A Structural and Content-based Approach for a Precise and Robust

Detection of Malicious PDF Files

Davide Maiorca, Davide Ariu, Igino Corona and Giorgio Giacinto

Department of Electrical and Electronic Engineering, University of Cagliari, Cagliari, Italy

Keywords:

PDF, Evasion, Adversarial Machine Learning, Malware, Javascript.

Abstract:

During the past years, malicious PDF ﬁles have become a serious threat for the security of modern computer

systems. They are characterized by a complex structure and their variety is considerably high. Several so-

lutions have been academically developed to mitigate such attacks. However, they leveraged on information

that were extracted from either only the structure or the content of the PDF ﬁle. This creates problems when

trying to detect non-Javascript or targeted attacks. In this paper, we present a novel machine learning system

for the automatic detection of malicious PDF documents. It extracts information from both the structure and

the content of the PDF ﬁle, and it features an advanced parsing mechanism. In this way, it is possible to detect

a wide variety of attacks, including non-Javascript and parsing-based ones. Moreover, with a careful choice of

the learning algorithm, our approach provides a signiﬁcantly higher accuracy compared to other static analysis

techniques, especially in the presence of adversarial malware manipulation.

1 INTRODUCTION

Malicious PDF ﬁles have become a well known threat

during the past years, and they still constitute a very

effective weapon for cybercriminals, as new exploits

have recently been released. This is due to the fact

that, in spite of the efforts of software vendors such

as Adobe, PDF software is often vulnerable to zero-

day attacks. In particular, such attacks exploit the in-

tegration of the PDF ﬁle format with third-party tech-

nologies (e.g., Javascript or Flash), thus making the

creation of ad-hoc patches a challenging task. More-

over, due to the architectural complexity of PDF ﬁles

and given the wide variety of code obfuscation tech-

niques employed by miscreants, it is hard for antivirus

vendors to provide protection against novel or even

known attacks (Symantec, 2014).

Attackers mainly adopt Javascript code to exploit

PDF vulnerabilities, by leveraging on well-known

techniques, such as Return Oriented Programming

and Heap Spraying (Buchanan et al., 2008; Ratana-

worabhan et al., 2009). However, there have been

cases in which ActionScript code has been employed.

For instance, CVE 2010-3654 exploits a vulnerability

in Adobe Flash Player using a “Just in Time Spray-

ing” approach (Bania, 2010). In order to evade detec-

tion, PDF attacks may also resort to advanced encryp-

tion methods for hiding malicious code or malicious

embedded ﬁles (Adobe, 2008).

Signature-based approaches adopted by current

anti-malware systems, based on heuristics or string

matching, are not able to cope with novel attacks,

and have proved to be weak against polymorphic

ones (Esparza, 2011). Aiming at addressing such

weaknesses, recent research works mainly focused on

two different directions: ﬁrst, they focused on de-

tecting malicious Javascript code within PDF ﬁles,

through both static and dynamic (behavioral) anal-

ysis (Cova et al., 2010; Laskov and

Srndi

c, 2011;

Tzermias et al., 2011). Then, they leveraged on the

external structure of the PDF ﬁle (i.e., PDF objects)

in order to detect malicious PDF ﬁles regardless of

the attack or exploit they carried (Maiorca et al.,

2012; Smutz and Stavrou, 2012;

Srndi

c and Laskov,

2013). The latter approaches have proved to be gen-

erally more effective than the ﬁrst ones, since they

also allowed for the detection of non-Javascript at-

tacks. However, further research showed that they

are extremely vulnerable against deliberate attacks

(Maiorca et al., 2013;

Srndic and Laskov, 2014). For

this reason, research has focused again on the detec-

tion of malicious Javascript code (Corona et al., 2014;

Liu et al., 2014) and on hardening security through the

adoption of a sandbox (Maass et al., 2014).

In this paper, we present a novel machine

learning-based approach to the detection of malicious

Maiorca D., Ariu D., Corona I. and Giacinto G..

A Structural and Content-based Approach for a Precise and Robust Detection of Malicious PDF Files.

DOI: 10.5220/0005264400270036

In Proceedings of the 1st International Conference on Information Systems Security and Privacy (ICISSP-2015), pages 27-36

ISBN: 978-989-758-081-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

PDF ﬁles that leverages on information extracted both

from the structure and the content of the PDF ﬁle.

On one hand, we represent the information about the

structure by analyzing: a) general properties of the

PDF ﬁle structure and b) structural properties of the

PDF objects in terms of keywords. On the other hand,

we analyze content-based information such as: a)

malformed objects, streams and codes, b) known vul-

nerabilities in Javascript code and c) embedded con-

tents such as other PDF ﬁles. To perform these oper-

ations, and to address parsing-related vulnerabilities

presented in previous works, we leverage on two well-

known tools for PDF analysis, namely, PeePDF

and

Origami

. Such approach allows for an extremely ac-

curate detection of PDF malware deployed in the wild

(including non-Javascript attacks and recent vulnera-

bilities) with very low false positives. At the same

time, with a careful choice of the learning algorithm

(whose role will be discussed in detail), it provides a

signiﬁcant improvement on detecting targeted attacks

in comparison to the other state of the art approaches.

Contributions

The contributions made by this work can be summa-

rized into four points:

• We develop a novel, machine learning based ap-

proach to the detection of malicious PDF ﬁles that

leverages on information extracted from both the

structure and the content of a PDF ﬁle;

• We experimentally evaluate the performances of

our system on a dataset that contains a wide num-

ber of PDF-related vulnerabilities. We compare

such performances to the ones of the most impor-

tant, publicly available tools;

• We evaluate the robustness of our system against

automatic attacks and evasion attempts that have

proved to be extremely effective against public

available tools;

• We discuss the limits of our system and the role of

the learning algorithm in assessing its robustness.

In relation to that, we provide research guidelines

for future work.

Paper Structure

This paper is divided into six Sections beyond this

one. Section 2 provides an insight into the struc-

ture of the PDF ﬁles. Section 3 presents related

works on malicious PDF detection. Section 4 de-

scribes our methodology to the detection of malicious

http://eternal-todo.com/tools/peepdf-pdf-analysis-tool

http://esec-lab.sogeti.com/pages/origami

PDFs. Section 5 provides the experimental results.

Section 6 discusses the limits of our approach and

provides guidelines for future research work. Sec-

tion 7 provides conclusive remarks.

2 PDF FILE FORMAT

A PDF ﬁle is a hierarchy of objects logically con-

nected to each other. For the sake of the following

discussion, we will model the PDF ﬁle structure as

composed by four parts (Adobe, 2006):

• header: a line which gives information on the PDF

version used by the ﬁle.

• body: it is the main portion of the ﬁle, and con-

tains all the PDF objects.

• cross-reference table: it indicates the position of

every indirect

object in memory.

• trailer: it gives relevant information about the root

object and number of revisions made to the docu-

ment.

Typically, a PDF ﬁle presents, in its body, a se-

quence of indirect objects, described by the expres-

sion ObjectNumber 0 obj. Each object consists of a

dictionary which deﬁnes, through a sequence of cou-

pled keywords (also called name objects) represented

by a /, the characteristics of the data inside the ob-

ject itself or in one of its references (e.g., in case of

an attack, the presence of malicious code through the

presence of the keyword /Javascript). Optionally,

an object might also include a stream, which contains

the object data that will be parsed by the reader and

visualized by the user (e.g., in case of an attack, the

code whose presence is signaled by the dictionary).

For more information on the PDF structure, please

check the PDF Reference (Adobe, 2006).

3 RELATED WORK

First approaches to malicious PDF detection proposed

static analysis on the raw (byte-level) document, by

means of n-gram analysis (Li et al., 2007; Shaﬁq

et al., 2008) and decision trees (Tabish et al., 2009).

However, these approaches were not really tailored

to PDF ﬁles, as they mainly targeted different ﬁle

formats, such as DOC, EXE, etc. Whereas such a

raw analysis may detect many malware “implemen-

tations” besides malicious PDFs, it may be quite easy

In the PDF language, indirect means that the object can

be referenced by other objects.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

to evade it either by using modern obfuscation tech-

niques, such as AES encryption (Adobe, 2008), or

by resorting to different techniques to exploit vulner-

abilities, such as Return Oriented Programming, Heap

Spraying or JIT Spraying (Buchanan et al., 2008;

Ratanaworabhan et al., 2009; Bania, 2010).

To address the increasing complexity of PDF mal-

ware, subsequent works focused on the analysis of

embedded Javascript code. A number of solutions for

the detection of malicious Javascript code have been

proposed in the context of web security. For instance,

Jsand (Cova et al., 2010), Cujo (Rieck et al., 2010),

Zozzle (Curtsinger et al., 2011), Prophiler (Canali

et al., 2011) are well-known tools for the dynamic and

static analysis of Javascript code. These tools are of-

ten employed by systems designed to identify threats

embedded in different document formats.

Wepawet

, a framework for the analysis of web-

based threats, relies on JSand to analyze Javascript

code within PDF ﬁles. Jsand (Cova et al., 2010)

adopts HtmlUnit

, a Java-based browser simulator,

and Mozilla’s Rhino

to extract behavioral features

related to the execution of Javascript code. A statisti-

cal classiﬁer is trained on a representative number of

samples containing benign code, and malicious code

is spotted by detecting anomalous patterns (i.e., codes

that are signiﬁcantly different to the ones the system

has been trained with).

A similar approach is adopted by MalOffice (En-

gleberth et al., 2009). MalOffice uses pdftk

to ex-

tract Javascript code, and CWSandbox (Willems et al.,

2007) to analyze the code behavior: Classiﬁcation is

carried out by a set of rules (CWSandbox has also been

used to classify general malware behavior (Rieck

et al., 2008)). MDScan (Tzermias et al., 2011) fol-

lows a different approach as malicious behavior is de-

tected through Nemu, a tool able to intercept memory-

injected shellcode. A very similar idea, but with

a different implementation, has been developed in

ShellOS (Snow et al., 2011).

Dynamic detection by executing Javascript code

in a virtual environment may be time consuming and

computationally expensive, and it is prone to eva-

sion by a clever attacker that leverages on differ-

ent implementations of the JavaScript engine used

by the PDF reader and by the code analyzer (Tzer-

mias et al., 2011). To reduce computational costs,

PJScan (Laskov and

Srndi

c, 2011) proposed a fully

static lexical analysis of Javascript code by training a

statistical classiﬁer on malicious ﬁles.

http://wepawet.iseclab.org/index.php

http://htmlunit.sourceforge.net

http://www.mozilla.org/rhino

http://www.pdﬂabs.com/tools/pdftk-the-pdf-toolkit

In 2012 and 2013, malicious PDF detectors that

base their detection on the structure of the PDF ﬁle,

without analyzing the embedded code, have been de-

veloped. To distinguish them from the previous ap-

proaches, we call them structural systems (Maiorca

et al., 2012; Smutz and Stavrou, 2012;

Srndi

c and

Laskov, 2013). Among these, PDFRate

is the only

one publicly available. It is based on 202 features

extracted from both document metadata and structure

and it uses random forests as classiﬁcation algorithm.

All these systems have been motivated by the need to

detect PDF malware that also featured different con-

tents than Javascript, such as Flash. The analysis of

the PDF structure allowed for a wider detection rate in

comparison to previous systems, without having the

need of looking for embedded code or trying to de-

obfuscate it. However, recent works (Maiorca et al.,

2013;

Srndic and Laskov, 2014) showed that such sys-

tems suffer from parsing problems and might be eas-

ily attackable.

Because of the evident weaknesses of structural

systems, research focused again on detecting mali-

cious Javascript code. New approaches either resorted

to discriminant API analysis (Corona et al., 2014) or

code instrumentation (Liu et al., 2014). An approach

to harden security when opening a PDF ﬁle by lever-

aging on sandboxing has also been proposed (Maass

et al., 2014).

4 PROPOSED DETECTION

APPROACH

As stated in Section 3, the vast majority of recent

works on malicious PDF detection focused on the

analysis of either the Javascript code or the PDF ﬁle

structure (structural systems). Such information is

usually processed by a machine learning system, i.e.,

it is converted into a vector of numbers (features) and

sent to a mathematical function (classiﬁer or learner),

whose parameters have been tuned through a process

called training. Such training is performed by using

samples whose classes (benign or malicious) were al-

ready known.

However, systems developed until now suffer

from several weaknesses: on one hand, systems fo-

cused on Javascript cannot address other vulnerabili-

ties, such as the ones based on Flash (Maiorca et al.,

2012). On the other hand, structural systems resort

to information that can be easily manipulated by an

attacker in order to deceive the classiﬁer (Smutz and

Stavrou, 2012; Maiorca et al., 2013).

http://pdfrate.com/

AStructuralandContent-basedApproachforaPreciseandRobustDetectionofMaliciousPDFFiles

To overcome these weaknesses, we propose a new

machine learning-based approach, which extracts in-

formation both from the structure of the PDF ﬁle and

from its content. This method is purely static, as it

does not involve any dynamic simulation performed

by a PDF rendering engine.

Figure 1 shows the high-level architecture of our

system. To extract information, we created a parser

Classifier Classifier

Feature Extractor

PeePDF

Parser

Origami

Content

Information

Object

Structure

General

Structure

Malicious Benign

Feature Vector ( [x1, x2...] )

Extraction of Embedded PDF

Figure 1: High-level architecture of our system.

that leverages on PeePDF and Origami.

These tools perform an in-depth analysis of

PDF ﬁles to highlight known exploits, suspicious

objects, or functions that are known to be po-

tentially malicious (for example, see vulnerability

CVE-2008-2992). Moreover, they will extract and an-

alyze as a separate sample any embedded PDF ﬁle.

We adopted these two tools as they provide a reli-

able parsing process compared to other ones, such

as PdfID, which naively analyzes the PDF ﬁle ignor-

ing its structural properties, thus allowing attackers to

perform easy manipulations (Maiorca et al., 2013).

Each PDF document will be represented by a vec-

tor composed by: a) 8 features related to the general

structure of the ﬁle, in terms of number of objects,

streams, etc.; b) A variable number of features (typ-

ically not more than 120) related to the structure of

the PDF objects, represented by the occurrence of

the most frequent keywords in the training dataset (its

number is variable as it depends on the training data);

c) 7 features related to the content of the PDF objects.

In particular, the objects are scanned for known vul-

nerabilities, malformed objects, etc.

The remaining of this Section is organized as fol-

lows. Section 4.1 provides a detailed description of

all the features that we extract to discriminate between

benign and malicious PDF ﬁles. Section 4.2 describes

and motivates the adopted classiﬁcation algorithm.

4.1 Features

General Structure

We extract 8 structural features, which contain infor-

mation about: i) The size of the ﬁle; ii) The num-

ber of versions of the ﬁle; iii) The number of indi-

rect objects; iv) The number of streams; v) The num-

ber of compressed objects; vi) The number of object

streams

; vii) The number of X-ref streams

; viii)

The number of objects containing Javascript.

While these features may be considered as weakly

discriminant when singularly used, together they pro-

vide a good overview of the whole PDF structure. For

instance, from our experience, the size of malicious

PDFs (and their number of objects/streams) is often

smaller than the one of legitimate PDFs. This is some-

what reasonable, as malicious PDFs may not contain

text, and the smaller is the ﬁle size, the smaller is the

time needed to infect new victims. Likewise, object

and X-ref streams are usually employed to conceal

malicious objects inside the ﬁle, and compressed ob-

jects can include embedded contents, such as script-

ing code or other EXE/PDF ﬁles.

Object Structure

We extract the occurrence of the most characteris-

tic keywords deﬁned in the PDF language. With the

term characteristic, we refer to keywords that have

appeared in our training dataset D with a frequency

that is higher of a threshold t. Other works, such as

(

Srndi

c and Laskov, 2013), extracted a similar thresh-

old by arbitrarily deciding a reasonable value for it.

Our aim, though, is obtaining t in a more systematic

way, so that it better relates to the data in D. In order

to do so, we:

1. Split D into D

and D

, where the ﬁrst one only

contains malicious ﬁles and the second one only

legitimate ﬁles. Obviously, D = D

∪ D

;

2. For each of the two datasets, and for each keyword

of the PDF language, we deﬁne: f

= F(k

where f

is the number of samples of each dataset

in which k

appears at least once;

3. For each dataset, we ﬁnd the frequency threshold

value t by means of a k-means clustering algo-

Streams containing other objects.

A new typology of cross-reference table introduced by

recent PDF speciﬁcation.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

rithm (MacQueen, 1967) with k=2 clusters, com-

puted through an euclidean distance. In order to

establish with more precision the sizes of the two

clusters, the algorithm has been tested ﬁve times

with different starting points

. In this way, key-

words will be split into two groups basing on their

value. Thus, for each dataset, we get the set of

keywords K deﬁned as: K = {(k

)| f

> t} There-

fore, for D

we will obtain a set K

and for D

set K

;

4. We will get the ﬁnal set of characteristic keywords

by: K

= K

∪ K

The number of keywords in K

obviously depends

on the training data used and on the result of the clus-

tering. The reason why we considered characteristic

keywords, along with their occurrence, is that their

presence is often associated to speciﬁc actions per-

formed by the ﬁle. For example /Font is a charac-

teristic keyword in benign ﬁles. This is because it is

usually associated to the presence of a speciﬁc font in

the ﬁle. If this keyword occurs a lot inside a sample,

it means that the PDF renderer might display differ-

ent fonts, which is an expected behavior in legitimate

samples. Selecting the most characteristic keywords

also helps to exclude other ones that do not respect

the PDF language speciﬁcations. Including the occur-

rence of non-characteristic or extraneous keywords in

the feature set might allow an attacker to easily ma-

nipulate the PDF features without altering its func-

tionality, thus increasing the possibility of an evasion

of the detection system.

Content-based Properties

We verify if a PDF ﬁle is accepted or rejected by ei-

ther PeePDF or Origami. There are two features asso-

ciated to this information, one for PeePDF and one for

Origami. The two tools perform a non-forced scan

If one of these tools rejects the ﬁles, it means that

their might be suspicious elements such as the exe-

cution of code, malformed or incorrect x-ref tables,

corrupted headers, etc. It is worth noting that such

elements might as well be present in legitimate sam-

ples. Therefore, PeePDF and Origami cannot be used

as detectors of maliciousness, as they would generate

too many false positives.

There are also 5 features that represent informa-

tion about malformed a) objects (for example, when

The seed value has been set to the de-

fault value indicated here: http://weka. source-

forge.net/doc.dev/weka/clusterers/SimpleKMeans.html.

A scan that is stopped if it ﬁnds anomalies in the ﬁles.

This deﬁnition is valid for PeePDF; in Origami, such scan

is deﬁned as standard mode.

scripting codes are entirely injected inside a PDF dic-

tionary), b) streams, c) actions (using keywords not

proper of the PDF language), d) code (for example,

using functions related to known vulnerabilities) and

e) compression ﬁlters (the way in which data like im-

ages or code are compressed in the ﬁle to reduce the

ﬁle size). This is done as malicious PDFs often in-

clude objects that do not strictly follow the PDF lan-

guage speciﬁcations. However, such objects are nev-

ertheless parsed by the reader, which is quite ﬂexible

from this respect.

4.2 Classiﬁcation

We adopted a supervised learning approach, i.e., both

benign and malicious documents are used for training,

and we resorted to decision trees classiﬁers (Quin-

lan, 1996). Decision tree are capable of natively han-

dling the heterogeneous nature of features described

in Section 4.1, and they have exhibited excellent clas-

siﬁcation performances in previous works (Maiorca

et al., 2012; Smutz and Stavrou, 2012; Corona et al.,

2014). In particular, we decided to resort to the

Adaptive Boosting (AdaBoost) algorithm (Freund and

Schapire, 1995). Such algorithm linearly combines

a set of weak learners, each of them with a speciﬁc

weight, to produce a more accurate classiﬁer. As

weak learner, we deﬁne a low-complexity classiﬁ-

cation algorithm that usually yields results that are

better than random guessing. The weights of each

weak learner depend, obviously, on the ones of the

training instances with which each learner is trained.

Weak learners can be, for example, decision stumps

(i.e., decision trees with only one leaf) or simple de-

cision trees (J48). Choosing an ensemble of trees

also allows for more robustness against evasion at-

tacks compared to a single tree, as an attacker has to

gather knowledge of multiple tree-models in order to

perform an optimal attack (i.e., getting to know which

features are most discriminant for each tree of the en-

semble).

5 EXPERIMENTAL EVALUATION

In this Section, we ﬁrst describe the dataset employed

in our experiments, as well as the training and test

methodology for the performance evaluation. Then,

we provide two experiments. The ﬁrst one compares

the general performances of our approach, in terms

of detection rate and false positives, with the ones of

the other state of the art research. In particular, we

refer to PJScan, Wepawet, and PDFRate, as they can

be considered the three most important and publicly

AStructuralandContent-basedApproachforaPreciseandRobustDetectionofMaliciousPDFFiles

available research tools for malicious PDF ﬁles de-

tection. The second experiment focuses on testing our

approach against reverse mimicry attacks (Maiorca

et al., 2013), which have proved to be tremendously

effective structural systems. In order to concretely

validate our approach, we produce a high number of

real, working attack samples, and we test them against

our approach. Finally, we also provide a performance

comparison with the other state of the art tools.

Dataset

We conducted our experiments using real and up-to-

date samples of both benign and malicious PDFs in-

the-wild. Overall, we collected 11,138 unique mali-

cious samples from Contagio

, a well-known rep-

utable repository which provides information about

latest PDF attacks and vulnerabilities. Moreover, we

randomly collected 9,890 samples of benign PDFs,

by means of the public Yahoo search engine API

(http://search.yahoo.com). We kept a balance be-

tween malicious and benign ﬁles for the purpose of

supervised training.

For the second experiment, we created 500 at-

tack samples variants for each of the three attacks de-

scribed in our previous work (Maiorca et al., 2013)

Javascript Injection, EXE Embedding and PDF Em-

bedding. Hence, in total we generated 1500 real at-

tack samples.

Training and Test Methodology

For the ﬁrst experiment, in order to thoroughly eval-

uate the generalization capability of our tool, we ran-

domly split our data into two disjunct datasets:

• A training set composed by 11,944 ﬁles, sub-

divided into 5,993 malicious and 5,951 benign

ﬁles. This set is used to train the classiﬁer.

• A test set composed by 9,084 ﬁles, subdivided

into 5,145 malicious and 3,939 benign ﬁles. This

set is used to evaluate the accuracy of the classi-

ﬁer.

This process is repeated three times: we compute the

mean and the standard deviation of the True Positives

(TP) and False Positives (FP), over such three repli-

cas. As a unique measure of the classiﬁcation quality

we also employ the so-called Matthews Correlation

Coefﬁcient (MCC) (Baldi et al., 2000), deﬁned as:

MCC =

T P · T N − FP · FN

(T P + FP)(T P + FN)(TN +FP)(T N + FN)

http://contagiodump.blogspot.it

where T N and FN refer to the number of true and

false negatives, respectively.

In our experiments, we trained an AdaBoost en-

semble of J48 trees, whose parameters have been op-

timized with a 10-fold cross validation (Freund and

Schapire, 1995). We chose this kind of classiﬁer en-

semble as it showed the best accuracy compared to

single classiﬁers (we experimented with random for-

est and SVM) or other ensemble techniques on our

dataset. For the second experiment, we adopted the

same training sets of the ﬁrst experiment to train the

system but, as a test set, we adopted the 1500 attack

samples described before.

5.1 Experiment 1: General

Performances

This Section provides a comparison between our ap-

proach and three recent research tools for the de-

tection of malicious PDFs: Wepawet, PJScan and

PDFRate (see Section 3).

Since PJScan adopts a One Class SVM, no be-

nign samples have been used for training the system.

We trained PJScan with the same malicious samples

used to train our system. PDFRate is trained with

a balanced dataset of 5000 benign and 5000 mali-

cious samples, the latter collected from Contagio. It

is worth noting that PDFRate is available with three

different instances of the same classiﬁer (random-

forests), that only differ for the dataset on which they

have been trained. For the sake of providing a fair

comparison with our system, we considered only the

one trained on the Contagio dataset, as Contagio is

the same source from which we collected malware

samples. The training size of Wepawet is unfortu-

nately unknown

. We want to stress that we tried to

make the fairest comparison possible, given the fact

that it was not possible to train PDFRate and Wepawet,

being them online services, and that the training set of

the latter is unknown. Even though a perfect compar-

ison would require the same exact training set for all

the systems, we believe that, in this situation, this is

the best possible compromise to provide useful infor-

mation about their performances.

Table 1 shows the results of a direct comparison

between our approach and the other tools. For each

system, we show the average percentage of true pos-

itives (TP), false positives (FP), the related standard

deviation within parentheses, and the MCC coefﬁ-

cient computed on mean values for TP and FP. It must

be observed that Wepawet was not able to analyze all

Being Wepawet and PDFRate online services, we could

not train such systems with our own samples.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

Table 1: Experimental comparison between our approach

and other academic tools.

System TP(%) FP(%) MCC

Ours 99.805 (±.089) .068 (±.054) .997

PDFRate 99.380 (±.085) .071 (±.056) .992

Wepawet 88.921 (±.331) .032 (±.012) .881

PJScan 80.165 (±1.979) .013 (±.012) .798

the samples. In particular, it analyzed 5,091 mali-

cious ﬁles and 3,883 benign ﬁles. This is due to

some parsing problems that undermine the system, as

it does not fully implement all the Adobe speciﬁca-

tions and only simulates the execution of embedded

Javascript code and executables. We also point out

that PJScan considered as benign all the samples for

which it could not ﬁnd evidence of Javascript code

usable for the analysis.

Results show that our system deﬁnitely outper-

forms Wepawet and PJScan. PJScan shows the

smallest false positive rate, but provides a much lower

detection rate compared to the remaining solutions.

Wepawet performs slightly better than our approach in

terms of FP rate, but it exhibits a lower TP detection

rate. Our approach performs better than PDFRate. In

fact, results are better both in terms of TP and FP

rate, with an higher MCC coefﬁcient. Moreover, it is

worth noting that our approach is superior to PDFRate

while adopting a signiﬁcantly lower number of fea-

tures. In fact, PDFRate resorts to 202 features (Smutz

and Stavrou, 2012) to perform its analysis, whilst our

system has never gone beyond 135 (considering the

variable number of object-related features).

5.2 Experiment 2: Evasion Attacks

Differently from current state of the art approaches,

the features of our system, as well as its parsing

mechanism, have been designed to consider the pos-

sibilities of deliberate attacks. In particular, an at-

tacker can perform what has been presented as re-

verse mimicry, i.e., embedding malicious content in-

side PDFs that have been recognized as benign by the

targeted system. This is done by only slightly chang-

ing the overall structure of the ﬁle, thus making the

attack extremely effective against pure structural sys-

tems (Maiorca et al., 2013).

In our experiments, we implemented all the at-

tacks described in our previous work, using the simi-

lar vulnerabilities

: a) Javascript (JS) Injection (in-

For EXE Embedding we exploited the CVE-2010-1240

vulnerability and for PDF Embedding and Javascript Injec-

tion we exploited the CVE-2009-0927.

jecting a Javascript object that exploits a vulnerabil-

ity), b) EXE Embedding (injecting an executable that

is automatically opened at runtime) and c) PDF Em-

bedding (injecting a malicious PDF ﬁle that is opened

after the main ﬁle). We then produced, for each at-

tack, 500 attack variants for a total of 1500 samples.

We observe that the samples produced in our previous

work were only few compared to the ones we have

created for this experiment. This was done to better

assess the efﬁciency of the created attacks against the

various systems.

Table 2 shows the performances, in terms of true

positives (TP), of the systems tested during the pre-

vious experiment (training with the same data, with

the same splits as before). We notice that Wepawet

performs really well on EXE Embedding and JS In-

jection. That was expected since reverse mimicry ad-

dresses static systems. Interestingly, though, Wepawet

was not able to scan PDF Embedding attacks due to

parsing problems. We speculate that this might be

related to the fact that Wepawet does not fully im-

plement the PDF speciﬁcations, and therefore is not

able to analyze some elements of the ﬁle. Such pars-

ing problems also appeared with PJScan, that was not

able to analyze any of the samples we provided. This

is mainly due to the fact that this system is not able to

analyze embedded ﬁles, i.e., PDFs or other ﬁles such

as executables, and only focuses on Javascript anal-

ysis (which also failed, in this case). PDFRate per-

formed really poorly, as also shown by our previous

work (Maiorca et al., 2013).

As for our approach, the ﬁrst thing we notice is

that our system is able to detect all PDF Embedding

attacks, thanks to its advanced parsing mechanism.

In particular, the system automatically searches for

objects that contain, in their dictionary, the keyword

/EmbeddedFiles. If such object is found, the rela-

tive object stream is decompressed, saved as a sepa-

rate PDF and then analyzed. If this ﬁle is found to

be malicious, then the container of the original object

stream will be considered malicious as well. For the

other two attacks, a key role is played by the learning

algorithm parameters that we chose to train our sys-

tem. In fact, Table 2 shows that robustness is strongly

dependent on two aspects:

• The weight threshold (W ) parameter of the

AdaBoost algorithm (Freund and Schapire, 1995)

(expressed, in our case, as a percentage). Such

value allows to select the samples that will be

used, for each iteration of the AdaBoost algo-

rithm, to train the weak classiﬁers and tune their

weights. In particular, for each iteration, the sam-

ples are chosen as follows:

1. The training set samples are ordered by their

AStructuralandContent-basedApproachforaPreciseandRobustDetectionofMaliciousPDFFiles

Table 2: Comparison, in terms of true positives (TP), be-

tween our approach and research tools with respect to eva-

sion attacks (%).

System PDF E. EXE E. JS INJ.

Ours (Opt.) 100 (±0) 62.4 (±12.6) 69.1 (±16.9)

Ours 100 (±0) 32.26 (±9.18) 37.9 (±10.65)

PDFRate 0.8 0.6 5.2

Wepawet 0 99.6 100

PJScan 0 0 0

normalized weights (the lowest weight ﬁrst).

Samples that have been incorrectly classiﬁed at

the previous iteration get higher weights. The

normalized weights sum S

is set to zero.

2. Starting from the ﬁrst sample, S

= S

+ w

computed, where w

is the normalized weight

of the sample. If S

< W

, then the sample

will be used for the training. If not, the algo-

rithm stops.

• The shape of the decision function. Since these

attacks directly address the shape of the classiﬁer

decision function (Maiorca et al., 2013) (which

obviously depends on the weights of each weak

classiﬁer), sometimes it is necessary to correct

it by using resampling, i.e., generating artiﬁcial

training data from the samples set obtained given

a speciﬁc weight threshold W . Such data will be

then used to tune the weights of the samples that

will train each weak learner, and therefore of the

weak classiﬁers in the ﬁnal linear combination.

However, such correction might compromise an

already robust function, so it must only be used on

vulnerable shapes. We call this correction func-

tion optimization.

Using the default weight threshold, namely, W = 100

(the one adopted in experiment 1) with no optimiza-

tion, performances are already better than PDFRate

but still not fully satisfactory. With W = 1 and an op-

timized decision function, instead, performances are

almost two times better, completely outperforming all

the other static approaches. Using W = 1 on the test

data of experiment 1, we also notice that false posi-

tives increase up to 0.2%. We interpret this result with

the fact that, by reducing the value of W , we force

the algorithm to ignore some samples that might have

been incorrectly classiﬁed in the previous iterations.

This makes the decision boundary less subjected to

changes due to samples that might be difﬁcult to be

correctly classiﬁed. It is a small trade off we have to

pay for a higher robustness. The standard deviation

values will be discussed in the next section.

If W is in its percentage form, it must be divided by 100

ﬁrst.

6 DISCUSSION

Results attained in the second experiment show that

the features we have chosen allow for a signiﬁcantly

higher robustness when compared to the state of the

art. However, the high standard deviation attained in

Experiment 2 also shows some limits in our approach:

in fact, we did not design a robust decision function

from the beginning, as we mainly focused on deﬁning

signiﬁcant features. As a consequence, our approach

is extremely sensitive to the training data used, and

in order to improve robustness we were forced to in-

troduce some optimizations to correct the function pa-

rameters. For future work, it will be essential to de-

sign a decision function that, regardless of the quality

of the training data, is able to reliably detect targeted

and optimal attacks. This aspect has been often over-

looked, especially in computer security applications

and has been pointed out, for example, by Biggio et

al. (Biggio et al., 2014b; Biggio et al., 2014a; Big-

gio et al., 2013a; Biggio et al., 2012; Biggio et al.,

2010). Moreover, recent works have shown that clus-

tering algorithms can also be vulnerable against eva-

sion and poisoning attacks (Biggio et al., 2014c; Big-

gio et al., 2013b). Since our method resorts on a clus-

tering phase, possible future works might also address

its resilience against such attacks.

7 CONCLUSIONS

Malicious PDF ﬁles have become a well-known threat

in the past years. PDF documents constitute a very

effective attack vector for cyber-criminals. In spite of

the efforts of software vendors such as Adobe, PDF

software is often vulnerable to zero-day attacks. In

this work, we presented a new approach that lever-

aged on both structural and content-based information

to provide a very accurate detection of PDF malware.

We also showed that our approach, with a careful

choice of the learning algorithm, is also able to cope

with evasion attacks. Finally, our work also clearly

pointed out the need of secure learning techniques for

malware detection, in order to cope with deliberate,

adversarial attacks.

ACKNOWLEDGEMENT

This work is supported by the Regional Adminis-

tration of Sardinia, Italy, within the project “Ad-

vanced and secure sharing of multimedia data

over social networks in the future Internet“ (CUP

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

F71J11000690002). Davide Maiorca gratefully ac-

knowledges Sardinia Regional Government for the ﬁ-

nancial support of his PhD F.S.E. Operational Pro-

gramme of the Autonomous Region of Sardinia, Eu-

ropean Social Fund 2007-2013 - Axis IV Human Re-

sources, Objective l.3, Line of Activity l.3.1.).

REFERENCES

Adobe (2006). PDF Reference. Adobe Portable Document

Format Version 1.7. Adobe.

Adobe (2008). Adobe Supplement to ISO 32000. Adobe.

Baldi, P., Brunak, S., Chauvin, Y., Andersen, C. A. F., and

Nielsen, H. (2000). Assessing the accuracy of predic-

tion algorithms for classiﬁcation: an overview. Bioin-

formatics, 16(5):412–424.

Bania, P. (2010). Jit spraying and mitigations. CoRR,

abs/1009.1038.

Biggio, B., Corona, I., Maiorca, D., Nelson, B., Srndic, N.,

Laskov, P., Giacinto, G., and Roli, F. (2013a). Evasion

attacks against machine learning at test time. In M.

Learning and Know. Discovery in Databases - Europ.

Conf., ECML PKDD, pages 387–402.

Biggio, B., Corona, I., Nelson, B., Rubinstein, B., Maiorca,

D., Fumera, G., Giacinto, G., and Roli, F. (2014a).

Security evaluation of support vector machines in ad-

versarial environments. In Ma, Y. and Guo, G., ed-

itors, Support Vector Machines Applications, pages

105–153. Springer International Publishing.

Biggio, B., Fumera, G., and Roli, F. (2010). Multiple classi-

ﬁer systems for robust classiﬁer design in adversarial

environments. Int’l J. Mach. Learn. and Cybernetics,

1(1):27–41.

Biggio, B., Fumera, G., and Roli, F. (2014b). Security

evaluation of pattern classiﬁers under attack. IEEE

Transactions on Knowledge and Data Engineering,

26(4):984–996.

Biggio, B., Nelson, B., and Laskov, P. (2012). Poisoning at-

tacks against support vector machines. In Langford, J.

and Pineau, J., editors, 29th Int’l Conf. on M. Learn-

ing (ICML). Omnipress, Omnipress.

Biggio, B., Pillai, I., Bul

o, S. R., Ariu, D., Pelillo, M., and

Roli, F. (2013b). Is data clustering in adversarial set-

tings secure? In Proceedings of the 2013 ACM Work-

shop on Artiﬁcial Intelligence and Security, AISec

’13, pages 87–98, New York, NY, USA. ACM.

Biggio, B., Rieck, K., Ariu, D., Wressnegger, C., Corona,

I., Giacinto, G., and Roli, F. (2014c). Poisoning be-

havioral malware clustering. In Proc. 2014 Workshop

on Artiﬁcial Intelligent and Security Workshop, AISec

’14, pages 27–36, New York, NY, USA. ACM.

Buchanan, E., Roemer, R., Sevage, S., and Shacham, H.

(2008). Return-oriented programming: Exploitation

without code injection. In Black Hat ’08.

Canali, D., Cova, M., Vigna, G., and Kruegel, C. (2011).

Prophiler: a fast ﬁlter for the large-scale detection of

malicious web pages. In Proc. of the 20th Int. Conf.

on World Wide Web.

Corona, I., Maiorca, D., Ariu, D., and Giacinto, G.

(2014). Lux0r: Detection of malicious pdf-embedded

javascript code through discriminant analysis of api

references. In To appear in the Proc. of the 7th ACM

Workshop on Art. Intelligence and Security.

Cova, M., Kruegel, C., and Vigna, G. (2010). Detection

and analysis of drive-by-download attacks and mali-

cious javascript code. In Proc. of the 19th Int. Conf.

on World Wide Web.

Curtsinger, C., Livshits, B., Zorn, B., and Seifert, C. (2011).

Zozzle: fast and precise in-browser javascript mal-

ware detection. In Proc. of the 20th USENIX Conf.

on Security.

Engleberth, M., Willems, C., and Holz, T. (2009). Detect-

ing malicious documents with combined static and dy-

namic analysis. In Virus Bulletin.

Esparza, J. M. (2011). Obfuscation and (non-)detection of

malicious pdf ﬁles. In S21Sec e-crime.

Freund, Y. and Schapire, R. E. (1995). A decision-theoretic

generalization of on-line learning and an application

to boosting.

Laskov, P. and

Srndi

c, N. (2011). Static detection of ma-

licious javascript-bearing pdf documents. In Proc.

of the 27th Annual Computer Security Applications

Conf.

Li, W.-J., Stolfo, S., Stavrou, A., Androulaki, E., and

Keromytis, A. D. (2007). A study of malcode-bearing

documents. In Proc. of the 4th Int. Conf. on Detect. of

Intrus. and Malware, and Vulnerability Assessment.

Liu, D., Wang, H., and Stavrou, A. (2014). Detecting ma-

licious javascript in pdf through document instrumen-

tation. In Proc. of the 44th Annual Int. Conf. on De-

pendable Systems and Networks.

Maass, M., Scherlis, W. L., and Aldrich, J. (2014). In-

nimbo sandboxing. In Proc. of the 2014 Symp. and

Bootcamp on the Science of Security, HotSoS ’14,

pages 1:1–1:12, New York, NY, USA. ACM.

MacQueen, J. B. (1967). Some methods for classiﬁcation

and analysis of multivariate observations. In Cam, L.

M. L. and Neyman, J., editors, Proc. of the ﬁfth Berke-

ley Symp. on Mathematical Statistics and Probabil-

ity, volume 1, pages 281–297. University of California

Press.

Maiorca, D., Corona, I., and Giacinto, G. (2013). Looking

at the bag is not enough to ﬁnd the bomb: An evasion

of structural methods for malicious pdf ﬁles detection.

In Proc. of the 8th ACM SIGSAC Symp. on Informa-

tion, Computer and Communications Security.

Maiorca, D., Giacinto, G., and Corona, I. (2012). A pattern

recognition system for malicious pdf ﬁles detection.

In Proc. of the 8th Int. Conf. on M. Learning and Data

Mining in Pattern Recognition.

Quinlan, J. R. (1996). Learning decision tree classiﬁers.

ACM Comput. Surv., 28(1):71–72.

Ratanaworabhan, P., Livshits, B., and Zorn, B. (2009). Noz-

zle: a defense against heap-spraying code injection at-

tacks. In Proc. of the 18th conf. on USENIX security

symp.

Rieck, K., Holz, T., Willems, C., D

ussel, P., and Laskov, P.

(2008). Learning and classiﬁcation of malware behav-

AStructuralandContent-basedApproachforaPreciseandRobustDetectionofMaliciousPDFFiles

ior. In Proc. of the 5th Int. Conf. on Detect. of Intrus.

and Malware, and Vulnerability Assessment.

Rieck, K., Krueger, T., and Dewald, A. (2010). Cujo: ef-

ﬁcient detection and prevention of drive-by-download

attacks. In Proc. of the 26th Annual Computer Secu-

rity Appl. Conference.

Shaﬁq, M. Z., Khayam, S. A., and Farooq, M. (2008). Em-

bedded malware detection using markov n-grams. In

Proc. of the 5th Int. Conf. on Detect. of Intrus. and

Malware, and Vulnerability Assessment.

Smutz, C. and Stavrou, A. (2012). Malicious pdf detection

using metadata and structural features. In Proc. of the

28th Annual Computer Security Appl. Conference.

Snow, K. Z., Krishnan, S., Monrose, F., and Provos, N.

(2011). Shellos: enabling fast detection and foren-

sic analysis of code injection attacks. In Proc. of the

20th USENIX conf. on Security.

Symantec (2014). Internet Security Threat Reports. 2013

Trends. Symantec.

Tabish, S. M., Shaﬁq, M. Z., and Farooq, M. (2009). Mal-

ware detection using statistical analysis of byte-level

ﬁle content. In Proc. of the ACM SIGKDD Work. on

CyberSecurity and Intelligence Informatics.

Tzermias, Z., Sykiotakis, G., Polychronakis, M., and

Markatos, E. P. (2011). Combining static and dynamic

analysis for the detection of malicious documents. In

Proc. of the 4th Europ. Work. on System Security.

Srndi

c, N. and Laskov, P. (2013). Detection of malicious

pdf ﬁles based on hierarchical document structure. In

Proc. of the 20th Annual Network & Distributed Sys-

tem Security Symp.

Srndic, N. and Laskov, P. (2014). Practical evasion of a

learning-based classiﬁer: A case study. In Proc. of the

2014 IEEE Symp. on Security and Privacy, SP ’14,

pages 197–211, Washington, DC, USA. IEEE Com-

puter Society.

Willems, C., Holz, T., and Freiling, F. (2007). Toward au-

tomated dynamic malware analysis using cwsandbox.

IEEE Security and Privacy, 5(2).

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy
