Context

A critical challenges in person re-identification is to

recognize the same person viewed by disjoint

cameras at different times and locations. Some

techniques, e.g., those in (Sankaranarayanan et al.,

2008) and (Mazzon et al., 2012), integrate

information from feature tracking with those related

to context or environment. Mazzon et al. (2012) link

the appearance of people, the spatial location of

cameras, and the potential paths a person can choose

to follow. The technique adopts a Landmark-Based

Model (LBM) using people movements in non-

observed regions, a site map, and regions of interest

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

194

where people are likely to transit. Sankaranarayanan

et al. (2008) particularly highlight the efficient use

of the geometric constraints induced by the imaging

devices, to derive distributed algorithms for target

detection, tracking, and recognition. Their

conclusions underline the importance of an

integrated approach for solving the interdisciplinary

problems involved in automated monitoring.

2.6 A Note about Efficiency

An open problem for re-identification is

computational cost, especially with camera networks

for real-time applications. Satta et al. (2012) use the

Multiple Component Dissimilarity (MCD)

framework, where an appearance-based method

leverages dissimilarity-based distances. As the

dissimilarity-based descriptors are vectors of real

numbers, they are much more compact and the time

for matching them is greatly reduced. Moreover, the

dissimilarity-based representation used by MCD

allows very fast re-identification implementations.

3 REFERENCE DATASETS

The datasets used for testing and fine-tuning are

critical for the design, development and performance

Table 1: Resumes of contributions to the field of person re-identification referenced throughout the text.

# Authors Dataset Approach # Authors Dataset Approach

1 Ayedi et alii VIPeR

region covariance descriptor

based on multi-scale features

19 Gray et alii VIPeR

Ensemble of Localized Features

(ELF)

2 Bak et alii

CAVIAR,

TREC

Haar-like features and DCD,

HOG based detection and

tracking

20 Hu et alii NLPR body principal axis

3 Bak et alii

i-LIDS

HOG tracking, covariance

descriptors with color

normalization, spatial pyramid

matching

Hamdoun et

alii

CAVIAR

regions of interest: Haar/SURF

variant.

4 Bak et alii

i-LIDS,

ETHZ

covariance descriptors

with custom fusion based on

Riemann geometry.

22 Javed et alii Proprietary

multivariate probability density

of space-time variables

Bauml and

Stiefelhagen

CAVIAR,

Proprietary

subset

points of interest, local

descriptors

23 Javed et alii Proprietary

training-based,

MAP estimation of location

and appearance cues

6 Bauml et alii Proprietary

multiple detectors based on

Modified Census transform

Jeong and

Jaynes

Proprietary

(Terrascope)

estimation of unknown color

transfer function between pairs of

cameras

Bazzani et

alii

i-LIDS,

ETHZ

HSV histograms of

global/local color content

Jungling and

Arens

CASIA

SIFT features, Implicit Shape

Model (ISM),

Berdugo et

alii

GBSEO

appearance modeling, human

probabilistic model

26 Kuo et alii Proprietary

learned discriminative

appearance affinity model

Cai and

Aggarwal

Proprietary

Bayesian classification

schemes, multivariate normal

distribution

Madden et

alii

Proprietary

Major Colour Spectrum

Histogram Representation

(MCSHR)

Chellappa et

alii

Proprietary

PCA+LDA+SVM, Sparse

Representation-based

Classification (SRC)

Mazzon et

alii

i-LIDS Landmark Based Model (LBM)

11 Chien et alii Proprietary

Human Color Structure

Descriptor (HCSD)

Mittal and

Davis

Proprietary

Region-based stereo algorithm,

bayesian classification

Colombo et

alii

Proprietary

Gaussian Mixture Model

(GMM)

Oliveira and

Luiz

CAVIAR Hessian matrix, Haar wavelet

13 Corvée et alii

INRIA,

proprietary

LBP, ADAboost, Mean

Riemannian Covariance Grid

(MRCG)

31 Roy et alii Proprietary

gait, phase of motion,

spatiotemporal model

Dantcheva

and Dugelay

FERET

AdaBoost applied to hair, skin

and clothes patches

Sankaranaray

anan et alii

VIPeR

Multiple Component Matching

(MCM) based on Multiple

Instance Learning

15 Doretto et alii Proprietary

comparison of several

approaches

33 Satta et alii

VIPeR,

i-LIDS

Multiple Component

Dissimilarity (MCD)

Farenzena et

alii

VIPeR,

i-LIDS,

ETHZ

HSV histogram, Maximally

Stable Colour Regions

(MSCR), recurrent highly

structured patches

Truong Cong

et alii

Proprietary

color-position histogram, spectral

analysis, SVM

Gandhi and

Trivedi

Proprietary

multi-camera based Panoramic

Appearance Map (PAM)

35 Wang et alii Proprietary

shape and appearance context

modeling

Gheissari et

alii

Proprietary

Hessian-affine regions of

interest, dynamic graph-based

model

36 Zheng et alii

VIPeR, i-

LIDS

dynamic definition of a custom

distance function.

AComparisonofApproachesforPersonRe-identification

195

assessment of a re-identification system. Their

content may greatly affect the results from each

system, e.g., due to resolution, noise, illumination

conditions, camera distance from the subjects,

average number of people in each frame, etc. Some

publicly available dataset are briefly described,

while details can be found at the corresponding sites.

VIPeR (Viewpoint Invariant Pedestrian

Recognition): 632 images (128x48 pixels) taken

from arbitrary viewpoints under varying conditions.

http://vision.soe.ucsc.edu/?q=node/178

CAVIAR (Context Aware Vision using Image-

based Active Recognition): Video clips (384 x 288

pixels, 25 fps) of people walking alone, meeting

with others, window shopping, etc.

http://homepages.inf.ed.ac.uk/rbf/CAVIAR.

TREC (Video Retrieval Evaluation Data): ~100-

hour corpus of video from 5 cameras; contains

surveillance data collected by the UK Home Office

at the London Gatwick International Airport.

http://www.itl.nist.gov/iad/mig//tests/trecvid/2008/d

oc/EventDet08-EvalPlan-v06.htm.

INRIA (Person Dataset): images with different

characteristics aimed to detection of upright people.

http://pascal.inrialpes.fr/data/human/.

i-LIDS (Imagery Library for Intelligent

Detection Systems): library of CCTV video footage

from 5 cameras; dataset versions containing still

images are also available; event detection scenarios

include sterile zone, parked vehicle, abandoned

baggage, doorway surveillance; a tracking scenario

with multiple camera is also included.

https://www.gov.uk/imagery-library-for-intelligent-

detection-systems.

CASIA (Gait Database): image sequences

(Dataset A) and videos. Dataset A, Dataset B

(multiview dataset – 11 views), Dataset C (infrared

dataset), Dataset D (real surveillance scenes).

http://www.cbsr.ia.ac.cn/english/Gait%20Databases.

asp.

GBSEO: video streams (one hour long, split in 5

minutes clips) by two (not synchronized) cameras at

the same time from different viewpoints with some

overlap. Different people that appear and reappear

few times in both cameras - videos are manually

annotated with bounding boxed and person names.

http://sipl.technion.ac.il/GBSEO.shtml.

ETHZ: samples from street video sequences.

http://homepages.dcc.ufmg.br/~william/datasets.htm

PETS 2009 (Benchmark data for Eleventh IEEE

International Workshop on Performance Evaluation

of Tracking and Surveillance): video footage from 8

cameras (7 fps) containing different crowd activities.

http://www.cvg.rdg.ac.uk/PETS2009/a.html.

Videoweb Activities Dataset – Items: 2.5 hours

of video from 8 cameras (30 fps) in courtyard.

http://www.ee.ucr.edu/~amitrc/vwdata.php.

3D PES (3D People Surveillance Dataset): video

sequences from 8 video surveillance cameras.

http://www.openvisor.org/3dpes.asp

4 CONCLUSIONS

The efficiency of a person re-identification system is

obviously bound to the application. Real-time

processing imposes severe constraints. Machine

learning algorithms may require a kind of training

that may not be feasible in highly dynamic settings.

The use of one or more cameras, and of overlapping

or non-overlapping fields of view, has its

implications too. Single camera applications are

nowadays limited to simple settings. On the other

hand, while overlapping views provide more robust

information and allow more “intelligent” processing,

it is also to consider that possible triangulation is

computationally demanding. Therefore, the choice

of the system to use is bound to the real operational

needs. A plurality of issues must be addressed when

facing re-identification problems, including

clustering and selection of relevant regions,

recognition-by-parts, anomaly and change detection,

sampling and tracking, fast indexing and search,

sensitivity analysis, and their ultimate integration.

This implies plenty of sparks for present and future

research. Many problems are borrowed from

complementary fields, such as biometric recognition,

so that also solutions can be adapted and improved.

The challenge addressed is an evidence-based

management to progressively collect and add useful

information to data, in order to generate knowledge

and appropriate triggering of pre-determined actions.

REFERENCES

Ayedi W., Snoussi H., Abid M., 2012. A fast multi-scale

covariance descriptor for object re-identification. In

Pattern Recognition Letters, 33(14), pp. 1902-1907.

Bak S., Corvee E., Bremond F., and Thonnat M., 2010a.

Person Re-identification Using Haarbased and DCD-

based Signature. In 2nd AMMCSS, pp. 1-8.

Bak S., Corvee E., Bremond F., and Thonnat M., 2010b.

Person Re-identification Using Spatial Covariance

Regions of Human Body Parts. In 7

Intl. Conf. on

Advanced Video and Signal-Based Surveillance, pp.

435-440.

Bak S., Corvee E., Bremond F., and Thonnat M., 2011.

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

196

Multiple-shot human re-identification by mean

Riemannian covariance grid. In 8

IEEE International

Conference on Advanced Video and Signal-Based

Surveillance, pp. 179-184.

Bäuml M., Bernardin K., Fischer M.,. Ekenel H. K, 2010.

Multi-pose face recognition for person retrieval in

camera networks. In IEEE 7

Int. Conf. on Advanced

Video and Signal Based Surveillance, pp. 441-447.

Bäuml M., Stiefelhagen R., 2011. Evaluation of local

features for person re-identification in image

sequences. In 8

IEEE Int. Conf. on Advanced Video

and Signal Based Surveillance, pp. 291-296.

Bazzani L., Cristani M., Perina A., Farenzena M., and

Murino V., 2010. Multiple-Shot Person Re-

identification by HPE Signature. In Intl. Conf. on

Pattern Recognition, pp. 1413–1416.

Berdugo G., Soceanu O., Moshe Y., Rudoy D., and Dvir

I., 2010. Object re-identification in real world

scenarios across multiple non-overlapping cameras. In

European Signal Processing Conf., pp. 1806-1810.

Cai Q. and Aggarwal J.K., 1999. Tracking Human Motion

Using a Distributed-Camera System. In IEEE Trans.

On PAMI., 21(12), pp. 1241-1247.

Chellappa R., Ni J., Patel V. M., 2012. Remote

identification of faces: Problems, prospects, and

progress. In Pattern Recognition Letters, 33(14), pp.

1849-1859.

Chien S.Y., Chan W.K., Cherng D.C., Chang J.Y., 2006.

Human object tracking algorithm with human color

structure descriptor for video surveillance systems. In

IEEE Int. Conference on Multimedia and Expo, pp.

2097-2100.

Colombo A., Orwell J., and Velastin S., 2008. Colour

constan-cy techniques for re-recognition of pedestrians

from mul-tiple surveillance cameras. In Workshop on

Multi-camera and Multi-modal Sensor Fusion

Algorithms and Applications, 2008, Marseille, France.

Corvée E., Bak S., and Brémond F., 2012. People

Detection and Re-identification for Multi Surveillance

Camera. In VISAPP 1, SciTePress, pp. 82-88.

Dantcheva A.,. Dugelay J. L, 2011. Frontal-to-side face re-

identification based on hair, skin and clothes patches.

In IEEE Int. Conf. on Advanced Video and Signal-

Based Surveillance, pp. 309-313.

Doretto G., Sebastian T., Tu P., Rittscher J., 2011.

Appearance-based person reidentification in camera

networks: Problem overview and current aspects. In

Journal of Ambient Intelligence and Human

Computing, 2(2), pp. 1–25.

Farenzena, L. Bazzani, A. Perina, V. Murino, M. Cristani

M., 2010. Person Re-Identification by Symmetry-

Driven Accumulation of Local Features. In IEEE

Conf. on Computer Vision and Pattern Recognition,

pp. 2360-2367.

Gandhi T.and Trivedi M. M., 2007. Person tracking and

reidentification: Introducing panoramic appearance

map (PAM) for feature representation. In Machine

Vision Applications, 18(3), pp.207–220,

Gheissari N., Sebastian T. B., Tu P. H., Rittscher J., and

Hartley R., 2006. Person Reidentification Using

SpatioTemporal Appearance. In IEEE Conf. on Comp.

Vision and Pattern Rec., vol. 2, pp. 1528–1535.

Gray D., Tao H., 2008. Viewpoint invariant pedestrian

recognition with an ensemble of localized features. In

Conf. on Computer Vision, pp. 262-275.

Hamdoun O., Moutarde F., Stanciulescu B., and Steux B.,

2008. Person re-identification in multi-camera system

by signature based on interest point descriptors

collected on short video sequences. In ACM/IEEE Intl.

Conf. on Distributed Smart Cameras), pp.1–6.

Hu W., Hu M., Zhou X., Lou J., 2006. Principal Axis-

Based Correspondence between Multiple Cameras for

People Tracking. In IEEE Transactions on Pattern

Analysis and Machine Intelligence, 28(4), pp.663-671.

Javed O., Shafique K., Shah M., 2005. Appearance

modeling for tracking in multiple non-overlapping

cameras. In IEEE Conf. on Computer Vision and

Pattern Recognition, vol. 2, pp. 26-33.

Javed O., Shafique K., Rasheed Z., Shah M., 2008.

Modeling inter-camera spacetime and appearance

relationships for tracking across non-overlapping

views. Computer Vision and Image Understanding

109(2), pp.146–162.

Jeong K., Jaynes C., 2008. Object matching in disjoint

cameras using a colour transfer approach. Journal of

Machine Vision and Applications, 19(5), pp. 88–96.

Jungling K., Arens M., 2010. Local Feature Based Person

Re-identification in Infrared Image Sequences. In 7°

IEEE International Conference on Advanced Video

and Signal Based Surveillance, pp. 448-455.

Kuo C. H., Huang C., Nevatia R., 2010. Inter-camera

association of multi-target tracks by on-line learned

appearance affinity models. In Conference on

Computer Vision, pp. 383-396.

Madden C., Cheng E. D., Piccardi M., 2007. Tracking

people across disjoint camera views by an illumination

tolerant appearance representation. Journal of

Machine Vision and Applications 18(3), pp. 233–247.

Mazzon R., Tahir S. F., Cavallaro A., 2012. Person re-

identification in crowd. In Pattern Recognition

Letters, 33(14), pp. 1828-1837.

Mittal A., Davis, L. 2003. M2 tracker: a multi-view

approach to segmenting and tracking people in a

cluttered scene. Int. J. Comput. Vis. 51(3), pp.189–

203.

Oliveira I., Luiz J., 2009. People re-identification in a

camera network. In IEEE Int. Conf. on Dependable,

Autonomic and Secure Computing, pp. 461-466.

Phillips P. J., Scruggs T., O’Toole A., Flynn P. J., Bowyer

K. W., Schott C. and Sharpe M., 2010. FRVT 2006

and ICE 2006 Large-Scale Experimental Results.

IEEE Transactions on Pattern Analysis and Machine

Intelligence, 32(5), pp. 831–846.

Roy A., Sural S., Mukherjee J., 2012. A hierarchical

method combining gait and phase of motion with

spatiotemporal model for person re-identification. In

Pattern Recognition Letters, 33(14), pp. 1891-1901..

Sankaranarayanan A. C., Veeraraghavan A., and

Chellappa R., 2008. Object detection, tracking and

recognition for multiple smart cameras. In

AComparisonofApproachesforPersonRe-identification

197

Proceedings of the IEEE, vol.96, no.10, pp.1606-1624.

Satta R., Fumera G., Roli F., 2012. Fast person re-

identification based on dissimilarity representations. In

Pattern Recognition Letters, 33(14), pp. 1838-1848.

Truong Congl D.-N., Khoudour L., Achard C., Meurie C.,

Lezoray O., 2010. People re-identification by spectral

classification of silhouettes. Signal Processing, vol.

90, no. 8, pp 2362-2374.

Vezzani R., Baltieri D., Cucchiara R.,2013. People Re-

identification in Surveillance and Forensics: a Survey.

Accepted for publication in ACM Computing Surveys.

Wang X., Doretto G., Sebastian T., Rittscher J., Tu P.,

2007. Shape and appearance context modeling. In

IEEE Int. Conf. on Computer Vision, pp. 1-8.

Zheng W., Gong S., and Xiang T., 2011. Person re-

identication by probabilistic relative distance

comparison. In IEEE Conference on Computer Vision

and Pattern Recognition (CVPR), pp. 649-656.

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

198
