Fostering Co-operative Behaviour Through Social Intervention

Martyn Lloyd-Kelly

, Katie Atkinson

and Trevor Bench-Capon

Institute of Psychology, Health and Society, University of Liverpool, Liverpool, U.K.

Department of Computer Science, University of Liverpool, Liverpool, U.K.

Keywords:

Co-operation, Emotion, Agents, Simulation.

Abstract:

The emergence and maintenance of co-operation in a society of agents is an important issue and some recent

research has explored the role that can be played by a functional model of emotions. For example, it has been

shown that the emotions of gratitude and anger can be used to produce co-operative behaviour in a public

goods game from agents acting solely in accordance with their current emotional state. The effectiveness of

these emotions in producing co-operation depends on the emotional volatility of the agents, which determines

the strength of these emotions required to alter behaviour. Often, however, dysfunctional relationships de-

velop, which impairs the performance of the society as a whole. In this paper we explore through a series of

computational simulations how interventions by society can be used to correct dysfunctional behaviour. The

results of our simulations show that enforcement of co-operative behaviour and education to alter emotional

characters can improve overall performance in the dysfunctional cases and that different interventions are

appropriate given different initial circumstances.

1 INTRODUCTION

Emotions such as gratitude and anger have been

shown to be key determinants of social behaviour in

humans: gratitude is an essential motivator of co-

operative and pro-social behaviour (Vohs et al., 2006;

DeSteno et al., 2010), whilst altruistic punishment

resulting from anger is another essential element in

sustaining human co-operation (Fehr and G¨achter,

2002; Hirshleifer, 1987). Several papers provide log-

ical formalisations of emotions for agent systems and

demonstrate how emotions can be computationally

modelled to play a functional and beneﬁcial role in

enabling agents to determine how to respond to en-

vironmental information (Steunebrink et al., 2007;

Adam et al., 2009).

Using computational simulation, emotions have

been used to determine responses for agents play-

ing iterated Prisoner’s Dilemma games (Bazzan and

Bordini, 2001; Lloyd-Kelly et al., 2012a; Lloyd-

Kelly et al., 2012b). The latter two papers show

how the emergent property of co-operation, achiev-

able by game theoretic behaviour in the context of

the Prisoner’s Dilemma (Axelrod, 1984), can also be

achieved using simulated emotions. Our aim in this

work is to explore the effect of emotions and differ-

ent emotional characters on fostering co-operation

through computational simulation using the iterated

Prisoner’s Dilemma as a test-bed.

Interactions between emotional agents playing it-

erated Prisoner’s Dilemma games tend to go through a

period of initial variation and then settle down to one

of four relationships: mutual co-operation, mutual

defection, symmetric turn-taking or asymmetric turn-

taking (Lloyd-Kelly et al., 2012a; Lloyd-Kelly et al.,

2012b). In symmetric turn-taking, an agent, x, co-

operates in round n while its opponent, y, defects in n.

This continues for m rounds until, in round n+ m, the

behaviour of x and y switches (in this example, y co-

operates and x defects). This continues for l rounds

before behaviour switches back on round n+ m+ l. If

m = l turn-taking is symmetric; agents co-operate and

defect for an equal number of rounds before switch-

ing, otherwise it is asymmetric; one agent defects for

more rounds before switching behaviour. Over time,

symmetric turn-taking tends to equality for the agents

involved whilst both symmetric and asymmetric turn-

taking are signiﬁcantly better than mutual defection,

from the point of view of the system. Asymmetric

turn-taking is always better than mutual defection for

the individual that defects more and is often better for

the other agent also

See table 1: defecting even once every four rounds se-

cures greater individual utility rather than mutual defection.

578

Lloyd-Kelly M., Atkinson K. and Bench-Capon T..

Fostering Co-operative Behaviour Through Social Intervention.

DOI: 10.5220/0005039505780585

In Proceedings of the 4th International Conference on Simulation and Modeling Methodologies, Technologies and Applications (SIMULTECH-2014),

pages 578-585

ISBN: 978-989-758-038-3

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Prisoner’s Dilemma pay-off matrix.

Player i

Co-op Defect

Player j

Co-op 3

, 3

, 0

Defect 0

, 5

, 1

In human society, the temptation to secure an indi-

vidual advantage through defection when mutual co-

operation exists is ubiquitous (Simpson, 2003) so, in

this paper, hope is introduced as an emotion. Whether

this emotion will lead to defection will depend on how

likely it is that hope’s effect is manifest (here repre-

sented as a probability of defection when hope is ac-

tive). Consequently, hope potentially destabilises mu-

tual co-operation and the defecting agent may gain

some advantage (which is what is hoped for) before

the relationship stabilises again.

In the context of a society playing the Prisoner’s

Dilemma, mutual co-operation is best since it pro-

motes greater aggregate scores. Turn-taking (sym-

metric or asymmetric), may also be acceptable since

the reduction of aggregate score is relatively small.

Mutual defection is, however, dysfunctional since it

scores only a third of that achieved by mutual co-

operation, and 40% of that achieved by turn-taking.

In this paper we will explore the effects of two mech-

anisms implemented by society to intervene and at-

tempt to correct dysfunctional behaviour: enforcing

co-operative behaviour and altering the emotional

characters of the agents concerned through education.

Real examples of the latter are enforced attendance at

speed awareness courses for minor speeding offences,

or more generally the inclusion of rehabilitation in

prison regimes.

The paper is structured as follows: section 2 de-

scribes how we model emotions whilst section 3 dis-

cusses the simulation environment used. Section 4

gives key results from simulations where emotional

agents are not subject to intervention or education.

Section 5 presents results of enforcing co-operative

behaviour and applying to the simulations the four ed-

ucation strategies modelled. Section 6 offers a discus-

sion of some interesting results, and section 7 presents

the main conclusions.

2 MODELLING EMOTION

The emotion modelling framework used in this paper

has been used in previous work (Lloyd-Kelly et al.,

2012a; Lloyd-Kelly et al., 2012b) and is underpinned

by the OCC model of emotion (Ortony et al., 1988).

Use of the OCC model by computer scientists for

computationally modelling emotion (Bazzan and Bor-

dini, 2001; Burghouts et al., 2003; Steunebrink et al.,

2007; Adam et al., 2009) is largelydue to its tractabil-

ity and use of concepts that are closely linked to those

used by the agent systems community. The OCC de-

ﬁnes emotions as valenced reactions by an agent to

the consequences of an event (relevant to the agent it-

self or another), an action (performed by the agent it-

self or another) or some aspect of an object in relation

to the agent’s current goals. Numeric emotion poten-

tials are increased or decreased as the agent’s goals

are impacted by the three factors mentioned. When

an agent’s emotion potential equals the emotion’s ac-

tivation threshold, the agent’s intentional behaviour is

affected. Therefore, an agent’s intentional behaviour

is determined by its current emotional state which it-

self is a product of all interactions the agent has had

with its opponent in accordance with the descriptions

of these emotions given in the OCC model.

Nine emotional characters are deﬁned in our pre-

vious work (Lloyd-Kelly et al., 2012a; Lloyd-Kelly

et al., 2012b); different emotional characters have dif-

ferent activation thresholds for emotions (see table 2).

The emotional character notation used in table 2 is

based upon the ﬁrst letter of an emotion and the ac-

tivation thresholds modelled for that emotion

. The

difference in activation thresholds for anger and grat-

itude result in degrees of tolerance and responsive-

ness: in table 2 tolerance increases down the rows and

responsiveness decreases across the columns (from

left to right). Tolerance is determined by anger’s ac-

tivation threshold and indicates the readiness of an

agent to punish (the higher the activation threshold for

anger, the slower an emotional character is to punish

and the more tolerant it is said to be). Responsive-

ness is determined by gratitude’s activation thresh-

old and indicates the readiness of an agent to reward

(the higher the activation threshold for gratitude, the

slower an emotional character is to reward and the

less responsive it is said to be). Computational simu-

lations show that high tolerance and responsiveness

promote total system scores when agents play iter-

ated Prisoner’s Dilemma games (Lloyd-Kelly et al.,

2012b). This is because a high tolerance and respon-

siveness increases the likelihood of establishing and

maintaining co-operation, even when the opponent

initially defects.

In this paper, the nine emotional characters de-

scribed in table 2 are modelled and augmented with

hope, resulting in three emotions being modelled:

anger, gratitude and hope. These emotions will be

used to explore the interaction between emotional

For example, the activation thresholds for Anger and

Gratitude in A1:G1 are both set to 1.

FosteringCo-operativeBehaviourThroughSocialIntervention

579

Table 2: Emotional character descriptions.

If defecting, #co-ops

required to co-op.

1 2 3

If co-op,

#defects

required to

defect.

1 A1:G1 A1:G2 A1:G3

2 A2:G1 A2:G2 A2:G3

3 A3:G1 A3:G2 A3:G3

Table 3: Details of emotions modelled.

Emo.

Eli.

Cond.

Act.

Thresh.

Effect

Prob.

Effect.

Anger

Opp.

defect

1/2/3 Defect 1

Gratitude

Opp.

co-op

1/2/3 Co-op 1

Hope

Mutual

co-op

3 Defect 0.4

character and societal intervention. The emotion

modelling framework used here stipulates that an

emotion must have the followingfactors deﬁned: elic-

iting conditions, potential, activation threshold, satu-

ration, effect and probability of effect (Lloyd-Kelly,

2014). These factors (excluding emotion potential

since this is variable but is initialised to 0 and satu-

ration which is always equal to the activation thresh-

old) for each emotion are given in table 3. When an

eliciting condition for an emotion is registered by an

agent, the emotion’s potential increases by 1 until its

saturation point is reached. When an emotion’s poten-

tial is greater than or equal to its activation threshold,

the emotion’s effect has a probability (0-1) of being

manifest in the agent.

Justiﬁcations for anger and gratitude’s eliciting

conditions, effects and probability of effect are pro-

vided in previous work (Lloyd-Kelly et al., 2012a;

Lloyd-Kelly et al., 2012b); eliciting conditions and

effects of hope are based upon work by Lazarus and

Snyder (Lazarus, 1999; Snyder, 2002). Lazarus states

that hope is elicited by a strong desire to be in a sit-

uation that is more favourable than the current one

and Snyder states that hope motivates agents to derive

pathways to desired goals and use agency thinking

to traverse those pathways. Therefore, hope causes

the agent to defect with some probability. We use

0.4, a mid-range value for which co-operation is more

likely. A defecting agent will obtain 5 points rather

than 3 if the opponent continues to co-operate. Algo-

rithms for anger, gratitude and hope are provided in

sections 2.1 and 2.2 for clariﬁcation. Note that emo-

tions are directed towards speciﬁc agents so an agent,

x, may be angry with its opponent, y, and not hopeful

of defecting against it whilst simultaneously grateful

to its opponent, z, and hopeful of defecting against it.

2.1 Anger and Gratitude Algorithm

1. Agent x analyses its opponent y’s behaviour in the

round just played.

(a) If y defected and x’s anger potential for y is <

x’s anger saturation value, x increases its anger

potential for y by 1.

(b) If y co-operated and x’s gratitude potential for

y is < x’s gratitude saturation value, x increases

its gratitude potential for y by 1.

2. Agent x checks anger and gratitude potentials for

(a) If x’s anger potential for y >= x’s anger activa-

tion threshold, x’s behaviour towards y is set to

defect and x’s gratitude potential for y is reset

to 0.

(b) If x’s gratitude potential for y >= x’s grati-

tude activation threshold for y, x’s behaviour

towards y is set to co-operate and x’s anger po-

tential for y is reset to 0.

< their activation thresholds, x’s behaviour to-

wards y is determined by x’s initial behaviour

setting.

2.2 Hope Algorithm

1. Agent x analyses its opponent y’s behaviour in the

round just played.

(a) If y defected, x’s hope potential for y is reset to

(b) If y co-operated, x checks own behaviour in the

round just played:

i. If x also co-operated and x’s hope potential for

y is < x’s hope saturation value, increase hope

potential for y by 1.

ii. If x defected, reset hope potential for y to 0.

2. Agent x checks hope potential towards y. If x’s

hope potential for y >= x’s hope activation thresh-

old, x randomly selects an integer, i between 1 and

10:

(a) If i <= 4, x will defect against y in the next

round.

(b) If i > 4, x will defect/co-operate with

y in the next round according to x’s

anger/gratitude/initial behaviour status.

SIMULTECH2014-4thInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

580

3 SIMULATION DETAILS

The simulation environment used is based upon that

used in previous work (Lloyd-Kelly et al., 2012a;

Lloyd-Kelly et al., 2012b): 576 agents play in con-

text of an iterated Prisoner’s Dilemma game on a vir-

tual, two-dimensional, 24 × 24, grid whose edges are

not bound. Agents remain stationary and always play

against their 8 immediate neighbours at their cardi-

nal and inter-cardinal compass points. Since there

are nine emotional characters, 576 agents ensures

that emotional characters are equally represented (64

agents of each emotional character) in mixed popu-

lation simulations. The iterated Prisoner’s Dilemma

game permits agents to evaluate events and modify

their emotional state and intentional behaviour in light

of them

. Furthermore, there are very few variables

that can inﬂuence outcomes, ensuring that any results

are relatively free from contamination by unmanaged

variables. Finally, since agents are only capable of ei-

ther co-operating or defecting, this facilitates a deter-

mination of emotions to be modelled along with their

eliciting conditions and effects.

The pay-off distribution for the standard Pris-

oner’s Dilemma formalisation (see table 1) is used.

The number of agents whose initial behaviour is set

to co-operate/defect for each scenario run is kept con-

sistently equal (288) and the location of agents within

the simulation environment is randomised to ensure

no experimenter bias with respect to spatial distri-

bution of emotional characters or initial behaviour

which could skew results.

In section 1, we mentioned that agents will be sub-

ject to intervention from society through behaviour

enforcement or education; table 4 indicates which

simulations use behaviour enforcement and educa-

tion strategies. Behaviour enforcement occurs when

an agent and its opponent have mutually defected 3

times consecutively and immediately results in the re-

establishment of mutual co-operation and all emotion

potentials being reset to 0 for these agents. We chose

3 mutual defections as a condition for behaviour en-

forcement since none of the emotional characters im-

plemented are capable of re-establishing co-operation

with an opponent after 3 mutual-defections by virtue

of their emotional character. If education is used, the

agent’s anger or gratitude threshold is additionally in-

cremented or decremented by 1

. With our emotional

characters there are four possible education strategies:

This is obviously not possible using the “one-shot”

variation of the game.

Agents will only have their anger/gratitude thresholds

decremented until they equal 1; the minimum value for

these thresholds.

Table 4: Emotions, behavioural enforcement and education

strategy used in each simulation type.

Sim. Type Emotions Behv. Enf. Edu. Str.

1 A, G - -

2 A, G, H - -

3 A, G, H X -

4 A, G, H X 1

5 A, G, H X 2

6 A, G, H X 3

7 A, G, H X 4

1. Increase tolerance. Add 1 to an agent’s anger

activation threshold. This can be seen as anger

management since the agent will not punish others

so quickly.

2. Decrease responsiveness. Add 1 to the agent’s

gratitude activation threshold. This represents a

form of assertiveness training where the agent is

less likely to be misled by co-operative behaviour

and is made more ready to insist on its rights.

3. Decrease tolerance. Subtract 1 from an agent’s

anger activation threshold. This can be seen as

another form of assertiveness training, in which

defections are more likely to be punished.

4. Increase responsiveness. Subtract 1 from the

agent’s gratitude activation threshold. This is

analogous to increasing empathy and altruism, so

that an agent is less suspicious of others and read-

ier to respond to co-operation.

In total, 140 simulations were run; 70 for 500

rounds and 70 for 1000 rounds. Longer round-limits

were used to ascertain the effects of education and in-

tervention over longer periods of time. In this paper

we will discuss the 500 round simulations in detail

and comment on the effects of additional rounds in

section 6. Each half of the 140 simulations consists

of 7 simulation types which prescribe the emotions

and intervention used. A succinct description of these

simulation types can be found in table 4. For each

simulation type, 10 emotional character populations

were used: 1-9 are initially composed of a single emo-

tional character whilst population 10 is composed of

an equal mix of all emotional characters. Note that

initial behaviour setting for population 10 is not de-

cided at the level of emotional characters but rather at

the level of the population.

When the round limit is reached, the simulation

environment is completely reset (including all vari-

ables for all agents) and the total system score (the

sum of every agent’s ﬁnal score in the population) is

recorded with the number of interventions that have

occurred (if any).

FosteringCo-operativeBehaviourThroughSocialIntervention

581

Table 5: Total system scores for emotional character popu-

lations when hope is/is not modelled and loss incurred when

hope is introduced.

Ch. No Hope Hope Loss

A1:G1 5193000 4426616 766384

A1:G2 3463444 2316024 1147420

A1:G3 3437522 2316018 1121504

A2:G1 5744862 4709929 1034933

A2:G2 5196000 4517117 678883

A2:G3 3462912 2333223 1129689

A3:G1 5760846 4613945 1146901

A3:G2 5771668 4634982 1136686

A3:G3 5186000 4540339 645661

Mixed

4630504 2928854 1701650

4 WITHOUT INTERVENTION

Table 5 shows the total score for all 10 populations

without behaviour enforcement or education. The

emotional characters can be divided into two broad

groups: one (A1:G2, A1:G3 and A2:G3) contains

those that are quicker to punish than to respond to co-

operation (and which perform relatively badly) and

the other is composed of the remaining emotional

characters from table 2 that are at least as ready to

respond as to punish (and which perform relatively

well). A mixed population performs somewhere be-

tween these two groups. Table 5 also shows how the

introduction of opportunistic defection due to hope

signiﬁcantly decreases total system scores. Emo-

tional characters that performed worse initially suffer

more than the better performing emotional characters.

Those which are equally ready to punish and to re-

spond (A1:G1, A2:G2 and A3:G3) suffer least. The

mixed group suffers worst of all.

5 WITH INTERVENTION

As mentioned in section 1, the simulations will set-

tle down into mutual defection, turn-taking (whether

symmetric or asymmetric), or periods of mutual co-

operation (which break down when an agent suc-

cumbs to the temptation to defect due to hope). From

the viewpoint of society as whole, mutual defection

is highly detrimental to the system score and should

be avoided. Therefore in this section we will explore

the effects of intervention, described in section 3, de-

signed to prevent mutual defection.

5.1 Enforcing Behaviour

Table 6 shows the effect of enforcing mutual co-

operation following 3 rounds of mutual defection on

Table 6: Total system scores for hopeful emotional charac-

ter populations when behaviour enforcement occurs without

education.

Ch. Score Gain # Int. Gain per. Int.

A1:G1 5746674 1320058 2560 515.65

A1:G2 4297626 1981602 292636 6.77

A1:G3 4298293 1982275 292574 6.78

A2:G1 5487839 777910 1134 685.99

A2:G2 5739134 1222017 3126 390.92

A2:G3 4919034 2585811 138944 18.61

A3:G1 5387322 773377 1132 683.20

A3:G2 5415490 780508 1156 675.18

A3:G3 5731018 1190679 2826 421.33

Mixed

5106992 2178138 99502 21.89

the populations of table 5, giving the total score, the

gain in total score achieved by each population when

its total score is compared to the total score achieved

by the same population when intervention does not

occur and hope is present in the population (see table

5), the number of interventionsmade, and the gain per

intervention.

From the results shown in table 6, we can see sev-

eral points of interest. In all cases the intervention

does much to remedy hope’s effect. Indeed, except

for the emotional characters which are more respon-

sive than tolerant (A2:G1, A3:G1 and A3:G2), inter-

vention improves the system score compared with the

situation where hope is not present. The number of

interventions required, however, varies substantially,

with the dysfunctional emotional characters (A1:G2,

A1:G3 and A2:G3) requiring a very large number

of interventions, as they frequently return to mutual

defection. The mixed population also requires very

frequent intervention. It is the emotional characters

which are more responsive than tolerant that require

fewest interventions. Thus the gain per intervention

is very small for emotional characters A1:G2, A1:G3

and A2:G3, and rather small for the mixed popula-

tion: in these cases the gains may well not justify the

cost of intervention. Other emotionalcharacters attain

substantial gains per intervention, especially A2:G1,

A3:G1 and A3:G2, for which the smaller number of

interventions means that the value for money is great-

est for these emotional characters.

The improved score should exceed the cost of in-

terventions, and so we can establish a maximum inter-

vention cost

from the ﬁnal column of table 6: if the

A1:G1 population expects to gain 515.65 per inter-

vention then interventions should not cost more than

this. Although intervention to enforce co-operation

The maximum cost that can be paid to intervene with-

out the total system score incurring a loss as a result.

SIMULTECH2014-4thInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

582

Table 7: Total system scores for hopeful emotional charac-

ter populations with behaviour enforcement and education

strategy 1 (anger management).

Ch. Score Gain

Int.

Gain

per.

Int.

Edu.

Gain

A1:G1 5291340 864724 1134 762.54 -455334

A1:G2 5281348 2965324 3416 868.07 983722

A1:G3 5281345 2965327 3416 868.07 983052

A2:G1 5290610 580681 1160 500.59 -197229

A2:G2 5290353 773236 1134 681.87 -448781

A2:G3

5292018 2958795 1162 2546.30 372984

A3:G1

5288354 674409 1106 609.77 -98968

A3:G2

5290109 655127 1150 569.68 -125381

A3:G3

5290230 749891 1176 637.66 -440788

Mixed

5288846 2359992 1686 1399.76 181854

will improve the aggregate system scores, mutual de-

fection will still develop as the enforced co-operation

breaks down in the face of temptation. We assume

that the resources to supervise every move are not

available: the intervention should encourage agents

to work together in a productive relationship.

5.2 Education

As argued in section 5.1, enforcing co-operation will

not prevent mutual defection from developing. We

now explore the use of education to alter emotional

character, in the hope that this will reduce the recur-

rence of mutual defection.

Tables 7-10 show the results of the four different

educational strategies on the various populations, to-

gether with the number of interventions and the aver-

age gain per intervention. The gain from education,

rather than simply enforcing co-operation of dysfunc-

tional pairs is also shown.

Table 7 shows that education strategy 1 has a dra-

matic effect on the number of interventions, so that all

initial emotional characters now have an acceptable

number of interventions, although emotional charac-

ters A1:G2 and A1:G3 require more than the rest.

The gain per intervention is now uniformly good, and

spectacular in the case of emotional character A2:G3.

The mixed population also beneﬁts considerably, es-

pecially from the dramatically reduced number of in-

terventions, so that the gain per intervention is second

only to emotion character A2:G3.

This education strategy is, however, not beneﬁ-

cial in terms of system score for emotional characters

A1:G1, A2:G1, A2:G2, A3:G1, A3:G2 and A3:G3.

Moreover, while education does have value for emo-

tional characters A1:G1, A2:G2 and A3:G3, for those

that required fewest interventions without education,

Table 8: Total system scores for hopeful emotional charac-

ter populations with behaviour enforcement and education

strategy 2 (assertiveness training 1).

Ch.

Score Gain # Int.

Gain

per.

Int.

Edu.

Gain

A1:G1

4298740 -127876 292326 -0.44 -1447934

A1:G2

4296902 1980878 292720 6.77 -724

A1:G3

4297804 1981786 292649 6.77 -489

A2:G1

4714455 4526 196271 0.02 -773384

A2:G2

4708261 191144 197526 0.97 -1030873

A2:G3

4709001 2375778 197385 12.04 -210033

A3:G1

4885127 271182 150845 1.80 -502195

A3:G2 4878522 243540 152240 1.60 -536968

A3:G3 4879912 339573 152166 2.23 -851106

Mixed 4646843 1717989 211521 8.12 -460149

Table 9: Total system scores for hopeful emotional charac-

ter populations with behaviour enforcement and education

strategy 3 (assertiveness training 2).

Ch.

Score Gain # Int.

Gain

per.

Int.

Edu.

Gain

A1:G1

5747270 1320654 2443 540.59 596

A1:G2

4297206 1981182 292608 6.77 -420

A1:G3

4296484 1980466 292710 6.77 -1809

A2:G1

5738050 1028121 4022 255.62 250211

A2:G2 4298235 -218882 292267 -0.75 -1440899

A2:G3 4300303 1967080 292297 6.73 -618731

A3:G1 5739073 1125128 3843 292.77 351751

A3:G2 4301740 -333242 291950 -1.14 -1113750

A3:G3 4296964 -243375 292458 -0.83 -1434054

Mixed 4472148 1543294 257417 6.00 -634844

the emotional characters which are initially more re-

sponsive than tolerant, the gain per intervention is re-

duced, so that for these emotional characters this form

of education is not worthwhile.

From table 8 we see that the effects of educa-

tion strategy 2, which is designed to reduce respon-

siveness, is in complete contrast to education strat-

egy 1. In no case is education strategy 2 beneﬁcial

when compared with enforcing co-operation, and al-

though there are gains from intervention for all emo-

tional characters (except A1:G1), the number of in-

terventions required as a result of applying education

strategy 2 is considerably less value for money com-

pared to when behaviour enforcement is the sole in-

tervention used.

Table 9 gives a similar picture to table 8. Charac-

ters A1:G1, A2:G1 and A3:G1 do show some gains

from education, but these are small, and are out-

weighed by the increased number of interventions re-

quired. Therefore education strategy 3 is not recom-

mended, unless the desire to maximise overall sys-

FosteringCo-operativeBehaviourThroughSocialIntervention

583

Table 10: Total system scores for hopeful emotional charac-

ter populations with behaviour enforcement and education

strategy 4 (increase empathy/altruism).

Ch.

Score Gain

Int.

Gain

per.

Int.

Edu.

Gain

A1:G1

5746418 1319802 2608 506.06 -256

A1:G2

5728120 3412096 6256 545.41 1430494

A1:G3

5728255 3412237 6243 546.57 1429962

A2:G1

5487031 777102 1144 679.28 -808

A2:G2

5490113 972996 1126 864.12 -249021

A2:G3

5488354 3155131 1486 2123.24 569320

A3:G1

5389241 775296 1170 662.65 1919

A3:G2 5388275 753293 1138 661.94 -27215

A3:G3 5389058 848719 1287 659.46 -341960

Mixed 5477148 2548294 8319 306.32 370156

tem score is paramount and overrides value for money

considerations, in which case it may be useful for

emotional characters A1:G1, A2:G1 and A3:G1.

Finally, from table 10, we can see that education

strategy 4 offers considerable advantages for the most

dysfunctional emotional characters: A1:G2, A1:G3

and A2:G3, and for the mixed population. Again the

number of interventions is signiﬁcantly reduced, al-

though not by as much as education strategy 1, which

increases tolerance (as shown in table 7).

From these results we can see that the education

strategies that are likely to have a beneﬁcial impact

are those which increase tolerance or responsiveness

i.e. strategies 1 and 4.

6 DISCUSSION

From tables 7-10 we can derive the summary shown

in table 11, which shows for each emotional character

the best intervention strategy in terms of total score

and gain per intervention. For three emotion charac-

ters: A2:G2, A3:G2 and A3:G3, there are no gains

from education either in terms of overall score or in

terms of gains per intervention. In other cases, in-

creasing tolerance (education strategy 1) tends to of-

fer the best value for money by reducing the number

of interventions required, whereas increasing respon-

siveness (education strategy 4) offers the best system

scores since this increases the likelihood of develop-

ing mutual co-operation. Of course, it is this very in-

crease in mutual co-operation which sets the scene for

a unilateral defection that can result in the need for in-

tervention.

The results presented so far relate to a simulation

of 500 rounds. In broad terms the conclusions were

not affected when 1000 rounds were played: the sum-

Table 11: Results summary.

Ch.

Best

Edu.

Str. for

Score

Edu.

Gain

Best

Edu.

Str. for

Value

Gain per.

Int.

A1:G1

3 596 1 762.54

A1:G2

4 1430494 1 868.07

A1:G3

4 1429962 1 868.07

A2:G1

3 250211 - 685.99

A2:G2

- - 390.92

A2:G3

4 569320 1 2546.29

A3:G1

3 569320 - 683.20

A3:G2 - - 675.18

A3:G3 - 4 659.46

Mixed 4 370156 1 1399.76

mary given in table 11 also applies to the longer ver-

sions. Where there is a signiﬁcant impact is on the

gain per intervention: for homogeneous populations

these approximately double as the number of rounds

double (increases between 48% for emotional charac-

ter A2:G2 and 55% for emotional character A3:G3).

From this we can say that, the longer the period of

concern, the more worthwhile it is to try to improve

emotional characters of agents. Increased responsive-

ness for the mixed population was something of an

exception giving an increase in gain per intervention

of only 23% compared with the 53% increase in gain

per intervention for increased tolerance.

Whilst the ideal from society’s point of view is

mutual co-operation, this will inevitably lead to in-

tervention so turn-taking, which is maintenance free,

may be an acceptable alternative. Consequently, the

most cost-effective education strategies may be those

that produce emotional characters that form symmet-

ric and asymmetric turn-taking interactions with oth-

ers. Society’s acceptance of turn-taking is likely to

increase as simulation length and the likelihood of

hopeful defection increase.

7 CONCLUSIONS

What we have attempted to show through these simu-

lations is that the emergence of a successful society, in

terms of co-operation amongst its members, is highly

dependent on the members’ emotional characteristics.

Thus while the emotions of anger and gratitude can

assist the emergence of co-operation, if the thresholds

of activation are not well set, the desired effects do

not emerge and the agents become locked in an un-

breakable sequence of mutual defection. In such cir-

cumstances a society may need to intervene to correct

SIMULTECH2014-4thInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

584

this detrimental behaviour. The need becomes even

more pressing when there are forces working against

the development of co-operative relations, here repre-

sented by the emotion of hope and the temptation to

defect to which it gives rise.

In many cases, however, simply correcting un-

wanted behaviour is not enough: action is also re-

quired to try to prevent recurrence of the unwanted

behaviour. Often, there are several ways in which the

emotional characteristics of agents can be changed to

achieve this; the strategy selected, however, may de-

pend on the aims and emotional characters concerned.

Here we have seen that the interventions that provide

the best value in terms of gains per intervention do

not necessarily lead to the best overall system score.

Moreover, the nature of the changes, or even whether

changes are worthwhile, will depend on the emotional

characteristics of the initial population. In homoge-

neous populations it will be possible to tailor the ed-

ucation to the population, but in a mixed population

this may not be possible.

Of course, what we have reported here applies to a

single simulation environment with single parameters

for aspects such as the likelihood of defection once

hope is activated; changing these parameters may sig-

niﬁcantly affect the results. However, we believe that,

as with increasing the length of the simulations, the

effects are likely to be quantitative rather than qual-

itative. Thus we would expect that the greater the

chance of defection once hope is activated, the more

essential it will be to change the emotional character

of the most dysfunctional agents to keep the number

of interventions reasonable; if the probability of de-

fection is small, this becomes less important. Further

simulations will be run to conﬁrm these conjectures.

Whilst simulating a society of agents is a good

way of investigating the emergence of co-operation,

in practice, societies do not allow agents to act as they

choose. Societies have a vision for what they deem to

be desirable behaviour and will actively intervene to

impose upon or persuade their members to adopt - or

at least conform to - this desirable behaviour. We be-

lieve that it is therefore important that such interven-

tions are themselves modelled, so that the interaction

of agents within a society can be better understood.

REFERENCES

Adam, C., Herzig, A., and Longin, D. (2009). A logi-

cal formalization of the OCC theory of emotions.

Synthese, 168(2):201–248.

Axelrod, R. (1984). The Evolution Of Cooperation.

Basic Books, Inc.

Bazzan, A. L. C. and Bordini, R. H. (2001). A frame-

work for the simulation of agents with emotions:

Report on experiments with the Iterated Pris-

oner’s Dilemma. In Proceedings of the 5th In-

ternational Conference on Autonomous Agents.

Burghouts, G. J., Heylen, D., Poel, M., Akker, R.

O. D., and Nijholt, A. (2003). An action se-

lection architecture for an emotional agent. In

Recent Advances in Artiﬁcial Intelligence, pages

293–297. Menlo Park: AAAI Press.

DeSteno, D., Bartlett, M. Y., Baumann, J., Williams,

L. A., and Dickens, L. (2010). Gratitude as

moral sentiment: Emotion-guided cooperation

in economic exchange. Emotion, 10(2):289–293.

Fehr, E. and G¨achter, S. (2002). Altruistic punishment

in humans. Nature, 415:137–140.

Hirshleifer, J. (1987). The Latest on the Best:

Essays in Evolution and Optimality, chapter

On the Emotions as Guarantors of Threats and

Promises, pages 307–326. MIT Press.

Lazarus, R. S. (1999). Hope: An emotion and a vi-

tal coping resource against despair. Social Re-

search, 66(2):653–678.

Lloyd-Kelly, M. (2014). Modelling Emotions and

Simulating their Effects on Social Interactions in

Agent Systems. PhD thesis, University of Liver-

pool.

Lloyd-Kelly, M., Atkinson, K., and Bench-Capon, T.

(2012a). Developing co-operation through simu-

lated emotional behaviour. In 13th International

Workshop on Multi-Agent Based Simulation.

Lloyd-Kelly, M., Atkinson, K., and Bench-Capon, T.

(2012b). Emotion as an enabler of co-operation.

In Proceedings of the 4th International Confer-

ence on Agents and Artiﬁcial Intelligence, pages

164–169.

Ortony, A., Clore, G. L., and Collins, A. (1988).

The Cognitive Structure of Emotions. Cambridge

University Press.

Simpson, B. (2003). Sex, fear, and greed: A social

dilemma analysis of gender and cooperation. So-

cial Forces, 82(1):35–52.

Snyder, C. R. (2002). Hope theory: Rainbows in the

mind. Psychological Inquiry, 13(4):249–275.

Steunebrink, B. R., Dastani, M., and Meyer, J.-J. C.

(2007). A logic of emotions for intelligent

agents. In 22nd Conference on Artiﬁcial Intel-

ligence, pages 142–147. AAAI Press.

Vohs, K. D., Mead, N. L., and Goode, M. R. (2006).

The psychological consequences of money. Sci-

ence, 314:1154–1156.

FosteringCo-operativeBehaviourThroughSocialIntervention

585
