Interdependent Components for the Development of Accessible XUL

Applications for Screen Reader Users

Xabier Valencia

, Myriam Arrue

, Halena Rojas-Valduciel

and Lourdes Moreno

EGOKITUZ: Laboratory of HCI for Special Needs, University of the Basque Country (UPV/EHU),

Informatika Fakultatea 20018, Donostia, Spain

Computer Science deparment, Universidad Carlos III de Madrid, 28911, Leganés, Spain

Keywords: Accessibility, User Testing, Expert Review, XUL, Mozilla Firefox Browser, Screen Reader.

Abstract: Web applications based on XUL technology have reached great development. This technology enables

developers to easily create extensions and add-ons of Mozilla Firefox browser. It is essential to keep in

mind accessibility in the development of such applications in order to not discriminate user groups. In this

sense, standards and good practices have to be considered. Furthermore, User-Centred Design and Inclusive

Design approaches should be followed as they involve users with disabilities in the development process.

This paper presents an analysis of XUL accessibility guidelines created by Mozilla Foundation. An

accessible XUL application has been designed and developed based on the guidelines. User testing has been

conducted by two blind users revealing several important accessibility barriers. In addition, an expert review

process was carried on by a blind accessibility consultant. They all used JAWS screen reader. The results

obtained show that the existing guidelines conformance is not enough for ensuring accessibility of the

application. There are other factors dependent on assistive technologies and user agent that have to be

considered in the development of accessible XUL applications.

1 INTRODUCTION

The use of Internet has experienced a vertiginous

growth in the last few years. Users access the Web

employing diverse devices, modalities and

technologies. Due to this diversity, inclusion

approaches are necessary in order to provide full

accessibility to Web contents and avoid the

exclusion of some user groups.

Users with disabilities are the most affected by

accessibility barriers on the Web. They access the

Web using assistive technologies, for example, a

screen reader that relates content in audio to the

visually impaired. It is essential to develop

accessible web applications to ensure appropriate

assistive technology support.

Currently, research work regarding web browser

functionality augmentation is gaining attention.

Some examples of Mozilla Firefox add-ons are

(Greasmonky, 2012), (Stylish, 2013) and (Turn off

the Lights, 2013).

These augmented functionalities could be

utilized by all users only if accessibility aspects are

considered in their development process. Thus, a

comprehensive inclusive design paradigm for

augmented browser functionalities should integrate

User-Centred Design (UCD) methods and Inclusive

Design approaches in addition to accessibility

guidelines compliance (Lawton, 2007) (Newell,

2000).

The interest of “design for all” paradigm is

rapidly increasing in the community and several

efforts have been made in this way. In fact, there are

several organizations concerned with web

accessibility. They develop and maintain support

resources for complying with accessibility standards

such as guidelines. This is the the case of Mozilla

Foundation (XUL, 2013b). In addition, it provides

extension mechanisms to augment browser

functionality and develop application add-ons for

Mozilla Firefox through one specific technology

such as XUL (XUL, 2013a).

The objective of this paper is to analyse the

appropriateness of the set of accessibility guidelines

defined for XUL technology. For achieving this

objective, an accessible add-on for augmenting

Mozilla Firefox browser functionalities has been

developed. In the development process, a

Valencia X., Arrue M., Rojas-Valduciel H. and Moreno L..

Interdependent Components for the Development of Accessible XUL Applications for Screen Reader Users.

DOI: 10.5220/0004855200650073

In Proceedings of the 10th International Conference on Web Information Systems and Technologies (WEBIST-2014), pages 65-73

ISBN: 978-989-758-024-6

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

comprehensive inclusive design paradigm has been

applied, including UCD approach and user testing.

User testing was performed by two screen reader

users. Several accessibility barriers were observed in

the testing which were later on evaluated by an

expert screen reader user who works as an

accessibility consultant. As a result, a review of the

XUL accessibility guidelines and conclusions of the

development process carried on are presented.

2 OVERVIEW

2.1 XUL

XUL (XML User Interface Language) is a XML

based language to create User Interfaces (UIs), in the

Mozilla platform. The main goal of the language is

to allow easy development of cross-platform add-on

applications which run on any Mozilla integrated

platform.

It separates the program logic from the user

interface components, facilitating the work of the

designers and programmers. This approach is also

applied in languages like (QML, 2013) or (XAML,

2013).

XUL is based on existing standards such as

XML, HTML, CSS, DOM and Javascript. In

addition, the Cross-Platform Component Object

Model (XPCOM) technology can be applied

(XPCOM, 2013) when operating system

functionalities are required.

2.2 Related Work

In the development processes, technological, human

and legislative aspects must be considered in order

to manage accessibility issues. Consequently, related

work from numerous disciplines should be taken

into account. In the standardization field, the W3C

ought to be highlighted along with the Web

Accessibility Initiative (WAI) (WAI, 2013). The

Web Content Accessibility Guidelines (WCAG) 2.0

(WCAG 2.0, 2008) is one of the most important

components, and is viewed as the official standard.

The ISO 9241-210:2010 standard provides a

framework for following and incorporating a UCD

approach into a particular context of accessibility.

Following methods that integrate usability and

accessibility in products design processes will

ensure that users with and without disabilities could

be able to access. This is the distinguishing

characteristic that User Sensitive Inclusive Design

(Abascal et al., 2007) has; the user with disabilities

is in mind. This work is focused on carrying out user

testing technique in order to validate the

accessibility included in a web application.

Several works related to XUL and accessibility

has been found in the literature. These research

works are related to developments of browser

extensions for Mozilla Firefox. All of them are

oriented to people with disabilities (Mirri et al.,

2011) (Hanson et al., 2005).

Nevertheless, very few articles have been found

that directly address the question of how to model

accessibility according to the WCAG (Moreno et al,

2013), (Martin et al, 2010). An interesting attempt

meriting particular mention is the Dante approach

integrating the Web Authoring for Accessibility

(WAfA) ontology (Yesilada et al, 2004) (Harper and

Yesilada, 2007) for the visually impaired into

WSDM (Plessers et al, 2005).

2.3 XUL Accessibility Guidelines

XUL language is based on web standards so its

accessibility guidelines do not differ too much from

previously published web accessibility guidelines.

The XUL accessibility guidelines are divided in

six different sections: Keyboard Access, Assistive

Information, Display, Human Computer Interaction,

Media and Custom Widgets (XUL, 2013b). Each of

one has a set of checkpoints to verify. For instance,

the guideline Keyboard Access defines eight

checkpoints that should be considered: one related

to tab order, another one to keyboard shortcuts and

so on.

All the guidelines and the related checkpoints

can be seen as an accessibility checklist to be

considered in order to evaluate the accessibility of a

developed add-on application. The XUL

accessibility guidelines document states a pass/fail

statement to each checkpoint which could be applied

in order to elaborate a checklist easy to verify by

developers at design time. Table 1 presents the

checklist for evaluating XUL accessibility

guidelines.

3 EXPERIMENTAL DESIGN

3.1 Object of Study

The object of study is to analyse the appropriateness

of XUL Accessibility Guidelines for the

development of accessible XUL-based applications.

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

Table 1: XUL accessibility checklist.

1.1 Logical tab order is provided

1.2

Keyboard functionality is provided for

inaccessible features such as the column picker

or added features such as column sorting

1.3

Keyboard alternatives are provided for

toolbarbutton functionality

1.4

Keyboard shortcuts are present for important

functionality

1.5

Context menus are triggered by the

oncontextmenu event handler

1.6

All mouse operations have keyboard accessible

equivalents

1.7

All scrollable elements are controllable with the

keyboard

1.8

Keyboard focus is maintained and does not move

unexpectedly

2.1

Alternative text is provided for meaningful

images

2.2

All windows, including dialogs and wizards,

have a descriptive title

2.3

Every form element has an associated label and

radiobuttons are encapsulated in a groupbox

3.1 System settings are maintained

3.2

Color alone is not used to convey meaning and

sufficient contrast exists between font color and

background color

3.3 Visual elements and containers resize gracefully

4.1

Help documentation is provided including a

description of keyboard shortcuts

4.2

Alerts are displayed using the alert scripting

function or the notification box element

4.3

Interactive elements are sufficiently large and

visible

4.4

Alerts are presented when the user initiates an

error. The user has the opportunity and

instruction to fix the error

4.5

User is informed of time limits and has control of

response time when appropriate

5.1 Transcripts are provided for audio tracks

5.2 Video is captioned and a transcript is provided

5.3

User has control over animation and is warned

about flashing content

6.1 Custom widgets provide accessible functionality

3.2 Experiment Context

Following XUL accessibility guidelines, a XUL-

based application has been developed. Its

accessibility has been evaluated using the XUL

Accessibility Checklist (see Table 1). The developed

application is an add-on for augmenting Mozilla

Firefox browser functionalities.

Figure 1: Demographic information form.

3.3 Sample

The add-on application for Mozilla Firefox includes

several pages with different type of web content.

For this study, two web pages containing forms

have been selected. The selection of such type of

application was due to the following reasons: the

diversity of elements included in it, importance of

accessibility in order to get to each question of the

forms and fill it in and the high interaction it

requires from users (Lazar et al., 2007).

The questions that users are required to fill in are

about demographic information, emotional aspects

and issues related to the design of the visited web

pages. These forms are presented to the user after

some specific time interval browsing in a website.

Figure 1 shows one the forms developed based on

XUL.

Forms were implemented using the following

XUL elements: Window, Radiogroup/Radio,

Textbox, Label/Description, Image, Button,

Hbox/Vbox/Box, DialogHeader and Spacer.

The developed forms share a similar structure.

We can resume this XUL structure in the following

way:

• Each form is a Window element which has a Box

as a container of the form.

• The title of the form is defined with a

DialogHeader element.

• Description elements have been included for

providing explanations.

The input elements are one of the following: text

inputs, number inputs and radio inputs. In Figure 2

an extract of a XUL document is shown.

InterdependentComponentsfortheDevelopmentofAccessibleXULApplicationsforScreenReaderUsers

As it can be appreciated in Figure 2, a label has

been attached to the radiogroup through the control

attribute. This mechanism ensures that assistive

technologies would adequately present the form to

the user.

Figure 2: XUL extract for demographic information form.

The other input elements have been implemented

similarly, ensuring that all title values are unique and

that all labels were attached to the corresponding

input element

The implemented application was verified by

developers using the checklist presented in Table 1.

Not all the checkpoints are relevant to the developed

application as some of them are considered content

not usually present in common forms. The results

obtained in this initial evaluation are presented in

Table 2.

All checkpoints in the checklist were fulfilled

with the exception of item 4.1, the help function. It

was decided not to include this function in this

preliminary version. However, for upcoming

development iterations, the help function will be

incorporated. In conclusion, we would not expect

interaction problems with the application as almost

checkpoints were fulfilled. Therefore, accessibility

of the application was ensured.

3.4 Participants

Two screen reader users with more than 6 years of

expertise browsing the web were recruited for the

user testing: a woman (User 1) and a man (User 2)

whose ages were 30 and 40 respectively. User 1

considered herself as an intermediate Web browser

user whereas User 2 considered himself as an

advanced user.

They both use JAWS, but one of them (User 1)

uses it infrequently as she prefers to use VoiceOver

screen reader on Mac OS operating system. User 2

uses Windows and JAWS, but he does not usually

use Firefox. Even though, both are Mozilla Firefox

sporadic users.

The experimental sessions were carried out in the

same lab. They were asked to bring their laptop so

they used JAWS configured with their personal

preferences. The platform used was similar for both

users: Windows operating system (User 1 used

Windows XP and User 2 used Windows 7), JAWS

12 and Mozilla Firefox 22. Users were encouraged

to report any barrier they detect when interacting

with the XUL application. The sessions were

recorded with a camera located behind the user in

order to obtain information about the interaction.

The interviews were taped with a voice recorder.

Table 2: The XUL accessibility checklist applied.

1.1 The tab order works correctly

1.4 Buttons have shortcuts

1.6

All actions are accessible from keyboard and

mouse

1.7 The scroll can be done with the keyboard

1.8 The focus works as expected

2.1

The images have no alt text since are targeted to

other users and it has nothing meaningful for

blind

2.2 All windows have different titles

2.3 Labels are connected with their input element

3.1 Elements size has been set using “em” units

3.2

Elements colour have not meaning and the fonts

and background has enough contrast

3.3

Flex elements has been used to avoid unexpected

UI behaviours.

4.1 It is not provided in this draft version

4.2

Alerts are displayed using the alert scripting

function

4.3 Form is clearly differentiated

4.4 Uncompleted form or errors are advised

In addition, an expert evaluation was performed by

an expert screen reader user who has been working

as ICT accessibility consultant at least for the last

five years. All the evaluation was carried on at her

usual working setting, and reported her findings by

email.

3.5 Procedure

First, the XUL application was installed on users’

laptop. Then, all users were asked to perform two

tasks. The first one consisted on freely navigate

during five minutes in a concrete website

(www.discapnet.com). Then, the application

presented the first form to complete. The questions

in this form were related to their navigation

experience. The second task consisted on a search

task on the same website with a limited time interval

of ten minutes. Finally, the application presented the

second form containing questions related to

demographic data.

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

4 RESULTS

4.1 User Testing

4.1.1 User 1

This user experienced several barriers when filling

in the forms developed with XUL. The barriers

reported by the user are the following. Besides,

related XUL guidelines are indicated in each case:

 Barrier 1.1: She was unable to know which answer

option was checked in the multiple-choice type

questions. This occurred when the user wanted to

verify that the selected answer was the correct one.

She navigated with the virtual cursor of JAWS and

it read the labels correctly. However, it only read

the value of the option and informed that it was not

checked even if it really was checked. Therefore,

we had to tell her which option was selected in

order to ensure that it was the desired one. (Related

guideline: 2.3)

 Barrier 1.2: She experienced navigation problems.

Surprisingly, when she filled in a multiple-choice

question, JAWS focus was moved to the first

question of the form. Then, she had to navigate to

the next question from the beginning of the form.

This happened even though the program focus was

at the correct position. (Related guidelines: 1.1,

1.8)

 Barrier 1.3: JAWS shortcuts navigation feature did

not work properly. Due to the difficulties she was

having, she tried to navigate through the form

using the JAWS shortcuts, like for instance, forms

or headings shortcuts but it did not worked as

expected. (Related guideline: 2.3)

 Barrier 1.4: Problems for clicking on a button. She

was unable to find the button to continue. The

button was located at the end of the form and was

accessible using tab or arrows. However, JAWS

did not correctly detect this element. (Related

guideline: 2.3)

4.1.2 User 2

This user experienced similar problems reported by

User 1 except of Barrier 1.3 (he did not try this

mode of navigation). In addition, he reported other

barriers:

 Barrier 2.1: Problems with text input questions.

JAWS was unable to detect a text area element

even if the focus was on one. Sometimes, he

reported listening a label that was not the correct

one. (Related guideline: 2.3)

 Barrier 2.2: Alert messages were not adequately

presented. JAWS detected the alert windows but

not the containing text. Therefore, he only could

hear the default sound of the alert and “OK” button

but he missed the alert message. (Related

guideline: 4.2)

 Barrier 2.3: Problems with numeric type inputs.

Firefox adds special controls for this type of

inputs. These controls are for entering the numeric

value using two small buttons inside the element,

one of them for increasing the value and the other

for reducing it. These controls entered into conflict

with his navigation controls. They are activated

with keyboard arrows which were the navigation

mode used by this user. Consequently, he was

unable to correctly enter his age. (Related

guidelines: 1.6, 2.3)

 Barrier 2.4: JAWS read not existing options in the

UI. He reported us that JAWS sometimes read text

elements that were not in the UI. (Related

guideline: 2.3)

4.1.3 Discussion of Results

The user testing carried on indicates that there are

quite accessibility barriers in the developed XUL

application, even if accessibility guidelines have

been considered.

Some of the detected barriers are high impact

ones as users could not complete the tasks without

any assistance, for instance, barrier 1.4 (Problems

for clicking on a button) experienced by both users.

This barrier is related to activating the submit button

of the forms. Users could not get to these buttons so

they could not complete the tasks on their own.

These types of barriers are accessibility problems,

which should be documented in the accessibility

guidelines. In the group of accessibility barriers

should be also included the following ones: Barrier

1.1, Barrier 2.1, Barrier 2.2 and Barrier 2.3.

Other group of barriers detected in the user

testing were of moderate impact, as they do not

compromise the accessibility of the application.

However, they make the application less usable and

users can be disappointed inducing negatively in

their accessibility perception. These barriers should

be erased as well for ensuring a satisfactory user

interaction. For instance, Barrier 1.3 (JAWS

shortcuts navigation feature did not work properly)

user has other alternatives of navigation with the

screen reader so this problem does not compromise

the correct completion of tasks. Even though, the

inexistence of this barrier makes the application

more usable and user experience could be more

satisfactory. In the group of usability barriers should

InterdependentComponentsfortheDevelopmentofAccessibleXULApplicationsforScreenReaderUsers

be also included the following ones: Barrier 1.2 and

Barrier 2.4.

The detected barriers influenced negatively in the

user satisfaction when interacting with the XUL

application and they both needed around 15 minutes

to fill in each form. Considering that each form

consisted of ten short questions the time spent is not

acceptable.

There are remarkable differences between the

results obtained by each user. User 1 detected only

two high impact barriers (Barrier 1.1 and Barrier

1.4) whereas User 2 experienced more barriers of

this type (Barrier 1.1, Barrier 1.4, Barrier 2.1,

Barrier 2.2 and Barrier 2.3). They both used the

same version of the screen reader but the navigation

strategies applied can differ a lot from user to user.

In addition, our opinion is that User 1 is a more

experienced user. Our observation in the

experimental sessions revealed that User 1 has a

wide range of knowledge about functionalities of

screen readers. This observation differs from the

perception of their own expertise as User 1 defines

herself as an intermediate user and User 2 as an

advanced one.

All in all, accessibility guidelines should

consider all potential barriers independently of

assistive technology version used, navigation

strategies applied and user expertise level.

4.1.4 Improvements to XUL Guidelines

As can be seen most of the barriers are related to

those guidelines regarding form elements, like the

guideline 2.3 or the keyboard related issues 1.1 or

1.8.

Tagging labels with the corresponding control

seems to be not enough. It is essential to correctly

identify all questions and provide mechanisms in

order to alert user and assistive technology about the

existence of a list of questions or choices. Adding a

new XUL element to tag the whole form would

allow assistive technologies to handle better the

information and also ensure the correct behaviour of

the screen reader cursor.

Orientation of screen reader users would

considerably improve by applying a simple good

practice: informing at the beginning of the form

about the total number of questions in it and

numbering each question.

Regarding the keyboard, the added controls and

shortcuts could create conflicts with browser

controls or shortcuts as well as with assistive

technologies controls. In this sense, information

about the shortcuts available in the most used

assistive technologies would be helpful. This would

allow a better and more efficient navigation to the

user and would avoid unexpected technology

behaviour.

Finally, for the alert message issues, instead of

using the standard alert element, the

“notificationbox” should be used. In our preliminary

tests, this element seemed to work better with

JAWS. However, it may cause inconveniences to

other type of users such as those using magnifiers.

Another alternative solution could be to apply alert

functions on the active window. This issue requires

more investigation to carry on.

4.2 Expert Evaluation

Due to the distinct results obtained by the users and

in order to obtain a factual knowledge of the

situation; a review process was conducted by an

expert blind screen reader user. She is a consultant

on ICT accessibility.

She was asked to conduct a test with different

versions of JAWS, Firefox and operating systems. A

summary of the testing can be found in Table 3.

Results of the testing show the strong dependency

that XUL accessibility features have with the user

agent, the operating system and version of the screen

reader. For instance, checkpoint 2.2 “All windows

have different titles” only can be correctly detected

if the user interacts with the application on a

Windows 7, JAWS 13 and Firefox 23 platform. The

fulfilment of checkpoint 2.2 is not so essential for

user interaction (the user could complete a task even

if the title of windows are not correctly presented).

However, the same platform is required for

checkpoint 2.3 “Labels are connected with their

input element”. This checkpoint is essential if the

user is supposed to access and fill in questions

presented in a form.

The expert noted that Firefox generates

inaccessible HTML elements for the application

interface. Therefore, JAWS does not correctly read

them to the user. This is due to the way JavaScript

implements and interprets the DOM. Visually, the

element appears in the interface, but it is as if the

element was non-existent in the DOM. The screen

reader just ignores it.

In conclusion, the latest version of Firefox and

JAWS (at least versions JAWS 13 and Firefox 23)

seems to be the best combination for using the

developed XUL application. Nevertheless, it is

unusual that users have the latest versions of screen

readers. The same occurs with browsers. Most of

screen reader users use outdated browser versions

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

since the cursor mode of JAWS does not work with

the latest versions. Sometimes this mode is

necessary in order to access user interface elements

that cannot be read as usually.

Table 3: Correspondence of XUL accessibility checklist

with the expert review results.

1.1 Only in Firefox 23.

1.4 Better using Firefox 23

1.6 Only using Firefox 23

1.7 Only using Firefox 23

1.8 JAWS 13 and Firefox 23

2.1

When running the extension on Windows 7,

using Firefox 23

2.2 Windows 7, JAWS 13 and Firefox 23

2.3 Only using JAWS 13 and Firefox 23

3.1 Good feature for low vision using a magnifier

3.2 Good feature for low vision

3.3 Better using Firefox 23 and JAWS 13, JAWS 14

4.1 -

4.2 Better using Firefox 23

4.3 When refreshing the virtual buffer of JAWS,

refresh the page or when the form is being read

automatically

4.4 Only using Firefox 23 JAWS 13 and Windows 7

Some suggestions for improving the current version

of the developed XUL application were indicated by

the expert:

 The text for the questions should be defined as a

header element.

 The multiple-choice questions should define the

possible answers as a list element.

 Users should be provided by an input text element

for introducing the answer. This suggestion would

increase the form response time, therefore it would

be less efficient and usable. However, it would be

accessible for screen reader users.

Implementing these suggestions would overcome

some of the most significant problems that users will

have probably to face to. Mainly when they do not

use the latest versions of browser and screen reader.

5 LESSONS LEARNED

From the results obtained in user testing and expert

evaluation, it is clear that there are extremely

important accessibility barriers in the developed

XUL application. The user testing can bring up

problems that have not been detected previously.

Findings reported in section 4 also highlight the

importance of testing applications with different

versions of Firefox and screen reader. There are too

many differences between versions and possible

combinations. Each combination has its strengths

and weaknesses. Using the latest versions of each

one seems to be the best solution. Even though,

many people do not update their software,

principally, due to the price of these updates. But

sometimes there are some functionalities that the

user is used to, that he cannot leave behind. For

these reasons, it is crucial to ensure that the

developed applications can be used in the wider

range of versions as possible.

User agent developers should consider the

accessibility barriers detected in this work. Universal

access to existing augmented browser applications

can be guaranteed only if inclusion design

paradigms are adequately defined and applied.

In the mean time, a transitory solution could be

to transform the application into a browser XUL

element to display the forms coded in HTML inside

the XUL code. As HTML accessibility issues have

been more analysed and considered in the last

decades. A great amount of documentation, tools

and methods exist for making accessible HTML

code. It would avoid the creation of the keyboard

scripts, because the keyboard behaviour would work

as expected and also reduces the workload. But the

main advantage is that it would make possible a

higher compatibility between different Firefox

versions and screen readers.

Anyway, XUL accessibility guidelines should be

reviewed in order to update issues regarding

keyboard navigation, assistive technologies

compatibility, forms elements tagging, etc. Not only

to ensure that all elements are accessible but

guarantee also the HTML-like behaviour so users do

not get confused or disoriented during the

interaction.

6 CONCLUSIONS

Web access to all users should be ensured, including

people with disabilities who use assistive technology

to access ICTs. Many organizations are concerned

about this issue, and they work towards accessibility

compliance. This is the case of the Mozilla

Foundation that provides accessibility guidelines to

apply when developers use their technologies like

XUL.

This paper presents a study of XUL and its

accessibility guidelines. We have developed an

application for augmenting browser functionalities

in XUL. The development process considered UCD

approach with the aim of creating an accessible

InterdependentComponentsfortheDevelopmentofAccessibleXULApplicationsforScreenReaderUsers

application with form content type. User testing with

2 legally blind users was carried on in addition to

accessibility guidelines conformance evaluation. The

developed application seemed to be accessible

according to XUL accessibility guidelines. However,

the results gathered in the user testing indicated

important accessibility barriers. Some of the

detected barriers make the application not operable

for screen reader users.

An expert evaluation has also been considered in

this paper. A screen reader user with more than five

years of experience as a consultant on ICT

accessibility has conducted the review. The results

reveal a strong dependence between platform used

(versions of user agent, operating system and screen

reader) and the accessibility barriers experienced by

users.

The findings of this paper should be considered

in next versions of XUL accessibility guidelines.

Some of them could be included as guidelines

whereas others could be considered as best practices.

This research was oriented to screen reader users

and XUL applications containing forms. In the near

future, there is a need of performing evaluation

studies with more content type, other groups of users

and other assistive technologies. Therefore, future

work will be motivated to the evaluation and

improvement of other XUL accessibility checkpoints

not considered in this work. This research work will

lead to ensure universal access to Mozilla Firefox

add-on applications.

ACKNOWLEDGEMENTS

The authors gratefully acknowledge the support of

the Spanish Ministry of Science and Innovation

through Project ModelAccess (TIN2010-15549) and

the MULTIMEDICA project (TIN2010-20644-C03-

01).

EGOKITUZ is supported by the Department of

Education, Universities and Research of the Basque

Government (Eusko Jaurlaritza/Gobierno Vasco)

through Grant# IT-395-10.

REFERENCES

Abascal, J and Azevedo, L. Fundamentals of Inclusive

HCI. Design. (2007) Universal Access in Human

Computer Interaction, 4th International Conference on

Universal Access in Human-Computer Interaction,

UAHCI 2007, Held as Part of HCI International 2007,

Beijing, China, July 22-27.

Greasmonky (2012) http://wiki.greasespot.net/Main_

Page.

Hanson, V. L., Brezin, J., Crayne, S., Keates, S.,

Kjeldsen, R., Richards, J. T., Swart, C., & Trewin, S.

(2005). Improving Web accessibility through an

enhanced open-source browser. IBM Systems Journal,

44 (3), 573 - 588.

Hanson V. L., Richards. J. T., and Swart. C., (2008)

Browser augmentation, Harper S. and Yesilada Y,

Web Accessibility, Springer London, pp. 215-229.

Harper, S. and Yesilada, Y., (2007). Web Authoring for

Accessibility (WAfA). Web Semantics: Science,

Services and Agents on the World Wide Web. 5, 3, pp.

175-179.

Lawton S, H. (2007) Just Ask: Integrating Accessibility

Throughout Design. Madison,: ET\Lawton, available

at www.uiAccess.com/justask/

Lazar J, Allen A, Kleinman J, Malarkey C. (2007) What

Frustrates Screen Reader Users on the Web: A Study

of 100 Blind Users, International Journal of human-

computer interaction, Taylor & Francis, 22 (3), pp.

247-269.

Martín, A, Rossi, G, Cechich, A and Gordillo, S. (2010)

Engineering Accessible Web Applications. An Aspect-

Oriented Approach. World Wide Web, Springer US

13 (4), pp. 419-440,

Mirri, S, Salomoni, P, and Prandi, C. 2011. Augment

browsing and standard profiling for enhancing web

accessibility. In Proceedings of the International

Cross-Disciplinary Conference on Web Accessibility.

ACM, New York, NY, USA, Article 5 , 10 pages.

Moreno L, Valverde F, Martínez P, Pastor O, (2013).

Supporting accessibility in Web engineering methods:

a methodological approach, January, 2013, Journal of

Web Engineering , RINTON PRESS, INC, ISSN: 12

(3&4), pp. 1540-9589.

Newell, A.F.; Gregor, P. (2000) User Sensitive Inclusive

Design: in search of a new paradigm. Proceedings on

the 2000 conference on Universal Usability, pp. 39-44.

Plessers P, Casteleyn S, Yesilada Y, De Troyer O, Stevens

R, Harper S, and Goble C (2005) Accessibility: A Web

Engineering Approach. In Proceedings of the 14th

International Conference on World Wide Web (WWW

’05) ACM, New York, NY, USA, pp. 353-362.

QML (2013) http://qt-project.org/doc/qt-5.0/qtquick/

qtquick-applicationdevelopers.html.

Stylish http://userstyles.org/

Turn off the Lights (2013) http://www.stefanvd.net/

project/turnoffthelights.htm.

WAI (2013) http://www.w3.org/WAI/

WCAG 2.0 (2008). http://www.w3.org/TR/WCAG20/

XAML (2013) http://msdn.microsoft.com/en-us/

library/ms752059.aspx.

XPCOM (2013) https://developer.mozilla.org/en-US/

docs/XPCOM.

XUL (2013a) https://developer.mozilla.org/en-US/

docs/XUL.

XUL Accessibility Guidelines (2013b)

https://developer.mozilla.org/en-US /docs/ XUL_

accessibility_guidelines.

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

Yesilada,Y., Harper, S., Goble, C. and Stevens. (2004) R.

Dante annotation and transformation of web pages for

visually impaired users. In The Thirteenth

International World Wide Web Conference. ACM,

New York, NY, USA, pp. 490-491.

InterdependentComponentsfortheDevelopmentofAccessibleXULApplicationsforScreenReaderUsers
