Automatic and Graceful Repairing of Data Inconsistencies Resulting

from Retroactive Updates in Temporal Xml Databases

Hind Hamrouni, Zouhaier Brahmia and Rafik Bouaziz

Department of Computer Science, Faculty of Economics and Management, University of Sfax, Sfax, Tunisia

Keywords: Temporal XML Databases, Retroactive Update, Data Inconsistency, Inconsistency Periods, Repairing an

Inconsistency, Side Effect, Side Effects Recovery.

Abstract: In temporal XML databases, a retroactive update (i.e., modifying or deleting a past element) due to a

detected error means that the database has included erroneous information during some period and,

therefore, its consistency should be restored by correcting all errors and inconsistencies that have occurred

in the past. Indeed, all processing that have been carried out during the inconsistency period and have used

erroneous information have normally produced erroneous information. In this paper, we propose an

approach which preserves data consistency in temporal XML databases. More precisely, after any

retroactive update, the proposed approach allows (i) detecting and analyzing periods of database

inconsistency, which result from that update, and (ii) repairing of all inconsistencies and recovery of all side

effects.

1 INTRODUCTION

Nowadays, supporting the temporal aspect is a

requirement for most computer applications,

including processing of scientific and census data,

banking and financial transactions, record-keeping

and scheduling applications. In fact, these

applications need to store and manipulate data while

taking into account the time dimension; this has led to

the appearance of temporal databases (Etzion et al.,

1998, Grandi, 2014) which retain data evolution over

transaction-time dimension and/or valid-time

dimension (Jensen et al., 1998):

 The valid-time of a datum is the time when a

datum is true in the real world; each time-varying

datum is timestamped with a validity start time

(VST) and a validity end time (VET).

 The transaction-time of a datum is the time when a

datum is current in the database; each time-varying

datum is timestamped with a transaction start time

(TST) and a transaction end time (TET).

In temporal databases, there are three types of

updates concerned with the time when updates are

made: retroactive, proactive (Etzion et al., 1994), and

real-time (or on-time) updates.

 A retroactive update is done after the change

occurred in reality (i.e., the TST of the datum is

superior to its VST).

 A proactive update is done before the change

occurs in reality (i.e., the TST of the datum is

inferior to its VST).

 A real-time update is done when the change occurs

in reality (i.e., the TST of the datum is equal to its

VST).

Retroactive and proactive updates occur naturally

in many applications. For example, a salary increase

may be retroactive to some past date, and a postdated

check is a proactive update.

On the other hand, currently, XML databases

(Bourret, 2005) are widely used, especially on the

web. The introduction of temporal (Dyreson et al.,

2009) aspects in such databases gave rise to temporal

XML databases (Brahmia et al., 2014). In these

databases, any temporal XML document can store

transaction-time, valid-time and bi-temporal XML

elements. Moreover, these databases are very useful

for several domains (e.g., managing evolution of legal

texts in e-government systems, online management of

patients’ medical records...). Notice that temporal

XML databases are richer than temporal relational

databases at structure and textual content levels.

Moreover, temporal XML data are presented with

temporally grouped data models. Indeed, each time-

varying XML element evolves individually over time.

However, although temporal XML databases

allow end users/applications to perform retroactive

243

Hamrouni H., Brahmia Z. and Bouaziz R..

Automatic and Graceful Repairing of Data Inconsistencies Resulting from Retroactive Updates in Temporal Xml Databases.

DOI: 10.5220/0005004102430250

In Proceedings of 3rd International Conference on Data Management Technologies and Applications (DATA-2014), pages 243-250

ISBN: 978-989-758-035-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

updates on stored data, such updates are not always

performed safely since they could have a harmful

effect on the consistency of the database. Let’s take

the example of correcting a past banking interest rate

in a bank, which was applied during the period going

from 2013-01-01 to 2013-12-31. All existing data

(e.g., interest bank accounts, balances of bank

accounts, scheduled payment amounts) that have been

obtained using the erroneous past banking interest

rate are consequently erroneous and should be

corrected. The database was inconsistent during the

period where this interest rate was effective.

In this paper, we focus on the impacts of

retroactive updates on the consistency of the database

and we propose an approach that allows the temporal

XML database management system (DBMS) (i) to

detect any database inconsistency that happens due to

a retroactive update, and (ii) to perform automatically

the necessary processings, in a transparent way, in

order to repair the detected inconsistencies.

The rest of this paper is organized as follows: the

next section motivates the need for a new approach

for preserving the consistency of temporal XML

databases; Section 3 describes data inconsistencies

resulting from retroactive updates in such databases;

Section 4 presents our approach for an automatic and

graceful repairing of data inconsistencies that occur

due to retroactive updates; Section 5 discusses related

work; Section 6 concludes the paper.

2 MOTIVATION

In this section, we first present an example that

illustrates how maintaining consistency in temporal

XML databases after a retroactive update is a

complicated task that could not be achieved using

existing supports provided by DBMSs. Then we show

the need for systems providing supports for

preserving consistency of temporal XML databases.

2.1 Motivating Example

Suppose that on 2014-03-25, the auditor detects an

error that has occurred on 2014-01-05: the bank

employee saved a deposit transaction which adds an

amount of 550 TND (the erroneous value) instead of

500 TND (the correct value), to the account of a

customer; thus, an amount of 50 TND was stored in

the database but really was not provided by the

customer. Obviously, this error was propagated to all

other financial transactions that have been done on

this account between 2014-01-05 and 2014-03- 25;

there was always an amount of 50 TND which should

be subtracted from the balance.

The semantics of existing data update operations

(Brahmia et al., 2009), which should be used to

correct both the deposited amount and the balance

account on 2014-01-05, does not support the

correction of the impact of this error (i.e., to correct

each balance of this account, related to each

transaction performed after 2014-01-05). Such an

operation corrects only the details of the financial

transaction (i.e., the deposited amount and the

balance of the account at the end of the transaction)

done on 2014-01-05. To restore the database

consistency, the database administrator should

proceed in an ad hoc manner: first, he/she should

determine the list of all transactions that were

performed on this account going from the transaction

during which the error has occurred until the last one.

Then, he/she should update all erroneous data by

writing an appropriate XML update (Tatarinov et al.,

2001; W3C, 2011; Hamrouni, 2012).

2.2 Need for New DBMS Supports

The consistency of a temporal XML database could

not be ensured easily, since (i) all temporal

dimensions are supported (i.e., data can evolve over

transaction time and/or valid time), and (ii) a data

management operation that is originally devoted to

insert, delete, or update an XML element could

involve several other XML elements (e.g., when the

temporal interval of a new element that modifies an

existing one overlaps, completely or partially,

temporal intervals of other existing XML elements).

Furthermore, since the database administrator lacks

methods and tools needed to automate the activity of

detecting and repairing data inconsistencies in

temporal XML databases, such an activity remains an

error-prone and time-consuming undertaking.

Thus, the challenges described above show that

end users/applications, using temporal XML

databases, need DBMSs with built-in support for

detecting and repairing automatically inconsistencies

which result from retroactive updates.

3 DATA INCONSISTENCIES

RESULTING FROM

RETROACTIVE UPDATES

In (Bouaziz et al., 1998), the authors defined an

inconsistency period resulting from a retroactive

update of data as the temporal interval which delimits

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

244

the scope of side effects that are expected to be

generated by this update. Such an inconsistency

period could be of one of the following three types:

“Wrong Absence of Data”, “Wrong Presence of

Data”, or “Errors in Data”.

 Wrong Absence of Data: the inconsistency is due

to the absence of a datum that had to be present in

the database during this period;

 Wrong Presence of Data: the inconsistency comes

from the presence of a datum that had to be absent

in the database during this period;

 Errors in Data: the inconsistency results from the

existence of some data with erroneous values

during this period.

An inconsistency period, resulting from a

retroactive update can be divided into several sub-

periods; each one of these sub-periods should be

interpreted according to the nature (i.e., insertion,

deletion, or correction) of the retroactive update. In

the following, we study periods of inconsistency, and

their sub-periods.

3.1 Data Inconsistencies Resulting from

a Retroactive Insertion of Data

The insertion of an XML element with retroactive

effect generates an inconsistency period of “Wrong

Absence of Data” type: the inserted element, which

was absent before its transaction start time, should be

normally present in the temporal database since its

validity start time. Fig. 1 illustrates such a period of

inconsistency. In the following, we use CT to denote

the “current time”.

Figure 1: The inconsistency period resulting from a

retroactive insertion of data.

As shown by Fig. 1, the period of inconsistency,

which is delimited by the VST (period beginning) and

the TST (period ending) of e

, can be divided into two

sub-periods:

 [VST

– VET

]: the interval during which the

consequent side effects concern all processings

that had to use the element e

while it had to be a

current element;

 ]VET

– TST

]: the interval during which the

generated side effects concern all processings that

had to use the element e

while it had to be a past

element.

3.2 Data Inconsistencies Resulting from

a Retroactive Deletion of Data

The removal of an XML element with retroactive

effect generates an inconsistency period of “Wrong

Presence of Data” type: the deleted element, which

was present before the instant of its deletion (i.e.,

before the TST of the deletion element (Brahmia et

al., 2009) which is used to perform this deletion),

should not normally exist in the temporal database

since its validity start time. Fig. 2 illustrates such a

period of inconsistency.

Figure 2: The inconsistency period resulting from a

retroactive deletion of data.

As shown by Fig. 2, the period of inconsistency,

which is delimited by the VST of e

(period

beginning) and the TST of e

(period ending), can be

divided into two sub-periods:

 [VST

- VET

]: the interval during which the

resulting side effects concern all processings that

had used the element e

while it was a current

element;

 ]VET

- TST

]: the interval during which the

consequent side effects concern all processings

that had used the element e

while it was a past

element.

3.3 Data Inconsistencies Resulting from

a Retroactive Correction of Data

Retroactive correction operations could be done only

on valid-time and bitemporal data. In this paper, we

deal only with retroactive correction of bitemporal

data, since we think that it is more complex and, thus,

it requires much attention.

The correction of a bitemporal element is

performed by inserting a new element containing the

correct values, called the element of correction

(Brahmia et al., 2009). A correction operation can

affect (i) the contents of the corrected element, (ii)

values of non-temporal attributes (i.e., attributes

different of VST, VET, TST, and TET attributes) of

the corrected element, and/or (iii) the valid-time

interval of the corrected element (i.e., values of VST

and VET attributes); obviously, the transaction-time

AutomaticandGracefulRepairingofDataInconsistenciesResultingfromRetroactiveUpdatesinTemporalXmlDatabases

245

interval (i.e., values of TST and TET attributes) of

any element cannot be modified owing to the

definition of transaction time. In the first and/or the

second case (i.e., points (i) and (ii)), the correction

operation generates an inconsistency period of type

“Errors in Data”. However, in the third case (i.e.,

point (iii)), it generates an inconsistency period which

can be divided into several sub-periods each one of

them has a different type.

In the following, we deal with inconsistencies

resulting from a retroactive correction operation that

updates the contents and/or the values of non-

temporal attributes of a bitemporal element; it

modifies neither the VST attribute, nor the VET

attribute. This correction generates an inconsistency

period of type “Errors in Data”: it means that the

corrected element had an erroneous value. Fig. 3

illustrates such a period of inconsistency.

When the valid-time interval of a bitemporal

element is modified, we distinguish ten cases

according to Allen's interval algebra (Allen, 1983)

and all possible relations between the valid-time

interval of the correction element (e

) and that of the

corrected element (e

); more details on all these cases

can be found in (Hamrouni et al., 2014).

Figure 3: The inconsistency period resulting from a

retroactive correction operation which does not modify the

valid-time interval of a bitemporal element.

As shown by Fig. 3, the period of inconsistency,

which is delimited by the VST of e

(period

beginning) and the TST of e

(period ending), can be

divided into two sub-periods:

 [VST

- VET

]: the interval during which the

generated side effects concern all processings that

had used the element e

while it was a current

element;

 ]VET

- TST

]: the interval during which the

consequent side effects concern all processings

that had used the element e

while it was a past

element.

4 DETECTING AND REPAIRING

DATA INCONSISTENCIES

RESULTING FROM

RETROACTIVE UPDATES IN

TEMPORAL XML DATABASES

In this section, we propose an approach that allows

restoring automatically the database consistency after

a retroactive update of temporal XML data. First, we

describe the process of detecting and repairing

automatically database inconsistencies. Then, we

present the architecture of a native temporal XML

DBMS which provides supports for an automatic

detection and repair of data inconsistencies after a

retroactive update.

4.1 Process of Detecting and Repairing

Automatically Data Inconsistencies

When an end user or an application submits to the

temporal XML DBMS a retroactive update of

temporal XML data, the DBMS performs the

following sequence of tasks:

Task 1: it updates the database as required by the end

user or the application (obviously after checking the

update syntactically).

Task 2: it determines automatically the period of

inconsistency resulting from the retroactive update

of data, and its sub-periods.

Task 3: it determines automatically the list of

transactions that were executed during each sub-

period of inconsistency and had used erroneous past

data (in case that the corresponding sub-period of

inconsistency is of type “Wrong Presence of Data”

or “Errors in Data”) or had to use new data (in case

that the corresponding sub-period of inconsistency

is of type “Wrong Presence of Data” or “Errors in

Data”); for each concerned transaction, it should

provide its commit time, all its elementary

operations (for the sake of simplicity, we suppose

that a transaction is composed of a single operation,

i.e., a single insert, delete, or update operation), and

all data that were written and read by this

transaction.

Task 4: it re-executes in a provisory workspace the

list of corresponding transactions during each sub-

period of inconsistency either (a) without using the

corresponding past data, if this sub-period is of type

“Wrong Presence of Data”, or (b) while using (b.1)

the correct values of past data, if this sub-period is

of type “Errors in Data”, or (b.2) the specified past

data, if this sub-period is of type “Wrong Absence

of Data”.

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

246

Task 5: it compares the old results of determined

transactions (i.e., results already stored in the

database, as written data by these transactions) with

the new results of them (i.e., the new data that are

written by these transactions in the provisory

workspace).

Task 6: it replaces every old result with the

corresponding new result when there is a difference

between them.

In the following, we provide main requirements of

some tasks presented above:

 Task 1 requires that the DBMS supports

management of temporal XML data under schema

versioning; we have studied this aspect in our

previous work (Hamrouni, 2012).

 Task 3 requires beforehand keeping track of all

transactions which are executed: all operations

which compose each transaction, all written and

read data, and its commit time;

 Task 4 requires that the provisory workspace

should be a copy of the database (schema and

instances) during the inconsistency period, before

the execution of the retroactive update operation.

 Task 6 requires that replacing old data with new

data should be performed logically and not

physically (i.e., in a destructive manner); each

existing erroneous data is logically corrected by a

new correct data. After restoring the database

consistency, only correct data must be used by the

DBMS to answer user/application queries;

erroneous data could be vacuumed later (Skyt et

al., 2003) by the database administrator.

4.2 Architecture of a DBMS Supporting

Detection and Repair of Data

Inconsistencies

Owing to the general architecture of a DBMS

(Hellerstein et al., 2007), the transaction manager is

the component which is devoted to managing

transactions resulting from user/applications queries

and updates submitted to the database. Therefore, if

we would like to have an automatic restoring of the

database consistency after any retroactive update of

temporal XML data, we think that (i) the transaction

manager of a temporal XML DBMS should be

extended by four new components: “Retroactive

Update Checker”, “Inconsistency Period Manager”,

“Side Effect Recovery Manager” and “Optimizer”,

and (ii) the temporal XML DBMS itself should

include a “Transaction Catalog Manager”, a

“Transaction Catalog”, and a “Provisory Workspace”.

The new general architecture of a temporal XML

DBMS is depicted in Fig. 4.

The “Retroactive Update Checker” checks that

the Temporal XML Update submitted by the end

user/application is an update operation with

retroactive effect (i.e., this operations adds, deletes, or

modifies past data). Notice that a past data has a

valid-time interval which ends before the current time

(i.e., VET < CT).

The “Inconsistency Period Manager”, which is

invoked by the “Retroactive Update Checker” in case

it detects a retroactive update, determines

automatically the period of inconsistency which

results from a retroactive update of data, and its sub-

periods with their types. Suppose that an erroneous

past element “ee” is corrected by a correct past

element “ce”. The resulting period of inconsistency is

defined by either the interval [VST

- CT] (if VST

< VST

), or [VST

- CT] (if VST

< VST

). The

sub-periods of inconsistency related to this period are

identified according to the study presented in the

subsection 3.3.

After determining all sub-periods of

inconsistency, the “Inconsistency Period Manager”

(i) invokes the “Transaction Catalog Manager” in

order to retrieve from the “Transaction Catalog” the

list of transactions that were executed during each

one of these sub-periods, and (ii) sends all retrieved

transactions to the “Side Effect Recovery Manager”.

The “Side Effect Recovery Manager” controls

the re-execution of transactions which have used

erroneous data (i.e., transactions executed during a

period of inconsistency of type “Wrong Presence of

Data” or “Errors in Data”) and transactions that had

to use newly added data (i.e., transactions executed

during a period of inconsistency of type “Wrong

Absence of Data”). The concerned transactions are

re-executed in a “Provisory Workspace” which is a

copy of the database during the corresponding period

of inconsistency. At the end of the re-execution of

each transaction, the “Side Effect Recovery Manager”

compares the results of determined transaction

already stored (as written data) in the database with

the results of the execution in the provisory

workspace. If there are differences between them, so

an inconsistency is detected and it should be repaired.

For that, the “Side Effect Recovery Manager”

replaces the old result with the new one.

The “Side Effect Recovery Manager” interacts

with the “Optimizer” module which implements a set

of optimization rules. Indeed, the “Optimizer”

receives a sequence of non-optimized transactions

that should be re-executed, and tries to reduce them

(if possible). In the following, we present three

examples of these optimization rules:

 Rule 1: if two successive transactions, T1 and T2,

AutomaticandGracefulRepairingofDataInconsistenciesResultingfromRetroactiveUpdatesinTemporalXmlDatabases

247

Figure 4: General Architecture of a temporal XML DBMS supporting automatic detecting and repairing of data

inconsistencies resulting from retroactive updates.

act on the same XML element e12, such that T1

adds e12 and T2 deletes e12, then the system has

to ignore these two transactions and do not re-

execute them.

 Rule 2: if two successive transactions, T3 and T4,

act on the same XML element e34, such that T3

adds e34 and T4 updates e34, then the system has

to combine/merge the two transactions into the

first one (which is T3) and re-executing it (i.e., re-

executing T3) but with updated values provided in

the second one (which is T4): adding e34 with

updated values provided in T4.

 Rule 3: if a transaction does not include any

operation of type data insertion, deletion, or

modification, then the system has to ignore this

transaction and do not re-execute it.

The “Transaction Catalog Manager” is added in

order to have a history of transactions, which is

complete (all details of transactions) and useful (i.e.,

easy-to-use by Side Effect Recovery Manager). For

each transaction, it saves its commit time, the

specified insert, delete, or update operation (since we

suppose that each transaction include only one data

manipulation operation), data read from the database,

data written to the database, data values provided by

the user in its data manipulation operation.

5 RELATED WORK

Despite the importance of preserving consistency of

temporal databases after retroactive updates, this

issue has been considered only to a limited extent in

the current literature.

In (Samet, 1997), the author proposed the use of

temporal active rules and retroactive rules (Pissinou

et al., 1994) in order to redress side effects resulting

from a retroactive update in a temporal relational

active database. An active rule or an Event-

Condition-Action (E-C-A) rule is said to be temporal

if (1) the event is temporal, or (2) the condition is

temporal. A retroactive rule is a rule whose action

includes a retroactive update.

In (Bouaziz et al., 1998), the authors proposed a

solution for redressing side effects generated by a

retroactive update, named “correction propagation”.

This solution is defined to repair only inconsistencies

which affect cumulative attributes (i.e., attributes

which can undergo only operations of additions or

subtractions of values, like the balance of a bank

account or the turnover of a company).

Preserving the consistency of temporal databases

was studied in other works which did not consider

retroactive updates. Indeed, some of these works have

dealt with database consistency with regard to (i) the

respect of integrity constraints (Campo et al., 2006;

Svirec et al., 2012), (ii) the concurrency control of

transactions, by proposing new pessimistic (De

Castro, 1998) and optimistic algorithms (Makni et al.,

2010), or (iii) the forensic analysis of database

tampering (Pavlou et al., 2013).

Retroactive and proactive updates were studied in

temporal active databases (Etzion et al., 1994) and in

conventional (non-temporal) databases (Deng et al.,

1995). However, none of these works has dealt with

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

248

inconsistencies that could result from such updates.

In (Pardede et al., 2008), the authors propose a

generic methodology for the management of XML

data update in XML-enabled databases. However,

they did not deal with retroactive updates, and define

a data inconsistency as a data invalidity resulting

from an XML data update.

Brahmia et al. (2009) and Hamrouni (2012) have

studied data management in multi-temporal XML

databases supporting schema versioning, but none of

them have taken into account data inconsistencies

resulting from retroactive update operations.

Afrati et al. (2009) have dealt with managing

inconsistency in databases, within the framework of

database repairs (Arenas et al., 1999); a repair of an

inconsistent database is a database over the same

schema that satisfies the integrity constraints at hand

and differs from the given inconsistent database in

some minimal way.

Consistency of data, which takes into account the

violation of semantic rules defined over a set of data

items, has been also studied within the issue of data

cleansing (Mezzanzanica et al., 2013) and considered

as a data quality dimension (Batini et al., 2006).

Recently, Zellag et al. (2014) propose an

approach for detecting consistency anomalies and

automatically reducing their occurrence, in multi-tier

architectures.

6 CONCLUSION

In this paper, we proposed an approach for an

automatic and graceful repairing of data

inconsistencies in temporal XML databases, resulting

from retroactive updates. It allows the DBMS (i) to

detect any database inconsistency that happens after a

retroactive update operation, and (ii) to perform

necessary processings, in a transparent way, in order

to repair inconsistencies automatically.

We think that our approach (i) maintains

effectively the consistency of the database, and (ii)

provides a low-impact solution since it requires

neither modifications of existing temporal database,

nor extensions to existing temporal XML models

(e.g., τXSchema (Snodgrasss et al., 2008)) and query

languages (e.g., TXPath (Rizzolo et al., 2008)).

A system prototype which shows the feasibility of

our approach is under development (at the University

of Sfax), as a temporal stratum on top of the existing

XML DBMS xDB (EMC, 2014). In fact, the first

author is extending the prototype TempoXUF-Tool

(Hamrouni, 2012), developed within her master's

project for temporal XML data management under

schema versioning, to support detecting and repairing

data inconsistencies resulting from retroactive

updates. Currently, this prototype allows only

determining periods of inconsistencies when it

receives a temporal XQuery Update Facility query

with retroactive effect.

As a part of our future work, we envisage to

extend our work by (i) dealing with retroactive

updates which concern several temporal XML

elements (in our present work we have supposed that

a retroactive update consider always one temporal

XML element), and (ii) studying transactions that

include several temporal XML updates with

retroactive effect (in fact, in the current work we

supposed that a transaction include always a single

temporal XML retroactive update).

Furthermore, we also plan to study how to repair

inconsistencies resulting from on-time and proactive

updates of temporal XML databases, since the update

of a current or a future temporal XML element could

also give rise to some inconsistencies.

REFERENCES

Afrati, F. N. & Kolaitis, P. G. 2009, ‘Repair Checking in

Inconsistent Databases: Algorithms and Complexity’,

Proceedings of the 12

International Conference on

Database Theory (ICDT 2009), St. Petersburg, Russia,

23-25 March, pp. 31-41.

Allen, J. F. 1983, ‘Maintaining Knowledge About

Temporal Intervals’, Communications of the ACM, Vol.

26, No. 11, pp. 832-843.

Arenas, M., Bertossi, L. & Chomicki, J. 1999, ‘Consistent

Query Answers in Inconsistent Databases’, Proceedings

of the 18

ACM SIGACT-SIGMOD-SIGART

Symposium on Principles of Database Systems (PODS

1999), Philadelphia, Pennsylvania, USA, 31 May – 2

June, pp. 68-79.

Batini, C. & Scannapieco M. 2006, (eds.), Data Quality:

Concepts, Methodologies and Techniques. Data-Centric

Systems and Applications. Springer, Heidelberg.

Bouaziz, R. & Moalla, M. 1998, ‘Historisation of Data and

Recovery of Side Effects’ (in french), Proceedings of

Journées de Bases de Données Avancées

(BDA’1998), Hammamet, Tunisia, 23-26 October, pp.

487-507.

Bourret, R. 2005, XML and Databases, available at:

<http://www.rpbourret.com/xml/XMLAndDatabases.ht

m>, last updated in September 2005.

Brahmia, Z. & Bouaziz, R. 2009, ‘Data Manipulation in

Multi-Temporal XML Databases Supporting Schema

Versioning’, Proceedings of the 4

International EDBT

Workshop on Database Technologies for Handling

XML Information on the Web (DaTaX’09), Saint-

Petersburg, Russia, 22 March.

AutomaticandGracefulRepairingofDataInconsistenciesResultingfromRetroactiveUpdatesinTemporalXmlDatabases

249

Brahmia, Z., Grandi, F., Oliboni, B. & Bouaziz, R. (in

press, to appear during 2014), ‘Schema Change

Operations for Full Support of Schema Versioning in

the tauXSchema Framework’, International Journal of

Information Technology and Web Engineering.

Campo, M. & Vaisman, A. 2006, ‘Consistency of Temporal

XML Documents’, Proceedings of the 4

International

XML Database Symposium (XSym 2006), Seoul, Korea,

10-11 September, pp. 31–45.

De Castro, C. 1998, ‘On concurrency management in

temporal relational databases’, Proceedings of 6

Italian Symposium on Database Systems (SEBD 1998),

Ancona, Italy, June, pp. 189-202.

Deng, M., Sistla, A. P., & Wolfson, O. 1995, ‘Temporal

Conditions with Retroactive and Proactive Updates’,

Proceedings of the 1

International Workshop on Active

and Real-Time Database Systems (ARTDB-95), Skövde,

Sweden, 9-11 June, pp. 122-141.

Dyreson, C. E., & Grandi, F. 2009, ‘Temporal XML’, in L.

Liu and M. T. Özsu (Eds.), Encyclopedia of Database

Systems. Heidelberg: Springer-Verlag, pp. 3032–3035.

EMC. 2014, Documentum xDB. Available at:

<http://www.emc.com/products/detail/software2/docum

entum-xdb.htm>

Etzion, O., Gal A. & Segev A. 1994, ‘Retroactive and

Proactive Database Processing’, Proceedings of the 4

International Workshop on Research Issues in Data

Engineering: Active Database Systems (RIDE-ADS

1994), Houston, Texas, USA, 14-15 February, pp. 126-

131.

Etzion O., Jajodia S., Sripada S. 1998, (eds.), Temporal

Databases: Research and Practice, LNCS 1399,

Springer-Verlag.

Grandi F. (in press, to appear in July 2014), ‘Temporal

Databases’, In M. Koshrow-Pour, (Ed.), Encyclopedia

of Information Science and Technology (3rd Ed.), IGI

Global, Hershey.

Hamrouni, H. 2012, Extending XQuery Update Facility to

Temporal and Versioning Aspects, Master thesis,

Faculty of Economics and Management of Sfax,

Tunisia.

Hamrouni, H., Brahmia, Z. & Bouaziz, R. 2014, An

Efficient Approach for Detecting and Repairing Data

Inconsistencies Resulting from Retroactive Updates in

Multi-Temporal and Multi-version XML Databases,

TimeCenter Technical Report TR-97, 22 pages, 17

June.

<http://timecenter.cs.aau.dk/TimeCenterPublications/T

R-97.pdf>

Hellerstein, J. M., Stonebraker, M. & Hamilton, J. 2007,

‘Architecture of a Database System’, Foundations and

Trends

in Databases, Vol. 1, No. 2, pp. 141-259.

Jensen, C. S., Dyreson, C. E., (Eds.), et al. 1998, ‘The

Consensus Glossary of Temporal Database Concepts –

February 1998 Version’, In O. Etzion S. Jajodia, & S.

Sripada, (Eds.), Temporal Databases: Research and

Practice, LNCS 1399, pp. 367–405. Berlin: Springer-

Verlag.

Makni, A. & Bouaziz, R. 2010, ‘Performance evaluation of

an optimistic concurrency control algorithm for

temporal databases’, Proceedings of the 2

International Conference on Advances in Databases,

Knowledge, and Data Applications (DBKDA 2010),

Menuires, France, 11-16 April, pp. 75–81.

Mezzanzanica, M., Boselli, R., Cesarini, M., & Mercorio,

F. 2013, ‘Automatic Synthesis of Data Cleansing

Activities’, Proceedings of the 2

International

Conference on Data Management Technologies and

Applications (DATA 2013), Reykjavík, Iceland, 29-31

July, pp. 138-149.

Pardede, E., Rahayu, J. W., & Taniar D., ‘XML data update

management in XML-enabled database’, Journal of

Computer and System Sciences, Vol. 74, No. 2, pp. 170-

195.

Pavlou, K. E., & Snodgrass, R. T. 2013, ‘Generalizing

database forensics’, ACM Transactions on Database

Systems, Vol. 38, No. 2, paper 12.

Pissinou, N., Snodgrass, R. T., Elmasri, R., Mumick, I. S.,

Özsu, M. T., Pernici, B., Segev, A., Theodoulidis, B. &

Dayal, U. 1994, ‘Towards an Infrastructure for

Temporal Databases: Report of an Invitational

ARPA/NSF Workshop’, SIGMOD Record, Vol. 23, No.

1, pp. 35-51.

Rizzolo, F. & Vaisman, A. A. 2008, ‘Temporal XML:

modeling, indexing, and query processing’, The VLDB

Journal, Vol. 17, No. 5, pp. 1179-1212.

Samet, A. 1997, Automatic Recovery of Side Effects in a

Multi-Version Environment, Master thesis, Faculty of

Science of Tunis, Tunisia.

Skyt, J., Jensen, C. S. & Mark, L. 2003, ‘A foundation for

vacuuming temporal databases’, Data and Knowledge

Engineering, Vol. 44, No. 1, pp. 1 – 29.

Snodgrass, R. T., Dyreson, C. E., Currim, F., Currim, S. &

Joshi S. 2008, ‘Validating Quicksand: Schema

Versioning in τXSchema’, Data Knowledge and

Engineering, Vol. 65, No. 2, pp. 223-242.

Svirec, M. & Mlýnková, I. 2012, ‘Efficient Detection of

XML Integrity Constraints Violation’, Proceedings of

the 4

International Conference on Networked Digital

Technologies (NDT 2012) - Part I, Dubai, UAE, 24-26

April, pp. 259-273.

Tatarinov, I., Ives, Z. G., Halevy, A. Y. & Weld, D. S.

2001, ‘Updating XML’, Proceedings of ACM SIGMOD

Conference 2001, Santa Barbara, California, USA, , pp.

413-424.

W3C. 2011, XQuery Update Facility 1.0, W3C Candidate

Recommendation, 17 March.

<http://www.w3.org/TR/2011/REC-xquery-update-10-

20110317/>

Zellag, K. & Kemme, B. 2014, ‘Consistency anomalies in

multi-tier architectures: automatic detection and

prevention’, The VLDB Journal, Vol. 23, No. 1, pp.

147-172.

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

250
