Web-based Demonstration of Semantic Similarity Detection Using

Citation Pattern Visualization for a Cross Language Plagiarism Case

Bela Gipp

1,2

, Norman Meuschke

1,2

Corinna Breitinger

, Jim Pitman

and Andreas Nürnberger

University of California Berkeley, Berkeley, U.S.A.

Otto-von-Guericke University, Magdeburg, Germany

Keywords: Plagiarism Detection, Citation Analysis, Similarity Visualization.

Abstract: In a previous paper, we showed that analyzing citation patterns in the well-known plagiarized thesis by

K. T. zu Guttenberg clearly outperformed current detection methods in identifying cross-language

plagiarism. However, the experiment was a proof of concept and we did not provide a prototype. This paper

presents a fully functional, web-based visualization of citation patterns for this verified cross-language

plagiarism case, allowing the user to interactively experience the benefits of citation pattern analysis for

plagiarism detection. Using examples from the Guttenberg plagiarism case, we demonstrate that the citation

pattern visualization reduces the required examiner effort to verify the extent of plagiarism.

1 INTRODUCTION

Detecting academic plagiarism is an important task

that remains tedious, especially for disguised

plagiarism forms, such as paraphrases or

cross-language plagiarism, because these forms

exhibit little or no literal text overlap. Plagiarism

detection systems (PDS) facilitate the identification

of plagiarism, yet their detection and visualization

capabilities are limited.

Today’s PDS are typically web-based and allow

users to upload documents for which the system

retrieves suspiciously similar documents from a

large reference collection, which often includes a

subset of the Web (Stein et al. 2011). PDS in

practical use rely exclusively on literal text string

comparisons. The systems examine the percentage

of lexical overlap among documents and treat

overlap above a pre-defined threshold as an indicator

for potential plagiarism. Subsequent to retrieving

similar sources, systems rank the sources by

“similarity score” and highlight the sections with the

highest lexical similarity for user inspection. Due to

their literal detection approach, current PDS capably

identify copies, but fail to detect disguised

plagiarism, including paraphrases or cross-language

plagiarism (Weber-Wulff 2012).

2 RELATED WORK

In previous work, we introduced Citation-based

Plagiarism Detection (CbPD) and showed that this

approach can significantly increase the detection rate

for disguised plagiarism (Gipp et al. 2011). CbPD

examines order, proximity, and distinctiveness of

in-text citations in academic literature to identify

citation patterns that can serve as a

language-independent similarity characteristic (Gipp

and Meuschke 2011). We examined the prominent

plagiarism case of Germany’s former Minister of

Defense, Karl Theodor zu Guttenberg, as a

preliminary assessment of CbPD’s ability to detect

disguised plagiarism (Gipp et al. 2011).

Guttenberg’s thesis is one of the most thoroughly

investigated plagiarism cases to date. Volunteers of

the crowd-sourced GuttenPlag Wiki project

(GuttenPlag Wiki 2011) manually examined the

thesis and revealed approx. 64 % of all lines of text

to be plagiarized.

The barcode representation of the thesis in

Figure 1 illustrates this finding.

Figure 1: Plagiarized pages in Guttenberg’s thesis

(GuttenPlag Wiki 2011).

677

Gipp B., Meuschke N., Breitinger C., Pitman J. and Nürnberger A..

Web-based Demonstration of Semantic Similarity Detection Using Citation Pattern Visualization for a Cross Language Plagiarism Case.

DOI: 10.5220/0004985406770683

In Proceedings of the 16th International Conference on Enterprise Information Systems (ISS-2014), pages 677-683

ISBN: 978-989-758-028-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Red bars in Figure 1 represent pages with plagiarism

from multiple sources, while black bars indicate

pages with plagiarism from a single source. White

bars represent pages on which no plagiarism was

found and blue sections represent the table of

contents and bibliography.

We applied the CbPD algorithms to the verified

cases of cross-language plagiarism in Guttenberg’s

thesis and compared the performance of our

algorithms to state-of-the-art PDS. The CbPD

algorithms identified 13 of the 16 instances of

cross-language plagiarism in the thesis, while the

other tested PDS found none (Gipp et al. 2011). This

initial examination indicated that citation patterns

are language independent and capable of identifying

suspiciously similar documents for disguised

plagiarism instances, which are undetectable by

today’s PDS.

However, it remained an open question to what

degree a citation-based PDS could provide

meaningful visual cues that allow a user to recognize

the detected suspicious similarities. To answer this

question, this paper uses the prominent cross-

language plagiarism case of K.T. zu Guttenberg to

demonstrate how an interactive, web-based

visualization of citation patterns can facilitate the

analysis of suspicious non-lexical similarities.

3 WEB-CLIENT

We visualize the longest instance of cross-language

plagiarism in Guttenberg’s thesis using CitePlag, a

prototype of a PDS that integrates citation pattern

analysis with traditional character-based detection

methods (Gipp et al. 2013). The rationale is to offer

an intuitive, highly interactive side-by-side

document comparison, which the user can enhance

with customizable highlights of citation-based and

character-based similarity information.

Figure 2 shows the system architecture of

CitePlag. The prototype’s backend consists of a

MySQL database and Java-based components for

data disambiguation, document parsing, similarity

detection and generating the output document format

visualized in the fronted.

The document parser extracts metadata, citations,

and references from the input documents and stores

the data in the database. The data disambiguation

component uses heuristics to consolidate all data

stored in the database, e.g. to match references and

to augment incomplete reference records with data

from matching records with additional information.

The detector implements the citation-based and

character-based detection algorithms. The detector

reads the necessary data from the database to run the

different algorithms and writes the identified citation

and text patterns back to the database. The

component for output conversion retrieves all

information visualized in the fronted from the

database and generates XML-based output

documents.

Figure 2: System architecture of the CitePlag prototype.

The frontend visualization, which is the focus of

this paper, is implemented in HTML 5. Figure 3

shows two screenshots of the CitePlag user interface

each displaying the Guttenberg thesis in German on

the left and the retrieved source document, an

English analysis of the U.S. constitution by the

Congressional Research Service, on the right. The

texts are individually scrollable. Footnotes in the

documents are embedded in the full-text display and

can be expanded or collapsed when clicking on a

footnote marker.

In the left screenshot in Figure 3, citation pattern

visualization is deactivated and only matching text is

highlighted in identical colors. In this mode, the

CitePlag user interface resembles the interfaces of

most PDS in use today. In Figure 3, the only lexical

match visible happens to be a legitimate quote.

Identifying quotes as potential plagiarism is a

common cause of false positives for plagiarism

detection systems (Stein et al. 2007).

In the right screenshot in Figure 3, the interactive

visualization of citation patterns is activated. In this

mode, identical citation patterns are highlighted in

addition to matching text in the full-text displays.

Hovering over citations in the text opens a pop-up

displaying metadata of the cited source.

Additionally, a scrollable central document browser

schematically displays the documents, while

highlighting and connecting the matching patterns.

Lexical similarity among sections is shaded in

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

678

Figure 3: Interactive web-based citation pattern visualization for cross-language plagiarism (source: http://citeplag.org).

different intensities of red depending on severity.

Clicking on citations or text highlights in either the

full-text or the central browser aligns the matches,

thus enabling a quick inspection of similarities.

The user can select among citation pattern

visualization algorithms above the document

browser.

4 DEMONSTRATION OF

ALGORITHMS

This section presents the visualization algorithms

implemented in the CitePlag prototype and

demonstrates their benefits using examples from the

excerpt of the Guttenberg cross-language plagiarism

case. We published a detailed description of the

algorithms in (Gipp and Meuschke 2011).

The reader is invited to visit the prototype at

http://citeplag.org/ to interactively explore the

Guttenberg plagiarism case and other plagiarism

cases. CitePlag’s source code is freely available

under a MIT License.

4.1 Bibliographic Coupling

Bibliographic Coupling (BC) is a traditional and

widespread citation-based similarity measure that

denotes the number of identical bibliographic

references in two academic documents (Fano 1956).

A Bibliographic Coupling relationship is denoted in

terms of a single value, the so called Bibliographic

Coupling strength. Bibliographic Coupling strength

is a raw measure of global document similarity,

since it considers only the reference lists found in

academic texts, but does not take into account the

position or order of the citations within the full texts

of the documents.

To visualize Bibliographic Coupling relations in

CitePlag, we extended the original approach, which

solely considers matching entries in the reference

lists, to take into account matching citations in the

full-texts instead. CitePlag highlights all citations of

a source that both documents reference in the same

color and connects each matching citation in the first

document with every matching citation in the second

document in the central document browser.

The leftmost image in Figure 4 visualizes the

citation patterns formed by the Bibliographic

Coupling approach for the longest instance of

cross-language plagiarism in the Guttenberg thesis.

In this particular case, the BC visualization results in

a network of lines that are very dense and can thus

become hard to trace.

The algorithm immediately shows the high

topical similarity even if the lexical similarity

between both documents is low, e.g. due to

cross-language plagiarism as in this case, or in the

case of paraphrases. Although Bibliographic

Coupling is a very basic visualization method, the

many parallel lines show that structural similarity is

given throughout the entire excerpt, which is

untypical for original work.

However, structurally similar documents with a

high number of matching citations must not

necessarily be plagiarisms. Dense BC overlaps can

also be the case for highly related publications, such

as literature reviews on the same topic. In the case of

a chronological literature review, structural

similarity may be acceptable. Therefore, in all cases

a careful human examination is necessary.

Web-basedDemonstrationofSemanticSimilarityDetectionUsingCitationPatternVisualizationforaCrossLanguage

PlagiarismCase

679

Bibliographic Coupling Citation Chunking Greedy Citation Tiling Longest Common Citation Seq.

Figure 4: Overview of citation pattern visualization algorithms using the plagiarism detection prototype CitePlag.

4.2 Citation Chunking

Citation Chunking (CC) describes a set of heuristic

algorithms that aim to identify matching citation

patterns regardless of whether the order of matching

citations differs in both documents.

We derived strategies to form citation chunks by

observing behaviors of plagiarists and modelling the

resulting citation patterns. Chunking means that

matching citations are grouped and considered as a

single unit (a chunk). The chunking strategy

implemented in the CitePlag prototype chunks both

documents. A matching citation is included in a

chunk if the number of non-matching citations that

separate the matching citation from the preceding

matching citation is not larger than the number of

matching citations already included in the chunk that

is currently under construction (Gipp 2013).

Once chunks have been formed for both

documents, the order of citations within a chunk is

disregarded and each chunk of the first document is

compared with each chunk of the second document.

The chunk pairs with the highest number of

matching citations are permanently related to each

other and considered a match. If multiple chunks in

the documents share the same number of matching

citations, all combinations of chunks with equally

many matching citations are stored.

Figure 5 demonstrates the conceptual formation

and comparison of chunks for two documents A and

B. Numbers in Figure 5 represent matching citations,

i.e. citations that occur in both documents. The letter

x denotes non matching citations in the two

documents.

Figure 5: Citation Chunking schematic concept.

The chunking algorithm starts by identifying all

citations that occur in both documents regardless of

their positions and number of occurrences in the

documents. With regard to Figure 5, one could say

that the algorithm distinguishes the numbered

citations from the remaining citations marked as x.

Next, the algorithm chunks the citation sequence

of document A and subsequently the citation

sequence of document B according to the rules

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

680

explained. Note that only the order of matching and

non-matching citations in the document that is

chunked determines which chunks are formed for

that document. The citation sequence of the other

document has no influence on the chunk formation.

For document A in Figure 5, the algorithm starts

forming the first chunk shown in red by including

the matching citations #1, #2 and #3, because no

non-matching citations separate those matching

citations. The first chunk contains three matching

citations at this point. Therefore, the algorithm will

include the next matching citation in the sequence if

three or less non-matching citations separate it from

the last matching citation in the chunk (#3). Citation

#4 fulfills this condition, thus is included in the first

chunk, as is citation #5, which directly succeeds #4.

At this point, the first chunk contains five matching

citations. The next matching citation in the sequence

(#6) is separated from the last matching citation in

the first chunk (#5) by six non-matching citations. In

other words, the number of non-matching citations

in between the matching citations #5 and #6 is larger

than the number of matching citations in the first

chunk. Therefore, the algorithm finalizes the first

chunk and includes citation #6 and #7 in a second

chunk shown in green thereby completing the

processing of document A. By processing the

citation sequence of document B in the same

manner, the algorithm forms two chunks for

document B, although the order of matching

citations in document A and B differs.

In the following comparison step, the Citation

Chunking algorithm compares all chunks formed for

both documents with each other. The chunks with

the highest overlap in matching citations are stored

as a citation pattern match. For the example shown

in Figure 5, the algorithm stores a pattern match of

length four between the red chunks and a pattern

match of length two for the green chunks.

Citation Chunking aims to uncover potential

cases in which text segments or logical structures

have been copied or were influenced by another text.

The chunking strategy implemented in the CitePlag

prototype allows for sporadic non-shared citations

that may have been inserted to make the resulting

text appear more “genuine”. By allowing an

increasing number of non-shared citations within a

chunk, given that a certain number of shared

citations have already been included, the Citation

Chunking algorithm can also detect potential

plagiarism cases where text segments and citations

from different sources were copied and interwoven

(shake&paste plagiarism).

The second image from the left in Figure 4

shows the citation patterns identified in the instance

of cross-language plagiarism from the Guttenberg

thesis using the Citation Chunking algorithm. The

substantial overlap in citations, which was already

apparent by visualizing Bibliographic Coupling

relations, is also reflected by the numerous and

densely linked citation chunks. Visualizing the

patterns returned by the Citation Chunking

algorithm reveals a number of clusters pointing to

similar text segments. Within individual clusters,

lines connecting matching citations are mostly

parallel with only few overlaps. The pattern suggests

that the selection and placement of citations in

numerous well defined segments of the Guttenberg

thesis is highly similar to the source document.

4.3 Greedy Citation Tiling

The Greedy Citation Tiling (GCT) algorithm

identifies all individually longest citation patterns

that consist entirely of matching citations in the

exact same order. Individually longest patterns refer

to sequences of matching citations in the same order

that cannot be extended to the left or right without

encountering a citation that is not shared by both

documents being compared. Such individual longest

matches are called citation tiles.

Figure 6 illustrates the formation of Greedy

Citation Tiles. Using the notation introduced in

Figure 5, Arabic numerals represent matching

citations, the letter x denotes non-matching citations.

Colored highlights with roman numerals represent

citation tiles. Citation tiles are stored as a numeric

triplet shown at the bottom of Figure 6. The first

element of the triplet indicates the starting position

of the citation tile in document A, the second

element denotes the starting position in document B

and the third element corresponds to the length of

the tile.

Figure 6: Greedy Citation Tiling schematic concept.

Finding many or long matching citation tiles is

rarely a coincidence, and can thus be a strong

indicator of plagiarism. In Figure 4, the third image

from the left shows the visualization of citation tiles

for the longest instance of cross language plagiarism

in the Guttenberg thesis. Numerous citation tiles up

to a length of five citations were identified in this

Web-basedDemonstrationofSemanticSimilarityDetectionUsingCitationPatternVisualizationforaCrossLanguage

PlagiarismCase

681

excerpt of the thesis. In many sections, even longer

sequences of matching citations were only

interrupted by a few non-matching citations,

resulting in the identification of several shorter

citation tiles.

The large number and length of citation tiles in

this example is clearly suspicious. Despite the lack

of lexical overlap, the long citation tiles found

should quickly point an examiner to the text

segments that require closer inspection. By

examining these text segments, an investigator will

quickly identify the instances where content was

translated from the source document. Within the

translated segments, the citations placed at the end

of many sentences were simply copied along with

the translated version of that sentence. Citations

distributed within a sentence were partially

transposed due to different sentence structure in the

translation.

4.4 Longest Common Citation

Sequence

The Longest Common Citation Sequence (LCCS)

algorithm visualizes the longest string of citations

that match in both documents in identical order.

Transpositions of matching citations, i.e., citations

that have been rearranged, are not detected, and any

interruptions by non-matching citations are skipped

and the string continued upon the next match. Thus,

a document pair has either exactly one or no LCCS.

Figure 7 illustrates a LCCS pattern using the

notation established in Figure 5 and Figure 6.

Figure 7: Longest Common Citation Sequence schematic

concept.

The LCCS measure is very indicative of

originality, because long strings of identical

citations, even with interruptions, reflect that both

authors presented the content in a similar order.

Such parallel structure is often not a coincidence.

In Figure 4, the rightmost image shows the

LCCS pattern of the examined cross-language

plagiarism excerpt of the Guttenberg thesis. The

LCCS pattern reflects the extent of global structural

similarity between the original and the plagiarism.

The strong parallel structure of matching citations

with few interruptions suggests a significant

similarity between numerous sections of both

documents, thereby amplifying the suspicion raised

by the Citation Chunking and GCT patterns. Since

almost no literal text overlaps exist between the two

documents, the examiner can deduce that the

analyzed excerpt is in large parts a directly

translated plagiarism.

Although the LCCS algorithm correctly points to

the suspicious global document similarity in the

Guttenberg case, the algorithm can return misleading

results if literature is cited in chronological or

alphabetical order. While such similarities are

reflective of topical similarity, they are likely

genuine.

4.5 Longest Common Sequences of

Distinct Citations

The Longest Common Sequence of Distinct

Citations (LCCS Dist.) is a more restrictive variant

of the LCCS algorithm presented in the previous

section. LCCS Dist. includes only the first

occurrence of a matching citation and ignores

repeated citations to the same source regardless of

whether they occur in the same order in both

documents. As such, the measure is simply more

restrictive than the LCCS measure. Therefore, the

outcome for LCCS Dist. is not pictured.

5 CONCLUSION AND FUTURE

WORK

As demonstrated using an instance of cross-language

plagiarism in the thesis of K. T. zu Guttenberg,

citation-pattern visualization is especially beneficial

for examining potential plagiarism that features little

or no lexical overlap. By visualizing citation patterns

in addition to lexical text matches, CitePlag enables

a faster inspection, especially for the harder to detect

heavily disguised plagiarism forms.

Future systems may benefit from interactive

side-by-side visualizations of both lexical and

non-lexical similarities, as demonstrated by the

CitePlag prototype. This paper examined only the

visual representation of citation patterns for a certain

plagiarism case. A formal evaluation of the citation-

based approach is currently awaiting publication in

(Gipp et al. 2014) and is scheduled to appear in the

course of the next months.

Lastly, it remains worthy to mention that no

plagiarism detection system alone can fully

automate the identification of plagiarism. The

verification of the detected similarities and the final

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

682

decision on plagiarism remains with the user. The

necessity of humans in the plagiarism detection

process demands that the visualizations employed by

plagiarism detection systems are interactive,

customizable, and intuitive to users if the system is

to provide optimal utility.

ACKNOWLEDGEMENTS

We wish to acknowledge the contributions of André

Gernandt, Leif Timm, Markus Bruns, Markus

Föllmer, and Rebecca Böttche for their contributions

to the development of the prototype.

REFERENCES

FANO, R. M. 1956. Documentation in Action. Reinhold

Publ. Co., New York, Chapter Information Theory and

the Retrieval of Recorded Information, 238–244.

IPP, B. 2013. Citation-based Plagiarism Detection:

Applying Citation Pattern Analysis to Identify

Currently Non-Machine-Detectable Disguised

Plagiarism in Scientific Publications. Ph.D. thesis,

Department of Computer Science, Otto-von-Guericke

University Magdeburg, Germany.

GIPP, B. AND MEUSCHKE, N. 2011. Citation Pattern

Matching Algorithms for Citation-based Plagiarism

Detection: Greedy Citation Tiling, Citation Chunking

and Longest Common Citation Sequence. In

Proceedings of the 11th ACM Symposium on

Document Engineering. ACM, Mountain View, CA,

USA, 249–258.

IPP, B., MEUSCHKE, N., AND BEEL, J. 2011. Comparative

Evaluation of Text- and Citation-based Plagiarism

Detection Approaches using GuttenPlag. In

Proceedings of 11th ACM/IEEE-CS Joint Conference

on Digital Libraries (JCDL’11). ACM, Ottawa,

Canada, 255–258.

IPP, B., MEUSCHKE, N., AND BREITINGER, C. 2014.

Citation-based Plagiarism Detection: Practicability on

a Large-scale Scientific Corpus. Journal of the

American Society for Information Science and

Technology (to appear).

IPP, B., MEUSCHKE, N., BREITINGER, C., LIPINSKI, M.,

AND NÜRNBERGER, A. 2013. Demonstration of the

First Citation-based Plagiarism Detection Prototype.

In Proceedings of the 36th International ACM SIGIR

conference on research and development in

Information Retrieval. ACM, Dublin, Ireland, 1119–

1120.

GUTTENPLAG WIKI. 2011. Eine kritische

Auseinandersetzung mit der Dissertation von Karl-

Theodor Freiherr zu Guttenberg: Verfassung und

Verfassungsvertrag. Konstitutionelle

Entwicklungsstufen in den USA und der EU. Online

Source. Retrieved Apr. 25, 2012 from:

http://de.guttenplag.wikia.com/wiki/GuttenPlag_Wiki.

TEIN, B., LIPKA, N., AND PRETTENHOFER, P. 2011.

Intrinsic Plagiarism Analysis. Language Resources

and Evaluation 45, 1, 63–82.

TEIN, B., MEYER ZU EISSEN, S., AND POTTHAST, M. 2007.

Strategies for Retrieving Plagiarized Documents. In

Proceedings of the 30th Annual International ACM

SIGIR Conference. ACM, 825–826.

WEBER-WULFF, D. 2012. Portal Plagiat - Softwaretest

Report 2012. Online Source. Retrieved Nov. 27, 2012

from: http://plagiat.htw-berlin.de/collusion-test-2012/.

Web-basedDemonstrationofSemanticSimilarityDetectionUsingCitationPatternVisualizationforaCrossLanguage

PlagiarismCase

683
