A Numerical Data Standard Joining Units, Numerical

Accuracy and Full Metadata with Numerical Values

Joseph E. Johnson

Department of Physics, University of South Carolina, Columbia SC, 29208, U.S.A.

Abstract. Numerical measurements have little meaning without the associated

units of measurement, level of accuracy, and defining metadata tags. Yet these

three associated items are scattered in rows, columns, references, the title, and

other positions in data tables separated from the values themselves and usually

immersed in unstructured text. Thus unambiguous electronic readability is not

possible but requires human preformatting to link these three data components

to the value for computer processing. This paper proposes a tight linkage among

numerical values, units, accuracy, and meaning as a string expression that

provides a numerical standard which we call a “metanumber” along with a set

of requirements for this structure. We require that this metanumber string object

be instantly readable by both humans and computers. Our work then develops

the requisite algorithms for automated computer processing of the metanumber

expressions resulting in a new metanumber where (a) all units and dimensional

analysis are automatically processed, (b) numerical accuracy of results are

computed, and (c) unlimited metadata tags and structures provide a trace of all

historical operations with component meaning providing both the exact

evolutionary path of each computed number, and a unique name (as an internet

path) for every single measured v4alue. We also propose a flexible table-like

structure for archiving all numerical data as metanumbers that allows the

automated sharing of data among users. This structure can serve as a foundation

for high –speed data exchange removing the costs, errors, and time delays

required with human preprocessing and thus serving as a critical component in

Big Data processing and as a foundation for advanced artificial intelligence.

Other features are explored including an optional proposed expansion of the

base units for the SI (metric) system as well as user defined units that are

natural for users with commercial, industrial, medical, and scientific problems.

These components offer a transformational increase in computational power in

every domain of inquiry.

Keywords. Units, Dimensional Analysis, Metadata, Numerical Uncertainty &

Accuracy, Metanumber, Error Management, Data Tags, Numerical Information

Standards, Si & Metric Units, Big Data.

1 Introduction

Numeric data by itself, except for pure numbers, is meaningless without three

associated components: a. units of measurement, b. accuracy level (numerical

uncertainty), and c. the associated defining and modifying information. All these are

requisite for the unambiguous meaning of numerical values. Yet in every domain,

numerical data tables have these three components scattered in the title, row &

Johnson J.

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values.

DOI: 10.5220/0006156400140030

In European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health and Sports (EPS Rome 2014), pages 14-30

ISBN: 978-989-758-154-0

column headings, and footnotes. Sometimes such auxiliary data is just assumed to be

apparent. There is no universal standard for the attachment of such metadata to

numeric values or even a unique computer readable symbol structure for these

components. The resulting arbitrary positions, fonts, and formatting styles prevent

unambiguous automated electronic reading and requires that all data must be

manually converted to a useful form by each user prior to their computer processing

each and every time it is used thus incurring substantial costs, time delays, and

associated errors. The reason we believe that no standard has emerged is that no

single convention seems preferable or natural. Also storage space, in both print and

electronic representation, has historically always been a primary consideration, so the

compressed formats that are currently used were historically optimal for printing,

direct human viewing, and to minimize electronic storage. A substantial component of

this problem is that the units, accuracy, and defining tags are not only separated from

the values, they are also embedded in text thus making it extremely difficult to extract

their content by computer algorithms. Those space considerations are no longer an

issue with current technology. Having a numerical metadata standard for automatic

electronic data processing would not only remove all of these problems and lead to

fully automated sharing and processing of all numerical data, but could lay the

foundation for far more advanced and intelligent automated analysis and decision

systems, that will not require human preprocessing or intervention. The

standardization can be implemented automatically from the initial observation or

measurement device when the data is originally recorded. Such a solution is essential

for the emergence of a new level of artificial intelligence. When any numerical value

is retrieved, using a unique name, it arrives with units, uncertainly level, and complete

metadata so that logical and numerical processing is executed not only for

dimensional and error analysis but also with advanced metadata tag management and

tracing of the historical evolution of numbers. So there are two problems that have to

be simultaneously addressed: (a) create a standard for such integrated metanumber

formats so that they are easily read by both humans and computers, and (b) create the

algorithms for mathematical and logistic processing that evaluates all expressions

among such objects.

2 Proposed Solution

The author here proposes standards for attaching the units, error, and all other

descriptive metadata, to numerical values along with the associated three software

algorithms that mathematically processes such extended information [1]; [2], [3]; [4].

We call such objects “metanumbers” to denote their informational completeness. Our

integrated algorithm satisfies our criteria that these metanumbers must (A) be easily

readable both by humans and by computers, (B) require the minimum of storage, (C)

process at the fastest possible speed, (D) be easily extensible to allow for user defined

units, and (E) support computation at all levels from simple calculations as web

“apps” on internet devices to unlimited “Big Data” applications in large scale

computing. It must also (F) automatically manage all computations among

metanumbers with dimensional analysis to trap invalid unit combinations as well as

(G) compute the associated accuracy (numerical uncertainty) of the result using error

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

analysis with user selectable means of combining error. It must (H) provide a simple

rapid means for the one-time initial formatting of data into the requisite metanumber

format, and (I) allow one to easily retrieve and use all past results. Finally, (J) the

algorithms must allow unlimited metadata to be linked to numerical values and still

manage that attachment with the absolute minimum number of characters and without

any reduction in the processing speed. The author has developed a methodology for a

simple one-time reformatting of numerical data sets into such a standardized

metanumber form that, with the algorithms we have developed, will satisfy each and

all of the listed requirements and still provide unlimited traceability of all metadata

linkages and origins.

3 Historical Development & Current Status

Early versions of the author’s unit and dimensional management software were built

and deployed on a web site that has been in use for over a decade and is still used by

students in several university courses but it was limited. Recent developments by the

author led to (a) a new optimized design methodology that vastly extends numerical

operations with units and dimensionality analysis including (b) the reuse of any

previous expression, (c) improved means for output of an expression in any desired

units by using a resolution of the identity, (d) an improved means for users to define

personal units for their specialized domain of work, (e) a new method of error

analysis with an awarded U.S. patent to the author, and (f) a new innovative design

for optimally managing unlimited metadata attachments to numerical values. This

new algorithm can also support a ten-fold increase in processing speed using a

parallelization of the code over multiple processors for Big Data problems. Then a

future stage will support a dedicated accelerator chip for ultra-fast processing. The

author has completed the full design, programming, and testing of both the units and

metadata management components along with several important metanumber tables

in a fully operational system. This software and methodology is now fully tested and

operational on our central server as a cloud application available from any internet

device. The central server approach is necessary in order to support multiple users,

rapidly deploy code upgrades, and, most important, to share a rapidly growing

interdisciplinary standardized library. Such a cloud system allows use by any internet

linked device, (tablets/iPads, smart phones, PCs) as well as large central systems. The

software has been developed in the Python language which is open source with

extensive additional components, and is a widely accepted very modern framework

for rapid development. The addition of a Python algorithm for the processing of

numerical accuracy has also been fully integrated using the “Python Uncertainty”

system developed by Leibigot and associates. The final phase of building user

interface tools is currently active. We will discuss each of these three active

components separately.

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

4 The Units (Dimensional Analysis) Algorithm

4.1 Units Introduction

There are a large number of ‘unit conversion programs’ and some that can process

expressions containing multiple units. Our algorithm however is optimal with both

maximum speed and minimum space whereby one simply attaches unit names as

variables within any valid algebraic expression such as (4.3*ft/s+7*meter/hour). The

‘value’ of each unit and constant provides the instantaneous requisite conversion with

effortless readability for humans. With this algorithm, each unit name or constant is a

unique variable defined in terms of the foundational metric (SI) system units. The

units algorithm contains most normally encountered units (over 800 units and

essential fundamental constants). It also supports the introduction of other units as

defined by users in terms of existing units and constants (such as the lightyear). These

results have led us to change a number of traditional notations.

4.2 Units Standards

In order to be compatible with modern computer languages and optimal electronic

processing without ambiguity, we define all units in lower case with standard

alphanumeric characters, without Greek characters, without superscripts or subscripts,

and without any other special characters, symbols, or fonts. The past denotations for

unit names and constants lead to ambiguities in different computer languages and thus

we seek unit and constant names that are expressible in simple lower case

alphanumeric characters. Specifically we remove the capitalization of all proper

names assigned to a unit and thus we write “newton” or “nt” rather than “Newton” or

“Nt” because the value of a variable in modern computer languages is case sensitive

for alphabetical symbols. Likewise the potentially ambiguous encoding of units and

constants with multiple fonts, superscripting and subscripting, and of foreign

alphabets is removed. Thus we use “ohm” rather than  and hb (h-bar) for Planks

constant divided by 2 Pi is likewise written as pi rather than as . Our motives are

format consistency, adherence to modern software convention (variables are lower

case), the use of only standard alphanumeric characters for variables, and to remove

the ambiguity that can result from font and format imbedded information. Although a

few of the most common units are allowed in the plural form, we generally restrict the

spelling to only the singular form thus removing some ambiguities in spelling and

simultaneously making the underlying code shorter. Our core units algorithm is

essentially the same in any language (C/C++, Java, Ruby, Python…) and can be

easily enhanced by parallel processing on a dedicated accelerator chip [5]. Our

algorithm catches all exceptions for dimensional errors, and returns expressions in

standard format for use in subsequent expressions. These in turn, can be referenced

with a unique name for insertion in any future expressions and are functionally valid

although they are expressed in different units. All computational history is maintained

for each user.

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

4.3 Units Features

Mathematical expressions of values are returned in metric unless other units are

specified using the format “(expression) ! (units desired)” . The speed of light in miles

per minute would be written as c!(mile/min). Formally the algorithm multiplies the

expression by (desired_units / desired_units) which is technically unity and does not

change the value. The software divides the value of the expression (in default units)

by the desired_units and then writes the final expression as “final_expression *

desired_units”. The effect is to both divide by the desired units then multiply by the

desired units. So although the value is numerically different when expressed in

different units, it is computationally equivalent to the original value since it is now

multiplied by different output units and either expression will evaluate equivalently.

For example 35*acre*!(ft2) would give the value of 35 acres in square feet and then

multiply that value by square feet (ft2).

4.4 Units Base Si System

The units algorithm is defined and based upon the SI (metric) system in terms of

meter, kilogram, second, ampere, kelvin, and candela. All the other primary units and

core constants are then defined in terms of these allowing also for altered spelling and

abbreviations such as m for meter, sec and s for second, etc. Dimensionless prefixes

(kilo, mega, centi, million, dozen, etc. can be mixed with units in any mathematically

valid manner thus eliminating the need for joined definitions. The 800 or so primary

units and physical constants are then each defined in terms of previous units,

sequentially back to the fundamental metric units. Values assume the accuracy level

of the computational environment while the accuracy is indicated as the median value

with an associated accuracy (uncertainty).

4.5 Powers of Base Units

In the original definitions we also define m2= m*m; and m3=m*m2 up to the fourth

power in order to assign basic unit variables that have these multiple powers in an

abbreviated manner. We likewise define the inverse powers of the base SI units as

m_2 = 1/m2, m_3 = 1/m3 also up to the inverse fourth power. If any mathematical

expression is then well formed using unit names then the result will be returned in SI

units by default. Thus (34.6*acre*(1.2*ft+7.2*inch-3.4*cm)) will give the computed

volume (numerically) in cubic meters (m3). In order to obtain that volume in gallons,

one would instead enter: (34.6*acre*(1.2*ft+7.2*inch-3.4*cm)) ! gallon.

4.6 Standardized Metanumber Data Tables

The core fundamental constants and primary units are defined within the metanumber

program. All other numeric data, user defined units, and special constants are defined

in tables of various dimensionalities using the format [server-path_ directory-

path_table-name_row-name_column-name…)]. For example the elements table

(which has the unique abbreviated name of “e”), contains all elements in rows, with

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

columns providing over 50 associated properties. This path name (currently using our

default server) of [file_row_column] can itself be used as a variable to retrieve that

metanumber value from the stored data tables. Thus [E_Gold_Density] /

[E_Silver_Density] computes the ratio of the density of gold to that of silver. All

stored data is to be standardized and retrievable by its unique internet path name as

here described.

4.7 Unique Path Names

These internet path names are unique, and thus exactly define the metanumber of

interest as well as provide an unambiguous name for that single unique metanumber.

Furthermore the [ … ] structure can be used as a variable in any mathematical

expression, function, or algorithm to retrieve that metanumber. For the file name, row

name, and column name, the comparison is made with all white space removed and

all case changed to lower case. We envision that all numerical data be standardized as

metanumbers in tables appropriate dimensionalities: zero dimension (a single value),

or one dimension (a list of values such as the masses of objects), or two dimensions

such as the elements table, or even other data tables of any higher dimensionality. The

metanumbers in each of these tables are to be stored in comma separated values

(CSV) formats thus allowing easy viewing and editing in spreadsheets such as Excel

and avoiding any extraneous symbols in any type of markup language which could be

problematic with the retrieving algorithm.

5 The Metanumber Algorithm

5.1 Metadata Overview

By “metadata” we refer to the collection of all information (other than units and

accuracy) that describe, define, and explain the meaning of the associated

metanumber. By “metanumber” we refer to a single numerical value with attached

units, accuracy level, and its metadata that describes it. We propose that all numerical

data be standardized as metanumbers and stored in archived tables as described here.

In the last section we concluded that the units are to be attached as variable names in

valid mathematical forms to the numerical value as for example with the velocity of

3.759e4*m*s_1. Here we discuss the metanumber archive tables as mentioned above

with greater detail on how metadata is stored and associated with a value. When one

normally stores structured numerical data, it can be as a single value, a list of values, a

rectangular table of values, or an array of higher dimension (such as when economic

data has an associated date or location). Our methodology applies to data arranged in

any dimensionality. But data which is laid out as a two dimensional table is the most

common with a format like “Entity vs Property”. The “ Entity” might be the 110

chemical elements corresponding to the rows, and where the “Property” might be any

of 40 to 50 different properties given in columns, such as density, atomic number,

atomic mass, thermal or electrical conductivity, heat capacity, melting point, boiling

point , etc. Likewise, the rows might specify a person’s ID and the columns might be

properties such as medical data for each person such as DOB, weight, pulse, blood

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

pressure ... We will use the two dimensional table as an example. The format is to be

in rows of comma separated values. This is the most common and open format, and it

is easily imported and exported from Excel and other editors as well as read by

Python. It is also structured so that at any point it can be automatically loaded easily

into any relational database such as Oracle, or SQL if desired by a simple program

and fully automated.

5.2 Metadata for a Table as a Whole

Some metadata values are associated with (a) an entire table, while other metadata is

associated with just the (b) entries in a given column, (c) or entries in a given row, or

(d) perhaps only associated with a specific value (such as longitude and latitude or

date-time). To capture metadata associated with the table as a whole, we standardize

the first two rows of each table with row one containing the names of fields

describing the table, while their associated values are contained in the second row in

the corresponding column. This ‘table metadata’ will contain the table name, a unique

table abbreviation, the source(s) of the data such as a web address, the table creator’s

name, and email address, date created & last updated, security level and codes,

references, footnotes, and other associated data related to the collective data in the

table as a whole. All of this data is metadata that pertains to every metanumber in the

table. Thus this data is applicable and linked to all values in that table.

5.3 Metadata Associated with Specific Rows and Columns

The first column (beginning in row three) is to contain the unique row (entity)

name/index identifier (such as the element name of gold) while row three will contain

a unique column (property) name/index identifier (such as Thermal Conductivity).

Other columns (after the first) and other rows (after the third) can contain other

metadata associated with that row or column. For example if the third row has an

entry of “Thermal Conductivity” for a given column, then several of the rows beneath

the heading of Thermal Conductivity could contain references to the source(s) of

those data values, web links to discussions of thermal conductivity, associated

equations and web links to explanatory videos or notes. Units would preferably be

attached to the end of each numerical value or one could have row or column

headings labeled as “*units” in which case the units in that column or row would be

distributed by multiplication over the values in the associated row or column. The

reference [E_Gold_Thermal Conductivity] will find the unique table named “E”

referring to the elements, then find the row labeled “Gold” in column 1, and the

corresponding column labeled “Thermal Conductivity” in row three. The metanumber

string for gold’s thermal conductivity will then be retrieved from that table, that row,

and that column and the metadata that pertains to that table, associated with that row

and that column are linked to the value without having to be transferred into

expressions. Although the heading is Thermal Conductivity, the search will compare

the name with all case lowered and all white space removed. And thus it would match

‘thermalconductivity’. A comparison of lowered case with removed white space is

used for all components of the [table_row_column] lookup. Tables of metanumbers

cannot contain any set of the symbols “, _ {}()[ ]” as each of these has a reserved use.

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

When metadata occupies a row or column, this is to be indicated by having the name

of that row or column prefixed by a “%”. If the metadata values are unique and could

be used as an alternative index then the prefix is to be “%%”. An example with the

elements table is that both the atomic number and the symbol are unique metadata and

thus those columns are labeled as %% Atomic Number and %% Symbol.

5.4 Metadata Associated with Individual Values

Finally, there are times when specific metanumbers have an associated metadata just

for that one value such as a longitude-latitude or date-time of measurement. This

value specific metadata is encoded in the format {var1=value1|var2=value 2|…}

which multiplies the associated metanumber and which always evaluates to unity in

any mathematical expression and thus disappears. Thus this expression serves as a

wrapper to carry any information to be attached to a specific numeric value. By using

the reference [E_Gold_Thermal Conductivity] as a variable, one has therewith a

unique name for every archived metanumber along with potentially vast associated

metadata that is linked but not transferred until requested.

5.5 Data Archived on Other Servers

When data is stored on other servers (as opposed to the central cloud system in the

default directory) then the table name is to be preceded with “(the web address of the

server) _ (director path to the file)” followed by a double underscore ‘__’ and then

“(the table-name_row_name_column-name)”. This gives unlimited capacity to the

coding for data retrieval as is done with web addresses with a unique name for every

single metanumber value.

5.6 A Distinct Pathname for every Metanumber

A powerful feature of the reference string […] is that it gives a unique name to each

metanumber via the unique internet path to each separate value of metadata in the

table. Thus the metanumber name links to the table metadata, row metadata, and

column metadata without having to include that metadata with the value in the

expression. This is a critical concept. Furthermore, as all computational history is

archived, this structure supports an essentially unlimited unique line of tracing the

meaning, method of measurement, and unlimited other metadata via the indirect

reference to the numerical value. This can be of great value with the properties of

pharmaceuticals, where the non-numeric metadata can give critical associated data

such as batch and expiration data, or in accounting for the tracing of the origins of

funds and the means by which they were processed to give the current value. A

separate application easily reformats existing data tables. Once this conversion to

standard metanumber form is done, one can operate with the data at a speed and

accuracy never before possible with full automation and no human intervention. This

is especially critical with extremely large data sets and even more so when there are a

very large number of data tables from multiple sources. Finally, if data is formatted

this way as it is created, by that creator, then it can be subsequently used and shared at

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

maximum speed and confidence by everyone.

5.7 User Defined Units and Archived Results

A users submitted expressions are always archived into a single table under the user’s

name. This “user’s archive table” is created for each user and contains the values:

Seq#, DateTime, Submitted Expression, Resultant MetaNumber, and UnitID. The

Seq# is the unique submission sequence number for that user: 1, 2, …. The DateTime

is in the format YYYYMMDD:HHMMSS. The Submitted Expression is the string

that is submitted for evaluation. The Resultant MetaNumber is the metanumber that

results from the evaluation of the submitted expression. The UnitID is an integer

consisting of 10 single digits that contains a code for the powers of the fundamental

metric units in a given order and thus which is unique for each combination of units.

This integer is thus representative of the resulting concept and can be used for

different types of analysis, classification of results, tracking of work done, and the

creation of networks among users, metadata tabs, and concepts studied. One recalls

that any string that is bounded by {} will evaluate to unity (1) and thus can multiply

any metanumber at any position although the formal structure places it at the end of a

metanumber to denote the specific metadata such as Lon Lat for that value. If one

prefaces a submitted expression with {= expression name} such as {= Physics 211

Lab problem 4.38}, then later analysis of that users work, when downloaded to a PC

into Excel, can be used to filter and sort different computational efforts. Within

Metanumber, one can also reference the result as [my_expression name] in order to

use it in other expressions. One can also reference past work as [my_ seq#]. More

advanced features and operations are also possible. This means that all metanumbers

that are used, whether they are tables using [name_row_column] or past input results

as [my_name or #] provide unique names for every possible metanumber. In a sense,

the ability to create a (one dimensional) table with [my_name or #] means that a users

work creates a standardized table of all evaluated expressions by each user. As the

form {=name} is maintained as part of the input expression, it follows that it as well

as all component parts of the input expression with other metadata can always be

searched for content. If one is careful to use unique neumonic names, then such

results can constitute a user’s own set of ‘units’ as units are simply values of

metanumbers. It is easy to add additional user defined personal units and constants to

the system by prefixing any metanumber expression with {=unit or constant

name}*(metanumber expression) such as {=bluetruckvolume}*38*m3. A full

discussion of these advanced features would take us beyond the scope of this

introduction. The expression “[my_string]” is executed by the substitution of the users

unique PIN address for “my” and then all the previous discussions on archived table

data apply. Thus the term “my” is automatically replaced by the users PIN when used

and thus is kept private for that person. Data and special units for a company or

government agency can also be kept secure and private and thus shared only among

members of a closed user group. The system allows the use of any previous result

with the unique sequence number “i”, referenced as [my_i] , in a new expression as a

variable. Thus all the linkages back to the origin for every numerical value are

maintained among contributing users and their work. The software can peel back

layer after layer of how a given value was created along with all associated metadata

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

tags, assumptions, equations, accuracy levels, literally everything, in manufacturing a

product, pharmaceutical, account, and scientific measurement, thus supporting levels

of artificial intelligence never before possible and thus providing the complete

evolutionary history of every number.

5.8 Current Archived Data Tables

Our interdisciplinary team has been creating sample metanumber data tables in

several disciplines as examples for training. It is the identification of those tables and

that data that is most generally utilized and shared among groups that will enable

highly innovative computations crossing multiple disciplines supporting both research

programs and student course work. Optimizing our methodology for these tables has

been the main research thrust in parallel with refining our algorithms, notations, and

user tools.

5.9 Conclusions

To conclude the metadata descriptor section, we have shown that by standardizing all

metanumbers in tables with unique file, row and column names, that the internet path

to the metanumber [file_row_column …] provides a unique name for entering the

metanumber into a mathematical expression and also makes all action sequences fully

traceable. The same functionality applies also to each users past work with [my_name

or seq#] although this table is private to the user unless more advanced actions are

executed for the sharing of data among users.. But an equally important feature is that

all table, row, and column metadata is linked by that name enabling intelligent

systems to form networks among tags, concepts, dates and locations, units, special

constants, and even computational actions. Metadata for pharmaceuticals can describe

side effects, dosages, batch numbers, expiration dates, and other metadata which can

be automatically linked to recipient patients without the specific transfer of such

extensive metadata in the computational process as one only needs the internet path.

We will discuss these potential networks in the following.

6 The Numerical Accuracy Standard and Algorithm

6.1 Numerical Accuracy Overview

The most complex domain is the automated processing of numerical uncertainty

which is a core research area of the author and is too technical for a full presentation

here. The author has jointly published this research with a university colleague and

also presented it in the AMUEM international conference on numerical uncertainty in

Sardagna, Trento Italy [6] and has been awarded a U.S. patent for this algorithm.

Numerical “accuracy” or equivalently “uncertainty” can be computed by several

methods: A numerical accuracy algorithm could (a) treat the metanumber value as

being exact. But with the exception of the integer counting of objects, values that are

represented by real numbers cannot be either measured or represented exactly.

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

However there are a few “real numbers” that are by definition established as exact

such as the speed of light or the number of cm in an inch. We could (b) treat the value

with an uncertainty following the last listed valid digit when expressed in scientific

notation and follow the standard statistical rules for determining the accuracy of the

result for each operation given the accuracy of the operands. This method has the

advantage that if one intercepts the raw data prior to processing, then one can count

the number of digits present. We could (c) assume a normal (Gaussian) distribution to

the value and combine the standard deviations of operands thus basically treating each

value as a distribution instead of a real number which is done in the most exacting of

cases and which is the most accurate. But the problem with this is that one almost

never knows the actual standard deviation. Most measurements are made once or

twice and time, effort and cost are not available to reasonably determine the standard

deviation of the value except when different scientific teams expend a great effort

over many measurements as with the NIST fundamental constants. It is furthermore

an assumption that such normal probability distributions accurately represent the true

distributions without skewness or kurtosis. Furthermore normal distributions do not

close under operations other than multiplication and division meaning that the mean

and variance as a pair do not close mathematically except in approximation. This is in

contrast to the complex numbers which do close mathematically. We must choose the

method of combining values where the accuracy level is simply indicated by an

uncertainty of one in the last digit since that information is known and the standard

deviation is not known. This method of representing error is always known as one has

only a fixed number of valid digits in the value which is always observable. We will

choose this method because it is always known and displayed. When a more accurate

representation of uncertainty of the probably distribution such as standard deviation is

available, the algorithm is able to utilize that framework. The very complex patented

technique of the author is so exacting that the supporting information is almost never

available and it will not be offered in this release version.

6.2 Use of Accuracy as Measured by Significant Digits

Even this method is in general very complex because one is now representing each

numerical value with a pair of values: the known value as represented by a sequence

of digits along with an uncertainty value. However it is essential that this error of the

last digit be captured in the algorithm at the point when the number is introduced

either (a) keyed in by a user or (b) listed in a data table. This is because all

mathematical operations between the value of interest and other values in an

expression will erase the knowledge of the accuracy of each and provide results of

operations that only indicate the limit of accuracy being kept by that computer

software. Computer generated results, without an accuracy algorithm, always generate

a great overrepresentation of the true accuracy with excessive digits for the value as

one can see when dividing say 17 by 3 when the result might only be accurate to one

digit. Even this method of accurately computing the number of significant digits of

the result is very complex algorithmically as different operations and different

functions follow different rules for accuracy combinations and thus the expression

must be parsed for the correct operational sequence and the values themselves cannot

now be just real numbers but must be a new mathematical class of objects. Here we

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

are extremely fortunate that several such algorithms have been created for inclusion

with the Python language.

6.3 Python Uncertainty Package

We will use the Python Uncertainty package which can be found at

http://pythonhosted.org/uncertainties by Dr. Eric O. Lebigot [2]. Our procedure is

this: Each data value when loaded from MetaNumber tables, or a keyed entry by the

user must be immediately captured (using python code and ‘regular expressions’

methodology) and converted to a new type of object which is defined as a “ufloat” of

a string which contains the known digits. Once this is done then this uncertainty

algorithm evaluates the component values and maintains both the full accuracy of the

result as though there is no error and simultaneously gives the resulting uncertainty of

the numerical result. This algorithm also correctly mediates the operations between

the ufloat values and the other values which are known exactly. To utilize the Python

Uncertainty algorithm values, they must be identified by the software in order to be

converted to the ufloat class of objects or must be identified as exact and thus treated

as an exact standard value with no error. Our technique is to identify all uncertain

values by numbers which contain a decimal point such as 5.793e5 where the value of

5.793 will be identified via the decimal point and converted to a ufloat and then

multiplied by 1e5. An exact value must therefore be entered without a decimal by

adjusting the exponent to remove the decimal as 5.793e5, if exact would entered as

5793e2 and thus stored as an exact real number. This methodology requires no new

symbol or other indicator and is fully automatic. Thus the coding of numerical

certainty or uncertainty does not need an explicit coding but rather uses this implicit

coding methodology of our capture algorithm. This algorithm must act on all numeric

values in both the data tables as values are brought into an expression and on keyed

values that are entered by the user.

6.4 Conventions for Exact & Uncertain Values

We will take all unit conversions to be exact. The current algorithm automatically

converts all table values to ufloat objects along with automatic conversion of all user

keyed numerical components to ufloat based metanumbers when there is a decimal

present as well as decimal present values that are keyed in by the user. For exact

values, the user will only need to remove the decimal point by altering the associated

exponent in the scientific notation in order to enter a value as exact, either in the

tables or in the keyed values. Thus 3.2e4 becomes 32E3 with no decimal in the value

to indicate that the value is exact. Keyed or table values that have a decimal present

will be assumed to be ufloat objects. Any expression that contains a missing value

will automatically return a missing metanumber with the metanumber code. Thus the

result of this convention on encoding uncertainty is that no explicit notation is

required other than the presence or absence of the decimal point in the value to get the

value to be treated as uncertain or exact respectively.

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

7 Network and Cluster Analysis

7.1 Networks and Cluster Identification

Networks represent one of the most powerful means for representing information

interrelationships (topologies) among abstract objects called nodes which are

identified by sequential integer 1, 2,... Cluster analysis on these networks can uncover

the nature of those structures. We have been able to link objects in this numerical

standardization using our past research on the mathematical classification of networks

and associated cluster analysis. A network is defined as a square (sparse) matrix (with

the diagonal missing) that consists of non-negative real numbers, and which normally

is very large, that represent the connection degree between node i and node j as C

The mathematical classification and analysis of the topologies represented by such

objects is one of the most challenging and unsolved of all mathematical domains.

We have built some far-reaching extensions of the metanumber system that can be

constructed on the foundation laid by the standardization described above. Let us first

consider the standardization of numerical data as metanumbers in tables with units,

accuracy, and metadata descriptors linked as described above. Next consider how

each number in such a design has a unique reference name (such as [server

path_dir_table_row_column_...]). Likewise there is a unique name for every past

computation of each user (such as [my_ref#]), as well as a link for each shared

computational path by a project team under a given subject name (or

[subject_user_ref#]. We suggest that the resulting system supports vast and powerful

automated networks which can be constructed as described in 7.3 and 7.4 below.

7.2 Mathematics Underlying Our Network and Cluster Discoveries

This section will provide a very brief overview of our mathematical results that

provide a new foundation for network and cluster analysis. In previous work the

author discovered a new method of decomposing the continuous general linear (Lie)

group of (n x n) transformations into a Markov type Lie group (with n

-n parameters)

and an Abelian scaling group (with n parameters). Each is generated as is standard, by

exponentiation of the associated (Markov or scaling) Lie algebra. The Markov type

generating Lie algebra consists of linear combinations of the basis matrices that have

a “1” in each of the (n

-n ) off-diagonal positions with a “-1” in the corresponding

diagonal for that column. When exponentiated, the resulting matrix M(a) = exp(a C)

conserve the sum of elements of a vector upon which it acts, but can take a vector

with positive components into one with some negative components (which is not

allowed for a true Markov matrix). However, if one restricts the linear combinations

to only non-negative values then we proved that one obtains all discrete and

continuous Markov transformation of that size. This links all of Markov matrix theory

to the theory of continuous Lie groups and provides a foundation for continuous

Markov transformations.

Our next discovery was that every possible network (C

) corresponds to exactly

one element of the Markov generating Lie algebra (those with non-negative

combinations) and conversely, every such Markov Lie algebra generator corresponds

to exactly one network! Thus they are isomorphic and one can now study all networks

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

by studying the associated Markov transformations and Lie algebra and associated

groups. Our subsequent recent discoveries are (a) all nodes in any network can be

ordered by the second order Renyi entropy of the associated column in that Markov

matrix thus representing the network by a Renyi entropy spectral curve and removing

the combinatorial problems so that now one can both compare two networks (by

comparing their entropy spectral curve) as well as study the change of a networks

topology over time. One can even define the “distance” between two networks (as the

exponentiated negative of the sum of squares of difference of the Renyi entropies).

We recently showed that the entire network topology of any network can be

represented by the sequence of the necessary number of Renyi entropy orders. This is

similar to the Fourier expansion of a function such as for a sound wave where each

order represents successively less important information. Our next and equally

important result was that an agnostic (assumption free) identification of the n network

clusters can be found from the eigenvectors for this Markov matrix which not only

show the clustering of the nodes but actually rank the clusters using the associated

eigenvalues thus giving a name (the eigenvalue) for each cluster.

Our final recent development that is important for the current issues is that one can

generate two different networks from a table of values T

for entities (such as the

chemical elements in rows) with properties (such as density, boiling point, …) for

each element in columns. To do this we first normalize the table by finding the mean

and standard deviation of each column and then rewrite each column value as the

number of standard deviations (represented by the table value), divided by the mean

for that column, away from the norm. This process also removes any units that are

present as the results are dimensionless. We then define a network C

among the n

entities (here the elements listed in rows) as the exp of the negative of the sum of the

squares of the differences between T

and T

thus

= exp-

- T

)

. This gives a maximum connectivity of ‘1’ if the values are

the same and a connection of ‘0’ if they are far apart as would be required for the

definition of a network. We form a similar network among the properties for that

table. One then, as before, adjusts the diagonal to be the negative of the sum of all

terms in that column to give a new C, forms the Markov matrix M(a) = exp (aC) and

finds the eigenvectors and eigenvalues for M to reveal the associated clustering. The

rationale for how this works can be understood when the Markov matrix is viewed as

representing the dynamical flow of an invisible conserved substance among the

nodes. This methodology includes and generalizes the known methodology with the

Lagrange matrix for a network.

7.3 User-data Type Networks

Users (using the PIN#), can each be linked to (a) unit id (UID) hash values of the

results of their calculations, as well as to (b) the table, row, and column names of each

value. These linkages can be supplemented with linkages of each user to those

universal constants that occur in the expressions which they evaluate. The resulting

network links users to (a) concepts such as thermal conductivity, (b) substances such

as silver alloys, and (c) core constants such as the triple point of methane, the

Boltzmann constant, Planks constant, or the neutron mass. The expansion of this

network in different powers, giving the different degrees of separation, can then link

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

users via their computational profiles, (the user i x user j component of C

) as well as

linkages among substances, metadata tags, and constants. The clustering revealed in

different levels of such expansions then reveals groups of users with linkages that are

connected by common computational concepts. Users working on particular domains

of pharmaceuticals and methodologies are thus identified as clusters as well as groups

of astrophysicists that are utilizing certain data and models. At that same time, the

clustering can identify links among specific substances, models, and methodologies.

Our current research is exploring such networks and clusters as the underlying

metanumber usage expands.

7.4 Table Generated Networks among Entities and also among

Properties

The methodology for converting a table to a network among row items or among

column items was briefly discussed above. We are currently exploring the clusters

and network analysis that can be generated from the tables of standardized

metanumber values. We have done this for the elements table which was very

revealing as it displayed many of the known similarities among elements. The cluster

of iron, cobolt and nickel was very clear as well as other standard clusters of

elements. We are currently analyzing a table on the properties of pesticides and we

have just obtained a table of 56 nutrients for 8600 natural and processed foods. The

study of clustering in foods based upon their nutrient and chemical properties as well

as the clustering among the properties themselves will be reported as available on the

www.metanumber.com web site. As usage of the metanumber system expands, we

will also report the results of clustering among similar scientific investigations. These

results are expected by the end of August 2015.

7.5 Multiuser Collaboration Application

Often with more complex computations and multi-tier problems, it is useful for a

number of engineers, scientists, students, or business workers to collaborate on a

problem. This requires that comments be shared as explanatory of the work that is in

progress as well as questions and responses to others in the collaboration. This is even

true for a user who wishes to document his or her own work. The metanumber

application supports documenting text which is archived as an entry just like an

expression that is to be evaluated. All that is necessary is to enter a “#” as the first

character (similar to the method of entering a remark or comment line in python or

other languages). When the “#” is seen, then all processing is bypassed and all text up

to the end of that entry (cr lf) is archived as a string. Then when a user’s past history

is exported or read or shared, then these text entries are seen correctly positioned

among the computations giving explanations or recording ones technique. The

collaboration part is achieved by entering a command {subject = ‘some name’|PW}

where ‘some name is the name of the subject to be shred. A file is created with that

name (in lower case with white space removed and with the attached password. The

creator of the subject must then share the name and password (if any) with users in a

closed group. The subject stays active until the end of the session or until one enters

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports

{subject = }. While the subject is active, each user with such an active subject has

each line that is entered to be written to that new (subject name) file in the form:

UserPIN, Seq#. This is all that is needed in the shared file because each user can then

open that file to read only all of the entries from other in the group. More information

will be available from www.metanumber.com help screens.

8 Conclusions

The use of these algorithms with the approximately 800 units and fundamental

constants, can support a standardization of all numerical data. This metanumber

environment also presents all data in human and machine readable formats and

satisfies the listed set of 10 essential requirements. The resulting system provides a

vast saving of time, costs, and a removal of associated errors by supporting the

instantaneous use of data without preprocessing. This system can support new levels

of artificial intelligence and improved human interaction. It can also support new

methods for the creation of novel networks [9] in numerical data that in turn can

support new methods of cluster analysis [10].

References

1. Johnson, Joseph E., 2009, Dimensional Analysis, Primary Constants, Numerical

Uncertainty and MetaData Software”, American Physical Society AAPT Meeting, USC

Columbia SC

2. Leibigot, Eric O., 2014, A Python Package for Calculations with Uncertainties,

http://pythonhosted.org/uncertainties/.

3. Johnson, Joseph E., 2013, The Problem with Numbers – MetaNumbers – A Proposed

Standard for Integrating Units, Uncertainty, and MetaData with Numerical Values, USC

Physics Colloquium

4. Johnson, Joseph E., 2014, New Software Developed for Interdisciplinary Data Sharing and

Computation: Units, Uncertainty, & Metadata, USC School of the Earth, Ocean, and

Environment Colloquium

5. Johnson, Joseph E. 1985 US Registered Copyrights TXu 149-239, TXu 160-303, & TXu

180-520

6. Johnson, Joseph E, Ponci, F. 2008 Bittor Approach to the Representation and Propagation

of Uncertainty in Measurement, AMUEM 2008 International Workshop on Advanced

Methods for Uncertainty Estimation in Measurement, Sardagna, Trento Italy

7. Johnson, Joseph E., 2006 Apparatus and Method for Handling Logical and Numerical

Uncertainty Utilizing Novel Underlying Precepts US Patent 6,996,552 B2.

8. Johnson, Joseph E. 1985, Markov-Type Lie Groups in GL(n,R) Journal of Mathematical

Physics. 26 (2) 252-257

9. Johnson, Joseph E. 2005 Networks, Markov Lie Monoids, and Generalized Entropy,

Computer Networks Security, Third International Workshop on Mathematical Methods,

Models, and Architectures for Computer Network Security, St. Petersburg, Russia,

Proceedings, 129-135US

10. Johnson, Joseph E. 2012 Methods and Systems for Determining Entropy Metrics for

Networks US Patent 8271412

11. Johnson, Joseph E, & Cambell, William 2014, A Mathematical Foundation for Networks

with Cluster Identification, KDIR Conference Rome Italy

A Numerical Data Standard Joining Units, Numerical Accuracy and Full Metadata with Numerical Values

12. Johnson, Joseph E. 2014, A Numeric Data-Metadata Standard Joining Units, Numerical

Uncertainty, and Full Metadata to Numerical Values, EOS KDIR Conference Rome Italy

EPS Rome 2014 2014 - European Project Space on Computational Intelligence, Knowledge Discovery and Systems Engineering for Health

and Sports
