Applying Design Principles for Enhancing Enterprise System
Usability
Tamara Babaian, Jennifer Xu and Wendy Lucas
Department of Computer Information Systems, Bentley University, Waltham, MA 02452, U.S.A.
Keywords: ERP Usability, Human-Computer Interaction, Design Principles, Process Visualization, Tutorial Systems.
Abstract: Experienced users learn the “tricks of the trade” that allow them to make effective and efficient use of
enterprise systems. New users and even experienced ones accessing unfamiliar parts of the system,
however, are stymied by the lack of navigational cues, the ubiquity of tabbed pages, and the sheer number
of fields that may be required. In earlier work, we documented the usability issues users are facing in the
field, derived four design principles for guiding the design of systems that collaborate with their users, and
implemented a database framework for supporting those principles. In this paper, we present two
interventions targeted at the design principle that calls for providing navigational and progress guidance,
while supporting the principle requiring that the system make use of contextual information in presenting
data and choices to the user. Using visualizations in conjunction with a playback mechanism, users can
learn about system-supported processes, find detailed information on the particular process instances on
which they are working, and view automated playbacks of users completing the same and other types of
tasks. This paper is the next step in designing enterprise systems that help, rather than hinder, their human
partners by sharing their knowledge.
1 INTRODUCTION
How to get started, what to do next, what came
before, and where does my work fit in to the wider
business context are some of the questions users of
Enterprise Resource Planning (ERP) systems ask
themselves time and again. Novice and experienced
users alike are often stymied by the lack of
navigational cues, missing indicators of required
versus optional steps, and the opacity surrounding
how the system’s imposed implementation of tasks
relates to the underlying business processes.
These hurdles are much more than a distraction,
with serious repercussions for the bottom line.
Industry reports attribute the inability of ERP
systems to achieve their full potential on their poor
usability characteristics, which negatively impact
adoption rates and end-user productivity (Matthews,
2008; Iansiti, 2007). While advances stemming from
the increasing use of service-oriented architectures
(SOAs) offer the potential for more improvements in
usability, as it is easier for ERP vendors to apply
changes, the coupling of diverse components may
also lead to additional usability issues related to
navigation and redundant functionality (Matthews,
2008). Similarly, more flexibility in ERP systems
has been achieved via cloud-based applications that
use a software as a service (SaaS) delivery model.
Implementations using this approach, too, have yet
to solve the inherent usability issues of ERP systems
(Ganly and Montgomery, 2013), which remain a
significant source of angst to users and their
employers.
Field studies we undertook as part of a
comprehensive project for improving the usability of
ERP systems (Topi et al, 2006; Babaian et al., 2010)
revealed several sources of confusion and frustration
experienced by users across the board. Issues
frequently cited in our own and the work of others
include difficulties with navigation, overly complex
interfaces, and hard-to-understand error messages
(Singh and Wesson, 2009; Calisir and Calisir, 2004;
Lambeck et al., 2014).
The issues we identified were first analyzed in
light of the human-computer collaboration
paradigm, which holds that the system must support
its users in the increasingly complex environments
of modern applications (Grosz, 2005). We then
systematically categorized those issues on the basis
of non-collaborative behaviors between the system
162
Babaian T., Xu J. and Lucas W..
Applying Design Principles for Enhancing Enterprise System Usability.
DOI: 10.5220/0005099001620169
In Proceedings of the 9th International Conference on Software Engineering and Applications (ICSOFT-EA-2014), pages 162-169
ISBN: 978-989-758-036-9
Copyright
c
2014 SCITEPRESS (Science and Technology Publications, Lda.)
and its users. From these categorizations, we derived
four principles for guiding the design of enterprise
systems that act as users’ collaborative partners
(Babaian et al., 2010).
In this paper, we present two novel interactive
user interface components specially designed to
address one of our design principles, which concerns
the need for providing navigational and progress
guidance in light of the business and user contexts of
each interaction. The first component presents the
user with interactive visualizations of the current
business process being performed. The second
component allows users to view on-demand,
automated demonstrations of how to execute the
current task or any other task that has been
previously performed with the system. The two user
interface features are integrated within a single ERP
prototype in a way that conforms to another design
principle, which requires that the system uses its
knowledge of the context of the current interaction
in presenting choices and data to the user.
These two design interventions address many of
the concerns we heard most frequently from users in
our field studies. Providing access to process-based
visualizations and automated playback of tasks
improves the users’ understanding of the flow of
information between tasks, task composition into
processes, the users' performing those tasks, and
other details.
In order for a system to provide user access to
such information, it needs to be able to store and
retrieve data on the tasks it supports, task
composition into processes, task interfaces, and the
histories of system-user interactions. A database
framework consisting of a Task-Interface-Log (TIL)
data model and algorithms for deriving process-
related data provides the needed functionality and
underlies the implementations described here (Lucas
and Babaian, 2012; Babaian and Lucas, 2013a).
We have previously reported on earlier versions
of the individual components of the work presented
here (Babaian and Lucas, 2013b, Lucas et al., 2013).
The contribution of this paper is in
presenting a prototype that incorporates
enhanced versions of the Interactive Process
Visualization and Automated Playback
features for on-going, continuous support of
ERP users,
explaining how these components and their
integration within the prototype implement the
design principles for achieving better ERP
usability.
In the next section of the paper, we introduce the
four design principles for improving the usability of
ERP systems. Section 3 presents our design
interventions implemented in an ERP prototype, and
provides an overview of the TIL model, which
makes those implementations possible. Related work
is presented in Section 4, followed by conclusions
and directions for future research in Section 5.
2 DESIGN PRINCIPLES
In the process of identifying usability issues with
ERP systems, we interviewed and observed 33
enterprise system users in three organizations. The
human-computer collaboration paradigm (Terveen,
1995) provided a unifying perspective for analyzing
the usability issues and grouping them based on their
underlying causes. The outcome of this evaluation
was the four design principles shown in Figure 1.
The “transactions” that are mentioned in these
principles are typically referred to as “tasks”
throughout this paper.
Design Principle 1 focuses on aligning the way
information is presented to users with the internal
conception users have developed based on
organizational practices. Even experienced users
often maintain lists of system terms side by side with
the terms used in practice. The extensive and
prolonged training typically required before
employees can put ERP systems to use in their work
is necessitated in large part by generic interfaces
overflowing with components bearing
unrecognizable labels, many of which are irrelevant
to the user. Customizations addressing these issues
are lost with system upgrades: hence the requirement
for a means for incorporating earlier customizations.
Design Principle 2’s call for navigational aids
also addresses system learnability and the need for
users to be able to recognize what to do. The deep
menu structure of many ERP systems makes it
virtually impossible for users to find the necessary
transaction without either referring to detailed
documentation they and their colleagues maintain or
memorizing transaction codes. In addition, ERP
interfaces often hide the underlying workflow from
the user, including where the user is in the current
process, what has been accomplished, and what
steps remain. This can lead users to think they have
completed a process when in fact that is not the case,
leading to significant logistical problems down the
road. Progress guidance is therefore another
essential element for improving usability.
ApplyingDesignPrinciplesforEnhancingEnterpriseSystemUsability
163
1. The user interface should provide a mechanism for customizing the vocabulary of terms used by the system in its
communication to the user, the composition of business transactions, and the content of the system's informational
output to match the practices of the organization. There should be a mechanism for incorporating the customizations
from an earlier version of the system to a later one.
2. The system should provide navigational and progress guidance to a user performing a transaction, indicating the
broader context of each interaction in terms of the related business process components and specifying the completed
and remaining parts. A sufficiently competent user should be able to turn off this guidance if it becomes a distraction.
3. When the system detects a problem, it should identify the possible causes and ways of resolving it. If the fix is
obvious, the system should inform the user and perform it. If it isn't obvious, the possible causes and resolution
scenarios should be presented to the user and be readily executable. If the system is unable to identify resolution
strategies, it should present the user with the relevant data and transactions.
4. In presenting selection choices, the system should utilize what it knows about the user, the organization, the task, and
the context, and provide faster access to the more likely choices than the less likely ones. Where the choice of data or
action is obvious, the system should have an option of not waiting for the user to enact it. The user should have an
option to replace/cancel the system's provided choice of data/action.
Figure 1: Design principles for collaborative ERP systems.
Design Principle 3 deals with error situations,
which can stymy even the most sophisticated of
users. Oftentimes the error message fails to identify
the cause of the error, much less presents strategies
for resolving it, even when the system has access to
the pertinent information. For significant errors,
users often need to turn for help to a colleague with
the appropriate expertise, adversely affecting the
productivity of both parties.
Lastly, Design Principle 4 calls on the system to
utilize all the information it has access to in
presenting options and data to the user. In
conducting a search, for example, a large, unfiltered
list is often displayed rather than a selection that has
been filtered based on the information entered in
other fields. Adhering to this design principle would
save time for the user and lessen the frustration that
arises from having to specify obvious information.
The design interventions presented in this paper
were driven by the requirements of Design Principle
2 while also supporting Design Principle 4, as
described in the next section.
3 PROVIDING NAVIGATIONAL
AND PROGRESS GUIDANCE
ERP systems provide modules and functions to
enable and facilitate a large number of business
processes used in modern organizations. Many of
these business processes are complex, involving
multiple paths, tasks, data objects, users, business
units, etc. Each task may also require multiple pages
or forms, which contain many fields, tables, menu
options, and tabs.
One consequence of the complexity of these
systems is that they cannot be put to successful use
without extensive training, as reported in ERP
studies (e.g., Scott, 2005) and noted frequently in
our previously mentioned field studies. Even after
training, users typically consult their colleagues
when learning to operate an ERP interface for an
unfamiliar task. In addition, they often create notes
to help themselves and their coworkers learn details
of how to perform tasks within the system (Topi,
Lucas, and Babaian, 2006). These notes come in
various forms, including flowcharts, step sequences,
and annotated sequences of screenshots. They are
remarkably well maintained (some are even
laminated) in order to withstand heavy usage.
A time- and resource-saving alternative is for the
system to provide intuitive, interactive, and context-
sensitive navigational support and guidance that help
users perform their tasks effectively and efficiently.
Although system help menus and high-level process
definitions (e.g., SAP’s Business Blueprint) may
exist, they are not usually interactive and do not
alleviate the cognitive burden associated with
learning to perform tasks and navigate through
processes (Hipp, Mutschler, and Reichert, 2012).
The goal of the design interventions described next
is to provide this crucially needed support and
guidance.
3.1 Interactive Process and Instance
Visualizations
The visualization component in our ERP prototype
was implemented based on Design Principle 2,
which is intended to help ERP users navigate
through tasks involved in a business process. The
behavior of this component also adheres to Design
ICSOFT-EA2014-9thInternationalConferenceonSoftwareEngineeringandApplications
164
Principle 4 by presenting visualizations that take
into account the context of the interaction without
requiring the user to specify the obvious process and
process instances of interest.
A business process is rendered as an interactive,
clickable graph, which consists of two types of
objects: nodes and links. Each node represents a task
or a task instance (an execution of a specific task);
and each link represents a data flow from one node
to another. We distinguish between two types of
graphs: a process graph and a process instance
graph.
A process graph specifies what tasks are
included in a business process and how data flow
through those tasks. Processes in commercial ERP
systems are usually predefined by system vendors or
configured and customized by adopting
organizations. A process definition reflects how an
organization believes a process should typically be
carried out. Processes supported by our prototype
are also pre-specified in the TIL model as a
composition of tasks that can be configured to match
the practices of the organization, in accordance with
Design Principle 1. Process graphs are derived from
these static representations of processes within the
TIL model, which maintains data on the tasks (e.g.,
IDs, names, descriptions, and output document
types) and process structures (e.g., component tasks
and data flow links).
A process instance graph represents a specific
execution of a process corresponding to a set of task
instances. Process instance graphs are dynamically
constructed, based on the system’s usage logs in the
TIL model, by tracing the input/output chains
backward from the current task instance to the
starting instance.
A user can interact with a process or process
instance graph by clicking on an object (node or
link) to view its details. Through interactions with
the visualized graph, a user can learn important
contextual information about:
how tasks are formed into a process (e.g., what
has been done and what comes next),
how documents flow between tasks,
how a specific process instance is executed,
users involved in a process instance, and
task-specific information (e.g., pages to be
filled out and the completion status of a task).
Henceforth, we will use material purchasing as
the exemplar process to illustrate how the
visualization component in our prototype
implements Design Principle 2 while following
Design Principle 4 in providing navigational support
and guidance without users having to request it.
Figure 2 presents our prototype’s typical
interface, which is divided into two sides. The left-
hand side is for selecting a task and entering
parameters for performing it. The right-hand pane is
for visualizing the process and instance graphs
underlying the task. This pane can be detached and
minimized for users who do not wish to use it.
Figure 2: The system interface.
In this figure, the Enter Header and Defaults
page is shown after the user has logged in and
selected the Add Purchase Order task. The required
fields (e.g., the Issue Date) are highlighted in green,
while fields automatically populated by the system
are shown in grey.
The right-hand pane is split into two panels. The
upper panel contains two tabs, with one for the
process graph and the other for the process instance
graph. The lower panel is for displaying detailed
information about graph objects selected by the user.
3.1.1 Visualizing Processes
Figure 3 presents only the right-hand side of the
interface from Figure 2. It draws the graph for the
purchasing process, in which the Add Purchase
Order task is a component. Each box stands for a
task node object and each arrow represents a data
flow link object. Boxes with solid borders are
mandatory tasks in this process, and boxes with
dashed borders are optional. The box corresponding
to the current task (Add Purchase Order) is
highlighted with a heavy border and blue label. Two
tasks (Edit Purchase Requisition and Edit Purchase
Order) have circles attached to them, meaning that
they are recursive and can be repeated many times.
The links in the graph are weighted based on the
frequency of the data flow.
When the user clicks on any object in the graph,
the object’s color will change to green and its details
will be displayed in the lower panel. For example,
the green link currently selected carries the output
ApplyingDesignPrinciplesforEnhancingEnterpriseSystemUsability
165
document (purchase_order) from Add Purchase
Order and provides the input to the Add Goods
Receipt task; and for 68.4% of the time a goods
receipt is posted directly after a purchase order is
added without the editing task being performed. This
panel also displays details about the previously
selected Add Purchase Order task in terms of its
output document name, whether it is optional, and
the two pages that need to be filled out.
Figure 3: A process graph.
The visualization of a process graph can enhance
the user’s context awareness. In the above example,
a user can easily see that the Add Purchase Order
task is a required component within the business
process for purchasing materials, that several tasks
(e.g., Add Material and Add Purchase Requisition)
may precede this task, and that more tasks (e.g., Edit
Purchase Order and Add Goods Receipt) may follow
it. The user can also get a clear idea about what data
are needed as inputs for a task and what document
will be generated as the output. For example, the
inputs for Add Purchase Order include material data
and a purchase requisition document. Moreover, link
frequencies calculated based on system usage logs
can, to some extent, serve as a recommendation for
the most “popular” path of tasks among alterative
paths in a process. The task details provide
additional contextual information about whether a
task is optional and which pages are required for it.
3.1.2 Visualizing Process Instances
The upper panel in Figure 4 displays the process
instance graph tab for an Add Goods Receipt task
instance. The graph for the purchasing process, of
which the Add Goods Receipt is a component, can
be viewed in the process graph tab (Figure 3).
Figure 4: A process instance graph.
In the instance graph, each box represents a
specific task instance labeled by its instance ID, task
name, and the output document number. As in the
process graph, the current task instance (TI4064:
Add Goods Receipt #4) is highlighted with a heavy
border and blue label. The links are document flows
between task instances. It is clear that this process
instance started with two materials (#121 and #122)
being added in two task instances, TI4047 and
TI4053, respectively. A purchase requisition
(PR#103) was then created in task instance TI4056,
based on which a purchase order (PO#34) was
created in TI4059. Subsequently, PO#34 underwent
two rounds of editing in TI4062 and TI4063. In the
last step, a goods receipt (GR#4) was posted in
TI4064.
Unlike the process graph in Figure 3 the instance
graph includes only those task instances that were
actually involved in the specific execution of the
process. Tasks such as Edit Purchase Requisition are
not part of this process instance’s history.
The lower panel in Figure 4 shows detailed
information about two selected task instances:
ICSOFT-EA2014-9thInternationalConferenceonSoftwareEngineeringandApplications
166
TI4056 and TI4063. By reviewing the task instance
details, the user can quickly learn the instance ID,
task name, output document number, status
(complete or incomplete), the start and end times,
and the user names of those performing the task
instance. The system’s ability to identify each of the
task instances and who performed them is especially
useful in error situations, as the current user can
trace back through an instance graph to identify the
sources of an error and the users who may be able to
help resolve it.
3.2 Automated Playback
In developing the automated playback component
and following the directive of Design Principle 2 to
supply process guidance, we have sought to build
into the system the capability to provide users with a
feature for reviewing how a task or a business
process instance was performed in the past. As
previously noted, users often turn to their colleagues
for demonstrations of how to complete new or
infrequently performed tasks. With the automated
playback feature, the user first selects a task or
process instance. That instance is then replayed step-
by-step by the system as originally executed, thus
serving as a form of a tutorial. This tutorial is
created dynamically by the system without any
human intervention, based only on the automatically
collected records of past system-user interactions
stored in the TIL model, as described in detail in
(Lucas and Babaian, 2012; Babaian and Lucas,
2013a). Access to this automated playback is
provided from every task page via a click on a Show
Me button.
A user can specify parameters to narrow down
the list of task instances for replay by specifying a
particular user, time window, or specific document
produced by the task instance. However, even with
filtering by search parameters, finding the
appropriate task instance may yield a large set of
instances. In the prototype, we extended the
playback interface by providing the user with the
option to review the associated process instance
prior to selecting it for replay. As shown in Figure 5,
when a user clicks on a task instance from the list on
the left-hand side, the system automatically
reconstructs the process instance graph that includes
the chosen task instance and presents it in the
process visualization pane on the right. This
mechanism follows the directive of Design Principle
4 to use the information that is available to the
system to simplify the selection task for the user.
Upon the user submitting the selected task instance,
the system runs an animation of that instance in a
separate window. A video demonstration of the
playback feature can be viewed by accessing the
website at http://cis.bentley.edu/ERP/demos.html.
Figure 5: Integrated view of task instances for playback and the corresponding process instance visualization.
ApplyingDesignPrinciplesforEnhancingEnterpriseSystemUsability
167
3.3 Supporting Infrastructure
The user support features presented here require
system access to the history of system-user
interactions. This history, which in our prototype is
automatically collected during the regular course of
use, is recorded within the aforementioned Task-
Interface-Log (TIL) model. While commercial ERP
systems typically include several logging facilities,
the information available from their data logs is not
sufficient to enable the kinds of user support
presented here. The TIL model was specially
designed (Lucas and Babaian, 2012; Babaian and
Lucas, 2013a) to enable the system to be aware of its
own functionality and interface components, as well
as the users’ interactions with those components.
The specification of the task and interface
models within the TIL model allows user interaction
data to be captured and later reconstructed within a
broader task and process context, as is the case in the
two interactive user interface components we have
presented here. The TIL data provides the system
with a rich infrastructure for runtime reasoning
about the relationships between tasks, processes,
domain data, and users, and for extracting
knowledge about system usage. In addition to the
history of task instances and records of system-user
interactions, which are primarily exploited by our
prototype, the data within the TIL model can also
serve as a basis for other system interventions that
implement the design principles presented here. For
example, the data can be used to assess the user’s
familiarity with a task, find the most commonly
entered values, and determine a set of related tasks.
Furthermore, the TIL model makes it possible to
specify the composition of processes from tasks and
to adjust the labels on input fields to match a
specific organization’s practices and vocabulary.
4 RELATED WORK
Industry reports acknowledge that ERP systems are
rife with usability problems (Hestermann, 2009;
Matthews, 2008; Otter, 2008 Iansiti, 2007), but there
is a dearth of research on means for improving the
user experience. A study by Parks (2012) shows that
interface complexity has a significant impact on task
time. A recent survey-based study of ERP users
(Lambeck et al., 2014) confirms that locating the
desired functionality within a system remains a
significant usability obstacle. The study also finds
that visualization and error support reduce the
perception of complexity of the interface.
Process visualization is a natural fit for aiding
navigation and improving understanding of business
processes. The advent of process-aware information
systems (PAISs) has led to large collections of
process models. Hipp, Mutschler, and Reichert
(2012) note that process models are typically
presented as static drawings. They present a
framework for navigating large process spaces at
varying levels of detail. The proView framework
(Kolb and Reichert, 2013) provides personalized
views from large collections of business processes
and process instances by showing only those
activities in which the user is involved. However,
none of the frameworks that we found in literature
has been integrated in an interactive way within an
enterprise system for aiding end users during active
system use, as ours has been.
In addition to their application for process
discovery (van der Aalst, 2011), event logs have
been used for providing context-aware assistance to
users. Dorn et al. (2010) describe an approach to
providing context-sensitive recommendations on the
most suitable next step in flexible, people-driven
processes. Schnonenberg et al. (2008) propose a
recommendation service for use with flexible PAISs
for providing users with recommendations on
possible next steps based on past process executions.
Plaisant and Shneiderman (2005) note that
recorded demonstrations of interfaces are very
effective for helping users learn procedural tasks.
These tutorials, however, are typically prerecorded
demonstrations, not integrated with the user
interface. CoScripter (Leshed et al., 2008) enables
users to record their interactions with websites as
editable, executable scripts, which are stored in a
wiki for sharing among users. ActionShot (Li et al.,
2010) provides visualization interfaces for exploring
and searching the user’s detailed history of
interactions within a web browser for sequences of
actions. Actions can be shared via email or the web,
or converted into a CoScripter script and stored on
the CoScripter wiki. Studies of CoScripter usage
indicate that enterprise users chose to incorporate
these process scripts into their work practices.
5 CONCLUSIONS AND FUTURE
WORK
We have presented a prototype ERP system that
integrates two kinds of user support features: process
visualization and automated playback of previous
task interactions. These features are included
ICSOFT-EA2014-9thInternationalConferenceonSoftwareEngineeringandApplications
168
alongside the usual ERP functionality for providing
additional, and much needed, support to the users.
Inclusion of this type of interactive process and task
guidance distinguishes our work from other business
process mining and visualization research.
The presented prototype serves as an illustration
of possible ways of implementing some of our
design principles for achieving better ERP usability
by focusing on improving the collaborative
capability of the system. Furthermore, the presented
interventions, which were designed using the TIL
model and algorithms, confirm the suitability of TIL
as a framework for implementing a variety of
features supporting system-user collaboration.
The design principles and interventions were
motivated by field studies of ERP usage. Thus, the
next step in this research involves evaluating the
proposed solutions with users and fine-tuning the
solutions based on their feedback. We are also
working on optimizing the algorithms for logging
and information extraction from the TIL model.
REFERENCES
Babaian, T., Lucas, W., 2013a. Modeling data for
enterprise systems with memories. Journal of
Database Management, 24(2), 1-12.
Babaian, T., Lucas, W., 2013b. Composing interface
demonstrations automatically from usage logs. LNBIP,
vol. 141, Springer, 376-392.
Babaian, T., Lucas, W., Xu, J., Topi, H., 2010. Usability
through system-user collaboration: Deriving design
principles for greater ERP usability. LNCS, vol. 6105,
Springer, 394-409.
Calisir, F., Calisir, F., 2004. The relation of interface
usability characteristics, perceived usefulness, and
perceived ease of use to end user satisfaction with
enterprise resource planning (ERP) systems.
Computers in Human Behavior, 20(4), 505-515.
Dorn, C., Burkhart, T., Werth, D., Dustdar, S., 2010. Self-
adjusting recommendations for people-driven ad- hoc
processes. In Proc. of BPM’10, LNCS vol. 6336,
Springer-Verlag, 327-342.
Ganly, D., Montgomery, N., 2013. Hype Cycle for ERP,
2013. Gartner, Stamford, CT.
Grosz, B.G., 2005. Beyond mice and menus. In
Proceedings of the American Philosophical Society,
149 (4), 529-543.
Hestermann, C., 2009. Key issues for enterprise resource
planning. Gartner, Stamford, CT.
Hipp, M., Mutschler, B., Reichert, M., 2012. Navigating
in complex business processes. In Proc. of DEXA’12,
Part II, Springer, 466-480.
Iansiti, M., 2007. ERP End-user business productivity: A
field study of SAP & Microsoft. http://download.
microsoft.com/download/4/2/7/427edce8-351e-4e60-
83d6-28bbf2f80d0b/KeystoneERPAssessment
Whitepaper.pdf
Kolb, J., Reichert, M., 2013. Data flow abstractions and
adaptations through updatable process views. In Proc.
of SAC’13, EE’13. ACM, 1447-1453.
Lambeck, C., Fohrholtz, C., Leyh, C., Šūpulniece, I.,
Müller, R., 2014. Commonalities and contrasts: An
investigation of ERP usability in a comparative user
study, In Proc. of ECIS-2014.
Leshed, G., Haber, E.M., Matthews, T., Lau, T., 2008.
CoScripter: Automating & sharing how-to knowledge
in the enterprise. In Proc. of CHI '08, ACM, 1719-
1728.
Li, I., Nichols, J., Lau, T., Drews, C., Cypher, A., 2010.
Here's what I did: Sharing and reusing web activity
with ActionShot. In Proc. of CHI'10, ACM, New
York, NY, USA, 723-732.
Lucas, W., Babaian, T., 2012. Implementing design
principles for collaborative ERP systems. LNCS, vol.
7286, Springer, 88-107.
Lucas, W., Xu, J., Babaian, T., 2013. Visualizing ERP
usage logs in real time. In Proc. of the 14th
International Conference on Enterprise Information
Systems (ICEIS ’13), 83-90.
Matthews, D., 2008. Usability as an ERP Selection
Criteria, IFS. http://ifs.datahost.com/shop/images/wp-
usability.pdf
Otter, T., 2008. Case study: Ness combines consumer
application ease of use with ERP robustness. Gartner,
Stamford, CT.
Parks, N. E., 2012. Testing & quantifying ERP usability.
In Proc. Of RIIT '12. New York, USA, ACM, 31-36.
Plaisant, C., Shneiderman, B., 2005. Show me! Guide-
lines for producing recorded demonstrations. In Proc.
of VL/HCC 2005, IEEE Computer Society, 171-178.
Schonenberg, H., Weber, B., van Dongen, B., van der
Aalst, W., 2008. Supporting flexible processes through
recommendations based on history. In Proc. of BPM
2008. LNCS, vol. 5240. Springer, Heidelberg, 51-66.
Scott, J. E. 2005. Post-implementation usability of ERP
training materials: The user's perspective. Information
Systems Management, 22(2), 67-77.
Singh, A., Wesson, J., 2009. Evaluation criteria for
assessing the usability of ERP systems. In Proc. of
SAICSIT 2009, ACM, 87-95.
Terveen, L.G., 1995. An overview of human-computer
collaboration. Knowledge-Based Systems Journal,
Special Issue on Human-Computer Collaboration,
8(2-3), 67-81.
Topi, H., Lucas, W., Babaian, T. 2006. Using informal
notes for sharing corporate technology know-how.
European Journal of Information Systems, 15(5), 489-
499.
van der Aalst, W. M. P., 2011. Process mining: Discovery,
conformance, and enhancement of business processes,
Heidelberg, Springer-Verlag.
ApplyingDesignPrinciplesforEnhancingEnterpriseSystemUsability
169
