Motivations for the Development of a Multi-objective Algorithm

Configurator

Nguyen Thi Thanh Dang and Patrick De Causmaecker

K.U. Leuven KULAK, CODeS, Etienne Sabbelaan 53, 8500 Kortrijk, Belgium

Keywords: Automated (Automatic) Algorithm Configuration, Multi-objective Optimization.

Abstract: In the single-objective automated algorithm configuration problem, given an algorithm with a set of

parameters that need to be configured and a distribution of problem instances, the automated algorithm

configurator will try to search for a good parameter configuration based on a pre-defined performance

measure. In this paper, we point out two motivations for the development of a multi-objective algorithm

configurator, in which more than one performance measure are considered at the same time. The first

motivation is a parameter configuration case study for a deterministic single machine scheduling algorithm

with two performance measures: minimization of the average running time and maximization of the total

number of optimal solutions. The second one is the configuration problem for non-exact multi-objective

optimization algorithms. In addition, a discussion of solving approach for the first motivating problem is

also presented.

1 INTRODUCTION

The automated algorithm configuration problem,

sometimes called parameter tuning, can be

informally stated as follows: given an algorithm A

(target algorithm) with a list of parameters, a set of

problem instances B and a performance measure for

the evaluation of A's quality on B; the automated

algorithm configurator (or simply configurator) will

try to find a good parameter configuration of A, i.e.,

an assignment of A's parameters into specific values,

in such a way that the performance measure's value

on B is optimized. The problem instance set B could

be generated from a problem's distribution and its

size is usually chosen to be large to well represent

the problem. Since this set is large, the exact

evaluation of the performance measure over B often

incurs very high computational costs. Therefore, the

configurator normally deals with a subset of B,

called training instance set, during the configuring

procedure. To avoid over-fitting, this training set

certainly should be sufficiently large and widely

spread over the problem distribution, then, the final

parameter configuration obtained is tested on

another problem instance set, named test instance

set, to evaluate the efficiency of the configurator.

The test set could be a subset of B, or even the same

as B.

The automated algorithm configuration problem

could be considered as an optimization problem, in

which the search space is the set of possible

parameter configurations and the objective function

is the performance measure over the training

instance set. This optimization problem presents

three challenges. The evaluation of each solution's

quality is often very expensive. This evaluation

could be stochastic if the target algorithm is not

deterministic. And finally, different types of

variables (target algorithm's parameters) could exist

in the same configuration problem. To be more

specific, an algorithm's parameter could be

continuous, integer or categorical. A parameter

could also be conditional, i.e., its activation could

depend on specific values of some other parameter.

The automated algorithm configuration problem

has received large attention in the last decade. A vast

number of solving approaches, originating from

various fields, have been proposed in recent years.

According to Stutzle et al., 2013, they could be

classified into four groups: approaches from the

experimental design community, sequential

statistical testing techniques, model-based

optimization approaches and metaheuristics. Several

other works have also been devoted to a literature

review of the algorithm configuration topic, such as

Hoos, 2012. Among these methods, irace (López-

328

Dang N. and De Causmaecker P..

Motivations for the Development of a Multi-objective Algorithm Conﬁgurator.

DOI: 10.5220/0004925203280333

In Proceedings of the 3rd International Conference on Operations Research and Enterprise Systems (ICORES-2014), pages 328-333

ISBN: 978-989-758-017-8

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Ibánez et al., 2011, a statistical testing technique),

Gender-based Genetic Algorithm (Ansótegui et al.,

2009), ParamILS ((Hutter et al., 2009), a

metaheuristic based on Iterated Local Search) and

SMAC (Hutter et al 2011, a model-based

optimization method) have shown remarkable results

on several hard algorithm configuration problems

with large numbers of parameters. As an example,

ParamILS has been used to configure the CPLEX

solver with 76 parameters and has achieved a

speedup ratio up to 50 over CPLEX’s default

parameter configuration as well as configurations

got from CPLEX’s automatic tuning tool (Hutter et

al 2010). Several other academic applications of

ParamILS have also been reported on the website of

its authors: http://www.cs.ubc.ca/labs/beta/Projects/

ParamILS/applications.html.

Solving approaches for the automated algorithm

configuration problem so far are single-objective,

i.e., only one performance measure is considered

during the configuring stage. In this paper, we

describe two motivations for the development of a

multi-objective algorithm configurator, in which

multiple performance measures are considered at the

same time. The first one is an algorithm

configuration case study for a single machine

scheduling algorithm, with the requirement of

balancing between target algorithm’s robustness and

speed, the second one is the case when the target

algorithm is a non-exact multi-objective

optimization algorithm.

Please note that there are some works in the

evolutionary computation community that are

dedicated to a Multi-Objective Tuning Problem

(MOTP), such as the tuner BONESA proposed in

Smit et al., 2011. However, MOTP is different from

the multi-objective algorithm configuration

considered in this paper. In MOTP, the problem

instance set is just a limited and small set of

continuous optimization functions, so that it does not

have to deal with the problem of configuration’s

expensive evaluation. The main goal of MOTP is

trying to balance algorithm configurations’

performance over all optimized functions, i.e.,

finding robust algorithm configurations, while the

multi-objective algorithm configuration problem

focus on solving the problem of over-fitting: trying

to deal with a quite large training instance set.

This paper is organized as follows: section 2

describes the first motivation and a proposal of

solving approach, section 3 presents the second

motivation and section 4 draws some conclusions

and future works.

2 THE FIRST MOTIVATION

2.1 Problem Description

The target algorithm considered in this problem is

SiPSi, a single machine scheduling algorithm

proposed in Tanaka et al., 2012. The algorithm and

relevant problem instances are downloadable from

Tanaka’s website (http://turbine.kuee.kyoto-

u.ac.jp/~tanaka/index-e.html). SiPSi is applied on

different single machine scheduling instances with

various sizes (the number of jobs). This algorithm is

single-objective, exact and deterministic. It has 25

parameters, including 14 continuous parameters, 7

integer parameters and 4 categorical parameters.

Among them, 11 parameters are conditional.

In this case study, a pre-defined cut-off time is

specified for each problem size. The running of

SiPSi on a problem instance is stopped when either

an optimal solution is found or the running time

reaches the relevant cut-off time. The goal of the

algorithm configuration task is to find parameter

configurations that have small running time and

large number of optimally solved instances over the

whole instance set. The specification of cut-off time

for each problem size is two-fold: first, when some

researcher develops an algorithm for solving a well-

known problem, some so-far-state-of-the-art method

for that problem usually exists and the researcher

wants to “beat” the performance of this state-of-the-

art algorithm, then problem-size-dependent cut-off

time is an appropriate choice; second, if we are

interested in configuring algorithm for very large

problem’s sizes, e.g., from 500 to thousands of jobs,

a configuring procedure directly deals with a

training instance set of such large sizes is

impossible, in that case, problem instance set with

smaller sizes in which cut-off time is gradually

increased according to problem size can be helpful,

since we can try the configuring procedure on this

alternative problem instance set, in the hope that the

obtained parameter configuration is robust enough to

work well on even unseen and larger problem

instance sizes.

During Tanaka’s manual tuning procedure, he

observed a possible trade-off between the two

mentioned performance measures: “A safe

parameter configuration performs well for many

types of instances, but the algorithm becomes slow,

on the other hand, a tuned set of parameters

improves the speed of the algorithm, but the

performance deteriorates considerably (and

sometimes the algorithm fails to find an optimal

solution) for some specific instances due to

MotivationsfortheDevelopmentofaMulti-objectiveAlgorithmConfigurator

329

parameter sensitivity”. Such an example is shown in

table 1. In this experimental example, the first

parameter configuration, dubbed c

default

, is the

currently default configuration of SiPSi. The second

one, denoted by c

tuned

, is a configuration obtained by

using ParamILS (Hutter et al., 2009), with a

weighted aggregation function of the two

performance measures. Results are tested on 5975

problem instances. From table 1, we can see the

trade-off between the total average running time

over all problem sizes and the total number of

optimally solved instances. The total number of

optimal solutions gained from c

default

is smaller than

tuned

, but the average running time results of c

default

are better and also statistically different throughout

the non-parametric pairwise Wilcoxon test with

significance level 0.05.

Table 1: Summarized performance of two configurations.

#optimal

solutions

#total average

runtime (s)

default

5963

603.2

tune

5970

693.1

From this analysis, the motivation for a multi-

objective automated algorithm configurator becomes

obvious. As being seen in table 1, when we consider

the two performance measures’ values over the

whole test set, incomparable parameter

configurations do exist. Therefore, result obtained

from such a multi-objective algorithm configurator

is a Pareto-approximation set of parameter

configurations. The algorithm designer will do a

manually deeper analysis on the resulting

configurations, such as consideration of average

running time on each problem sizes, the minimum

and maximum running time, the average optimality

gap, etc, to choose the final best algorithm

configuration for future usage.

2.2 Solving Approach

In this part, we discuss our initial idea for a solution

approach. Taking advantage of remarkable

techniques currently available for single-objective

algorithm configuration problem, we try to adapt

them into the multi-objective context. Among the

four groups of single-objective configurators, we

decide to focus on the group of metaheuristics, due

to their significant results on several hard algorithm

configuration problems.

In order to design a solving approach for this

case study, we firstly discuss the question of which

metaheuristic should be chosen. An analysis of

challenges when applying that metaheuristic to our

multi-objective algorithm configuration problem as

well as our proposed solution approach is presented.

Finally, addition of preference information into our

configurator is mentioned.

2.2.1 Choosing a Metaheuristic

Since we are solving an algorithm configuration

problem, chosen metaheuristic should be parameter-

independent as much as possible. We keep this

condition in mind during the search for an

appropriate multi-objective metaheuristic approach.

Multi-objective metaheuristics can be divided

into three major groups: aggregation-based, Pareto-

dominance-based and indicator-based methods

(Basseur et al., 2012). Among them, we decide to

focus on the aggregation-based group. The reason

for our choice is the impossibility of using adaptive

capping strategies in the search procedure when the

two later groups are used. We explain capping

strategies in the next sub-section.

In aggregation-based approaches, all objective-

functions are integrated into a single function

throughout some scalarization technique, in which

various sets of weight for each objective function are

considered sequentially, each set will guide the

search towards a point of optimal Pareto front. The

main advantage of these approaches is that if solving

methods for single-objective version of the

considered problem are already available, we can re-

use them to solve the multi-objective problem in a

fairly straight forward manner. However, these

techniques have a major drawback when the single-

objective algorithm requires expensive

computational cost, since each run of this algorithm

just aims to only one point in the true Pareto front.

Algorithms in this group usually require parameters

for specifying running time amount for each

scalarization. Algorithms’ performance is influenced

by these parameters. To avoid such a parameter

sensitivity, we choose the Adaptive Anytime Two-

Phase Local Search (AA-TPLS) proposed in

Dubois-Lacoste et al 2011, in which these running

time amount values are adaptively chosen based on

information collected from previous runs.

The underlying single-objective algorithm

configurator used in AA-TPLS could be either

ParamILS or GGA, since such a choice is

independent of the general framework of AA-TPLS.

2.2.2 Adaptation: Challenges and Solutions

In this subsection, we firstly describe a group of

techniques, named adaptive capping, for solving the

ICORES2014-InternationalConferenceonOperationsResearchandEnterpriseSystems

330

expensive evaluation problem; then, we discuss

challenges faced in adaptations of the chosen

metaheuristics into our configuration problem, as

well as our initial ideas for solving them.

a) Capping Techniques. The most difficult

challenge in solving algorithm configuration

problems is the expensive evaluation of an algorithm

configuration’s quality, due to the usual large size of

the training instance set. In ParamILS by Hutter et al

2009, special techniques, named adaptive capping

methods, have been developed to reduce the

computational effort required for this task. Given

two parameter configuration c

and c

, a problem

instance set S and a performance measure f that

needs to be minimized, assume that c

has been run

on S already and its performance value is known.

Now we want to compare c

and c

and discard the

worse one. The idea of adaptive capping is to try to

not run c

on the whole set S, but stopping earlier at

some instance according to information collected

before.

Here we briefly describe the two adaptive

capping techniques proposed by Hutter et al 2009,

namely trajectory-preserving and aggressive

capping, and propose some additional adaptive

capping methods to improve the reduction of

computational cost.

 Trajectory-preserving: Let us assume that the

performance measure f is the average running

time over the whole instance set, N is the total

number of problem instances in S, t

and t

are

the total running time of c

and c

, respectively,

on S (t

= f

x N). When we run c

on S, if the

total running time value so far is larger than t

we can stop the run immediately and conclude

that c

is worse than c

, instead of running c

the whole set S.

 Aggressive capping: this is a heuristic version of

trajectory-preserving capping, in which the total

running time t

best

of the best configuration so far

best

is saved and T x t

best

will serve as an upper

bound for the running of other configurations.

Here T is a predefined ratio (T = 2 in ParamILS’s

setting). When a configuration c

is run on S, if t

got so far exceeds the upper bound, c

’s run is

stopped.

 Additional capping methods: In our case study,

the target algorithm is deterministic. We do not

have to deal with the difficulty of stochastic

evaluation. Hence, another capping idea is that

for each parameter configuration c and each

problem instance p, the performance of c on p is

saved when its running time exceeds a pre-

defined threshold (we do not save all cases for

reasons of memory size). This information is

useful when c is revisited. Moreover, from this

information, we can also roughly predict

performance of a configuration c

on p if c

’s

neighbors have been run on p so far. The

predicted value could be a weighted sum of c

’s

neighbors’ performance values on p, whereas the

weight is smaller for larger dissimilarity between

p and the neighbor. For a good prediction, it is

reasonable to have an upper bound for the

dissimilarity between c

and its considered

neighbors.

b) Adaptation of AA-TPLS. First, we briefly

describe general ideas of the AA-TPLS in

Dubois-Lacoste et al 2011. The AA-TPLS

algorithm has two phases. In the first phase, the

available single-objective algorithm is separately

applied on a randomly chosen objective function

to conduct an initial solution for the next phase.

(Application on all objective functions is also

possible. In this case, the best solution according

to the first scalarization in phase 2 will be taken.)

Then, in the second phase, a sequence of

scalarizations will be called; the single-objective

algorithm is used to solve the problem at each

scalarization. Solution obtained from a

scalarization will be used as the initial solution

for its succeeding scalarization. Non-dominated

solutions are also saved in an archive. The set of

weight for each objective function in each

scalarization is adaptively determined based on

solutions from previous scalarization to

guarantee the coverage the true-Pareto front.

The challenge when applying AA-TPLS to our

problem lies in the algorithm’s sequential

implementation. Each step in phase 2 just provides

only one solution, so that if the single-objective

algorithm requires too large running time, it might

be impossible to get a reasonable number of Pareto-

optimal solutions. In the literature of algorithm

configuration techniques, for problem with large

number of parameters (more than 24), the

appropriate amount of each configurator’s run

should be at least 10 hours. Therefore, the sequential

implementation of AA-TPLS should be modified in

order to deal with such an expensive computational

running time. Here we propose a parallelization of

AA-TPLS’s phase 2 as depicted in Figure 1. We still

keep a part of the sequential property due to its

important role: adapting weight values in

scalarizations based on information from previous

steps to ensure the diversity of the obtained

approximation front. The new scheme of phase 2 has

MotivationsfortheDevelopmentofaMulti-objectiveAlgorithmConfigurator

331

k sequential steps. At each step, n different

scalarizations are run in parallel. In order to guide

the search better, we can let them cooperate with

each other: after some time interval, the best

solutions obtained so far of every parallel

scalarization are put into a global archive, then each

scalarization will check this archive for a better

solution than the best one found by itself, based on

its currently used set of weight, if such a solution

exists, it will be updated into the scalarization

searching process.

It is worth noting that besides the usage of

capping strategies mentioned in previous part,

performance value (for each objective function) of

the best solution found so far on every run problem

instances will also be saved, and the order of

training instances considered in every parallel

scalarization at the same step are fixed. Thanks to

that, when the best configuration c from some

scalarization s

is considered for entering some other

scalarization s

, the computational cost of evaluating

c according to the s

’s set of weight will be lower,

since we just need to run c on problem instances in

that have not been saved yet.

Besides, order of instances in the training set also

influences ParamILS’s or GGA’s results. Since at

each iteration, just a subset of the training set is used

for configuring in order to save computational cost,

this subset is extended gradually after time, so that

the more iterations the algorithm runs, the more

exact the estimation of performance measure value

on the whole training set is. Therefore, in this AA-

TPLS, to deal with such a variance, order of training

instances are randomly shuffled after each step of

phase 2.

Figure 1: Parallel scheme of AA-TPLS’s phase 2.

2.2.3 Integration of Preference Information

Trade-off between two considered performance

measures is possible. For example, given two

configurations c

and c

, if the percentage of

corresponding optimal solutions are respectively

90% and 70%, while the total average running time

of c

is just some second less than c

, c

is certainly

preferred. Consequently, extreme points towards the

average running time axis are not interesting and

could be ignored. Moreover, configurations with

small optimality gap for hard unsolved instances are

also preferable. Integration of such preference

information into the configuration algorithm is

useful to reduce the computational effort and make a

better matching with algorithm designer’s desire.

We are in presently collaborating with Tanaka, the

author of the target algorithm SiPSi, to identify

characteristics of this integration.

3 THE SECOND MOTIVATION

In this section, we explain the second algorithm

configuration problem supporting the need for a

multi-objective algorithm configurator: the case

when the target algorithm is a non-exact Multi-

Objective Optimization Algorithm (MOOA).

Given a MOOA configuration c and problem

instance p, the result obtained from a run of c on p is

an approximation set of the optimal Pareto front. In

order to compare two MOOA configurations based

on p, we can use different performance assessment

methods, including unary indicators, binary

indicators, statistical testing on multiple-run and

attainment function analysis. We refer to Ziztler et

al., 2008 for a comprehensive description. Among

these methods, the unary indicator approaches, in

which a real-value is assigned to each approximation

set to define a total order in the objective function

space, are the ones that usually require the lowest

computational cost. However, each indicator has its

own preference and might bias towards some

specific parts the true Pareto front. As suggested in

Knowles et at., 2006: “Each unary indicator is based

on different preference information - therefore using

them all will provide more information than using

just one”. Indeed, different unary indicators could

give inconsistent conclusion, as observed in the

experimental results of Jaeggi et al 2008. Moreover

preference of some unary indicators have been

theoretically shown, as e.g. in the analysis of

hypervolume indicator in Auger et al., 2012 and of

the R2 indicator in Brockhoff et al., 2012. Hence,

the configuration task for a MOOA could be done as

follows: first, a multi-objective algorithm

configurator is used to find a set of good parameter

configurations based on a set of unary indicators as

performance measures; then, a post-processing step

starts, in which a final best algorithm configuration

is decided based on more expensive assessment

methods, e.g., statistical testing over several runs

with different indicators.

Scalarization

…

Scalarization

…

Step 1

Step k

ICORES2014-InternationalConferenceonOperationsResearchandEnterpriseSystems

332

4 CONCLUSIONS

In this paper, we present two algorithm

configuration problems in which more than one

performance measures should be considered at the

same time, leading to a multi-objective algorithm

configurator. Development of the solving approach

is still in progress. We are currently focusing on the

first problem: balancing between algorithm

configuration’s robustness and speed, while the

second one is reserved for our future work. Although

several single-objective configurators with

significant performance have been proposed in the

literature, the application in a multi-objective

context is quite challenging. However, we believe

that such an effort is worthwhile. The consideration

of more than one algorithm performance measure

during the automated configuration process and the

postponement of the final choice to a deeper analysis

in a post-processing phase will give more flexibility

to the algorithm designer. Indeed, the definition of a

good algorithm configuration in practice usually

depends on various performance perspectives.

ACKNOWLEDGEMENTS

The authors would like to thank Professor Thomas

Stutzle for his valuable comments. This work is

supported by the Belgian Science Policy Office

(BELSPO) in the Interuniversity Attraction Pole

COMEX. (http://comex.ulb.ac.be) and by Research

Foundation Flanders (FWO).

REFERENCES

Ansótegui, C., Sellmann, M., & Tierney, K. (2009). A

gender-based genetic algorithm for the automatic

configuration of algorithms. In Principles and

Practice of Constraint Programming-CP 2009 (pp.

142-157). Springer Berlin Heidelberg.

Basseur, M., Zeng, R. Q., & Hao, J. K. (2012).

Hypervolume-based multi-objective local search.

Neural Computing and Applications, 21(8), 1917-

1929.

Brockhoff, D., Wagner, T., & Trautmann, H. (2012). On

the Properties of the R2 Indicator. In Proceedings of

the fourteenth international conference on Genetic and

evolutionary computation conference (pp. 465-472).

ACM.

Dubois-Lacoste, J., López-Ibáñez, M., & Stützle, T.

(2011). Improving the anytime behavior of two-phase

local search. Annals of mathematics and artificial

intelligence, 61(2), 125-154.

Hoos, H. H. (2012). Automated algorithm configuration

and parameter tuning. In Autonomous Search (pp. 37-

71). Springer Berlin Heidelberg.

Hutter, F., Hoos, H. H., Leyton-Brown, K., & Stützle, T.

(2009). ParamILS: an automatic algorithm

configuration framework. Journal of Artificial

Intelligence Research, 36(1), 267-306.

Hutter, F., Hoos, H. H., & Leyton-Brown, K. (2010).

Automated configuration of mixed integer

programming solvers. In Integration of AI and OR

Techniques in Constraint Programming for

Combinatorial Optimization Problems (pp. 186-202).

Springer Berlin Heidelberg.

Hutter, F., Hoos, H. H., & Leyton-Brown, K. (2011).

Sequential model-based optimization for general

algorithm configuration. In Learning and Intelligent

Optimization (pp. 507-523). Springer Berlin

Heidelberg.

Jaeggi, D. M., Parks, G. T., Kipouros, T., & Clarkson, P.

J. (2008). The development of a multi-objective tabu

search algorithm for continuous optimisation

problems. European Journal of Operational Research,

185(3), 1192-121

Knowles, J., Thiele, L., & Zitzler, E. (2006). A tutorial on

the performance assessment of stochastic

multiobjective optimizers. Tik report, 214, 327-332.

López-Ibánez, M., Dubois-Lacoste, J., Stützle, T., &

Birattari, M. (2011). The irace package, iterated race

for automatic algorithm configuration. IRIDIA,

Université Libre de Bruxelles, Belgium, Tech. Rep.

TR/IRIDIA/2011-004.

Smit, S. K., & Eiben, A. E. (2011). Multi-problem

parameter tuning using BONESA. In Artificial

Evolution (pp. 222-233).

Stützle, T., & López-Ibáñez, M. (2013, July). Automatic

(offline) configuration of algorithms. In Proceeding of

the fifteenth annual conference companion on Genetic

and evolutionary computation conference companion

(pp. 893-918). ACM.

Tanaka, S., & Fujikuma, S. (2012). A dynamic-

programming-based exact algorithm for general

single-machine scheduling with machine idle time.

Journal of Scheduling, 15(3), 347-361.

Zitzler, E., Knowles, J., & Thiele, L. (2008). Quality

assessment of pareto set approximations. In

Multiobjective Optimization (pp. 373-404). Springer

Berlin Heidelberg.

MotivationsfortheDevelopmentofaMulti-objectiveAlgorithmConfigurator

333
