Enforcing Data Protection Regulations within e-Government Master
Data Management Systems
Federico Piedrabuena, Laura González and Raúl Ruggia
Instituto de Computación, Facultad de Ingeniería, Universidad de la República,
J. Herrera y Reissig 565, Montevideo, Uruguay
Keywords: Master Data Management, e-Government, Data Protection, Information as a Service.
Abstract: The growing adoption of information technology by governments has led to the implementation of e-
Government systems which are usually supported by middleware-based integration platforms. In particular,
the increasing need of information sharing across government agencies has motivated the implementation of
shared Master Data Management (MDM) Systems. On the other hand, these systems have to comply with
Data Protection regulations which may hinder an extensive reuse of information in a government context.
This paper addresses the issues of enforcing Data Protection (DP) regulations in e-Government MDM
systems. In particular, it analyzes the requirements that DP issues pose on these systems and it proposes
solutions, which leverage middleware-based capabilities and traditional MDM systems, to enforce these
regulations considering different MDM architecture styles.
1 INTRODUCTION
E-Government systems have been increasingly
implemented to improve the quality of public
services by providing relevant information and self-
services to citizens as well as by enabling a more
effective inter-organizational coordination among
public agencies and partners (Akeroyd, 2009). These
systems are usually based on middleware platforms
providing capabilities to interconnect agencies
(Baldoni et al., 2008)(González et al., 2012).
Information sharing is at the root of e-
Government as it is required to achieve a consistent
systems’ interoperability as well as to promote
efficiency by reducing duplication of effort in
collecting and storing information (Akeroyd, 2009).
This has motivated the inclusion of an “Information
dimension” in e-Government architectures.
Furthermore, ensuring the quality of shared data and
the application of rigorous management practices
have motivated the adoption of Master Data
Management (MDM) as a key component in e-
Government (Boydens, 2011).
Briefly, MDM systems consist of Information
Systems on core business data enriched with tools
and management practices. In this way, MDM
systems provide an integration and quality assurance
tier between business components implementing
public services and data distributed in organizations
connected through the e-Government system
(Dreibelbis et al., 2008).
In turn, a major challenge to inter-organizational
data sharing concerns the application of Data
Protection (DP) and other privacy-related
regulations which are nowadays adopted by a large
number of countries (Del Villar et al., 2001). This
fact may hinder an extensive reuse of information in
a government context, as shown in some empirical
studies (Lips et al., 2011), because they oblige to
perform a number of validations about the origins,
purpose and existing consents prior to share data.
This paper addresses the issues of enforcing Data
Protection regulations within e-Government MDM
systems by analyzing the requirements that these
issues pose and proposing enforcement solutions
considering the different MDM architecture styles.
The proposed solutions leverage capabilities of
middleware-based integration platforms (e.g. data
transformation) and traditional MDM systems as
well as broadly recognized standards (e.g. XACML).
The rest of the paper is organized as follows.
Section 2 presents background. Section 3 analyses
the requirements for a Data Protection-aware e-
Government MDM system. Section 4 proposes a
solution approach to address these requirements.
316
Piedrabuena F., González L. and Ruggia R..
Enforcing Data Protection Regulations within e-Government Master Data Management Systems.
DOI: 10.5220/0005458003160321
In Proceedings of the 17th International Conference on Enterprise Information Systems (ICEIS-2015), pages 316-321
ISBN: 978-989-758-098-7
Copyright
c
 2015 SCITEPRESS (Science and Technology Publications, Lda.)

Finally, Section 5 presents conclusions.
2 BACKGROUND
2.1 Master Data Management
Master Data Management (MDM) delivers a
consolidated, complete and accurate view of
business critical Master Data (MD) in an
organization or business area. MD are compose by
concepts and attributes such as “person” with
“name” and “birthday” or “product” with “color” or
“size”. Given the strategic nature of MD, quality and
reliability must be ensured. Therefore, well defined
Data Management and Governance practices
(Mosley et al., 2010) are established to MD and
constitute the roots of MDM.
Functions to manage MD lifecycle are
implemented in MDM Systems (MDMS). Design
and maintenance of the MDMS architecture is one
of the main MDM activities. This architecture
controls the shared access, data maintenance,
replication and flow of data with the goal of
ensuring their quality (Mosley et al., 2010). Several
architecture styles for MDMS are identified and
described throughout the literature with different
names and characteristics (Dreibelbis et al., 2008)
(Loshin, 2010) (Galhardas et al., 2010) (Baghi et al.,
2014)(Otto, 2012). This work summarizes these
styles in two approaches: Repository and Registry.
The Repository style involves storing the entire
data set (i.e. all MD attributes used in any and all
software applications) in a single database. Data
requests from clients are resolved by a central
MDMS without interacting with source systems
(application software data provider).This style has
three variants depending on where MD is maintained
(i.e. created, updated and deleted): i) Consolidation;
ii) Centralized; and iii) Coexistence. In the
consolidation variant all MD maintenance activities
are performed by local source systems and data
changes flow from these systems to the MDMS. In
the centralized variant all MD maintenance activities
are performed by MDMS and data changes flow
from the MDMS to target systems. Finally, the
coexistence variant is a combination of the previous
ones and data changes flow bidirectional.
The Registry style consists of only storing
references to actual MD attributes. Data requests
from clients are resolved by the MDMS by
interacting with the systems to retrieve MD.
These two architectural styles can also be
combined to implement hybrid solutions where, for
example, a portion of the MD is consolidated in the
MDMS and sensitive data is kept in source systems.
Three main stages can be identified in MD
lifecycle: i) maintenance (i.e. MD creation,
modification or deletion), ii) synchronization (i.e.
propagation of MD changes within the MDMS), and
iii) request (i.e. clients asks for MD to the MDMS).
2.2 E-Government Platforms
Integration Platforms have become a key tool to
support the development of e-Government in many
countries. They usually provide infrastructure and
capabilities aiming at facilitate the interconnection
between agencies as well as provide common
services to generate economy of scale and encourage
the development of multi-agency services (González
et al., 2012). Common capabilities are connectivity,
security (e.g. authentication), interoperability (e.g.
through the use of standards) and mediation services
implementing Enterprise Integration Patterns (EIP),
e.g. data transformation (Hohpe and Woolf, 2003).
The mediation and interoperability capabilities are
usually provided by traditional middleware
technologies, such as SOAP Web Services and
Enterprise Service Bus (ESB). In addition, security
capabilities usually rely on well-stablished standards
such as XACML (OASIS, 2013).
2.3 Data Protection Regulations
Personal data handled by governments are often very
sensitive (Wu, 2014). Indeed, their analysis can be
highly invasive when data is combined and
aggregated. As a result, most governments have
developed some sort of legislation focusing on Data
Protection (DP) with rather different approaches
(Akeroyd, 2009)(Wu, 2014). They mainly deal with
the re-use of information in other contexts for which
it was provided. Particularly, in many countries
(González et al., 2012) citizens have to provide
explicit consents which allow agencies to use / share
their information. As shown in Figure 1, in this kind
of laws citizens provide to agencies the consents to
Figure 1: Common concepts in DP Regulations.
EnforcingDataProtectionRegulationswithine-GovernmentMasterDataManagementSystems
317

use or share, with other agencies, sensitive data for a
given purpose and within a given time period.
2.4 Relevant Standards
ISO/IEC 8000-1X0:2009 is a family of standards
which deals with the requirement of using a pre-
established format for communicating MD, as well
as their quality level, between applications (Ismael
Caballero et al., 2013). In particular, the ISO 8000-
120:2009 part (ISO/IEC, 2009) specifies how
information is included in the exchanged messages
to describe the MD provenance. For example,
attributes are defined to specify the event type
performed over data, the date in which the event was
performed, the organization which provides the MD
and the organization that owns the MD, among
others (Ismael Caballero et al., 2013).
XACML (OASIS, 2013) is a specification that
describes a language for defining access control
policies as well as a language to request and
response access control decisions in XML. Usually,
a requester tries to run an action on a resource by
sending a request to the component that protects it:
Policy Enforcement Point (PEP). The PEP performs
an authorization request based on attributes of the
requester, the resource, the action to be executed and
any other relevant information. This request is sent
to a Policy Decision Point (PDP) which issues a
response indicating if access should be allowed
based on the request and policies managed through a
Policy Administration Point (PAP). Also, a Policy
Information Point (PIP) may be used if additional
information for taking the authorization decision is
needed. Based on the authorization response, the
PEP allows or denies access to the requester.
2.5 Related Work
Some authors have addressed the potentials and
challenges of MDM in e-Government and large-
scale collaborative systems (Akeroyd, 2009)(Yang
and Maxwell, 2011). Also, enforcing DP regulations
in cross-organizational data exchanges has been
addressed in (Armellin et al., 2010) (Sillaber and
Breu, 2012)(Stevovic et al., 2013). Still, to the best
of our knowledge, there are neither proposals that
jointly address the issues of DP and e-Government
MDM Systems nor solutions that leverage
middleware-based capabilities to solve them.
Finally, although some MDM products deal with
data privacy, they focus on solutions of lower level
of abstraction (e.g. data encryption) compared to our
approach (e.g. handling citizen consents).
3 REQUIREMENTS FOR
ENFORCING DP
This section establishes the e-Government MDM
context over which this work is based and analyses
the requirements for enforcing DP regulations in it.
3.1 E-Government MDM Context
E-Government systems usually have the following
characteristics: i) inter-organizational interactions;
ii) need to share data of citizens; iii) agreements on
data structure of shared information; iv) regulatory
bodies (e.g. supervisory agency); and v) use of
integration platforms. Figure 2 shows the MDM e-
Government context taken as a base for this work.
Figure 2: General MDM e-Government Context.
All interactions between public agencies pass
through an Integration Platform (InP) maintained by
a supervisory agency. This platform provides basic
mediation capabilities (e.g. data transformation) and
security services (e.g. authentication). It is also
responsible for hosting the MDM system which, in
particular, handles citizens’ data.
MDM interactions that pass through the InP take
place when MD is maintained (if this is done at the
InP, e.g. with a centralized repository style),
synchronized (between the InP and public agencies)
or requested (e.g. by other agencies or partners).
Public agencies share citizens’ data using a state-
wide agreed data model, which is a superset of the
MD schema, and following the IaaS approach (i.e.
via services). In particular, the MDM system
provides / consumes information services, sending
messages (e.g. SOAP messages) over the platform,
to get / send citizens MD attributes. These messages
are compliant with the family of standards ISO/IEC
8000-1X0:2009 (e.g. they include provenance data).
Figure 3 presents a citizens’ MD schema, taken
as a case study in the rest of the paper, and the
structure of messages sent and received through InP
to share data. Note that besides citizens’ data, the
message includes information of its origin, its
destination, the sender and provenance data.
ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems
318

MessageStructure
ORIGIN:
Agency‐A
DESTINATION:
Agency‐B
IDENTIFICATION:
Role:doctor
User:smith
BUSINESSDATA:
<citizen>
<name>John</name>
‐‐‐‐‐‐‐‐‐‐
</citizen>
PROVENANCEDATA:
<provenance>
<date>….</date>
‐‐‐‐‐‐‐‐‐
</provenance>
‐name:String
‐lastname:String
‐birthday:Date
‐sex:Char
‐address:String
‐email:String
Person
Figure 3: Master Data Schema and Structure of Messages.
3.2 Analysis of Requirements
A solution that allows a supervisory agency to
guarantee that all MDM interactions comply with
DP regulations in the presented context has the
following four general requirements:
RQ1: It has to monitor and enforce DP
regulations through components hosted in the InP.
This is because: i) the supervisory agency needs full
control over the enforcing mechanisms as well as the
penalty actions to be taken if a regulation is not
satisfied, and ii) some public agencies may not have
the infrastructure to host the required components.
RQ2: It has to monitor and enforce all MDM
interactions performed within the InP (i.e. when
maintaining, synchronizing and requesting MD).
RQ3: It has to allow maintaining the category
(i.e. sensitive or public) of each MD attribute, the
consents provided by citizens and current DP
policies. This is required to know if a given
interaction is compliant with the regulations.
RQ4: It has to be able to handle and obtain other
required information to verify the compliance of the
interactions. This includes: i) information required in
the requests (e.g. purpose for which the MD is
requested); and ii) information not included in the
MD schema (e.g. nationality) that may be required
to verify the compliance of the interactions.
4 PROPOSED APPROACH
This section describes a high level architecture of
the proposed approach, the process for designing an
extended MD and how DP regulations are enforced
in the different MDM interactions.
4.1 High Level Architecture
Figure 4 presents a high level architecture of the
proposed solution which includes several specialized
components hosted in the InP.
First, the Consent Management System (CMS) is
in charge of maintaining citizens’ consents
Figure 4: High Level Architecture of the Proposal.
according to the conceptual model of Figure 1.
Ideally, it may provide a web-based user interface so
citizens can manage their own consents.
Second, various components following the
XACML standard are included. The Data Protection
Administration Point (DPAP) has the responsibility
of managing the DP policies and the category of
each MD attribute. The Data Protection Information
Point (DPIP) has the function of obtaining additional
information required to take an authorization
decision; this information may be part of the MD or
may have to be obtained from external systems. The
Data Protection Decision Point (DPDP) is in charge
of taking an authorization decision based on the data
included on the requests, current policies and,
eventually, additional information obtained from the
DPIP. Lastly, the Data Protection Enforcement Point
(DPEP) is responsible for enforcing regulations by:
i) intercepting all MDM interactions; ii) requesting
the DPDP an authorization decision; and iii) acting
accordingly (e.g. blocking an interaction).
Third, two specialized components based on
well-stablished EIP are also included. The Master
Data Enricher (MDE), based on the content-enricher
EIP, is in charge of complementing the MD (e.g. at
synchronization time) with information required to
take the authorization decision. This information,
may consist of additional MD attributes (e.g.
nationality) or metadata (e.g. provenance). In turn,
the Master Data Filter (MDF), based on the content-
filter EIP, has the function of taking out MD
attributes from a MDM interaction in case they are
not allowed to be used or shared. The DPEP may
decide to route an interaction to this component
based on the response from the DPDP. In addition,
the DPDP may decide to route an interaction to other
EIP-based components (not included in Figure 4),
for example, to log or notify interested parties.
The Extended MD is MD augmented with
additional data required to take authorization
decisions. This may be new MD concepts or
attributes (e.g. nationality) as well as metadata (e.g.
provenance). Other required information to take
these decisions may not be included in the Extended
MD due to it comes from sources outside the
MDMS or it is not citizen information.
EnforcingDataProtectionRegulationswithine-GovernmentMasterDataManagementSystems
319

Lastly, the solution requires MDM interactions
to include the purpose for which MD are shared or
requested. This can be done with the elements
defined in the XACML Privacy Policy Profile.
Note that all components are hosted in the InP
which fulfills RQ1. RQ2 is mainly achieved by the
DPEP and MDF components and RQ3 is satisfied by
the CMS and DPAP components. Lastly, RQ4 is
achieved by the DPIP and MDE components.
4.2 Extended MD Design
The process to extend MD takes as input the original
MD and DP policies and consists of the following
steps: 1) identify required data to take authorization
decisions and indicate if they should be included in
the MD or not, 2) identify sensitive data in the
original MD and in the additional data identified in
the previous step, and 3) include provenance
attributes for each sensitive attribute.
Figure 5 presents the result of applying the above
steps to the example presented in Figure 3. In this
example nationality is an additional required
attribute and is added to the original MD.
Figure 5: Extended MD Design Steps.
4.3 Enforcing DP in MDM Interactions
This section describes how the proposed solution
enforces DP regulations within MDM interactions
(maintenance, synchronization and requests) in view
of the different architecture styles.
MD maintenance interactions pass through the
InP when the coexistence or centralized variants of
the repository approach are used. In these cases, the
interactions have to include a purpose with the value
“MDM-maintain”. The DPEP has to allow these
interactions if citizens informed consents for using
all MD attributes involved in the operation, to the
supervisory agency and for the purpose of
maintaining (MDM-maintain). Also, if the operation
is “insert” or “update”, the interaction is routed to
the MDE to perform MD augmentation. In these
cases, obtaining provenance data is trivial, since MD
is maintained at the supervisory agency.
MD synchronization interactions pass through
the InP when the repository approach is used. In
these cases, the interactions have to include a
purpose with the value “MDM-synchronize”. The
DPEP has to allow these interactions if citizens
informed consents for sharing all MD attributes
involved in the operation, from the source agency to
the target agency (supervisory or others) and for the
purpose of synchronizing (MDM-synchronize).
Also, if MD is being inserted or updated the
interaction is routed to the MDE to perform MD
augmentation. In these cases, provenance data is
obtained from the messages, given that they are
compliant with the standard ISO 8000-120:2009.
MD requests pass through the InP when using
both approaches: Registry and Repository. In these
cases, the purpose included in the interactions is
business-oriented (e.g. it refers to a specific e-
Government procedure). The DPEP has to allow
these interactions if citizens informed consents for
sharing all MD attributes involved in the operation,
from their source agency to the requesting agency
(client) and for the purpose specified in the request.
The source agency of a given attribute is obtained
from the provenance data (already stored in the InP
if a repository style is used or coming in the MDM
response messages if a registry style is used).
In all the interactions, if citizens only provide
consents for a subset of the involved MD attributes,
the interactions are routed to the MDF to take out
the attributes which are not allowed to be used or
shared. Also, some attributes may be encrypted if
they cannot be shared with the supervisory agency
but they can be shared with other agencies.
Finally, other DP-related issues affecting MDM
interactions are currently being analyzed. Some of
them include: i) DP requirements on the additional
information required to take authorization decisions,
and ii) variants of different synchronization styles
(e.g. notification, request-response).
5 CONCLUSIONS
This paper analyzes requirements to enforce Data
Protection in e-Government-based Master Data
systems and depicts solutions to guarantee that
Master Data interactions comply with these
regulations. The overall goal is to carry out efficient
DP enforcement in inter-organizational contexts
using shared MDMS and e-Government platforms.
To achieve this, the proposed approaches point at
ICEIS2015-17thInternationalConferenceonEnterpriseInformationSystems
320

using the e-Government platform as a common
component to control DP compliance as well as to
enforce regulations by transforming data and
operation flows. Such solutions leverage
mechanisms of mainstream middleware technologies
and of MDM systems in addition to apply
recognized standards (e.g. XACML, ISO/IEC 8000).
The main contributions of this ongoing work are:
i) identifying requirements of a DP aware MDM e-
Government system, ii) specifying a reference
architecture to enforce DP in these systems, and iii)
proposing enforcement mechanisms (e.g. MD filter).
Moreover, this work constitutes a step forward on
addressing the issues of regulatory compliance in e-
Government systems (González and Ruggia, 2014).
ACKNOWLEDGEMENTS
This work was partially funded by the Comisión
Sectorial de Investigación Científica (CSIC),
Universidad de la República, Uruguay.
REFERENCES
Akeroyd, J., 2009. Information Architecture and e-
Government. INFuture2009“Digital Resour. Knowl.
Shar.
Armellin, G., Betti, D., Casati, F., Chiasera, A., Martinez,
G., Stevovic, J., 2010. Privacy Preserving Event
Driven Integration for Interoperating Social and
Health Systems, in: Secure Data Management, Lecture
Notes in Computer Science. Springer, pp. 54–69.
Baghi, E., Schlosser, S., Ebner, V., Otto, B., Oesterle, H.,
2014. Toward a Decision Model for Master Data
Application Architecture, in: 2014 47th Hawaii
International Conference on System Sciences
(HICSS). pp. 3827–3836.
Baldoni, R., Fuligni, S., Mecella, M., Tortorelli, F., 2008.
The Italian e-Government Enterprise Architecture: A
Comprehensive Introduction with Focus on the SLA
Issue, in: Service Availability, Lecture Notes in
Computer Science. Springer Berlin Heidelberg, pp. 1–
12.
Boydens, I., 2011. Strategic Issues Relating to Data
Quality for E-Government: Learning from an
Approach Adopted in Belgium, in: Assar, S.,
Boughzala, I., Boydens, I. (Eds.), Practical Studies in
E-Government. Springer New York, pp. 113–130.
Del Villar, R., de Leon, A.D., Hubert, J.G., 2001.
Regulation of Personal Data Protection and of
Reporting Agencies: a Comparison of Selected
Countries of LA, the US and EU Countries. MIT
Press.
Dreibelbis, A., Hechler, E., Milman, I., Oberhofer, M.,
Run, P. van, Wolfson, D., 2008. Enterprise Master
Data Management: An SOA Approach to Managing
Core Information. Pearson.
Galhardas, H., Torres, L., Damásio, J., 2010. Master data
management: a proof of concept, in: International
Conference on Information Quality.
González, L., Ruggia, R., 2014. Towards a Compliance-
Aware Inter-organizational Service Integration
Platform, in: On the Move 2014 Workshops, LNCS.
Springer Berlin Heidelberg.
González, L., Ruggia, R., Abin, J., Llambías, G., Sosa, R.,
Rienzi, B., Bello, D., Alvarez, F., 2012. A Service-
oriented Integration Platform to Support a Joined-up
E-government Approach: The Uruguayan Experience,
in: Joint International Conference on Electronic
Government, the Information Systems Perspective,
and Electronic Democracy. Austria.
Hohpe, G., Woolf, B., 2003. Enterprise Integration
Patterns: Designing, Building, and Deploying
Messaging Solutions. Addison-Wesley.
Ismael Caballero, Isabel Bermejo, Luisa Parody, María
Teresa Gómez López, Rafael Gasca, Mario Piattini,
2013. I8k: an Implementation of ISO 8000-1x0.
Presented at the 10th International Conference on
Information Quality, USA.
ISO/IEC, 2009. ISO/DIS 8000-120. Master data:
Exchange of characteristic data: Provenance.
Lips, A.M.B., O’Neill, R.R., Eppel, E.A., 2011. Cross-
agency collaboration in New Zealand: An empirical
study of information sharing practices, enablers and
barriers in managing for shared social outcomes. Int. J.
Public Adm. 34, 255–266.
Loshin, D., 2010. Master Data Management. Morgan
Kaufmann.
Mosley, M., Brackett, M.H., Earley, S., Henderson, D.,
2010. The DAMA Guide to the Data Management
Body of Knowledge: (DAMA-DMBOK Guide).
Technics Publications, LLC.
OASIS, 2013. eXtensible Access Control Markup
Language (XACML) v3.
Otto, B., 2012. How to design the master data architecture:
Findings from a case study at Bosch. Int. J. Inf.
Manag. 32, 337–346.
Sillaber, C., Breu, R., 2012. Managing legal compliance
through security requirements across service provider
chains: A case study on the German Federal Data
Protection Act., in: GI-Jahrestagung.
Stevovic, J., Casati, F., Farraj, B., Li, J., Motahari-Nezhad,
H.R., Armellin, G., 2013. Compliance aware cross-
organization medical record sharing, in: 2013
IFIP/IEEE International Symposium on Integrated
Network Management.
Wu, Y., 2014. Protecting personal data in E-government:
A cross-country study. Gov. Inf. Q. 31.
Yang, T.-M., Maxwell, T.A., 2011. Information-sharing in
public organizations: A literature review of
interpersonal, intra-organizational and inter-
organizational success factors. Gov. Inf. Q. 28.
EnforcingDataProtectionRegulationswithine-GovernmentMasterDataManagementSystems
321
