Exploring Data Fusion under the Image Retrieval Domain
N
´
adia P. Kozievitch
1
, Carmem Satie Hara
2
, Jaqueline Nande
2
and Ricardo da S. Torres
3
1
Dept. of Informatics, Federal University of Technology, Curitiba, Brazil
2
Dept. of Informatics, Federal University of Paran
´
a, Curitiba, Brazil
3
Institute of Computing, University of Campinas, Campinas, Brazil
Keywords:
Content-based Image Retrieval, Data Fusion, XML, Metadata.
Abstract:
Advanced services in data compression, data storage, and data transmission have been developed and are
widely used to address the required capabilities of an assortment of systems across diverse application do-
mains. In order to reuse, integrate, unify, manage, and support heterogeneous resources, a number of works
and concepts have emerged with the aim of facilitating aggregation of content and helping system developers.
In particular, images, along with existing Content-Based Image Retrieval services, have the potential to play
a key role in information systems, due to the large availability of images and the need to integrate them with
existing collections, metadata, and available image manipulation softwares and applications. In this work,
we explore a data fusion approach for solving data value conflicts in the context of image retrieval domain.
In particular, we target the process of solving value conflicts resulted from different features integrating the
data resulted from the Content-Based Image Retrieval process, along with the image metadata, provided from
a number of sources and applications. Our approach reduces the need of human intervention for keeping a
clean and integrated view of an image repository when new data sources are added to an image management
system.
1 INTRODUCTION
The process of organizing new information, and inte-
grate them with data acquired from external sources
are usually very time consuming tasks. Users in-
volved in managing these data are often looking for
ways to improve their productivity, and it is thus im-
portant to provide them with effective tools to reuse
and aggregate content.
Motivated by the need for integration and interop-
erability, a number of works have proposed the ag-
gregation of different information combined together
to compose a single logical object. The resulting
object has been denoted as Aggregation (Williams
and Suleman, 2003), Component-Based Object (San-
tanch
`
e and Medeiros, 2007; Santanch
`
e et al., 2007),
Complex Object (Nelson et al., 2001), and Compound
Object (Awre, 2009). In particular, images are a rep-
resentative example of a data source which is gener-
ally integrated and combined with different compo-
nents, such as metadata, links, videos, and image ma-
nipulation softwares and applications.
One common strategy used to support image
searches in large datasets is called Content-Based Im-
age Retrieval (CBIR) (Torres et al., 2006). Roughly,
the process can be divided in three steps: (1) feature
vectors that represent image visual properties (such as
color, texture, and shape) are extracted; (2) the simi-
larity between images are computed based on the dis-
tance between their feature vectors; and (3) the most
similar collection images are returned as the search
result.
In fact, there are a number of works (Akbar et al.,
2008; Nanni et al., 2011) that propose the integra-
tion or parallel use of several feature vectors, but few
that propose the integration of a general purpose data
fusion system in the context of CBIR, considering
both image and metadata. A fusion process involves
both entity resolution and cleaning. Entity resolution
refers to the problem of identifying overlapping data
in different sources. This problem has been the sub-
ject of extensive research on relational (Lim et al.,
1996), entity-relationship (Menestrina et al., 2006),
and XML (Poggi and Abiteboul, 2005) data mod-
els. Cleaning refers to the process of solving attribute
value conflicts. In particular, several issues can be
cited regarding integration of different sources in the
CBIR domain: (i) existence of duplicate images, (ii)
the use of different descriptors, (iii) the existence of
images with different transformations (crop, resolu-
171
P. Kozievitch N., Satie Hara C., Nande J. and da S. Torres R..
Exploring Data Fusion under the Image Retrieval Domain.
DOI: 10.5220/0004869901710178
In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 171-178
ISBN: 978-989-758-027-7
Copyright
c
2014 SCITEPRESS (Science and Technology Publications, Lda.)
tion, etc.), (iv) definition of different ranked lists (e.g.,
defined in terms of different descriptors), (v) different
sizes of ranked lists, among others.
Most of existing systems for data fusion consider
data structured on relational format. Nevertheless,
given that XML has become the de facto standard for
data exchange on the Web, it is natural to also con-
sider this format in the fusion process.
In this paper we report on a system that combines
a general purpose data fusion system in the context
of CBIR. In particular, we target the process of solv-
ing value conflicts resulted from different features in-
tegrating the data resulted from the CBIR process,
along with the image metadata, provided from a num-
ber of sources and applications. The main novelty re-
sides in automatically solving conflicts in CBIR with-
out user intervention, using rules to integrate images,
metadata, and sources along the fusion process. Nev-
ertheless, these formalized rules can also be extended
to compare, and highlight the differences among dif-
ferent multimedia resources.
1.1 A Motivating Example
Consider an infrastructure (shown in Figure 1) which
has as input images and metadata and as output a
XML file, aggregating the input data with resulting
resources from the CBIR process. For instance, con-
sider Source 1, which stores the CBIR information
for Figure 2-a (a parasite image), within an XML file.
The XML file is composed of a feature vector FV1
(processed by a color descriptor BIC), the similarity
scores SM1, an image IM1, and the respective meta-
data M1 (with attributes such as name, path, size, and
resolution).
Figure 1: Fusion process integrating CBIR sources.
Now consider Source 2, where the same im-
age (shown in Figure 2-b) was processed by another
descriptor (SASI texture descriptor). The resulting
XML file would include the feature vector FV2, with
the respective similarity scores SM2, and metadata
M2. Assume that both sources need to be integrated
and stored in a repository. That demands that existing
conflicts among entities need to be solved. The result-
ing XML file should automatically integrate the CBIR
information, and metadata on Source 1 and Source 2
within one XML tree structure.
(a) (b)
Figure 2: CBIR for image 01 ancylostoma.jpg, using the (a)
BIC (Stehling et al., 2002) descriptor and (b) SASI (Carka-
cioglu and Yarman-vural, 2001) descriptor.
In XFusion (Cecchin et al., 2010), the user defines
a set of rules for solving these conflicts after merging
the information imported from several data sources.
In this paper, using basic services from XML, we ex-
plore XFusion in order to aggregate different CBIR-
related data. The novelty resides on the use of fusion
rules to automate the decision process regarding con-
flicted values, considering aggregation of metadata,
images, and CBIR-related data.
1.2 Organization
The remainder of this paper is organized as follows.
Section 2 contains a description of related work. An
overview of our solution is described in Section 3.
A case study is presented in Section 4. Finally, we
present our conclusions and draw future work in Sec-
tion 5.
2 RELATED WORK
2.1 Integration of Resources
Multiple definitions have been used (Kozievitch et al.,
2011a; Nelson et al., 2001) to name the integration
of resources into a single digital object as Aggrega-
tion (Williams and Suleman, 2003), a Component-
Based Object (Santanch
`
e and Medeiros, 2007; San-
tanch
`
e et al., 2007), a Complex Object (Nelson et al.,
2001; Lagoze et al., 2006), or a Compound Ob-
ject (Awre, 2009).
Several integration formats arise from different
communities (Nelson and de Sompel, 2006; Nelson
et al., 2001; Fox and France, 1997; Karpovich et al.,
1994; Burnett et al., 2006). In particular, Santanch
`
e
used the idea of integration within the field of soft-
ware reuse and exchange (Santanch
`
e and Medeiros,
2007; Santanch
`
e et al., 2007), in a component-
based technology named Digital Content Component
(DCC). A DCC is composed of four distinct subdivi-
sions: (a) content, (b) structure,(c) interfaces, and
(d) metadata, used to manage different layers of the
object aggregations.
ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems
172
2.2 Images and Applications
If we consider image data, new challenges have
emerged to handle the Content-Based Image Retrieval
services. A typical solution for this service requires
the construction of image descriptors, which are
characterized by: (i) an extraction algorithm to en-
code image features into feature vectors; and (ii) a
similarity measure to compare two images based on
the distance between their corresponding feature vec-
tors. The similarity measure is a matching function,
which gives the degree of similarity for a given pair
of images represented by their feature vectors, often
defined as a function of the distance (e.g., Euclidean),
that is, the larger the distance value, the less similar
the images.
There are several applications which support ser-
vices based on image content, allowing integration in
distinct domains (Murthy et al., 2010; Achananuparp
et al., 2007). And along with these applications, im-
ages can also be explored to integrate annotation sup-
port for image digital libraries such as (Jochum et al.,
2007). In particular, consider for the following exam-
ples a recently developed component-based CBIR in-
frastructure aiming to process and encapsulate images
and related data (Kozievitch et al., 2012; Kozievitch
et al., 2011b), presented in Figure 3. The bottom layer
contains the data sources: the descriptor library, the
image collection, and the database. The second layer
contains DCCs, which encapsulate, provide access,
and manage several parts of the CBIR process: the
descriptors, the descriptor library, the images, the re-
trieval from the database, and finally a manager, for
setting up the entire process. The third layer com-
prises the applications which manipulate the image
aggregations, by accessing the CBIR process or the
data sources.
1
Feature
Vectors
Images
Videos
DBMS (marks,
metadata)
Descriptor
Library
XML
Files
ImageCODCC
DescriptorDCC
ManagerDCC
DescriptorLibraryDCC
ImageDCC
CBIRStoryDCC
ExtractStoryDCC
StoryDCC
VideoDCC
RetrievalDCC
AnnotationDCC
PublishingDCC
Data Insertion
Content-Based
Image Search
Text-Based
Search
Combined Search
Video
Browsing
Video
CBIRProcessDCC
Video
Indexing
Video
Search
Indexing
Browsing
Layer 1: Data
Layer 2: DCCs
Layer 3: Interface
Annotation
Publishing
Figure 3: Management Layers (Kozievitch et al., 2012).
2.3 Data Integration and Cleaning
Data fusion and cleaning have been studied exten-
sively by the database community (Bhattacharya and
Getoor, 2006; Bleiholder and Naumann, 2008). Most
of previous works consider data on relational format,
but recently it has been stressed the need for inves-
tigating the problem of solving conflicts on semi-
structured data. XClean (Weis and Manolescu, 2007)
is a system that allows declarative and modular spec-
ification of a cleaning process. It consists of a declar-
ative language with operators that cover not only the
fusion process, but also entity identification and com-
bination of values that refer to the same object. The
main goal is to provide a modular system that can be
easily extended with new operators. Potter’s Wheel
(Raman and Hellerstein, 2001) follows a cleaning
strategy based on a set of operations to transform data,
such as format, drop, copy, merge, split, divide, fold
and select. However, instead of storing the result of a
data transformation, the sources are stored along with
the definition of the transformation. The transforma-
tion is applied on-the-fly whenever a consistent and
clean information is required.
Several systems have been proposed in the litera-
ture on (i) the fusion process (such as Hummer (Bilke
et al., 2005) and Fusionplex (Motro and Anokhin,
2006)), (ii) sharing structured data (Orchestra (Ives
et al., 2008)), and (iii) update data-oriented workflow
(Panda (Ikeda and Widom, 2010)).
There are a number of strategies for data fusion
proposed in the literature (Yin et al., 2008; Dong
et al., 2010; Cao et al., 2013; Fan et al., 2013), and
a survey can be found in (Bleiholder and Naumann,
2008). The approach presented within this paper al-
lows strategies to be reapplied in subsequent integra-
tion processes, and also keeps provenance informa-
tion for tracing back the origin of the data stored in
the repository.
3 OVERVIEW OF OUR
SOLUTION
From a formal perspective, an aggregation of
Content-Based Image Retrieval components com-
prises an structure that aggregates the image, fea-
ture vector, and similarity scores (Kozievitch et al.,
2011a). In addition, each digital object might have
metadata (such as file name, file size, among others).
In this section, we outline the proposed two-step
solution, namely the information extraction from im-
ages, described in Section 3.1 and the fusion process,
detailed in Section 3.2.
ExploringDataFusionundertheImageRetrievalDomain
173
3.1 Gathering the Information from the
CBIR Process
Suppose that within the parasite domain, a researcher
has metadata, several images, and their respective
CBIR information for several species (Kozievitch
et al., 2010), from different sources. Recall that the
CBIR process is responsible for creating the respec-
tive image feature vector and similarity scores among
the images.
Consider now the CBIR infrastructure pre-
sented in Figure 3. As input, consider im-
age 35 hnanagravpp5x.jpg and respective metadata.
Within Source 1, the image is processed by the BIC
descriptor (Stehling et al., 2002), showed in Figure 4.
The CBIR infrastructure aggregates all the related in-
formation within an XML file. Within Source 2, the
same image processed by the same descriptor. In this
case, however, Source 2 considers a different image
collection, i.e., images found within Source 2 are not
necessarily the same managed within Source 1. Note
that, comparing the two XML files, besides meta-
data conflicts that might appear (such as different file
paths), both images also present a different ranked
lists (the 5th image is different in both ranked lists,
as shown in Figure 8).
(a)
(b)
Figure 4: CBIR for image 35 hnanagravpp5x.jpg, within
(a) Source 1 and (b) Source 2.
3.2 Fusion of Image-related Data
The data fusion problem refers to the merging of data
provided from two or more sources. In particular,
the CBIR information presented in Figure 4-a and
Figure 4-b could be summarized within a XML tree
representation, as shown in Figure 7. Basically each
image (identified by a name) is processed by an im-
<db>
<image>
<image_name>39_Hnanagravpp5x.jpg</image_name>
<image_path>/tmp/39_Hnanagravpp5x.jpg</image_path>
<image_feature_vector_name>/tmp/fv/39_Hnanagravpp5x.jpg
</image_feature_vector_name>
<image_descriptor><descriptor>Bic</descriptor>
<distance><rank>1</rank>
<imageId>39_Hnanagravpp5x.jpg</imageId>
<image_dist_value>0</image_dist_value></distance>
<distance><rank>2</rank>
<imageId>29_dipilmad.jpg</imageId>
<image_dist_value>38</image_dist_value></distance>
<distance><rank>3</rank>
<imageId>38_dipilgrav.jpg</imageId>
<image_dist_value>47</image_dist_value></distance>
<distance><rank>4</rank>
<imageId>42_tsoliumgrav.jpg</imageId>
<image_dist_value>49</image_dist_value></distance>
<distance><rank>5</rank>
<imageId>Taenia_solium_scolex1.jpg</imageId>
<image_dist_value>49</image_dist_value></distance>
</image_descriptor>
</image>
</db>
Figure 5: XML file for Source 1, representing Figure 4-a.
<db><image>
<image_name>39_Hnanagravpp5x.jpg</image_name>
<image_path>/home/nadiapk/data/uploads/39_Hnanagravpp5x.jpg</image_path>
<image_feature_vector_name>/data/fv/39_Hnanagravpp5x.jpg
</image_feature_vector_name>
<image_descriptor>
<descriptor>Bic</descriptor>
<distance> <rank>1</rank>
<imageId>39_Hnanagravpp5x.jpg</imageId>
<image_dist_value>0</image_dist_value></distance>
<distance> <rank>2</rank>
<imageId>29_dipilmad.jpg</imageId>
<image_dist_value>38</image_dist_value> </distance>
<distance><rank>3</rank>
<imageId>38_dipilgrav.jpg</imageId>
<image_dist_value>47</image_dist_value> </distance>
<distance> <rank>4</rank>
<imageId>42_tsoliumgrav.jpg</imageId>
<image_dist_value>49</image_dist_value></distance>
<distance><rank>5</rank>
<imageId>03_ancylostoma.jpg</imageId>
<image_dist_value>53</image_dist_value></distance>
</image_descriptor>
</image>
</db>
Figure 6: XML file for Source 2, representing Figure 4-b.
age descriptor (identified by a name), which thereby
provides a feature vector and a ranked list of similar
images.
Consider now the XML documents presented in
Figures 5 and 6. Each element provided by
Source 1 has a corresponding one in Source 2.
However, some of the values associated with ele-
ments disagree, such as the elements image path,
image feature vector name, and the fifth element
of the ranked list (imageId and image dist value),
as illustrated in Figure 8. Note that there are two types
of conflicts: metadata conflicts (such as the first two
listed above) and CBIR conflicts (such as elements
within the ranked list).
A cleaning strategy for solving metadata conflicts
may determine that whenever a data item provided
from Source 1 disagrees with any other source, we
should choose Source 1s value over the others, for
example. As a result of applying this strategy, the
data repository keeps a single consistent value for all
subelements.
ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems
174
Figure 7: XML tree representation for CBIR-related data.
Figure 8: XML tree representation with conflicting ele-
ments (in yellow) from Source 1 and Source 2.
A cleaning strategy for CBIR conflicts may also
determine that all conflicting values should be kept
within the repository. As a result of applying this
strategy, the union of the ranked lists are kept within
the XML representation after cleaning, as shown in
Figure 9.
XFusion is a system which provides the function-
ality described within this paper. It relies on the con-
cepts of XML keys (Buneman et al., 2002) for deter-
mining which elements should be merged when inte-
grating one or more data sources, and a set of cleaning
rules for generating a consistent data repository.
Figure 9: XML tree representation after cleaning.
3.2.1 XML Keys
XML keys are used within our context to express the
result of the entity matching process. Thus, whenever
objects from distinct data sources agree on their keys,
they are merged into a single object in the repository.
When the values of non-key objects differ we say that
a conflict has been detected.
An XML key is defined as (context-path, (target-
path, { key-paths})), where the values of the key-paths
uniquely identify nodes reached following a target-
path in the context of each subtree defined by the
context-path. In order to generate the merge docu-
ment in Figure 9, keys were defined within the CBIR
context, such as:
(ε, (image, {image name}): in the context of the
entire document, (ε denotes the root), an image is
identified by its name;
(image, (image descriptor, {descriptor})): in the
context of the each subtree rooted at image, the
image descriptor is identified by descriptor;
(image/image descriptor, (distance, {rank})): in
the context of the each subtree rooted at im-
age/image descriptor, their elements distance are
identified by their rank;
(image, (image path, {})): in the context of any
subtree rooted at image node, there is at most one
image path.
Although here we have presented keys following
the syntax proposed in (Buneman et al., 2002), in
(Cecchin et al., 2010) the key definitions are stored
within an XML format. Note that within CBIR do-
main, additional keys can be used to define if how
many descriptors can be used do characterize the vi-
sual properties of an image, how many images will be
available at the ranked list fusion, etc.
3.2.2 Rules
Rules define high-level strategies for deciding how
value conflicts should be solved. The context of a rule
is defined by a path expression, and a list of strate-
gies for solving a conflict. There are a number of
strategies proposed in the literature for solving value
conflicts. The following subset of those proposed by
(Bleiholder and Naumann, 2008) is adopted by XFu-
sion:
Trust Your Friends. This strategy is based on
a reliability criterion: the value provided by the
source with the highest confidence rate assigned
by the user is chosen to be stored in the reposi-
tory;
Meet In The Middle. This strategy mediate the
conflict by generating a new value which repre-
sents an average among all conflicting values;
Cry With The Wolves. This strategy is defined
by choosing the value reported by the majority of
data sources;
Roll The Dice. A random value is choose among
the conflicting ones; and
ExploringDataFusionundertheImageRetrievalDomain
175
Pass It On. All the conflicting values are kept in
the repository.
As an example, consider the following fusion rule:
(/image[image name=“39 Hnanagravpp5x.jpg”]
/image path, [Trust your Friends, Pass it On])
The rule determines that whenever image
‘‘39 Hnanagravpp5x.jpg’’ conflicts on the
image path element, the conflict is solved by first
applying strategy Trust your Friends, followed by
strategy Pass it On. Considering that the user has
assigned a higher confidence rate to Source 1 over
Source 2, the result of the rule’s application is
illustrated in Figure 9.
Note that rules can be defined on larger contexts
than on single elements. Suppose, for example, that
the same strategy described above should be applied
to any conflict on image path elements. This rule can
be expressed as:
(/image/image path, [Trust your Friends, Pass it On])
With such a rule, future conflicts on this element
do not require any user intervention.
3.2.3 XFusion Usage
XFusion has a graphical interface that allows the user
to load data sources into the repository and perform
cleaning operations through the definition of fusion
rules. The tool’s main window is shown in Figure 10,
with the main screen after both Sources 1 and 2, pre-
sented in Figures 5 and 6, have been uploaded. Note
that the right window shows all uploaded sources,
associating a different color with each of them, and
showing their confidence rate inside the parenthesis.
Figure 10: XFusion main screen.
Figure 11: XFusion conflict resolution screen.
The merged document is shown in the main win-
dow, with value conflicts identified with the sources
that provide the conflicting values, represented by the
colored squares that precede each value.
When the user selects an existing conflict and
clicks on the resolve button, the screen depicted in
Figure 11 is shown. Note that the user has three main
options for solving a conflict: choose one among the
conflicting values, manually insert a new value, or ap-
ply some of the available strategies (described in Sec-
tion 3.2.2). Strategies are chosen by clicking on the
direction buttons in the middle of the screen, deter-
mining the order in which they should be considered.
Below the strategy boxes, the context of the rule is
presented. This path is originally set to uniquely iden-
tify the conflicting element or attribute, according to
the XML keys defined on the repository. Neverthe-
less, the user can edit the path for applying the list of
strategies on larger contexts. Finally, when the user
clicks on the Clean button, the new rule is inserted
into the policy base and its execution propagates the
chosen value to the repository. XFusion allows the
user to define rules incrementally. The user can then
check whether the strategy has been effective for solv-
ing all conflicts within the rules context. If not, she
may decide to extend the rule by defining additional
strategies to be applied.
In particular, within the context of the presented
parasite domain (Kozievitch et al., 2010), the fusion
of different sources centralizes the data, providing
more information about CBIR services and metadata.
This strategy can provide parasite experts with an in-
tegrated view on available datasets, which can foster
knowledge sharing. The same approach could be ex-
plored within other CBIR-related applications.
ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems
176
4 CONCLUSIONS
Many digital library implementations and applica-
tions demand additional and advanced services to ef-
fectively specify, reuse, describe and aggregate differ-
ent resources. Examples of commonly required ser-
vices include those related to the support of images
and related CBIR tasks.
In this paper, we address the integration of im-
age retrieval with XFusion, a rule-based cleaning tool
that stores curated data in an integrated repository. A
metamodel is proposed in order to specify the com-
ponents of the CBIR related tasks, validated through
a case study within the parasite domain. The main
novelty resides in automatically solving conflicts in
CBIR without user intervention, using rules to inte-
grate images and associated metadata.
A straightforward future work consists in the use
of rules to guide the design and implementation of im-
age digital libraries that integrate different (and possi-
bly distributed) image collections. One starting point
relies on the use of applications, like those proposed
in (Gonc¸alves and Fox, 2002; Zhu et al., 2003).
ACKNOWLEDGEMENTS
We would like to thank CAPES, CNPq, FAPESP,
AMD, Microsoft Research, and Fundac¸
˜
ao Arauc
´
aria.
REFERENCES
Achananuparp, P., McCain, K. W., and Allen, R. B. (2007).
Supporting student collaboration for image index-
ing. In ICADL’07, pages 24–34, Berlin, Heidelberg.
Springer-Verlag.
Akbar, S., Kung, J., and Wagner, R. (2008). Multishape-
features and text-feature integration on 3d model simi-
larity retrieval. Int. J. Innov. Comput. Appl., 1(3):171–
184.
Awre, C. (2009). Managing compound objects
within Fedora, Enhanced E-theses Project
Deliverable 9, available at http://igitur-
archive.library.uu.nl/DARLIN/2010-0526-
200241/UUindex.html. Knowledge Exchange
Group.
Bhattacharya, I. and Getoor, L. (2006). Collective entity
resolution in relational data. IEEE Data Engineering
Bulletin, 29(2):4–12.
Bilke, A., Bleiholder, J., Naumann, F., B
¨
ohm, C., and
Weis, M. (2005). Automatic data fusion with hum-
mer. In Proc. of the 31st VLDB Conference, pages
1251–1254.
Bleiholder, J. and Naumann, F. (2008). Data fusion. ACM
Comput. Surv., 41(1):1:1–1:41.
Buneman, P., Davidson, S., Fan, W., Hara, C., and Tan,
W.-C. (2002). Keys for XML. Computer Networks,
39(5):473–487.
Burnett, I. S., Pereira, F., de Walle, R. V., and Koenen, R.
(2006). The MPEG-21 Book. John Wiley & Sons.
Cao, Y., Fan, W., and Yu, W. (2013). Determining the rel-
ative accuracy of attributes. In SIGMOD’13: Proc. of
the ACM SIGMOD International Conference on Man-
agement of Data, pages 565–576.
Carkacioglu, A. and Yarman-vural, F. (2001). Sasi: A new
texture descriptor for content based image retrieval.
IEEE International Conference on Image Processing,
2:137–140.
Cecchin, F., Ciferri, C. D. A., and Hara, C. (2010).
XML Data Fusion. In International Conference
on Data Warehousing and Knowledge Discovery
(DaWaK‘2010).
Dong, X., Berti-Equille, L., Hu, Y., and Srivastava, D.
(2010). SOLOMON: Seeking the truth via copying
detection. PVLDB, 3(2):1617–1620.
Fan, W., Geerts, F., Tang, N., and Yu, W. (2013). Inferring
data currency and consistency for conflict resolution.
In ICDE’13: Proceedings of the IEEE International
Conference on Data Engineering, pages 470–481.
Fox, E. A. and France, R. K. (1997). Architecture of an
expert system for composite document analysis, rep-
resentation, and retrieval. In Readings in Information
Retrieval, pages 400–412. Morgan Kaufmann Pub-
lishers Inc., San Francisco, CA, USA.
Gonc¸alves, M. A. and Fox, E. A. (2002). 5SL: A Language
for Declarative Specification and Generation of Digi-
tal Libraries. In JCDL ’02, pages 263–272, New York,
NY, USA. ACM.
Ikeda, R. and Widom, J. (2010). Panda: A system for
provenance and data. IEEE Data Engineering Bul-
letin, 33(3):42–49.
Ives, Z. G., Green, T. J., Karvounarakis, G., Taylor, N. E.,
Tannen, V., Talukdar, P. P., Jacob, M., and Pereira,
F. (2008). The Orchestra collaborative data sharing
system. SIGMOD Record, 37(3):26–32.
Jochum, W., Kaiser, M., Schellner, K., and Wirl, F. (2007).
Living memory annotation tool image annotations
for digital libraries. In Proc. of the 11th European
conference on Research and Advanced Technology for
Digital Libraries, ECDL ’07, pages 549–550, Berlin,
Heidelberg. Springer-Verlag.
Karpovich, J. F., Grimshaw, A. S., and French, J. C. (1994).
Extensible file system (elfs): an object-oriented ap-
proach to high performance file i/o. ACM SIGPLAN
Notices, 29(10):191–204.
Kozievitch, N. P., Almeida, J., da S. Torres, R., Santanch
`
e,
A., Leite, N. J., Murthy, U., and Fox, E. A. (2012).
Reusing a compound-based infrastructure for search-
ing and annotating video stories. International Jour-
nal of Multimedia Technology, 2:89–97.
Kozievitch, N. P., Almeida, J., Torres, R. S., Leite, N. A.,
Gonc¸alves, M. A., Murthy, U., and Fox, E. A. (2011a).
Towards a Formal Theory for Complex Objects and
Content-Based Image Retrieval. JIDM, 2(3):321–336.
Kozievitch, N. P., da S. Torres, R., Santanch
`
e, A., Pe-
dronette, D. C. G., Calumby, R. T., and Fox, E. A.
ExploringDataFusionundertheImageRetrievalDomain
177
(2011b). An infrastructure for searching and harvest-
ing complex image objects. The Information - Inter-
action - Intelligence (I3) Journal, 11(2):39–68.
Kozievitch, N. P., Torres, R. d. S., Andrade, F., Murthy, U.,
Fox, E., and Hallerman, E. (2010). A teaching tool for
parasitology: enhancing learning with annotation and
image retrieval. In ECDL’10, pages 466–469, Berlin,
Heidelberg. Springer-Verlag.
Lagoze, C., Payette, S., Shin, E., and Wilper, C. (2006).
Fedora: an architecture for complex objects and their
relationships. Int. J. Digit. Libr., 6:124–138.
Lim, E., Srivastava, J., Prabhakar, S., and Richardson, J.
(1996). Entity identification in database integration.
Information Sciences, 89(1).
Menestrina, D., Benjelloun, O., and Garcia-Molina, H.
(2006). Generic entity resolution with data confi-
dences. In Proc. of VLDB Work. on Clean Databases.
Motro, A. and Anokhin, P. (2006). Fusionplex: resolu-
tion of data inconsistencies in the integration of het-
erogeneous information sources. Information Fusion,
7(2):176–196.
Murthy, U., Kozievitch, N. P., Leidig, J., da S. Torres, R.,
Yang, S., Goncalves, M., Delcambre, L., Archer, D.,
and Fox, E. A. (2010). Extending the 5S Frame-
work of Digital Libraries to support Complex Objects,
Superimposed Information, and Content-Based Image
Retrieval Services. Technical Report TR-10-05, Vir-
ginia Tech, Department of Computer Science.
Nanni, L., Brahnam, S., and Lumini, A. (2011). Combining
different local binary pattern variants to boost perfor-
mance. Expert Syst. Appl., 38(5):6209–6216.
Nelson, L. and de Sompel, H. V. (2006). IJDL special is-
sue on complex digital objects: Guest editors’ intro-
duction. International Journal of Digital Libraries,
6(2):113–114.
Nelson, M. L., Argue, B., Efron, M., Denn, S., and Pattuelli,
M. C. (2001). A survey of complex object technolo-
gies for digital libraries. Technical report, NASA/TM-
2001-211426.
Poggi, A. and Abiteboul, S. (2005). XML data integration
with identification. In Proc. of DBPL, pages 106–121.
Raman, V. and Hellerstein, J. M. (2001). Potter’s wheel:
An interactive data cleaning system. In VLDB ’01:
Proceedings of the 27th International Conference on
Very Large Data Bases, pages 381–390.
Santanch
`
e, A. and Medeiros, C. B. (2007). A Compo-
nent Model and Infrastructure for a Fluid Web. IEEE
Transactions on Knowledge and Data Engineering,
19(2):324–341.
Santanch
`
e, A., Medeiros, C. B., and Pastorello Jr, G. Z.
(2007). User-author centered multimedia building
blocks. Multimedia Systems, 12(4):403–421.
Stehling, R. O., Nascimento, M. A., and Falc
˜
ao, A. X.
(2002). A compact and efficient image retrieval ap-
proach based on border/interior pixel classification.
In CIKM ’02, pages 102–109, New York, NY, USA.
ACM.
Torres, R. d. S., Medeiros, C. B., Gonc¸alves, M., and Fox,
E. A. (2006). A Digital Library Framework for Bio-
diversity Information Systems. International Journal
on Digital Libraries, 6(1):3–17.
Weis, M. and Manolescu, I. (2007). Declarative XML
data cleaning with XClean. In International Conf. on
Advanced Information Systems Engineering (CaiSE),
pages 96–110.
Williams, K. and Suleman, H. (2003). A sur-
vey of digital library aggregation services. In
Scholarship at Penn Libraries, available at
http://works.bepress.com/martha
brogan/10.
Yin, X., Han, J., and Yu, P. S. (2008). Truth discovery with
multiple conflicting information providers on the web.
IEEE Transactions on Knowledge and Data Engineer-
ing, 20(6):796–808.
Zhu, Q., Gonc¸alves, M. A., and Fox, E. A. (2003). 5SGraph
demo: a graphical modeling tool for digital libraries.
JCDL ’03, pages 385–385, Washington, DC, USA.
IEEE Computer Society.
ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems
178
