Data-Centric Workflow Approach to Lifecycle Data Management

Marko Junkkari

and Antti Sirkka

School of Information Sciences, University of Tampere, Kanslerinrinne 1, Tampere, Finland

Tieto Finland, Hatanpäänvaltatie 30, Tampere, Finland

Keywords: Data-Centric Workflow, Complex Objects, Physical Assembly, Data Model, Lifecycle Data Management,

Traceability Graph.

Abstract: Data-centric workflows focus on how the data is transferred between processes and how it is logically

stored. In addition to traditional workflow analysis, these can be applied to monitoring, tracing, and

analyzing data in processes and their mutual relationships. In many applications, e.g. manufacturing, the

tracing of products thorough entire lifecycle is becoming more and more important. In the present paper we

define the traceability graph that involves a framework for data that adapts to different levels of precision of

tracing. Advanced analyzing requires modeling of data in processes and methods for accumulating

resources and emissions thorough the lifecycle of products. This, in turns, requires explicit modeling and

presentation how objects are divided and/or composed and how information is cumulated via these tasks.

The traceability graph focuses on these issues. The traceability graph is formally defined by set theory that

is an established and exact specification method.

1 INTRODUCTION

The data-centric approach for designing workflows

is based on defining how the data is transferred

between processes and how it is logically stored

(Akram, Kewley and Allan, 2006; Caswell and

Nigam, 2003). The approach examines how

processes transform data and which entities send and

receive the data. The main goal of data-centric

workflows is to present the data sets in the

workflows. In other words, data-centric workflows

must involve an integrated data model for storing

and manipulating data.

Complex objects consist of objects that in turn

may consist of smaller objects (Motschnig-Pitrik and

Kaasböll, 1999). This makes their manipulation

demanding because both immediate and indirect

components must be taken into account in analyzing

information associated with complex objects.

Physical assemblies are complex objects with the

exclusivity constrain i.e. no component is shared

(Junkkari, 2005). Workflows are usually focused on

management of manufacturing of physical

assemblies and they describe how physical

assemblies are constructed. In manufacturing of

physical assemblies, objects may be composed of

components or an object may be divided into smaller

objects. In manufacturing, information related to

physical assemblies is cumulated via different types

of processes. Division and composition require

specific rules for information accumulation.

In the present study, we develop a data-centric

workflow approach, called the traceability graph,

focused on management of information allocation

and accumulation in object transformation (division

or composition). It supports dynamic data

management techniques for data refinement such as

aggregation, attribute value propagation, and derived

attributes. Integration of object transformation with

other dynamic data management issues gives an

advanced approach to analyze data associated with

processes, products the processes yield, and their

components.

In our approach a (database) object may

correspond to a real life entity, a set of real life

entities or mass of material that can be physically

identified thorough the part of a process chain in

which it is participating. This means that physical

entities of a patch are manipulated by a single object

in a database if physical entities cannot be

individually identified.

In data-centric workflows, the manipulation of

complex objects requires specific features because

objects may be changed into other objects in both

the logical (in databases) and physical (real world)

116

Junkkari M. and Sirkka A..

Data-Centric Workﬂow Approach to Lifecycle Data Management.

DOI: 10.5220/0005001001160124

In Proceedings of 3rd International Conference on Data Management Technologies and Applications (DATA-2014), pages 116-124

ISBN: 978-989-758-035-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

levels. This means that object transformation and

related data derivation rules must be modeled. In

addition, objects are manipulated in patches that can

be divided into subsets. In turn, patches may be

collected into larger patches. The above issues

means that there must be rules for determining how

resources, emissions and other information of

processes are allocated to products in object

transformation and how these are accumulated in a

workflow.

We use the term supply chain, borrowed from

manufacturing, to determine all the processes that

are participating directly or indirectly in the

production of a product. The supply chain is a

directed subgraph of a workflow diagram, i.e. the

result of a process is a raw material for another

process. Processes possess properties, such as

resources and emissions, associated with the result

products of processes. From data-oriented

perspective, these properties are accumulated in a

supply chain, i.e. the information on the preceding

processes of a process is also associated with the

process and its products. For example, for

calculating the used energy of a product, all history

(preceding processes) must be taken into account.

For modeling this accumulation of products, a

process contains two values: ordinal and cumulated

where the ordinal value is focused on an underlying

process whereas the cumulated value is aggregated

from previous processes. The information from a

process to another is transferred by derived

attributes.

Unlike existing methods our model enables

analyzing resources and emissions on the single

product level – not only average values. Nowadays a

common method for calculating the environmental

impact is to measure the input and output flows of

the whole supply chain during some time period and

calculate the average environmental impact for the

product (Puettmann and Wilson, 2005).

We aim to find the principal primitives needed to

model and manipulate data-centric aspects in

workflows in a way that enables tracing of products

at different granularity levels. We do not bind our

model to any existing data or workflow methods, i.e.

we give freedom to apply our model into existing

formalisms and systems.

The rest of the paper is organized as follows.

In Section 2 we present a short survey on workflow

models and traceability. The used mathematical

notational conventions are given in Section 3 and the

traceability graph is defined in Section 4. The

analytic capabilities of the traceability graph are

demonstrated in Section 5. In Section 6, we discuss

implementation issues of the present model, and

finally, the conclusions are given in Section 7.

2 RELATED WORKS

In workflows, materials, documents and other

information are transferred from a process to another

(van der Aalst and van Hee, 2002; Bonner, 1999).

Different types of activities are typically

distinguished in workflow diagrams, like sending,

transforming and packing of materials. Some

modern modeling methods of information systems,

e.g. UML (Booch, Rumbaugh and Jacobson, 1999),

contain diagrams for dynamic aspects of programs

(interaction diagrams) and modeling of workflows

(activity diagram). The purpose of workflow model

of UML is to map real world activities to the

underlying software solution.

There are several formal methods for modeling

functionality of information systems that are not

primarily intended to any specific purpose. For

example Petri nets are traditionally used for defining

or describing functionality of computer programs,

but they are also proposed for exact representation

of workflow models (van der Aalst, 1998; van der

Aalst and van Hee, 2002). YAWL (van der Aalst

and Ter Hofsted, 2005), Temporal logic (Attie et al.,

1993), and Transaction Logic (Bonner, 1999) are

other good representatives for formalizing

workflows. These methods emphasize timing within

processes and supply chains. From our perspective,

timing is a secondary feature. Instead we emphasize

handling the data aggregation and movement

between processes.

Workflow models have also been investigated

from the perspective of how they support different

data-centric aspects (Curcin and Ghanem, 2008).

The main aspects include concentrating on process

functionality based on the data, i.e. each node has

behavior instructions with regard to the data.

Deutsch and others (2009) present an advanced data-

centric business processes model and its verification.

They define several essential primitives such the

artifacts schema, artifact instance, and service

logically integrated with each other. The main

difference between our study and their approach is

that we address the explicit object sifting,

transformation and derivation of the information

through processes.

The present study focuses on tracing based on

object transformation in a supply chain. In general,

the importance of traceability has been noticed in

software development (Gotel and Fincesteins, 1994,

Data-CentricWorkflowApproachtoLifecycleDataManagement

117

Sommerwille, 2007; Podeswa, 2009; Bouillon et al.,

2013; Breaux and Gordon, 2013; Rempel et al.,

2013) as well as in manufacturing (Cheng and

Simmons, 1994; Jansen-Vullers et al., 2003; 2004;

Campos and Hardwick, 2006; Folinas et al., 2006).

In software engineering it is essential to find the

origin of a requirement when a system is changed

(Gotel and Fincesteins, 1994; Sommerwille, 2007).

In this context, traceability is seen as a property of a

requirements specification that reflects the case of

finding related requirements (Sommerwille, 2007).

Requirements traceability refers to the ability to

describe and follow the life of a requirement (Gotel

and Fincesteins, 1994). In the context of UML

based system specification, tracing between the

behavioral and structural models has also noticed

essential (Podeswa, 2009). This relates to our

approach where aimed to integrated manipulation of

data structures and workflows / data-flows.

In the context of requirements traceability and

manufacturing, traceability is based on analyzing

workflows or data-flows (with possible class and

object diagrams) and there are different methods to

represent traceability data. We, in turn, develop

workflows for supporting information tracing

through object transformations.

3 NOTATIONAL CONVENTIONS

Standard set theory is used for representing the

traceability graph. Next we introduce only those

notational conventions which have widely used

alternative representations.

 Tuple is an ordered sequence of elements

represented between angle brackets.

 If t is a tuple and x its uniquely labeled member

then t.x refers to x in t. For example if t =

a,b,cthen t.b refers to the second member of

 If it is not necessary to refer to a member of a

tuple the underline space can be used. For

example in 3-tuple





the first and last

members are not referred.

 The power set of the set S is denoted by P(S)

 Cartesian product between sets A and B is

denoted by A  B.

 Mapping f from a set X to another set Y is a 2-

place relation ( X  Y) denoted by f:X  Y.

X or Y may be a set consisting of sets, e.g. a

power set.

 If R is a 2-place relation R  X  Y then the

domain of R ({x  X |

x,y  R}) is denoted

by dom(R), whereas the range ({y  Y |

x,y



  R}) is denoted by rng(R).

A (directed) graph is a pair (N,E) where N is a set

of nodes (vertexes) and E is a set of edges.

Nodes and edges are represented by set theory

as follows:

 A node is represented as a tuple

Node id, P1, , Pn







 , where Node-id is the

identity of the node and P1, …, Pn are the

properties associated with the node. For brevity,

Node-id can be used to refer to the node. Thus,

the notation Node-id.Pi refers to the property Pi

in the node having the underlying identity.

 A directed edge is represented as a tuple

Node idS, Node idE, P1, , Pn









, where

Node-idS and Node-idE are the identities of the

start and end nodes, respectively. P1 ,…,Pn are

the properties associated with the edge.

4 TRACEABILITY GRAPH

In the traceability graph each node describes a

process where resources are needed or new costs

(e.g. environmental impacts) emerge. A node

involves a set of attributes and a set of product

portions. These are the properties of the node. An

edge describes division, composition or transferring

of products portions. Each edge possesses a set of

product portions which are shifted to the following

process. In an edge neither new resources are needed

nor new costs are emerged, i.e. ordinary attributes

are not associated with an edge. Instead, an edge

may involve derived attributes that describe portions

of previous product portions and attributes. In other

words, sifted product portions and derived attributes

are properties of an edge. Next we define our model

in detail.

4.1 Node and Related Properties

Products which are identified physically and

logically in the application domain are called

objects. For logical identifying each object of

interest possesses an identity. The set of possible

identities of an application domain is denoted by ID.

In processes, different products are manufactured

or manipulated. Products can be divided in different

portions (patches) based on their types or

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

118

manipulation needs. The product portion is defined

as follows:

Definition 1: Product portion is a tuple P-

Name, C, ID-set, R where P-Name is the name of

product, C is the amount of the portion, ID-set is the

set of object identities in the portion, and R is the

ratio of the portion related the underlying total

amount of the products.

In Definition 1 the ratio R is calculated by some

application specific method based on e.g. the weight

of the product portion related to the total weight of

products in the underlying process, or used time

related to total time needed in the process. For a

product portion associated with other than objects,

ID-set is empty and the portion is manipulated as a

mass without interest on individual products.

An attribute describes some information bound

to a process. The attributes are divided into the three

categories based on their nature as follows:

1. Input attribute describes costs, used materials

and other resources needed in a process. For

example the used fuel is an input attribute. In

the present approach the input attribute has a

numeric value.

2. Output attribute describes other matters than

products that a process produces. For example,

a process may produce some tons of CO-gas.

The output attribute has a numeric value.

3. Info attribute contains other data or documents

associated with a process. The value of an info

attribute is a set of strings or documents.

An attribute involves two values: one for the

underlying process (ordinal value) and another for

the previous production chain (cumulated value).

The cumulated value is derived from previous

processes based on the specific rules given later in

Definition 6. So far we can assume that ordinal and

cumulated values are the same. The attribute with its

properties is defined as follows:

Definition 2: Attribute is a tuple -Name, T, V,

W where A-Name is the name of attribute, T is the

type of the attribute ( {input, output, info}), V is

the ordinal value of the attribute, and W the

cumulated value of the attribute.

Now, we are able to define a process node

involving product portions and attributes.

Definition 3. Process node (simply node) is a

tuple Nid, N-type, P-set, A-set where Nid is the

identity of the node, N-type is the type of the

process, P-set is the set of product portions and A-

set is the set of attributes associated with the node.

The nodes are connected to each other via edges.

Next we define the primitives associated with edges.

4.2 Edge and Related Properties

In a supply chain, information on previous processes

(nodes) is propagated to forthcoming processes. This

information consists of object identities and the

values of attributes. An identity shift determines

those objects that are transferred from a process to

another or a mapping among objects. There are tree

types of the identity shift. 1. Equivalence means that

objects of the start and end nodes are the same. 2.

Composition means that several objects are

composed to single objects. 3. Division means that

single objects are auto-identification into several

objects. Formally the identity shift is defined as

follows:

Definition 4: Identity shift is a mapping M

among identities or the sets consisting of them. The

mapping M may be:

1. equivalence, where M:ID  ID and dom(M) =

rng(M)

2. division, where M:ID  P(ID) and Y 

rng(M) x  dom(M): |Y| > 1

3. composition, where M:P(ID)  ID and y 

rng(M) X  dom(M): |X| > 1.

Case 1 maintains the object identities, whereas in

cases 2 and 3 object identities are typically changed.

In case 2, a single object is mapped to a set of object

identities, whereas in 3 a set of object identities is

mapped to a single object identity. Further, only

some objects may be selected for refining or objects

for refining may be collected from several previous

processes.

For propagating information represented as

attributes among nodes, the notation of the derived

attribute is used. Attribute value propagation rules

are based on the types of attributes, i.e. propagation

for input and output attributes requires calculation

whereas info attributes are propagated by collecting

all the data and documents for forthcoming

processes. These rules are involved in the definition

of the edge below.

A (shift) edge describes the connection between

two nodes. An edge involves a set of derived

attributes and a set of sifted product portions. A

sifted product portion describes products that are

shifted from a process to another. In order to

maintain a product portion and the related objects,

an identity shift is associated with shifted product

portions. The edge is formally defined as follows:

Definition 5. Shift edge (simply edge) is a tuple

N

, N

, SP, D, where N

and N

are identities of

the start and end nodes, SP is a sifted product

portion, and D is a set of derived attributes.

Data-CentricWorkflowApproachtoLifecycleDataManagement

119

 SP is a tuple P-Name, C, M, Rp, such that

there exists P-Name,C’,ID-set

,_  N

.P-set

and _,_, ID-set

,_ N

.P-set. The mapping M

is an identity shift where objects in dom(M)

belong to ID-set

and objects in rng(M) belong

to ID-set

. C is the amount of the sifted product

portion and Rp = C/C’ is the ratio of the sifted

product portion.

 A derived attribute ( D) is a tupleA-Name,

A.T, DV where A  N

.A-set, i.e. A-Name

is the name of an attribute in N

and A.T its

type. DV is the value of the derived attribute. It

A.W,if A.T = info

A.W  P.R  SP.Rp where P  N

.P-set: P.P-

Name = SP.P-Name, if A.T  {input,

output}

In Definition 5, the sifted product portion is P-

Name, C, M, Rp where Rp is the ratio of the

portion. This is calculated such that the sifted

amount C is divided by the original amount C’ of the

start node. This ratio is used for calculating the value

of derived attributes. A derived attribute is a 3-tuple

where the first and second members possess the

name and the type of the attribute inferred from the

start node. The value of a derived attribute is

cumulated as such from the start node if the type of

the attribute is info. Otherwise, the original value is

multiplied by the ratio of the original product

portion (P.R), and by the ratio of the sifted product

portion (SP.Rp).

In a traceability graph there are two kinds of

nodes based on their roles in the graph. Initial nodes

have no predecessors, i.e. there is no edge to them.

Other nodes possess at least one predecessor. This

distinction is essential because attribute values are

cumulated in other nodes than initial ones. In initial

nodes an attribute has the same cumulated value as

the ordinal value. For attributes in the other nodes,

the cumulated value is derived from previous nodes

via edges. If the underlying attribute is an info

attribute, then the cumulated value is the set

consisting of the ordinal value and values of derived

attributes in incoming edges. Otherwise it is the sum

of the value of the ordinal attribute and the

corresponding values of derived attributes in

incoming edges. Formally, the cumulated value is

defined as follows:

Definition 6: Let A be an attribute in node N, V

its ordinal value and S = {E|E.N

= N} the set of

immediate incoming edges E to N, then the

cumulated value W of A is

The traceability graph involves the

abovementioned primitives and it is defined as

follows:

Definition 7: Let N-Set be a set of process nodes

and E-Set a set of shift edges, then N-Set, E-Set is

a traceability graph.

4.3 Sample System

In order to illustrate the traceability graph let us

consider an example from a forest industry. In

Figure 1, a simplified production of glued laminated

timber is illustrated. The processes included in the

example are felling the trees (harvesting), sawing

logs to boards, drying the boards and jointing the

glued laminated timbers (glulam beams) from

boards.

The first phase of production has two nodes

describing the amount of daily harvesting.

Harvesting has attributes Diesel (input), CO2

(output), Location (info) and Company (info).

Harvesting nodes has tree product portions: Logs,

Pulp wood and Harvesting waste. Only logs are

transferred to the sawing node. A double headed

arrow illustrates that in the sawing nodes, the objects

(logs) from harvesting nodes are divided into several

objects (boards). Information associated with logs is

first allocated to shifted product portions and then

the products of sawing. Then information is

reallocated to forthcoming product portions in the

supply chain.

Figure 1: Sample Traceability Graph.

Between Sawing and Drying nodes the objects

are not changed. This is illustrated with a plain

arrow. Objects from the preceding node can be

moved as such, or only part of the objects can be

moved, or all the objects can be moved from the

























S D_,_,_,

output} {input, A.T if D, DV_,A, :DV V

info A.T if D, DV_,A, :DV V



Harvesting

#N1

Harvesting

#N2

Sawing

#N3

Drying

#N4

Drying

#N5

Gluing

#N6

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

120

preceding node together with some objects from

other nodes.

In the gluing nodes the objects from the drying

nodes are composed as an object of the gluing node.

In other words objects from the drying nodes are

components of objects in the gluing nodes. An arrow

with a divided start illustrates this.

In other words, the emissions, resources and

other properties of the end products are accumulated

through their supply chain. For example, calculating

the CO2 footprint of a glulam beam all processes are

taken into account and allocated among sub-

products.

4.4 Schema

Definitions 1-7 determine explicitly the instance

level of the traceability graph but they also

implicitly involve schema level descriptions. The

schema is a framework that determines the structure

of instances with possible constraints in terms of

which restrictions for nodes and edges can be stated.

At the schema level, a node type determines a set

of similar nodes whereas an edge type determines a

set of similar edges between similar nodes. A node

type contains slots for a node id, node name, product

portions and attributes, and possible constrains for

them. Typical constraints are:

 Types of product portions

 Measures of product portions

 Types of attributes

 Measures of attributes

As an example, we define the harvesting node

type.

N-type = ‘Harvesting’

PP: Name: PineSawLog, Measure: cubic meter

PP: Name: PinePulpWood, Measure: cubic meter

PP: Name: HarvestingWaste, Measure: ton

Attribute: Name:Diesel, Type: input, Measure:liter

Attribute: Name:CO2, Type: output, Measure:

kilograms

Attribute: Name: Location, Type: info

Attribute: Name: CompanyCode, Type: info

An edge type contains slots for two node

identities such that the type of the node can be

specified. Further, there are slots for sifted product

portions, identity mapping and derived attributes.

The type (composition, division or equivalence) of

mapping can be specified as well as the names, types

and measures of the derived attributes.

For example, an edge type between harvesting

and sawing nodes can be specified as follows:

Node type of N

= ‘Harvesting’

Node type of N

= ‘Sawing’

EdgeType = Division

PP: Name: PineSawLog, Measure: cubic meter

D_attribute: Name: CO2, Type: output, Measure:

kilograms

D_attribute: Name: Diesel, Type: input, Measure: liter

Attribute: Name: CompanyCode, Type: info

The schema level description may also contain

other constraints or derivation rules. For example,

the value of the CO2 attribute (output) may be

derived from the values of the Diesel attribute

(input).

5 ANALYZING TRACEABILITY

GRAPH

For analyzing structural aspects of the traceability

graph functions different function can be defined.

For the sake of limited space we only two sample

function needed in the sample queries.

Successors of an object mean those objects for that

the object has been raw material or component. The

functions i_successors and successors yield the

immediate and all successors, respectively.

i_successors(id) = {id’  ID | E  E-Set  id 

rng(E.SP.M)  id’  dom(E.SP.M): id,id’ 

E.SP.M}

successors(id) =

For example, if id1 is the identity of a log then

successor(id1) all products that is sawed from the

log or has a component come down the log. An

object may belong to several nodes in process chain.

The function node(id) yields all the nodes that the

object with id has associated with:

node(id)={N.Nid|NN-set: tN.P-set  dt.ID-set}

Among these nodes the last one is of special

interest because it refers to the final state of the

object. The function last_node(id) returns it as

follows.

last_node(id) = N| Nnode(id)  id  successors(id)

Next we demonstrate querying possibilities of

the traceability graph.

















otherwise ,

S if (id),_ S where(i), S

S i



successorsisuccessors





















Data-CentricWorkflowApproachtoLifecycleDataManagement

121

Sample Query 1: Calculating the Item Level

Carbon Footprint

The carbon footprint of an object can be

calculated by using the cumulated value of the CO2

attribute of the final node that the object has

participated in. For example, let us assume that

object with id5000 is a glulam beam then the carbon

footprint associated with it can be achieved as

follows:

where t  N.P-set: id5000  t.ID-set  t'  N.A-

set: t.A-name = CO2 such that N = last_node(id)

In other words t.R refers to the ratio R of the

node t (a tuple) and t’.W refers to the cumulated

value W of the attribute t’ (a tuple).

The formula can easily be extended to concern

several objects when the dispensation would be

multi-valued set.

Sample Query 2: Benchmarking

Benchmarking the processes between companies

and manufacturing facilities enables to identify the

processes with biggest environmental impact so that

we improve the environmental performance of the

supply chain. We can calculate a key performance

indicator for the nodes using the bench() functions.

 nodes define the set of nodes used in

benchmarking

 prod_name defines the product portion used in

benchmarking

 prop_name defines the attribute used to

calculate the key performance indicator.

 group defines the attribute used to analyze the

traceability graph.

bench(nodes, prod_name, prop_name, group) =

{x,y | x  t

.V: t

 N.A-set  t

.A-name = group

 t

.T = info  where

S = {t

.V| t

 N.A-set  t

.A-name = prop-name}

T = {t

.V| t

 N.P-set  t

.P-name = prod-name}

where N  nodes}

According to Figure 1, #N1 and #N2 are

identities of harvesting nodes of different companies

The harvesting efficiency can be calculate as

follows:

bench({N1,N2},PineSawLog,Diesel,CompanyCode)

The result a set of pairs that represents how

much diesel companies have used per cubic meter of

saw logs.

6 DISCUSSION

The presented data-centric workflow model enables

tracing, monitoring, analyzing and querying the

properties of processes and their mutual

relationships. The formal specification allows

services to handle the products lifecycle data

formally. To be able to share the life cycle data in

real a world supply chain, we must:

1. ensure correspondence between logical objects

with real life products of processes

2. have an infrastructure that enables multiple

companies in a supply chain to share and use

the information regarding products.

In tracing products, in addition to logical

identities, they must be identified by physical

identifiers. For physical products, various marking

methods are in use: Imprinting, the finger print

method, Laser marking, Label marking, Ink jet

marking and transponder marking. In practice a

physical identifier corresponds to an object identity

in the database. This also gives natural interpretation

for an object in the traceability graph.

We have implemented a pilot project for using

RFID (Radio Frequency IDentification) marking in

forest industry for product level tracing (Junkkari

and Sirkka, 2011; Björk et al. 2011). The product

level marking needs marking of single products and

their components. This is, of course, expensive and

requires advanced infrastructure. Rougher marking

reduces the costs but makes tracing vaguer.

However, the price of RDIF techniques have

decreased constantly which will enable item level

tracing probably near in future.

We have implemented the traceability graph on

the top of a relational database and investigated

possibilities to OLAP (Online Analytic Processing)

analysis (Sirkka and Junkkari, 2012). According to

our experience the present formalisms give a good

background to analyze traceability data

multidimensionally. The product, process, time and

elementary flow are possible dimensions for

reporting recourses and emissions for benchmarking

and the decision support.

t'.W t.R

|set}-{t.ID|

|}id5000{|















T j

S i

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

122

7 CONCLUSIONS

We have presented a data-centric workflow model,

called the traceability graph. It integrates data-

centric aspects of products and processes to

traditional graph-based workflows. The approach

supports attribute value propagation and aggregation

in the supply chains. The input and output costs of

processes can be allocated into products, which

enables tracing and analyzing these costs precisely.

The model can be applied to single products as well

as larger patches. Unlike existing methods the

traceability graph enables precisely calculated input

costs (e.g. recourses) and output costs (e.g.

emissions and waste) of products and processes. So

far these have been based on average values from a

large set of processes. Through the presented object

transformation it is possible to model and

manipulate data allocation and aggregation in the

composition and division of objects in processes.

REFERENCES

van der Aalst, W.M.P., 1998. The application of Petri nets

to workflow management. The Journal of Circuits,

Systems and Computers, 8, 1, 21-66.

van der Aalst, W.M.P., Ter Hofstede, A.H.M., 2005.

YAWL: Yet another workflow language. Information

Systems, 30, 4, 245-275.

van der Aalst, W.M.P., van Hee, K., 2002. Workflow

Management, Models, Methods, and Systems, The

MIT Press, Cambridge, MA.

Akram, A., Kewley, J., Allan, R., 2006. A Data Centric

approach for Workflows. In Proceedings of EDOC

Workshops, 10.

Attie, P., Singh, M., Sheth, A., Rusinkiewicz, M., 1993.

Specifying and enforcing intertask dependencies. In

Proceedings of 19th International Conference on Very

Large Data Bases (VLDB’93) Morgan Kaufmann

Publishers, 134-145.

Björk, A., Erlandsson, M., Häkli, J., Jaakkola, K., Nilsson,

Å., Nummila, K., Puntanen, V., Sirkka, A. 2011.

Monitoring environmental performance of the forestry

supply chain using RFID, Computers in Industry, 62,

8-9, 830–841.

Bonner, A.J., 1999. Workflow, transactions and datalog.

In Proceedings of the Eighteenth ACM Symposium on

Principles of Database System (PODS’99), ACM

Press, 294-305.

Booch, G., Rumbaugh, J and Jacobson I., 1999. The

Unified Modeling Language User Guide, Addison-

Wesley, Reading, MA.

Podeswa, H., 2009. UML for the IT Business Analyst: A

Practical Guide to Requirements Gathering Using the

Unified Modeling Language, Course Technology,

Boston, MA, USA.

Bouillon, E., Mäder, P., Philippow. I., 2013. A survey on

usage scenarios for requirements traceability in

practice. In Proceeding of 20th International Working

Conference on Requirements Engineering:

Foundation for Software Quality, LNCS 7830, 158-

173.

Breaux, T.D., Gordon, D.G., 2013. Regulatory

requirements traceability and analysis using semi-

formal specifications. In Proceeding of 20th

International Working Conference on Requirements

Engineering: Foundation for Software Quality, LNCS

7830, 141-157

Campos, J.G., Hardwick, M., 2006. A traceability

information model for CNC manufacturing.

Computer-Aided Design, 38, 540-551.

Caswell, N.S., Nigam, A., 2003. Business artifacts: An

approach to operational specification. IBM Systems

Journal, 42, 3, , 428–445.

Cheng, M.J., Simmons, J.E.L., 1994. Traceability in

manufacturing systems. International Journal of

Operations & Production Management, 14, 10, 4-16.

Curcin, V., Ghanem, M., 2008. Scientific workflow

systems - can one size fit all? In Proceedings

Biomedical Engineering Conference (CIBEC 2008), 1-

Deutch, A., Hull, R., Patrizi, F., Vianu, V., 2009.

Automatic verification of data-centric business

processes. In Proceedings of the 12th International

Conference on Database Theory, 252-267.

Folinas, D., Manikas, I., Manos, B., 2006. Traceability

data management for food chains. British Food

Journal, 108, 8, 622-633.

Gotel, O.C.Z., Finkelstein, A.C.W., 1994. An analysis of

the requirements traceability problem. In: IEEE

Proceedings of the First International Conference on

Requirements Engineering, 94–101.

Jansen-Vullers, M.H., van Dorp, C.A., Beulens, A.J.M.,

2003. Managing traceability information in

manufacture. International Journal of Information

Management, 23, 395-413.

Jansen-Vullers, M.H., Wortmann, J.C., Beulens, A.J.M.,

2004. Application of labels to trace material flows in

multi-echelon supply chains. Production Planning &

Control: The Management of Operations, 15, 3, 303-

312.

Junkkari, M., 2005. PSE: An object-oriented

representation for modeling and managing part-of

relationships. Journal of Intelligent Information

Systems, 25, 2, 131-157.

Junkkari, M., Sirkka, A., 2011. Using RFID for tracing

cumulated resources and emissions in supply chain,

International J. of Ad Hoc and Ubiquitous Computing,

8, 4, 220-229.

Motschnig-Pitrik, R., Kaasböll, J., 1999. Part-whole

relationship categories and their application in object-

oriented analysis. IEEE Transactions on Knowledge

and Data Engineering, 11, 5, 779-797.

Puettmann, M., Wilson, J., 2005. Gate-to-gate Life-Cycle

Inventory of Glued Laminated Timbers Production.

Wood Fiber Sci., 37, 99-113.

Data-CentricWorkflowApproachtoLifecycleDataManagement

123

Rempel, P., Mäder, P., Kuschke, T., Philippow, I., 2013.

Requirements traceability across organizational

boundaries - a survey and taxonomy. In Proceeding of

20th International Working Conference on

Requirements Engineering: Foundation for Software

Quality, LNCS 7830, 125-140.

Sirkka, A., Junkkari, M., 2012. Multidimensional Analysis

of Supply Chain Environmental Performance, Chapter

10 in Sustainable ICTs and Management Systems for

Green Computing, 231-250.

Sommerwille, I., 2007. Software Engineering, 8th edition,

Addison-Wesley, Harlow, England, 2007.

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

124
