Computational Models of Classical Conditioning

A Qualitative Evaluation and Comparison

Eduardo Alonso

1,2

, Pavandeep Sahota

and Esther Mondragón

Department of Computer Science, City University London, London EC1V 0HB, U.K.

Centre for Computational and Animal Research Centre, St. Albans AL1 1RQ, U.K.

Keywords: Computational Models, Classical Conditioning, Quantitative and Qualitative Evaluation, Comparison.

Abstract: Classical conditioning is a fundamental paradigm in the study of learning and thus in understanding

cognitive processes and behaviour, for which we need comprehensive and accurate models. This paper aims

at evaluating and comparing a collection of influential computational models of classical conditioning by

analysing the models themselves and against one another qualitatively. The results will clarify the state of

the art in the area and help develop a standard model of classical conditioning.

1 INTRODUCTION

In natural environments, there is a constant need for

organisms to accommodate their behaviour to

dynamic surroundings. Learning to predict the

regularities in such sensory rich conditions is the key

for adaptive behaviour and decision-making.

Predictive learning studies have mostly been

conducted within the context of classical

conditioning –which is based on the principle that

repeated pairings of two events will allow an

individual to predict the occurrence of one of them

upon presentation of the other, as consequence of the

formation of a link between them (see Mackintosh,

1994; Pearce and Bouton, 2001; Hall, 2002). This

simple idea is at the basis of many associative

learning phenomena and has proved to be relevant to

human learning both theoretically (judgment of

causality and categorization, e.g., (Shanks, 1995))

and practically, as the core of a good number of

clinical models (Haselgrove and Hogarth, 2011;

Schachtman and Reilly, 2011).

The last 50 years has seen the progressive

refinement of our understanding of the mechanisms

of classical conditioning and this has resulted in the

development of several influential theories that are

able to explain with considerable precision a wide

variety of experimental findings, and to make non-

intuitive predictions that have been confirmed. This

success has spurred the development of increasingly

sophisticated models that encompass more complex

phenomena. In such context, it is widely

acknowledged that computational modelling plays a

fundamental part (e.g., Dayan and Abbot, 2001;

Schmajuk, 1997; 2010a).

There are two main motivations for using

computational models: on the one hand, be it in the

form of a specific programming language or as a

formal model, implementations require

unambiguous definitions that make the underlying

psychological models more precise. On the other

hand, algorithms allow us to execute calculations

rapidly and, most importantly, accurately. The

outputs of a simulation feedback the psychological

models –thus becoming an essential part of the cycle

of theory formation and refinement. Automation is

critical, particularly when models are described in

non-linear equations that can only be solved

numerically as it is the case of recent models of

conditioning (Vogel et al., 2004; Schmajuk, 2010b;

Alonso and Mondragón, 2011). In particular,

(Schmajuk and Alonso, 2012) brought together as a

special issue on computational models of classical

conditoining a collection of papers that represent the

leading edge of the field. Henceforth we are

referring to the papers in the issue by acronysms of

the models themselves or the by the initials of the

authors if none was given, that is, we are coining

them GP, LCT, SLGK, PHK+, TD, MKM/APECS,

AMAN and SOCR, respectively. Notwithstanding

the relative merits of each model, as a theoretical

corpus (Schmajuk and Alonso, 2012) showed that

there is no unanimity on what the basic principles

544

Alonso E., Sahota P. and Mondragón E..

Computational Models of Classical Conditioning - A Qualitative Evaluation and Comparison.

DOI: 10.5220/0004903105440547

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 544-547

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

and mechanisms of classical conditioning are or on

standard procedures to investigate them. Although

there is agreement, or at least some convergence,

that learning is driven by the minimization of

prediction error (but see Witnauer et al. above for a

different view), the models considered differ

substantially on the nature of stimulus representation

(configural vs. elemental), the role of attention in the

formation of associations, and about how temporal

properties affect conditioning.

In order to build more comprehensive theories of

classical conditioning it is thus critical that we carry

out an exhaustive analysis of such models, that is,

that we evaluate them and compare them against one

another. Crucially, three requirements for

contributors to the special issue were set (Alonso

and Schmajuk, 2012): (1) models should be tested

against a list of phenomena for which there was a

consensus about their reliability; (2) model

parameters should be fixed across simulations; and

(3) authors should make available the simulations

they used to test their models. In short, the models

and their simulations should be replicable.

The list of phenomena was compiled by

domains, as follows: acquisition phenomena (6

phenomena), extinction (3), generalization (3),

discriminations (17), inhibitory conditioning (6),

combination of separately trained CSs (3), stimulus

competition/potentiation in training (11), CS/US

preexposure effects (11), transfer (4), recovery (8),

higher-order conditioning (5), and temporal

properties (9). Phenomena were characterised as

“General”, meaning that results had been

demonstrated in a wide variety of

procedures/organisms, or “Some Data” otherwise.

Regardless of the advances reported, (Schmajuk

and Alonso, 2012) demontrated that models in the

area are still partial (no model covers all the

phenomena under investigation), incomplete (there

are phenomena unaccounted for) and to some extent

inconsistent (different models make contradictory

predictions). (Schmajuk and Alonso, 2012)

represents the vanguard in computational models of

classical conditioning and, at the same time,

provides us with the appropriate tools to evaluate

and compare them.

2 EVALUATION

The over-reaching goal of this position paper is to

diagnose the state of the art in computational

modelling of classical conditioning, explain

divergences and convergences, and identify those

models that seem more promising in the search for a

standard model of classical conditioning.

The evalution consists of two phases: a

preliminary analysis of the software used in each

case. Additionally, we are also considering how

intuitive the underlying psychological assumptions

of each model are, and other factors such as how

many domains of phenomena each model crosses,

that is, their generality, and whether they account for

critical phenomena (for instance, latent inhibition or

spontaneous recovery). Before proceeding, it should

be noted that by a “computational model” we mean

an implementation of a (pre-existing) psychological

model, that is, we don’t consider computational

models as formal models that act as psychological

models by proxy. Also, we do not enter into the

philosophical debate about the different levels at

which psychological phenomena can be interpreted

and about the relationship between the so-called

computational level and other levels, algorithmic or

physical (see, (Alonso and Mondragón, 2012) for a

review on the uses, abuses and misuses of the

concept “computational” in psychology).

2.1 Software

It is beyond the purpose of this paper to carry out

validation and verification tests on the simulators in

wich the computational models in (Schmajuk and

Alonso, 2012) were run. We are not checking the

replicability of the results reported either. Instead,

we are summarizing, Table 1, which programming

language was used in each case, whether it was

documented (including a user’s guide), and whether

the code was made available.

Table 1: Software.

Model Language Document Code Guide

SLGK C Y Y Y

AMAN MATLAB Y Y Y

GP MATLAB Y Y Y

PKH+ Visual

Basic

Y Y Y

TD MATLAB N Y N

LCT MATLAB N Y N

MKM/AMEC MATLAB N N N

SOCR MATLAB N N N

It is up to the reader to decide whether, given the

resources made available to them by the authors, the

results reported are trustworthy. We are only

commenting on the programming language used and

on the software development characteristics that

underlies all simulators. Regarding the former,

MATLAB was the preferred choice. From the point

ComputationalModelsofClassicalConditioning-AQualitativeEvaluationandComparison

545

of view of a programmer, MATLAB is relatively

easy to learn and to use (at least, for simple

applications). Speed-wise MATLAB is rather

similar to alternatives like C, no matter whether they

compile or interpret. One of MATLAB’s

disadvantages is that it is not a fully bodied

programming language, and the user is not able to

create modular programs and reusable code with it.

In addition, MATLAB is proprietary software

and a proprietary language. MATLAB works only

with MathWork’s MATLAB software – meaning

that if you have created programs in MATLAB, you

will generally only be able to use those programs in

MATLAB, and would need to do extensive porting

to move to a different platform. MATLAB is not a

platform-independent language.

More generally, most simulators are not

professionally developed, failing to address the

following issues:

 Inputting data is cumbersome.

 The system must be run afresh each time the

input parameters are changed.

 Outputs cannot be directly exported and

manipulated in widespread data processors such

as, for example, excel.

 Interfaces and visualization of data are poor.

 Simulators are not portable across platforms.

 Simulators cannot be scaled up to accommodate

new parameters and/or models.

Although classical conditioning software has been

recently described in the literature (Schultheis et al.,

2008a; 2008b; Thorwart et al., 2009; Alonso et al.,

2012; Mondragón et al., 2013a; 2013b), it is still the

case that most psychologists in the area view

simulations as mere tools rather than as an integral

part of experimental methodology. Software is

developed, implemented and documented in an ad

hoc manner, raising serious concerns about its

reliability, usability and scalability.

2.2 Qualitative Analysis

The very essence of a model refers to the choices

scientists make –choices that reflect what they

consider relevant– and thus evaluating a model

requires careful consideration of many factors, both

technical and formal (Baum, 1983). However, in

assessing and selecting models (and in identifying

which features a good model should show) it is

critical that we use measurable criteria (see (Shiffrin

et al., 2008) for a recent survey). Typically, the

behaviour of a model is considered locally, that is, at

its best fitting parameter values. This approach is

problematic, since best fits leave us with snapshots

of the model’s performance that are difficult to piece

together into a comprehensive, global understanding

of the model. In addition, quantitative analysis based

on goodness-to-fit criteria can result in selecting

overly complex models that generalize poorly.

Finally, comparing models is even more difficult

with local quantitative methods. On these grounds

we will prioritize global qualitative analysis over

local quantitative analysis.

(Wills and Pothos, 2012a; 2012b) have

convincingly argued that relative adequacy, defined

in terms of the number and proportion of

irreversible, ordinal successes, might be a useful

metrics for model evaluation and comparison.

Central to their approach is the concept of

irreversible success, that is, success in the absence

of arbitrarily variable free parameters. In addition,

parameters should be determined at the level of the

domain of phenomena that the model is intended to

address, not at the level of individual experiments.

This seemingly uncontroversial proposal, that a

model that accommodates more successes is, other

things being equal, a better model, contrasts sharply

with current practice in classical conditioning

research, which is to examine in depth the results of

a single or a handful of experiments, rather than to

seek breadth. Moreover, some researchers insist that

model parameters should be derived independently

on each occasion. These practices make the

evaluation and comparison of computational models

of classiscal conditioning harder. To circumvent the

difficulties posed by using arbitrary free parameters,

(Schmajuk and Alonso, 2012) required the authors

to use fixed parameters across all simulations

(notice, however, that we didn’t penalize the number

of parameters à la BIC). However, the fact that most

models were tested against small datasets remains an

issue. The results in terms of numer of parameters

and number of phenomena replicated are shown in

Table 2. We are not disputing that the models in

(Schmajuk and Alonso, 2012) may account for more

results than those explictely reported. However we

can only evaluate the models in the light of the

evidence provided.

Of course, the meaning of these results is

debatable. Nevertheless, it gives researchers in the

area a guide of the predictive power of the models.

In terms of the number of phenomena replicated, it

seems that SLGK is the most comprehensible model.

On the other hand, LCT uses only one parameter –

which makes us wonder about its real value. It is

preferable to endorse models whose verbal

description allows some understanding of the

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

546

Table 2: Qualitative analysis results.

Model Number of

parameters

Number of

phenomena

replicated

SLGK 11 82

GP 7 39

AMAN 16 38

SOCR 5 38

TD 11 10

LCT 1 16

PHK+ 5 5

MKM/APECS Unclear Not fixed

model’s processes in psychological terms. This

property, that Willis and Pothos call penetrability is

important, particularly in cases where computational

models are taken as psychological models by proxy

rather than as formal expressions of psychological

models (see, Alonso and Mondragón, 2012).

REFERENCES

Alonso, E., & Mondragón, E. (Eds.)(2011),

Computational Neuroscience for Advancing Artificial

Intelligence: Models, Methods and Applications,

Hershey, PA: IGI Global.

Alonso, E., & Mondragón, E. (2012), Uses, Abuses and

Misuses of Computational Models in Classical

Conditioning. In N. Rußwinkel, U. Drewitz & H. van

Rijn (Eds.), Proceedings 11th International

Conference on Cognitive Modeling (ICCM-12), pp.

96-100. Berlin, Germany: Universitaetsverlag der TU

Berlin.

Alonso, E., Mondragón, E., & Fernandez, A. (2012), A

Java simulator of Rescorla and Wagner's prediction

error model and configural cue extensions, Computer

Methods and Programs in Biomedicine, 108, 346-355.

Alonso, E., & Schmajuk, N. (2012), Computational

Models of Classical Conditioning guest editors’

introduction, Learning & Behavior, 40(3), 231-240.

Baum, W. M. (1983), Matching, Statistics, and Common

Sense, Journal of the Experimental Analysis of

Behavior, 39, 499- 501.

Dayan, P., & Abbott, L. F. (2001). Theoretical

Neuroscience: Computational and Mathematical

Modeling of Neural Systems. Cambridge, MA: MIT

Press.

Hall, G. (2002), Associative structures in Pavlovian and

instrumental conditioning. In H. Pashler, S. Yantis, D.

Medin, R. Gallistel an J. Wixted (Eds.), Stevens'

Handbook of Experimental Psychology, Volume 3, pp

1-45. Hoboken, NJ: John Wiley and Sons.

Haselgrove, M., & Hogarth, L. (2011), Clinical

Applications of Learning Theory. London, UK:

Psychology Press.

Mackintosh, N. J. (1994)(Ed.), Animal Learning and

Cognition, San Diego, CA: Academic Press.

Mondragón, E., Alonso, E., Fernandez, A., & Gray, J.

(2013a), A Rescorla and Wagner simulator with

context compounds, Computer Methods and Programs

in Biomedicine. DOI: 10.1016/j.cmpb.2013.01.016.

Mondragón, E., Gray, J., & Alonso, E. (2013b), A

Complete Serial Compound Temporal Difference

Simulator for Compound stimuli, Configural cues and

Context representation, Neuroinformatics. DOI:

10.1007/s12021-012-9172-z.

Pearce, J. M., & Bouton, M. E. (2001), Theories of

associative learning in animals. Annual Review of

Psychology, 52, 111-139.

Schachtman, T. R., & Reilly, S. (2011), Associative

Learning and Conditioning Theory: Human and Non-

Human Applications. Oxford, UK: Oxford University

Press.

Schmajuk, N. A. (1997), Animal Learning and Cognition:

A Neural Network Approach. Cambridge, UK:

Cambridge University Press.

Schmajuk, N. A. (2010a), Mechanisms in Classical

Conditioning: A Computational Approach.

Cambridge, UK: Cambridge University Press.

Schmajuk, N. A. (2010b)(Ed.), Computational Models of

Conditioning.

Cambridge, UK: Cambridge University

Press.

Schmajuk, N. A., & Alonso, E. (Eds.)(2012).

Computational Models of Classical Conditioning,

Learning & Behavior, 40(3).

Schultheis, H., Thorwart, A., & Lachnit., H. (2008a),

HMS: A MATLAB simulator of the Harris model of

associative learning, Behavior Research Methods, 40,

442-449.

Schultheis, H., Thorwart, A., & Lachnit, H. (2008b),

Rapid-REM: A MATLAB simulator of the replaced

elements model, Behavior Research Methods, 40, 435-

441.

Shanks, D.R. (1995), The Psychology of Associative

Learning. Cambridge, UK: Cambridge University

Press.

Shiffrin, R. M., Lee, M. D., Kim, W., & Wagenmakers,

E.-J. (2008), A survey of model evaluation approaches

with a tutorial on hierarchical Bayesian methods.

Cognitive Science, 32, 1248–1284.

Thorwart, A., Schultheis, H., König, S., & Lachnit, H.

(2009), ALTSim: A MATLAB simulator for current

associative learning theories, Behavior Research

Methods, 41(1), 29-34.

Vogel, E. H., Castro, M. E., & Saavedra, M. A. (2004),

Quantitative models of Pavlovian conditioning, Brain

Research Bulletin, 63, 173-202.

Wills, A.J. & Pothos, E.M. (2012a), On the adequacy of

current empirical evaluations of formal models of

categorization, Psychological Bulletin, 138, 102-125.

Wills, A. J. & Pothos, E. M. (2012b) On the adequacy of

Bayesian evaluations of categorization models: Reply

to Vanpaemel & Lee (2012), Psychological Bulletin,

138, 1259-1261.

ComputationalModelsofClassicalConditioning-AQualitativeEvaluationandComparison

547
