Optimizing Access Control Performance for the Cloud

Slim Trabelsi

, Adrien Ecuyer

, Paul Cervera Y Alvarez

and Francesco Di Cerbo

SAP Labs France, Mougins, France

Open Systems, Zurich, Switzerland

Amadeus, Sophia-Antipolis, France

Keywords: Cloud, Access Control, Performance, Caching, Scalability, Policy, Security.

Abstract: Cloud computing is synonym for high performance computing. It offers a very scalable infrastructure for

the deployment of an arbitrarily high number of systems and services and to manage them without impacts

on their performance. As for traditional systems, also such a wide distributed infrastructure needs to fulfil

basic security requirements, like to restrict access to its resources, thus requiring authorization and access

control mechanisms. Cloud providers still rely on traditional authorization and access control systems,

however in some critical cases such solutions can lead to performance issues. The more complex is the

access control structure (many authorization levels, many users and resources to protect); the slower is the

enforcement of access control policies. In this paper we present a performance study on these traditional

access control mechanisms like XACML, which computes the overhead generated by the authorizations

checking process in extreme usage conditions. Therefore, we propose a new approach to make access

control systems more scalable and suitable for cloud computing high performance requirements. This

approach is based on a high speed caching access control tree that accelerates the decision making process

without impacting on the consistency of the rules. Finally, by comparing the performance test results

obtained by our solution to a traditional XACML access control system, we demonstrate that the ACT in-

memory approach is more suitable for Cloud infrastructures by offering a scalable and high speed AC

solution.

1 INTRODUCTION

Cloud computing offers a high performance

computing infrastructure, combined with a huge

amount of resources (like storage, database,

network, servers, memory, virtual machines, etc.).

Resources are made available to customers with a

strong guarantee on the high quality of the

computing performance. Scalability, availability and

accessibility are among the key pillars of a cloud

service or platform; naturally, these characteristics

must not be sacrificed at the altar of security.

Security comprises many aspects and functionalities,

and access control represents one of the most

common concepts which are mandatory for any

production system. Access control (AC) is a

mechanism in charge of restricting and filtering the

access to system resources (data objects, Personal

Identifiable Information PII, services, platforms, or

infrastructure). Specific authorizations (also called

permissions) are assigned to system users; when a

user requests access to a resource, an AC engine is

in charge of checking if the requesting user’s

permissions are compliant with the set of AC rules

associated to that resource. The AC rules can be

expressed using very basic lists called ACL, or using

a more sophisticated and structured representation

called policy. The AC rules described via policies

are largely adopted in complex systems, those that

are available to many potential users and that offer

different resources. The main advantage of using AC

policies is the possibility to manage and maintain a

huge number of complex rules. Compared to the

basic ACLs, AC policies require a reasoning engine

able to explore process and decide on the

applicability of AC rules against access requests.

Cloud computing instances rely on AC systems

configured via AC policies that express AC rules

targeting a complex structure of user set and

resources (Popa, 2010). The more significant is the

density of the user and resource model; the more

complex is the structure of the policies. A complex

AC policy requires an additional computing and

reasoning effort to the AC engine in order to

interpret its rules and enforce the decision. Some

551

Trabelsi S., Ecuyer A., Cervera Y Alvarez P. and Di Cerbo F..

Optimizing Access Control Performance for the Cloud.

DOI: 10.5220/0004854005510558

In Proceedings of the 4th International Conference on Cloud Computing and Services Science (CLOSER-2014), pages 551-558

ISBN: 978-989-758-019-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

studies (Antonios, 2011) and (Tang, 2012) pointed

out the new requirements in terms of AC models

introduced by cloud computing the difficulties of

traditional authorization systems to handle very

complex policies for cloud computing systems, and

in some critical cases this can lead to performance

issues in the resource access process. In this paper

we conduct a performance study on a XACML

(OASIS, 2013) AC engine for a cloud infrastructure.

XACML, stands for eXtensible Access Control

Markup Language, is an OASIS XML policy

standard for AC. Although if XACML is not initially

designed for the Cloud, a deployment was proposed

in (Reddy, 2012). Our performance study consists of

stress tests on the AC enforcement engine, requiring

it to process a huge number of access requests for a

wide range of resources protected by complex

policies. The objective of this study is to indicate the

limitation of traditional AC engines when they are

deployed in cloud platforms. Subsequently, we

propose two approaches to optimize the performance

of the considered AC enforcement engine and make

it more suitable to cloud platforms. Both solutions

are based on a pre-caching authorization tree; this

method consists of storing all AC rules in a tree data

structure, in order to optimize the policy exploration

operation. This access tree can be implemented in

two ways: Using a traditional DB (loaded in

memory), or using a structured hash table system

(also loaded in memory). We stress the importance

of the in-memory deployment, in order to take

advantage of the “unlimited” resources offered by

the Cloud infrastructures.

This paper is organized as follows: In section

two we survey the state of the art on the different

performance studies dealing with performances of

AC systems, in section three we describe the

deployment of the XACML engine in the cloud as a

reference study basis, in section four we detail our

access control tree based solutions, in the section

five we compare the different approaches through

performance tests and try to identify the most

scalable approach.

2 RELATED WORK

Optimizing performances of AC enforcement

engines is an issue that appeared and was partially

addressed before the emergence of the Cloud

computing paradigm. It is interesting to review these

studies to learn about their approaches and try to

map them to the new requirements introduced by the

cloud infrastructures. An AC mechanism has its

deployment and operational costs, for instance when

implementing its structure in very large scale storage

systems, one has to face a trade-off among

performance, availability and security (Leung,

2007). Balancing this trade-off is particularly

challenging in the storage cloud environment, as

providers must implement an efficient access control

system that scales elastically and meets the high

availability requirements of the cloud. The

bottleneck caused by the lack of cloud-adapted AC

enforcement mechanisms can be exploited for DoS

attacks to break a service or a system like in the case

described in (Niu, 2009).

2.1 Performance Issues for Access

Control Enforcement in

Traditional Systems

One of the most interesting approaches that inspired

our solution is the XEngine. In (Hwang, 2011), and

(Daly, 2011) the XEngine is presented as a fast and

scalable evaluation engine for XACML. This work

proposes to transform a XACML policy into a

different data structure; this method converts the

hierarchical structure of the XACML policy into a

flat structure and then transforms any set of multiple

combining algorithms into a first-applicable

algorithm section. This work is inspired by the

decision diagram approach where the decision is

made based on a tree data structure. This work

addresses the problem of performing fast XACML

evaluation; however their model is quite static

especially with respect to the proposed tree structure

that systematically uses the subject as root of the AC

tree. Such model lacks of efficiency especially when

many resources are requested at the same time. In

our solution, we proposed several enhancements to

this approach in order to make it more flexible and

efficient for any type of queries.

(Squicciarini, 2011) proposed an alternative

approach called reordering and clustering policy

rules. Their work proposes a way to optimize

policies based on statistics to reorder rules. As it

consists of a reordering of rules, only the deny-

overrides and permit-overrides combining algorithm

are taken in consideration for the optimization. Their

solution works well if the amount of requests per

requesters and the type of requester are not dynamic.

In the case where they are dynamic the reordering is

not efficient, and a clustering solution is proposed.

The clustering is based on a per subject basis. In our

previous example, this leads to the creation of two

views, one for each subject, student and faculty.

However, Squicciardini et al consider only two

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

552

XACML combining algorithms.

2.2 Performance Issues for Access

Control Enforcement in Cloud

Systems

An initial study was proposed by (Punithasurya,

2012) to compare different AC models; they tried to

compare different parameters including the

performance aspect. This evaluation of such

parameters was not really motivated by a technical

analysis. Therefore, it is hard to interpret their

results and compare the different AC models with

respect to performance aspects.

Well known cloud providers like Amazon S3 or

Microsoft Windows Azure Storage, has a simple

method for granting access to third parties using

ACLs, provided that they are registered as S3 users

or groups (they do not implement complex AC

rules). Objects can be made public by granting

access to the Anonymous group but there is no way

to selectively grant access to principals outside of

the S3 domain. The main limitation of S3 ACLs is

the restriction to list 100 principals. Instead of

proposing a scalable solution, Amazon S3 proposed

to split the ACLs into small independent clusters.

EMC Atmos Online opted for the same approach

with a more hierarchical structure between the

different cluster groups.

The caching solution was also proposed for

cloud computing systems (Reeja, 2012). The

approach described in that paper implements two

policy decision points (PDP), one for new access

requests and another one for access requests that

were already processed by the primary PDP.

(Harnik, 2011) conducted an analysis on the

ACL based mechanism for cloud computing in order

to point out their weaknesses and to propose their

AC mechanism. It is based on a capability-based

system that allows the integration of existing AC

solutions thus leading to hybrid architectures for AC

systems. Such hybrid systems combine the benefits

of capability-based models with other commonly

used mechanisms such as ACLs or RBAC. On the

other hand this study points out the weakness of

ACL used by many major cloud providers like

Amazon and Microsoft.

3 DEPLOYING XACML IN THE

CLOUD

In the previous section we explored the different

access control system deployed in the current cloud

infrastructures. We observed that most of the

solutions are based on basic ACLs and not really

adapted to the Cloud requirements. We explain in

this section how the XACML is deployed in a Cloud

platform, and how to optimise the enforcement

process using access control trees. We explain how

our new solution takes benefit and enhance the tree

based structures proposed by other studies in the

literature.

3.1 XACML Integration

XACML is a declarative AC policy language

implemented in XML and a processing model

describing how to evaluate authorization requests

according to the rules defines in policies. It allows

for the definition of AC but also usage control rules

through obligations. This language is very

expressive and can be used to define a lot of

different kind of policies. The choice of this

language was due to the completeness of its

expressivity for access control rules. We can define

many AC models (like RBAC, ABAC, UBAC, etc.)

with this language. It has a good flexibility for

defining rule conditions.

We propose the XACML engine architecture

depicted in Figure 1 as an integration architecture to

the Cloud infrastructure.

 Cloud User interface: UI layers provided by the

cloud as a service or as a platform feature. This

cloud layer offers an IDM function to manage

the user identity and authentication features.

Through this UI the user can access to the

different services and resources offered by the

cloud. The identity (or role) of the user and her

access request are collected at this level in

order to be exploited by the PEP (Policy

Enforcement Point) of the XACML engine

 XACML Engine: it is deployed in the cloud a

service or as platform functionality (in this

paper we chose to deploy it as a service). It

offers the traditional functionality defined by

the XACML specifications: PAP (Policy

Administration Point) to manage the policy

repository, PDP (Policy Decision Point) that

evaluates the user request, and the

authorizations contained in the policies, PIP

(Policy Information Point) that provides

external information about the user profile, and

the Context Handler that coordinates all the

previous components.

 Cloud Resources: we connected the resource

manager of the XACML engine to the different

resources provided by the cloud infrastructure

OptimizingAccessControlPerformancefortheCloud

553

(database, services, VMs, etc.) in order to

associate a user request with the requested

resources. These resources are only accessible

if the PDP evaluates positively the user request.

Figure 1: XACML Architecture for the Cloud.

3.2 Cloud Platform

The XACML AC engine that we used and modified

in this paper is deployed as a service on a PaaS. We

chose SAP Hana Cloud since it can be seen as SaaS

and PaaS. SAP Hana Cloud platform also offers

services like connectivity, document storing,

identity, persistence and mail. But the most

important selling argument offered by SAP Hana

Cloud is that the platform is running over an in-

memory database (Plattner, 2009), which fits

perfectly with our in-memory based solution,

described in details in the next sections.

4 OPTIMIZED ACCESS

CONTROL ENFORCEMENT

The AC policy evaluation and enforcement can be

complex and lengthy tasks to perform, impacted by

the complexity of rules. In cloud computing, this

issue is combined with thousands of users requesting

simultaneously access to resources. This leads to an

overhead during the authorization checking process.

Therefore, it is important to implement a solution for

speeding up the policy-based authorization checking

process. Such solution should scale properly in order

to handle multiple concurrent requests.

4.1 Access Control Trees

The main issue with XACML is the complexity due

to its high expressivity. In order to optimize the

evaluation computation process, we decided to

implement a solution based on AC trees (ACT). The

ACT is a concept based on aggregation. The use of

pre-processing to aggregate privacy policies into the

ACT will allow performance efficient AC check on

mass of data. We can represent the aggregate AC

information into a tree. The tree data structure has

two key advantages for us: first, it provides a simple

view of the AC structure; secondly, it facilitates the

application of hashing techniques on a tree for

efficient data search functions. This hashing

technique will allow us to use an emerging database

class (NoSQL) in order to improve further the

already good performance of an ACT

implementation in a relational database.

To map the AC rules into a tree structure we

adopted the model proposed by (Bascou, 2002) and

adapt it to the XACML policy schema. In this

model, only accessible data objects are available. If

the access to an object is denied, it will not appear.

Following this model, our ACT contains only

permitted data objects. If the data object cannot be

accessed it will simply not appear. For this reason

we call this tree the “Permit Tree” (PT). The AC tree

or PT can be represented as follows:

Figure 2: Access Control Tree (Permission Tree).

The PT (the same procedure can be applied for the

Deny rules thus obtaining a Deny Tree) represented

in Figure 2 is structured in three main levels: The

first level contains the list of authorized subjects (or

users, or roles, etc.) declared in the XACML policy

repository. The ANY subject ID is used for objects

that are accessible to all users with no restrictions.

The second level represents the different actions or

operations that can be executed on the data. If the

list of actions is undefined, there is also an element

Any (Action). The third level represents the different

types for data objects. Subsequently, the fourth layer

contains a list of accessible data object IDs. The

layer order (in the example subject, action and

resource) can change according to system

requirements. For example the first level can be the

ID of the object. In that case the selection is made on

the object to be accessed, for which one gets the list

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

554

of authorized users.

4.2 Tree Management Algorithms

In this section we describe the tree management

algorithms, i.e. how the AC tree is built, maintained

and explored.

4.2.1 Insertion Algorithm

This algorithm describes how one can add a new

data object associated with its XACML rule. In other

words, this means to insert data object references in

the ACT corresponding to the XACML policy

associated to the data object.

Tree Input Parameters

The input for the insertion or “insert” algorithm is a

data object with a policy associated to it. The policy

is seen as a rule set that can be composed by 4 rule

types; they are listed in Table 1. One of them is

specific, while others are not specific. The first rule

type is a specific rule and can be easily mapped in

the ACT tree. The others (2-4) are not specific. Not

specific rules can be recognized by the “any”

keyword.

Table 1: List of rule types.

Rule Type Specific rule?

1.< subject; action; decision > specific

2.< subject; any; decision > non-specific

3.< any; action; decision > non-specific

4.< any; any; decision > non-specific

Tree Insertion Algorithm

The insertion algorithm consists of a body and two

functions. The body loops over each rule and check

if the rule is specific or not. If it is not specific, the

algorithm creates all specific rules corresponding to

it, by means of the first function

getAllSpecificRules(). Then for all specific rules the

algorithm executes the handleSpecificRule()

function. The getAllSpecificRules() function receives

as input a non-specific rule which is (specific type).

According to the non-specific rule type, all

corresponding specific rules will be created.

The handleSpecificRule() focuses on what to do

with a specific rule. First it checks if the rule was

already handled. Then it checks if the subject of the

rule already exists in PT. If it is not the case, the

subject is created in the tree and any sub-tree of the

PT is copied. If a specific subject can access any

data object ID in the “any” action sub-tree (rule type

2 in Table 1), the algorithm firstly extracts all action

sub-trees then checks if the rule decision is permit or

deny. If it is permit, the algorithm adds data object

ID to the subject sub-tree for the corresponding

action. At the end the algorithm inserts the rule in

the handled rule set in order to ensure the

consistency of the PT.

Insertion Algorithm

Input: <R1,R2,…,Rn> as P,PII, current tree as T

handeledRules={} //set of rules of type <subject,action>

for each rule R in P do

if R is of type <subject,action,permit> OR <subject,any decision> then

if T.subject not exist then

Add subject in T.subjects

Copy actions from T.any into T.subject

end if

endif

if R is of type <subject ,action,decision> then

if decision == permit then

Add PII in T.subject.action

endif

Add <subject, action> in handledRules

else if R is of type <subject, any ,decision> then

actionList = T.decision.subject.actions

for each action A in actionList do

if <subject, A> not in hanledRules then

if decision == permit then

add PII in T.subject.A

endif

Add <subject, A> in handledRules

endif

endfor

else if R is of type <any,action,decision> then

Subjectlist = T.decision.subjects

for each subject S in subjectList do

if <S, action> not in handledRules then

if decision == permit then

Add PII in T.S.actions

endif

Add <S, Actions> in handledRules

Endif

Enfor

else if R is of type <any, any, decision> then

subjectList = T.decision.subjects

for each subject S in subjectList do

actionList = T.decision.S.actions

for each action A in actionList do

if <S, A> not in handledRules then

if decision == permit then

add PII in T.S.A

endif

add <S, A> in handledRules

endif

endfor

endif

endfor

return T

4.2.2 Request Algorithm

The request algorithm is used to explore the AC tree

in an optimal way and retrieve the authorizations

related to a particular rule. This algorithm is

executed when a user requests access to a resource.

Tree Input Parameters

The request input takes the form: < Subject; Action;

Resource Type >. If one created a tree where the

level 1 node is a subject, then it is possible to start

the exploration using the input parameter Subject.

OptimizingAccessControlPerformancefortheCloud

555

Tree Request Algorithm

If the subject exists in the tree then a deep

exploration of the path is needed to find the data

object IDs related to it. If the subject does not exist,

the access to the resource is denied.

Request Algorithm

Input: <subject, action> as R, current tree as PT

If R.subject not exist in PT then

Return set of data objects ids resulting form PT.any.action

Else

Return set of Data object ids resulting form PT.subject.action

endif

5 IMPLEMENTING THE ACT

FOR THE CLOUD

Compared to the XEngine solution, we propose

implementations specially designed for the Cloud

platforms and the in-memory capabilities offered by

such platforms. The proposed ACT can be stored in

two ways: in a relational database or in structured

hash tables. Both are stored in-memory (using the

in-memory Hana DB). Each of the solutions has its

own advantages and drawbacks, detailed in the

following performance analysis section.

5.1 Database Implementation

In this implementation, the ACTs (Permit Tree and

Deny Tree) are stored in a relational database,

therefore any request is performed in the database

using SQL queries. The two ACTs are stored in the

same table: ACT(uniqueId, subject, name)

This table is composed by three columns:

 UniqueId: representing the IDs of data

objects.

 Subject: representing the user ID or role

specified in the Policy.

 Name: the value of the data object (ex:

john.doe@example.com).

The primary key of this table is composed of the

three columns. The composed primary key ensures

that a tuple is unique in the table and so in the ACTs

as well. Additionally, the primary key also creates

indexes on the three columns that will accelerate the

queries performed on the table.

Each request type is translated into a SQL

statement:

 Verify the access on a given data object by

a given subject:

SELECT uniqueId FROM ACT WHERE Subject =

? AND Name = ?, If the query returns an

unique Id, then the access can be granted

 Retrieve the list of data objects that a given

Subject can access

SELECT uniqueId FROM ACT WHERE subject =

?,the query returns a set of Data objects

IDs

 Retrieve the list of data objects from a

given category (Name) that a given subject

can access

SELECT uniqueId FROM ACT WHERE subject =

? AND name = ?, the query returns a set

of data objects ids

 Retrieve the list of subjects for a given data

object

SELECT subject FROM ACT WHERE uniqueId =

?, the query returns a set of Subjects

5.2 Hash based Implementation

In this implementation, we proposed to store the

access control trees into in-memory hash tables and

persisted in a relational database. The persistence of

ACTs is managed like in the previous

implementation. The tree data structure fits well

with the use of hash tables. This implementation

consists of two different trees, ACTbyData and

ACTbySubject with their own data structures.

The ACTbyData is implemented using the Java

structure HashTable. It maps keys to values. In our

case we mapped the Data IDs to a set of delegates.

The set of delegates is represented using the java

structure HashSet, which implements a set back by a

hash table. We mapped the delegates to a nested

HashTable. This nested HashTable maps the Data

names to sets of Data IDs. This latter set is

represented using the Java structure HashSet.

Therefore, we propose the following two data

structures:



ACTbyPii: Hashtable<Long,

HashSet<String>>

 ACTbySubject: Hashtable<String,

Hashtable<String, HashSet<Long>>>

The performance of Hashtables and Hashsets

depends on two parameters: the initial capacity and

the load factor. The former defines the number of

buckets that are created at the creation of the hash

tables. The load factor is a measure representing

how full the hash table is allowed to get before its

capacity is automatically increased. It is a Boolean

value.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

556

6 PERFORMANCE STUDY

In this section we evaluate the implementation of the

ACT in the use case. The setup for the evaluation is

the following. It is a PC with an Intel(R) Core(TM)

i5-2500 CPU @ 3.30 GHz. It has 8.00 GB of RAM

and is running Windows 7. The SAP HANA Cloud

Platform where we deployed our application offers

an elastic package with a limit of 12 GB of RAM.

For the ACT we performed the tests on a traditional

XACML engine HERAS-AF, the Cloud platform.

We developed two different ACT implementations,

one using a Derby DB loaded in-memory and the

hash version using Redis.

6.1 Comparing the Three AC

Implementation Versions

The basic testing scenario is a sequential query of

2000 different subject requesting 2000 different data

objects (in our scenario PIIs representing e-mail

addresses, and names). Every request is made by a

single user that asks to access everything and only

gets one object at the end. Every PII is constrained

by a policy permitting one subject to access.

Both of the XACML engines are deployed as a

service on the SAP Hana Cloud platform and

installed on top of a database containing PIIs.

Access requests are generated then sent to the the

engines as a HTTP REST requests.

At 2000 data object, the Derby version is 2428x

faster than the HERAS one, and the hybrid version

is even 16998x faster. The difference is important

since the HERAS based solution has to explore a

complex structure of XML and objects representing

the policy rules in order to match the applicable

policy with the context of the request. This is more

expensive in terms of processing time than a DB

SQL query execution or a Hash function call.

Figure 3: Comparing ACT solution with the traditional

XACML HERAS engine.

6.2 Comparing the in-DB and the

in-Hash ACT Solutions

The processing time of the HERAS solution gets

worse with the increase of the system population

(data objects + users). We decided then to focus our

performance study on the comparison between the

two proposed ACT implementations.

We run the same tests with a set of 6000 data

objects accessible for 6000 different subjects. At

6000 data objects available the in-hash

implementation of the ACT is 6x faster than the DB

one. Furthermore the in-hash version scales better.

Its performances are more stable as we can see with

the standard deviation which is more important for

the DB solution.

Figure 2: ACT in DB Vs. In-hash with 100% of the data

objects accessible

7 CONCLUSION

The performance requirement for AC systems on the

cloud is currently neglected by most of the cloud

providers. Most of the cloud services are relying on

single central AC systems implementing ACLs and

in charge of handling all the access requests coming

from all the cloud users. This issue can end up with

serious performance problems especially when the

cloud systems become complex. AC systems may

become the main bottleneck disrupting the high

speed computing capabilities of cloud servers. In our

paper we evaluated a XACML engine for a cloud

platform and demonstrated the limits of such policy

based AC engine when access requests become

huge. We proposed an AC tree caching system that

can be implemented in parallel to the traditional AC

systems in order to accelerate AC decisions. For this

solution we proposed two implementations: one

based on a relational database, and another one

OptimizingAccessControlPerformancefortheCloud

557

based on a structured hash table system. Both

solutions are stored in-memory. We tested these two

solutions against a traditional XACML-based

solution for the cloud. The performance discrepancy

between the traditional AC system and our ACT

based solutions is very important. Especially the

hash based ACT seems the more scalable and the

more adapted to cloud platforms.

ACKNOWLEDGEMENTS

This paper is done in the context of the PPP Fi-Ware

project and the FP7 EU COCO Cloud Project.

REFERENCES

G. Antonios, “Towards new access control models for

Cloud computing systems”, PhD report University of

Macedonia, Department of Applied Informatics

Z. Tang, J. Wei, A. Sallam, K. Li, R. Li, “ A New RBAC

Based Access Control Model for Cloud Computing”,

7th International Conference, GPC 2012, Hong Kong,

China, May 11-13, 2012. Proceedings, pp 279-288

OASIS. Extensible Access Control Markup Language

(xacml).https://www.oasis-open.org/committees/xacml

J. J. Bascou L. Gallon A. Gabillon, M. Munier and E.

Bruno, « An access control model for tree data

structures”. In ISC '02 Proceedings of the 5th

International Conf. on Information Security, 2002.

A. W. Leung, E. L. Miller, and S. Jones. Scalable security

for petascale parallel file systems. In SC ’07:

Proceedings of the 2007 ACM/IEEE conference on

Supercomputing, pages 1–12, New York, NY, USA,

2007. ACM. ISBN 978-1-59593-764-3. doi:

http://doi.acm.org/10.1145/1362622.1362644.

Z. Niu, H. Jiang, K. Zhou, T. Yang, and W. Yan.

Identification and authentication in large-scale storage

systems. Networking, Architecture, and Storage,

International Conference on, 0:421–427, 2009.

J. Hwang A.X. Liu, F. Chen and T. Xie. Designing fast

and scalable xacml policy evaluation engines. IEEE

Transactions on Computers, Dec 2011.

A. Squicciarini S. Maruf, M. Shehab and S.

Sundareswaran. Adaptive reordering and clustering

based framework for efficient xacml policy evaluation.

IEEE Transactions on Services Computing, Oct-Dec

2011.

J. Daly J. Brown and A. Gregory. The xengine policy

decision point for xacml 3.0. Computer security

project in Department of Computer Sciences at the

Michigan State University, 26 Oct 2011.

Popa, Lucian, Minlan Yu, Steven Y. Ko, Sylvia

Ratnasamy, and Ion Stoica. "CloudPolice: taking

access control out of the network." In Proceedings of

the 9th ACM SIGCOMM Workshop on Hot Topics in

Networks, p. 7. ACM, 2010.

Punithasurya K and Jeba Priya S. Article: Analysis of

Different Access Control Mechanism in Cloud.

International Journal of Applied Information Systems

4(2):34-39, September 2012. Published by Foundation

of Computer Science, New York, USA.

C.K. K. Reddy, P.R Anisha, K.S. Reddy, S.S. Reddy,

“Third Party Data Protection Applied To Cloud and

Xacml Implementation in the Hadoop Environment

With Sparql”, IOSR Journal of Computer Engineering

(IOSRJCE) ISSN: 2278 - 0661 Volume 2, Issue 1

(July - Aug. 2012), PP 39 – 46

Reeja S L, “Role Based Access Control Mechanism in

Cloud Computing using co-operative secondary

authorization Recycling Method”, 2012. International

Journal of Emerging Technology and Advanced

Engineering Website: www.ijetae.com (ISSN pp.

2250-2459, Volume 2, Issue 10, October 2012)

Amazon Simple Storage Service (Amazon S3). Amazon,

b. http://aws.amazon.com/s3/.

Windows Azure Platform. Microsoft, a. http://

www.microsoft.com/windowsazure/windowsazure/.

Atmos Online Programmer’s Guide. EMC, a. https://

community.emc.com/docs/DOC-3481, accessed Jan

12, 2010.

D. Harnik, E. K. Kolodner, S. Ronen, J. Sataran, A.

Shulman-Peleg, S. Tal,”Secure Access Mechanism for

Cloud Storage”, Journal of Scalable Computing:

Practice and Experience Volume 12, Number 3, pp.

317–336. http://www.scpe.org

HERAS-AF XACML - University of Applied Sciences

Rapperswil. http://www.herasaf.org/

SAP HANA Cloud Portal http://scn.sap.com/

community/hana-cloud-portal

Apach Derby http://db.apache.org/derby/

Redis Database http://redis.io/

Plattner, H. "A common database approach for OLTP and

OLAP using an in-memory column database."

Proceedings of the 2009 ACM SIGMOD International

Conference on Management of data. ACM, 2009.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

558
