An Application Speciﬁc Processor for Enhancing Dictionary

Compression in Java Card Environment

Massimiliano Zilli

, Wolfgang Raschke

, Johannes Loinig

, Reinhold Weiss

and Christian Steger

Institute for Technical Informatics, Graz University of Technology, Inffeldgasse 16/I, Graz, Austria

Business Unit Identiﬁcation, NXP Semiconductors Austria GmbH, Gratkorn, Austria

Keywords:

Smart Card, Java Card, Hardware-supported Interpreter, Compression.

Abstract:

Smart cards are low-end embedded systems used in the ﬁelds of telecommunications, banking and identiﬁ-

cation. Java Card is a reduced set of the Java standard designed for these systems. In a context of scarce

resources such as smart cards, ROM size plays a very important role and dictionary compression techniques

help in reducing program sizes as much as possible. At the same time, to overcome the intrinsic slow execu-

tion performance of a system based on interpretation it is possible to enhance the interpreter speed by means

of speciﬁc hardware support. In this paper we apply the dictionary compression technique to a Java interpreter

built on an application speciﬁc processor. Moreover, we move part of the decompression functionalities in

hardware with the aim of speeding up the execution of a compressed application. We obtain a new interpreter

that executes compressed code faster than a classic interpreter that executes non-compressed code.

1 INTRODUCTION

Entering a building with restricted access without a

metal key, calling someone with a mobile phone, and

paying at the supermarket without physical money are

all activities based on the use of smart cards. With the

increase of informatization in many sectors of soci-

ety, these systems are destined to become even more

widespread.

Smart cards are low-end embedded systems con-

sisting of a 8/16 bit processor, some hundreds kilo-

bytes of persistent memory and some kilobytes of

RAM. The applications running on smart cards are

often developed in C and in assembly to maximize

execution time and minimize ROM size. Even fol-

lowing good programming practices, developing the

applications in C and assembly has the problem of

portability and demands a great amount of time for

porting the applications from one platform to another.

A programming language based on an interpreter like

Java would resolve the problem of portability and also

introduce security mechanisms included in the Java

run-time environment.

A complete Java run-time environment requires

hardware resources two orders of magnitude higher

than the typical smart card hardware conﬁguration.

Java Card standard is a reduced set of the Java stan-

dard tailored for smart cards (Oracle, 2011a) (Ora-

cle, 2011b). Moreover, with the “sandbox model”,

the Java Card run-time environment offers a secure

and sound environment protecting against many types

of security attacks. In contrast to standard Java envi-

ronments, Java Card virtual machine is split in two

parts: one off-card and the other on-card. The off-

card Java Card Virtual Machine consists of the con-

verter, the veriﬁer, and the off-card installer. The con-

verter transforms the class ﬁle into a CAP ﬁle, which

is the shipment format of Java Card applications. The

veriﬁer checks the CAP ﬁle for legitimacy so that the

code can be safely installed. After veriﬁcation, the

off-card installer establishes a communication chan-

nel with the on-card installer to transfer the content of

the CAP ﬁle to the smart card. The on-card installer

proceeds with the installation of the application, so

that afterwards the application execution is possible.

In smart cards, where the persistent memory size

is a ﬁrst order issue, keeping the ROM size of the

application as small as possible is a prominent is-

sue. Compression techniques based on the dictionary

mechanism ﬁt very well in a software architecture

based on a “token” interpreter like Java. The com-

pression phase is performed off-card between the ver-

iﬁcation and the installation processes. The on-card

Java Card virtual machine provides for the decom-

pression during run-time. The drawback of this ap-

proach is the slow-down of the application execution

305

Zilli M., Raschke W., Loinig J., Weiss R. and Steger C..

An Application Speciﬁc Processor for Enhancing Dictionary Compression in Java Card Environment.

DOI: 10.5220/0005318703050311

In Proceedings of the 5th International Conference on Pervasive and Embedded Computing and Communication Systems (PECCS-2015), pages

305-311

ISBN: 978-989-758-084-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

due to the decompression phase. As a consequence,

time performance issues could preventthe adoption of

the compression system especially in contexts where

time constraints are strict.

The most popular technique for speeding-up the

Java interpreter is the Just In Time (JIT) compilation.

Unfortunately, this approach is not compliant with the

typical smart card hardware conﬁgurations. A differ-

ent approach based on an interpreter with hardware

support is more suitable for smart cards.

In this paper we integrate the dictionary decom-

pression functionality on an interpreter with hardware

support. As ﬁnal result, we obtain an interpreter able

to execute compressed applications faster than a stan-

dard software interpreter executing a non-compressed

application.

The structure of the rest of this paper is as follows.

Section 2 reviews the previous work that forms the

basis of this research. Section 3 analyzes the dictio-

nary compression and its application to the interpreter

with hardware support. In section 4 we evaluate the

proposed models with particular attention to the exe-

cution time. Finally, in section 5 we report our con-

clusions and present suggestions for future work.

2 RELATED WORKS

Java Card is a Java subset speciﬁcally created for

smart cards that allows developers to use an object-

oriented programming language and to write appli-

cations hardware independently (Chen, 2000). The

virtual machine in the run-time environment repre-

sents a common abstraction layer between the hard-

ware platform and the application, and makes it pos-

sible to compile the application once and run it in each

platform deploying a compliant Java Card environ-

ment. The issuing format of Java Card applications

is the CAP ﬁle, whose inside is organized in compo-

nents (Oracle, 2011b). All the methods of the classes

are stored in the method component; consequently the

latter is usually the component with the highest con-

tribution to the overall application ROM size. For this

reason, a reduction of the size of the method compo-

nent would mean a signiﬁcant reduction of the ROM

space needed to install the application on the smart

card.

Alongside following good programming prac-

tices, the main solution for reducing the ROM size

of an application is the compressing of said applica-

tion. The drawback of common compression tech-

niques based on Huffmann and LZ77 algorithms is

their need of a considerable amount of memory to

decompress the application before its execution (Sa-

lomon, 2004).

Dictionary compression is a technique based on

a dictionary containing the deﬁnitions of new sym-

bols (macros) (Salomon, 2004). Each deﬁnition in

the dictionary consists of a sequence of symbols that

is often repeated in the data to compress. In the com-

pression phase the repeated sequences are substituted

with the respective macros (the macro deﬁnition and

the substituted sequence have to be the same), while

in the decompression phase the macros are substituted

with their deﬁnition. Claussen et al. applied dictio-

nary compression to Java for low-end embedded sys-

tems (Clausen et al., 2000). Applied to interpreted

languages like Java, the main advantage of this com-

pression technique, when compared to the traditional

techniques, resides in the possibility to decompress

the code on-the-ﬂy during run-time. In fact, when the

interpreter encounters a macro in the code, it starts

the interpretation of the code in the macro deﬁnition,

not needing the decompression of the entire code.

Claussen et al. could save up to 15% of the appli-

cation space, but this had also the disadvantage of a

slower execution speed quantiﬁable between 5% and

30%. In (Zilli et al., 2013), we explored the exten-

sions of the base dictionary technique. In that work,

we evaluated the static and dynamic dictionary as well

as the use of generalized macros with arguments.

The main disadvantage of interpreted languages

compared with native applications is the low execu-

tion performance. The system commonly used to im-

prove the execution speed in standard Java environ-

ments is the “Just In Time” (JIT) compilation (Sug-

anuma et al., 2000) (Cramer et al., 1997) (Krall and

Graﬂ, 1997). JIT compilation consists of the run-time

compilation and optimization of sequences of byte-

codes into native machine instructions. The disadvan-

tage of this technique is the amount of RAM memory

required to temporary store the compiled code. For

low-end embedded systems such as smart cards, the

amount of RAM memory needed for JIT compilations

does not comply with the memory conﬁgurations.

Another solution for overcoming the low execu-

tion speed is the hardware implementation of the Java

virtual machine. Previous works can be categorized

into two main approaches: the direct bytecode execu-

tion in hardware, and the hardware translation from

Java bytecode to machine instructions. An example

of the ﬁrst case is picoJava (McGhan and O’Connor,

1998), a Java processor that executes the bytecodes

directly in hardware. This approach reaches high ex-

ecution performance, but has the disadvantage of a

difﬁcult integration with applications written in na-

tive code. An example of hardware bytecode transla-

tion is the ARM Jazelle technology (Steel, 2001). In

PECCS2015-5thInternationalConferenceonPervasiveandEmbeddedComputingandCommunicationSystems

306

this case the integration with native code is possible

through an extension of the machine instruction set,

but the performances are not as good as in the Java

processor.

In the context of Java Card, we proposed a Java

interpreter with hardware support (Zilli et al., 2014).

In this work, we re-designed the interpreter as a

“pseudo-threaded” interpreter where each bytecode

provides for the jump to the next one. Moreover we

moved the part of the Java interpreter responsible for

the fetch and decode of the bytecode into the hard-

ware. With this approach, we obtain a time reduction

on the single bytecode execution of 40%.

The base of this research is the work in (Zilli et al.,

2014). We extend the interpreter proposed for the

handling of the dictionary decompression and present

two solutions. One is in software, while, in the sec-

ond, we implement part of the dictionary functional-

ities in hardware. For the evaluation of our work, we

compare the two solutions with a software implemen-

tation on a standard hardware platform.

3 DESIGN AND

IMPLEMENTATION

3.1 Dictionary Compression

In the context of Java Card, dictionary compression is

an off-card process and consists of the substitution of

repeated sequences of bytecodes with a macro whose

deﬁnition is stored in a dictionary (Clausen et al.,

2000) (Zilli et al., 2013). Given that 68 of the pos-

sible bytecode values are not deﬁned by the standard,

part of these can be used to extend the virtual machine

instruction set and to represent the macros.

While the compression phase is performed in the

off-card part of the Java Card virtual machine, the

decompression phase is done on-card during the run-

time. The decompression phase adapts well to the in-

terpreter architecture, because every dictionary macro

can be interpreted similarly to a “call” instruction. In

Figure 1 we convey the structure of the dictionary,

where two main components can be found. The ﬁrst

one consists of the look-up table containing the ad-

dresses of the macro deﬁnitions. The second com-

ponent of the dictionary is the set of the macro def-

initions. The latter consists of sequences of Java

bytecodes with a ﬁnal Java bytecode being speciﬁc

to the dictionary compression, whose mnemonic is

ret macro

The realization of the decompression module in

the Java Card virtual machine requires the imple-

macro1 address

macro2 address

macro3 address

Look-up Table

jbc1

jbc2

ret_macro

macro1 def

jbc1

jbc2

ret_macro

macro2 def

Figure 1: Organization of a dictionary.

mentation of the Java bytecode functions for the

dictionary macro (

macro jbc

) and for

ret macro

(

ret macro jbc

). These two Java bytecodes are sim-

ilar to the call and the return opcodes of a micro-

controller, but they act on the program counter of

the Java Card virtual machine (JPC). Figure 2 shows

pseudo-assembly code for the implementation of the

two bytecodes on a standard architecture. For the

macro_jbc:

MOV A, JPC

MOV JPC_RET, A

MOV A, #LOOKUP_TABLE

ADD A, JBC

MOV DPTR, A

MOV A, @DPTR

MOV JPC, A

RET

ret_macro_jbc:

MOV A, JPC_RET

MOV JPC, A

RET

Figure 2: Macro function and

ret macro

function in

pseudo-assembly code for the standard architecture.

sake of easier readability, the pseudo-code does not

take the real address width into consideration. In

the ﬁrst part of the

macro jbc

function, the actual

JPC is stored into a “return” variable. Afterwards,

the actual Java bytecode (e.g. the macro value) is

used to calculate the offset in the look-up table from

which the address of the corresponding macro def-

inition is fetched. At this point, the JPC is loaded

with the address of the macro deﬁnition. From this

point on, the Java virtual machine interprets the byte-

codes contained in the macro until it encounters the

ret macro

Java bytecode. Figure 2 shows the im-

AnApplicationSpecificProcessorforEnhancingDictionaryCompressioninJavaCardEnvironment

307

plementation of the

ret macro

bytecode in pseudo-

assembly code. As can be seen, the Java program

counter value contained in the “return” variable is re-

stored within the function. After the interpretation of

the

ret macro

bytecode, the Java Card virtual ma-

chine continues with the execution of the bytecodes

following the macro instruction.

3.2 Decompression with the Hardware

Supported Interpreter

In a context such as that of smart cards where the

resources are limited, a solution to speed up the vir-

tual machine is represented by an interpreter that uses

hardware extensions speciﬁc for the Java Card in-

terpretation (Zilli et al., 2014). Figure 3 explains,

by means of a state machine, how the fetch and the

decode phase of the interpretation are performed in

hardware.

State2

JBCFunct =

*(JBCTableOffset +

JBC * AddrWidth)

State3

jmp JBCFunct

Increment JPC

SW Domain

EXECUTE

HW Domain

DECODE

State1

JBC = *(JPC)

HW Domain

FETCH

Figure 3: State machine of the intepreter with the fetch and

the decode phase performed in hardware.

To do this, the authors added the JPC register to

the hardware architecture of the microcontroller, and

extended the instruction set of the latter to enable ac-

cess to the new functionalities. Moreover, they modi-

ﬁed the interpreter from a classical “token” model to a

“pseudo-threaded” model where every Java bytecode

function has at its end the instructions to fetch and to

decode the next bytecode.

We implement the dictionary decompression

functionality for this enhanced architecture. In Fig-

ure 4 we show the pseudo-code for the implementa-

tion of the Java bytecode functions

macro jbc

and

ret macro jbc

. In this implementation the dictio-

nary decompression is completely performed in soft-

ware and is analogous to the implementation for the

normal interpreter, except for the use of the extended

functionalities for manipulating the JPC that is now

an internal register of the hardware architecture. The

macro implementation is the same as the standard

case except for the fact that we use the new machine

instructions and that, at the end of the function, in-

macro_jbc:

GET_JPC_IN_A

MOV JPC_RET, A

MOV A, #LOOKUP_TABLE

ADD A, JBC

MOV DPTR, A

MOV A, @DPTR

SET_JPC_FROM_A

GOTONEXTJBCFUNCT

ret_macro_jbc:

MOV A, JPC_RET

SET_JPC_FROM_A

GOTONEXTJBCFUNCT

Figure 4: Macro function and

ret macro

function in

pseudo-assembly code for the interpreter with the fetch and

the decode phase in hardware.

stead of a normal RET instruction, we have the acti-

vation of the hardware fetch and decode of the next

Java bytecode. The same considerations can be made

for the

ret macro

bytecode.

3.3 Hardware Extension for Dictionary

Decompression

The architecture extension of the hardware aided in-

terpreter represents the core of this work. In a hard-

ware/software co-design context, we moved parts of

the software implementation of the dictionary decom-

pression to hardware. Referring to Figure 1, it is nec-

essary for the hardware architecture to have access to

the dictionary look-up table base address and to the

actual value of the macro. Moreover, we added a reg-

ister for storing the return address of the Java program

counter (JPC) and an internal register to temporary

store the value of the processor program counter (PC).

Figure 5 sketches the ﬁnite state machine tak-

ing charge of the macro decodiﬁcation. In the ﬁrst

step, the PC and the JPC are stored in the respec-

PC_RET <-- PC

JPC_RET <-- JPC

PC <-- MACRO_TABLE

+ macro_value

JPC <-- fetch(PC)

PC <-- PC_RET

Figure 5: State machine of the PRECALL MACRO ma-

chine opcode.

PECCS2015-5thInternationalConferenceonPervasiveandEmbeddedComputingandCommunicationSystems

308

tive “return” register. In the second step, the PC is

loaded with the value resulting from the sum of the

macro look-up table base address (MACRO

TABLE)

and the offset relative to the actual macro being de-

coded (macro

value). At this point, the value fetched

from the ROM at the address pointed by the PC cor-

responds to the address of the macro to be executed.

The fetched value is then stored into the JPC and the

PC is restored.

The hardware functionality just described is ac-

tivated by means of an additional machine instruc-

tion (whose mnemonic is PRECALL

MACRO) part

of the extended instruction set. In Figure 6 we

report the implementation of the

macro jbc

and

ret

macro jbc bytecode functions. After the modi-

macro_jbc:

MOV A, #LOOKUP_TABLE

SET_DICTLOOKUP_TABLE

MOV A, JBC

PRECALL_MACRO

GOTONEXTJBCFUNCT

ret_macro_jbc:

REST_DICT_JBC

GOTONEXTJBCFUNCT

Figure 6:

macro jbc

and

ret macro jbc

functions in

pseudo-assembly code for architecture with hardware sup-

port for dictionary decompression.

ﬁcation of the JPC, the

GOTONEXTJBCFUNCT

instruc-

tion starts the execution of the bytecodes of the

macro deﬁnition. When the interpreter executes the

ret macro

bytecode, the

REST DICT JBC

machine in-

struction is executed to restore the JPC value previ-

ously stored into the internal return register within the

PRECALL MACRO

machine instruction. Afterwards, the

instruction

GOTONEXTJBCFUNCT

continues the execu-

tion ﬂow from the ﬁrst bytecode after the macro byte-

code.

4 RESULTS AND DISCUSSION

The results of this work can be subdivided into two

parts: one related to the compression phase and the

other to the decompression phase. For the ﬁrst part we

consider the space savings that we obtained by apply-

ing the dictionary compression to a set of industrial

applications. For the decompression we analyze the

run-time improvements due to the use of the new mi-

crocontroller architecture.

4.1 Compression

The main aspect regarding the compression phase is

the space savings that can be obtained. We did not

evaluate the compression speed performance because

it is performed off-card, hence in a platform with no

particular hardware constrains. For the assessment

of the space savings, we applied the dictionary com-

pression method to a set of three banking applications

(XPay, MChip and MChip Advanced).

Table 1: Space savings obtained with the dictionary com-

pression.

Application Size [B] Space Savings [%]

XPay 1784 12.2

MChip 23305 9.2

MChip Advanced 38255 10.5

Table 1 summarizes the space savings obtained for

the three applications. The second and third columns

show the sizes of the method component and the

space savings over the method component expressed

in percentage. The reported space savings also ac-

count for the ROM space needed for the storage of

the dictionary.

4.2 Decompression

To evaluate the decompression, we implemented the

proposed architectures before building the relative in-

terpreters onto them . The 8051 architecture is a low-

end microcontroller consistent with hardware conﬁg-

urations of typical smart cards. As a starting point we

took the 8051 implementation provided by Oregano

and we added to it the extensions described in Sec-

tion 3. We created two different architectures: one

has the fetch and decode phase of the interpreter re-

alized in hardware (FDI8051); the other, in addition

to the fetch and decode of the interpreter, also has the

hardware extension for the dictionary decompression

(FDI8051DEC).

4.2.1 Additional Hardware

We synthesized the proposed hardware architectures

on a Virtex-5 FPGA (FXT FPGA ML507 Evaluation

Platform). In this way we are able to quantify the

FPGA usage in terms of ﬂip-ﬂops (FFS) and look-up

tables (LUTs). Table 2 shows the necessary hardware

for the three available architectures. Both architec-

tures have an increment of the FPGA usage with an

higher increment for the FDI8951DEC. The higher

AnApplicationSpecificProcessorforEnhancingDictionaryCompressioninJavaCardEnvironment

309

Table 2: FPGA utilization for the different architectures.

Architecture

FPGA Util.

FFs Diff. % LUTs Diff. %

Std8051 582 - 2623 -

FDI8051 613 5.3 2921 11.4

FDI8051DEC 666 14.4 2946 12.3

FPGA usage in the FDI8051DEC is due to the in-

troduction of the decompression mechanism in hard-

ware.

4.2.2 Execution Speed-up

For the evaluation of the run-time performance we

proceeded with the evaluation of the execution of a

dictionary macro. For the sake of this assessment we

proceeded in two steps. The ﬁrst step consists of the

execution time measurement of a sequence of byte-

codes running on a completely software-based inter-

preter (on the Std8051 architecture) and on the inter-

preter running on the architecture with the fetch and

the decode phase of the interpretation in hardware

(FDI8051 architecture). In the second step we eval-

uated the increment of the execution time due to the

encapsulation of the sequence under test into a macro

deﬁnition.

The analysis coming from the off-card compres-

sion shows that macros have an average length of

three bytecodes. In a second instance, we mea-

sured and averaged the interpretation time of a set

of frequently used bytecode instructions (

sconst n

bspush

sspush

sstore n

sload n

sadd

ifeq

ifcmpeq

) to calculate the “average bytecode interpre-

tation time”. For the assessment, we took the imple-

mentation of the bytecodes from the Java Card refer-

ence implementation provided by Oracle. The mea-

surement of the interpretation time was performed on

two architectures: one with the interpreter completely

in software (Std8051), and the other with the fetch

and the decode phase of the interpreter performed in

hardware (FDI8051).

Table 3: Execution time of a bytecode sequence.

Architecture Exec. Time [Clk Cycles] Diff [%]

Standard 8051 680 -

FDI8051 400 -41%

At this point it is possible to evaluate the time

needed for the execution of a sequence composed of

general bytecodes with a length equal to the average

length of a macro deﬁnition. Table 3 lists the execu-

tion time for the two architectures.

To assess the inﬂuence on the execution time due

to the sequence being encapsulated into a macro deﬁ-

nition, we took into consideration the same “average”

sequence previously examined. In this case we com-

pleted the evaluation using the three hardware archi-

tectures available, because each of them displays dif-

ferent behavior during the execution of a macro. The

20%

13%

100

200

300

400

500

600

700

800

900

Standard 8051 FDI8051 FDI8051DEC

Execution Time [clock cycles]

Architecture

Macro

Overhead

Sequence

Execution

Figure 7: Execuiton time of a macro on three architectures.

graphic of Figure 7 summarizes the results regard-

ing the interpretation of the macro. The execution

time (vertical coordinate) is expressed in clock cy-

cles. In each bar the light-gray part represents the time

needed for the interpretation of the sequence. The

dark gray part accounts for the overhead due to the

macro encapsulation, which means the interpretation

of the macro bytecode and the

ret macro

bytecode.

The entire bar represents the time needed to execute a

macro. At the top-right corner of each bar there is a

percentage number representing the macro overhead

compared to the overall macro execution.

4.3 Discussion

Dictionary compression allows space savings of about

10% of the applications ROM footprint. With a stan-

dard architecture, the execution overhead due to the

macro encapsulation would take 20% of the overall

macro interpretation (Figure 7).

The architecture with the fetch and the decode

phase of the interpreter in hardware (FDI8051) pro-

vides a signiﬁcant acceleration of the macro execution

because of the increase in speed of the single bytecode

execution. Compared to the macro execution on the

standard 8051 architecture, the FDI8051 architecture

permits a decrease in the execution time of 45%.

The new architecture with the support for the dic-

tionary compression (FDI8051DEC) furtherimproves

the execution performance, reducing the time over-

head owed to the macro encapsulation of the se-

PECCS2015-5thInternationalConferenceonPervasiveandEmbeddedComputingandCommunicationSystems

310

quence. Compared to the FDI8051 architecture, the

overhead time is reduced by about 50%. Compared to

the standard 8051 architecture, the FDI8051DEC ar-

chitecture allows a speed-up of 2 in the execution of a

dictionary macro.

5 CONCLUSIONS

In this paper we combined the dictionary compres-

sion technique with a Java Card interpreter based

on an application speciﬁc processor. Moreover, we

moved part of the decompression functionalities to

the hardware architecture, further extending the ap-

plication speciﬁc processor. The result of this design

is a new Java Card interpreter able to execute com-

pressed code twice as fast as a standard interpreter.

Although the new hardware architecture needs a little

additional hardware, the compressed Java Card appli-

cations need about 10% less memory footprint than

the non-compressed ones.

Beyond plain dictionary compression, dictionary

compression techniques that make use of general

macros deﬁnitions with arguments are available. The

integration of these dictionary compression tech-

niques in the application speciﬁc processor provides

opportunities for future research.

ACKNOWLEDGEMENTS

Project partners are NXP Semiconductors Austria

GmbH and TU Graz. The project is funded by

the Austrian Federal Ministry for Transport, Innova-

tion, and Technology under the FIT-IT contract FFG

832171. The authors would like to thank their project

partner NXP Semiconductors Austria GmbH.

REFERENCES

Chen, Z. (2000). Java Card Technology for Smart Cards:

Architecture and Programmer’s Guide. Addison-

Wesley Professional.

Clausen, L. R., Schultz, U. P., Consel, C., and Muller, G.

(2000). Java Bytecode Compression for low-end Em-

bedded Systems. ACM Trans. Program. Lang. Syst.,

22(3):471–489.

Cramer, T., Friedman, R., Miller, T., Seberger, D., Wilson,

R., and Wolczko, M. (1997). Compiling Java Just in

Time. Micro, IEEE, 17(3):36–43.

Krall, A. and Graﬂ, R. (1997). CACAO - A 64-bit JavaVM

Just-in-Time Compiler. Concurrency Practice and

Experience, 9(11):1017–1030.

McGhan, H. and O’Connor, M. (1998). PicoJava: A Di-

rect Execution Engine For Java Bytecode. Computer,

31(10):22–30.

Oracle (2011a). Java Card 3 Paltform. Runtime Environ-

ment Speciﬁcation, Classic Edition. Version 3.0.4. Or-

acle.

Oracle (2011b). Java Card 3 Paltform. Virtual Machine

Speciﬁcation, Classic Edition. Version 3.0.4. Oracle.

Salomon, D. (2004). Data Compression: The Complete

Reference. Springer-Verlag New York Incorporated.

Steel, S. (2001). Accelerating to Meet the Challenges of

Embedded Java. Whitepaper, ARM Limited.

Suganuma, T., Ogasawara, T., Takeuchi, M., Yasue,

T., Kawahito, M., Ishizaki, K., Komatsu, H., and

Nakatani, T. (2000). Overview of the IBM Java Just-

in-Time Compiler. IBM Systems Journal, 39(1):175–

193.

Zilli, M., Raschke, W., Loinig, J., Weiss, R., and Steger, C.

(2013). On the dictionary compression for java card

environment. In Proceedings of the 16th International

Workshop on Software and Compilers for Embedded

Systems, M-SCOPES ’13, pages 68–76, New York,

NY, USA. ACM.

Zilli, M., Raschke, W., Loinig, J., Weiss, R., and Ste-

ger, C. (2014). A high performance java card virtual

machine interpreter based on an application speciﬁc

instruction-set processor. In Digital System Design

(DSD), 2014 Euromicro Conference on. in print.

AnApplicationSpecificProcessorforEnhancingDictionaryCompressioninJavaCardEnvironment

311
