Analysing the Lifecycle of Future Autonomous Cloud Applications

Geir Horn

, Keith Jeffery

, Jörg Domaschka

and Lutz Schubert

University of Oslo, Olav Dahls hus, P.O. Box 1080, 0316 Oslo, Norway

Keith G Jeffery Consultants, 10 Claypits Lane, Shrivenham, U.K.

University of Ulm, 89069 Ulm, Germany

Keywords: Cloud Computing, Software Design, Autonomy, Adaptability.

Abstract: Though Cloud Computing has found considerable uptake and usage, the amount of expertise, methodologies

and tools for efficient development of in particular distributed Cloud applications is still comparatively

little. This is mostly due to the fact that all our methodologies and approaches focus on single users, even

single processors, let alone active sharing of information. Within this paper we elaborate which kind of

information is missing from the current methodologies and how such information could principally be

exploited to improve resource utilisation, quality of service and reduce development time and effort.

1 INTRODUCTION

Clouds are on the rise. A major problem is

heterogeneity of offered platforms and their

interfaces with consequent inability to port

applications. Traditional methodologies and

software engineering principles still dominate the

commercial software industry. These principles were

generated for single-user and typically single-

processor use, i.e. not for cloud concepts.

This paper argues the necessity to involve

additional skills beyond traditional software

development in order to master successfully the

Cloud deployment of an application. We describe

the application aspects that need to be provided as a

profile by the application owner; the characteristics

of Cloud platforms that are supplied by the platform

operator; the characteristics of the data used by the

application and the characteristics of the user input

must be provided by the user as a profile partly

modifiable for each individual execution of the

application. This information is metadata to be used

by the systems development process.

The main contribution of this paper is to identify

the data that must be considered for an effective

deployment, and show that the data requires

continuous monitoring to unlock the full benefits

offered by the elasticity and scalability of the Cloud.

This implies that the profiles may need continuous

monitoring and essentially that the application

owner needs to be aware of this application

lifecycle. Section 2 highlights the core aspects of

application deployment, and Section 3 identifies the

data needed for the deployment and the data profiles.

The results presented here base on the initial

work in the PaaSage project, and the architecture for

a system to support model driven autonomic

deployment and application adaptation is described

in Section 4. Although the PaaSage project is

working on implementing the necessary building

blocks, it is too early to report on the

implementation of the application lifecycle in this

paper.

2 ASPECTS OF APPLICATION

DEPLOYMENT

Current cloud applications are designed and

developed in much the same way as traditional

applications. The developer / provider only starts

thinking about the cloud specific characteristics once

he starts to deploy, respectively host the application.

In order to understand why traditional

engineering principles are insufficient and how they

need to change, it is necessary to analyse which kind

of factors play a role at executing the main Cloud

characteristics, including specifically:

1. sharing data (and computation)

2. replication and elasticity

3. (re)location and distribution

With traditional software engineering, the

569

Horn G., Jeffery K., Domaschka J. and Schubert L..

Analysing the Lifecycle of Future Autonomous Cloud Applications.

DOI: 10.5220/0004864705690577

In Proceedings of the 4th International Conference on Cloud Computing and Services Science (CLOSER-2014), pages 569-577

ISBN: 978-989-758-019-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

application would be designed to essentially host

one complete instance for a single user. Data sharing

has to be explicitly encoded and is not represented

on the level of actual execution state, let alone that it

automatically caters for consistency problems. To

make best use of resources (and thus to optimise cost

and quality of service), it is furthermore necessary to

assess the scaling behaviour of the individual

functionalities that compose the full application

logic.

Figure 1 depicts such varying scaling behaviour

of a simple online book store: following traditional

principles would result in a single workflow per

each user, including the services and data base.

However, information such as the database needs to

be available to all users, but the store front and the

publisher access are not necessary per user.

However, no current software engineering principle

allows for description of a behaviour as depicted.

The implication of this scaling behaviour,

however, has to be assessed on the overarching

level, as for example two individual services in the

application workflow may scale out beyond the total

cost agreements, simply because the behaviour of

the individual services did not cater for the total

impact.

We will elaborate the impacting characteristics in

more detail in the following sections:

2.1 Usage Aspects

There is a general tendency to treat a Cloud

application as a self-sustained application in a full-

blown virtual image, though an increasing number

of modern cloud applications are actually complex

business processes distributed over multiple

resources and multiple virtual images and potentially

integrating the capabilities of different Cloud

infrastructures at the same time, cf. (Schubert and

Jeffery, 2012). As has been shown, the intrinsic

characteristics of such applications determine the

scaling behaviour, and in particular its constraints,

and thus the optimal resource utilisation, see e.g.

(Becker, Koziolek and Reussner, 2009), (Rubio

Bonilla, Schubert and Wesner, 2012) (cf. Figure 1).

Not only the number of users (which may vary

significantly over time) impacts on application scale,

but also the usage behaviour of each individual user.

Already a comparatively simple application, such as

book selling exposes multiple functionalities:

searching for books, adding / removing from lists,

ordering from publisher etc. – all triggering different

processes and necessitating different data.

It may be safely assumed that the application

structure, namely its processes and their potential

relationship, is already known. This – structural –

information serves also one further purpose: the

relationship between processes (usually as services)

and their potential impact on execution criteria such

as performance, data consumption etc.:

Each service contributes differently to the overall

Figure 1: Potential distributed workflow with different overlapping processes and different scaling behaviour per service

instance.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

570

application workflow and hence exposes different

(a) resource requirements and (b) connections during

scaling. For example an individual instance of

service A may serve up to 9(!) instances of service B

provided that B only contributes 1/10 to the total

load. The multiple instance of B may be the

consequence of scaling out due to increased user

demand.

2.2 Performance Aspects

The application workflow information can indicate

problem areas, such as bottlenecks. In order to

assess these, standard relationship information needs

to be extended with data about the communication

frequency and width (average size and range size of

messages), as well as performance impact per delay.

It will be noted that the communication impact is

not only defined by the data exchange, but logically

by the data in use itself. As with any application,

data size and structure can have strong impact on

overall performance. Non- or semi-structured data

has particular characteristics when used for

searching, pattern detection etc. and streamed data

has even more difficult characteristics requiring

windowing of the stream and multiple complex

parameters being maintained to assure effective and

efficient management of the data. Restructuring for

efficiency improvement may prove difficult to

achieve in a Cloud environment especially if the

data is shared.

Even if performance plays a secondary role in

the context of cloud computing so far, quality of the

provided services is a major concern. In this context,

availability (uptime and response time) is crucial for

customer satisfaction: if a specific service is not

available at request time, it will stall the execution of

the total application workflow. Scaling out to reach

the desired quality of service would mean: (1) higher

resource usage and thus higher cost, as well as (2)

higher risk of bottlenecks and potential problems

that cannot be compensated by scale out.

Also the technical characteristics of the hosting

environment plays a major role in meeting the

quality of service: for example, the database system

may not be suited for the type of access

requirements by the application, or storage may be

insufficient etc.

2.3 Deployment Criteria Overview

We can thus isolate the following main “external”

criteria that (should) influence the behaviour of a

cloud application, but are not accessible to the

execution environment in any form, so that it must

be explicitly provided by the application owner (or

the Cloud provider):

(1) Number of service consumers (users):

increased number of users will increase traffic and

potential resource conflicts associated with access to

threads of code, data etc.

(2) Communication behaviour: the time and size

of data exchange is a critical performance factor and

may lead to conflicts if it coincides with a large

number of users or background processes

(3) Usage behaviour: process invocation

frequency and sequence may lead to different

resource usage and potentially conflicts

(4) Workflow: specifies the application’s

structure and thus potential bottlenecks, scaling

conditions etc.

(5) Data structure: classify the impact arising

from typical data types and structures related to the

execution of the application

(6) Quality constraints (provider, host,

consumer) specify the actual business constraints

and goals of the actors and must therefore be

respected throughout the whole application lifecycle.

(7) Technical characteristics: define the

performance of a given application with respect to

its explicit and implicit resource need. This is

especially true for specialised platforms.

Up until now, the developer and potentially the

application provider had to cater for these aspects

implicitly by generating the necessary configuration

information manually, respectively by incorporating

the according behaviour directly into the application

code or workflow. Not only do most developers lack

such expertise, but it also makes the code difficult to

adjust to new environments and usage conditions.

3 CONCRETE DEPLOYMENT

INFORMATION

The information identified in the previous section

must not only be captured in a form that is intuitive

and meaningful – more importantly, it must be

specified in a form that can be used for deployment

and execution control purposes. Therefore this

information must be provided in a common format

that allows combination, selection and reasoning

over it, so as to select the right rules that apply under

the given circumstances.

In general, this means that the specifications

must consider the following aspects:

AnalysingtheLifecycleofFutureAutonomousCloudApplications

571

 Conditions: under which circumstances does the

information apply. For example, given a generic

rule to scale out when the number of users

increase, when does this behaviour really apply?

When would it create a bottleneck? The main

problem with these conditions is that they are

generally not well-defined and cannot be

represented as simple scalar tests. Hence they

must be able to cater for probabilistic values.

 Actions to perform when the conditions are met,

e.g., to scale out by a certain number, to relocate

the service etc. The composed actions of all

services must thereby meet the overall quality

constraints. This means that actions may vary

between use cases.

 Events: conditions are only evaluated if certain

events occur. In most cases these events will be

triggered by environmental circumstances. Like

conditions, they will have to deal with

uncertainty in order to allow for delays and

predict likely occurrences.

Even though these three aspects are clearly

related to the Event-Condition-Action definition

commonly used in logic reasoning (Helmer,

Poulovassilis and Xhafa, 2011), there are some

substantial differences, as will be elaborated in

section 4.

3.1 User Profile

The user profile describes the way in which the end-

user (application end user, application developer or

administrator) interacts with the Cloud environment.

The expected parameters are required for access

control and security – however, other user

characteristics are also of interest for better

interaction, such as preferred interaction mode,

preferred language, screen set-up etc. It should be

noted that the user profile information can change

dynamically, e.g. access control as the application

accesses different (parts of) datasets or databases.

3.2 Application Profile

An application can be generalised to a set of

modules exchanging data. The modules can be

functions, objects, actors, processes, services etc.

The application profile captures the characteristics

of these modules and their relationships.

The application developer typically has limited

knowledge about the temporal aspects of the

application, e.g. how much data will be exchanged

among the modules at what time, CPU and memory

consumption of each module etc. These factors may

depend on the data processed (see data profile) and

the user behaviour (user profile). Such parameters

must therefore be deduced from past executions and

from the software structure and its deployment.

Due to the nature of these properties, they are mostly

stochastic. In order to evaluate conditions on such

parameters, one will have to resort to hypothesis

testing, or observation of summarising quantities.

For properties with high variability, such as CPU

load, a high sampling frequency will be necessary to

capture the variations and the large data volumes

resulting might not be possible to store. Hence, one

will have to resort to generalisations and fitting of

standard parameterised density functions to capture

the essential variability.

Finally, the application profile must encompass

the operational goals, policies, and preferences of

the application owner. These are not constraints by

themselves, though they may be linked to

constraints. Policies can, for example, put

restrictions on where data is stored, or which Cloud

providers can (not) be used for deployment – these

could also indicate preferences of one Cloud

provider over others.

The specification of constraints and goals is

difficult – there is a clear need for a rich language to

capture all aspects, that is tractable using knowledge

engineering techniques but which in addition is able

to capture the intent of the user.

3.3 Data Profile

The data profile characterises the data to be used by

the application – this includes size (number and size

of records), the kind of dataset (alphanumeric, file

etc.), degree of dynamicity, privacy and security

considerations. Even more important for Cloud

performance are the access characteristics: do

applications typically read the dataset sequentially or

randomly based on some key attribute value? Is the

data used concurrently? Does the data need to be

kept consistent? Finally backup mechanisms need to

be in place for system recovery.

3.4 Host Profile (Infrastructure

Characteristics)

The technical characteristics of the infrastructure

play a major role with two respects: (1) whether the

host is suitable for the technical requirements and

(2) what performance can be expected by using the

respective host. The relationship between

performance and executing platform is however

generally undefinable, see e.g. (Skinner and Kramer,

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

572

2005). Similar to the technical requirements (see

below), there are however indicators that help in

performing an “educated guess” about the right

matching, such as bandwidth between nodes, size of

storage, database type etc.

Some of these factors can be influenced by the

host, such as the number of virtual machines, other

factors depend completely on the application and the

data processed by it.

The developer should therefore be able to specify

all the characteristics that are of essence to executing

the application. Typically, this will be constrained to

low-level aspects, such as the type of operating

system, necessary libraries etc., as the average

developer will not be able to specify all performance

impacting factors. On the other hand, the developer

is the only person able to assess what kind of

communication density to expect etc.

Therefore the relevant information must be

conveyed in a way that is intuitive and yet

meaningful for deployment and configuration. This

means that the developer will have to provide (a) the

concrete technological deployment requirements

(deployment model) and (b) any performance related

information that compensate the application profile

– this means in particular information regarding

likelihood and category of occurrence. For example,

the developer indicates how likely specific data sets

occur, such as frequency of address changes versus

person queries in a personnel database.

3.5 Expertise

As noted earlier (see Section 2.3), the translation of

all the expectations towards the application is

currently achieved through manual labour, i.e. by the

expertise of the developers involved in the process.

However, the scope of information to be considered

may easily exceed any current developer’s expertise.

The problem is thereby not so much the

complexity of the individual knowledge “items”, but

the sheer scope of such expertise and the according

fine-grained application context. For example

Scale out with numbers of users

is fairly easy to grasp and apply in general.

However, correct application depends on a number

of factors, starting with the networking capacity of

the host, over its adaptation speed, up to the overall

quality expectations. But there are also commercial

aspects to be considered, such as maximum costs

and cost to quality ratio.

What is more, however, is that the combination

of rules for different services within an application

can lead to undesired side effects, if not properly

respected when applying these rules. As such, two

connected components that communicate with each

other may e.g. lead to mutual scale up beyond given

boundaries.

As already noted in the beginning of this section,

all rules must generally take an event-condition-

action (ECA) like structure in order to be applicable

under the right circumstances. As opposed to the

other information types, which generally are of the

form of conveying only parts of the ECA rules (such

as the conditions), the “expertise rules” directly

incorporate all information and should therefore be

formalised as ECAs. In principle, “expertise rules”

are the results of gathering all the historical

information, generating the rules and improving

them over time – with the difference, that such

knowledge is already available for exploitation,

though not properly formalised for automated usage

and application across domains and use cases.

4 AN ARCHITECTURE FOR

APPLICATION DEPLOYMENT

As noted, the rules and information to be applied to

the actual execution of an application take an event-

condition-action (ECA) like form – however:

(1) many of these rules have to be combined

under uncertain and partial unspecified conditions,

and

(2) the conditions will take the form of

mathematical equations with domains of applicable

values, rather than concrete Boolean formulas

4.1 Contextualising Rules

Normal ECA rules apply to strictly logical

expressions that evaluate to true or false, similar to

if (10 < #users < 100) then

However, in the case here, the actual conditions (and

also the events) are of a form that is closer to

if (p(invocation

processA

)>0.7) then

where p means the probability for invocation. In

other words, the rules apply when uncertain

boundary conditions are met. This can be for

example

Rule#1: scale out whenever the number of users

(per instance) is bigger than 10

Rule#2: only scale out, when the service is not a

bottleneck

Rule#3: service B has high communication needs

when process A is invoked (bottleneck)

AnalysingtheLifecycleofFutureAutonomousCloudApplications

573

Rule#4: probability for invoking process A is

0.25

In other words, rule#1 applies successfully for

service B in 75% of all cases.

To derive such rules and reason over them, the

information described (section 3) must be formalised

and provided to the executing environment.

4.1.1 Exploiting Specialisation

It will be noted that the rules in this form are per se

infrastructure agnostic – meaning in particular, that

they generalise over the potential cloud behaviour.

At this level, the rules can be executed on any

platform that supports the necessary actions.

Some providers may however not offer full

support for all of this information, e.g. not all

platform providers allow fully detailed monitoring

information and not all allow full control over

scaling behaviour. The implication of this is, that not

all of the rules are equally applicable to all

environments.

By exploiting the host profiles, however, it can

be easily identified which provider supports which

rules. Implicitly, the combination of selected rules

constraints the selection of providers.

Vice versa, and more interestingly, the same

principle holds true to exploit specialised

capabilities: these form nothing but action rules that

only apply to a dedicated platform or host. Thus,

these rules restrict the choice of providers, if the

constraints demand for the according rule set.

Hence, the probability of fulfilment may alter by

selecting an alternative host.

This principle allows full exploitation of

specialisation according to the abstract requirements

of the application (see above).

4.2 Conceptual Architecture

Self-adaptive software systems have been studied

extensively ever since the vision of autonomic

computing arose (Jeffrey O. Kephart and David M.

Chess 2003). This vision basically specified that the

management of any adaptive system would have to

carry out four essential processes: (1) the system

must be monitored, (2) the gathered information

must be analysed to decide what the current system

state is and to decide if an adaptation is necessary,

after which the adaptation is (3) planned before it is

(4) executed. This has become known as the MAPE-

K loop of autonomic systems, where the K stands

for the knowledge available and exploited executing

this loop. The MAPE-K loop must also be enacted

for autonomous cloud applications.

One could build the adaptation plan reactively

taking only the current application context into

consideration when defining the next model and then

Figure 2: The fundamental modules for adapting a model-based application at runtime. Platform specific scripts ensure a

safe transition from the current to the new application configuration. Taken from (Geir Horn 2013).

Running system

Adaptation trigger:

Complex event

processor

Goal based

reasoning engine

Application

model

New model

needed

Aspect model

weaver

Configuration

checker

Configuration

manager

Ta rg et

model

Running

Configuration

model

Invalid target

model detected

Casually

connected

Valid target

configuration

Safe

reconfiguration

scripts

Current

context

model

Monitoring information

Deduced parameters

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

574

plan the adaptation as transformation from the

running application model to the new one. This

approach, known as models@run.time (Gordon

Blair, Nelly Bencomo, and Robert B. France 2009)

was used in (Brice Morin et al. 2009), which

identified the following five modules necessary in

order to carry out the MAPE-K loop:

(1) A complex event processor to identify when

the running context of the application has changed to

the extent that an adaptation is necessary.

(2) A goal based reasoning engine to select the

model conﬁguration that would be “best” for the

current context, i.e. the target model.

(3) An aspect model weaver to realise the target

model and its bindings.

(4) A conﬁguration checker to verify that the

target model is consistent and deployable.

(5) A conﬁguration manager to derive a safe

sequence of application reconﬁguration commands.

The relations of these modules are depicted in

Figure 2, which also advocates the need for a

stochastic goal based reasoning engine.

4.2.1 Monitoring

Monitoring is done by the execution platform (inside

the virtual machine or on system level). The monitor

provides information about the current execution

status, insofar as supported by the host (cf. section

4.1.1). Therefore the monitor provides relevant

information whether the expected constraints are

met.

Each monitoring instance fulfils a two-fold role

(cf. next section): (1) checking the performance of

the individual service (instance), and (2)

contributing to the analysis of the overall behaviour.

A definition of a monitor incorporates (1) what

type of information needs to be gathered (2) at what

frequency and (3) potentially how it needs to be

generated (metric), as well as (4) where it needs to

be sent to (such as the event filter).

Obviously, the information is constrained by the

hosting platform’s capabilities - in other words, no

metrics can be applied to data that is not provided by

the host. This is hence a selection criteria for the

right host (see section 4.1.1).

4.2.2 Analysis

The analysis of the monitored information can be

done locally or centrally: for instance local

monitoring can decide to scale out a local service,

but application level adaptation must be analysed

centrally to weigh the effect of all individual actions.

The simplest form of analysis is to compare the

monitored data against a threshold. However, this

will be vulnerable to variations. For instance, the

response time of a database query depends on its

complexity - hence, a complex query may exceed

the response threshold. Adapting on a single event

may therefore lead to erratic behaviour.

Statistical hypothesis testing is one alternative.

However, one should bear in mind that most

methods are developed for the linear model

(Franklin A. Graybill, 1976) and therefore sensitive

to deviations from the normal distribution of large

samples. The alternative is to use non-parametric

tests (Conover, 1999) or, if one is just interested in

detecting out of bounds events, one could use the

sample version of the Chebyshev inequality (John G.

Saw, 1984).

Finally, there are numerous techniques from the

field of information flow processing that can be

applied to correlate and understand the true system

state based on monitored events (Gianpaolo Cugola

and Alessandro Margara, 2012).

4.2.3 Planning

Adaptation planning takes place at three levels:

(1) The developer plans adaptation steps that

make sense for the application logic – for example

related to the workload assignment in distributed

applications.

(2) Plans for each Cloud provider adaptation

using the elasticity mechanisms offered by that

infrastructure. Such plans are provided as part of the

deployment of the application, and they are therefore

a part of the currently deployed configuration.

(3) When the system requires adaptation that is

not catered for, a new configuration is needed. Such

a global adaptation must be planned in response to

the detected changes in the application’s running

context using models@run.time as outlined above,

trying to meet all operational constraints (Geir Horn

2013).

4.2.4 Execution

The adaptation plan should be executed

hierarchically with the central authority maintaining

overall application consistency, whereas platform

level mechanisms are used to the largest possible

extent to allow a smooth transition.

The configuration manager will need to identify

the difference between the running and the new

configuration, to generate reconfiguration scripts for

each Cloud platform. This is also highly use case

dependent, as some applications allow

checkpointing and state recovery, whereas other

AnalysingtheLifecycleofFutureAutonomousCloudApplications

575

applications must simply be stopped with the new

configuration started from scratch.

The main point thereby is that not the services

themselves are adapted (in the sense of re-

programmed or re-configured with new parameters),

but the execution context instead. Using above

building blocks, the profiles and service

descriptions, the tasks (i.e. services) can be treated

individually as black boxes that are scaled out,

relocated, reconfigured much the same way a virtual

image would. In other words, the services

contributing to the overarching application logic are

basically subject to common cloud strategies that

together meet the overarching goals and constraints.

To realise such behaviour, the configuration

manager is closely linked to local execution engines

that perform the actual adaptation on a service level,

ensuring that the individual steps in the adaptation

script are executed correctly.

5 CONCLUSIONS

Our proposed model aims at integration across

multiple Cloud platforms of any kind. It will also

allow the application to be deployed optimally

taking account of the specialised characteristics of

different platforms matched to the requirements of

the application and its usage constraints.

Not all additional information necessary can

always be provided, or properly matched: so far, no

proper programming and modelling mechanism

exists that allows easy and intuitive definition of the

right type of information. Furthermore, reactive

adaptation planning using models@run.time is an

active research topic (Svein Hallsteinsen et al.

2012), and using these concepts for Cloud

deployment is currently under investigation.

A major open challenge thereby remains in

maintaining the compositional correctness of the

decomposed rules and actions: during deployment

and adaptation, the overarching constraints have to

be broken down to low-level rules that can be

enacted individually. To this end, the information

does have to be provided in a fashion that

incorporates both high- and low-level descriptions.

This paper described the approach pursued in the

PaaSage project, which develops the necessary

language, modelling and reasoning tools to allow

provisioning and exploitation of the type of

information described here. The tools will allow the

individual stakeholders to provider their respective

view on the goals and constraints by building up

from proven patterns that can be decomposed

through according reasoning mechanisms. The goal

is to make it easier to create and host applications

that can run effectively and efficiently on various

Cloud, thereby addressing a major barrier to take-up

of Clouds.

ACKNOWLEDGEMENTS

The research leading to these results has received

funding from the European Union Seventh

Framework Programme (FP7/2007-2013) under

grant agreement n° 317715. The views expressed in

this paper are those of the authors and do not

necessarily represent those of the consortium.

REFERENCES

Becker, S., Koziolek, H. & Reussner, R., 2009. The

Palladio component model for model-driven

performance prediction. Journal of Systems and

Software, 82:3-22.

Brice Morin, Olivier Barais, Jean-Marc Jézéquel, Franck

Fleurey, and Arnor Solberg. 2009. ‘Models@run.time

to Support Dynamic Adaptation’. Computer 42 (10):

44–51. doi:10.1109/MC.2009.327.

Conover, W. J.., 1999. Practical Nonparametric Statistics.

3rd ed. Wiley Series in Probability and Statistics:

Applied Probability and Statistics Section. John Wiley

& Sons.

Franklin A. Graybill. 1976. Theory and Application of the

Linear Model. North Scituate, MA, USA: Duxbury

Press.

Geir Horn. 2013. ‘A Vision for a Stochastic Reasoner for

Autonomic Cloud Deployment’. In Proceedings of the

Second Nordic Symposium on Cloud Computing &

Internet Technologies, edited by Muhammad Ali

Babar, Marlon Dumas, and Arnor Solberg, 46–53.

NordiCloud ’13. New York, NY, USA: ACM.

doi:10.1145/2513534.2513543. http://doi.acm.org/

10.1145/2513534.2513543.

Gianpaolo Cugola, and Alessandro Margara. 2012.

‘Processing Flows of Information: From Data Stream

to Complex Event Processing’. ACM Comput. Surv.

44 (3) (June): 15:1–15:62. doi:10.1145/

2187671.2187677.

Gordon Blair, Nelly Bencomo, and Robert B. France.

2009. ‘Models@run.time’. Computer 42 (10): 22–27.

doi:10.1109/MC.2009.326.

Hallsteinsen, S., Geihs, K., Paspallis, N., Eliassen, F.,

Horn, G., Lorenzo, J., Mamelli, A., and Papadopoulos,

G. A., 2012. A Development Framework and

Methodology for Self-adapting Applications in

Ubiquitous Computing Environments. Journal of

Systems and Software 85 (12) (December): 2840–

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

576

2859. doi:10.1016/j.jss.2012.07.052.

Helmer, S., Poulovassilis, A. & Xhafa, F., 2011.

Reasoning in Event-Based Distributed Systems.

Studies in Computational Intelligence 347, Springer-

Verlag Berlin Heidelburg.

Jeffrey O. Kephart, and David M. Chess. 2003. ‘The

Vision of Autonomic Computing’. Computer 36 (1):

41–50. doi:10.1109/MC.2003.1160055.

John G. Saw, Mark C. K. Yang, and Tse Chin Mo. 1984.

‘Chebyshev Inequality with Estimated Mean and

Variance’. The American Statistician 38 (2) (May):

130. doi:10.2307/2683249.

Rubio Bonilla, D., Schubert, L. and Wesner, S., 2012, The

Need to Comprehend Clouds: Why We Still Can’t Use

Clouds Properly. CloudComp Conference

Proceedings.

Schubert, L., & Jeffery, K., 2012. Advances in Clouds -

Research in Future Cloud Computing. Cordis

(Online). Brussels, BE: European Commission.

Retrieved from http://cordis.europa.eu/fp7/ict/ssai/

docs/future-cc-2may-finalreport-experts.pdf.

Skinner, D. & Kramer, W., 2005. Understanding the

causes of performance variability in HPC workloads.

International Symposium on Workload

Characterization.

AnalysingtheLifecycleofFutureAutonomousCloudApplications

577
