Privacy Issues and Pitfalls in VANET Standards

Sebastian Bittl and Arturo A. Gonzalez

Fraunhofer ESK, Munich, Germany

Keywords:

Privacy, Tracking, VANET, ETSI ITS, WAVE.

Abstract:

Wireless vehicular networks are about to enter the deployment stage in the next years with important progress

being made in Europe and the USA. Thereby, one of the core concerns is privacy of vehicles and their drivers,

especially in Europe. Prior work has regarded only a small sub-set of the information exposed by current

standards to an attacker for vehicle tracking. Thus, we take a close look on the data contained on different

protocol layers of an ETSI ITS system. We ﬁnd that much data is very distinctive and can be used to identify

static vehicle parameters such as manufacturer or even model. This greatly reduces the usability of formerly

proposed cooperative pseudonym switching strategies. Many more constraints have to be applied for selecting

cooperation partners signiﬁcantly reducing their availability. Therefore, current techniques cannot provide the

level of privacy deﬁned in VANET standards. Suggestions for improving the security entity and facility layer

of ETSI ITS are given to limit the impact of the found issues.

1 INTRODUCTION

Wireless intelligent transport systems (ITS) are about

to enter the mass marking in upcoming years. Impor-

tant examples being ETSI ITS in Europe (MoU, 2011)

and WAVE in the USA (J. Harding et. al., 2014).

Thus, these systems’ security and privacy aspects are

gaining increased attention. Thereby, the possibility

to track vehicles is a core point of concern, espe-

cially in Europe (Sch

utze, 2011). Many approaches

for realizing such tracking exist. Typically, such at-

tacks use the temporarily ﬁxed pseudonym certiﬁcate,

used by vehicles to authenticate their broadcast mes-

sages. However, higher level protocol information,

e.g., identiﬁers or current position and velocity of a

vehicle, is regarded for this purpose as well (Gerlach

and G

uttler, 2007).

Many studies have shown the possibility to track

vehicles in ITS systems based on the mentioned data

sets, e.g. (Tomandl et al., 2012). Therefore, a num-

ber of countermeasures has been published. These

include context aware pseudonym changes (Gerlach

and G

uttler, 2007) and time synchronized pseudonym

switching (Wiedersheim et al., 2010). Unfortunately,

these mechanisms require the exchange of further

messages between vehicles cooperating during the

pseudonym change. This clearly increases the already

signiﬁcant overhead introduced by security mecha-

nisms (see e.g., (Bittl et al., 2014)). Moreover, none

of these works studies the inﬂuence of metadata con-

tained in the security envelope of current ETSI ITS

and WAVE systems on the privacy of vehicles. Ad-

ditionally, only a fraction of the vast number of data

ﬁelds from higher level applications is taken into con-

sideration in prior work.

Our contribution focuses on the inﬂuence on the

privacy of information broadcast by vehicles in ETSI

ITS conforming VANETs. Thereby, we especially

study the metadata contained in the security en-

velope of broadcast messages apart from the used

pseudonym. Furthermore, we take a close look on

the high number of data sets used by higher level pro-

tocols regarding their possibility to ruin the privacy

efforts taken elsewhere. For the sake of compactness

we focus the study of the ETSI ITS facility layer on

Cooperative Awareness Messages (CAMs). However,

much similarity between ETSI ITS and WAVE exists

on the different protocol layers. Thus, we especially

point out the cases which also apply for WAVE based

systems.

The further outline is as follows. Section 2 re-

views related work. Afterwards, Section 3 provides

the in detail study of the impact of individual data

ﬁelds on privacy of broadcasting vehicles. In Section

4, the achieved results are used to determine a metric

for vehicle uniqueness within its vehicular environ-

ment. Finally, a conclusion is provided in Section 5

alongside with possible topics of future work.

144

Bittl S. and A. Gonzalez A..

Privacy Issues and Pitfalls in VANET Standards.

DOI: 10.5220/0005459101440151

In Proceedings of the 1st International Conference on Vehicle Technology and Intelligent Transport Systems (VEHITS-2015), pages 144-151

ISBN: 978-989-758-109-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

2 RELATED WORK AND

ATTACKER MODEL

Recent work on privacy in vehicular area networks

(VANETs) or intelligent transport systems (ITSs)

includes (Gerlach and G

uttler, 2007; Wiedersheim

et al., 2010; Eichler, 2007; Scheuer et al., 2008;

Buttyan et al., 2009; Tomandl et al., 2012). Basi-

cally, privacy in such networks relies on a pseudonym

scheme which changes the identiﬁers (IDs) of a vehi-

cle (or ITS-station (ITS-S)) on all protocol layers on

a regular basis to avoid tracking (Sch

utze, 2011).

There are mainly two kinds of attacks on privacy

in VANETs. Simple attacks just use identiﬁers like

the station ID and a very limited set of additional in-

formation about the ITS-S, typically only the vehicle

position. Advanced attacks include more context in-

formation for tracking, e.g., behavior of other vehicles

(Gerlach and G

uttler, 2007; Tomandl et al., 2012).

Thereby, it has been shown that simple pseudonym

change, like in ETSI ITS and WAVE, cannot avoid

tracking. The probability of two (or even more) vehi-

cles changing their pseudonym in close vicinity just

by chance, confusing an attacker, is just to small.

Many approaches to confuse an attacker trying

to track vehicles have been proposed. These ap-

ply concepts like MixZones (Scheuer et al., 2008),

silent periods, SLOW (Buttyan et al., 2009), con-

text aware pseudonym changes (Gerlach and G

uttler,

2007) and time synchronized pseudonym switching

(Wiedersheim et al., 2010) (see also (Tomandl et al.,

2012) and references within). A common requirement

of all these concepts is that vehicles must ﬁnd indis-

tinguishable partners in their vicinity with whom they

cooperate to perform a secure pseudonym change. All

vehicles should change all of their identiﬁcation pa-

rameters together to confuse the attacker (Sch

utze,

2011). However, we show that ﬁnding such partners

is quite unlikely to happen in VANETs using current

ETSI ITS and WAVE standards.

A commonly assumed attacker model is the global

passive adversary (Tomandl et al., 2012). This passive

attacker can monitor all messages in the whole ITS

system. This model is also assumed in the following.

Even advanced attacks from prior work (e.g.,

(Wiedersheim et al., 2010; Tomandl et al., 2012))

have so far not included usage of the biggest share of

metadata from the security envelope and higher pro-

tocol level data from cyclic messages in VANETs fol-

lowing current standards. Thus, we study the usability

of these data for more advanced attacks.

Properties of the studied standards from the ETSI

ITS and WAVE families are explained in the next sec-

tion alongside with their impact on privacy aspects.

3 DATA FOR VEHICLE

IDENTIFICATION

ETSI ITS uses Cooperative Awareness Messages

(CAMs) while WAVE utilizes Basic Safety Messages

(BSMs) for the main data exchange in their VANET

systems. Therefore, our focus is on the contents of

theses messages on the different protocol layers.

When looking for possible privacy issues, the core

focus is on data which differs for different groups of

vehicles but is also constant for the individual vehicle

over a long time. One example is vehicle dimensions

which are identical for all vehicles of the same model

but different for other models with high probability.

We call that kind of data volatile constant data. In

typical trafﬁc scenarios many different vehicle types

and models are present in the vicinity of a vehicle in-

tending to perform a secure pseudonym change. To

do so, the above described cooperative pseudonym

strategies select partners whose broadcast information

is as similar as possible to confuse the attacker. The

presence of volatile constant data clearly makes it less

probable to ﬁnd such proper partners leading to possi-

bly insecure pseudonym changes. Thus, the presence

of such data should be avoided as far as possible.

Current standards bind the lifetime of MAC ad-

dress, network layer address and station ID of the fa-

cility layer to the one of the pseudonym. This means,

once the pseudonym gets changed the other identiﬁers

get changed, too. Therefore, an attacker cannot proﬁt

from looking on more than one of these identiﬁers at

once as they all provide the same temporarily valid

information. Moreover, for the simple case of sin-

gle hop broadcast, like it is used for CAM and BSM,

the network and access layer do not add any informa-

tion to the transmitted messages which can be used to

track their senders.

In the next section metadata from the security en-

velope will be studied. Afterwards, the content of

CAMs at the facility layer will be discussed.

3.1 Metadata in Security Envelope

The security envelope is used to secure content from

the facility and network layer protocols by embedding

them into a dedicated header and trailer, each consist-

ing of different sub-parts. Thereby, content handed

over to the security entity is treated in dependency of

a so called security proﬁle. These proﬁles determine

the required header ﬁelds as well as the used cryp-

tographic techniques, which can be digitally signing

and/or encryption. The deﬁnition of the security en-

velope is quite similar in ETSI ITS (103, 2013) and

WAVE (WAV, 2012).

PrivacyIssuesandPitfallsinVANETStandards

145

In ETSI ITS the sets of mandatory header ﬁelds

for security proﬁles CAM and Generic are subsets of

the one for DENM (used for Decentralized Environ-

ment Notiﬁcation Messages (DENMs)). Thereby, the

location stamp in proﬁles DENM and Generic carries

the same information as the vehicle position inside a

CAM (103, 2013; 102, 2013b). Thus, this ﬁeld is not

discussed separately and the reader is referred to Sec-

tion 3.2.1 for details.

We focus the further discussion on mandatory

header ﬁelds from the CAM security proﬁle. Pri-

vacy issues resulting from such ﬁelds are more severe

than those from optional ones, as these can be simply

skipped in practical implementations. In contrast, to

ﬁx issues regarding mandatory ﬁelds the standard has

to be changed. Furthermore, (Nowdehi and Olovsson,

2014) suggests to remove the possible inclusion of op-

tional ﬁelds. We support this proposal, as differing

combinations of data sets in the envelope by different

implementations clearly give an attacker a possibil-

ity to easily distinguish vehicles independently from

their pseudonyms.

The following sections discuss the different

header ﬁelds’ privacy implications in detail.

3.1.1 Protocol Version

The used protocol version will be constant for all

vehicles at the beginning of the deployment phase.

However, over time it is very likely that multiple ver-

sions will be present in VANETs. As this value is

constant for an individual vehicle over a long time, it

is clearly volatile constant data. Thus, the presence

of many different versions should be avoided even if

they are otherwise compatible.

3.1.2 Security Proﬁle

The content of this data ﬁeld identiﬁes the message

type. In case all vehicles monitored by an attacker

only send the same type of message, e.g., CAMs, he

cannot discriminate the sender based on this data.

3.1.3 Signer Info

The signer information of a message may hold differ-

ent contents. Thus the available information for the

attacker differs. However, one can always uniquely

determine the signer (and sender) of the message.

Therefore, this is often called the pseudonym ID of

the sender. In both CAM and BSM the ﬁeld’s content

can either be the hash of the used pseudonym certiﬁ-

cate (PSC) or the full certiﬁcate (103, 2013; WAV,

2012). Both systems use cyclic inclusion of the full

certiﬁcate every 0.5 or 1 second, respectively. In case

of security proﬁles DENM and Generic the full cer-

tiﬁcate is always present (103, 2013).

In case of an included PSC the following data is

available to the receiver (103, 2013; WAV, 2012).

Signer Info of Pseudonym Certiﬁcates. A signer

info ﬁeld in a PSC identiﬁes its signer which is an

authorization authority (AA). This can be done either

by a hash digest or by the full AA certiﬁcate. Both

uniquely identify the AA. Current standards allow for

a possible multitude of such entities to exist. In prac-

tice this will be probably done by the car manufactur-

ers (OEMs). However, this leads to a privacy issue as

the signer information is volatile constant data. An at-

tacker can directly determine the OEM and use this to

distinguish PSCs and thereby vehicles. PSCs signed

by different AAs are very unlikely to be used by the

same vehicle and a vehicle will very likely use only

PSCs issued by the same AA. Obviously, vehicles of

low volume OEMs will be particularly vulnerable.

To limit the usability of the AA’s identity for an at-

tacker one can think of mainly two countermeasures.

Firstly, one could increase the number of AA certiﬁ-

cates and make a single AA use a multitude of them.

Thereby, the effort for an attacker to keep track of all

certiﬁcates would increase. However, this would sig-

niﬁcantly increase the effort for AA certiﬁcate distri-

bution to all ITS-S for a small security gain.

Secondly, one could limit the number of AAs. An

ideal choice would be to have only one AA. This

would clearly resolve the above described privacy is-

sue completely, as an attacker cannot distinguish ve-

hicles based on their used AA anymore. To imple-

ment this, OEMs would have to cooperate and use

a common AA. As they plan to establish a common

root certiﬁcate authority (CA) for Europe, this seems

to be a usable approach. In order to limit the number

of PSCs signed by a single AA certiﬁcate, one could

signiﬁcantly limit its lifetime. New ones can be de-

ployed together with PSC updates.

Additionally, one should coordinate the lifetime

of an AA’s certiﬁcate with the lifetime of its issued

PSCs. Thereby, any possibility to distinguish PSCs

based on their signing AA should be ruled out. More-

over, the number of AA certiﬁcates to be stored se-

curely inside the vehicles is kept (very) low.

Validity Restriction. The mandatory validity re-

striction of PSCs is a limited validity period. It is

determined by a start and end time stamp. Both are

used with an accuracy of one second. The PSC dis-

tribution scheme described in (WAV, 2012) and (102,

2010) deﬁnes that PSCs are delivered from an AA to

an ITS-S upon request of the ITS-S. The remaining

VEHITS2015-InternationalConferenceonVehicleTechnologyandIntelligentTransportSystems

146

details are implementation speciﬁc and not covered

by the standard. However, a possible pitfall for pri-

vacy of pseudonym users exists which is caused by

the mentioned time stamps.

This issue arises from the planned way of (re-

)using PSCs in Europe. Thereby, each vehicle uses

a pool of PSCs which are (re-)used until the full pool

gets updated (Tomandl et al., 2012). The update pe-

riod will probably be in the order of months.

A different approach is described in (J. Harding

et. al., 2014) for the USA. Thereby, each PSC is only

used once and the validity period is the order of min-

utes. However, this approach introduces signiﬁcant

overhead in the ITS system for PCS distribution. Ei-

ther vehicles require frequent, reliable connections to

the AA (or pseudonym certiﬁcate authority (PCA) (J.

Harding et. al., 2014)) or a huge buffer ﬁlled with

PSCs for future use. Even if the initially proposed va-

lidity period of ﬁve minutes gets doubled, this would

still require a maximum amount of 144 PSCs per day.

To protect the buffered PSCs, these have to be stored

in secure memory, e.g., inside a Hardware Security

Module (HSM). However, adding more memory to

an HSM signiﬁcantly increases its price. Moreover,

many issued PSCs will stay unused as their validity

period elapses while the vehicle is not in use. One

would have to know the usage times of each vehi-

cle in advance to avoid that, which is hardly practi-

cable. Thus, the approach from (J. Harding et. al.,

2014), while providing good privacy, probably bears

too much overhead for large scale deployment.

An alternative approach for securing re-usage of

PSCs is discussed in the following.

There are mainly two approaches for PSC gen-

eration inside the AA. Either the AA generates the

PSCs upon request or the AA keeps track of the expi-

ration of its users’ PSCs to generate new ones in ad-

vance. In both cases a straight forward implementa-

tion would take the same time stamp (e.g., the current

time at the AA) and use it as the common start va-

lidity time stamp of the signed PSCs. However, this

means that all PSCs of a set delivered to an ITS-S

have a very similar (or even the same) start validity

time stamp. Thereby, making this information volatile

constant data. Furthermore, this time stamp will be

different with a very high probability for most cars as

there is no timed synchronization of PSC requests.

The PSC users have no possibility to protect them-

selves against an attacker using validity time stamps

for tracking them, as they cannot change the content

of a PSC without invalidating its signature. Therefore,

countermeasures have to be taken within AAs.

A straight forward solution would be to dis-

cretized the time stamps deﬁning the validity period

of PSCs. For example, all PSCs issued in one month

could receive the start of this month as their start va-

lidity time stamp. The longer the discretization steps,

the more vehicles will receive a set of PSCs with the

same validity period. Thus the probability that multi-

ple vehicles with common values in these data ﬁelds

meet on the street increases removing the possibility

to distinguish them.

Subject Attribute. The subject attribute ﬁeld holds

the subject type and public key of the PSC. This key is

randomly generated and the subject type is ﬁxed for

all PSCs. Thus, there is no possibility to link PSCs

based on this data set.

Subject Info. The subject info ﬁeld holds a ﬁxed

value for all PSCs. Thus, it provides no possibility to

track vehicles.

3.1.4 Generation Time

The generation time is individual for each message.

However, the time difference between two sequential

messages is clearly deﬁned by the standard. Neither

ETSI ITS nor WAVE deﬁne any change to the sending

interval before or after a pseudonym change.

A common assumption is that clocks of ITS-S are

well synchronized using GPS (Wiedersheim et al.,

2010). Thus, time intervals between message gener-

ation of individual cars should be quite stable. Addi-

tionally, inside a group of cars the generation times of

messages should be randomly distributed leading to

an even distribution of used time stamps. Moreover,

these time stamps are generated and transmitted with

microsecond resolution (103, 2013). Thus, collisions

in this data ﬁeld confusing an attacker are unlikely.

Hence, an attacker can track vehicles just on the gen-

eration time of their messages with high probability.

In case of BSMs the sending interval is ﬁxed. For

CAMs, it is determined by multiple parameters and

can be in the range from 1 to 10 Hz. However, the

current interval can be found in the transmitted CAM

itself (102, 2013b). Thus, the attacker can easily use

this information to avoid being confused by the vari-

able sending interval of CAMs.

Furthermore, the time step is set at the network

layer. Thus, the actual sending time being somehow

randomized by the lower layer CSMA-CA scheme

does not confuse the attacker.

We propose two solutions to overcome the de-

scribed vulnerability. Both require the cooperating

vehicles to use the same sending frequency before

and after the pseudonym change for a minimum time

span, e.g., one second. Firstly, one could reduce

PrivacyIssuesandPitfallsinVANETStandards

147

the accuracy of the generation time to the maximum

transmission interval being 100 ms for BSMs and 1s

for CAMs. The security entity does not need to deter-

mine the sequence of received messages according to

standards. Moreover, the validity time spans of PSCs

are also given with full second resolution. Therefore,

currently there is no need to use a high precision time

stamp for the generation time of type Time64 and it

should be substituted by the lower resolution Time32

type. A side effect would be to reduce the size of the

security envelope by four bytes (103, 2013).

For the second solution, immediately after the

pseudonym change the next sending must be delayed

by a random waiting time. Its length should be in

the order of the normal time difference between two

successive transmissions. For example, for BSMs it

would be between zero and 100 ms. Thereby, the at-

tacker cannot determine the next generation time and

gets confused. The impact on higher level applica-

tions should be low. From their perspective a maxi-

mum delay looks just like one missed message from

the other vehicle.

3.1.5 Message Type

The message type ﬁeld holds the same information as

the security proﬁle does. Moreover, the security entity

does not need to distinguish different message types

sharing the same security proﬁle. Therefore, this ﬁeld

should be removed as it only adds overhead to the se-

curity envelope.

3.1.6 PSC Request List

An ITS-S requests up to six unknown PSCs by using

the least three bytes of their hash values. Standard are

unclear about when to remove entries from the request

list. It should be ﬂushed after a pseudonym change.

3.1.7 Trailer Field

There is only one type of trailer ﬁeld in the standards.

It holds metadata for interpreting the digital signature

as well as the signature itself. Most parts of the trailer

are ﬁxed and the signature of multiple messages can

only be linked together with the help of the respective

public key. Therefore, the signature does not carry

any additional privacy related information compared

to the public key in the corresponding PSC (see Sec-

tion 3.1.3 above).

Moreover, the encoding of the used ECC (elliptic

curve cryptography) point may vary in general, but

is probably constant for a particular vehicle. There

are four options for the ECC point type ﬁeld in the

standard, with the core difference being enabled or

disabled ECC point compression. With both choices

used, this information is volatile constant data. In the

worst case, with only two cars in a group and both

using a different ECC point type, this information is

already enough to render any pseudonym change use-

less. Thus, the standard should only allow only one

option to be used. For other reasons to do so see

(Nowdehi and Olovsson, 2014).

3.2 Data from Facility Layer

The CAM is deﬁned as a deeply nested data struc-

ture (302, 2013). Thereby, an ItsPduHeader and a

CoopAwareness ﬁeld are present on the top level. The

simple ItsPduHeader only holds basic information

like the protocol version, message id and station id.

These ﬁelds hold the same information as their re-

spective counterparts in the security envelope. There-

fore, their impact on privacy aspects is the same as for

those data sets already described in Section 3.1.3.

The CoopAwareness ﬁeld has two parts being the

current generation interval (usable by an attacker as

described in Section 3.1.4) and the CamParameters

ﬁeld consisting of several different containers. These

are described in detail in the following.

3.2.1 Basic Container

The always present basic container holds the compo-

nents station type and reference position.

Station Type. The station type associates the vehi-

cle to some generic class, e.g., passenger car or light

truck. This unchanging information is clearly volatile

constant data.

Reference Position. The current position of the

ITS-S measured at the vehicle’s reference point (see

(102, 2013a)) is available in each CAM. Prior work

already showed that this information can be used

to bypass simple pseudonym changes (Gerlach and

uttler, 2007; Wiedersheim et al., 2010). There-

fore, the advanced pseudonym switching strategies

suggested in these references should be used.

3.2.2 High Frequency Container

The high frequency container is part of every CAM.

In case of an ITS-S being a vehicle the only used

sub-part is a basic vehicle container. Parameters of

the vehicle’s current movement are given in this data

set. These include heading, speed and driving direc-

tion. All these values can be used for advanced vehi-

cle tracking (Gerlach and G

uttler, 2007; Wiedersheim

VEHITS2015-InternationalConferenceonVehicleTechnologyandIntelligentTransportSystems

148

et al., 2010). However, the remaining data inside this

container has not been regarded in prior work.

Dimensions. The vehicle’s dimensions length and

width are given. According to (102, 2013b) the reso-

lution is set to 0.1 meters. This value stays constant

during one journey of a vehicle and thus it has to be

regarded as volatile constant data. It is possible that

the length of a vehicle changes from one journey to

another, e.g., by extending it with a trailer. However,

this is rare in practice especially for passenger cars.

To evaluate privacy aspects of broadcasting a ve-

hicle’s dimensions, we determined the number of

different currently sold vehicle models in Germany.

Then, we assigned them to the individual discretiza-

tion steps of vehicle length and width. We took

publicly available data from the German Kraftfahrt-

Bundesamt (Kraftfahrt-Bundesamt, 2014) to obtain

the share of different vehicle types, separated into

OEMs and their models, on the overall trafﬁc in Ger-

many caused by new cars. Foreign cars traveling on

German roads are excluded from this data set. How-

ever, it should still give a reasonable estimate about

the distribution of models’ dimensions. Moreover, we

used public information from the 45 different OEMs

present in (Kraftfahrt-Bundesamt, 2014) to obtain the

individual dimensions of models.

We ﬁnd that 73% of all vehicle models share a

common combination of width and length with at

least one other model. These cars have a market share

of 75%. Thus, for a share of 25% one can determine

the model directly given its discretized dimensions.

Even the most populated set of vehicles with length

4.3 m and width 2.0 m includes only 17% of all cars.

Thus, distribution of vehicle dimensions clearly

decreases the probability to ﬁnd proper (i.e., indis-

tinguishable) partners for a cooperative pseudonym

change. Further discretization of the values to, e.g.,

0.3 m would signiﬁcantly improve the situation for

many vehicles but can still not help the ones with out-

standing dimensions and/or low penetration rates.

Dynamics. The parameters longitudinal accelera-

tion, curvature (consists of curvature value and con-

ﬁdence), curvature calculation mode and yaw rate are

included in the high frequency container. Thereby, the

curvature calculation mode is again a value which is

unlikely to change for an individual vehicle and may

differ for different vehicles. Therefore, it should be

regarded as volatile constant data.

The remaining values model a vehicle’s trajectory.

Many approaches for modeling and predicting such

trajectories exists, e.g., (Ammoun and Nashashibi,

2009; Houenou et al., 2013). In case of pure track-

ing, i.e., no realtime interaction between attacker and

vehicles, the attacker does not need to process the in-

formation in realtime. Thus, he can use computation-

ally expensive but accurate and complex movement

models. As we have seen above, the attacker can de-

termine either the vehicle type directly or a group of

possible vehicle types. This information can be used

to tune the parameters of a movement model making

it very accurate. Moreover, the prediction must only

work well for a short time span as the CAM genera-

tion rate is at most one second.

To evaluate the impact of using an advanced

movement model on the attackers ability to track ve-

hicles one should use data obtained from real test

drives instead of pure simulator output. This is be-

cause simulators like the well known SUMO use a

predeﬁned vehicle model. Therefore, tracking these

simulated vehicles with a model which ﬁts the one

used to generate their movement will probably yield

unrealistically high success rates. Further analysis of

this issue is beyond the scope of this work and is a

subject to future work.

Optional Data. Six more data sets may be option-

ally present in the container. Three of them (steering

wheel angle, lateral, vertical acceleration) can be used

to improve the movement model described above.

The remaining three values (acceleration control,

lane position, performance class) each describe a ve-

hicle’s feature. These can be expected to change quite

slowly, i.e., they should be regarded as volatile con-

stant data. As all these ﬁelds are optional and can be

added or removed individually, also the combination

of sent data sets may differ between vehicles. Thus,

usage of each extra value will increase the change that

a particular vehicle uses a unique set of data inside its

current vicinity. Thereby, it will strip itself from ﬁnd-

ing proper partners for a secure pseudonym change.

3.2.3 Optional Containers

In addition to the basic and high frequency container,

the low frequency container is distributed cyclically,

but not in every single CAM. It contains the vehicle

role, exterior lights and path history ﬁelds. See (302,

2013) for details about inclusion rules.

In case of an uncommon vehicle role, e.g., res-

cue vehicle, the corresponding additional container is

present in the CAM. The density of such vehicles in

ordinary trafﬁc is usually low. Thus, an attacker can

easily track them just based on the presence of their

dedicated containers in their CAMs.

PrivacyIssuesandPitfallsinVANETStandards

149

Typically, the status of exterior lights changes

slowly. Thus, it is volatile constant data.

The path history ﬁeld should obviously be erased

when a pseudonym change occurs or the inclusion

rate of the container has to be such low that sequen-

tially sent values of this ﬁeld cannot be linked. Oth-

erwise the attacker can simply link the pseudonyms

based on this data. However, the current standards do

not ensure such behavior.

4 VEHICLE UNIQUENESS

Secure pseudonym switching schemes from prior

work are based on the assumption that broadcast data

cannot be mapped to an individual vehicle except of

the changed identiﬁers. We have shown in Section 3

that this is clearly not the case due to the presence of

volatile constant data. To evaluate the impact of our

ﬁndings on vehicle privacy we introduce the metric

of vehicle uniqueness (VU). It measures how much

a particular vehicle differs from its vehicular environ-

ment regarding data observable by an attacker.

Prior work showed that tracking of vehicles be-

comes more difﬁcult alongside with higher trafﬁc

density and longer distances traveled during a cooper-

ative pseudonym switching maneuver (Tomandl et al.,

2012). However, this only holds in case the attacker

has no extra information for re-identiﬁcation of vehi-

cles after a pseudonym change. VU is a metric for the

availability of such extra information. In case a vehi-

cle is unique inside the area of pseudonym switching

the attacker can always track it, independently of the

used pseudonym switching algorithm.

To calculate VU an exposed feature vector e

hold-

ing all available volatile constant data is assigned to

each vehicle. Thereby, i ∈ I relates to a particular ve-

hicle within a group of vehicles I (|I| ≥ 1) cooperating

during a pseudonym change. VU is deﬁned by

VU = Pr{

{x|e

= e

;x 6= y;x, y ∈ I}

= 0} .

This means that VU ∈ [0;1] is the probability that

there is just one car within I having one particular ex-

posed feature vector. Such vehicles are indistinguish-

able for an attacker in regard to volatile constant data.

In the following, we take three different

pseudonym switching schemes into regard. These are

1. uncoordinated pseudonym switching (ETSI ITS

and WAVE) with |I| = 1 with high probability,

2. mix zones with |I| depending on trafﬁc ﬂow and

size of the mix zone and

3. silent periods with |I| depending on trafﬁc ﬂow

and length of silent periods.

Moreover, we include the following data into e

• AA of PSCs, we assume one AA per OEM and

• vehicle dimensions (see Section 3.2.2).

We assume that all cars from the same OEM use the

same encoding of ECC points (see Section 3.1.7).

Thus, this data does not inﬂuence VU in our case and

is not regarded further. The rest of the volatile con-

stant data sets from Section 3 are assumed to be iden-

tical for all cars. This leads to a best case assumption

for privacy of vehicles. Moreover, we assume that

the probability of two cars within I sharing a com-

mon value of e

(|e

| = 3) only depends on the share

of their particular model within the set of all vehicles.

We use the vehicle distribution from (Kraftfahrt-

Bundesamt, 2014) to estimate VU. Moreover, an

analysis of vehicle dimensions for the models of dif-

ferent OEMs (see also Section 3.2.2) shows that the

data included in e

allows to uniquely identify the

model of a vehicle, e.g., as VW Golf VII, from a sin-

gle CAM including the PSC. Thus, one can calculate

the probability to encounter a vehicle with a particular

from the mentioned vehicle distribution data set.

The number of vehicles encountered during a

pseudonym switching maneuver |I| is varied by vary-

ing the trafﬁc ﬂow (given in

vehicles

kilometer

) and size of mix

zones or length of silent periods, respectively. The

trafﬁc density is varied from 16 to 45

vehicles

kilometer

per

lane following (Gerlach and G

uttler, 2007) to repre-

sent low volume trafﬁc as well as a jammed setup. We

use the parameter set from (Tomandl et al., 2012) for

the size of mix zones (25m - 400m), length of silent

periods (1250ms - 20s) and velocity range (0 - 250

). The obtained results are given in Figure 1.

1e-06

1e-05

0.0001

0.001

0.01

0.1

5 10 15 20 25 30 35 40 45 50 55 60

probability of being

non-unique (1 - VU)

number vehicles encountered during pseudonym change (|I|)

average

best

worst

Figure 1: Vehicle uniqueness during pseudonym change.

Thereby, the best case relates to the most common

car model. It is obviously the least unique one within

the set of all vehicles. However, only about 7.7% of

all vehicles can proﬁt from the good results for this

model having a high chance to ﬁnd indistinguishable

partners for a cooperative pseudonym change. More-

over, the worst case relates to the least common car.

One can see from Figure 1 that the value of 1−VU

increases alongside with |I|. However, for an aver-

age vehicle it is very low for all regarded values of

|I|. However , combinations of high velocity and high

VEHITS2015-InternationalConferenceonVehicleTechnologyandIntelligentTransportSystems

150

trafﬁc ﬂow, leading to high values of |I|, rarely occur

in practice. Thus, VU will exceed 99.9% in most real

world scenarios with moderate trafﬁc ﬂow.

Higher values of |I| than the ones used above

would relate to unrealistically high trafﬁc ﬂow or ex-

tending the size of mix zones and length of silent peri-

ods to values rendering higher level ITS-applications

unusable (Tomandl et al., 2012). Calculation of VU is

independent of the pseudonym switching strategy, but

the achievable size of |I| differs. While cooperative

PSC switching strategies can adjust it, uncoordinated

ones, e.g., from ETSI ITS or WAVE, cannot do so.

The obtained results show that even without other

tracking mechanism an attacker can track a vehicle

with high probability using just a small set of con-

stant volatile data, even though the vehicle performed

a pseudonym change. This shows that the presence of

volatile constant data is able to render PSC changes

useless, as an attacker can re-identify vehicles us-

ing this data after the pseudonym change. Combin-

ing this attack with further tracking mechanisms, e.g.,

from (Tomandl et al., 2012), promises to achieve very

high tracking probabilities. Thus, the mechanisms for

avoiding volatile constant data in VANET messages

suggested in Section 3 should be used to limit the

trackability of vehicles.

5 CONCLUSIONS AND FUTURE

WORK

With upcoming deployment also privacy aspects of

VANETs gain increased attention. Therefore, we

studied the inﬂuence of information currently present

in ETSI ITS and WAVE standards on proposed pri-

vacy protecting pseudonym usage strategies.

Thereby, we ﬁnd that the main requirement of

pseudonym change strategies, the cooperation of mul-

tiple indistinguishable vehicles, is unlikely to be

found in practice with current standards being in use.

Multiple suggestions have been made to improve this

situation, which require to adjust the standards.

Future work can implement the outlined tracking

mechanisms in a simulation environment to study the

inﬂuence of parameters like CAM generation rules.

REFERENCES

(2010). Intelligent Transport Systems (ITS); Security; Se-

curity Services and Architecture. V1.1.1.

(2011). Memorandum of Understanding for OEMs within

the CAR 2 CAR Communication Consortium on De-

ployment Strategy for cooperative ITS in Europe.

(2012). Draft Standard for Wireless Access in Vehicular

Environments - Security Services for Applications and

Management Messages. P1609.2, D12.

(2013a). Intelligent Transport Systems (ITS); Facilities

layer function; Facility Position and time manage-

ment. V0.0.2.

(2013). Intelligent Transport Systems (ITS); Security; Se-

curity header and certiﬁcate formats. V1.1.1.

(2013b). Intelligent Transport Systems (ITS); Users and

applications requirements; Part 2: Applications and

facilities layer common data dictionary. V1.1.1.

(2013). Intelligent Transport Systems (ITS); Vehicular

Communications; Basic Set of Applications; Part 2:

Speciﬁcation of Cooperative Awareness Basic Ser-

vice. ES 302637-2, V1.3.0.

Ammoun, S. and Nashashibi, F. (2009). Real time trajec-

tory prediction for collision risk estimation between

vehicles. In IEEE ICCP.

Bittl, S., Gonzalez, A. A., and Heidrich, W. (2014). Perfor-

mance Comparision of Encoding Schemes for ETSI

ITS C2X Communication Systems. In VEHICULAR,

pages 58–63.

Buttyan, L., Holczer, T., Weimerskirch, A., and Whyte,

W. (2009). SLOW: A Practical pseudonym changing

scheme for location privacy in VANETs. In IEEE Ve-

hicular Networking Conference, pages 1–8.

Eichler, S. (2007). Strategies for Pseudonym Changes in

Vehicular Ad Hoc Networks depending on Node Mo-

bility. In IEEE Intelligent Vehicles Symposium.

Gerlach, M. and G

uttler, F. (2007). Privacy in VANETs us-

ing Changing Pseudonyms - Ideal and Real. In IEEE

VTC, pages 2521–2525.

Houenou, A., Bonnifait, P., Cherfaoui, V., and Yao, W.

(2013). Vehicle Trajectory Prediction based on Mo-

tion Model and Maneuver Recognition. In IEEE

IROS, pages 4363–4369.

J. Harding et. al. (2014). Vehicle-to-Vehicle Communica-

tions: Readiness of V2V Technology for Application.

Technical Report DOT HS 812 014, Washington, DC:

National Highway Trafﬁc Safty Administration.

Kraftfahrt-Bundesamt (2014). Neuzulassungen von Person-

enkraftwagen im August 2014 nach Marken und Mod-

ellreihen. online: 10.01.2015.

Nowdehi, N. and Olovsson, T. (2014). Experiences from

Implementing the ETSI ITS SecuredMessage Service.

In IEEE IVS, pages 1055–1060.

Scheuer, F., Pl

oßl, K., and Fedrrath, H. (2008). Preventing

Proﬁle Generation in Vehicular Networks. In IEEE

WiMob, pages 520–525.

Sch

utze, T. (2011). Automotive Security: Cryptography for

Car2X Communication. In Embedded World Confer-

ence.

Tomandl, A., Scheuer, F., and Federrath, H. (2012).

Simulation-based Evaluation of Techniques for Pri-

vacy Protection in VANETs. In IEEE WiMob, pages

165–172.

Wiedersheim, B., Ma, Z., Kargl, F., and Papadimitratos, P.

(2010). Privacy in Inter-Vehicular Networks: Why

simple pseudonym change is not enough. In WONS,

pages 176–183.

PrivacyIssuesandPitfallsinVANETStandards

151
