Addressing Issues of Cloud Resilience, Security and Performance

through Simple Detection of Co-locating Sibling Virtual Machine

Instances

hn O’Loughlin and Lee Gillam

Department of Computing, University of Surrey, Guildford, GU2 7XH, Surrey, U.K.

Keywords: Virtualisation, Xen, Cloud Computing, Co-location, Security, Performance.

Abstract: Most current Infrastructure Clouds are built on shared tenancy architectures, with resources shared amongst

large numbers of customers. However, multi tenancy can lead to performance issues (so-called “noisy

neighbours”) and also brings potential for serious security breaches such as hypervisor breakouts.

Consequently, there has been a focus in the literature on identifying co-locating instances that are being

affected by noisy neighbours or suggesting that such instances are vulnerable to attack. However, there is

limited evidence of any such attacks in the wild. More beneficially, knowing that there is co-location

amongst your own Virtual Machine instances (siblings) can help to avoid being your own worst enemy:

avoiding your instances acting as your own noisy neighbours, building resilience through ensuring host-

based redundancy, and/or reducing exposure to a single compromised host. In this paper, we propose and

demonstrate a test to detect co-locating sibling instances on Xen-based Clouds, as could help address such

needs, and evaluate its efficacy on Amazon’s EC2.

1 INTRODUCTION

Infrastructure Clouds offer compute resources for

rent on-demand, typically on a per hour basis

(Armbrust et al, 2009). One of the most popular

offerings is the virtual server, which is the mainstay

of providers of Infrastructure Clouds such as

Amazon, Google and Microsoft. Infrastructure

Clouds use virtualisation technologies such as Xen

and KVM to offer physical servers as (often,

multiple) virtual servers. Customers can rapidly

acquire virtual servers, use them for as long as

required, then release them back to the provider

when no longer needed, with the equivalent resource

then available for use by other customers.

At any given time, a physical server in a Public

Cloud could be running virtual servers, also referred

to as instances, for a number of different users

(customers). From the user’s perspective, shared

tenancy raises various concerns, of which security

and performance are key. For security, one particular

concern is hypervisor breakouts, where hypervisor

security can be compromised and a resulting

privilege escalation can be used to obtain data from

other customers’ instances. For performance, one

such concern is noisy neighbours, where

performance degradation occurs in one instance due

to the (legitimate and not necessarily malicious)

resource consuming actions of another.

In such cases, the concern tends to focus on the

security or performance impact from other users.

Consequently, research has tended to be focused on

identifying vulnerable instances, or hiding from

potential attackers. However, identifying co-locating

instances may be of even more use for the majority

of users with respect to their own instances. We will

refer to instances started by the same user,

irrespective of when, as sibling instances in the

remainder of this paper.

Sibling instances that are co-located on the same

host may be undesirable for the following reasons:

1. They may degrade the performance of each

other when running compute bound

workloads.

2. They are all vulnerable to failure, or

degradation, of the underlying host.

3. They are all vulnerable to other noisy

neighbours.

4. There is a greater exposure to a security

compromise on a single host.

Determining co-location is difficult, and to date,

no simple methods have been proposed that would

reliably allow for such detection. This paper aims to

O’Loughlin J. and Gillam L..

Addressing Issues of Cloud Resilience, Security and Performance through Simple Detection of Co-locating Sibling Virtual Machine Instances.

DOI: 10.5220/0005485000600067

In Proceedings of the 5th International Conference on Cloud Computing and Services Science (CLOSER-2015), pages 60-67

ISBN: 978-989-758-104-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

address this problem by exploring one kind of trace

left by virtualization on Xen based Clouds - domain

ids (domids). The rest of this paper is structured as

follows: In section 2 we review relevant related

work to offer background to the problem; in section

3, we discuss the Xen hypervisor and the generation

of domain ids, and in section 4 we discuss the results

of domids collected from a small sample (100) of

virtual servers in the Amazon Cloud, and use this as

a basis for tests for co-location in section 5. In

section 6 we use domids collected from further

samples to demonstrate likely recycling of resources.

Finally, in section 7 we present our conclusions, and

future directions of this work.

2 RELATED WORK

The ability for one instance to degrade the

performance of other co-located instances is well

known, and is referred to as noisy neighbours. Intel

identifies the primary cause of the problem as the

sharing of resources, such as the L2 cache, which

cannot be partitioned (Intel, 2014); that is, there is

no mechanism to limit how much of the resource an

instance may consume. Consequently, it is possible

for instances to use such resources

disproportionately, to the detriment others.

The standard metric for compute performance is

execution time. Identifying if a running task is likely

to suffer from poor performance i.e. need increased

execution time, is difficult. On their production

clusters, Google detects likely poor performance by

repeatedly measuring a task’s cycles per instruction

(CPI), i.e. the number of cycles required to execute

an instruction, and comparing with the known CPI

distribution (Zhang et al, 2013). If more outliers

(defined as more than 2 standard deviations from the

mean) are detected than expected, then performance

of the task is likely to be poor. The protagonist, i.e.

the noisy neighbour, is identified by correlating

other instances’ CPU usages with the increase in

CPI outliers for the victim.

On a Public Cloud, information about when an

instance is scheduled for CPU time by the

hypervisor is only available to the provider, and is

not subsequently made available to customers. As

such, it is not possible to precisely state when an

instance is running or not. A coarser approach would

be to attempt to correlate instance performance using

compute benchmarks. Such an approach would

likely require a minimum number of co-located

instances on a given host in order to be successful,

and so this already requires co-location to be

knowable, and there is the potential to miss a small

degree of co-location per host.

The problem of extracting information between

co-locating virtual machines has been investigated

by a number of authors. In (Zhang et al, 2012) the

sharing of an L2 cache between VMs was shown to

be vulnerability when it was demonstrated that one

VM may extract cryptographic keys from another

VM on the same host. Such an attack is known as an

access driven side channel attack. Particularly

noteworthy, is the fact that the attack was

demonstrated on an SMP system. In this case the

challenge of core migrations i.e. the scheduling of

VMs onto different cores during its lifetime, as

would be encountered in a Cloud environment,

needs to be overcome. However, the demonstration

was on a standalone Xen system rather than on a

Public Cloud.

The vulnerability of a shared cache relies, in

part, on exploiting hypervisor scheduling. Methods

to increase the difficulty of successfully using such

attacks are under development (Lui, Ren and Bai,

2014), and indeed, are already being integrated into

Xen. Whilst such work mitigates fine grained

attacks, denial of service attacks, which seek to

obtain a large share of the L2 cache, are considered

viable.

This has led to work on targeted attacks in the

Cloud, whereby an attacker seeks to co-locate with a

specific target. This requires methods for

determining co-location with the target before the

attack can be launched. In (Ristenpart, Tromer,

Shacham and Savage, 2010) a number of network

based probes have been proposed, for example ping

trip time and common IP address of dom0. In order

to test the veracity of these methods they also use

access timings of shared drives. No details are

provided of the type of drive being used (local or

network) or how the disk is being shared.

However, as the authors state, a provider can

easily obfuscate network based probes and this

already appears to the case. From our experiments

we can confirm this. Whilst access times to shared

drives may potentially be used for detecting co-

locating siblings, there are a number of issues not

discussed that need require further investigation.

Perhaps most importantly, is the widely reported

variation in disk read/write timings on EC2

(Armbrust et al, 2009), which clearly needs to be

accounted for in any test that proposes to use them.

In (Bates et al, 2013) watermarking of network

flows is proposed and demonstrated on a variety of

stand- alone virtual systems. However, as the

authors state, there a number of defences against

watermarking in place in Public Clouds, and in

particular on EC2, which prevented them from

successfully using the tests.

In (Zhang, Juels, Oprea and Reiter, 2011) a

cache avoidance strategy is used so that instances

AddressingIssuesofCloudResilience,SecurityandPerformancethroughSimpleDetectionofCo-locatingSiblingVirtual

MachineInstances

can co-ordinate their use (or avoidance) of the L2

cache and measure resulting cache use. This, then, is

a basis for detecting co-locating siblings. The

method is applicable to Xen-based Clouds but

requires modification of how the guest OS kernel

manages memory, and has a performance overhead

when cache use is turned off. Such an approach is

technically challenging, as it involves kernel

changes, and this is likely beyond the capabilities of

most Cloud users.

In summary, neither simple network probes nor

network flows watermarking co-location tests work

on EC2 due to measures in place, whilst cache

avoidance technically challenging. There is a need

for simple methods then.

3 THE XEN HYPERVISOR

The Xen system (Xen, no date) is a widely deployed

hypervisor in Infrastructure Cloud systems, and is in

use at Amazon, Rackspace, IBM and GoGrid,

amongst others. The Xen system consists of the Xen

hypervisor together with a privileged VM called

domain 0 or dom0. Xen is a bare-metal hypervisor,

started by the BIOS, which in turn starts dom0. The

dom0 is a privileged VM and can directly access

hardware such as network cards and local disk

storage. Dom0 provides a management interface for

the Xen system, from which system administrators

can launch and manage the life cycle of VMs. These

VMs are unprivileged domains and are referred to as

domUs.

The Xen hypervisor is responsible for scheduling

VM CPU time, managing memory, and handling

interrupts. On an x86 CPU, dom0 privilege

escalation is provided by running dom0 in ring 1,

whilst the Xen hypervisor runs in ring 0 (and the

unprivileged VMs, domUs, run in ring 3). DomUs

gain access to hardware devices such as disks and

network cards via calls to dom0.

Each domain is given two identifiers, a domid

and a UUID. The UUID is a unique identifier

amongst a deployment of multiple Xen systems; that

is, it uniquely identifies a domain amongst the set of

all domains across the Xen systems. For example on

EC2, the UUID assigned to a new instance will (in

theory) be unique to that instance, at least within the

Region it was launched in.

In addition, a newly launched domain is assigned

a domain identifier, referred to as the domid. This

uniquely identifies domains on the physical server

only. On EC2, instances on the same physical server

will have different domids. However, these may well

clash with domids for instances on other hosts. The

domid is a 16 bit integer and allocation is

monotonically increasing - Xen assigns the next

available domid. This means that instances that are

started one after the other will obtain consecutive

domids. On EC2, therefore, we would expect co-

locating instances, started at the same time, to have

consecutive domids – or, with other requests also

being satisfied, being quite close to each other.

Xen domids have a rather interesting property,

and one which will be crucial to us later: an instance

can increase its own domid simply by rebooting. An

instance’s new domid will be its old domid plus the

number of instances that have started on the same

host since it was last rebooted, plus the number of

reboots that have occurred. Domids do not, however,

seem to survive an underlying host reboot, and in

this case the next available domid is reset to 1.

A user does not have administrative access to

Xen on EC2 (or indeed any Public Cloud). However,

we can determine an instance’s domid via Xenstore.

Xenstore (Xenstore, 2014) is a data area exported

from dom0 to domUs, the interface of which is a

pseudo file system which can be mounted on

/proc/xen within a guest. This is analogous to the

/proc and /sys pseudo file systems in Linux which

provide an interface for user space processes to the

Linux kernel. Under a standard Xen system, a

domain can extract information such as the domids

of all the running domains and the CPU weightings

assigned to them. As one would expect, on EC2 the

data exported to the instances via Xenstore is

restricted, and does not allow a domain to obtain any

information other than about itself. However, it is

particularly useful, for our purposes that a domain

can obtain its own domid.

In the next section we present the results of

domids collected on EC2 via Xenstore from some

120 instances.

4 COLLECTING DOMIDS

We can initially collect domids from instances

launched on EC2, and examine the extent to which

these hint at co-location. Using an Ubuntu precise

12.04 AMI, we can readily launch 20 m1.small

instances as a single request in the Region US-East-

1, in AZ us-east-1b. Each instance gets xenstore-

utils installed, and has the exported Xen store file

system mounted on /proc/xen. In this setup, it is then

possible to obtain an instance’s domid, uuid and

cpuid.

In Table 1, below, we list 20 domids obtained

from just such a setup (on 07/10/2014), which are

readily organised into three sequences of

consecutive domids. For all instances, the CPU

model was an E5-2651.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

Table 1: Consecutive Domids.

Seq Domids

1 563, 564, 565, 566, 567 and 568

2 723, 724, 725, 726, 727, 728 and 729

3 752, 753, 754, 755, 756, 757 and 758

The simplest explanation for these consecutive

domids is that the 20 instances are allocated to just

three hosts. It may also be possible that these

sequences are obtained simply by chance across a

large number of hosts that are churning VMs at

similar rates, and we discuss this possibility in

section 5.

The AZ us-east-1b appears homogeneous (just

one CPU model) for the account we were using. To

simplify concerns further, we instead examine

domids in us-east-1a as this provides heterogeneous

hosts. This helps to improve clarity over co-location

since instances with consecutive domids on different

CPU models are clearly not co-located, and so here

the consecutive domids are more likely to indicate

co-locating instances – unless, of course, cpuid and

domid values are spoofed.

We ran 5 requests, with 20 instances per request,

on Amazon’s spot market for us-east-1b. Of the 100

instances started, 3 were reclaimed and so we have

results for just 97 instances. As before, we determine

the domid, uuid and cupid. After this information

was obtained, the instances were released. Each

request was made at a different time over a 2 day

period, from 07/10/2014 to 08/10/2014. In Table 2,

below, we list only the sequences with consecutive

domids found in each request, together with the

instance CPU models – one of E5645, E5507 or E5-

2650.

Table 2: Domids from Multiple Time-Separated Requests.

Request, Date

& Time

Consecutive Domids and CPU Model

07/10/2014

17:05

242,243,244 – E6545

469,470 – E5645

1499,1500 – E5645

1671, 1672 – E5645 + E5-2650

2627, 2628, 2629 – E5-2650

07/10/2014

17:58

None

07/10/2014

21:57

250, 251, 252, 253, 254, 255 ,256 – E5645

732, 733 – E5507

1501, 1502 – E5645

2630, 2631, 2632 – E5-2650

08/10/2014

10:25

263, 264, 265, 266 – E5645

501,502 – E5645

1505, 1506 – E5645

2637, 2638, 2639, 2640 – E5-2650

08/10/2014

21:50

None

3 out of 5 of the requests evidence consecutive

domids with E5645 CPUs, and all three contain at

least 2 such sequences. The most common pattern is

of two consecutive domids, and the longest sequence

is 7. We note consecutive domids in request 1 of

1671 and 1672, with different CPU models – E5645

and E5-2650 respectively – which clearly cannot be

co-located (unless, again, the cpuid is spoofed). In

request 1, it would appear that 10 of 20 instances are

not host separated, in request 3 this is 14, and in

request 4 it is 12.

5 CO-LOCATION TEST

Based on the discussion and results in section 4 we

can state that for any pair of instances the following

initial conditions must be satisfied if the instances

are more likely to be co-located:

1. Same CPU model

2. Values of domids are sufficiently close to

each other

For the second condition, we do not require that

the domids be consecutive but should be sufficiently

close to each other. In order to understand why

consider the following: two sibling instances are

scheduled onto the same host, but in between them

being launched an existing instance is rebooted. In

this case then, they will not have consecutive domids

but the domids will differ by (at least) 2. We discuss

how close is ‘sufficiently close’ later in this section.

Whilst the two conditions listed above are

necessary for co-location, they are not sufficient. It

is entirely possible that the instances have been

allocated to hosts whose next available domids were

within the domid distance simply by chance. Indeed,

this becomes more likely if the hardware platform

and configuration is identical, and if the churn rate

of VMs is the same. In fact, we have already seen an

example in batch 1 of instances with domids of 1671

and 1672 that had different CPU models.

For the second condition, closeness of the

domids depends in large part on how many instances

a host has been configured to support. If a host

supports k instances, then any instances started

within a short period of time on the host would

likely have their domids within k of each other. We

cannot state this for certain, since it’s possible that

within that period (1) a number of instances on the

host were rebooted (2) a number of instances were

terminated, and a number more were started.

We also cannot state the value of k for a host

with certainty, since it depends on its CPU model,

the CPU configuration, how many sockets the host

has, and the degree of over commitment. As an

example, we have previously shown (blind ref, no

AddressingIssuesofCloudResilience,SecurityandPerformancethroughSimpleDetectionofCo-locatingSiblingVirtual

MachineInstances

date) that m1.small instances on EC2 may be backed

by 6 different CPU models, including the AMD

2218 and the Intel Xeon E5-2651. The former is a

dual core CPU, so a host with dual socket can have

at most 4 cores. The latter, however, has 10 cores

per socket and dual socket would have 20 cores.

Further, if hyper threading is enabled (as is common

practice on EC2), the core count rises to 40. Finally,

the configured ratio of vCPUs to physical cores

determines k. As EC2 does not advertise socket

count, and only specifies vCPU to cores for some

instance type, as a rule of thumb we will take ‘close’

to be 2 times the core count of a CPU, and times

again by 2 if the CPU supports hyper threading.

In table 3 below we list the 6 models we have

identified to date as backing m1.small instances

together with a domids closeness range based on the

above reasoning:

Table 3: CPU model and Domid Range.

CPU Model Do

id Range

(m1.small only)

AMD 2218 4

Intel Xeon E5430 8

Intel Xeon E5507 8

Intel Xeon E5645 24

Intel Xeon E5-2650 32

Intel Xeon E5-2651 40

We are naturally led to the question of the

likelihood that non-co-locating instances have

domids near to each other. This question is similar to

the well known ‘birthday’ and ‘almost birthday’

problems. The birthday problem can be stated like

this: How many people do we need in a room in

order for there to be a 0.5 chance that at least 2

people will share the same birthday? In this case the

answer is 23. As we are interested in near domids

our problem is more akin the ‘almost birthday

problem’: In a room of 23 people how likely is it to

have at least one pair of consecutive birthdays? An

analytic solution to this is presented in (Dasgupta,

2004), with the answer 0.89.

Monte Carlo methods can be used to tackle the

birthday problems stated above. We can assume that

a birthday is equally likely to fall on any day in the

year. We then generate random samples, of size 23,

drawn from the uniform distribution. For each

sample we record a success if there is the matching

(or consecutive, depending upon the problem of

interest) birthday. The number of successes divided

by the number of trials is then the estimate of the

probability.

We note that the assumption that birthdays are

uniformly distributed is not entirely accurate and

that seasonal variations do exist. However, the

uniform distribution does provide a good

approximation.

Can we apply such methods to estimate the

probabilities of instances having consecutive, or

near, domids by chance – and not because they are

necessarily co-locating? An immediate requirement

is a reasonable approximation for the distribution of

domids across hosts. In theory, a domid is in the

range [1, 65536], however we have so far only

observed domids within a restricted range. Further,

the domid distribution is likely CPU dependent to

some degree. CPUs with more cores, such as the

E5-2651, will likely increment domids at a different

rate to the E5645, as they can run more instances.

We could assume that the range of domids for

hosts with the same CPU model is equally likely to

be between the observed minimum and maximum.

Applying this to the E5645, that would be between

252 and 20708. Using a Monte Carlo simulation, we

find that 20 non co-located instances, placed on

randomly selected hosts with E5645 CPUs, will

have at least one pair of consecutive domids with a

probability of 0.009. That is, approximately 1 in 100

batches of 20 instances would have at least one pair

with consecutive domids.

However, it is not obvious that we can model the

problem in a manner similar to the birthday

problems. Consider for example, a power failure in

one portion of a data centre resulting in a large

number of E5645 hosts being rebooted. In this case

then, we initially have a large number of E5645

hosts with small domids. Instances allocated to these

hosts would have a far greater chance of

consecutive, or near, domids then our estimate

would imply. Whereas birth dates do not tend to

change in such a way.

Indeed, it is not clear that the domid range should

be well approximated by any statistical distribution.

Further, the VM allocation mechanisms in use,

which are not advertised, may well produce domid

ranges whereby near domids are more likely, and

perhaps considerably so, than our assumptions

would allow for. As such, developing a model to

accurately represent domid distribution across hosts

is beyond the scope of this paper, so we do not rely

on purely statistical arguments and instead look for

further evidence for co-location, which we describe

now.

We have already seen that when an instance is

rebooted it acquires a new domid. This will be the

number of new instances started on the host plus the

number of instance reboots. This observation allows

us to add an additional condition:

Suppose, then, that we have two instances both

on hosts with the same CPU model. If they have

identical domids they are not on the same host.

Suppose that the instances’ domids are different and

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

within a host’s domid range (from Table 3). We

denote the lower domid by m, and refer to the

instance with this domid by A. We refer to the

higher domid by n and the instance with this domid

by B. Upon rebooting A, its new domid must,

simply, be greater than the domid of B.

We now state this as a third necessary condition

for co-location:

3. A and B are instances with domids (m,n)

respectively, where m < n. If A and B are

co-locating, then upon rebooting B, its new

domid, p, must satisfy p > n.

Of course, we still do not have a sufficient

condition – instances may satisfy the above by

chance. However, a user is free to reboot their

instances as often as the like. So we can strengthen

the condition as follows:

a. Reboot the instance A, which has

domid p, k times. When rebooted,

the instance with domid n will

obtain a new domid, q, that must

satisfy q > p + k.

Whilst again this may be satisfied by chance,

further repetition should lead to greater confidence

as co-locating instances will satisfy these conditions

To test this, we used 2 pairs of instances, the first

pair with domids (7635, 7638) respectively, and the

second pair (9536, 9538). As the first pair of

instances were on E5-2650 hosts (condition 1), and

have close domids (condition 2) they are good

candidates for co-location. However, upon rebooting

instance with domid 7635, its new domid was 7636,

and so cannot be co-locating with the instance with

domid 7638 (due to condition 3). For the second

pair, again both with CPU model of E5-2650

(condition 1) when rebooting the instance with

domid 9536, its new domid was 9539, and so greater

than 9538 (condition 3). We rebooted this instance a

further 5 times and after the last reboot its domid

was 9544. We then rebooted the instance with domid

9538, after which its domid was 9545 (condition 3a).

This more strongly suggests co-location, and we

note again that a user is of course free to set the

domid distance to any value they like by rebooting

(we set to 6), and to repeat as many times as they

wish.

To now, we only considered instances started

within a short space of time of each other. A user

may have long running instances, and want to know

if newly started instances are co-located with any

long running instance. In this case, a long running

instance’s domid is likely not representative of the

current domids available from the host due to

requests and reboots in the intervening period. In

this case, rebooting the long running instance will

update its domid, and bring the domid into range of

new instances, allowing for further confirmatory

tests to be run.

We now state our test for co-location as follows:

Two instances, A and B, chosen because they have

domids, m and n, such that m < n are likely co-

locating if they satisfy the following:

1. Same CPU model

2. Values of domids are in range (by

Table 3). That is, n –m <= k where k is

the CPU domid range in Table 3.

3. Upon rebooting instance A, its new

domid satisfies p > n.

If 3 is satisfied, then we strengthen the condition as

follows:

3a. Upon rebooting instance A a further k

times, a reboot of B results in a new domid, q

satisfying q > p + k.

We reiterate that (3a) can be carried out as many

times as the user wishes, for any value of k.

6 RECYCLED RESOURCES

In addition to some degree of co-location, we also

observe that instances started from later requests

appear to be scheduled onto the same hosts as earlier

ones. This observation is also based on domids, as

we explain now.

In request 1 we obtain instances with domids

1499 and 1500, and both have E5645 CPUs. In

request 3 we obtain instances with domids of 1501

and 1502, and in request 4 we have 1505 and 1506 –

again all E5645. One explanation is that these

instances were scheduled onto just one host. As

another example, we have the domids 2627, 2628

and 2629 in request 1, followed by 2630, 2631 and

2632 in request 3 and then followed by 2637, 2638,

2639 and 2640 in request 4. All of the instances

were running on a host with a E5-2650 CPU, so

could again have been scheduled onto just one same

host.

In a follow up experiment, we launched 100

instances and found 4 consecutive domids. We

terminated these instances, and 5 minutes later

started another 100 instances (5 of which were

reclaimed). The domids in the two sets ranged

between 759 and 7292. Comparing domids in the

first set to the second, we found a remarkable 51

domids in the first set with consecutive domids in

the second set, 27 domids in the first set with a ‘plus

2’ in the second, 7 at ‘plus three’ and 1 at ‘plus 4’.

The likelihood of our second set of instances being

on a completely different set of hosts to the first, but

having domids so close to the first set would appear

to be small.

AddressingIssuesofCloudResilience,SecurityandPerformancethroughSimpleDetectionofCo-locatingSiblingVirtual

MachineInstances

Running 3 further requests, again of size 100, we

find the same behavior of later instances appearing

to be scheduled on to previously used hosts. This is

also not just a feature of either on-demand or spot

instances, as we observe this for both. Indeed, when

running a batch of spot instances after a batch of on-

demand, we again observe such behavior, suggesting

that requests are being satisfied from the same

resource pool.

It is unclear whether this might be a temporal or

spatial issue. In the former, it may simply be the

case that whilst there is a large amount of available

resource, instances started shortly after earlier ones

are scheduled back on to previously obtained hosts.

In the latter, it may be that a user is restricted to a

subset of the available resources. We know that EC2

is vast in scale, with 28 AZs, most of which

comprise at least 2 data centres - with the largest AZ

having 6 - and each data centre houses between

50,000 to 80,000 physical servers (Vanian, 2014).

For each user, an AZ identifier, such as us-east-1a,

relates to some pool of resources out of which

requests are served. It is possible that AZ identifiers

may map to a data centre in an AZ, or indeed to

some rather smaller subset thereof.

Recycling of resources has the clear potential to

impact on a user’s ability to separate co-locating

instances. In this case, a user may be interested in

the number of attempts needed, and so the cost, to

ensure separation. Perhaps more intriguingly, if a

user is restricted to a subset of resources then

launching a targeted attack against them on EC2

would be much harder - you would only be able to

target users that you share the same resource

partition with. With sufficient data, it may be

possible to answer these questions, and also estimate

the size of resource pool available for use. From this,

one might also estimate a likely number of people

with whom the resource pool is shared, and could

use this number to suggest the risk of security and

performance issues arising.

Finally, given the well established problem of

performance variation due to the heterogeneous

(Osterman et al, 2010

, Iosup, Nezih and Dick, 2011)

nature of Public Clouds, there has been interest in

so-called ‘instance seeking’ or ‘deploy and ditch’

strategies (Farley et al, 2012, Zhuang, Liu, Ou and

Arberer, 2013). The assumption behind these

strategies is that a poorly performing instance can be

released and a new, better performing one, found.

However, as the performance of an instance is

determined by the hosts it is running on, such

strategies are rather less likely to produce

performance gains in the face of resource recycling.

7 CONCLUSIONS

Identifying when sibling instances are co-locating is

beneficial to users in a number of situations:

1. Co-located instances may degrade the

performance of each other when running

compute bound workloads.

2. Co-located instances are all vulnerable to

failure, or degradation, of the underlying

host.

3. Co-located instances are all vulnerable to

other noisy neighbours.

4. Co-located instances imply is a greater

exposure to a security compromise on a

single host.

Determining co-location is challenging,

particularly so on Public Clouds. The simple

approach we have presented in this paper is based on

information provided from Xen, which is currently

the dominant hypervisor technology used in Public

Infrastructure Clouds. Xenstore provides an

interface for domains to obtain information such as

domids and uuids. However, as would be expected,

on EC2 the interface is restricted so a domain can

only obtain information about itself. But the domid

is still very useful for our purposes. On a standard

Xen system, domids are assigned consecutively

when starting domains and are not recycled – except

when the range itself cycles. Instances are assigned

the next available (new) domid when rebooted.

Domids also do not survive host reboots, which

resets the next available domid to 1.

These characteristics of domids allow for the

formulation of the simple test for co-locating sibling

instances as described, based on the same CPU

model and close domids (per Table 3 for the various

CPU models we have observed backing m1.small

instance types). It is still, as we have elaborated,

possible that such instances have close domids

simply by chance, and indeed we have seen such

examples. Simulation methods could be employed to

determine the likelihood of this, but assumptions

regarding the distribution of domids are required, the

validity of which is difficult to establish. Whilst

nearness hints at co-location, further evidence is

required.

Further evidence is provided by the observation

that one instance can restrict the possible range of

values for another instance’s domid – simply via

rebooting itself and so increasing the next available

domid value. The second instance, upon a reboot,

can then in turn restrict possible domid values for the

first instances. This process can be repeated as often

as a user chooses, and at the domid distance the user

chooses (the reboot value), and therefore each time

this is done the probability that this happens by

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

chance decreases. Further, this is not limited to

instances started close to each other in time, but can

be used when any pair of instances is suspected of

co-locating.

We should be clear that whilst passing the tests

described in section 5 decreases the likelihood that

the instances are not co-locating, increasingly so

when repeated, we cannot say for certain that the

instances are co-locating. From a pragmatic point of

view, a user must balance the risk of having co-

located instances with the cost of (determining and

then ensuring) separation.

Determining such costs may be difficult as there

appears to be a degree of recycling of resources, as

described in section 6. This also has an immediate

and significant consequence for the probability of

success in carrying out a targeted side channel attack

on a Public Cloud. Indeed, from our work here, we

find the chance of intentionally co-locating with

sibling instances to be fairly small. Co-locating with

any intended target would therefore be more

unlikely still, if it is indeed possible at all. We also

note the impacts for so-called ‘performance seekers’,

whereby a user releases back underperforming

instances in the hope of acquiring better performing

new instances. A user may simply be paying to

obtain resources they have already had.

In summary, our test is simple to implement and

works on Linux, Windows and FreeBSD Operating

Systems, with the appropriate Xenstore client tool.

Future work is largely aimed at further exploration

and confirmation of the ideas discussed in this paper.

In particular, we would like to be able to identify

behaviours of instances that can be detected by

others as would confirm co-location, without

incurring the effort involved with rewriting (for

Linux) kernel memory management features to spot

avoidance of shared cache use, and further ensuring

that any such observation are not due to chance.

REFERENCES

Armbrust, M. et al. (2009) “Above the clouds: a Berkely

view of cloud computing”. Technical Report EECS-

2008-28, EECS Department, University of California,

Berkeley.

Intel, (2014) [Online]. Available at: www.intel.com/

content/dam/www/public/use/en/documents/white-

papers/intel-saa-performance-white-paper.pdf.

[Accessed on 02/01/2015]

Zhang, X. et al. (2013) CPI^2: CPU performance isolation

for shared compute clusters, Proc of EuroSys 2013, pp

379-391.

Zhang, Y. et al. (2012) Cross-VM Side Channels and their

use to Extract Private Keys, Proc of the 2012 ACM

Conference on Computer and communications

Security, pp305-316.

Ristenpart, T. Tromer, E. Shacham, H. Savage, S. (2010)

Hey you get off my Cloud, Proc of the 16

ACM

Conference on Computer and communications

Security, pp199-212.

Bates, A. et al (2013) On Detecting Co-resident Cloud

Instances using Network Flow Watermarking

Techniques, International Journal of Information

Security, Vol 13, Issue 2, pp 171-189.

Lui, F. Ren, L. Bai, H. (2014) Mitigating Cross-VM Side

Channel Attacks on Multiple Tenants Cloud Platform,

Journal of Computers, Vol 9, No 4, pp1005-1013.

Zhang, Y. Juels, A. Oprea, A. Reiter, M.K. (2011) Home

Alone: Co residency detection in the cloud via side

channel analysis, Proc 2011 IEEE Symposium on

Security and Privacy, pp313-328.

Xen, (no date) [Online]. Available at: www.xenproject.org

[Accessed: 08/02/2015].

Xenstore, (2014) [Online]. Available at:

http://wiki.xen.org/wiki/XenStoreReference

[Accessed: 08/02/2015].

Blind Ref, no date:

Dasgupta, A. (2004) The Matching, Birthday and Strong

Birthday Problem: A Contemporary Review, Journal

of Statistical Planning and Inference 130, pp377-389,

2004.

Vanian, J., 2014. [Online]. Available at: https://gigaom.

com/2014/11/12/amazon-details-how-it-does-

networking-in-its-data-centers/ [Accessed:

08/02/2015].

Osterman, S., et al. (2010) A performance analysis of EC2

cloud computing services for scientific computing,

Cloud Computing, Lecture Notes of the Institute for

Computer Sciences, Social-Informatics and

Telecommunications Engineering, vol 34, pp115-131.

Iosup, A. Nezih, Y. and Dick, E. (2011) On the

performance variability of production cloud services.

In Cluster, Cloud and Grid Computing (CCGrid),

2011.

Farley, B. et al. (2012) “More for your money: exploiting

performance heterogeneity in Public Clouds”, in Proc.

of the Third ACM Symposium on Cloud Computing,

article no. 20.

Zhuang, H. Liu, X. Ou, Z. Arberer, A. (2013) “Impact of

Instance Seeking Strategies on Resource Allocation in

Cloud Data Centres”, in Proc. Of the IEEE Sixth

International Conference on Cloud Computing, pp27-

34.

AddressingIssuesofCloudResilience,SecurityandPerformancethroughSimpleDetectionofCo-locatingSiblingVirtual

MachineInstances
