Evolutionary Inheritance in Workflow Scheduling Algorithms within

Dynamically Changing Heterogeneous Environments

Nikolay Butakov, Denis Nasonov and Alexander Boukhanovsky

e-Science Research Institute, ITMO University, Birzhevaya liniya 4, Saint-Petersburg, Russia

Keywords: Genetic Algorithm, HEFT, Evolution, Workflow Scheduling, GAHEFT.

Abstract: State-of-the-art distributed computational environments requires increasingly flexible and efficient

workflow scheduling procedures in order to satisfy the increasing requirements of the scientific community.

In this paper, we present a novel, nature-inspired scheduling approach based on the leveraging of inherited

populations in order to increase the quality of generated planning solutions for the occurrence of system

events such as a computational resources crash or a task delay with the rescheduling phase .The proposed

approach is based on a hybrid algorithm which was described in our previous work and includes strong

points of list-based heuristics and evolutionary meta-heuristics principles. In this paper we also

experimentally show that the proposed extension of hybrid algorithms generates more effective solutions

than the basic one in dynamically heterogeneous computational changing environments.

1 INTRODUCTION

Today, scientific progress dramatically depends on

the achievements of high performance

computational (HPC) researches. One of the most

important aspects of HPC environment operability is

task-scheduling management. There are several

features which commonly have to be taken into

consideration for almost all HPC environments

during the task-planning operation, they are: (a)

distributed infrastructure peculiarities, (b)

heterogeneity of computational resources,

computational models, and storage nodes, (c) price

policies, and (d) dynamically variable system state

during run-time. Because of the fact that most

present scientific problems require complicated

complex multistep computations, the workflow

formalism is chosen as an easy-to-use and

convenient way to represent scientific tasks in the

executed HPC environments. Currently, a lot of

workflow management systems exist in the scientific

field (Xhafa et al. 2008, Yang and Xin 2008) and all

of them include task scheduling functionality. A

commonly used form of scientific workflow

representation is a directed acyclic graph (DAG). In

DAG, nodes correspond to computational tasks that

should be executed in the system and edges

correspond to data dependencies (due to data

transfers). Further information and the detailed

definition of the DAG workflow formalism can be

found in Sinnen (2007). As optimal workflow (task)

scheduling is an NP-complete problem, the scientific

community is motivated to investigate new

approaches for more efficient planning in HPC

environments.

The main criterion in workflow-scheduling

optimization that should be minimized is makespan,

i.e. overall execution time (Casanova et al.).

Moreover, during makespan optimization the

scheduling algorithms must take into account many

aspects, such as data transfer overheads,

dynamically changing workload, and the user’s

specified constraints. Data transfer overheads are

especially significant for data-intensive

computations. This may lead to situations in which

one less-powerful resource used for the execution of

two or more related tasks can overcome several

powerful separated resources because of a reduction

of data-transfer cost. Constraints which may be

required by users can include limitations on cost of

transfer and computations, deadlines (especially for

early warning systems), resource preferences, and

different priorities.

State-of-the-art distributed computational

environments increases the complexity of scheduling

algorithms by including the heterogeneous aspects

of the resources employed, such as computational

160

Butakov N., Nasonov D. and Boukhanovsky A..

Evolutionary Inheritance in Workﬂow Scheduling Algorithms within Dynamically Changing Heterogeneous Environments.

DOI: 10.5220/0005035201600168

In Proceedings of the International Conference on Evolutionary Computation Theory and Applications (ECTA-2014), pages 160-168

ISBN: 978-989-758-052-9

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

performance, network bandwidth, access policies for

different users, and installed software. Moreover,

sets of resources may change during the execution

process, i.e. some failures can occur or new

resources can be added or excluded from the

environment. Also the stochastic nature of the

computational environment makes it impossible to

predict precisely the amount of computational or

transfer time, even for a single task.

As mentioned previously, the goal of the

scheduling is to minimize makespan. In our previous

work, we identified the following requirements for

workflow scheduling(Nasonov et al. 2014): (a)

processing of dynamic workload without pausing for

rescheduling of operations, (b) consideration of extra

scheduling for incoming workflows without

changing the existing applied plan, (c) operation in a

dynamic distributed environment where resources

can be added at runtime and crashes can occur, (d)

consideration of task execution delays, (e)

processing of workflows’ priorities, and (f)

providing a better solution than traditional heuristics

can generate.

In order to satisfy these requirements,

traditionally two classes of algorithms are used. The

first class is a list-based heuristic such as HPS,

CPOP, PETS, or HEFT(Arabnejad, 2013 and

Topcuoglu, 2002). With some differences, all of

these algorithms of this class perform two main

steps: prioritize and sort all workflow tasks and then

schedule them in ‘task-by-task’ manner according to

assigned priority. The fact that speed of execution

and satisfied quality of solution can be addressed is

one of the advantages of this class.

The second class is meta-heuristics algorithms

such as GRASP, GA, PSO, and ACO (Singh, Singh,

2013). They search through all of solution space and

thus are able to generate final solutions with much

higher quality than list-based heuristics (Rahman et

al., 2013), but in contrast to the previous class they

require much more time to generate solutions with

better quality than list-based algorithms can propose

in similar situations.

The hybrid algorithm proposed in our previous

work combines the advantages of both classes but

still needs to improve convergence in order to be

able to generate better solutions in a hard-limited

time. The extended algorithm will be described in

detail later. Our goal in this work is to investigate

and demonstrate how the convergence and the

performance can be improved with a proposed

novel, nature-inspired approach based on reusing the

inherited population in subsequent runs of the

scheduling algorithm. It is inspired by the idea of

inheritance and survival of populations in the natural

environment when subject to different changes. We

have extended our previously developed hybrid

algorithm with this technique and use multiple

population in order to improve the quality of

generated solutions and to leverage possibilities for

parallelization and increased reliability of GA.

This paper is organized into the following

sections. In Section 2 a review of related works is

presented. Section 3 is concerned with a description

of GAHEFT, the new approach and its application to

the workflow scheduling problem; the multi-

population modification of GAHEFT algorithm

called MPGAHEFT, which leverages potentialities,

is presented there. Section 4 contains an

experimental study of the proposed approach and the

performance of the MPGAHEFT algorithm. In

Section 5 conclusions and future works are

discussed.

2 RELATED WORKS

By our investigations, at the present time, there is no

research that has been completed in the field of

scheduling algorithms in which was addressed the

reuse of inherited populations with an inconsistency

that was produced by some system changes, such as

computational resource fail. We made a review of

works which are the most closely related to our

work.

Rahman et al. (2013) investigated how different

topologies of workflow influence performance of

different kinds of algorithms, including list-based

and meta-heuristics. The authors proposed the idea

of a hybrid algorithm which uses GA to correct the

deadlines of single tasks before DCP-G start, than

DCP-G corrects scheduling during the execution

process; however, there has not been any

experimental study of this technique. There is no

further improvement on the runtime of the generated

solution by the meta-heuristic algorithm.

Xhafa et al. (2008) presented a modification of

cellular memetic algorithm (cMA) to deal with

rescheduling. The algorithm shows good quality of

generated solutions and short execution time that can

be considered suitable for the rescheduling

procedure. But, the proposed approach is adapted

only for batch jobs and can't be applied for

workflows. Also, the executing process pauses each

time there scheduling procedure is performed.

Liu X. et al.(2010) proposed a modification of

ant colony-based(ACO) method and use this strategy

for rescheduling under temporal violations. The

EvolutionaryInheritanceinWorkflowSchedulingAlgorithmswithinDynamicallyChangingHeterogeneousEnvironments

161

rescheduling procedure is applied only for the part

of the workflow that has been affected by the

system. The approach does not take into

consideration the entire structure of the workflow; in

some situations it may show worse performance than

rescheduling with the rest of the workflow. Also, the

rescheduling procedure is not immediate that leads

to execution process pausing. Also, ACO

rescheduling may take a prolonged period which

means significant loss of time and delays in

execution of workflows.

Jakob et al.(2013) proposed a hybrid two-stage

scheme for workflow rescheduling. But,

ideologically, it is absolutely different from the one

we use. The authors apply several simple heuristics

to form an initial population for an evolutionary

algorithm and search for the solution while the

execution process is stopped. By comparison, we

almost immediately create and apply an initial

planning solution generated by the HEFT heuristic.

Then we form several populations (a population

generated by a random heuristic, an adapted

inherited population, and a HEFT-based initial

population) to improve the proposed solution of the

remaining part of the queued-for-execution tasks in

the hard-limited time. Such approaches release us

from task-execution interruptions that can be

unacceptable in some cases of real workload: for

example, for workflows with small execution time.

In this case, very frequent interruptions due to the

rescheduling procedure may lead to resource

underutilization.

Cochran et al. also use a two-stage approach for

scheduling. The distinguishing feature of this work

is using regular GA for the first stage and then using

a final population in multi-population GA for

exploring different areas of solution space.

Compared with our approach, this work operates

only with batch jobs and does not employ

rescheduling at all. The usage procedure for the

inherited population is significantly different from

ours, since the authors do not anticipate multiple

runs caused by changing environment events, for

which inherited populations have to adapt to these

changes.

In the field of evolutionary dynamic

optimization, there are works dedicated to reusing

individuals and to population management.

Rohlfshagen and Xin (2010) investigate reusing

previously found global optima in order to acquire a

closer starting point than random populations can

provide toward the new global optimum. But the

main goal of the authors is to study how genotype

distance impacts the performance of a solution that

is applied on the set of test problems, while our goal

is to create a practical approach for solving a

discrete optimization problem in the workflow-

scheduling field. Also, the authors do not consider a

situation when the previously found optimal solution

is no longer valid, whereas our work proposes an

approach to make the solutions consistent and reused

in the next generation. The paper does not contain

any experimental study of the discrete dynamic

optimization problem.

Yang and Xin(2008) proposed an associative

memory-based scheme in order to record good

solutions in different points of the search space and

recall the values when the environment changes.

Compared to our work, the paper does not consider

preparation of invalidated previous solutions for the

next generation.

Given this analysis of prior works, there is no

existing approach that can efficient satisfy the

proposed above requirements for the rescheduling

procedure.

3 ALGORITHM SCHEME

3.1 Problem Definition

The workflow scheduling problem can be

formulated in the following way. Let us assume that

we have a workflow W(T, E) that consists of a set of

tasks T = {T

, T

, … T

} and set of dependencies

between tasks E = {<T

, T

>,…,< T

, T

>}. Each

task requires computational time to be executed.

Given the set of available computational resources R

= {R

, R

, …, R

} we build a mapping among tasks

and resources (T and R) in the form of a schedule,

where each task T

will be executed on a resource R

;

it also has a start time and includes an estimated end

time. The final mapping must accept all

dependencies of E, and execution intervals of

different tasks that are scheduled on the same

resource should not overlap each other and should

have makespan as minimal as possible. Also, there

can appear different violations such as are (a)

resource crash, (b) adding a new resource to the

system, and (c) workload changes, all of it need to

be handled by a scheduler with

rescheduling(recreating previously generated

schedule). Finally, we have a NP-complete single-

objective optimization problem.

3.2 GAHEFT Scheme

In our previous research (Arabnejad, 2013) we

ECTA2014-InternationalConferenceonEvolutionaryComputationTheoryandApplications

162

proposed a hybrid algorithm called GAHEFT which

combines, on the one hand, small execution time for

the generation of an initial suitable solution and, on

the other hand, tries to improve it with the use of a

meta-heuristic in a dynamically recalculated period

of time. The conceptual scheme of GAHEFT can be

viewed in Fig. 1.

GAHEFT consists of two main stages:

generation of the initial solution with a fast, list-

based heuristic and improving it with a more precise

meta-heuristic while the first part of the generated

schedule on the first stage is executing. The whole

procedure is the following. When rescheduling is

needed because of the generation of some event,

such as resource crash (the ‘Event received’ block in

Fig 1.), the scheduler updates information about the

state of the environment (‘Get actual state of

resources’), then it executes HEFT which generates

an initial solution (‘Run HEFT’). There are

situations when GA has been started because of a

previous event occurrence and has not reached a

sufficiently good solution at the present time; in this

case we interrupt its execution (‘Stop GA’) and run

the HEFT procedure (‘Run HEFT’).

Figure 1: GAHEFT scheme.

HEFT execution is a very cheap operation in

terms of execution time and takes almost nothing in

comparison with meta-heuristics like GA. On the

next step, the scheduler applies HEFT’s plan to

workflows execution, determines the time available

for GA performance, sets the state to unchangeable

for all the tasks which are started in the determined

time window(‘Determine period for GA execution

and fixed window’),and runs GA to improve the

schedule for the tasks out of the fixed window(‘Run

GA in background’). With the term ‘fixed window’

we mean the time interval which starts with the

resuming of interrupted workflow execution until

the point of some task finishing. It should be noted

that GA is running in the background, i.e. in parallel

with the execution of computational tasks on

resources, and every iteration it saves the best found

solution to storage(‘Periodically save data to

storage’) as it can be interrupted in the middle of the

current generation computation because of the end

of the fixed window. In this case, an appropriate

event will be generated and the algorithm will pass

by the block ‘Is it a signal to GA solution?’If a fail

occurs during execution of any fixed task in the

fixed window, GA will be interrupted and the

scheme will be started again (as explained

previously).When the final task of the fixed window

is finished, GA is stopping and the best solution is

extracted from storage (‘Get result of GA from

storage’). It will be applied if it is better than the

HEFT solution generated during the first stage. As it

was shown in our previous work, use of this hybrid

algorithm may lead to makespan improvement up to

25% in comparison to standard HEFT algorithm and

up to 10% in comparison to GA. For GA, we use

two-dimension chromosomes. The first dimension

represents computational resources where tasks of

the workflow have to be executed and the second

dimension is the order sequence of the workflow

tasks. Because of the existence of the tasks’

precedence order and transfer costs between related

tasks, it is important to have representation of a

second dimension and be able to manage it. Detailed

information about chromosome structure and other

genetic operators can be found in Yu and Buyya

(2006).

3.3 IGA

Despite all of the advantages of the proposed

GAHEFT algorithm, there remains a critical point to

provide a better solution as quickly as possible.

Since GA has only hard-limited time to find

improved solutions and may be interrupted on any

iteration when this time is expired, it must be revised

in order to increase convergence speed to deliver a

more suitable solution faster. To resolve this

problem we propose the following nature-inspired

approach. Different kinds of environmental changes

— e.g., failures of resources, task fails, adding new

resources, and excess of estimated execution or

transfer times — can be seen as disasters of different

scales like ones that occur in nature. Populations in

nature under such circumstances, and depending on

the scale of a disaster, either adapt to new conditions

and change, lose features of their individuals or get

EvolutionaryInheritanceinWorkflowSchedulingAlgorithmswithinDynamicallyChangingHeterogeneousEnvironments

163

replaced by populations of other more fit

species(Graham, 1994). An example of the first way

in nature is described in (Zimmer and Douglas,

2013),. The essence of it is the following. The

poison for defence of seeding from insects kills huge

amounts of insects, but there is some amount of the

insects that do not get enough of the poison to be

killed or which have specific genes to effectively

resist the poison. Such individuals of the population

will gain a significant edge on their fellows and

increase their proportion in the population in

subsequent generations, providing a resistance to the

poison. For the second way there is the classic

example of dinosaurs and mammals. Graham (1994)

highlights that survived dinosaurs could not find

their usual food to eat after the meteor strike because

it had been destroyed; whereas mammals could eat

insects and aquatic plants, which were relatively

intact.

So, in our case we can take the last population

from the previous run of the algorithm and try to

adapt it to new conditions. When changes are not so

dramatic— for example, we lose resources with a

relatively small number of scheduled tasks — it may

happen that a modified inherited parent is closer to

the optimal solution than the new generated ones. It

means that acceptable-by-quality solutions can be

found in several generations and provides significant

performance for algorithm execution time. In

contrast, if resource with many tasks fails, then this

procedure will serve as a randomized heuristic for

creating an initial population. Currently, we do not

consider impact of workflow structure on the

performance of this procedure and leave that to our

future works. Pseudo code of our adaptation

procedure for resource failures and our proposed

approach are shown on Fig. 2.

INPUT: storage s, finished tasks fsts , failed tasks flts, alive

nodes alns, added nodes addns, failed nodes fns.

OUTPUT: initial population for the next run.

# get the population of previous GA execution

GET inherited population ip FROM s;

FOREACH individual ind IN ip DO:

REMOVE fsts and flts FROM ind;

# handle the nodes which didn’t exist

in resource set for previous GA run

FOREACH node n IN addns DO:

ADD n to the chromosome of ind

# move left tasks from failed nodes to available nodes

FOREACH node n IN fns DO:

tasks = GET all tasks scheduled TO n

FOREACH task IN tasks DO:

K = RANDOM node FROM alns or addns;

M = RANDOM new place IN order seq of node K;

MAP task to node K IN position M;

RETURN inherited population;

Figure 2: Chromosome adaptation procedure.

Depending on the circumstances of the

environment at the moment of the failure, it may

happen that the time available for rescheduling is

enough to run GA without providing temporary

solutions. An example of such situation is illustrated

on Fig. 3. In the end of T9 task execution, the R2

resource crash has occurred and tasks T7 and T10

have to be remapped on other computational

resources as their resource is no longer available.

The algorithm has determined the duration of a fixed

window from the red line to the green line(the block

‘Determine period for GA execution and fixed

window’ in Fig. 1) that is illustrated in Fig. 3. In this

time interval no task will be finished so the

algorithm can run GA without generating a temporal

HEFT schedule.

Figure 3: Rescheduling example without HEFT.

3.4 IGAHEFT Scheme

As described earlier, adaptation can be applicable

for the GAHEFT algorithm, too. Indeed, in order to

make it possible to use the proposed procedure for

GAHEFT, we only need to account for changes

made by HEFT’s fixed window. In order to do this,

we have to remove all tasks of HEFT’s fixed

window from chromosome of each individual of the

inherited population and account for tasks which

have been scheduled by HEFT to newly added

resources. The modified adaptive procedure is

presented in Fig. 4.

INPUT: storage s, finished tasks fsts , failed tasks flts,

alive nodes alns, added nodes addns, failed nodes fns,

heft’s fixed window hw.

OUTPUT: initial population for the next run.

# get the population of previous GA execution

GET inherited population ip FROM s;

FOREACH individual ind IN ip DO:

REMOVE fsts and flts FROM ind;

REMOVE all tasks OF hw FROM ind;

SAVE info about scheduled tasks FROM hw to account it by

fitness function;

# handle the nodes which didn’t exist in resource set for previous GA run

FOREACH node n IN addns DO:

ADD n to the chromosome of ind

# move left tasks from failed nodes to available nodes

FOREACH node n IN fns DO:

tasks = GET all tasks scheduled TO n

FOREACH task IN tasks DO:

K = RANDOM node FROM alns or addns;

M = RANDOM new place IN order sequence of node

MAP task to node K IN position M;

RETURN inherited population;

Figure 4: Chromosome adaptation for GAHEFT.

ECTA2014-InternationalConferenceonEvolutionaryComputationTheoryandApplications

164

This approach is based on the following rationale. If

workload is large enough and HEFT’s fixed window

touches only a relatively small amount of tasks, then

the impact produced by HEFT may be relatively

small and adaptation of chromosomes of the

inherited population will not change it too much.

Applicability of this scheme may be higher if we

have workload consisting of several different

workflows.

3.5 MPGAHEFT Scheme

During our investigations we also tried to reduce

algorithm execution time and increase the reliability

of the scheduling process from failure of

computational resources where the scheduler is

executed. Also, Nguyen et al. (2012) highlight that

multi-populational schemes are increasing in

popularity and receiving much attention from the

scientific community of evolutionary dynamic

optimization.

Figure 5: MPGAHEFT scheme.

Firstly, we divide the whole population of GAHEFT

into three subpopulations and evaluate them

separately from each other. Using this approach

provides a possibility to parallelize GA through

several computational resources and allow the whole

evolution process to continue its running if any

failure occurs. Also, it may help to discover different

areas of searched space and make the final solution

better; i.e., it can serve the purpose of increasing an

individual’s diversity. Randomly chosen 5% of

individuals for every subpopulation migrate each 10

generations. Secondly, we made the initial

generation for every subpopulation different. The

first subpopulation is randomly initialized as it is

done in the GAHEFT algorithm. The second

subpopulation is initialized from adapted best

individuals of the inherited population. The inherited

population for every algorithm’s run is formed by

the following scheme: all final subpopulations are

collected in one, then the individuals are sorted by

decreasing fitness values and the best representatives

are taken to the new run. For the third

subpopulation, we take the solution generated by

HEFT and apply random mutations. The scheme of

the modified algorithm is presented in Fig. 5.

The scheme is almost the same as for the

regular GAHEFT case, but several blocks are added.

After the end of the first stage (‘Determine period

for GA execution and fixed window’) MPGAHEFT

gets new populations from initializers which run in

parallel and create populations in the separated

islands (‘Determine initializers’, ‘Random

initializer’, ‘Inherited population initializer’, and

‘HEFT-based initializer’). The rest of the scheme is

the same as GAHEFT's one.

4 EXPERIMENTS

In order to verify our approach, three experiments

were done for the case of resource crashing as it is

the most frequent reason of changes in such

environments. GA parameters are: population

size,50; generations count, 100; crossover

probability, 0.8; replacing mutation probability, 0.5;

sweep mutation probability, 0.4; selection,

tournament 4 individuals. We tested our algorithms

on the well-known Montage workflow (Deelman et

al., 2004) with different task counts: 35, 50, 75, 100.

For our experimental study we determine

computational cost of every task in the workflow as

a content of runtime attribute from the xml

multiplied by a constant value (20). For any two

different resources, transfer cost is a constant greater

than zero. No one task can be parallelized; it is

computed only on one computational resource at one

single moment of time. Every computational

resource has a predefined value of power in flops

unit per unit of time. For experiments, the set of

resources consists of four resources with the

following characteristics of computational power:

10, 15, 25, and 30. The specification of the computer

used for the experimental study is: Intel core 2

Q6600 2.4 GHz, 6GB RAM, Windows 7 64bit.

4.1 GA and IGA Case

In the first experiment, we compared the GA

algorithm with IGA, which uses inherited population

EvolutionaryInheritanceinWorkflowSchedulingAlgorithmswithinDynamicallyChangingHeterogeneousEnvironments

165

for initialization step. The results are presented in

the Fig.6.a. In this experiment, Montage with 100

tasks (m100) was used. Several tasks of m100 were

chosen (0, 10, 20, 40, 50, 70, 90) and failures of

random computational resources were simulated.

Every point on the presented graphs corresponds to

the average value of 100 runs.

Figure 6.a: IGA makespan improvement in comparison

with regular GA (ID 00-70).

Figure 6.b: IGA(red) and GA(green) makespans.

The graphs show that IGA has a higher

convergence rate than regular GA provides. The

results generated by IGA on the 20th iteration are

better in most cases than the same generated by

regular GA. On the other hand, solutions generated

by IGA even on the 5th–10th iteration can be

applied to the scheduling by acceptable makespan

values (see Fig.6.b). It has more than 97% of the

optimal value for the ID00 case and more than

98.5% for ID20. For the failed ID00 case, the result

of GA becomes close enough to the IGA solution

only on the 50th iteration. For the ID70 case, the

result achieves the same values only on the 90th

iteration; for the ID40,after the 30th iteration. For

failures simulated on the ID90 step, GA-generated

results are better than IGA has, but the final

difference is approximately1–2%and IGA results are

still good enough to be used. This can be explained

by the fact that, when failure occurs on the ID90,

there are only a few tasks that still should be

rescheduled and random diversity in the initial

population can produce closer solutions to the

optimal one than the population with inheritance.

The generation of initial solutions and adapting of

inherited population take small time in comparison

with the evolution process and equals approximately

50–100 ms. For example, for ID00(Fig. 6.a) it can be

seen that the performance of GA and IGA becomes

equal only approximately 18–20 s from the start.

Thus, the result gained by IGA with 25 iterations

after 8.2 s can be achieved by GA only with 60

iterations after 19.8 s .Execution time decreases with

increasing task number because of the fact that it

depends on the count of tasks that need to be

scheduled.

For an experiment with a bigger workflow

Montage with 250 tasks we used a different

configuration of computational resources: 2x10,

2x15, 2x25, and 2x30, due to the fact that a crash of

any resource in the previous configuration leads to

very dramatic changes in the schedule because of the

workflow size.

Figure 7: IGA makespan improvement in comparison with

regular GA(Montage 250).

The approach shows better performance in

comparison with regular GA (see Fig. 7).

4.2 GAHEFT and IGAHEFT Case

In the second experiment, the GAHEFT algorithm,

which uses a randomly generated initial population,

and modified GAHEFT, which takes a previously

generated population for its initialization, are

compared. The results are presented in Fig.8

For the GAHEFT algorithm, the high speed of

convergence is an important aspect. So, it is

preferred to generate as good a result as possible on

the first iterations. The experiment shows that the

results which are generated by GAHEFT with the

inherited population (IGAHEFT) on the 20th

iteration are better than the ones generated by

ECTA2014-InternationalConferenceonEvolutionaryComputationTheoryandApplications

166

GAHEFT. Also, for most cases GAHEFT could

achieve as good a result as IGAHEFT only on the

–30th iteration. GAHEFT with random initial

population generates better results for the ID00 case.

The final difference is about 5%, so the results

on this task generated by IGAHEFT are still good

enough to be used. As in the previous experiment,

for the ID90 case IGAHEFT does not outperform

GAHEFT because of the relatively small search

space, where the randomized heuristic output is

closer to the optimal one.

Figure 8: IGAHEFT makespan improvement in

comparison with regular GAHEFT(ID 00–70).

The results of makespan improvement for

IGAHEFT in most cases are worse than the ones for

GAHEFT, especially for the tasks that are closer to

the beginning of workflow execution. This can be

explained by the fact that when the failures of the

resource occur at the beginning of the workflow

there is a high possibility that many other tasks have

been scheduled on the failed resource. In contrast,

when a resource with the task from the middle of

workflow execution fails, fewer tasks need to be

moved to the other resources. In the case of

GAHEFT we have a “fixed window, which can be

dynamically or statically set. In the case of a

predefined static interval equal to 6, the results

show3.5–4 % of profit on ID 10, 20, 40, 70 against

regular GAHEFT in this limited time. Also, if the

interval is shorter, then the profit is higher.

For demonstration purposes we allowed the

evolution process to continue for 100 iterations. On

ID 50 (as well as ID 90), the difference between

IGAHEFT and GAHEFT at the point of deadline is

not sufficient. But, in the case of a dynamic “fixed

window,” when the interval depends on the

remaining part of work, it can decrease and provide

better performance in comparison with regular

GAHEFT too.

For larger workflow Montage with 250 tasks we

got better performance too (see Fig. 9).

Figure 9: IGAHEFT makespan improvement in

comparison with traditional GAHEFT(Montage 250).

4.3 Multi-populational Case

Also, we compared our multi-populational algorithm

with regular GAHEFT. We chose several tasks and

simulated failures of random resources and applied

the both algorithms to reschedule. The notation

AxB, for example 20x3, means that MPGAHEFT

uses 3 subpopulations and each one has 20

individuals whereas GAHEFT uses a single

population with 60 individuals. The simulation was

repeated 100 times for every chosen task for each

workflow and then the mean value of all obtained

results for every workflow is calculated. The

migration scheme is circular with random choice of

migrants. The results are on Fig.10. MPGAHEFT

shows improvement for all cases varying from

4.15% to 16.42%. The experiment demonstrates an

efficient growing trend with decreasing of number of

tasks in the workflow: from m100 (max=7.95%) to

m35 (max=16.42%). This can be explained by the

fact that the dimension of the solution space is

smaller for workflow with 35 tasks and it is easier to

find a better solution. The second emphasized trend

is increase of the makespan improvement with the

decrease of the count of individuals.

Figure 10: MPGAHEFT makespan improvement in

comparison with regular GAHEFT.

EvolutionaryInheritanceinWorkflowSchedulingAlgorithmswithinDynamicallyChangingHeterogeneousEnvironments

167

For the 50x3 configuration, with a total 150

individuals, the improvement ranged from 4.15% to

11.25% while for 20x3 configuration the

improvement ranged from 7.95% to 16.42%. By our

investigations, this fact is also connected with the

dimension of searching space and size of generated

populations.

5 CONCLUSION

In this paper, various hybrid algorithm schemes for

workflow scheduling in dynamically changing

distributed computational environments are

presented. They are modifications of GAHEFT

hybrid algorithm, combining the best features of a

list-based heuristic HEFT and meta-heuristic GA.

The experiments show that the new algorithms are

more effective than basic GAHEFT and can achieve

better results up to16%. The experiments show that

our nature-inspired approach based on reusing of

inherited populations may lead to speed up in

convergence and even help to generate better results.

High rate of convergence is especially required in

hard-limited time constraints, for example, in early

warning systems scenarios.

ACKNOWLEDGEMENT

This paper is supported by Russian Scientific

Foundation, grant #14-21-00137 "Supercomputer

simulation of critical phenomena in complex social

systems". The research is done in Advanced

Computing Lab (ITMO University), which is opened

in frame of 220 Decree of Russian Government,

contract #11.G34.31.0019.

REFERENCES

Arabnejad, Hamid. "List Based Task Scheduling

Algorithms on Heterogeneous Systems-An overview."

(2013)

Casanova, Henri, et al. "Heuristics for scheduling

parameter sweep applications in grid environments."

Heterogeneous Computing Workshop, 2000.(HCW

2000) Proceedings. 9th. IEEE, 2000.

Cochran, Jeffery K., Shwu-Min Horng, and John W.

Fowler. "A multi-population genetic algorithm to

solve multi-objective scheduling problems for parallel

machines." Computers & Operations Research 30.7

(2003): 1087-1102.

Deelman, Ewa, et al. "Pegasus: Mapping scientific

workflows onto the grid." Grid Computing. Springer

Berlin Heidelberg, 2004.

Graham, R.W. Dinosaurs: old bones and living animals.

Living Museum 56:35–37. 1994.

Jakob, Wilfried, et al. "Fast rescheduling of multiple

workflows to constrained heterogeneous resources

using multi-criteria memetic computing." Algorithms

6.2 (2013): 245-277.

Liu, Xiao, et al. "Handling recoverable temporal violations

in scientific workflow systems: a workflow

rescheduling based strategy." Proceedings of the 2010

10th IEEE/ACM International Conference on Cluster,

Cloud and Grid Computing. IEEE Computer Society,

2010.

Nasonov, Denis, et al. "Hybrid Evolutionary Workflow

Scheduling Algorithm for Dynamic Heterogeneous

Distributed Computational Environment."

International Joint Conference SOCO’14-CISIS’14-

ICEUTE’14. Springer International Publishing, 2014.

Nguyen, Trung Thanh, Shengxiang Yang, and Juergen

Branke. "Evolutionary dynamic optimization: A

survey of the state of the art." Swarm and

Evolutionary Computation 6 (2012): 1-24.

Rahman, Mustafizur, et al. "Adaptive workflow

scheduling for dynamic grid and cloud computing

environment." Concurrency and Computation:

Practice and Experience 25.13 (2013): 1816-1842.

Rohlfshagen, Philipp, and Xin Yao. "On the role of

modularity in evolutionary dynamic optimisation."

Evolutionary Computation (CEC), 2010 IEEE

Congress on. IEEE, 2010.

Singh L., Singh. S A Survey of Workflow Scheduling

Algorithms and Research Issues. - International

Journal of Computer Applications. –V.74, No 15. –

2013.

Sinnen, Oliver. Task scheduling for parallel systems. Vol.

60. John Wiley & Sons, 2007.– p. 108.

Topcuoglu, Haluk, Salim Hariri, and Min-you Wu.

"Performance-effective and low-complexity task

scheduling for heterogeneous computing." Parallel and

Distributed Systems, IEEE Transactions on 13.3

(2002): 260-274.

Xhafa, Fatos, et al. "Efficient batch job scheduling in grids

using cellular memetic algorithms." Metaheuristics for

Scheduling in Distributed Computing Environments.

Springer Berlin Heidelberg, 2008. 273-299.

Yang, Shengxiang, and Xin Yao. "Population-based

incremental learning with associative memory for

dynamic environments." Evolutionary Computation,

IEEE Transactions on 12.5 (2008): 542-561.

Yu, Jia, and Rajkumar Buyya. "Scheduling scientific

workflow applications with deadline and budget

constraints using genetic algorithms." Scientific

Programming 14.3 (2006): 217-230.

Zimmer Carl, and Douglas John Emlen. Evolution:

Making Sense of Life. Roberts, 2013.

ECTA2014-InternationalConferenceonEvolutionaryComputationTheoryandApplications

168
