A Method of Topic Detection for Great Volume of Data

Flora Amato, Francesco Gargiulo, Antonino Mazzeo and Carlo Sansone

Dipartimento di Ingegneria Elettrica e delle Teconolgie dell’Informazione (DIETI) University of Naples Federico II,

Via Claudio 21, Naples, Italy.

Keywords:

Topic Detection, Clustering, t f − id f, Feature Reduction.

Abstract:

Topics extraction has become increasingly important due to its effectiveness in many tasks, including infor-

mation ﬁltering, information retrieval and organization of document collections in digital libraries. The Topic

Detection consists to ﬁnd the most signiﬁcant topics within a document corpus. In this paper we explore the

adoption of a methodology of feature reduction to underline the most signiﬁcant topics within a document

corpus. We used an approach based on a clustering algorithm (X-means) over the t f − id f matrix calculated

starting from the corpus, by which we describe the frequency of terms, represented by the columns, that occur

in each document, represented by a row. To extract the topics, we build n binary problems, where n is the

numbers of clusters produced by an unsupervised clustering approach and we operate a supervised feature

selection over them considering the top features as the topic descriptors. We will show the results obtained on

two different corpora. Both collections are expressed in Italian: the ﬁrst collection consists of documents of

the University of Naples Federico II, the second one consists in a collection of medical records.

1 INTRODUCTION

Topic extraction from text has become increasingly

important due to its effectiveness in many tasks, in-

cluding information retrieval, information ﬁltering

and organization of document collections in digital li-

braries.

In this paper we explore the adoption of a method-

ology of feature extraction and reduction to underline

the most signiﬁcant topic within a corpus of docu-

ments.

We used an approach based on a clustering algo-

rithm (X-means) over the TF-IDF matrix calculated

starting from the corpus.

In the proposed approach, each cluster represents

a topic. We characterize each of them through a set of

words representing the documents within a cluster.

In literature a standard method for obtaining this

kind of result is the usage of a non-supervised feature

reduction method, such as the Principal Component

Analysis (PCA). However the high dimensionality of

the feature vectors associated to each document make

this method not feasible.

To overcome this problem we build n binary prob-

lems, where n is the numbers of clusters produced by

the X-means. Then we operate a supervised feature

selection over the obtained clusters, considering the

cluster membership as the class and the selected top

features (words) as the researched topic.

We exploit two different ground truth made by do-

main expert in order to evaluate the most signiﬁcant

feature that separates the class of interest from all the

rest.

The paper is organized as follows. Section 2 de-

scribes the most recent related work for topic detec-

tion. Section 3 outlines the proposed methodology.

In Section 4, we present the performed experiments,

showing dataset used for experimental validation and

the obtained results. Eventually, in Section 5 we dis-

cuss conclusions and possible future directions for our

research.

2 RELATED WORKS

Nowadays we have available a large amount of infor-

mation on web but we would access to this informa-

tion in the shortest time and with the highest accuracy.

To help people to integrate and organize scattered in-

formation several machine learning approaches have

been proposed for the topic detection and tracking

technology. Moreover Topic detection and tracking

(TDT) is to study the problem of how to organize

information which is based on event in natural lan-

guage information ﬂow and Topic Detection is a sub-

434

Amato F., Gargiulo F., Mazzeo A. and Sansone C..

A Method of Topic Detection for Great Volume of Data.

DOI: 10.5220/0005145504340439

In Proceedings of 3rd International Conference on Data Management Technologies and Applications (KomIS-2014), pages 434-439

ISBN: 978-989-758-035-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

task of TDT. In the Topic Detection (TD) task the set

of most prominent topics have been found in a col-

lection of documents. Furthermore, in other words,

TD is based on the identiﬁcation of the stories in sev-

eral continuous news streams which concern new or

previously unidentiﬁed events. Sometimes unidenti-

ﬁed events have been retrieved in an accumulated col-

lection (“retrospective detection”) while in the “on-

line detection” the events could be labelled when they

have been ﬂagged as new events in real time. Give

the TD is a problem to assign labels to unlabelled

data grouping together a subset of news reports with

similar contents, most unsupervised learning meth-

ods, proposed in literature as (Wartena and Brussee,

2008), (Jia Zhang et al., 2011), exploit the text clus-

tering algorithms to solve this problem.

Most common approaches, as (Wartena and

Brussee, 2008), given list of topics the problem of

identifying and characterizing a topic is a main part

of the task. For this reason a training set or other

forms of external knowledge cannot be exploited and

the own information contained in the collection can

be used to solve the Topic Detection problem. More-

over the method, proposed in (Wartena and Brussee,

2008), is a two-step approach: in the former a list of

the most informative keywords have been extracted;

the latter consists in the identiﬁcation of the clusters

of keywords for which a center has been deﬁned as

the representation of a topic. The authors of (Wartena

and Brussee, 2008) considered topic detection with-

out any prior knowledge of category structure or pos-

sible categories. Keywords are extracted and clus-

tered based on different similarity measures using the

induced k-bisecting clustering algorithm. They con-

sidered distance measures between words, based on

their statistical distribution over a corpus of docu-

ments, in order to ﬁnd a measure that yields good

clustering results.

In (Bolelli and Ertekin, 2009), a generative model

based on Latent Dirichlet Allocation (LDA) is pro-

posed that integrates the temporal ordering of the doc-

uments into the generativeprocess in an iterative fash-

ion called Segmented Author-Topic Model (S-ATM).

The document collection has been split into time seg-

ments where the discovered topics in each segment

has been propagated to inﬂuence the topic discovery

in the subsequent time segments. The document-topic

and topic-word distributions learned by LDA describe

the best topics for each document and the most de-

scriptive words for each topic. An extension of LDA

is the author-topic model (ATM). In ATM, a docu-

ment is represented as a product of the mixture of

topics of its authors, where each word is generated by

the activation of one of the topics of the document au-

thor, but the temporal ordering is discarded. S-ATM

is based on the (ATM) and extends it to integrate the

temporal characteristics of the document collection

into the generative process. Besides S-ATM learns

author-topic and topic-word distributions for scien-

tiﬁc publications integrating the temporal order of the

documents into the generative process.

The goals in (Seo and Sycara, 2004) are: i) the

system should be able to group the incoming data into

a cluster of items of similar content; ii) it should re-

port the contents of the cluster in summarized human-

readable form; iii) it should be able to track events of

interest in order to take advantage of developments.

The proposed method has been motivated by con-

structive and competitive learning from neural net-

work research. In the construction phase, it tries to

ﬁnd the optimal number of clusters by adding a new

cluster when the intrinsic difference between the pre-

sented instance and the existing clusters is detected.

Then each cluster moves toward the optimal cluster

center according to the learning rate by adjusting its

weight vector.

In (Song et al., 2012), a text clustering algorithm

C-KMC is introduced which combined Canopy and

modiﬁed k-means clustering applied to topic detec-

tion. This text clustering algorithm is based on two

steps: in the former, namely C-process, has been ap-

plied Canopy clustering that split all sample points

roughly into some overlapping subsets using inaccu-

rate similarity measure method; in the latter, called

K-process, has been employed a modiﬁed K-means

that take X-means algorithm to generate rough clus-

ters from the canopies which share common instance.

In this algorithm, Canopies are an intermediate result

which can reduce the computing cost of the second

step and make it much easier to be used, although

Canopy is not a completed cluster or topic.

The authors of (Zhang and Li, 2011) used vector

space model (VSM) to represent topics, and then they

used K-means algorithm to do a topic detection exper-

iment. They studied howthe corpus size and K-means

affect this kind of topic detection performance, and

then they used TDT evaluation method to assess re-

sults. The experiments proved that optimal topic de-

tection performance based on large-scale corpus en-

hances by 38.38% more than topic detection based on

small-scale corpus.

3 METHODOLOGY

The proposed methodology, aiming to extract and re-

duce the features characterizing the most signiﬁcant

topic within a corpus of documents, is depicted in

AMethodofTopicDetectionforGreatVolumeofData

435

Fig. 1.

The considered features are computed on the basis

of the Term Frequency-Inverse Document Frequency

(t f − id f) matrix from the corpus.

Process implementing the methodology is com-

posed by several steps. The ﬁrst step is the evaluation

of a t f − id f matrix (Manning and Sch¨utze, 1999),

consisting of an m× n matrix where m is the number

of documents in the collection and n is the number

of tokens we are considering. The tokens could be

Lemmas, Terms, Synonymous or more complex Lex-

ical Structures (Amato et al., 2013b),(Amato et al.,

2010),(Amato et al., 2013a).

Each row represents a document and each column

represents the t f − id f value calculated for each doc-

ument’s token.

The t f − id f value is deﬁned as follows:

t f − id f = t f × id f (1)

where t f is the number of the token occurrence

in the document and id f is a measure of whether the

occurrence is common or rare across all collection

items.

Each rows of t f − id f matrix contains a vector of

real numbers which represents the projection of each

document in an n-dimensional feature space, for seek

of simplicity in the Figure 1(a) we represent the doc-

uments as projected in a bi-dimensional space.

To overcome the high-dimensionality feature

space (more than 60.000 tokens) that makes the us-

age of an unsupervised feature selection method, such

as Principal Component Analysis (PCA), not feasi-

ble, we adopted a novel solution based on a prelimi-

nary documents clustering. In the Figure 1(b) is rep-

resented the clustering process.

After that we built n binary problems where n is

the number of clusters obtained. Each problem is

created using a one vs all strategy such as for each

cluster i, all the documents that belong to the cluster

i were labelled as True otherwise all the other docu-

ments were labelled as False, see Figure 1(c).

In order to obtain the topics characterizing each

cluster, corresponding to a binary problem, we used

a supervised feature selection method on each of

them, using the previous assigned labels indicating

the group membership as class on which evaluate

each feature. The feature selection gave in output a

set of ranked features that represent the tokens that

more discriminate the cluster under analysis from all

the rest. These tokens ﬁgure out the searched topic.

4 RESULTS

In order to evaluate the effectiveness of this approach,

we used the Weka library (Holmes et al., 1994), which

is a collection of data mining algorithms.

We selected for the clustering process the X-

means algorithm (Dan Pelleg, 2000). The X-means is

an evolution of the K-means, the main difference be-

tween them is on the choice of the optimal number of

clusters to use, while X-means set automatically this

number, the K-means use a manual parameter (K).

More in details we conﬁgure the X-means with: 4

as Max Number of Iteration and 15 as Max Number of

Clusters.

The proposed approach has been applied on two

different corpora. Both collections are expressed in

Italian: the ﬁrst one, called UNINA, consists of doc-

uments of the University of Naples Federico II, the

second one, called Medical Records, consists in a

collection of medical records.

We compare the performances obtained on these

two corpora in terms of precision, recall and cluster

coverage.

precision =

out

− N

false

out

(2)

recall =

out

− N

false

ins

(3)

coverage =

out

tot

(4)

where N

out

is the number of instances in result

clusters, N

false

is the number of mistake instances in

result clusters, N

ins

is the sample size of the category

under test and N

tot

is the total number of instances.

4.1 Corpora Description

The corpus UNINA was originally collected from the

web site of the University of Naples Federico II (Un-

ina) and labelled by a domain expert. It consists of a

total of 469 documents, divided into four categories

statistically characterized in the Table 1.

The corpus Medical Records consists of about

5.000 medical diagnoses coming from various health

Table 1: Categories distribution for corpus UNINA.

Class Number of documents

Amministrativo 17

Bandi 111

Didattica 224

Relazioni Attivit´a 117

TOT. 469

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

436

Figure 1: Main Schema.

Table 2: Categories distribution for corpus Medical

records.

Class Number of documents

Consulenze 96

Doppler 593

Ecoc 702

Ecograﬁa 1171

Endoscopia 365

Intervento 346

Radiologia 1726

TOT. 4999

care organization in Campania (Italy). Since each

fragment is a document produced from Medical Cen-

ter, containing a description of a patient health care.

For privacy issues, these documents are opportunely

anonymized. The medical records are divided into

seven categories detailed within the Table 2.

4.2 Experimental Results

The results of the two case studies are reported in Ta-

ble 3 and Table 4. The ﬁrst consideration is that not all

the classes are characterized with a cluster, this fact is

directly correlated to the number of documents belong

to each of them.

For example, the absence of the class Amministra-

tivo within the Corpus UNINA is due to the few doc-

uments that belongs to that class, see Table 1. For the

same motivation it is possible to justify the absence of

the classes Consulenze, Intervento and Endoscopia in

the corpus Medical Records, see Table 2.

Table 3: Clusters assignments for Unina.

Cluster

Assigned category Precision Recall Coverage

Didattica 100.0% 4.0% 1.9%

Didattica 100.0% 3.1% 1.5%

Didattica 100.0% 12.5% 6%

Bandi 100.0% 36.0% 8.5%

Relazioni Attivit´a 99.0% 81.2% 20.5%

Didattica 41.1% 13.4% 15.6%

Didattica 67.5% 62.1% 43.9%

Didattica 100.0% 2.2% 1.1%

Didattica 100.0% 1.8% 0.9%

Didattica 100.0% 0.4% 0.2%

Average Parameters 76.4% 50.0% 100.0%

Table 4: Clusters assignments for medical records.

Cluster

Assigned category Precision Recall Coverage

Ecograﬁa 91.6% 59.8% 15.3%

Ecoc 99.7% 99.4% 14.0%

Ecograﬁa 61.0% 35.1% 13.5%

Doppler 100.0% 67.3% 8.0%

Radiologia 41.0% 35.0% 29.4%

Radiologia 94.5% 12.9% 4.7%

Radiologia 100.0% 24.5% 8.5%

Radiologia 100.0% 1.0% 0.4%

Radiologia 100.0% 0.8% 0.3%

Radiologia 100.0% 17.4% 6.0%

Average Parameters 75.9% 47.22% 100.0%

Another important results is that the cluster with

the highest coverage is composed in large part by

noise. A possible motivation could be that the biggest

cluster contains a collection of documents that are

AMethodofTopicDetectionforGreatVolumeofData

437

Table 5: Topic detection for dataset Unina.

Cluster Rel. Att. Amm. Bandi Didat- tica Coverage Top features

6 3% 29% 67% 43.9% emanato, norme, seguito, conto, u.s.r

4 99% 1% 20.5%

legittimata, odierna, giudizi, alfabetico,

riunione

5 21% 23% 15% 41% 15.6% gara, foro, cauzione, possedute, addebito

3 100% 8.5%

incombenza, destituzione, rimborsabile,

risiedere, assunzione

100% 6%

facilitarne, aggrega, preﬁggono, consecutivo,

pianiﬁca

100% 1.9%

regolamentazioni, oligopolio, monopolio,

microeconomia, macroeconomia

1 100% 1.5% ebbe, opzione, roffredo, lictera, spagnole

7 100% 1.1%

pneumoconiosi, 2607, extraepatiche, ards,

propriocettiva

100% 0.9%

ril, discip, coordinatoredel, periimplantari,

dental

100% 0.2%

anaﬁlotossine, passivazione, overjet, overbite,

otori

Table 6: Topic detection for dataset Medical records.

Cluster Radio-

logia

Eco-

graﬁa

Ecoc Consu-

lenze

Endo-

scopia

Doppler Inter-

vento

Coverage Top features

4 41.0% 4.1% 0.3% 2.6% 15.3% 13.2% 23.5% 29.4% norma, alterazioni, esame, eseguito, volume

8.4% 91.6% 15.3% fegato, pancreas, milza, colecisti, reni

99.7% 0.3% 14.0% sezioni, normali, aortica, sinistre, deﬁcit

12.0% 61.0% 6.2% 20.8% 13.5% tiroide, lobo, prevalente, nodulari,

componente

100.0% 8.5% compatibile, cardiaca, lesioni,

aortica.immagine, focolaio

100.0% 8.0% intimale, vasale, ispessimento, assi, succlavio

100.0% 6.0% carattere, periferica, attivit , ilare,

distribuzione

94.5% 5.5% 4.7% ingrandita, stasi, cardiaca, piccolo, costo

100.0% 0.4% prominenza, attivit .regolare, arco,

periferica.marginale,

100.0% 0.3% aerea, bozzatura, tracheale, emidiaframma,

scoliotica

very close to each other, even if they belong to differ-

ent categories. A possible solution is to not consider

this cluster of documents or to use approachesto clean

this data (Gargiulo and Sansone, 2010) or to use multi

classiﬁcation schemas (Gargiulo et al., 2013).

Within the Table 5 and Table 6 we represented the

top features evaluated for each cluster with the per-

centage of documents belongs to each original cate-

gory.

5 CONCLUSION

Topic extraction from documents is a challenging

problem within the data mining ﬁeld. The main mo-

tivation is due to its effectiveness in many tasks such

as: information retrieval, information ﬁltering and or-

ganization of documents collection in digital library.

In this paper we presented a methodology to im-

plement an unsupervised topic detection for high di-

mensional datasets.

To this aim we used a preliminary clustering ap-

proach over the t f − id f matrix computed starting

from the corpora and we built n binary problems, one

for each cluster obtained; we considered a supervised

features selection over such problems to select the

most important features and consequently the asso-

ciated topics.

We showed the effectiveness of this approach on

two different corpora, UNINA and Medical Records,

obtaining interesting results.

As feature work we are planned to evaluate a set

of distance measures to automatically ﬁgure out the

degree of belonging between the selected features set

and the most interesting topics set.

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

438

ACKNOWLEDGEMENTS

This work has been partially supported by the

“SMART HEALTH CLUSTER OSDH SMART FSE

STAYWELL” project, funded by MIUR (Ministero

dellIstruzione, dellUniversit`a e della Ricerca).

REFERENCES

Amato, F., Casola, V., Mazzeo, A., and Romano, S. (2010).

A semantic based methodology to classify and protect

sensitive data in medical records. In Information As-

surance and Security (IAS), 2010 Sixth International

Conference on, pages 240–246. IEEE.

Amato, F., Casola, V., Mazzocca, N., and Romano, S.

(2013a). A semantic approach for ﬁne-grain access

control of e-health documents. Logic Journal ofIGPL,

21(4):692–701.

Amato, F., Gargiulo, F., Mazzeo, A., Romano, S., and San-

sone, C. (2013b). Combining syntactic and semantic

vector space models in the health domain by using a

clustering ensemble. In HEALTHINF,pages 382–385.

Bolelli, L. and Ertekin, Giles, C. (2009). Topic and trend

detection in text collections using latent dirichlet al-

location. In Boughanem, M., Berrut, C., Mothe, J.,

and Soule-Dupuy, C., editors, Advances in Informa-

tion Retrieval, volume 5478 of Lecture Notes in Com-

puter Science, pages 776–780. Springer Berlin Hei-

delberg.

Dan Pelleg, A. M. (2000). X-means: Extending k-means

with efﬁcient estimation of the number of clusters. In

Proceedings of the Seventeenth International Confer-

ence on Machine Learning, pages 727–734, San Fran-

cisco. Morgan Kaufmann.

Gargiulo, F., Mazzariello, C., and Sansone, C. (2013).

Multiple classiﬁer systems: Theory, applications and

tools. In Bianchini, M., Maggini, M., and Jain,

L. C., editors, H. on Neural Information Processing,

volume 49 of Intelligent Systems Reference Library,

pages 335–378. Springer.

Gargiulo, F. and Sansone, C. (2010). SOCIAL: Self-

organizing classiﬁer ensemble for adversarial learn-

ing. In Gayar, N. E., Kittler, J., and Roli, F., editors,

MCS, volume 5997 of Lecture Notes in Computer Sci-

ence, pages 84–93. Springer.

Holmes, Donkin, A., and Witten, I. H. (1994). Weka: a ma-

chine learning workbench. In Intelligent Information

Systems,1994. Proceedings of the 1994 Second Aus-

tralian and New Zealand Conference on, pages 357–

361.

Jia Zhang, I., Madduri, R., Tan, W., Deichl, K., Alexan-

der, J., and Foster, I. (2011). Toward semantics

empowered biomedical web services. In Web Ser-

vices (ICWS), 2011 IEEE International Conference

on, pages 371–378.

Manning, C. D. and Sch¨utze, H. (1999). Foundations of

Statistical Natural Language Processing. MIT Press,

Cambridge, MA, USA.

Seo, Y.-W. and Sycara, K. (2004). Text clustering for topic

detection.

Song, Y., Du, J., and Hou, L. (2012). A topic detection

approach based on multi-level clustering. In Control

Conference (CCC), 2012 31st Chinese, pages 3834–

3838. IEEE.

Wartena, C. and Brussee, R. (2008). Topic detection by

clustering keywords. In Database and Expert Sys-

tems Application, 2008. DEXA’08. 19th International

Workshop on, pages 54–58. IEEE.

Zhang, D. and Li, S. (2011). Topic detection based on k-

means. In Electronics, Communications and Control

(ICECC), 2011 International Conference on, pages

2983–2985.

AMethodofTopicDetectionforGreatVolumeofData

439
