Ensemble Method for Prediction of Prostate Cancer

from RNA-Seq Data

Yongjun Piao, Nak Hyun Choi, Meijing Li, Minghao Piao and Keun Ho Ryu

Database/Bioinformatics Laboratory, Chungbuk National University, Cheongju, South Korea

1 STAGE OF THE RESEARCH

The main idea of our research is to develop an

ensemble machine learning algorithm to accurately

classify prostate cancer using RNA-Seq data. To

date, many studies have focused on predicting

prostate cancer using microarray data. These days,

RNA-Seq is rapidly being used for cancer studies as

an alternative to microarrays. Thus, new machine

learning algorithms are needed to analyze RNA-Seq

data, which have different characteristics compared

to microarray data. The current PhD research has

been running for one year and has focused on

analyzing existing state-of-the-art normalization

methods, gene expression data analysis, and

ensemble methods. Besides that, we designed an

ensemble feature selection algorithm to select

relevant genes from the gene expression data.

Moreover, we developed a “digital” gene expression

data simulator for evaluating the performance of the

proposed algorithms. The next step will be to

construct an accurate ensemble prediction model to

diagnose prostate cancer. Finally, the model will be

fine-tuned based on feedback from medical doctors.

2 OUTLINE OF OBJECTIVES

The goal of this research is to accurately predict

prostate cancer using RNA-Seq data. To ensure a

systemic approach, the overall research problem is

divided into a set of sub-problems: i) comparative

analysis of normalization methods, ii) development

of RNA-Seq simulators, and iii) ensemble algorithm

design and implementation. The specific objectives

in each sub-problem are as follows.

 Provide a Clear Guideline for Choosing the

Appropriate Normalization Methods. Bullard

et al. (2010) indicated that the choice of

normalization procedure has a decisive effect on

identifying candidate genes. The aim of data

normalization is to minimize the effects caused

by technical variations, such as library size or

sequencing depth, gene length, and GC-content.

Various normalization methods have been

developed. However, it is difficult to decide

which normalization methods should be used

among the various approaches. Therefore,

comparative analysis of these normalization

methods will improve the performance of final

prediction.

 Develop a Gene Expression Data Simulator.

Various computational methods have been

proposed, and new methods are continuously

being developed for identifying candidate genes

in gene expression data. One major problem with

newly developed approaches is the issue of

assessing accuracy and false positive rates in the

absence of a so-called “gold standard.” Thus,

using both simulated and real datasets to evaluate

proposed methods will increase the reliability of

the prediction model.

 Propose an

Ensemble Classification Algorithm.

In general, ensembles of classifiers provide

better classification accuracy than a single

predictor. The main characteristic of expression

data is high dimensionality. Thus, we need to

consider both dimension reduction techniques

that identify a small set of genes and ensemble

classification methods to achieve better learning

performance.

3 RESEARCH PROBLEM

Cancer is a class of complex genetic diseases

characterized by out-of-control cell growth. Cancer

classification has been a crucial topic of research in

cancer treatment. For the last decade, microarray

data have been widely used to classify the different

types of human cancers (Kim et al., 2013). Recently,

the emergence of next-generation sequencing (NGS)

technology has brought significant changes in many

biological and medical applications (Metzker, 2010;

Lee et al., 2013; Shon et al., 2013). Whole

transcriptome shotgun sequencing, also known as

Piao Y., Choi N., Li M., Piao M. and Ryu K..

Ensemble Method for Prediction of Prostate Cancer from RNA-Seq Data.

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

RNA-Seq, is often being used for cancer studies as

an alternative to microarrays (Rapaport et al., 2013).

Generally, an RNA-Seq analysis pipeline consists of

the following procedures. An RNA sample is

converted to cDNA fragments or RNA fragments

with adapters and sequenced on a high-throughput

sequencing platform, such as Illumina or Roche 454.

As a result, millions of short reads (30-400 bp) are

produced. Next, these short reads are mapped back

to a reference genome or transcriptome. After that,

the expression levels are estimated for each gene.

Then, the count data are normalized. Finally, a

machine learning technique is adopted to identify

candidate genes. However, several issues still exist

in RNA-Seq data analysis. Various normalization

methods have been developed for removing the bias

of RNA-Seq experiments. However, there is no clear

guideline as to how the normalization procedure

affects downstream analysis. Thus, it is difficult to

decide which normalization methods should be used

from among the various approaches. Moreover,

there is not much work focused on machine learning

approaches with RNA-Seq data for prostate cancer

prediction.

In general, ensembles of classifiers provide

better classification accuracy than a single predictor.

To improve classification accuracy, ensemble

methods, also known as classifier combinations, first

generate a set of base classifiers from training data

and then perform actual classification by combining

the results of base classifiers. To achieve better

accuracy in the combined set of multiple classifiers,

each base classifier should be diverse and

independent. When it comes to building each base

classifier, ensemble classifier generation methods

can be broadly categorized into four groups

(Rahman and Verma, 2013): i) by selecting different

subsets of instances from a training set to build each

base classifier, ii) by choosing different subsets of

features from the input features to construct each

base classifier, iii) by basing the selection on

different categories of class labels to build each base

classifier, and iv) by manipulating the learning

algorithm. Theoretical and empirical results (Tumer

and Oza, 1999) indicate that the most effective

method of achieving independence on high-

dimensional data is by training base classifiers on

different feature subsets (Bryll et al., 2003; Bashir et

al., 2012). The basic idea of a feature subset–based

ensemble is simply to give each classifier a different

projection of the training set (Rokach, 2008).

Especially for high-dimensional data, adopting

independent feature subsets for ensemble generation

has been shown to be more efficient (Rokach, 2010)

compared with manipulating the training samples.

This may be due to the following: i) a feature subset-

based ensemble can perform faster due to the

reduced size of input space; or ii) it can reduce the

correlation among the classifiers.

4 STATE OF THE ART

4.1 Gene Expression Data Analysis

Much research has been performed on analyzing

microarray gene expression data for cancer

classification over the past several years. For

example, Fujibuchi and Kato (2007) proposed the

maximum entropy kernel, which they applied in the

field of support vector machine (SVM) classification

of microarray data. For classifying a leukemia

dataset, Cho and Ryu (2002) proposed an ensemble

classifier trained from a subset selected using SNR

measurement. Cho and Won (2007) also proposed

an ensemble model. Hsu et al. (2011) introduced a

hybrid feature selection model based on information

gain and F-score, and performed the classification

task using SVM. Dettling and Buhlmann (2003)

modified the boosting classifiers and applied

Wilcoxon’s two-sample test to select discriminative

genes on the breast and lymphoma dataset. Lee et al.

(2005) noted that SVM with a BSS/WSS feature-

ranking criterion outperforms other classifiers on a

lymphoma dataset. Liu et al. (2010) proposed an

ensemble gene selection method based on

normalized conditional mutual information and

evaluated their method on a central nervous system

(CNS), lymphoma and prostate dataset with a Naïve

Bayes classifier and a k-nearest-neighbor classifier.

Kanna and Ramaraj (2010) used a correlation-based

memetic feature selection algorithm to select genes

on a CNS and leukemia dataset. Tan and Gilbert

(2003) and Yeh (2008) also worked on CNS

datasets, and Yang et al. (2006) proposed two gene

selection methods that were not affected by

unbalanced sample class sizes. Yang et al. (2009)

introduced a hybrid feature selection method based

on information gain and a genetic algorithm.

4.2 Ensemble Methods

4.2.1 Bagging

Bagging (Breiman, 1996) is a method for generating

multiple versions of classifiers and using these to get

an aggregated classifier. Each base classifier is

generated by different bootstrap samples. Algorithm

IC3K2014-DoctoralConsortium

1 shows the bagging algorithm (Bauer and Kohavi,

1999). The algorithm takes training data D, inducer

I, and the number of bootstrap samples N as input,

and then produces an ensemble classifier that is the

combination of the classifiers trained from the

multiple bootstrap samples. D is obtained by

repeatedly sampling instances from a data set

according to probability distribution (line 2). Since

the sampling is done with replacement, some

instances may appear several times in the same

training set, while others may not. Consequently, N

bootstrap samples, D

, D

, ..., D

, are generated,

from which a classifier C

is trained by using each

bootstrap sample D

(line 3). Finally, a combined

classifier C* is built from C

, C

, …, C

, and C*

predicts the class label of a given instance x by

counting votes (line 5).

Algorithm 1 Bagging

Input: training data D, Inducer I, number of bootstrap

samples N

1. for i = 1 to N {

D = bootstrap sample from D (sample

with replacement)

= I(D)

4. }









yxCi

)(:

1maxarg)(*

Output: Aggregated classifier C*

4.2.2 Boosting

Boosting (Freund and Schapire, 1996) is also a

widely used ensemble method developed to improve

the performance of learning algorithms that generate

multiple classifiers and vote on them. Unlike

bagging, boosting assigns a weight to each training

instance and may adaptively change the weight at

the end of each boosting round. AdaBoost is an

improved boosting algorithm, with the pseudo code

shown in Algorithm 2. The algorithm takes as input

training data D containing m instances, inducer I,

and iteration parameter N, and then outputs a

combined classifier. Initially, all of the instances are

equally assigned the same weight (line 1). Then, the

algorithm gradually constructs classifiers by

modifying the weights of training instances based on

the previous classifier's performance (lines 2-9).

This is accomplished by computing the new

classifier while putting more emphasis on those

objects previously found to be difficult to accurately

classify. After generating each classifier, a

proportion of the incorrect classification rate is

calculated (line 4). If the weighted error is larger

than 0.5, the current D will be set to a bootstrap

sample with weight 1 for every instance. Otherwise,

the weight of correctly classified instances will be

updated by a factor inversely proportional to the

error (lines 6-8). In other words, if the current

classifier finds a certain object difficult to classify,

then that object will be assigned a greater weight for

the next iteration. Conversely, if an object is found

to be easy to classify, then it will have less weight in

the next iteration. Finally, the classifiers are

combined using a weighted voting scheme (line 10).

Algorithm 2 AdaBoost

Input: training data D, size m, Inducer I, number of

iterations N

D = D with instance weights assigned at 1

2. for i = 1 to N {

= I(D)







jjij

yxCDx

xweight

)(:'

)(



2/1



, set D to a bootstrap sample

from D with weight 1 for

every instance and go to

step 3

)1/(

iii









For each

'Dx



, if

jji

yxC )(

then

ijj

xweightxweigh





 )()(

Normalize the weights of instances so the

total weight of D is m

9. }

10.









yxCi

)(:

logmaxarg)(*



Output: Aggregated classifier C*

4.2.3 Random Forest

Random forest is an ensemble classification method

that consists of multiple unpruned decision trees.

Unlike bagging, random forest forms bootstrap

samples by randomly partitioning the original

feature space instead of using the whole input

features. As shown in Algorithm 3, to construct

individual decision trees, bootstrap samples are

selected from the training instances, with

replacement (line 2). Then, a classification and

regression tree (CART) algorithm is applied to grow

the decision tree. At the node selection stage, it

decides the best splitting node from a randomly

selected subspace of m features (lines 3-4).

EnsembleMethodforPredictionofProstateCancerfromRNA-SeqData

Algorithm 3 Random forest

Input: training data D, number of selected variables m,

number of trees N

1. for i = 1 to N {

D = bootstrap sample from D (sample

with replacement)

S size of m= S (S will be randomly

selected from original input space)

= I(D, S



) (I: Classification and

regression tree)

5. }









yxCi

)(:

1maxarg)(*

Output: Aggregated classifier C*

5 METHODOLOGY

5.1 Normalization

As mentioned above, the choice of normalization

procedure has a decisive effect on identifying

differentially expressed genes. The aim of data

normalization is to minimize the effects caused by

technical variations, such as library size or

sequencing depth, gene length, and GC-content. In

general, a larger sequencing depth results in higher

counts, which means that the observed counts are

not directly comparable between different samples

(Soneson and Delorenzi, 2013). Likewise, long

genes tend to be mapped to a larger number of reads.

These systematic variations make it difficult to

capture true differential expression. Several

normalization methods have been developed, such as

Total Count, Upper Quality, Median, Trimmed

Mean of M values (TMM), Quartile, the Reads Per

Kilobase per Million mapped reads (RPKM), and

RSEM, to reduce the biases existing in RNA-Seq

analysis. Thus, these methods will be carefully re-

evaluated by comparing the correlations with qRT-

PCR data.

5.2 Simulation

To obtain a reliable prostate prediction model, the

proposed methods will be tested on both real and

simulated data. Thus, we developed a gene

expression data simulator. As input, the simulator

simply takes several parameters, such as number of

samples in condition 1, the number of samples in

condition 2, the number of genes, the number of

differentially expressed genes, the number of co-

expressed genes, the number of highly expressed

genes, and the number of zero count genes,

distribution types, and distribution parameters. Then,

simulated data is generated as output.

5.3 Ensemble Gene Selection

In our previous work (Piao et al., 2012), we

proposed a hybrid feature selection algorithm and

demonstrated that there are lots of feature subsets

with good discriminative capability, and the

proposed algorithm was more efficient than FCBF

and other feature selection mechanisms for gene

expression data analysis. While the goal of our

previous work was to find the best feature subset

that is most relevant to the target, there needs to be

an additional goal of finding a set of feature subsets.

Therefore, we extend our previous work to generate

a set of feature subsets by considering the relevance

and redundancy of the features.

5.4 Ensemble Construction

Over the past few years, SVM has been widely used

for classification because of its good performance on

high-dimensional data. SVM was developed to solve

the problems occurring in applications like

handwritten digit recognition, object recognition,

text classification, cancer diagnosis, and

bioinformatics. Hence, we use SVM as the base

classifier in our ensemble method. The goal of SVM

is to find a hyper-plane with a maximal margin (the

distance between two groups of data points) as

defined and illustrated in Figure 1. Given some data

points that are assumed to be divided into two

groups (circles and squares), the hyper-plane can be

written as:

0bxw 





(3)

1 bxw

||||

arg

inm 

(4)

Figure 1: Example of support vector machine.

IC3K2014-DoctoralConsortium

Hence, the learning task in SVM can be formalized

as the following constrained optimization problem:

||w||

min

(5)

n ..., 2, 1,i 1,b)x(wy subject to



(6)

This is also known as a convex optimization

problem, which can be solved by using the standard

Lagrange multiplier method:







iii

1)-b)x(w(y-||w||



(7)

where parameters σ



are called the Lagrange

multipliers. With the Lagrange multipliers, the

decision function can be written as follows:

b)x),K(xysgn(f(x)









(8)

Additionally, the results of each classifier are

combined by majority voting, and classification of

unknown data is performed based on the class label

to obtain the most frequent votes. The mathematical

function of our ensemble method with k classifiers

can be written as:

))c ,(x)(fmax( argclass(x)





(9)

6 EXPECTED OUTCOME

At the end of this PhD research, a new ensemble

classification method will be available for predicting

prostate cancer from RNA-Seq data. Moreover, a

complete gene expression data simulator will be

developed. The simulator may help to research non-

parametric methods for cancer classification. The

research will lead to new insights for understanding

prostate cancer by identifying candidate genes from

high-dimensional gene expression data. If this is

proven successful, our approach could be applied to

other types of disease.

ACKNOWLEDGEMENT

This work was supported by the National Research

Foundation of Korea (NRF) grant funded by the

Korea government (MSIP) (No. 2008-0062611) and

the Basic Science Research Program through the

National Research Foundation of Korea (NRF)

funded by the Ministry of Science, ICT & Future

Planning (No.2013R1A2A2A01068923).

REFERENCES

Bullard, J., Purdom, E., Hansen, K., Dudoit, S., 2010.

Evaluation of statistical methods for normalization and

differential expression in mRNA-Seq experiments.

BMC Bioinformatics 11:94.

Kim, Y., Yoon, H., Kim, J., Kang, H., Min, B., Kim, S.,

Ha, Y., Kim, I., Ryu, K., Lee, S., Kim, W., 2013.

HOXA9, ISL1 and ALDH1A3 methylation patterns as

prognostic markers for nonmuscle invasive bladder

cancer: array-based DNA methylation and expression

profiling. International Journal of Cancer 133, 1135-

1143.

Metzker, M., 2010. Sequencing technologies – the next

generation. Nature Reviews Genetics, 11, 31-46.

Rapaport, F., Khanin, R., Liang, Y., Pirun, M., Krek, A.,

Zumbo, P., Mason, C., Socci, N., Betel, D., 2013.

Comprehensive evaluation of differential gene

expression analysis methods for RNA-Seq data.

Genome Biology, 14:R95.

Rahman, A., Verma, B., 2013, Ensemble Classifier

Generation using Non–uniform Layered Clustering

and Genetic Algorithm. Knowledge-Based System 43,

30-42.

Tumer, K., Ghosh, J., 1996. Classier combining: analytical

results and implications. Proc. Nat’l Conf. Artificial

Intelligence, Portland, Ore, 126-132.

Tumer, K., Oza, N., 1999. Decimated input ensembles for

improved generalization. International Joint

Conference on Neural Network 5, 3069-3074.

Bryll, R., Gutierrez-Osuna, R., Quek, F., 2003. Attribute

bagging: improving accuracy of classifier ensembles

by using random feature subsets, Pattern Recognition

36, 1291-1302.

Rokach, L., 2006. Genetic algorithm-based feature set

partitioning for classification problems, Pattern

Recognition 41, 1676-1700.

Rokach, L., 2010. Ensemble-based classifiers. Artif. Intell.

Rev. 33, 1-39.

Fujibuchi, W., Kato, T., 2007. Classification of

heterogeneous microarray data by maximum entropy

kernel. BMC Bioinformatics 8, 267-277.

Cho, S., Ryu, J., 2002. Classifying gene expression data of

cancer using classifier ensemble with mutually

exclusive features. Proceedings of the IEEE, 90(11),

1744-1753.

Bashir, M., Lee, D., Li, M., Bae, J., Shon, H., Cho, M.,

Ryu, K., Trigger Learning and ECG Parameter

Customization for Remote Cardiac Clinical Care

Information System. IEE Transactions on Information

Technology in Biomedicine, 16, 561-571.

Cho, S., Won, H., 2007. Cancer classification using

ensemble of neural networks with multiple significant

gene subsets. Applied Intelligence 26, 243-250.

EnsembleMethodforPredictionofProstateCancerfromRNA-SeqData

Hsu, H., Hsieh, C., Lu, M., 2011. Hybrid feature selection

by combining filters and wrappers. Expert System

with Applications 38, 8144-8150.

Dettling, M., Buhlmann, P., 2003. Boosting for tumor

classification with gene expression data.

Bioinformatics 19 (9), 1061-1069.

Lee, J., Lee, J., Park, M., Song, S., 2005. An extensive

comparison of recent classification tools applied to

microarray data, Comput. Statist. Data Anal. 48, 77-87.

Liu, H., Liu, L., Zhang, H., 2010. Ensemble gene selection

for cancer classification. Pattern Recognition 43,

2763-2772.

Lee, D., Ryu, K.S., Bashir, M., Bae, J., Ryu, K.,

Discovering Medical Knowledge using Association

Rule Mining in Young Adults with Acute Myocardial

Infarction. Journal of Medical Systems, 37.

Kannan, S., Ramaraj. N., 2010. A novel hybrid feature

selection via symmetrical uncertainty ranking based

local memetric search algorithm. Knowledge-Based

Systems 23, 580-585.

Tan, A., Gilbert, D., 2003. Ensemble machine learning on

gene expression data for cancer classification.

Bioinformatics 20, 3583-3593.

Yeh, J., 2008. Applying data mining techniques for cancer

classification on gene expression data. Cybernetics

and Systems: An International Journal 39, 583-602.

Yang, K., Cai, Z., Li, J., Lin, G., 2006. A stable gene

selection in microarray data analysis. BMC Bioin-

formatics 7:228.

Yang, C., Chuang, L., Yang, C., 2009. IG-GA: A hybrid

filter/wrapper method for feature selection of

microarray data, Journal of Medical and Biological

Engineering 30 (1), 23-28.

Breiman, L., 1996. Bagging predictors, Machine Learning

24, 123-140.

Bauer, E., Kohavi, R., 1999. An empirical comparison of

voting classification algorithms: bagging, boosting and

variants, Appears in Machine Learning 36, 105-139.

Freund, Y., Schapire, R., 1996. Experiments with a new

boosting algorithm, International Conference on

Machine Learning, 148-156.

Soneson, C., Delorenzi, M., 2013. A comparison of

methods for differential expression analysis of RNA-

Seq data. BMC Bioinformatics, 14:91.

Piao, Y., Piao, M., Park, K., Ryu, K., 2012. An ensemble

correlation-based gene selection algorithm for cancer

classification with gene expression data,

Bioinformatics, 28, 3306-3315.

Shon, H., Kuk, H., Whan, B., Ah, KIM., Lee, J., Ryu, K.,

N-terminal pro-B-type natriuretic peptide as

prognostic marker for patients of non ST-segment

elevation myocardial infarction. J. Cent. South Univ.,

20, 2226-2232

IC3K2014-DoctoralConsortium
