Clothes Change Detection Using the Kinect Sensor
Dimitrios Sgouropoulos, Theodoros Giannakopoulos, Sergios Petridis,
Stavros Perantonis and Antonis Korakis
Computational Intelligence Laboratory (CIL), Institute of Informatics and Telecommunications, National Center for
Scientific Research DEMOKRITOS, Patriarchou Grigoriou & Neapoleos, Ag. Paraskevi 15310, Athens, Greece
Keywords:
Kinect, Clothes Change Detection, Activities of Daily Living.
Abstract:
This paper describes a methodology for detecting when a human has changed clothes. Changing clothes is
a basic activity of daily living which makes the methodology valuable for tracking the functional status of
elderly people, in the context of a non-contract unobtrusive monitoring system. Our approach uses Kinect and
the OpenNI SDK, along with a workflow of basic image analysis steps. Evaluation has been conducted on a
set of real recordings under various illumination conditions, which is publicly available along with the source
code of the proposed system at http://users.iit.demokritos.gr/ tyianak/ClothesCode.html.
1 INTRODUCTION
The elderly population is constantly growing during
the last decades and is expected to grow dramatically
over the next few years, especially in Europe. This
increase has made elderly care a rapidly growing task
and in particular it has led to major research effort
on implementing automatic assistive services for the
elderly, in order to facilitate independent living. In
this work, we employ image analysis techniques ap-
plied on data recorded from the Kinect sensor (Kin,
2011)(Zhang, 2012), in order to detect that a human
has changed clothes between two successive record-
ing sessions. The purpose of such a service is to mea-
sure the functional status of a person in the context
of in-home unobtrusive health monitoring. The abil-
ity to change clothes is an important self-care tasks
taken into consideration by health professionals when
monitoring a patient, especially for the case of people
with disabilities or the elderly. Such functional activi-
ties are referred to as Activities of daily living (ALDs)
(Self-maintenance, 1969) and include self-care tasks
such as: bathing, personal hygiene, toilet hygiene and
eating (Collin et al., 1988)(Collin and Wade, 1988)
Automatically recognizing ADLs has gained re-
search interest during the last years. This is usually
achieved through sensors such as accelerometers, Ra-
dio Frequency Identification (RFIDs), microphones
and cameras (Fleury et al., 2010)(Stikic et al., 2008).
In (Fleury et al., 2010) a multi-class Support Vec-
tor Machine (SVM) has been employed in order to
recognize among 7 ADLs, based on several sensors:
infra-red presence sensor, wearable kinematic sen-
sors, microphones and others. For the particular case
of the dressing/undressing activity, the overall classi-
fication accuracy was found equal to 75%, while the
maximum confusion was observed for the “resting”
and “sleeping” activities. Instead of recognizing the
(un)dressing activity among other classes of events,
in this work we focus on simply answering the binary
question: “has the person changed clothes between
two successive recordings?”. The task then simplifies
to (a) detect the clothes worn by the person (b) model
the clothes and (c) measure the similarity of clothes
detected between two recordings.
Automatically recognizing apparel using visual
information can have a wide range of potential ap-
plications: surveillance, e-commerce, household au-
tomated services, etc. Depending on the field of ap-
plication and the approach of information acquisition
the respective methods has been either applied on sin-
gle color images (e.g., (Chen et al., 2012)(Liu et al.,
2012b)) or combination of color and depth images
(e.g., (Maitin-Shepard et al., 2010)). In the context
of shopping recommendation and customer profiling,
some papers have proposed adopting visual analy-
sis methods to describe clothing appearance with se-
mantic attributes. (Chen et al., 2012) proposes us-
ing SIFT descriptors and SVMs to predict 26 pre-
defined attributes concerning clothing patterns, col-
ors, gender as well as general clothing categories (e.g.
shirts). (Liu et al., 2012b) describes a method for
85
Sgouropoulos D., Giannakopoulos T., Petridis S., Perantonis S. and Korakis A..
Clothes Change Detection Using the Kinect Sensor.
DOI: 10.5220/0005001200850089
In Proceedings of the 11th International Conference on Signal Processing and Multimedia Applications (SIGMAP-2014), pages 85-89
ISBN: 978-989-758-046-8
Copyright
c
2014 SCITEPRESS (Science and Technology Publications, Lda.)
clothing retrieval using a daily human photo captured
in a general environment (e.g. street). In (Liu et al.,
2012a), an automatic occasion-oriented (e.g. wed-
ding) clothing recommendation system is presented.
Towards this end, Histograms of Oriented Gradient
(HOG) and color histograms have been adopted as
features, while SVMs have been used as classifiers.
In a similar context, (Bossard et al., 2013) introduces
a pipeline for recognizing and classifying people’s
clothing in natural scenes. Among others, HOGs and
color histograms are used as features, while classifi-
cation is achieved via Random Forests. (Kalantidis
et al., 2013) presents a visual analysis method that
suggests clothing results given a single image.
Visual-based clothing classification has also been
used in household service robotic applications, i.e.
in automated laundry. In (Willimon et al., 2011), a
robotic system which identifies and extracts items se-
quentially from a pile using only visual sensors is de-
scribed. Classification of each clothing item is con-
ducted based on a six-class hierarchy (pants, shorts,
short-sleeve shirt, long-sleeve shirt, socks, or under-
wear). Depth information is also used based on a
stereo pair of cameras. In (Maitin-Shepard et al.,
2010) an application of robotic towel folding is pre-
sented, where image (both color and depth) analysis is
adopted to detect corners that can be used for grasping
the towel. (Ramisa et al., 2012) also presents a grasp-
ing point detection method using color and depth
information from a Kinect device. This work fo-
cuses on identifying the grasping points in one single
step, even when clothes are highly wrinkled, there-
fore avoiding multiple re-graspings. (Willimon et al.,
2013) focuses on defining mid-level features in or-
der to boost the clothing classification performance.
Again, the task here is to classify clothes from a pile
of laundry (three categories have been used: shirts,
socks and dresses).
2 METHODOLOGY
2.1 Clothes Detection
The Kinect Sensor provides RGB, depth data and
skeletal tracking information, i.e 3D coordinates of
tracked body skeletons ( (Xia et al., 2011)(Shotton
et al., 2013)). In particular, we have employed the
OpenNI SDK (http://www.openni.org/) in order to
identify the positions of these key joints on the hu-
man body (hands, elbows, head, etc), along with other
human position information such as orientation esti-
mates and distance from the sensor. The first step is
to specify the bounds of the areas of interest to nar-
rowdownthe particular task. The Kinect middle-ware
produces two matrices that are used for this purpose:
(a) pixel matrix: this matrix contains the color infor-
mation of each pixel in the RGB color space (b) user
matrix: this matrix indicates if the respective pixels
belong to a user (human) or not.
Using these matrices it is possible to maintain only
the important information, that is, the user-related
color values. Following that basic notation, the areas
of interest for the particular task have been set. In par-
ticular, two primary areas have been defined, namely,
the torso area (used to model the upper clothes eval-
uation) and the lower body (used to model the lower
clothes). The determination of these areas of inter-
est was based on the user data provided by Kinect
and information stemming from particular joint co-
ordinates of the skeleton, also provided by the Kinect
sensor. The upper body area is based on a rectangu-
lar area, with dimensions that are primarily defined
by the shoulders and torso joints and then enhanced
based on the user’s body width and height. Following
the same method we form the user’s lower body area
by using his hip and knee joints, from the skeleton
estimate, and performing similar improvements.
2.2 Clothes Color Representation
For each area of interest (torso and lower body), 60
feature values related to the color of the respective
clothing are extracted. In particular, 30 features stem
from the three histograms from the color information
(RGB), since 10 bins per color channels are used in
the histogram calibration. Similarly, 30 features stem
from the histograms of the edges of each color coor-
dinate. Towards, this end, the Sobel image operator
is applied on each color coordinate. At each frame
where a human is detected, a feature vector of the area
of interest is calculated as described above, along with
a respective confidence measure related to that detec-
tion. This process forms a feature matrix X : M ×D,
whose rows correspond to the respective feature vec-
tors. The confidence measure is extracted according
to the following weighted heuristic:
H(O, R, D) = w
1
·cos
2
(O)+ w
2
·R+ w
3
·
1
2
πσ
e
D
2
2σ
2
(1)
The first factor is based on the user’s orientation in
the room (in degrees): frontal orientation either look-
ing to the Kinect (O = 0) or at the other side (O = 180)
gives the highest confidence while profile orientations
(e.g. O = 90) gives the lowest. The second fac-
tor depends on R which is the ratio of the current to
the previous user pixel count (i.e. number of pixels
SIGMAP2014-InternationalConferenceonSignalProcessingandMultimediaApplications
86
that belong to the human, as estimated by the mid-
dleware). The last factor takes into account the user’s
distance from the sensor, where the σ is set to reflect
the expected. The respective weights of each factor
w
i
are determined by the efficiency of the heuristic
in our various experiments and our only restriction is
that w
1
+ w
2
+ w
3
= 1. In our experiments we use
w
1
= w
2
= 0.4 , w
3
= 0.2.
Finally, each recording session is represented as a
single feature vector which is computed as a weighted
average of individual feature vectors F
n
=
M
i=1
X
i,n
·C
i
M
i=1
C
i
,
where D is the number of feature dimensions (60),
M is the number of samples (feature vectors) of the
recording session, X
i,n
is the n-th feature of the i-th
sample, n = 1, . . . , D, and C
i
is the confidence value
of the i-th sample of the recording.
2.3 Color Constancy
The proposed system should function under a real
home-environment, therefore there is a need for ro-
bustness to varying illumination conditions. Towards
this end, we include in our methodology a color
constancy method, aiming towards color features re-
taining constant statistics under different illumination
conditions (Funt et al., 1996). In particular, we have
experimented with the following static methods for
color constancy: (a) the Grey-World algorithm which
assumes that the average color in a scene is achro-
matic and therefore normalizes each color based to
the respective gray (average) values (b) the White-
Patch method which normalizes each color coordinate
by the respective maximum channel value achieving
maximization towards a hypothetical white reference
area and (c) a simple modification of the White-Patch
which uses the average value of a range of high-
valued pixels (instead of using the global maximum)
in order to increase robustness to noise.
3 EXPERIMENTS
3.1 Data Used
In order to evaluate the cloth change detection ability
of the proposed approach, a dataset of real recordings
has been compiled and manually annotated. In total,
four humans have participated in the recordings un-
der two different lighting conditions, namely natural
and artificial lighting. For each case, a different num-
ber of upper and lower apparel has been used. Each
recorded session is stored on a separate
oni
file using
the OpenNI library. The name of these files indicate
the IDs of the corresponding apparel.
3.2 Evaluation Method
In this Section we describe the adopted methodol-
ogy for the evaluation of the discrimination ability of
the adopted color representation. We particularly de-
scribe the process for the upper clothes as it is exactly
the same for the lower clothes case. Given:
a set of upper clothes feature vectors FU
i
, i =
1, . . . , N, where N is the total number of video ses-
sions of 60 elements each.
a vector of upper labels LU
i
, i = 1, . . . , N where
each different value represents a distinct piece of
clothing. This is used as ground truth in the eval-
uation process.
We start by creating the confusion matrix CM
and initializing it with zeros. Then for each pos-
sible pair of FU
i
and FU
j
where i = 1, . . . , N and
j = 1, . . . , N, j 6= i we compute their Euclidean dis-
tance DU
i, j
and compare it to a user-defined threshold
T. If DU
i, j
is greater than T then that pair of clothes
is perceived to be different, otherwise the same. So
we now have four separate cases:
CM
1,1
: number of times that two feature vectors
have the same estimated label (DU
i, j
T) and the
same ground truth label (LU
i
= LU
j
) - true nega-
tive
CM
1,2
: number of times that two feature vectors
have different estimated labels (DU
i, j
> T) but the
same ground truth label (LU
i
= LU
j
) - false posi-
tive
CM
2,1
: number of times that two feature vectors
have the same estimated label (DU
i, j
T) but dif-
ferent ground truth labels (LU
i
6= LU
j
)- false neg-
ative
CM
2,2
: number of times that two feature vectors
have different estimated labels (DU
i, j
> T) and
different truth labels (LU
i
6= LU
j
) - true positive
After computing the overall confusion matrix, as
described above, it is normalized so that the two
events are considered equiprobable and finally the
performance measures Precision, Recall and F1 mea-
sure are calculated: Pr =
CM
2,2
2
i=1
CM
i,2
, Re =
CM
2,2
2
i=1
CM
2,i
and F1 =
2·Pr·Re
Pr+Re
. The exact same evaluation process
is repeated for the lower clothing.
3.3 Evaluation Results
As described above, the recordings have been con-
ducted under two different general illumination cate-
ClothesChangeDetectionUsingtheKinectSensor
87
Table 1: F1 evaluation results (%) for different lighting con-
ditions and all feature calibration methods.
Artificial Natural Mixed
No color constancy 77 82 72
Gray world
78 83 71
White Patch
84 82 77
Modified White Patch
85 85 80
gories (natural and artificial lighting). The evaluation
has been based on these two categories, as long as
their “mixed” condition: the latter is the general (and
harder) case of detecting changes under all possible
illumination conditions. The results of this process
are shown in Table 1. Due to space limitations, we do
not present the performance results for the upper and
lower clothings but only their averages. However, we
would like to report that, in average, the problem of
detecting changes on the lower clothes is at least 10%
harder, in terms of F1 measure. This is probably due
to the fact that the lower body part is usually not en-
tirely visible, in the context of a real home environ-
ment, since there are usually pieces of furniture and
other objects intervening between the sensor and the
human.
4 CONCLUSIONS
We have presented a Kinect-based approach to detect-
ing changes in users’ clothes in a smart home envi-
ronment in the context of measuring the functional
status of the elderly. The whole system has been im-
plemented in the Processing programming language,
using the OpenNI SDK and achieves real-time detec-
tion. In order to evaluate the proposed approach, a
dataset of recordings under various illumination con-
ditions has been compiled, which is also publicly
available. Experimental results have indicated that
the overall change detection method achieves up to
80% performance for mixed lighting conditions and
85 for single conditions, that is 8% compared to the
performance when the initial feature representation is
adopted. In addition, the adopted color constancy ap-
proach abridges the gap at the performance between
different illumination conditions. In the context of the
carried out ongoing work we focus on the following
directions: (a) implementation of more advanced im-
age features (e.g. HOGs) (b) evaluation of more so-
phisticated color constancy techniques and (c) exten-
sion of the benchmark with more users and clothes
combinations.
ACKNOWLEDGEMENTS
The research leading to these results has re-
ceived funding from the European Union’s Seventh
Framework Programme (FP7/2007-2013) under grant
agreement no 288532. For more details, please see
http://www.usefil.eu.
REFERENCES
(2011). Microsoft kinect sensor. Online available:
http://www.microsoft.com/en-us/kinectforwindows/.
Accessed April 1, 2013.
Bossard, L., Dantone, M., Leistner, C., Wengert, C., Quack,
T., and Gool, L. V. (2013). Apparel classification with
style. In Computer Vision–ACCV 2012, pages 321–
335. Springer.
Chen, H., Gallagher, A., and Girod, B. (2012). Describing
clothing by semantic attributes. In Computer Vision–
ECCV 2012, pages 609–623. Springer.
Collin, C. and Wade, D. (1988). The barthel adl index: a
standard measure of physical disability? Disability &
Rehabilitation, 10(2):64–67.
Collin, C., Wade, D., Davies, S., and Horne, V. (1988). The
barthel adl index: a reliability study. Disability & Re-
habilitation, 10(2):61–63.
Fleury, A., Vacher, M., and Noury, N. (2010). Svm-based
multimodal classification of activities of daily liv-
ing in health smart homes: sensors, algorithms, and
first experimental results. Information Technology in
Biomedicine, IEEE Transactions on, 14(2):274–283.
Funt, B., Cardei, V., and Barnard, K. (1996). Learning color
constancy. In IS&T/SID Fourth Color Imaging Con-
ference, pages 58–60.
Kalantidis, Y., Kennedy, L., and Li, L.-J. (2013). Getting
the look: clothing recognition and segmentation for
automatic product suggestions in everyday photos. In
Proceedings of the 3rd conference on International
conference on multimedia retrieval, pages 105–112.
ACM.
Liu, S., Feng, J., Song, Z., Zhang, T., Lu, H., Xu, C., and
Yan, S. (2012a). Hi, magic closet, tell me what to
wear! In Proceedings of the 20th international con-
ference on Multimedia, pages 619–628. ACM.
Liu, S., Song, Z., Liu, G., Xu, C., Lu, H., and Yan, S.
(2012b). Street-to-shop: Cross-scenario clothing re-
trieval via parts alignment and auxiliary set. In Com-
puter Vision and Pattern Recognition (CVPR), 2012
IEEE Conference on, pages 3330–3337. IEEE.
Maitin-Shepard, J., Cusumano-Towner, M., Lei, J., and
Abbeel, P. (2010). Cloth grasp point detection based
on multiple-view geometric cues with application to
robotic towel folding. In Robotics and Automa-
tion (ICRA), 2010 IEEE International Conference on,
pages 2308–2315. IEEE.
Ramisa, A., Alenya, G., Moreno-Noguer, F., and Torras, C.
(2012). Using depth and appearance features for in-
formed robot grasping of highly wrinkled clothes. In
SIGMAP2014-InternationalConferenceonSignalProcessingandMultimediaApplications
88
Robotics and Automation, International Conference
on, pages 1703–1708. IEEE.
Self-maintenance, P. (1969). Assessment of older people:
self-maintaining and instrumental activities of daily
living.
Shotton, J., Sharp, T., Kipman, A., Fitzgibbon, A., Finoc-
chio, M., Blake, A., Cook, M., and Moore, R. (2013).
Real-time human pose recognition in parts from sin-
gle depth images. Communications of the ACM,
56(1):116–124.
Stikic, M., Huynh, T., Laerhoven, K. V., and Schiele, B.
(2008). Adl recognition based on the combination of
rfid and accelerometer sensing. In Pervasive Com-
puting Technologies for Healthcare, 2008, pages 258–
263. IEEE.
Willimon, B., Birchfleld, S., and Walker, I. (2011). Clas-
sification of clothing using interactive perception. In
Robotics and Automation (ICRA), 2011 IEEE Interna-
tional Conference on, pages 1862–1868. IEEE.
Willimon, B., Walker, I., and Birchfield, S. (2013). A
new approach to clothing classification using mid-
level layers. In Proceedings of the International Con-
ference on Robotics and Automation (ICRA).
Xia, L., Chen, C.-C., and Aggarwal, J. (2011). Hu-
man detection using depth information by kinect. In
Computer Vision and Pattern Recognition Workshops
(CVPRW), 2011 IEEE Computer Society Conference
on, pages 15–22. IEEE.
Zhang, Z. (2012). Microsoft kinect sensor and its effect.
Multimedia, IEEE, 19(2):4–10.
ClothesChangeDetectionUsingtheKinectSensor
89
