A Systematic Review on Performance Evaluation of Aspect-Oriented

Programming Techniques used to Implement Crosscutting Concerns

Rodrigo F. G. da Silva

, Marcelo A. Maia

and Michel S. Soares

Computing Faculty, Federal University of Uberlˆandia, Uberlˆandia, Brazil

Computing Department, Federal University of Sergipe, Sergipe, Brazil

Keywords:

Aspect-Oriented Programming, Systematic Review, Crosscuting Concerns, Performance.

Abstract:

Aspect-Oriented Programming (AOP) was proposed with the main objective of addressing an important soft-

ware quality principle that is modularization. The basic idea of the paradigm is to capture crosscutting con-

cerns as a programming abstraction called aspect. Since the introduction of aspects as a complement to object-

oriented programming, many evaluations and empirical studies were provided to the new paradigm, including

the application of a variety of software metrics in order to provide evidence of the beneﬁts or problems with

the new paradigm. There is no consensus about the impact on performance of the use of AOP techniques

to deal with crosscutting concerns. The use of AOP to implement crosscutting concerns and its impact on

performance is the motivation for this study. This paper explores further the evaluation of performance by

proposing a systematic literature review with the purpose of ﬁnding out how performance is affected by the

introduction of aspects. The result of this systematic review is that there has been few studies on scientiﬁc

literature concerning AOP and performance and most of these studies are too speciﬁc, and sometimes even

inconclusive. This article presents these miscellaneous results and how they were extracted from the literature.

1 INTRODUCTION

Currently, performance is one of the non-functional

requirements which has become of utmost relevance

for users. Performance is a pervasive quality of soft-

ware systems (Woodside et al., 2007) and is an im-

portant non-functional attribute to be considered for

producing quality software (Evangelin Geetha et al.,

2011). The performance of software systems is a

serious problem in many projects (Smith, 1990), as

it may cause delays, cost overruns, failures on de-

ployment, and even abandonment of projects. Even

tough, such failures are seldom documented (Wood-

side et al., 2007).

The growing demand for more complex software

which can be executed on several kinds of platforms

and architectures, with varied hardware constraints,

has been postulating that software can adapt to new

requirements, and performance becomes an impor-

tant feature. This feature, however, can be affected

by many elements in a Software Engineering process.

One of these elements is related on how crosscutting

concerns are implemented in software.

Aspect Oriented Programming (AOP), ﬁrst pre-

sented by Kiczales (Kiczales et al., 1997), came as

an attempt to deal with the crosscutting concerns aim-

ing to improve modularization. AOP has gained im-

portant interest since its introduction to implement

crosscutting concerns, with varying degree of suc-

cess (Ali et al., 2010) (Przybylek, 2011) (Mortensen

et al., 2012) (Franc¸a and Soares, 2012). Within AOP,

crosscutting concerns are implemented as aspects and

are further weaved into code. The way aspects are

weaved into code may affect performance as the as-

pect weaving process introduces new code to the orig-

inal programs.

There are different approaches to accomplish as-

pect weaving (Hundt and Glesner, 2009): Compile-

time weaving which weaves the aspect in a static

way into the original code, Run-time weaving which

weaves the aspect dynamically at runtime, and Load-

time weaving which delays weaving of crosscutting

concerns until the class loader loads the class ﬁle and

deﬁnes it to the Virtual Machine (Dyer and Rajan,

2010).

Because there are different constructions intro-

duced in AOP languages and because there are dif-

ferent ways to implement those constructions, we can

expect that a speciﬁc running system implemented

with AOP may have speciﬁc impact in its perfor-

F. G. da Silva R., A. Maia M. and S. Soares M..

A Systematic Review on Performance Evaluation of Aspect-Oriented Programming Techniques used to Implement Crosscutting Concerns.

DOI: 10.5220/0004863800050013

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 5-13

ISBN: 978-989-758-028-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

mance compared for example with traditional proce-

dural languages such as C, which is widely known for

producing high performance executables. This con-

cern that also existed when introducing dynamic bind-

ing in object-oriented languages, is equally expected

to exist in aspect-oriented languages, specially when

we consider runtime and load-time weaving, because

if the corresponding operation is moved away from

the compilation it is expected that it will impact in

runtime or load-time.

The impact on performance, caused by AOP tech-

niques, has motivated previous works in scientiﬁc lit-

erature. Liu (Liu et al., 2011) showed that the aspect-

oriented approach does not have signiﬁcant effect on

performance, and that in some cases, aspect-oriented

software even outperform the non-aspect one. Ad-

ditionally, introduction of a large number of join

points does not have signiﬁcant effect on perfor-

mance. Remko (Bijker, 2005) assessed the perfor-

mance effects between programs created by a weaver

and a hand-coded version. This work came to the con-

clusion that simple advices give no real performance

penalties, but the more sophisticated advices are, the

slower they become, and this impact can reach more

than 100 percent of penalty. Kirsten (Kirsten, 2005)

compared the four leading AOP tools at the time

(2004) and, when it comes to performance, he pos-

tulated that, in general, code with aspects performs

similarly to that of a purely object-oriented solution,

where the crosscutting code is scattered throughout

the system. Nonetheless, some performance over-

head may be noticed either in build-time or in run-

time, depending on the used AOP approach. Kirsten

also showed the tools’ language mechanisms and the

trade-offs imposed by the different approaches, as

well as the tools’ integration with the development

environment and build process, including a point-by-

point comparison of the tools’ IDE features and pro-

viding a summary of each one’s strengths and weak-

nesses.

The use of AOP to implement crosscutting con-

cerns and its impact on performance is the motivation

for this study. The goal of this systematic review is to

understand the extent of the impact of AOP on the per-

formance of software systems, if there is an impact.

Our main result reveal that there has been few stud-

ies on scientiﬁc literature concerning AOP and per-

formance and most of these studies are too speciﬁc,

and sometimes even inconclusive. There is a lack of

studies in which an in-depth focus on performance

is taken into account. For instance, there are many

variables that can inﬂuence the studies that should be

taken into account, such as different crosscutting con-

cerns, different kinds of AOP implementation, differ-

ent weaving processes, and different tools. In addi-

tion, as this research presents, there is no consensus

about the impact on performance of the use of AOP

techniques to deal with crosscutting concerns. The

reason for this is probably because there are too many

concerns and several kinds of AOP tools and tech-

niques to be evaluated. This paper shows these mis-

cellaneous results and how they were extracted from

scientiﬁc literature. We expect to show that this is an

open ﬁeld for further research.

The remainder of this article is organized as fol-

lows. In Section 2, we present the research method

used for this systematic review. In Section 3, the re-

sults are presented and evaluated. In Section 4, we

discuss the results and ﬁnally in Section 5 we provide

the conclusion of this work.

2 RESEARCH METHOD

The main question that motivated this research is:

Does the use of aspect-oriented techniques to imple-

ment crosscutting concerns impact software perfor-

mance ? A derived research question is “If the im-

pact exists, how meaningful is it ?”. The answer to

both questions could help developers to reason about

the feasibility of the use of AOP techniques to handle

crosscutting concerns on architectures where perfor-

mance is itself a concern, as in embedded platforms.

In order to answer both questions, a systematic

literature review (Kitchenham, 2004) has been made

with the purpose of identifying what type of research

has been performed relating AOP and performance.

The systematic review started with searching in a

number of software engineering conferencesand jour-

nals. The search was performed considering publica-

tions in the past 6 years. Although the seminal works

on aspects were published in the late 1990’s, we want

to evaluate most up-to-date articles, therefore only the

last 6 years were considered.

The chosen conferences were: AOSD (Interna-

tional Conference on Aspect-Oriented Software De-

velopment) and ICSE (International Conference on

Software Engineering). Papers published on spe-

ciﬁc workshops held together with these conferences

were not considered. The chosen journals were:

JSS (Journal of Systems and Software), IST (Infor-

mation and Software Technology), SCP (Science of

Computer Programming), TSE IEEE (IEEE Trans-

actions on Software Engineering), TOSEM (ACM

Transactions on Software Engineering Methodology).

ENTCS (Electronic Notes in Theoretical Computer

Science), which can be considered a series, was also

included.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

Table 1: Search Results and selected papers.

Publication Retrieved Papers Relevant Papers Selected Papers Data Source

JSS 38 2 1 ScienceDirect

IST 32 10 5 ScienceDirect

SCP 32 2 1 ScienceDirect

TSE 1 1 1 IEEExplorer

TOSEM 21 3 1 ACM Digital Library

ENTCS 26 3 1 ScienceDirect

AOSD 127 9 3 ACM Digital Library

ICSE 61 2 2 ACM Digital Library

Total 338 32 15

The search string used was (“Aspect-oriented pro-

gramming” AND “performance”). The search has re-

trieved 338 papers. From these 338 papers, a sub se-

lection has been made with the purpose of separating

those relating AOP with any performance metrics. In

a ﬁrst step, 32 papers were selected and classiﬁed as

relevant. For the ﬁrst selection, the title, the keywords

and the abstract were read. If the subject was perti-

nent to AOP and performance, the introduction and

the conclusion were read as well. In case of doubt

about the relevance of the paper, speciﬁc keywords

were searched in the paper, such as aspect, crosscut-

ting and performance. There were also relevant pa-

pers which used other terms, including cost, payload

and overhead when considering assessment of perfor-

mance of some AOP technique, and in those cases,

they were selected too.

Table 2: Selected papers.

Venue/year Reference

1 ICSE/07 (Froihofer et al., 2007)

2 SCP/08 (Fabry et al., 2008)

3 IST/09 (Georg et al., 2009)

4 ENTCS/09 (Hundt and Glesner, 2009)

5 IST/09 (Ganesan et al., 2009)

6 ICSE/09 (Zhang, 2009)

7 AOSD/09 (Cannon and Wohlstadter, 2009)

8 JSS/10 (Malek et al., 2010)

9 ACM/10 (Dyer and Rajan, 2010)

10 IST/10 (Ortiz and Prado, 2010)

11 AOSD/10 (Toledo et al., 2010)

12 IST/10 (Janik and Zielinski, 2010)

13 AOSD/10 (Ansaloni et al., 2010)

14 IEEE/12 (Mortensen et al., 2012)

15 IST/12 (de Roo et al., 2012)

In a second step, of the 32 relevant papers, only

those ones which assess the performance of imple-

mentation of some crosscutting concern were selected

to be fully read. As a result, 15 papers were selected

in total. Several types of concerns have been clas-

siﬁed by the papers as crosscutting concerns, even

though some of them were domain speciﬁc. How-

ever, papers which had crosscutting concerns imple-

mented through some AOP technique but which did

not consider any assessment of the used technique(s),

or this assessment was incomplete, were discarded.

The summary of the ﬁltering process can be seen in

Table1 and the ﬁnal selection of papers is presented

in Table 2.

3 EVALUATION OF RESULTS

All 15 selected papers were fully read for the evalua-

tion. The selected papers were evaluated based on two

sets of criteria: Application Type and Performance.

This section classify the papers for both sets of crite-

ria.

3.1 Application Type Criteria

The ﬁrst set of criteria concerns about Application

Type and encompass the following metrics: number

of assessed studies, lines of code (Size, in LOCs),

original programming language (Original PL), aspect

programming language (Aspect PL) and application

domain.

The application type is related to the type of appli-

cation of the case studies or experiments which have

been assessed by the papers. The following types

were retrieved from the papers: Middleware, Web

Service, Embedded, Platform, System or Applica-

tion, Language or Extension (Language) and Frame-

work. Cases where their case studies were described

as Monitoring Systems were classiﬁed as System or

Application. Papers which did not mention the appli-

cation type of their experiments have been classiﬁed

under the closest deﬁnition of these ones already men-

tioned.

The number of assessed studies indicates only

those studies that were implemented by some AOP

technique and were assessed by some kind of metric.

Concerningthe metric lines of code (LOC), papers

showed LOC in different ways: SLOC (Source lines

of code), NCLOC (Non-Comment Lines of Code) and

ASystematicReviewonPerformanceEvaluationofAspect-OrientedProgrammingTechniquesusedtoImplement

CrosscuttingConcerns

Table 3: Summary of studies.

Application

Type

Article Assessed

studies

LOC / Size Original

Aspect PL Application

Domain

Middleware

(Malek et al., 2010) 2 NA

Java

AspectJ Generic

(Zhang, 2009) 3 12.7 KLOC,

113Kb,

190Kb

FlexSync

Industrial

Embedded

(Hundt and Glesner, 2009) 1 NA ObjectTeams,

Java

(de Roo et al., 2012) 2 NA GPL NA

Application

(Janik and Zielinski, 2010)

1 NA

Java

JBoss AOP Generic

System or (Ganesan et al., 2009) AspectJ Ofﬁce

(Cannon and Wohlstadter,

2009)

1 46KLOC Java, As-

pectJ

Generic

(Fabry et al., 2008)

1 NA

KALA Bank

(Froihofer et al., 2007) AspectJ,

JBoss AOP

Industrial

(Mortensen et al., 2012) 3 1.6 KLOC,

13.9 KLOC,

51.6 KLOC

C++ AspectC++

Language

(Toledo et al., 2010) 1 118 KLOC JavaScript AspectScript Generic

(Dyer and Rajan, 2010) 2

Java

NA Industrial

Framework (Ansaloni et al., 2010)

Compatible

with As-

pectJ

Generic

Platform (Georg et al., 2009) NA NA

E-commerce

Web Service (Ortiz and Prado, 2010) Java AspectJ

only LOC where no citation about source of com-

ments were made. Some papers showed size of the

applications instead of LOC. There were papers, how-

ever, which did not present any size or LOC of their

studies.

Several languages were identiﬁed in the papers

concerning the original languages and aspect lan-

guages. Some papers presented their own languages

or extensions in spite of using the most common pro-

gramming and aspect languages.

The application domain includes: e-commerce

(E-C), industrial application (Ind), Ofﬁce, Bank and

Generic. Cases where there is no speciﬁc domain,

for example a toolkit or a language extension, were

classiﬁed as Generic. Some papers, mostly in appli-

cation type, did not mention the application domain

and were also classiﬁed by proximity.

The summary of studies is presented in Table 3.

Cases where no metric was presented or in which

it was not possible to identify were classiﬁed as not

available (NA).

3.2 Performance Criteria

The second set of criteria concerns Performance. Four

metrics were extracted from the papers: weaving

type, implemented crosscutting concerns, used per-

formance method, and performance overhead.

The weaving type indicates the type of weaving

performed by the studies in the papers. Two main

kinds were considered: Compile-time and Runtime

weaving. Some papers presented studies by perform-

ing Load-time weaving process and these cases were

classiﬁed as Run-time weaving, as Load-time is a spe-

ciﬁc stage of Runtime.

Several kinds of crosscutting concerns were re-

trieved from the papers. There were cases where

the crosscutting concerns were domain speciﬁc. Pa-

pers which treated only one concern in the study pre-

vailed, but there were cases where more than one con-

cern was considered, one of them domain speciﬁc

(Mortensen et al., 2012).

The performance methods retrieved were the mea-

surements of running or execution time (ext), business

operations per second (bos), average memory over-

head (avmo), CPU usage (cpu), qualitative observa-

tion of the overall execution (obs), parsing time (pat),

and average number of method calls per second (met).

Some papers presented more than one assessed vari-

able. In these cases, when there was performance re-

duction, the considered measurements were based on

the worst case. The performance overhead was mea-

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

Table 4: Performance analysis of studies.

Weaving

Type

Article Implemented cross-

cutting concerns

Performance

Method

Performance over-

head

Run-time

(Malek et al., 2010) Stylistic ext, avmo ext: -negl, avmo:

+1.03x to 1.1x

(Zhang, 2009) Synchronization bos negl

(Hundt and Glesner, 2009) Maintainability, Exten-

sibility and Reusability

ext - 2x for 100 instances

(Janik and Zielinski, 2010) Reconﬁgurability ext, cpu, avmo ext: +1.1x to 1.22x,

cpu: +NA, avmo: +NA

(Ganesan et al., 2009) Monitoring Qualitative Ob-

servation

not notably

(Cannon and Wohlstadter,

2009)

Security pat + up to 1.16x

(Toledo et al., 2010) Expressiveness met, cpu met: + up to 16.1x, cpu:

negl

(Fabry et al., 2008) Transaction Manage-

ment

NA + NA

Compile-time

(Mortensen et al., 2012) Caching, Check-

FwArgs, Excepter,

Singleton, Tracing,

CadTrace, FwErrs,

FetTypeChkr, Timer,

UnitCvrt, ViewCache,

ErcTracing, QueryCon-

ﬁg, QueryPolicy

ext, avmo ext: + up to 1.18x,

avmo: + up to 1.15x

(Ansaloni et al., 2010) Comunication between

threads

ext + factor up to 31.08x

(Ortiz and Prado, 2010) Device adaptation ext negl

Compile-time

/ runtime

(Froihofer et al., 2007) Constraint validation ext + varies according to

approach

Domain Spe-

ciﬁc

(Dyer and Rajan, 2010) Cache met + 1.015x

(de Roo et al., 2012) Safety NA + NA

(Georg et al., 2009) Security ext + varies according to

approach

sured in factors (when comparable to the original im-

plementation) or percentage. Some cases related this

overhead as negligible (negl).

The results of the performance assessment per-

formed by the papers are presented in Table 4. In the

Performance Overhead column, the “+” and the “-’’

signs means decrease and increase in performance,

respectively. If a sign is followed by negl, it means

that the paper reported a degradation or gain in per-

formance, but this result is negligible according to the

authors.

4 DISCUSSION

Considering the fact that all the papers selected in

this systematic review were fully read, and all the 15

selected ones are about the implementation of cross-

cutting concerns through AOP techniques and perfor-

mance, important results can be extracted from this

research.

4.1 On the Target Applications

From the ﬁrst set of criteria, related to Application

type, it is possible to conclude that most papers, 10

out of 15, assessed only one study or experiment.

However, only four of them showed the LOC or

size of their assessed studies. The two studies that

have evaluated more systems, evaluated three small-

scale systems (at most 50KLOC or 190Kb). The

larger evaluated system had 118KLOC. One hypoth-

esis for such lack of large scale studies is that aspect-

oriented programming is not extensivelyadopted such

as object-oriented programming or procedural pro-

gramming. Therefore, the low adoption from the

ASystematicReviewonPerformanceEvaluationofAspect-OrientedProgrammingTechniquesusedtoImplement

CrosscuttingConcerns

Table 5: Application Type versus Performance.

Application

Type

Article LOC / Size Original

Aspect PL Application

Domain

Perf. Overhead

Middleware

(Malek et al., 2010) 12.3 KSLOC

Java

AspectJ Generic ext: -negl,

avmo: +1.03x to

1.1x

(Zhang, 2009) 12.7 KLOC,

113Kb,

190Kb

FlexSync

Industrial

negl

Embedded

(Hundt and Glesner,

2009)

NA ObjectTeams,

Java

- 2x for 100 in-

stances

(de Roo et al., 2012) NA GPL NA + NA

System or

(Janik and Zielinski,

2010)

Java

JBoss AOP Generic ext: +1.1 to

1.22x, cpu:

+NA, avmo:

+NA

(Ganesan et al., 2009) AspectJ Ofﬁce not notably sig-

niﬁcant

Application (Cannon and

Wohlstadter, 2009)

46KLOC Java, As-

pectJ

Generic + up to 1.16x

(Fabry et al., 2008)

KALA Bank + NA

(Froihofer et al., 2007) AspectJ,

JBoss AOP

Industrial

+ varies accord-

ing to the ap-

proach

(Mortensen et al., 2012) 1.6 KLOC,

13.9 KLOC,

51.6 KLOC

C++ AspectC++ ext: + up to

1.18x, avmo: +

up to 1.15x

Language

(Toledo et al., 2010) 118 KLOC JavaScript AspectScript Generic met: + up to

16.1x, cpu: negl

(Dyer and Rajan, 2010)

Java

NA Industrial + 1.15x

Framework (Ansaloni et al., 2010) Compatible

with As-

pectJ

Generic + factor up to

31.08x

Platform (Georg et al., 2009) NA NA

E-commerce

+ varies accord-

ing to the ap-

proach

Web Ser-

vice

(Ortiz and Prado, 2010) Java AspectJ negl

community restricts the availability of large systems

for experimentation.

The prevailing application type was System or

Application. That is reasonable to expect because in

general this kind of applications are more frequent

and more accessible. The prevailing application do-

main was Industrial applications followed by appli-

cations with no speciﬁc domain, hereby classiﬁed as

Generic. We can observe that there is reasonable vari-

ability in terms of Application Type and Application

Domain.

In Table 5, we combined the application type fea-

tures and the performance result in order to evaluate if

there is some inﬂuence of the application type in the

performance.

We could observe that in Middleware software the

overhead was negligible. In the category System or

Application, there is a tendency of more impact in the

performance.

The LOC seems not to inﬂuence because the

larger studies systems had negligible impact on ex-

ecution time and CPU performance. The Application

Domain also seems not to inﬂuence the performance

because of the high variation in the results. The ap-

plication domain did not present a clear inﬂuence in

performance. The Industrial domain, which has the

larger number of studies, had also presented negligi-

ble and positive impact in performance.

Finally, concerning the implemented crosscutting

concerns in the applications, there was no prevailing

concern in the studies, and surprisingly, none of the

studies implemented common concerns such as Log-

ging or Exception Handling. This can be an indicative

that the studied cases were not representative in terms

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

of typical aspect-oriented software.

4.2 On the Used Programming

Languages

The prevailing original programming language was

Java with 11 out of 15 studies and the prevailing as-

pect programming language was AspectJ with 6 out

of 15 studies. Here we can see that although Java

is the preferred target for aspectizing and AspectJ is

the preferred solution for aspects (concerning studies

on performance evaluation), we could observe stud-

ies on less common solutions, such as FlexSync, Ob-

jectTeams and KALA. This is a negative point for

those studies because the underlying aspect technol-

ogy may not be an adequate representativeof the com-

mon practice. JBoss AOP was present only in two

cases, and Spring AOP was not used in any of them.

Considering the impact of the programming lan-

guage in performance, we can observe that the orig-

inal programming language that has signiﬁcant num-

ber of studies is Java, but there was no clear indica-

tion that Java is an inﬂuence factor. In the same way,

AspectJ, which is the prevailing aspect language has

shown no direct inﬂuence on the performance because

it presented either negligible or positive impact in per-

formance. Although only two studies were carried out

with JBoss AOP, both studies have shown a positive

impact in performance.

4.3 On the Type of Weaving

From the second set of criteria, it is possible to con-

clude that run-time is the most common weaving type

process presented by papers in the experiments. One

of the reasons for this choice, instead of compile-time

weaving, is the fact that runtime weaving allows as-

pects to be added to the base program dynamically,

which is better for a context-aware adaptation of the

applications (Hundt and Glesner, 2009). Some pa-

pers not only used the runtime weaving process but

also extended it to adequate the process to their stud-

ies. Also concerning the weaving process, the papers

in general postulated that runtime weaving requires

more effort at runtime, impacting on performance, but

no proofs about this assumption was found in this re-

search.

4.4 On the Experimental Setting

Papers assessed their experiments in different ways,

but the prevailing performance metric was measure-

ment of execution time (ext). The performance over-

head varied according to a set of variables such as the

used approach, implemented concern, the aspect pro-

gramming language, weaving type process and the

used aspect weaver. This motivates the fact that to

reason about AOP and performance is not a trivial

task, and further research is necessary. There are

many variables that impact performance and a con-

trolled experiment is necessary to understand the im-

pact of each variable. The difﬁculty of this kind of ex-

periment is its multi-factor nature and in order to con-

trol the factors, a factorial design is required. The ad-

vantage of multi-factor experiments is that all paired

interactions can be analyzed. However, the number of

runs grows exponentially with the addition of factors.

Moreover, we know that one important and criti-

cal factor for performance evaluation is the workload

used for measuring the execution (Jain, 1991). In this

case, the workload is strongly inﬂuenced by the target

application, which deﬁnes several other sub-factors:

the kind of join points, pointcuts and advices, the ratio

of occurrence of AOP constructs and the other non-

AOP constructs, the requirement of the application

for speciﬁc type of weaving. Considering the space

for combination of levels for these factors, it is chal-

lenging (if not impossible) to ﬁnd a real world appli-

cation (or a set of them) that can have all the possi-

ble levels. Therefore, an alternative could be the de-

sign of a synthetic application that could be use as a

benchmark for performance evaluation of AOP tech-

niques. This benchmark would need to be meaningful

to mimic real world scenarios and would need to be

comprehensive to guarantee that all important factors

and their respective levels would be considered.

4.5 Threats to Validity

The short number of selected papers after the ap-

plication of the search string and the criteria to in-

clude papers for evaluation is a threat to validity of

results. A possible solution could be to include ad-

ditional venues in future research. However, in or-

der to assess if the recall of this approach was ade-

quate, we made a query in Google Scholar using the

same string (“Aspect-oriented programming” AND

“performance”). The query returned 10,400 results,

but the best ranked links did not showed relevant re-

sults for this research. Next, we decided to restrict the

string only to the title of the paper and only 12 results

were returned. We analyzed each one of the results

and only (Liu et al., 2011) was a new result that have

not already been selected. Therefore, we conclude

that our recall is fairly adequate.

ASystematicReviewonPerformanceEvaluationofAspect-OrientedProgrammingTechniquesusedtoImplement

CrosscuttingConcerns

5 CONCLUSION

This work showed through a systematic review and

the further analysis of the retrieved papers that there

are few experiments concerning AOP and perfor-

mance in scientiﬁc literature. More speciﬁcally, too

few experiments were reported about the performance

of AOP techniques when implementing crosscutting

concerns. From the results, it is clear that there is no

prevailing implemented concern in the studies. On

the contrary, most of the implemented concerns were

domain speciﬁc.

Most papers postulated that runtime weaving re-

quires more effort at run-time, impacting on perfor-

mance. However, according to the results of this re-

search, the weaving type process does not appear to

be the only factor that impacts performance. Other

variables such as the used aspect weaver, the imple-

mented crosscutting concern, the aspect programming

language and even the performance method of evalu-

ation could impact the performance results.

This systematic review about AOP and perfor-

mance address several research ﬁelds for future

works. We suggest that one of the possible rea-

sons that explain why performance evaluation of AOP

did not attract more attention from the community is

rooted in the complexity of establishing a comprehen-

sive design of experiment that could produce more

solid analysis on the impact of AOP in the perfor-

mance of running systems. For instance, the devel-

opment of synthetic benchmarks would help to ex-

plain the impact that transformed crosscutting con-

cerns through AOP have in real applications and in

what circumstances that impact occurs in the overall

performance.

ACKNOWLEDGEMENTS

The authors would like to thank CAPES

(www.capes.gov.br), CNPq grant 475519/2012-

4, FAPEMIG Grant APQ-01589-11, FAPEMIG grant

APQ-2086/2011 and Federal University of Sergipe

for the ﬁnancial support.

REFERENCES

Ali, M. S., Ali Babar, M., Chen, L., and Stol, K.-J. (2010).

A Systematic Review of Comparative Evidence of

Aspect-Oriented Programming. Information and Soft-

ware Technology, 52:871–887.

Ansaloni, D., Binder, W., Villaz´on, A., and Moret, P.

(2010). Parallel Dynamic Analysis on Multicores with

Aspect-Oriented Programming. In Proceedings of

the 9th International Conference on Aspect-Oriented

Software Development, AOSD ’10, pages 1–12, New

York, NY, USA. ACM.

Bijker, R. (2005). Performance effects of Aspect Oriented

Programming. Technical report, Twente University,

Enchede, The Netherlands.

Cannon, B. and Wohlstadter, E. (2009). Enforcing Secu-

rity for Desktop Clients using Authority Aspects. In

Proceedings of the 8th ACM international conference

on Aspect-oriented software development, AOSD ’09,

pages 255–266, New York, NY, USA. ACM.

de Roo, A., Sozer, H., and Aksit, M. (2012). Veriﬁcation

and Analysis of Domain-Speciﬁc Models of Physical

Characteristics in Embedded Control Software. Infor-

mation and Software Technology, 54(12):1432–1453.

Special Section on Software Reliability and Security.

Dyer, R. and Rajan, H. (2010). Supporting Dynamic

Aspect-Oriented Features. ACM Transactions on Soft-

ware Engeneering Methodology, 20(2):7:1–7:34.

Evangelin Geetha, D., Suresh Kumar, T., and Rajani Kanth,

K. (2011). Predicting the Software Performance Dur-

ing Feasibility Study. IET Software, 5(2):201–215.

Fabry, J., Tanter,

E., and D’Hondt, T. (2008). KALA: Ker-

nel Aspect Language for Advanced Transactions. Sci-

ence of Computer Programming, 71(3):165–180.

Franc¸a, J. M. S. and Soares, M. S. (2012). A Systematic Re-

view on Evaluation of Aspect Oriented Programming

using Software Metrics. In ICEIS 2012 - Proceedings

of the 14th International Conference on Enterprise In-

formation Systems, Volume 2, pages 77–83.

Froihofer, L., Glos, G., Osrael, J., and Goeschka, K. M.

(2007). Overview and Evaluation of Constraint Val-

idation Approaches in Java. In Proceedings of the

29th international conference on Software Engineer-

ing, ICSE ’07, pages 313–322, Washington, DC,

USA. IEEE Computer Society.

Ganesan, D., Keuler, T., and Nishimura, Y. (2009). Archi-

tecture compliance checking at run-time. Information

and Software Technology, 51(11):1586–1600. Third

IEEE International Workshop on Automation of Soft-

ware Test (AST 2008) Eighth International Confer-

ence on Quality Software (QSIC 2008).

Georg, G., Ray, I., Anastasakis, K., Bordbar, B., Toahc-

hoodee, M., and Houmb, S. H. (2009). An Aspect-

Oriented Methodology for Designing Secure Ap-

plications. Information and Software Technology,

51(5):846–864.

Hundt, C. and Glesner, S. (2009). Optimizing Aspectual

Execution Mechanisms for Embedded Applications.

Electronic Notes in Theoretical Computer Science,

238(2):35–45. Proceedings of the First Workshop on

Generative Technologies (WGT) 2008.

Jain, R. (1991). The art of computer systems performance

analysis - techniques for experimental design, mea-

surement, simulation, and modeling. Wiley profes-

sional computing. Wiley.

Janik, A. and Zielinski, K. (2010). AAOP-Based Dynami-

cally Reconﬁgurable Monitoring System. Information

and Software Technology, 52(4):380–396.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C., marc Loingtier, J., and Irwin, J. (1997).

Aspect-Oriented Programming. pages 220–242.

Springer-Verlag.

Kirsten, M. (2005). AOP@Work: AOP tools comparison,

Part 1: Language mechanisms. Technical report, IBM

Developer Works.

Kitchenham, B. (2004). Procedures for Performing Sys-

tematic Reviews. Keele university. technical report

tr/se-0401, Department of Computer Science, Keele

University, UK.

Liu, W.-L., Lung, C.-H., and Ajila, S. (2011). Impact

of Aspect-Oriented Programming on Software Perfor-

mance: A Case Study of Leader/Followers and Half-

Sync/Half-Async Architectures. In Proceedings of the

2011 IEEE 35th Annual Computer Software and Ap-

plications Conference, COMPSAC ’11, pages 662–

667, Washington, DC, USA. IEEE Computer Society.

Malek, S., Ramnath Krishnan, H., and Srinivasan, J. (2010).

Enhancing Middleware Support for Architecture-

Based Development through Compositional Weav-

ing of Styles. Journal of Systems and Software,

83(12):2513–2527.

Mortensen, M., Ghosh, S., and Bieman, J. (2012). Aspect-

Oriented Refactoring of Legacy Applications: An

Evaluation. IEEE Transactions on Software Engineer-

ing, 38(1):118–140.

Ortiz, G. and Prado, A. G. D. (2010). Improving device-

aware web services and their mobile clients through an

aspect-oriented, model-driven approach. Information

and Software Technology, 52(10):1080–1093.

Przybylek, A. (2011). Impact of Aspect-Oriented Program-

ming on Software Modularity. In Proc. of the 15th

European Conference on Software Maintenance and

Reengineering, pages 369–372.

Smith, C. U. (1990). Performance Engineering of Software

Systems. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA, 1st edition.

Toledo, R., Leger, P., and Tanter, E. (2010). AspectScript:

Expressive Aspects for the Web. In Proceedings of

the 9th International Conference on Aspect-Oriented

Software Development, AOSD ’10, pages 13–24, New

York, NY, USA. ACM.

Woodside, M., Franks, G., and Petriu, D. (2007). The Fu-

ture of Software Performance Engineering. In Future

of Software Engineering, 2007. FOSE ’07, pages 171–

187.

Zhang, C. (2009). FlexSync: An Aspect-Oriented Ap-

proach to Java Synchronization. In Proceedings of

the 31st International Conference on Software Engi-

neering, ICSE ’09, pages 375–385, Washington, DC,

USA. IEEE Computer Society.

ASystematicReviewonPerformanceEvaluationofAspect-OrientedProgrammingTechniquesusedtoImplement

CrosscuttingConcerns
