Plan-belief Revision in Jason

Andreas Schmidt Jensen and Jørgen Villadsen

DTU Compute - Algorithms, Logic and Graphs Section, Department of Applied Mathematics and Computer Science,

Technical University of Denmark, Richard Petersens Plads, Building 324, DK-2800 Kongens Lyngby, Denmark

Keywords:

AgentSpeak, Jason, Plan-belief Revision.

Abstract:

When information is shared between agents of unknown reliability, it is possible that their belief bases become

inconsistent. In such cases, the belief base must be revised to restore consistency, so that the agent is able to

reason. In some cases the inconsistent information may be due to use of incorrect plans. We extend work by

Alechina et al. to revise belief bases in which plans can be dynamically added and removed. We present an

implementation of the algorithm in the AgentSpeak implementation Jason.

1 INTRODUCTION

Agents receive information from different more or

less reliable sources. This information leads to new

information by the use of so-called declarative rule

plans. When information is shared between many

sources it is likely that some of this information is

inconsistent, which could result in even more incon-

sistent information when plans are executed. Further-

more, plans could be wrong, meaning that derived in-

formation might not hold. In such situations the agent

needs to be able to revise its beliefs to maintain con-

sistency. This process is called belief revision and de-

ﬁnes three operators: expansion, contraction and re-

vision. The details of the operators will be explained

later.

There are two main approaches to belief revi-

sion: AGM (short for Alchourron, G¨ardenfors and

Makinson) style belief revision (Alchourron et al.,

1985) and reason-maintenance style belief revision

(Doyle, 1977). AGM style belief revision requires

that changes to a belief base is as small as possi-

ble, where as reason-maintenance style belief revision

tracks how beliefs justify each other, using this infor-

mation to render inconsistent beliefs underivable.

In (Nguyen, 2009) the algorithm for literals was

extended to include contraction by rules. Our aim is

to show practical uses of the algorithm. Furthermore,

our focus is on situations where plans are exchanged

or derived.

We consider reason-maintenance belief revisionin

the implementation of AgentSpeak called Jason. Re-

vision of literals in Jason has been considered before

(Alechina et al., 2006a). We show how this can be

extended to include revision of plans as well.

The paper is organised as follows. In section 2 we

brieﬂy introduce Jason. We motivate the need for re-

vision of plans and beliefs in section 3. In section 4

we describe belief revision for both beliefs and plans.

Section 5 describes how belief revision can be imple-

mented in Jason. In section 6 we give an example

of how belief revision can maintain consistency in an

agent’s belief base. Finally we conclude our work by

summarising the contribution and introducing direc-

tions of future work.

2 JASON

We provide an overview of the Jason interpreter by

introducing how to program multi-agent system using

it, however we will not go into details with all parts of

the system. The overview should give a basis for un-

derstanding simple systems using Jason. A thorough

description of Jason is found in (Bordini et al., 2007).

The language of Jason, AgentSpeak, is a Prolog-

like logic programming language which allows the

developer to create a plan library for the agent. A

plan in AgentSpeak is basically of the form

+triggering event : context <- body.

Roughly speaking, if an event matches a trigger, the

context is matched with the current state of the agent.

If the contextmatches the current state, the body is ex-

ecuted; otherwise the engine continues to match con-

texts of plans with the same trigger. If no plan is ap-

plicable, the event fails.

182

Jensen A. and Villadsen J..

Plan-belief Revision in Jason.

DOI: 10.5220/0005221101820189

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence (ICAART-2015), pages 182-189

ISBN: 978-989-758-073-4

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

The fact that AgentSpeak is a logic programming

language allows one to transfer certain speciﬁcations

written in logical formulas of a multi-agent system

to an implementation written in Jason. For instance,

part of a plan for a vacuum cleaner agent [9] is shown

below:

+!cleaning : in(X,Y) & dirt(X,Y)

<- do(suck).

The plan is triggered by the goal

!cleaning

, so if the

vacuum cleaner is in a “cleaning state”, this trigger-

ing event would be applicable. The context speciﬁes

that this plan is relevant if the agent currently is some-

where in the environment which is dirty. If the con-

text can be uniﬁed with beliefs from the belief base of

the agent, it will perform the body, which in this case

means that it will perform the action

do(suck)

. How-

ever, as mentioned it is quite possible to have several

plans for the same triggering event if those plans have

different contexts:

+!cleaning : in(X,Y) & dirt(X+1,Y)

<- do(right).

This plan will then be applicable if the agent has per-

ceived dirt in an area to the right of its current area. In

that case, it will perform the action

do(right)

3 CASE STUDY

We present a scenario in which inconsistency arise as

a result of both exchange of beliefs and plans. An

agent is on a mission to retrieve a treasure. Its main

goal is achieved by ﬁrst ﬁnding the treasure and then

retrieving it. Finding the treasure can be achieved by

conducting a search or by asking other agents for the

location. The agent knows that it should dig for the

treasure when it has found a plausible location:

+at(X) <- +dig(X).

Consider the following situation (

refers to the

fact that beliefs are revealed over time). We write

⊳

a[Ag

] when Ag

learns a from Ag

∼

de-

notes strong negation in Jason.

broadcasts a request for the treasure location.

#22

⊳

at(a)[Ag

]

#28

⊳

∼

at(a)[Ag

]

#45

⊳

∼

at(b)[Ag

]

The belief base of Ag

is now in an inconsistent

state (since it knows both at(a) and

∼

at(a)). Fur-

thermore, Ag

perceives a plausible location for trea-

sure (using its sensors), meaning it both knows at(b)

and

∼

at(b)

#35

⊳

at(b)[Ag

]

Even though the situations are a bit different (two

communicated beliefs versus a communicated belief

and a percept), we argue that in each pair, one lit-

eral should be removed; the treasure cannot both be

and not be at the same location. Intuitively, the agent

would want to discard

∼

at(b)[Ag

] since it may not

know whether Ag

is deceitful, but it trusts its own

sensors. However, since both beliefs about location a

are communicated, it is harder to decide which one to

keep. We will elaborate on this later in this paper.

Finally, Ag

, who does not know the location of

the treasure, believes that the treasure is found in a

tree, and shares a plan for retrieving it:

#59

⊳ {

+!get treasure : at(X) <-

+climb tree(X); +

∼

dig(X)

}[Ag

]

Following this plan could lead to a state where

both

dig(b)

and

∼

dig(b)

are in the belief base.

Clearly some kind of belief revision is needed. We

describe an approach which can be used to revise be-

liefs in the next sections.

4 BELIEF REVISION

We considertwo approachesfor belief revision: AGM

(Alchourron, G¨ardenfors and Makinson) style be-

lief revision (Alchourron et al., 1985) and reason-

maintenance style belief revision (Doyle, 1977). The

AGM approach requires that a revision of a belief

base removes as little as possible in order to obtain

consistency. This means that even though an agent

gives up believing P, it should not give up believing

things which were solely justiﬁed by P; unless they

are inconsistent with the rest of the belief base, in

which case they should be revised as well. In reason-

maintenance style belief revision, the agent must not

only give up P, but ensure that P is no longer deriv-

able from the remaining set of beliefs and rules. This

is realized by keeping track of dependencies between

beliefs, so that the reason for believingP can be traced

back to a set of foundational beliefs. One of these be-

liefs should then be removed, ensuring that P is no

longer derivable from the beliefs in the belief base.

In AGM belief revision the belief base is closed

under logical consequence. Three operators are de-

ﬁned: expansion, contraction and revision. Expan-

sion, K + A, which adds A to K and closes the result-

ing set under logical consequence. Contraction, K

−A

Believing both

at(a)

and

at(b)

could also be consid-

ered inconsistent, but that is out of scope for this paper.

Plan-beliefRevisioninJason

183

(contract by A), removes A from K and changes the

set K so that it no longer entails A. Revision, K

+A,

modiﬁes K to make it consistent with A before adding

A. If adding A to K is consistent with K, then the

revision operator is equal to the expansion operator.

In general there is no unique maximal set K

′

⊂ K

which does not imply A, so contraction and revision

cannot be deﬁned uniquely. The AGM theory charac-

terises the set of “rational” contraction and revision

operators by a set of postulates (Alchourron et al.,

1985). The postulates for contraction are:

−1) K

−A = Cn(K

−A)

(closure)

−2) K

−A ⊆ K

(inclusion)

−3) If A 6∈ K, then K

−A = K

(vacuity)

−4) If not ⊢ A, then A 6∈ K

−A

(success)

−5) If A ∈ K, then K ⊆ (K

−A) + A

(recovery)

−6) If Cn(A) = Cn(B), then K

−A = K

−B

(equivalence)

where Cn(K) denotes the closure of K under logical

consequence.

While the deﬁnition looks desirable, it seems to

only apply to idealised agents, since it requires that

the belief base is closed under logical consequence.

In order to be able to revise a belief base which

cannot be assumed to be closed under logical con-

sequence, we weaken the logic and language of the

agent, so that it corresponds to a typical rule-based

agent (Alechina et al., 2006b). This approach leads

to a polynomial time algorithm, which satisﬁes all of

the AGM postulates but K

−5, the recovery postulate.

The algorithm allows for both AGM and reasoning-

maintenance style belief revision.

In (Alechina et al., 2006b) the weakened logic is

called W. In the corresponding language, L

, a well-

formed formula is either a literal (P or ¬P) or a plan

∧ ···∧ P

→ Q).

The only rule is a generalised modus ponens

(GMP):

δ(P

), . . . , δ(P

) P

∧ ··· ∧ P

→ Q

δ(Q)

δ is a substitution function replacing all free vari-

ables with constants. The agent uses GMP and its

belief base to reason. When the rule is ﬁred, the

derived (ground) literal δ(Q) will be justiﬁed by

δ(P

), . . . , δ(P

4.1 Justifying Plans and Beliefs

A derived belief has in most previous work only been

justiﬁed by the beliefs used to derive it, but not the

plan that was ﬁred. A reason for this is that the plans

of an agent is usually a part of a plan library that

is assumed to be correct and unlikely to be modi-

ﬁed. However, as described in (Nguyen, 2009), this

is not always the case. In fact, even if a derived belief

(Q) turns out to be wrong, this should not necessarily

mean that any of the supporting beliefs (P

, .. . , P

) are

wrong; it may just be wrong to conclude Q from them

(i.e. the plan is incorrect). In this case it might be

better to remove the plan rather than removing P

make Q underivable. Otherwise, if the agent realizes

that P

is actually true and the plan was not removed,

Q can again be derived.

Giving up the assumption that plans are part of

a static library and will not be changed, means that

plans are now also beliefs. The belief base of an agent

will therefore consist of both literals and plans.

We can now deﬁne justiﬁcations. All formulas are

associated with one or more justiﬁcations. A justiﬁ-

cation consists of a supported formula and a support

list. The formula is supported by the formulas in the

support list. We write (A, [B C]), when A is supported

by B and C. A formula is independent, if it has a non-

inferential justiﬁcation (i.e. a percept, mental note or

communicated belief). In that case, the justiﬁcation

has an empty support list.

Each formula P is associated with a dependency

and justiﬁcation list. The dependency list for P con-

tains all justiﬁcations for P, i.e. all justiﬁcations

where P is the supported formula. The justiﬁcation

list for P contains all justiﬁcations where P is a mem-

ber of the support list. If we consider the belief base

to be a graph, each justiﬁcation then has exactly one

outgoing edge (to the formula it is supporting) and

zero or more incoming edges (from the formulas in

the support list). Non-inferential justiﬁcations will

have zero incoming edges.

Example 1. Consider an agent with a plan, P(x) →

Q(x), and the beliefs P(a) and P(b). The dependency

graph in ﬁgure 1(a) shows that all formulas in the be-

lief base are non-inferential.

Running the plans of the agent to quiescence (i.e.

applying the only plan to both P(a) and P(b)) yields

two new beliefs, Q(a) and Q(b). This is shown in

ﬁgure 1(b). If for instance ¬Q(b) is introduced and

we choose to contract by Q(b), we can use the rela-

tion between formulas to backtrack from Q(b) to the

formulas supporting it.

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

184

(P(X) → Q(x), []) P(x) → Q(x)

(P(a), []) P(a)

(P(b), []) P(b)

(a) Initial formulas and dependencies.

(P(X) → Q(x), [])(P(a), [])

P(x) → Q(x)

(P(b), [])

P(a) P(b)

(Q(a), [P(a), P(x) → Q(x)]) (Q(b), [P(b), P(x) → Q(x)])

Q(a) Q(b)

(b) After ﬁring plans to quiescence.

Figure 1: Dependency graph of an agent.

4.2 Contracting by Formulas

When contracting by a formula, we need to further re-

vise the belief base such that the formula is no longer

derivable. This requires us to not only remove the

justiﬁcations for the formula, but also contract by a

support from each justiﬁcation. We use the notion

w(s) for the least preferred member of a support list s

(Alechina et al., 2006b). This formula will be the for-

mula that is not preferred to any other formula in the

list, such that we will be prepared to give it up ﬁrst.

Algorithm 1 is similar to the contraction algo-

rithm given in (Alechina et al., 2006a; Alechina et al.,

2006b), with the main difference that a justiﬁcation

can have edges to plans as well as literals. This allows

us to track dependencies through plans and thereby

contract by them. The check within the ﬁrst loop cor-

responds to reason-maintenance style belief-revision.

If AGM style belief-revision is preferred, we do not

contract by C.

Algorithm 1: Contraction by formula A.

for all j = (C, s), where A ∈ s do

remove j from the graph

if C has no justiﬁcations then

contract(C)

end if

end for

for all j = (A,s) do

if s = [] then

remove j from the graph

else

contract(w(s))

end if

end for

remove A

The overall complexity of the algorithm given in

(Alechina et al., 2006b) is O(kr + n) where k is the

maximal number of supports in any support list, r is

the maximal number of justiﬁcations with non-empty

supports and n is the number of literals in the belief

base.

This does not change when contracting plans as

well. The upper bound for the ﬁrst loop is r(k + 2);

one constant time operation for the plan itself, one

for the formula asserted by the plan, and k operations

for the premises of the plan. The second loop has an

upper bound of n. The overall complexity is therefore

O(kr+ n).

In (Alechina et al., 2006b) it was shown that

the contraction algorithm satisﬁes AGM postulates

−1)–(K

−4) and (K

−6). (K

−5) is not satisﬁed,

since if B is supported by A and we contract by B,

then both A and B are removed. If we add B again, A

is not added as well.

4.3 Revision Using Preferred

Contractions

We need to elaborate on how to select candidates for

contraction. Ideally, the quality of a justiﬁed formula

should be somehow related to the formulas that sup-

ports it (Alechina et al., 2006b). We say that the pref-

erence of a formula with the justiﬁcations j

, .. . , j

is:

p(P) = max{qual( j

), . . . , qual( j

)}

Furthermore, the quality of a justiﬁcation j =

(Q, [P

, .. . , P

]) is the preference value of the least

preferred formula in its support list:

qual( j) = min{p(P

), . . . , p(P

)}

We write j = (Q, [P

, .. . , P

], n), when qual( j) = n.

It is now possible to order beliefs using a to-

tal preference order relation, , on a set of beliefs

(Nguyen, 2009). Given two beliefs, P and Q, we write

P  Q if Q is preferred over P. This is the case if

p(P) < p(Q). Furthermore, if p(P) = p(Q), we can

use other measures to determine a strict preference

relation, such as taking the age of a belief into consid-

eration.

The quality deﬁnition only holds for inferential

justiﬁcations. It is clear that non-inferential justiﬁ-

cations must have some kind of a priori quality. In

(Nguyen, 2009) the following order of independent

Plan-beliefRevisioninJason

185

beliefs is suggested:

Percept

> Mental note

> Built-in plan

> Communicated data

As we shall see, choosing different orderings may

lead to very different contraction results.

Example 2. Recall the situation from example 1.

Suppose we choose to contract by Q(b)

. All jus-

tiﬁcations which has Q(b) in their support list are

then removed. Q(b) does not support any beliefs,

so nothing happens. All justiﬁcations for Q(b)

must then be removed. There happens to be one:

(Q(b), [P(b), P(x) → Q(x)]).

In order to render Q(b) underivable, one of the

supports must be contracted as well. Depending on

which formula is preferred least, this gives the two

situations shown in ﬁgure 2.

We assume that P(a), P(b) are percepts and

P(x) → Q(x) is a built-in plan (i.e. not communicated

from another agent).

In ﬁgure 2(a) the literal P(b) has been removed. In

this case, the ordering of independent beliefs is Built-

in plan > Percept.

Figure 2(b) shows a setting where the plan P(x) →

Q(x) has been removed. In this case, the ordering of

independent beliefs is Percept > Built-in plan.

The example shows that different preference re-

lations result in very different contraction results. In

some cases plans might generally be preferred to lit-

erals, while in other cases we might want to prefer

communicated beliefs the most. It is difﬁcult to de-

cide when one preference ordering is better than an-

other, since it depends on many factors such as the

reliability of the agents and correctness of their plans.

Algorithm 2: Revision by A.

add A to belief base

while belief base contains a pair (B, ¬B) do

contract(w(B, ¬B))

end while

Using the preferred contractions, we can now de-

ﬁne the revision operation (algorithm 2). In (Alechina

et al., 2006b) the revision operator and the basic AGM

postulates for it are described. It is furthermoreshown

that the operator satisﬁes ﬁve of the six postulates.

A ∈ K

+A is not satisﬁed since if we add A and use

it to derive B, but we already have ¬B in the belief

We could do this if, for instance, the agent perceives

¬Q(b).

base, then if p(B) < p(¬B) we would contract by B

and ﬁnally remove A.

4.4 Belief Revision in Jason

In Jason plans will not always be of the form required

by L

. When considering belief revision, we there-

fore only consider so-called declarative rule plans

(DRP), which are plans of the form

+t : l

& ... & l

← g

& ... & g

where t is a triggering event, l

& ... & l

is the con-

text, which must be a conjunction of literals and ﬁ-

nally the plan-body, which contains one or more be-

lief additions, g

& ... & g

. If the triggering event

is a belief addition event, then it will support each g

together with the context.

Given a DRP:

+t : l

& ... & l

← g

& ... & g

where t is a belief addition event, it is straightforward

to show its relation to GMP:

(t ∧ l

∧ . . . l

→ g

) ∧ ··· ∧ (t ∧ l

∧ . . .l

→ g

)

If t is not a belief addition event it is not included in

the antecedent of each implication.

When considering plans we allow g

to be the def-

inition of a plan, allowing us to add new plans to the

belief base. g

can then either be the addition of a

literal (+a, +

∼

a) or the addition of a plan, using the

internal action

.add plan

If a single g

is contracted, all other g

that were

derived in the same plan may very well be contracted

as well, assuming they are not justiﬁed by any other

plans. This could lead to situations where having a

single contradiction can lead to a much smaller belief

base after contraction.

If we contract by g

, g

is no longer re-derivable

from the set of plans used so far. This means that the

agent could have a plan +t : l

& ... & l

← g

that

will not be removed, even though it could be used to

derive g

. This is a drawback of using belief revision

in a non-quiescent setting.

5 IMPLEMENTATION IN JASON

We implement belief revision in Jason by extending

the buf (belief update function) and brf (belief revi-

sion function) methods of the agent (Alechina et al.,

2006a). The belief update function updates the be-

lief base with everything that is currently perceived

in the environment and removes anything in the be-

lief base that is no longer perceived. In other words,

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

186

(P(X) → Q(x), [])(P(a), [])

P(x) → Q(x)P(a)

(Q(a), [P(a), P(x) → Q(x)])

Q(a)

(a) Removing a literal.

(P(a), []) (P(b), [])

P(a) P(b)

(b) Removing a plan.

Figure 2: Contracting by Q(b) with different w(s).

it ensures that anything the agent can perceive in the

environment can be found in the agents belief base.

Since percepts are independent beliefs, we extend the

buf method to create a non-inferential justiﬁcation for

each percept. The standard implementation of the be-

lief revision function adds and removes beliefs from

the belief base. We extend it to revise beliefs using

the revision and contraction algorithms when plans

marked for revision are executed.

Beliefs and plans are annotated with their depen-

dency and justiﬁcation lists. Plans that are part of the

agents plan library a priori are independent and will

have non-inferential justiﬁcations. The belief

at(a)

with a non-inferential justiﬁcation of quality 3 is an-

notated as follows:

at(a)[dep([j(at(a),[],3)]),just([])]

This allows the programmer to create plans that only

applies to independentliterals, or to literals with a cer-

tain preference. For instance

+!goal : at(a)[dep(L)]

& .member(j(_,[],2), L)

<- ...

is only applicable if

at(a)

is an independent belief

with p(

at(a)

) = 2.

Communicated plans are – along with communi-

cated beliefs – also independent but have a lower pref-

erence. Using the internal action

.add plan

the agent

can add plans dynamically to its plan library. We cap-

ture this by extending the PlanLibrary so that all plans

that are added will be added with appropriate justiﬁ-

cations.

Adding a plan does not lead to an iteration of be-

lief revision. Remember that Jason does not run in a

quiescent setting, so the plan is not immediately ﬁred.

Therefore the plan could lead to inconsistency, but

this will only be discovered whenever it is actually

ﬁred.

We annotate plans that should be considered for

belief revision with

drp

(i.e. declarative rule plans).

@plan[drp] +!goal : p & q & r <- +s.

When this plan is chosen,

will be added to the belief

base. The revision algorithm will then be executed to

revise any inconsistent pairs of literals.

The justiﬁcation holds a support-list of type Lit-

eral, which in our case can be either LiteralImpl (be-

liefs) or Plan (declarative rule plans). Each justiﬁ-

cation has a quality – either assigned a priori (using

a preference ordering as described above) or when

propagating the quality.

Given the contraction and revision algorithms

above, the Jason agent can now revise its belief base

on-the-ﬂy. Whenever a relevant plan is chosen which

adds a belief A to the belief base, the brf method is

executed

, and it is checked whether an inconsistent

pair (B, ¬B) exists and should be revised.

The Jason platform also allows us to implement

the revision algorithm directly in the agent architec-

ture. We can then revise the belief base when a rea-

soning cycle is starting instead of revising during the

addition or deletion of a belief, meaning that incon-

sistent information will never exist at the beginning

of a reasoning cycle. Since we require belief-revised

plans to be annotated with DRP, this solution could

be relevant in a setting where it is difﬁcult to decide

exactly which plans could lead to inconsistency.

6 CASE STUDY — CONTINUED

We now consider the case study again. We choose the

following preference ordering of independent beliefs

and plans:

Percept

> Mental note

> Built-in plan

> Communicated data

Note that in Jason the brf method is always executed

when beliefs are added, but we ensure that the actual be-

lief revision only occurs when the executed plan is in fact a

DRP.

Plan-beliefRevisioninJason

187

For simplicity we give each inferential justiﬁca-

tion a numerical value representing their quality cor-

responding to the above ordering: 0 for communi-

cated data, 1 for built-in plans, 2 for mental notes and

3 for percepts.

The agent ﬁrst receives

at(a)

[Ag

] and

applies

+at(X) <- +dig(X)

, resulting in

dig(a)

. At this point the belief base is

consistent. The justiﬁcation for

dig(a)

(

dig(a)

, [

at(a)

+at(X) <- +dig(X)

], 0), since the

least preferred literal is

at(a)

(p(

at(a)

) = 0).

It then receives

∼

at(a)

[Ag

], which is added to

the belief base, but no plans apply. The agent now has

the following information:

Age Belief

R1 0

+at(X) <- +dig(X).

B1 22

at(a)

[Ag

]

B2 22

dig(a)

[Ag

]

B3 28

∼

at(a)

[Ag

]

This means that when B3 is added to the belief

base, the revision algorithm ﬁnds both

at(a)

[Ag

]

and

∼

at(a)

[Ag

]. The preference ordering is B1 

B3 even though p(B1) = p(B3) since B3 was

added after B1. Therefore the agent contracts by

at(a)

[Ag

], resulting in the removal of

dig(a)

well, since it depends on

at(a)

The agent perceives a plausible location, b, and

adds

at(b)

[Ag

] to its belief base. By applying R1 it

also adds

dig(b)

[Ag

]. It then receives

∼

at(b)

[Ag

]

rendering the belief base inconsistent again:

Age Belief

R1 0

+at(X) <- +dig(X).

B3 28

∼

at(a)

[Ag

]

B4 35

at(b)

[Ag

]

B5 35

dig(b)

[Ag

]

B6 44

∼

at(b)

[Ag

]

We have B6  B4 since p(B6) < p(B4) so the

agent will contract by

∼

at(b)

[Ag

The agent now receivesa plan for retrieving a trea-

sure located in a tree. It chooses to pursue this plan

immediately, adding the following information:

Age Belief

R2 49 (

+!get treasure : at(X) <-

+climb

tree(X);

∼

dig(X)

)[Ag

]

B7 52

climb tree(b)

[Ag

]

B8 52

∼

dig(b)

[Ag

]

Figure 3 shows the relation between the current

formulas in the agents belief base. We see that

p(B8) < p(B4), which means the agent will choose

to contract by

∼

dig(b)

[Ag

]. The agent will remove

B7, B8 and R2 and then has the following informa-

tion:

Age Belief

R1 0

+at(X) <- +dig(X).

B3 28

∼

at(a)

[Ag

]

B4 35

at(b)

[Ag

]

B5 35

dig(b)

[Ag

]

The agents belief base is again consistent.

The example shows how a belief base can become

inconsistent at any time and that it is relevant to con-

sider plans as well when revising. The algorithms we

have described can detect and remove inconsistency

in the belief base, and it should be evident by the

examples that the choice of preference ordering has

great impact on the contents of the belief base after a

revision has occurred.

7 CONCLUSIONS

We have successfully implemented revision of plans

and beliefs in the AgentSpeak implementation Jason.

The algorithm works in polynomial time, making it

useful in practice. Furthermore we have given an ex-

ample which shows the usefulness of revising both

plans and beliefs in an agent’s belief base.

We have built on the work presented in (Alechina

et al., 2006a; Alechina et al., 2006b; Nguyen, 2009)

by focusing on how plans can be added dynamically

(either by being exchanged or derived) and has shown

that this has practical use in Jason, because of its ex-

tensible nature.

We have shown that the choice of beliefs that

should be removed has great inﬂuence on the result

of a contraction, since reason-maintenance recurses

through the dependency-graph.

An interesting extension to the contraction algo-

rithm could be to allow non-inferential justiﬁcations

to have a dynamic quality, meaning that percepts or

built-in plans do not always have the same quality.

Furthermore, this paper has only looked at incon-

sistent pairs of the form (A, ¬A), but it would be in-

teresting to include means for discovering other types

of inconsistency, such as (dead(A), alive(A)).

Other recent work on approaches to inconsistency

handling in Jason and related systems should also be

considered (Alechina et al., 2008; Klapiscak and Bor-

dini, 2009; Villadsen, 2005; Fuzitaki et al., 2010;

Mascardi et al., 2011; Jensen and Villadsen, 2012;

Spurkeland et al., 2013).

ICAART2015-InternationalConferenceonAgentsandArtificialIntelligence

188

(R1, [], 3) (B4, [],3) (R2, [], 0)

R1 B4 R2

(B5, [R1,B4], 3)

(B7, [R2,B4], 0)

(B8, [R2,B4], 0)

Figure 3: The relation between the agents beliefs after receiving a new plan for retrieving the treasure.

REFERENCES

Alchourron, C. E., G¨ardenfors, P., and Makinson, D.

(1985). On the logic of theory change: Partial meet

contraction and revision functions. Journal of Sym-

bolic Logic, 50(2):510–530.

Alechina, N., Bordini, R. H., H¨ubner, J. F., Jago, M.,

and Logan, B. (2006a). Automating belief revision

for AgentSpeak. In Proceedings of the 4th Interna-

tional Conference on Declarative Agent Languages

and Technologies, DALT’06, pages 61–77. Springer.

Alechina, N., Jago, M., and Logan, B. (2006b). Resource-

bounded belief revision and contraction. In Proceed-

ings of the Third International Conference on Declar-

ative Agent Languages and Technologies, DALT’05,

pages 141–154. Springer.

Alechina, N., Jago, M., and Logan, B. (2008). Preference-

based belief revision for rule-based agents. Synthese,

165(1):159–177.

Bordini, R. H., Wooldridge, M., and H¨ubner, J. F. (2007).

Programming Multi-Agent Systems in AgentSpeak us-

ing Jason. John Wiley & Sons.

Doyle, J. (1977). Truth maintenance systems for prob-

lem solving. In Proceedings of the Fifth International

Joint Conference on Artiﬁcial Intelligence, IJCAI 77,

page 247.

Fuzitaki, C., Moreira, l., and Vieira, R. (2010). Onto-

logy reasoning in agent-oriented programming. In

da Rocha Costa, A., Vicari, R., and Tonidandel, F., ed-

itors, Advances in Artiﬁcial Intelligence - SBIA 2010,

volume 6404 of Lecture Notes in Computer Science,

pages 21–30. Springer.

Jensen, A. S. and Villadsen, J. (2012). Paraconsistent com-

putational logic. In Blackburn, P., Jørgensen, K. F.,

Jones, N., and Palmgren, E., editors, 8th Scandinavian

Logic Symposium, pages 59–61. Scandinavian Logic

Society.

Klapiscak, T. and Bordini, R. H. (2009). JASDL: A prac-

tical programming approach combining agent and se-

mantic web technologies. In Baldoni, M., Son, T. C.,

Riemsdijk, M. B., and Winikoff, M., editors, Declara-

tive Agent Languages and Technologies VI, pages 91–

110. Springer.

Mascardi, V., Ancona, D., Bordini, R. H., and Ricci, A.

(2011). CooL-AgentSpeak: Enhancing AgentSpeak-

DL agents with plan exchange and ontology services.

IEEE/WIC/ACM International Conference on Web In-

telligence and Intelligent Agent Technology, 2:109–

116.

Nguyen, H. H. (2009). Belief revision in a fact-rule agent’s

belief base. In Proceedings of the Third KES Inter-

national Symposium on Agent and Multi-Agent Sys-

tems: Technologies and Applications, KES-AMSTA

’09, pages 120–130. Springer.

Spurkeland, J., Jensen, A., and Villadsen, J. (2013). Belief

revision in the GOAL agent programming language.

ISRN Artiﬁcial Intelligence, 2013.

Villadsen, J. (2005). Supra-logic: Using transﬁnite type the-

ory with type variables for paraconsistency. Journal of

Applied Non-Classical Logics, 15(1):45–58.

Plan-beliefRevisioninJason

189
