New Trends in Knowledge Driven Data Mining

Cláudia Antunes and Andreia Silva

Instituto Superior Técnico, Universidade de Lisboa, Av Rovisco Pais, Lisboa, Portugal

Keywords: Domain Knowledge, Semantic Aspects of Data Mining, Domain Driven Data Mining, Constrained Data

Mining, Knowledge Representation, Domain Ontologies.

Abstract: Existing mining algorithms, from classification to pattern mining, reached considerable levels of efficiency,

and their extension to deal with more demanding data, such as data streams and big data, show their

incontestable quality and adequacy to the problem. Despite their efficiency, their effectiveness on

identifying useful information is somehow impaired, not allowing for making use of existing domain

knowledge to focus the discovery. The use of this knowledge can bring significant benefits to data mining

applications, by resulting in simpler and more interesting and usable models. However, most of existing

approaches are concerned with being able to mine specific domains, and therefore are not easily reusable,

instead of building general algorithms that are able to incorporate domain knowledge, independently of the

domain. In our opinion, this requires a drift in the focus of the research in data mining, and we argue this

change should be from domain-driven to knowledge-driven data mining, aiming for a stronger emphasis on

the exploration of existing domain knowledge for guiding existing algorithms.

1 INTRODUCTION

The rise of information society and its increasing

maturity, allied to the more recent explosion of big

data, made even clearer the need of efficient

techniques for mining unknown information from

data. In the last two decades, the field of data mining

(DM) proved to be effective when applied to almost

all domains and a large range of kinds of data, from

structured sources, as databases, to non-structured

ones, like social networks and text. However, this

success is mainly reached in classification tasks,

where the goal is clearly defined and is possible to

make use of past records, in order to predict new

outcomes. Indeed, when this is not the case, the

results are far from being useful per se in the

majority of situations.

Pattern mining is a paradigmatic mining task,

where this phenomenon occurs – existing

approaches discover either a small number of

irrelevant patterns or a very large number (usual

thousands) of possibly interesting ones. The

difficulty is just on choosing the best ones to

analyze, but the great variety of interestingness

measures available do not help on choosing the right

ones in accordance to user interests or expectations.

Actually, the advances in the area of data mining

are mainly centered on dealing with a wider range of

types of data and domains, and much less on the

quality of the models discovered, at least in terms of

their simplicity and easyness of interpretation. The

identified problem is not new, and was addressed by

different techniques, through ILP (Inductive Logic

Programming) or D3M (Domain-Driven Data

Mining) fields. In this paper, we discuss the reasons

for the failure of those approaches. Despite all the

progress made, most of them are focused on mining

specific domains, and therefore cannot be easily

reused in different domains, even if the domain

knowledge is represented with the same formalisms.

In this sense, we argue that it is necessary a drift

from domain-driven to knowledge-driven data

mining, and focus should be given to the definition

of techniques that are able to introduce domain

knowledge deep into existing and more general

algorithms.

Moreover, we argue that the best way to

approach this problem is to use more general

techniques, guided by domain knowledge,

represented through domain ontologies. We base our

argument on a clear problem statement and discuss

how algorithms may be adapted to be driven by

existing knowledge. Beside referring some

preliminar results, we discuss how the improvements

may be measured, in order to validate the real gains.

346

Antunes C. and Silva A..

New Trends in Knowledge Driven Data Mining.

DOI: 10.5220/0004974003460351

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 346-351

ISBN: 978-989-758-027-7

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

2 THE LANDSCAPE OF

KNOWLEDGE IN DM

The use of domain knowledge has been explored in

data mining since its early years, in a somehow

independent manner among different areas.

The first effort was undoubtedly made through

Inductive Logic Programming (ILP for short), which

is a paradigm of machine learning that is concerned

with inducing classification rules from examples and

background knowledge, all of which expressed as

Prolog programs (Lavrac et al. 2011) (Nienhuys-

Cheng and Wolf 1997), (Lisi and Malerba 2004),

(Lisi and Esposito 2009). It was born from the

interception of Concept Learning and Logic

Programming, with the goal of prediction within the

representation framework of Horn Clausal Logic.

The fact that all information must be written in

declarative languages (like Prolog and Datalog) is

one of the drawbacks of ILP approaches, and one of

the reasons for not being widely used. Nevertheless,

its structure promotes the representation and use of

domain knowledge. There are many ILP algorithms

that are able to introduce this knowledge into the

discovery process (see, for example, (Raedt and

Ramon 2004), (Malerba and Lisi 2001), (Levy and

Rousset 1998), (Rouveirol and Ventos 2000)).

ILP techniques must also deal with the tradeoff

between expressiveness and efficiency of the used

representations. Studies show that current algorithms

would scale relatively well as the amount of

background knowledge increases. But they would

not scale, at all, with the number of relations

involved, and in some cases, with the complexity of

the patterns being searched (Dzeroski 1996), (Lisi

and Malerba 2004).

A second strategy, was relying in the shoulders

of users / experts to guide the discovery, by

choosing the most promising search paths. These

interactive approaches (Nag, Deshpande and DeWitt

1999), (Goethals and Bussche 2000), (Goethals,

Moens and Vreeken 2011), (Druck and McCallum

2011) use users feedback iteratively and

incrementally, allowing them not only to view the

intermediate results, but also to chose the best steps

and measures, and even to change parameters. In

this sense, users understand more easily what

decisions lead to what results, therefore leading to

more interesting results, in their perspective.

However, one on the problem of these systems is

that users do not always know what they want, or

what are the best choices. And besides being hard to

define and implement, more elaborated domains

may make this process too labor intensive and error

prone. Furthermore, it is not straightforward the

reuse of the knowledge and efforts applied before.

More recently, the methodology of Domain

Driven Data Mining, D3M, was proposed (Cao and

Zhang 2006), (Cao 2008), (Cao 2010), defending an

urgent need for Actionable Knowledge Discovery to

support businesses and applications.

The motivation behind D3M is the gap between

academic objectives (innovation, performance and

generalization) and business goals (problem

solving), and between academic outputs and

business expectations (Cao et al. 2010). So that this

new data mining paradigm can be better accepted

and advantageously applied in real businesses and

applications, it is necessary to create methods and

tools capable of analyzing real world data and

extracting actionable knowledge, i.e. useful

information that can be (as far as possible) directly

converted into decision-making actions. The term

“actionability” measures the ability of a pattern to

prompt a user to take concrete actions to his

advantage in the real world (Cao, Luo and Zhang

2007) .

To achieve that, data mining must involve the

ubiquitous intelligence surrounding the business

problem, such as human intelligence, domain

intelligence, network and organizational/social

intelligence (Cao et al. 2010). D3M proposes,

therefore, a paradigm shift from data-centered

knowledge discovery to domain-driven actionable

knowledge discovery.

Research included in this area of D3M has been

centered on the proposal of methods dedicated to

specific domains, with a special emphasis on the

actionability of the results. The specificity of those

methods difficult their application to other domains,

and the need for a standard methodology that is able

to incorporate the existing knowledge of any domain

into the mining process remains an open issue. In

our opinion, existing work in D3M is more centered

in the actionability of results in some domain, than

on the reuse of the proposed strategies.

Along with the efforts in D3M, the use of

existing domain knowledge to enrich the mining

process has been explored under the umbrella of

Semantic Aspects of Data Mining, by trying to add

semantics to data under analysis.

The simplest approach, usually known as

semantic annotation (Diamantini and Potena 2008),

(Liu 2010), is just to use existing knowledge to

annotate data, in order to help users understanding

the data, and use it to get better results. This

approach is gaining more adepts with the

development of the Semantic Web, making it more

NewTrendsinKnowledgeDrivenDataMining

347

plausible.

A second alternative is to use the semantics of

some specific domain, represented through sound

knowledge representation formalisms, to guide the

mining algorithms, as proposed in (Antunes 2009),

(Novak et al. 2009), (Jozefowska, Lawrynowicz and

Lukaszewski 2010).

In this paper, we argue in favor of this last

approach, and discuss the use of domain knowledge

to guide DM algorithms in the search for more

focused results.

3 KNOWLEDGE DRIVEN DATA

MINING

The use of domain knowledge to improve the

mining process tries to accomplish two main goals:

to find more accurate and more easily

understandable models.

A paradigmatic technique, that pursues these two

goals are Bayesian networks (Pearl 1988), where a

directed acyclic graph represents the known

dependencies among variables, and algorithms are

able to estimate a classification model. However, the

difficulties on automatically designing these

networks are well known, being this problem NP-

hard (Heckerman, Geiger and Chickering 1995).

Indeed, these networks are one of the preferred

models, for example among physicians (see for

example (Kononenko 1997)), since they are easily

understandable reflecting cause-effects

dependencies, usually known and described by

them. Other techniques, like support vector

machines or ensemble, whose discovered models are

too hard to interpret, are actually put away, despite

their major accuracy.

In our opinion, the great advantage of these

models is their graphical representation, being

completely clear to any informed user. When

thinking about graphical knowledge representation

formalisms, taxonomies and ontologies are the

counterparts of Bayesian networks.

Before proceeding, we briefly overview the

meaning of taxonomies and domain ontologies.

3.1 Knowledge Representation

Modelling has been one of the core parts of

information science, either in information systems or

in artificial intelligence. In both ones, it is generally

accepted that without a good model, no system

works adequately.

The advances in the areas of modeling and

knowledge representation allow for using the

developed mature formalisms to represent existing

knowledge, and therefore making possible the

exploration of those models to guide the discovery

process. In particular, ontologies have gained a

central role, for example in the semantic web, and

begun to be used in many other contexts.

Ontologies are content theories about the objects,

their properties and relations, that are possible in a

specified domain of knowledge (Chandrasekaran,

Josephson and Benjamins 1999), along with a set of

explicit assumptions regarding the intended meaning

of the vocabulary words (Lisi and Esposito 2009).

An ontology captures the intrinsic conceptual

structure of the domain. In its simplest case, it

describes a hierarchy of concepts related by is-a

relations, a taxonomy. In more complex cases, other

relationships can be added, as well as a set of axioms

to help and constrain the interpretation of concepts.

One of the most important features of ontologies is

that they are valid, independently of the individuals

or instances belonging to the domain.

Formally, an ontology is a tuple O:=(C,≤

,R,A),

where C corresponds to the set of concept identifiers

(or just concepts) in the ontology, ≤

to the

hierarchy of concepts, i.e. the is-a relations between

concepts, R is the set of relation identifiers, and A a

set of axioms. Relations referring to just one concept

are called the attributes.

Among the formalisms proposed by Ontological

Engineering for the construction of ontologies, the

most currently used are Description Logics (DL)

(Baader et al. (eds.) 2003). DLs are a family of First

Order Logic fragments that allow for the

specification of knowledge in terms of classes

(concepts), relations (roles) and instances

(individuals). A DL knowledge base (KB) consists

in a terminological (schema) part, called T-Box, and

an assertional (data) part, called A-Box. The T-Box

part is where an ontology can be defined, and the A-

Box corresponds to the database, with all the

instances. The T-Box is usually referred to simply as

the ontology, and the A-Box as one of the possible

knowledge bases associated with that ontology.

Moreover, ontologies describe the context in which

the instances should be understood.

In a pragmatically view, an ontology just defines

a directed graph, with concepts represented by nodes

and relations by edges, which can be efficiently

traversed by search domain-independent algorithms.

In addition they incorporate axioms, which can be

useful for describing additional constraints. In this

sense, ontologies are a perfect tool to incorporate the

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

348

represented knowledge deep into the mining process.

3.2 Knowledge Exploration

As discussed before, the idea of using knowledge to

enrich the mining process is not new, and has been

explored by data mining methods, but only seldom,

and without having any significant results.

Examples of such approaches are the ones that

used taxonomies to bias the discovery process

(Srikant and Agrawal 1995) for pattern mining, but

also (Zhang, Silvescu and Honavar 2002) in the

classification context). In those methods, the main

idea was to use the taxonomy to decide the best level

of abstraction to consider, given the data under

analysis. Indeed, items have different levels of

support, when represented at different levels of

abstraction.

As a more expressive form of knowledge

representation than taxonomies, it is expected that

ontologies can help guiding data mining algorithms

finding more interesting results. The use of

ontologies in data mining with this purpose is recent,

and great parts of existing works are ad-hoc

applications to specific problems.

Our claim is based on three points. First, through

the taxonomy present in the domain ontology, data

may be mined at the most interesting granularity,

which is chosen on the fly, and allowing for

spanning patterns at different granularities. Along

with this use, it is then possible to reduce the time

spent on data understanding and preparation steps in

the mining process (Wirth and Hipp 2000).

Second, relations other than is-a relations,

described in the ontology, may be used to filter the

patterns that should be considered useful, reducing

the complexity of the models, either the number of

patterns or the depth / number of rules in

classification models.

Third, axioms may be used to automatize the

annotation of the data, by allowing for the automatic

inference of information from the original data, and

the posterior use of this information for being mined

along with the data.

Recent work (Antunes and Bebiano 2012) has

demonstrated that constraints defined over

ontologies may be used by constrained adaptations

of the most-well known algorithms for pattern

mining, namely apriori (Agrawal and Srikant 1994)

and FP-growth (Han, Pei and Yin 2000), without

impairing their efficiency, but enabling the reduction

of the number of patterns discovered, focusing the

discovery according to user expectations.

In this new context, constraints have to perform

three complementary roles – being the mapper, the

matcher and the filter.

The mapper is the responsible for linking the

data to be mined to the knowledge represented in the

domain ontology. It should be a function from the

set of items in the dataset to the concepts in the

ontology. By making this connection, it is then

possible to mine the concepts instead of the

individuals, reducing the number of distinct

elements during the mining process, which results in

a smaller number of patterns and a simplification of

the information discovered.

As a matcher, the constraint should be able to

apply equivalences among entities. It should be a

predicate among entities, either individuals or

concepts. The goal is to allow for considering known

and represented knowledge about the items, for

example equivalences, which may be useful for

choosing the right granularity and for counting the

frequency of each item. Like the mapper, the

matcher would allow for the simplification of the

models, and the simplification of the pre-processing

step.

At last, being a filter, the constraint avoids

exploring search branches that are not interesting in

accordance to user expectations. This filter would be

a predicate over sets of entities (patterns in pattern

mining and rules in classification).

Figure 1: Process for knowledge exploration through the use of ontology-based constraints.

Mining Visualization

Constraints

Algorithms

Data

Domain

knowledge

Expectations

Information

Pre‐processing

NewTrendsinKnowledgeDrivenDataMining

349

In all cases, and despite the different roles

played, constraints should be used as a decision -

maker by the mining algorithm. They should be the

responsible for all decisions in the mining process,

in particular for counting the frequency of each

entity and for deciding which entities should be

considered.

In this manner, the mining process becomes to be

controlled by constraints, which at the end are just

the mean to incorporate the domain knowledge deep

into the mining process

Figure 1.

4 VALIDATION

The simplification of the models discovered during

the mining process is mandatory, either for reducing

the bias of the models, or just for simplifying user

understanding. However, how can we measure the

improvements made by knowledge-driven

approaches?

This measure is not straightforward since a

simple count of the reduction on the number of

patterns or rules discovered, against the counterpart

in non-constrained algorithms, is not enough to

assess the gains. Indeed, through the use of

taxonomies is always possible to find just one rule

with 100% of support, however this rule does not

envisage any information.

In terms of efficiency, it is expected that

constrained algorithms would follow a more

complex process, more time consuming, since it is

necessary to assure that the results are accordingly to

the constraints. However, and as previous

experiments show (Silva and Antunes 2013), the

more expensive tasks in the mining step are the ones

that scan the database for counting frequency of

entities. So, and since constrained algorithms may

reduce considerably these scans, it is expected that

time efficiency of original algorithms remain

unaffected. In order to measure the increase of time

spent due to the complexity of the constrained task,

we may measure the average time spent for finding

each pattern, against the time spent in non-

constrained approaches.

In terms of efficacy, the important issues are the

quality of the discovered models and their

simplicity. Naturally, the first issue may be

measured through available measures, like support,

confidence and lift for patterns, and accuracy,

sensibility and specificity for classification.

The second assessment is much harder, and has

to pass through the analysis of the compactness of

the models discovered. One of the possible

approaches is to compute the average number of

non-constrained patterns / rules covered by a single

constrained one, and the lost of interest of that

condensed pattern / rule.

Note that this coverage identification is only

possible, recurring to the ontology, which

establishes the relation among the discovered

entities.

5 CONCLUSIONS

The incorporation of domain knowledge, deep into

the mining process, is expected to focus the search

and modeling process, allowing for finding more

interesting results. Despite the advances, most of the

existing work is designed for some specific domain,

and therefore cannot be reused.

In this position paper, we claim for a change in

the data mining research, from a data-driven to a

knowledge-driven process. We argue that

knowledge represented through mature formalisms

for knowledge representation, such as ontologies,

can be used to define constraints, which may guide

the mining process, by being responsible for the

most important decisions in the mining step.

Beside the definition of the main roles to be

played by constraints, we discuss different ways to

assess the improvements on the discovered

information, in terms of both efficiency and efficacy.

ACKNOWLEDGEMENTS

This work is partially supported by FCT Fundação

para a Ciência e a Tecnologia, under research project

D2PM (PTDC/EIA-EIA/110074/2009).

REFERENCES

Agrawal, R and Srikant, R 1994, 'Fast Algorithms for

Mining Association Rules', Int'l Conf on Very Large

Data Bases, Morgan Kaufmann, Chile.

Antunes, C 2009, 'Mining Patterns in the Presence of

Domain Knowledge', Int'l Conf on Enterprise

Information Systems, INSTICC, Italy.

Antunes, C and Bebiano, T 2012, 'Mining Patterns with

Domain Knowledge: a case study on multi-language

data. In', Int'l Conf on Information Systems (ACIS ICIS

2012), IEEE Press.

Baader, Franz, Calvanese, D, McGuinness, DL, Nardi, D,

Patel-Schneider, PF (eds.) 2003, The Description

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

350

Logic Handbook: Theory, Implementation, and

Applications, Cambridge University Press.

Cao, L 2008, 'Domain driven data mining (d3m)', 2008

IEEE Int. Conf. on Data Mining Workshops (DDDM

08), IEEE Computer Society.

Cao, L 2010, 'Domain-Driven Data Mining: Challenges

and Prospects', IEEE Transactions on Knowledge and

Data Engineering, vol 22, no. 6, pp. 755-769.

Cao, L, Luo, D and Zhang, C 2007, 'Knowledge

actionability: satisfying technical and business

interestingness', Int'l Journal of Business Intelligence

and Data Mining, vol 2, no. 4, p. 496–514.

Cao, L, Yu, P, Zhang, C and Zhang, H 2010, Data Mining

for Business Applications, Springer.

Cao, L and Zhang, C 2006, 'Domain-driven data mining:

A practical methodology', Int. Journal Data

Warehousing and Mining, vol 2, no. 4, p. 49–65.

Chandrasekaran, B, Josephson, JR and Benjamins, VR

1999, 'What Are Ontologies, and Why Do We Need

Them?', IEEE Intelligent Systems, vol 14, no. 1, p. 20–

26.

Diamantini, C and Potena, D 2008, 'Semantic annotation

and services for kdd tools sharing and reuse ', 2008

IEEE Int. Conf. on Data Mining Workshops (ICDMW

08), IEEE, Pisa, Italy.

Druck, G and McCallum, A 2011, 'Toward interactive

training and evaluation', ACM Int'l Conf on

Information and Knowledge Management, ACM.

Dzeroski, S 1996, 'Inductive logic programming and

knowledge discovery in databases', in Advances in

Knowledge Discovery and Data Mining, MIT Press.

Goethals, B and Bussche, J 2000, 'On Supporting

Interactive Association Rule Mining', Int'l Conf Data

Warehousing and Knowledge Discovery, Springer.

Goethals, B, Moens, S and Vreeken, J 2011, 'MIME: a

framework for interactive visual pattern mining', ACM

SIGKDD Int'l Conf on Knowledge discovery and data

mining (KDD 11), ACM.

Han, J, Pei, J and Yin, Y 2000, 'Mining Frequent Patterns

without Candidate Generation', Int'l Conf. on

Management of Data, ACM Press, TX.

Heckerman, D, Geiger, D and Chickering, DM 1995,

'Learning Bayesian Networks: The Combination of

Knowledge and Statistical Data', Machine Learning,

vol 20, pp. 197-243.

Jozefowska, J, Lawrynowicz, A and Lukaszewski, T 2010,

'The role of semantics in mining frequent patterns

from knowledge bases in description logics with rules',

Theory Practical Logical Programming, vol 10, no. 3,

p. 251–289.

Kononenko, I 1997, 'Machine learning for medical

diagnosis: history, state of the art and perspective', in

RS Michalski, I Bratko, M Kubat (eds.), Machine

Learning and Data Mining: Methods and

Applications, Wiley.

Lavrac, N, Vavpetic, A, Soldatova, LN, Trajkovski, I and

Novak, PK 2011, 'Using ontologies in semantic data

mining with segs and g-segs', Int'l Conf on Discovery

Science (DS 11), Finland.

Levy, A and Rousset, M-C 1998, 'Combining horn rules

and description logics in carin', Artificial Intelligence,

vol 104, no. 1, p. 165–209.

Lisi, F and Esposito, F 2009, 'On ontologies as prior

conceptual knowledge in inductive logic

programming', Studies in Computational Intelligence,

vol 220, p. 3–17.

Lisi, F and Malerba, D 2004, 'Inducing multi-level

association rules from multiple relations', Machine

Learning, vol 55, no. 2, p. 175–210.

Liu, H 2010, 'Towards semantic data mining', Int'l

Semantic Web Conf. (ISWC 10).

Malerba, D and Lisi, F 2001, 'Discovering associations

between spatial objects: An ilp application', Int'l Conf.

on Inductive Logic Programming (ILP 01), Springer-

Verlag, London, UK.

Nag, B, Deshpande, PM and DeWitt, DJ 1999, 'Using a

knowledge cache for interactive discovery of

association rules', ACM SIGKDD Int'l Conf

Knowledge Discovery and Data Mining, ACM.

Nienhuys-Cheng, S-H and Wolf, RD 1997, Foundations of

Inductive Logic Programming, Springer-Verlag.

Novak, P, Vavpetic, A, Trajkovski, I and Lavraˇc, N 2009,

'Towards semantic data mining with g-segs', Int'l

Multiconference Information Society (IS 09).

Pearl, J 1988, Probabilistic reasoning in intelligent

systems: networks of plausible inference, Morgan

Kaufmann.

Raedt, LD and Ramon, J 2004, 'Condensed representations

for inductive logic programming', Int'l Conf. on

Principles of Knowledge Representation and

Reasoning, AAAI Press.

Rouveirol, C and Ventos, V 2000, 'Towards learning in

carin-aln', Int'l Conf. on Inductive Logic Programming

(ILP 00), Springer-Verlag.

Silva, A and Antunes, C 2013, 'Pushing Constraints into a

Pattern-Tree', Int'l Conf. on Modeling Decisions for

Artificial Intelligence (MDAI 2013), Springer.

Srikant, R and Agrawal, R 1995, 'Mining Generalized

Association Rules', Int'l Conf on Very Large

Databases, Morgan Kaufmann, Switzerland.

Wirth, R and Hipp, J 2000, 'CRISP-DM: Towards a

Standard Process Model for Data Mining', Int'l Conf.

on the Practical Application of Knowledge Discovery

and Data Mining.

Zhang, J, Silvescu, A and Honavar, V 2002, 'Ontology-

driven induction of decision trees at multiple levels of

abstraction', in Abstraction, reformulation, and

approximation, Springer.

NewTrendsinKnowledgeDrivenDataMining

351
