An Agent Architecture for Adaptive Supervision and Control of Smart

Environments

Stefano Ferilli, Berardina De Carolis, Andrea Pazienza, Floriana Esposito

and Domenico Redavid

Dip. di Informatica, University of Bari, via E. Orabona 4, Bari, Italy

Keywords:

Ambient Intelligence, Workﬂow Management, Service Composition.

Abstract:

This paper describes the architecture and functionality of a generic agent that is in charge of handling a given

environment in an Ambient Intelligence context, ensuring suitable contextualized and personalized support to

the user’s actions, adaptivity to the user’s peculiarities and to changes over time, and automated management

of the environment itself. The architecture is implemented in a multi-agent system, where different types of

agents are endowed with different levels of reasoning and learning capabilities. In addition to controlling

normal operations of the environment, the system may identify user’s needs and goals and activate suitable

workﬂows to satisfy them. Some actions in these workﬂow involve the execution of semantic services. When

a single service is not available for fulﬁlling a given need, an automatic service composer is used to obtain a

suitable combination of services. The architecture has been implemented in a prototypical agent-based system

that works in a Smart Home Environment.

1 INTRODUCTION

Users of a smart environment often have contextual

needs depending on the situation. According to (Yau

and Liu, 2006), a situation-aware environment should

understand both the status of the environment, and

the status and the needs of users in order to proac-

tively support them with the most appropriate conﬁg-

uration of actions of various devices and resources in

the smart environment. This capability of the environ-

ment is even more important in the context of Ambi-

ent Assisted Living (AAL), where the aim is support-

ing elder people in their daily life by assisting them

with intelligent solutions for providing the services

they need (Sun et al., 2009).

Developing a situation aware environment re-

quires efﬁcient, ﬂexible and scalable solutions. We

propose an approach based on software agents able to

recognize the user’s situational goal, to provide smart

(i.e., integrated, interoperable and personalized) ser-

vices for satisfying this goal and to provide suitable

interfaces using the possibilities offered by the vari-

ous devices that are present in the environment. The

environment must be able to reason on the situation

of the users so as to understand their needs and goals

for composing the most appropriate services.

The following approaches for composing services

are most commonly used:

Manual Composition: the user must tell the system

how to compose services. In general, this process

is quite complex and requires knowledge about

existing available services and about how to com-

pose and integrate them. In order to help the

users in manual composition of services, some

interesting interaction metaphors have been pro-

posed (Humble et al., 2003).

Automatic Composition: service composition is

planned without human intervention by using

methods and techniques typical of planning in Ar-

tiﬁcial Intelligence (Paik and Maruyama, 2007).

The user has no workload for ﬁnding, ﬁltering

and integrating services. The system, starting

from the high-level goal of the user, automatically

generates the workﬂow of services that satisfy her

needs. Planning however is a complex task and

requires the correct formalization of the problem,

of the actions and of the constraints. Moreover,

problems might arise in understanding the user’s

goals and in matching them semantically against

existing services.

Semi-automatic Composition: the system, accord-

ing to the recognized needs and situation, se-

lects the most appropriate composition of services

160

Ferilli S., De Carolis B., Pazienza A., Esposito F. and Redavid D..

An Agent Architecture for Adaptive Supervision and Control of Smart Environments.

DOI: 10.5220/0005326301600167

In Proceedings of the 5th International Conference on Pervasive and Embedded Computing and Communication Systems (PECCS-2015), pages

160-167

ISBN: 978-989-758-084-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

among those that are available in a repository or

that can be planned. When this is not possible, the

system interactively guides the user in ﬁnding, ﬁl-

tering and composing services (Kim et al., 2004).

We work in this latter direction and propose a

Multi Agent System (MAS) architecture. The key

feature of our proposal is the design and development

of the architecture and functionalities of a generic

agent class that can be specialized for several speciﬁc

roles. These roles are in charge of handling the differ-

ent features and capabilities of a situation-aware en-

vironment, ensuring suitable contextualized and per-

sonalized support to the user’s actions, adaptivity to

the user’s status and needs and to changes over time,

and automated management of the environment itself.

The architecture has been implemented in a prototyp-

ical agent-based system that works in a Smart Home

Environment (SHE) scenario, where it is necessary

to combine services of the physical environment with

net-centric ones according to the recognized situation.

The paper is structured as follows. The proposed

architecture, and its most relevant components, are

described in Section 3. Then, Section 4 proposes sev-

eral kinds of roles to be implemented by agents that

work in the smart environment. A sample scenario

is proposed in Section 5, before concluding the paper

and outlining future work issues in Section 6.

2 RELATED WORK

A smart environment is able to acquire and apply

knowledge about its inhabitants and their surround-

ings in order to adapt to the situational goals (Cook,

2009). Then developing a smart environment requires

software components that, at different levels of ab-

straction, may perceive the environment and, more or

less autonomously,act on it by providing the response

that is appropriate to the situation. An agent is an

entity that matches these requirements (Wooldridge

and Jennings, 1995). In particular, BDI (Belief De-

sire Intention) agents are endowedwith this capability

and act on the basis of practical reasoning (Rao and

Georgeff, 1991). Their reasoning is based on their in-

tentions, that originate from the intersection between

beliefs about the state of the world, and desires (the

agents’ goals).

Moreover, agents can be organized in order to

solve complex and distributed problems in a Multi

Agent System (MAS). Typically MAS meet the re-

quirements on modularity, ﬂexibility and scalability

needed to handle the complexity of a smart environ-

ment (Ayala et al., 2012). When endowed with appro-

priate knowledge and reasoning capabilities a MAS

represents a way to design and implement a proactive

and adaptive environment in relation to individual and

changing needs (Cook, 2009; Wolf et al., 2010).

Early research projects concerned with applying

intelligent agents to the realization of a Smart Home

focused on the development of a home that programs

itself by observing the lifestyle and desires of the

inhabitants, and learns to anticipate and accommo-

date their needs (Mozer, 2005; Rao and Cook, 2004;

De Carolis et al., 2005). More recently, research has

focused on how smart environments can be used to

provide assistance and support to elderly people dur-

ing their life at home (Sun et al., 2009).

Applying agent-based approaches on this domain

seems to be a promising direction for research (Cook

et al., 2009; O’Grady et al., 2010). In particular, (Mc-

Naull et al., 2011) presented a context-aware MAS

that may help to assist an individual in an AAL sce-

nario. (Sernani et al., 2013) adopt the metaphor of

the Virtual Carer for implementing a MAS for mon-

itoring the health conditions of assisted persons and

facilitating their daily activities.

Recently the agent based approach has been com-

bined to the service oriented one (Wu et al., 2007).

In (Mars´a-Maestre et al., 2008) the problem of ser-

vice personalization in smart environments is ad-

dressed by a Service Oriented Architecture imple-

mentation based on multiagent systems. In particular

they take advantage of the mobility features of soft-

ware agents. In particular, they have developed a hi-

erarchical, agent-based solution intended to be appli-

cable to different smart space scenarios, ranging from

small environments to large smart spaces like cities.

The proactive nature of a smart environment has

been investigated by several research works that pro-

pose the processing of contextual data for carrying

out analysis for erroneous events in order to pro-

vide “relevant information and/or services to the user,

where relevancy depends on the user’s task.” (Dey,

2001). Many research projects touch upon context

aware computing and ambient assisted living. Exam-

ples include the research conducted by (Chun-dong

et al., 2009), that propose a framework providing

adaptive service in an intelligent home environment.

(D’Andrea et al., 2009) propose a system that in-

terprets user’s spoken dialogue and exploits writing

recognition to control a home environment. A frame-

work for developing multi-model interfaces for re-

minding meals to elderly people is described in (Blu-

mendorf and Albayrak, 2009) and a framework for

adapting interactive systems based on user behavior

is discussed by (Bezold, 2010).

Therefore, developing a smart environment re-

quires designing a complex intelligent system able to

AnAgentArchitectureforAdaptiveSupervisionandControlofSmartEnvironments

161

acquire and apply knowledge about the environment

and its residents in order to improve their quality of

life in that environment by providing situation-aware

services through natural and effective interfaces. To

achieve this aim, we recognized the need of develop-

ing an architecture of a MAS that combines the prac-

tical reasoning capabilities of BDI agents, the learn-

ing capabilities of intelligent learning agents and the

service oriented approach in order to implement an

Ambient Intelligence (AmI) system that is able to un-

obtrusively and proactively adapt to the individual sit-

uational needs.

3 ARCHITECTURE

The general architecture implemented by our agents,

which is an extended version of that introduced

in (Ferilli et al., 2011), is reported in Figure 1. Ac-

cording to this architecture, each agent is endowed

with a multi-strategy reasoning engine involving two

functional levels: the Reasoning Layer (ReaL) and the

Learning Layer (LeaL). The environment in which the

agent operates represents the Sensors, Effectors and

Applications Layer (SeaL). Both ReaL and LeaL are

able to apply several types of inference, including:

Abstraction used to simplify the available informa-

tion by removing irrelevant details;

Deduction used to apply the user and context models

in order to understand what is going on in the en-

vironment and what actions should be taken con-

sequently;

Abduction used to deal with cases of incomplete

knowledge, hypothesizing sensible values for

missing information;

Induction used to adapt the user and context mod-

els based on the feedback obtained during the sys-

tem’s interaction.

The initial knowledge base used by ReaL, organized

in several cooperating modules referred to speciﬁc

topics, is built using information provided by experts,

but can be reﬁned and improved automatically as long

as the system works by exploiting the functionality of

LeaL. Among other kinds of knowledge, it includes

user models, context models and process models to

be used for adapting/personalizing the interaction and

controlling the ﬂow of events.

A user model includes knowledge that allows to

infer his mental and physical status, his goals and ob-

jectives, his preferences and interests, and his needs

and requirements. Personalized models may be avail-

able for speciﬁc users, typically learned by monitor-

Figure 1: Agent’s architecture.

ing their behavior. A context model includes knowl-

edge that allows to infer what kind of situation is

faced by the system, what is going on in the environ-

ment, and how to act in order to properly handle the

situations that are occurring. A process model spec-

iﬁes which combinations of activities are allowed to

accomplish a given goal. Many models may be avail-

able for reaching the same goal. Process models can

be combined (e.g., one process may involve a com-

plex activity, for which one or more process models

may be available). Based on the user proﬁle and the

current context, the system identiﬁes possible goals of

the user, and extracts from its workﬂow repository the

items that specify how to satisfy those goals.

The two levels currently include the following op-

erational modules: AmICo (Ambient Intelligence Co-

ordinator) applies the knowledge base; InTheLEx (In-

cremental Theory Learner from Examples) reﬁnes it

according to the feedback obtained by the user and

the environment; WoMan (Workﬂow Manager) con-

trols process executions and SerPICo (Service Plan-

ner Identiﬁer and Composer) provides service com-

position facilities.

3.1 Workﬂow Management

WoMan (Ferilli, 2014) includes two submodules:

WEST (Workﬂow Enactment Supervisor and Trainer)

can supervise a process execution and foresee the next

activities of the user according to a given process

model; WIND (Workﬂow INDucer) can learn and/or

reﬁne the process model based on cases that are pro-

vided as successful examples of process execution.

Given a goal, the system selects the process mod-

els that allow to reach that goal. While receiving the

events coming from the environment, the system acts

PECCS2015-5thInternationalConferenceonPervasiveandEmbeddedComputingandCommunicationSystems

162

in supervision mode, checking whether it is compli-

ant with the current model(s) that have been activated.

The outcome for each activity can be:

ok the activity is compliant with the model;

warning the event does not match the model because

the activity is not allowed by the model in the cur-

rent status of the execution;

error termination of an activity that had never be-

gun; termination of the process execution with

still pending activities.

As long as the process execution proceeds, these out-

comes are collected. If several candidate workﬂow

models are considered, they are used by the system to

hypothesize which models are more likely to be tak-

ing place and which ones are less likely, using its sub-

module WoGue (acronym for WOrkﬂow GUEsser).

For each model WoMan can also, based on the

current status and context of the execution, foresee

which will be the next actions of the user. This al-

lows the agent to carry out suitable interventions that

support or facilitate the execution of these actions, by

just communicating useful information to the user or

to an external interested person or by directly acting

on suitable effectors to modify the environment. In

other cases, the desired effect is provided by existing

services that the agent may call. While atomic ser-

vices can be directly activated by the agent, there are

complex tasks for which a single service is not avail-

able, and there is no know composition of elementary

services that solves the problem. In these cases, the

system may call SerPICo to ﬁnd service compositions

that may reach the objective and are compliant with

the given constraints, preferences or requirements.

When the process execution terminates, if no error

was raised, and the system is notiﬁed that the execu-

tion was correct, the learning component is called to

reﬁne the process model as follows:

• adding new tasks to the activity ﬂow model;

• adding new paths between available activities in

the activity ﬂow model;

• changing the weights of the componentsof the ac-

tivity ﬂow model;

• reﬁning the pre- and/or post-conditions for the ac-

tivities and/or paths in the activity ﬂow model.

Correct cases just change the weights of the model.

3.2 Service Composition

Let us explain how to obtain OWL-S (OWL for Ser-

vices

) composed services using Semantic Web lan-

guages and tools, in particular the Semantic Web Rule

http://www.w3.org/Submission/OWL-S/

Language (SWRL)

. OWL-S is an ontology that en-

ables semantic descriptions of Web services by means

of three perspectives: ServiceProﬁle, with advertise-

ment aims; ServiceGrounding, used to link a concrete

service description (i.e., WSDL); and ServiceModel,

that deﬁnes the OWL-S process model. In particular,

each process is based on an IOPR (Inputs, Outputs,

Preconditions, and Results) model. The Inputs repre-

sent the information that is required for the execution

of the process. The Outputs represent the information

that the process returns to the requester. Precondi-

tions are conditions imposed over the Inputs that must

hold for successfully invoking the process. Since an

OWL-S process may yield several results with cor-

responding outputs, the Results entity of the IOPR

model provides a means to specify this situation.

Each result can be associated to a result condition,

called inCondition, that speciﬁes when that particular

result can occur. It is assumed that such conditions

are mutually exclusive, so that only one result can be

obtained for each possible situation. When an inCon-

dition is satisﬁed, there are properties associated to

this event that specify the corresponding output (with-

Output property) and, possibly, the Effects (hasEffect

properties) produced by the execution of the process.

Effects are changes in the state of the world. The

OWL-S conditions (Preconditions, inConditions and

Effects) are represented as logical formulas. Since

OWL offers limited support to formulate constructs

like property compositions without becoming unde-

cidable, a more powerful language is required for the

representation of OWL-S conditions.

One of the proposed languages is SWRL. Al-

though SWRL is undecidable, a solution has been

proposed in (Motik et al., 2005) where decidability

is achieved by restricting the application of SWRL

rules only to the individuals explicitly introduced in

the ABox. This kind of SWRL rules, called DL-safe,

makes this language the best candidate for represent-

ing OWL-S conditions (Redavid et al., 2013). Let us

now brieﬂy mention the characteristics of SWRL that

are relevant to our scope. SWRL extends the set of

OWL axioms (classes, properties, built-ins) to include

Horn-like rules in the form of implicationsbetween an

antecedent (body) and a consequent (head), both con-

sisting of conjunctions of zero or more atoms. The

intended meaning can be read as: whenever the con-

ditions speciﬁed in the antecedent hold, then the con-

ditions speciﬁed in the consequent must also hold. A

rule with conjunctive consequent can be transformed

into multiple rules each with an atomic consequent by

means of Lloyd-Topor transformations.

We encode an atomic OWL-S service with the fol-

http://www.w3.org/Submission/SWRL/

AnAgentArchitectureforAdaptiveSupervisionandControlofSmartEnvironments

163

lowing abstract rule (Redavid et al., 2013):

Preconditions ∧ inCondition → {output} ∧ E f fect

If the service has many Results, multiple rules having

different inCondition, output and/or Effect are used.

With this encoding we can apply the SWRL composer

proposed in the same work. It implements a backward

search algorithm for the composition task that works

as follows: it takes as input a set of SWRL rules and

a goal speciﬁed as a SWRL atom, and returns every

possible path built by combining the available SWRL

rules in order to achieve such a goal. These rules ful-

ﬁll the SWRL safety condition. Speciﬁcally, the algo-

rithm performs backward chaining starting from the

goal in the same way as Prolog-like reasoners work

for query answering. The difference is that this algo-

rithm works on SWRL DL-safe rules instead of Horn

clauses. This means that, besides the rule base, it

takes into account also the Description Logic ontol-

ogy the rules refer to.

The SWRL rule path found, and consequently the

resulting OWL-S service composition, will be valid

(in the sense that it will produce results for the se-

lected goal) only if the SWRL rules in the path are

DL-safe. In other words, DL-safety means that rules

are true for individuals that are known, i.e. that ap-

pear in the knowledge base. The implemented proto-

type performs DL-safety check. This guarantees that

the application of rules is grounded in the ABox and,

consequently, that the services embodying those rules

can be executed.

4 TYPES OF AGENTS

The types of agents that implement the above archi-

tecture extend those in (Cavone et al., 2012):

Sensor Agents (SA): provide information about sen-

sor parameters and values (e.g., temperature, light

level, humidity, etc.).

Context Agents (CA): determinethe current context

from sensor events; they are able to reason at a

higher level than sensor agents, for instance start-

ing from temperature and humidity data they may

determine whether the user is in a comfortable sit-

uation (De Carolis et al., 2005).

User Proﬁle Agent (UPA): is responsible for deter-

mining the preferencesproﬁle to be used, and may

serve personalization purposes.

Butler Agent (BA): combines intelligent reasoning,

machine learning, service-oriented computing

and semantic Web technologies for ﬂexibly coor-

dinating and adaptively providing smart services

in dynamically changing contexts.

Effector Agents (EA): each appliance and device is

controlled by an EA that reasons on the opportu-

nity of performing an action instead of another in

the current context.

Interactor Agents (IA): handle interaction with the

user. They are responsible for choosing the best

interaction metaphor according to the situation

and to the user’s needs and preferences, and for

executing suitable communicative tasks by per-

forming communicative actions.

Housekeeper Agent (HA): acts as a facilitator since

it knows all the agents that are active in the house

and also the goals they are able to fulﬁll.

The underlying metaphor is that of a butler in a grand-

house that is in charge of perceiving the situation of

the house and of coordinating the housestaff in order

to satisfy the needs of the house inhabitants. In par-

ticular, it reasons on the user’s goals and devises the

workﬂow to satisfy them.

These agents coordinate themselves as follows.

Cyclically, or as an answer to a user action, the but-

ler runs its reasoning model about the user. Based on

the information provided by the appropriate CAs, it

infers the possible goals and needs of the user and

ranks them by urgency or certainty by consulting

the UPA. Given a speciﬁc goal, it selects an appro-

priate workﬂow by matching semantically the goal

with all the Input, Output, Pre-Condition and Ef-

fect (IOPE) descriptions of the workﬂows stored in

a workﬂow repository. During workﬂow enactment,

semantic matchmaking is also used to select the ser-

vices/actions to be invoked among those available in

the environment.

The available semantic Web services are listed in

a Semantic Web Services Register (SWSR) according

to the IOPE standard representation (Meyer, 2007).

Hence, the workﬂow services are invoked dynami-

cally, matching the user’s needs in the most effec-

tive way. As regards predicates of Web Services,

both simple and complex Web Services will be im-

plemented according to the standard OWL-S.

5 SAMPLE SCENARIO

As a sample scenario, consider a SHE in which Steve

usually lives alone, but is occasionally visited by his

relatives, friends and girlfriend (Tina). It is Friday

evening, and based on the user’s proﬁle and cur-

rent context the system has inferred the need for

pursuing the goal ‘relaxing

amusement’. The cor-

responding workﬂow extracted from the repository

is ‘evening

at home’. The system loads the corre-

PECCS2015-5thInternationalConferenceonPervasiveandEmbeddedComputingandCommunicationSystems

164

(a) (b)

Figure 2: Choose Pizza service sequences (a) and Order Pizza service sequences (b).

sponding model and starts checking complianceof the

user’s actions with this model (in addition to carrying

out normal control activities over the environment).

Tina is also present.

At some point during workﬂow enactment, the

system foresees that the user will almost certainly per-

form task ‘dinner’ and, concurrently, ‘watch

movie’

or ‘watch football’.

• Dinner, is a complex activity that may be carried

out according to different sub-workﬂows: ‘for-

mal

dinner’, ‘informal dinner’, or ‘fast dinner’.

Since a precondition for ‘formal dinner’ is that

the user has dressed elegant clothes, and that

the ‘relax

amusement’ goal is not active, the

system discards the ‘formal

dinner’ option, and

starts checking compliance of the user’s actions

with the remaining two models. These actions

cause more warnings on ‘informal

dinner’ than

on ‘fast

dinner’ (e.g., activities ‘set table’ and

‘use kitchen’, required by the former, are not exe-

cuted), for which reason the latter is deemed as

more likely to be running. While tracking this

process, at some point the system foresees that the

user will carry out activities ‘pizza’ and ‘beer’. As

to the latter, it immediately activates suitable ef-

fectors to start cooling a beer. As to the former, no

pizza is available at home, so it must be ordered.

• As to the ‘watch

movie’ vs. ‘watch football’ op-

tion, the precondition for the latter requires,

among other features, that it must be Wednes-

day and that Steve’s girlfriend must not be present

(because, according to her proﬁle, she doesn’t

like football). Due to these requirements be-

ing not fulﬁlled, the option is discarded, and the

‘watch movie’ action is pursued.

Both actions ‘pizza’ and ‘watch

movie’ can be carried

out by the system by calling corresponding (compo-

sitions of) Web Services. E.g., suppose that no single

Web service is available to order a pizza, nor a com-

posite service is known to the system to do this. In

this case, the system activates the Service Composer

to ﬁnd one.

For instance, the set of available services, anno-

tated in OWL-S, might be as reported in Table 1. Us-

ing the OWL-S composer, the agent obtains the com-

positions in Figure 2. Note that different services use

different ontologies. These ontologies have been pre-

viously aligned, to know which classes of the former

are equivalent to which ones of the latter. Given the

compositions, the agent executes the following steps:

1. it uses the composition in Figure 2(a) to evalu-

ate what sequence of services best matches its

requirement (examples of evaluation conditions

might be a lower price or the possibility to change

the order);

2. it uses the composition in Figure 2(b) to evaluate

whether the sequence of services for the dealer se-

lected in the previous step can be used (i.e., it has

all the required input parameter values); if needed

or appropriate, it may consider the other services

offered by the provider (e.g., SpizzicoRegistration

or SpizzicoRechargeService for Spizzico);

3. in case the selected sequence is not applicable, it

goes back to step 1 to select another sequence, not

considering anymore the evaluated sequence;

4. it executes the chosen service sequence and ob-

tains the order receipt.

The agent might apply the same procedure to order

the movie.

6 CONCLUSIONS

This paper describes the architecture and functional-

AnAgentArchitectureforAdaptiveSupervisionandControlofSmartEnvironments

165

Table 1: Set of services annotated in OWL-S.

Spizzico PizzaHut RossoPomodoro GenericServices

SpizzicoMenu: given the requester’s

address and the name of the desired

Pizza, returns the internal Spizzico

Pizza code and the price, or an

unavailability message in case no

Dealer exists within acceptable dis-

tance.

• Input: Address, PizzaName

• Output: SpPizzaCode, Price

• Precondition: Ex-

ist(PizzaName) and Avail-

ableDealer(Address, Piz-

zaName)

SpizzicoOrder: given a Spizzico code,

a date and time, an optional address

and a userCode, returns a receipt

(with no more than half an hour

later than the time required) or an

unavailability message in case the

required pizza cannot be ordered or

the credit is insufﬁcient.

• Input: PizzaCode, DateAnd-

Time, Address, userCode

• Output: receipt or NotAvail-

ableMSG

• Precondition:

Valid(PizzaCode) and Ex-

ist(userCode) and ValidTime

(DateAndTime)

SpizzicoRegistration: the registration

is needed to use the home delivery

service.

• Input: userName, password,

address, city

• Output: userCode

SpizzicoRechargeService: allows to

charge the amount associated to

user code.

• Input: userCode, creditCard-

Number, amount

• Output: userCode

HutMenu: given the requester’s ad-

dress and the name of the desired

Pizza, returns its price.

• Input: Address, PizzaName

• Output: Price

• Precondition: Ex-

ist(PizzaName) and Avail-

ableDealer(Address, Piz-

zaName)

HutOrder: given a pizza name, a date

and time, the requester’s GPS co-

ordinates, a phone number for the

delivery and a credit card number,

returns a receipt with date and time

or an unavailability messagein case

the required pizza cannot be or-

dered or the distance is too long.

• Input: pizzaName, dateAnd-

Time, GPS, phoneNum, Cred-

itCardNum

• Output: receipt or NotAvail-

ableMSG

• Precondition: Ex-

ist(PizzaName) and Ex-

ist(userCode) and Valid (Date-

AndTime) and Valid(GPS)

RossoMenu: given theGPS coordinates

of requester and the name of the

desired Pizza, returns a Pizza code

with a grade of Semantic Match-

ing (0 the required pizza, 1 a pizza

with less ingredients, 2 a similar

pizza with some different ingredi-

ents) and the price or unavailability

message in case a Dealer does not

exists within acceptable distance.

• Input: GPS, PizzaName

• Output: PizzaCode, grade,

Price

• Precondition: Avail-

ableDealer(GPS, PizzaName)

RossoOrder: given a pizza code, a date

and time, an address, a doorphone

number and a credit card number,

returns an order code (allowing to

change the order until 3 hours be-

fore) or an unavailability message

in case the required pizza cannot be

ordered or the credit is insufﬁcient.

• Input: PizzaCode, DateAnd-

Time, Address, doorPho-

neNum, CreditCardNum

• Output: orderCode or No-

tAvailableMSG

• Precondition: Valid-

Code(PizzaCode) and

Valid(Address) and Valid-

Time (DateAndTime) and

Valid(CreditCardNum)

RossoChangeOrder:

• Input: orderCode, DateAnd-

Time

• Output: orderCode or No-

tAvailableMSG

AddressTranslator: given an address,

returns the corresponding GPS Co-

ordinates.

• Input: address

• Output: GPS

PizzaTranslator: given a listof ingredi-

ents, returns the PizzaName having

those ingredients.

• Input: IngredientList

• Output: PizzaName

ity of a generic agent that is in charge of handling a

given environment in an AmI context, ensuring suit-

able contextualized and personalized support to the

user’s actions, adaptivity to the user’s peculiarities

and to changes over time, and automated management

of the environment itself.

The architecture is implemented in a multi-agent

system, where different types of agents are in charge

of performing different tasks. At different levels, they

are endowed with reasoning and learning capabili-

ties, and are coordinated by a ‘butler’. In addition to

controlling normal operations of the environment, the

butler may identify user’s needs and goals and acti-

vate suitable workﬂows to satisfy them. Some actions

in these workﬂow involve the execution of semantic

services. When a single service is not available for

fulﬁlling a given need, an automatic service composer

is used to obtain a suitable combination of services.

The architecture has been implemented in a pro-

totypical agent-based system that works in a smart

home environment. It is currently undergoing exten-

sion and reﬁnement in order to make it able to deal

with more varied and complex situations.

ACKNOWLEDGEMENTS

This work was partially funded by the Ital-

ian PON 2007-2013 project PON02

00563 3489339

‘Puglia@Service’.

REFERENCES

Ayala, I., Amor, M., and Fuentes, L. (2012). Self-

conﬁguring agents for ambient assisted living appli-

cations. Personal and Ubiquitous Computing, pages

1–11.

Bezold, M. (2010). A framework for adapting interactive

systems to user behavior. Journal of Ambient Intelli-

gence and Smart Environments, 2:369–387.

Blumendorf, M. and Albayrak, S. (2009). Towards a frame-

work for the development of adaptive multimodal user

PECCS2015-5thInternationalConferenceonPervasiveandEmbeddedComputingandCommunicationSystems

166

interfaces for ambient assisted living environments.

In Proceedings of the 5th International on Confer-

enceUniversal Access in Human-Computer Interac-

tion (UAHCI ’09) – Part II, pages 150–159. Springer.

Cavone, D., De Carolis, B., Ferilli, S., and Novielli, N.

(2012). A multiagent system supporting situation

aware interaction with a smart environment. In 2nd

Int. Conf. on Pervasive Embedded Computing and

Communication Systems (PECCS-2012), pages 67–

72. SciTePress.

Chun-dong, W., Xiu-liang, M., and Huai-bin, W. (2009). An

intelligent home middleware system based on context-

awareness. In Fifth International Conference on Nat-

ural Computation, pages 165–169. IEEE.

Cook, D. (2009). Multi-agent smart environments. Jour-

nal of Ambient Intelligence and Smart Environments,

1:47–51.

Cook, D., Augusto, J., and Jakkula, V. (2009). Ambient

intelligence: Technologies, applications, and opportu-

nities. Pervasive and Mobile Computing, 5:277–298.

D’Andrea, A., D’Ulizia, A., Ferri, F., and Grifoni, P. (2009).

A multimodal pervasive framework for ambient as-

sisted living. In Proceedings of the 2nd International

Conference on PErvasive Technologies Related to As-

sistive Environments, PETRA ’09, pages 39:1–39:8.

ACM.

De Carolis, B., Cozzolongo, G., Pizzutilo, S., and Planta-

mura, V. (2005). Agent-based home simulation and

control. In International Symposium on Methodolo-

gies for Intelligent Systems (ISMIS), pages 404–412.

Dey, A. (2001). Understanding and using context. Personal

and Ubiquitous Computing, 5:4–7.

Ferilli, S. (2014). WoMan: Logic-based Workﬂow Learn-

ing and Management. IEEE Transaction on Systems,

Man and Cybernetics: Systems, 44:744–756.

Ferilli, S., Cavone, D., Carolis, B. D., and Novielli, N.

(2011). A layered architecture for situation-aware

home environments. In 6th Int. Workshop on Artiﬁ-

cial Intelligence Techniques for Ambient Intelligence

(AITAmI 2011), page 12.

Humble, J., Crabtree, A., Hemmings, T.,

Akesson, K.-P.,

Koleva, B., Rodden, T., and Hansson, P. (2003). Play-

ing with the bits - user-conﬁguration of ubiquitous do-

mestic environments. volume 2864 of Lecture Notes

in Computer Science, pages 256–263.

Kim, J., Spraragen, M., and Gil, Y. (2004). An intelligent

assistant for interactive workﬂow composition. In 9th

Int. Conf. on Intelligent User Interfaces, pages 125–

131. ACM Press.

Mars´a-Maestre, I., L´opez-Carmona, M. A., Velasco, J. R.,

and Navarro, A. (2008). Mobile agents for service per-

sonalization in smart environments. Journal of Net-

works, 3:30–41.

McNaull, J., Augusto, J., Mulvenna, M., and McCullagh, P.

(2011). Multi-agent interactions for ambient assisted

living. In Intelligent Environments, pages 310–313.

Meyer, H. (2007). On the semantics of service composi-

tions. volume 4524 of Lecture Notes in Computer Sci-

ence, pages 31–42.

Motik, B., Sattler, U., and Studer, R. (2005). Query An-

swering for OWL-DL with rules. Journal of Web Se-

mantics: Science, Services and Agents on the World

Wide Web, 3(1):41–60.

Mozer, M. C. (2005). Lessons from an adaptive house. In

Cook, D. and Das, R., editors, Smart environments:

Technologies, protocols, and applications, pages 273–

294. J. Wiley & Sons.

O’Grady, M., Muldoon, C., Dragone, M., Tynan, R., and

O’Hare, G. (2010). Towards evolutionary ambient as-

sisted living systems. Journal of Ambient Intelligence

and Humanized Computing, 1:15–29.

Paik, I. and Maruyama, D. (2007). Automatic web services

composition using combining HTN and CSP. In Conf.

on Computer and Information Technology (CIT 2007).

Rao, A. and Georgeff, M. (1991). Modeling rational agents

within a bdi-architecture. In Proc. 2nd Int. Conf. on

Principles of Knowledge Representation and Reason-

ing, pages 473–484.

Rao, S. and Cook, D. J. (2004). Predicting inhabitant ac-

tions using action and task models with application to

smart homes. International Journal of Artiﬁcial Intel-

ligence Tools, 13:81–100.

Redavid, D., Ferilli, S., and Esposito, F. (2013). To-

wards dynamic orchestration of semantic web ser-

vices. Transactions on Computational Collective In-

telligence, 10:16–30.

Sernani, P., Claudi, A., Palazzo, L., Dolcini, G., and Drag-

oni, A. (2013). Home care expert systems for ambient

assisted living: A multi-agent approach. In Workshop

on The Challenge of Ageing Society: Technological

Roles and Opportunities for Articial Intelligence, vol-

ume 1122, pages 1–16. CEUR Workshops.

Sun, H., Florio, V. D., Gui, N., and Blondia, C. (2009).

Promises and challenges of ambient assisted living

systems. In 6th Int. Conf. on Information Technology:

New Generations (ITNG ’09), pages 1201–1207.

Wolf, P., Schmidt, A., Otte, J., Klein, M., Rollwage,

S., Konig-Ries, B., and Gabdulkhakova, A. (2010).

Openaal - the open source middleware for ambient-

assisted living (AAL). In AALIANCE conf., pages 1–

Wooldridge, M. and Jennings, N. (1995). Intelligent agents:

Theory and practice. Knowledge engineering review,

10:115–152.

Wu, C.-L., Liao, C.-F., and Fu, L.-C. (2007). Service-

oriented smart-home architecture based on osgi and

mobile-agent technology. IEEE Transactions on Sys-

tems, Man, And Cybernetics – Part C: Applications

and Reviews, 37.

Yau, S. and Liu, J. (2006). Incorporating situation aware-

ness in service speciﬁcations. In 9th IEEE Int. Symp.

on Object and Component-oriented Real-time Dis-

tributed Computing (ISORC), pages 287–294.

AnAgentArchitectureforAdaptiveSupervisionandControlofSmartEnvironments

167
