PaaSword: A Holistic Data Privacy and Security by Design Framework

for Cloud Services

Yiannis Verginadis

, Antonis Michalas

, Panagiotis Gouvas

, Gunther Schiefer

, Gerald H

ubsch

and Iraklis Paraskakis

Institute of Communications and Computer Systems, National Technical University of Athens, Athens, Greece

Security Lab, Swedish Institute of Computer Science, Stockholm, Sweden

Ubitech Ltd., Athens, Greece

Karlsruhe Institute of Technology, Karlsruhe, Germany

CAS Software AG, Karlsruhe, Germany

South East European Research Centre, Thessaloniki, Greece

Keywords:

Data Privacy, Security by Design, Context-aware Security, Symmetric Searchable Encryption, Cloud Com-

puting.

Abstract:

The valuable transformation of organizations that adopt cloud computing is indisputably accompanied by a

number of security threats that should be considered. In this paper, we outline signiﬁcant security challenges

presented when migrating to a cloud environment and propose PaaSword – a novel holistic, data privacy and

security by design, framework that aspires to alleviate them. The envisaged framework intends to maximize

and fortify the trust of individual, professional and corporate users to cloud services. Speciﬁcally, PaaSword

involves a context-aware security model, the necessary policies enforcement and governance mechanisms

along with a physical distribution, encryption and query middleware, aimed at facilitating the implementation

of secure and transparent cloud-based applications.

1 INTRODUCTION

Until recently, large-scale computing was available

exclusively to large organizations with an abundance

of in-house expertise. Cloud computing has changed

that to the point where any user with even basic tech-

nical skills can obtain access to vast computing re-

sources at low cost. In the technology adoption life-

cycle, cloud computing has now moved from an early

adopters stage to an early majority, where we typi-

cally see exponential number of deployments (Santos

et al., 2009). Throughout the past few years, many

users have started relying on cloud services without

realizing it. Major web mail providers utilize cloud

technology; tablets and smartphones often default to

automatically uploading user photos to cloud storage

and social networks; ﬁnally, several prominent CRM

vendors offer their services using the cloud. In other

words, the adoption of cloud computing has moved

from focused interest to widely spread intensive ex-

perimentation and is now rapidly approaching a phase

of near ubiquitous use.

Enterprises increasingly recognize the compelling

economic and operational beneﬁts of cloud comput-

ing (Micro, 2010). Virtualizing and pooling IT re-

sources in the cloud enables organisations to realize

signiﬁcant cost savings and accelerates deployment of

new applications, simultaneously transforming busi-

ness and government at an unprecedented pace (CSA,

2013). However, those valuable business beneﬁts can-

not be unlocked without addressing new data security

challenges posed by cloud computing.

Despite the beneﬁts of cloud computing, many

companies have remained cautious due to security

concerns. Applications and storage volumes often re-

side next to potentially hostile virtual environments,

leaving sensitive information at risk to theft, unau-

thorized exposure or malicious manipulation. Gov-

ernmental regulation regarding data privacy and lo-

cation presents an additional concern of signiﬁcant

legal and ﬁnancial consequences if data conﬁden-

tiality is breached, or if cloud providers move regu-

206

Verginadis Y., Michalas A., Gouvas P., Schiefer G., Hübsch G. and Paraskakis I..

PaaSword: A Holistic Data Privacy and Security by Design Framework for Cloud Services.

DOI: 10.5220/0005489302060213

In Proceedings of the 5th International Conference on Cloud Computing and Services Science (CLOSER-2015), pages 206-213

ISBN: 978-989-758-104-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

lated data across national borders (Paladi and Micha-

las, 2014). The contribution of this position paper

is two-fold. First, we present a list of core security

requirements and challenges that must be considered

when migrating to a cloud environment. These se-

curity requirements were derived based on our expe-

rience with migrating existing applications to a pri-

vate Infrastructure-as-a-Service (IaaS) cloud (Micha-

las et al., 2014). We extend this guide by discussing

important attack vector characteristics for cloud envi-

ronments that will pave the way for providing tighter

security when building cloud services. Second, in or-

der to tackle the critical cloud security challenges we

present PaaSword, an envisaged framework that will

maximize and fortify the trust of individual, profes-

sional and corporate users to cloud services and appli-

cations. PaaSword achieves that by providing storage

protection mechanisms, which improves conﬁdential-

ity and integrity protection of users’ data in the cloud

while it does not affect the data access functionality.

The rest of this paper is organized as follows. In

Section 2, we further elaborate on the main data se-

curity challenges in cloud-enabled services and appli-

cations. In Section 3, we introduce a holistic, data

privacy and security by design, framework enhanced

by sophisticated context-aware access models and ro-

bust policy enforcement and governance mechanisms,

aimed at facilitating the implementation of secure and

transparent cloud-based applications. In Section 4,

we brieﬂy discuss relevant work while in Section 5,

we conclude the paper by presenting the next steps

for the implementation and evaluation of the proposed

framework.

2 DATA SECURITY

CHALLENGES IN THE CLOUD

According to the Cloud Security Alliance (Alliance,

2013), several top security identiﬁed threats refer

to information disclosure and repudiation, rendering

data security as realised through data protection, pri-

vacy, conﬁdentiality, and integrity as top priorities.

More precisely, the top four threats identiﬁed are:

data leakage, data loss, account hijacking and inse-

cure APIs. The externalized aspect of outsourcing

can make it harder to maintain data integrity and pri-

vacy (IBM, 2011) and organizations should include

mechanisms to mitigate security risks introduced by

virtualization. Especially when they deal with sen-

sitive data, such as health records, the protection of

stored information comes as a top priority. There-

fore, data security can be seen as the foundation upon

which the entire transition to a cloud architecture

should be based. Multiple risks must be addressed

in order for an organization to guarantee the safety of

users’ records. One of the most important aspects is

security of sensitive information. To this end, the de-

ployment must ensure that all sensitive data is stored

in encrypted form. Complementary to this, proper key

management must ensure that encryption keys are not

revealed to malicious users.

Based on this, it becomes evident that the most

critical part of a modern cloud application is the

data persistency layer and the database itself. As

all sensitive information (including user credentials,

credit card info, personal data, corporate data, etc.)

are stored in these architectural parts, the database-

takeover is the ultimate goal for every adversary.

The Open Web Application Security Project

foundation has categorized the database-related at-

tacks (SQL injection) as the most critical ones. The

importance of this attack vector is also reﬂected

by respective incident reports. According to the

Web Hacking Incidents Database

, SQL injections

represents 17% of all security breaches examined.

These injections were responsible for 83% of the to-

tal records stolen, in successful hacking-related data

breaches from 2005 to 2011. The criticality of the per-

sistency layer is therefore evident. Most of the secu-

rity fences that are conﬁgured in a corporate environ-

ment target the fortiﬁcation of the so-called network

perimeter (e.g. routers, hosts and virtual machines).

Although existing intrusion detection systems (IDS)

and intrusion prevention systems (IPS), try to cope

with database-takeover security aspects (like Snort),

the fact that, on the one side, automated exploitation

tools (e.g. SQLMap) are widely spread, and, on the

other side, IPS and IDS evasion techniques have be-

come extremely sophisticated, denote that the risk of

database compromise is greatest than ever. More-

over, by using mechanisms that rely on Web Appli-

cation Firewalls (WAF) an organization can prevent

various types of attacks but it is inadequate to protect

against todays sophisticated SQL Injection and DoS

attacks (Michalas et al., 2010). Additionally, inter-

nal adversaries in terms of cloud vendors or even un-

known vulnerabilities of software platforms and secu-

rity components widely adopted in cloud-based devel-

opment may provide malicious access to personal and

sensitive data. A recent example was the Heartbleed

ﬂaw

that constituted a serious fault in the OpenSSL

cryptography library, which remained unnoticed for

https://www.owasp.org/

http://projects.webappsec.org/w/page/13246995/Web-

Hacking-Incident-Database

http://www.infosecurity-

magazine.com/news/heartbleed-101/

PaaSword:AHolisticDataPrivacyandSecuritybyDesignFrameworkforCloudServices

207

more than two years and affected over 60% of Web

servers worldwide. Additionally, regarding the post-

exploitation phase, things are even worse in the case

where a symmetric encryption algorithm has been

employed to protect the application data. The already

available cracking toolkits that utilize GPU process-

ing power (e.g. oclHashcat) are able to crack ciphers

using brute-force techniques with an attack rate of

162 billion attempts per second.

While most of the attack vectors are exposed

in any Software-as-a-Service application by the sys-

tem administrators misconﬁgurations, the database

takeover and the post-exploitation of acquired data is

under the sole responsibility of the application devel-

oper. The application developer is the one responsi-

ble both for sanitizing all HTTP-input parameters that

could be used as attack vectors, and for reassuring that

compromised data will be useless under the existing

brute-forcing and reversing techniques. Nevertheless,

even if the application developer follows strict guide-

lines, the mere utilization of an IaaS provider in or-

der to host a Virtual Machine, or for a Platform-as-

a-Service (PaaS) provider in order to develop a cloud

application, may by itself spawn a multitude of in-

herent vulnerabilities. These vulnerabilities cannot

be tackled effectively as they typically exceed the re-

sponsibilities of an application developer.

3 ENVISIONED FRAMEWORK

In this section, we present PaaSword, a framework

that will allow cloud services to maintain a fully dis-

tributed and encrypted data persistence layer in order

to foster data protection, integrity and conﬁdential-

ity in the presence of malicious adversaries. To this

end, we describe the need for a context-aware security

model which will serve as the basis of a ﬁne-grained

access control scheme, one which allows the per-user

management of access rights. In addition to that, we

describe a physical distribution, encryption and query

middleware that will be based on a searchable encryp-

tion (SE) scheme which will allow legitimate users to

directly search on encrypted data, thus ensuring the

conﬁdentiality and integrity of stored data.

3.1 Context-aware Access Model

We envision a XACML-based

context-aware access

model, which is needed by the developers in order

to annotate the Data Access Objects of their appli-

cations. This context model should conceptualize the

OASIS eXtensible Access Control Markup Language

(XACML). https://www.oasis-open.org/

aspects, which must be considered during the selec-

tion of a data-access policy. These aspects may be any

kind of information which is machine-parsable (Dey,

2001); indicatively they may include the user’s IP ad-

dress and location, the type of device that she is us-

ing in order to interact with the application as well

as her position in the company. These aspects can

be interpreted in different ways during the security

policy enforcement. In particular, the context aware

access model determines which data is accessible un-

der which circumstances by an already-authenticated

user.

Access control models are responsible for decid-

ing if a user has the right to execute a certain operation

on a speciﬁc object. Objects can be a server, an ap-

plication, an entire database or even a single ﬁeld in

a table row. The user is considered as the active el-

ement and is called subject. A permission associates

an object with an operation (e.g. read, write etc.). Ac-

cess control models provide a list of permissions that

each subject has on certain objects.

Commonly used access control models are the

Mandatory Access Control (MAC), the Discretionary

Access Control (DAC) and the Role-Based Access

Control (RBAC) (Ferrari, 2010). In our approach, the

process of granting/denying access will be based on

dynamically changing parameters, thus our proposed

model relies on a DAC model with groups. The con-

text parameters are unique for every single user, so for

granting access it is necessary to consider all infor-

mation associated with a single user. Furthermore, an

RBAC model would be inappropriate since for every

change of a context parameter the role of each subject

has to be changed.

To implement the dynamic change of context pa-

rameters in a static access control model, we will use

the, so-called, context switches. Depending on the

current context, a permission can be granted or de-

nied (switched). This could switch dynamically with

every change of the context. Context switches are re-

sponsible for managing operational permissions and

object permissions. An operational permission gives

the right to a subject to perform a speciﬁc operation

while an object permission gives the right to perform

an operation on a speciﬁc object.

3.2 Policies Access and Enforcement

Another important aspect of our proposed framework

is a middleware that will encapsulate capabilities for

maintaining the access policies model, for annotat-

ing and managing data access object annotations, for

controlling their validity, for dynamically interpreting

them into policy enforcement rules and for enforc-

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

208

ing them. This envisaged middleware will provide:

(a) a transparent key usage for efﬁcient authentication

purposes, related to authenticating the origin of the

incoming access requests; (b) annotation capabilities

in the form of a tool (can also involve an IDE plug-

in) for allowing developers to declaratively create the

minimum amount of rule-set that is needed for secu-

rity enforcement purposes; (c) the dynamic interpre-

tation of the data access object annotations into pol-

icy enforcement rules; (d) the governance and quality

control of the annotations and their respective policy

rules; and (e) the formulation and implementation of

the overall policy enforcement business logic.

In terms of this middleware, we also consider the

reuse and proper extension of technologies for de-

veloping an appropriate key management mechanism.

This mechanism is necessary for the authentication of

different parties that will be involved in the encryp-

tion and decryption of data. We aim at constituting

the key-usage, transparent to the application usage.

This involves the key propagation upon authentica-

tion of the user, directly to the security enforcement

middleware. For efﬁciency, we will employ a hybrid

encryption capitalizing upon the utilization of two dif-

ferent encryption functions. The inner layer will be

encrypted with an algorithm that uses a symmetric

encryption key K, while the outer layer will use an

asymmetric encryption in order to encrypt the sym-

metric key K. Symmetric encryption allows more ef-

ﬁcient schemes but privacy concerns are raised due to

the fact that the involved parties must exchange the

secret key. However, combining both techniques help

to optimize the efﬁciency of the underlying protocols

without sacriﬁcing security. To this end, PaaSword

will rely on both symmetric and asymmetric encryp-

tion in order to securely distribute K between legiti-

mate users.

Additionally, we will also employ methods and

mechanisms for governance and validity control of

the data object annotations. More speciﬁcally, we

will focus on the application of an ontology-driven

governance approach for: i) the basic management of

data object annotations (i.e. storage, retrieval, dele-

tion, etc.), ii) validity checking of the data object an-

notations (e.g. rejecting any contradicting annotations

made by the developer) and iii) dependency tracking

among data objects annotations.

Another critical aspect of this middleware is the

annotations interpretation mechanism. Such a mech-

anism will be used for dynamically generating access

control policies, during application runtime, based on

the interpretation of data object annotations. Such a

mechanism will implement the essential decoupling

between the access decisions and the points of use

(i.e. Policy Enforcement Points (PEP) of the XACML

speciﬁcation). This interpretation is based on an

XACML compliant context model and it can augment

the offered functionality of any PaaS provider, with

a security-as-a-service layer. To do so, we will use

the OASIS XACML as it supports and encourages

the separation of the access decision from the point

of use.

Figure 1: High level view of XACML Components.

3.3 Threat Model, Secure Storage &

Query Middleware

In this sub-section, we provide a high level descrip-

tion of the protocol that will be used to effectively

protect the stored data from malicious adversaries.

To this end, we ﬁrst describe the threat model under

which a cloud application will be considered secure.

Threat Model. Similar to existing works in the

area (Paladi et al., 2014; Santos et al., 2009), we

assume a semi-honest cloud provider. In the semi-

honest adversarial model, a malicious cloud provider

correctly follows the protocol speciﬁcation. However,

she can intercept all messages and may attempt to

use them in order to learn information that otherwise

should remain private. Semi-honest adversaries are

also called honest-but-curious.

Furthermore, for the rest of the participants in

the protocol we share the threat model with (Santos

et al., 2009), which is based on the Dolev-Yao adver-

sarial model (Dolev and Yao, 1983) and further as-

sumes that privileged access rights can be used by a

remote adversary A DV to leak conﬁdential informa-

tion. The adversary, e.g. a corrupted system admin-

istrator, can obtain remote access to any host main-

tained by the provider. However, the adversary can-

not access the volatile memory of any guest virtual

machine (VM) residing on the compute hosts of the

provider. This property is based on the closed-box

execution environment for guest VMs, as outlined in

Terra (Garﬁnkel et al., 2003) and further developed

in (Zhang et al., 2011).

PaaSword:AHolisticDataPrivacyandSecuritybyDesignFrameworkforCloudServices

209

Secure Storage. A basic tenet of PaaSword is that

sensitive data stored on untrusted servers must be al-

ways encrypted. This effectively reduces the privacy

and security risks since it relies on the semantic se-

curity of the underlying cryptosystem, rendering the

system relatively immune to internal and external at-

tacks. Having this in mind, we propose a forward-

looking design for a cryptographic cloud storage that

will be based on a symmetric searchable encryption

(SSE) scheme similar to the one proposed in (Ka-

mara and Lauter, 2010). We plan to extend the pre-

vious work Cumulus4j (Huber et al., 2013) and Mi-

moSecco (Gabel and H

ubsch, 2014) in which an SSE

scheme was presented and it was based on the IND-

ICP security notion (B

osch et al., 2014) that hides re-

lations between different data values of a data row and

creates the base for secure database outsourcing.

An SSE scheme allows a user to search in en-

crypted data without learning any information about

the plaintext data. Let D B =

{

, . . . , m

}

be a set

of n messages (w.l.o.g DB can be considered as a

database). For each m

∈ DB we extract a set of key-

words which can later be used for executing queries.

This set of keywords is denoted as W =

{

, . . . , w

}

For each w

∈ W we calculate H(w

), where H(·) is

a cryptographically secure hash function under a se-

cret key K

. Then, we encrypt the elements of DB

with a secret key K

6= K

. By doing this, we create a

searchable encrypted index I where each index entry,

points to an encrypted list of rows that have a cer-

tain keyword. The client can use a trapdoor function

to search the index and determine whether a speciﬁc

keyword is contained in the index.

While the above-mentioned scheme is imple-

mented in previous works (Huber et al., 2013; Gabel

and H

ubsch, 2014) it has a limitation that we tend

to cover in our proposed framework. More precisely,

the current scheme follows a single write/single read

(S/S) architecture, which makes it unrealistic for our

cloud scenario. To overcome this limitation, we plan

to build an SSE that will support multi write/multi

read (M/M) meaning that a group of users based on

access rights will be able to both read and write on

the encrypted data. To this end, PaaSword will in-

volve a key distribution algorithm that will extend S/S

architecture to M/M. Additionally, a user revocation

function will be implemented in order to exclude a

user, which either acts maliciously or has no longer

access rights. This is a crucial and challenging pro-

cedure, if we consider that many of the existing SSE

schemes (B

osch et al., 2014) do not support user re-

vocation and thus are susceptible to many attacks.

Query Middleware. In order to successfully sup-

port the SSE scheme described above, we aim to de-

velop a persistency layer, called Virtual Database VB

(Figure 2), and will be the intermediary that secures

client data before it gets uploaded to the cloud. Addi-

tionally, this layer will be responsible for processing

user queries. In our framework, the VB plays the role

of a trusted third party. Consider, for example, the

scenario where a user wants to search for a certain

data in PaaSword secured databases. To do so, she

will generate a query (q) containing a set of keywords

that she is interested in and will send the request to the

VB. Upon reception, the VB extracts the keywords

from q calculates their hash values and queries the

databases where the keywords w

are stored. If the

queries are successful and the keywords exist in one

of the tables, the VB will obtain the row from the main

table that contains the encrypted original data. Upon

reception, the VB will reply to the users request by

sending the acquired data.

3.4 Conceptual Architecture

The PaaSword compliant cloud applications that will

be developed will inherit a fully physical distributed

and totally encrypted data persistence layer, which

will be able to determine on an ad-hoc basis whether

an incoming data querying and processing request

should be granted access to the target data during ap-

plication runtime. The transformation process of a

traditional application utilizing the PaaSword frame-

work and the way the transformed application secures

and protects the users’ sensitive data is presented in

Figure 2, which at the same time reveals high level

architectural details of the framework.

In this framework, we consider applications that

adopt and respect the Model-View-Controller (MVC)

development pattern (Krasner and Pope, 1988). As

seen in Figure 2 (step 1) the application developer

imports an existing or creates a new MVC-based ap-

plication in her favorite integrated development en-

vironment (IDE) for which an IDE-speciﬁc plug-in

will be provided. During the second step of this pro-

cess the application developer creates annotations at

the DAO of the Controller referring to sensitive data

that should be protected, according to the XACML-

based model and deﬁnes the physical distribution, en-

cryption and access rights scheme for each data ob-

ject. In the third step, the DAO annotations will be

checked for their validity and compiled with the over-

all application code. This will allow the transforma-

tion of the application’s controller that has been en-

hanced with XACML-based DAO annotations, lead-

ing to the implementation of a PaaSword secure ap-

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

210

plication. In the fourth step, the persistence layer

of the application will be physically distributed and

encrypted at the schema and instance level accord-

ing to the incorporated DAO annotations, impos-

ing the schema and driving query handling capabil-

ities of the VB that augments the actual data persis-

tence layer of the application. At application run-

time (step 5), each query and processing request of

the end-user is forwarded by the enhanced controller

to the query handling mechanism that is responsible

for the database proxy queries synthesis and aposyn-

thesis. In step 6 and before the submission of the en-

hanced query to the VB, the query handling mecha-

nism consults the policy enforcement mechanism to

determine whether the incoming request should be

granted or not. Upon policies enforcement and access

permission, the query handling mechanism submits

(step 7) the enhanced query to the augmented per-

sistence layer (virtual database). The database proxy

that is aware of the physical distribution scheme of

the actual application database realizes the distributed

query to the physically distributed and encrypted parts

of the actual application database (step 8). Next, the

federation of the respective encrypted data from the

distributed parts of the database takes place (step 9).

The federated data synthesis and ad-hoc decryption

utilizing the key of the end-user that is transparently

to the application, propagated to the query handling

mechanism (step 10). Last, the query handling mech-

anism delivers the decrypted data to the application

controller that forwards them to the end-user through

the “view” component of the application.

According to the conceptual view (Figure 2), each

end-user is equipped with a Hardware Security Mod-

ule, such as USB stick or a smart-phone with digital

rights management module, which contains a digital

certiﬁcate (e.g. X.509). Part of the certiﬁcate includes

keys that can be exported by the PaaS/IaaS provider.

These keys upon export and veriﬁcation will be trans-

parently handed over to the query middleware which

will be responsible for interacting with the VB, en-

crypting and decrypting the targeted data.

4 RELATED WORK

In an attempt to reinforce the security of remote ser-

vice accesses, researchers introduced the concept of

location-aware access control (LAAC), which allows

a system to grant, or deny, access to users based on

their physical location. LAAC models typically ex-

tend the three basic access control models DAC, MAC

and RBAC (Decker, 2011). Even though LAAC pro-

tocols have been studied extensively (Cleeff et al.,

2010), there is a clear lack of schemes that determine

user access not only on the basis of the users physi-

cal location and credentials, but also on the additional

pertinent contextual information.

The work reported in (Covington et al., 2001) was

the ﬁrst to introduce the notion of context-aware ac-

cess control (CAAC), motivated by applications for

intelligent homes. More precisely, the authors intro-

duced a set of services which are enabled based on

the location of objects or subjects. The main draw-

back of the proposed model is the fact that it does

not support dynamically generated context, whilst it

fails to address important requirements such as multi-

granularity of position. Other existing CAAC mod-

els are predominantly based on RBAC (Kayes et al.,

2013) and typically target a speciﬁc domain (Costa-

bello et al., 2012).These models, however, have not

been designed to provide ﬁne-grained data access

control, e.g. by providing the ability to specify dif-

ferent access rules for different rows of a database.

Regarding the policy management, as shown by

a recent survey of methods in contemporary open

source registry and repository systems (Kourtesis and

Paraskakis, 2012), a major weakness is the lack of

proper separation of concerns. The policy deﬁnition

and policy enforcement are entangled in the imple-

mentation of a single software component – the pol-

icy checker. The rules that a policy comprises are typ-

ically encoded in an imperative manner, as part of the

same code that checks for potential policy violations.

This has a number of negative repercussions among

which is the lack of portability and the lack of explicit

representation of policy relationships.

The data distribution and encryption algorithms

are also important aspects towards trusted cloud ser-

vices and applications. In (Gentry, 2009), C. Gen-

try presented the ﬁrst fully homomorphic encryption

scheme that enables semantically secure outsourcing

to the cloud. The cloud provider operates blindly on

the encrypted data and yields the correct, encrypted

result. Nevertheless, its practicality is in question as

the latest implementations are still orders of magni-

tude slower than just downloading all encrypted data,

decrypting, processing and encrypting it locally and

ﬁnally uploading it again. In another interesting ap-

proach (Popa et al., 2011), the concept of onions is

used. Onions are managed monolithically by a proxy,

acting as an adapter between the user and the storage

back-end. Each attribute in a relational table is ini-

tially asymmetrically encrypted. If certain queries for

an attribute are issued, layers of the onion are peeled

off, resulting in another, less secure onion. CryptDB

uses a novel scheme for order preserving encryption

that leaks no information about the data besides or-

PaaSword:AHolisticDataPrivacyandSecuritybyDesignFrameworkforCloudServices

211

Figure 2: PaaSword Framework Conceptual Architecture.

der and thus allows sorting encrypted data securely.

The main drawback of CryptDB is the lack of secu-

rity guarantees to the client. More precisely, the only

guarantee is that an untrusted server will learn only

the information that is necessary to process the query.

This may cause every attribute to be reduced to the

plain text in the worst case. Also, peeling off layers

cannot be reversed, so a single query is sufﬁcient to

lower the security forever.

5 CONCLUSIONS

In this position paper, we proposed the PaaSword

framework that can be exposed as a service at the

level of PaaS. This framework can tackle the identi-

ﬁed cloud security requirements and challenges that

should be considered in order to enhance data protec-

tion, integrity and conﬁdentiality in the presence of

malicious adversaries. The envisaged PaaSword goes

beyond the state-of-the-art and allows cloud services

to maintain a fully distributed and encrypted data per-

sistence layer. Our framework involves a context-

aware security model, the necessary policies enforce-

ment mechanism along with a physical distribution,

encryption and query middleware.

Future work involves the design and implementa-

tion of the proposed framework into a fully functional

solution which will be validated through the follow-

ing ﬁve pilots in various industrial contexts: i) En-

crypted persistency as a service in a PaaS provider, ii)

Intergovernmental secure document and personal data

exchange, iii) Secure sensors data fusion and analyt-

ics, iv) Protection of personal data in a multi-tenant

CRM, v) Protection of sensible enterprise information

in multi-tenant ERP. These pilots will allow us to test

PaaSword and validate its added value in a variety of

heterogeneous cases.

Finally, an area that will beneﬁt from PaaS-

word framework is the so called participatory sens-

ing (Michalas and Komninos, 2014). The evolution of

this ﬁeld is driven by the introduction of sensors into

mobile devices. The openness of such systems and

the richness of user data they entail raise signiﬁcant

concerns for their storage and processing. Protocol

designers by having PaaSword framework in hands

will be able to incorporate secure cloud computing

techniques in order to facilitate the storage and pro-

cessing of the vast amount of collected data.

ACKNOWLEDGEMENTS

The research leading to these results has re-

ceived funding from the European Union’s Hori-

zon 2020 research and innovation programme under

grant agreement No 644814, the PaaSword project

(www.paasword.eu) within the ICT Programme ICT-

07-2014: Advanced Cloud Infrastructures and Ser-

vices.

REFERENCES

Alliance, C. S. (2013). The notorious nine – cloud comput-

ing top threats in 2013.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

212

osch, C., Hartel, P., Jonker, W., and Peter, A. (2014).

A survey of provably secure searchable encryption.

ACM Comput. Surv., 47(2):18:1–18:51.

Cleeff, A. v., Pieters, W., and Wieringa, R. (2010). Beneﬁts

of location-based access control: A literature study. In

Proceedings of the 2010 IEEE/ACM Int’L Conference

on Green Computing and Communications & Int’L

Conference on Cyber, Physical and Social Computing,

GREENCOM-CPSCOM ’10, pages 739–746, Wash-

ington, DC, USA. IEEE Computer Society.

Costabello, L., Villata, S., and Gandon, F. (2012). Context-

aware access control for rdf graph stores. In Raedt,

L. D., Bessire, C., Dubois, D., Doherty, P., Frasconi,

P., Heintz, F., and Lucas, P. J. F., editors, ECAI, vol-

ume 242 of Frontiers in Artiﬁcial Intelligence and Ap-

plications, pages 282–287. IOS Press.

Covington, M. J., Long, W., Srinivasan, S., Dev, A. K.,

Ahamad, M., and Abowd, G. D. (2001). Securing

context-aware applications using environment roles.

In Proceedings of the Sixth ACM Symposium on Ac-

cess Control Models and Technologies, SACMAT ’01,

pages 10–20, New York, NY, USA. ACM.

Decker, M. (2011). Modelling of location-aware access

control rules. In Handbook of Research on Mobility

and Computing: Evolving Technologies and Ubiqui-

tous Impacts, pages 912–929. IGI Global.

Dey, A. K. (2001). Understanding and using context. Per-

sonal Ubiquitous Comput., 5(1):4–7.

Dolev, D. and Yao, A. C. (1983). On the security of pub-

lic key protocols. Information Theory, IEEE Transac-

tions, 29(2):198–208.

Ferrari, E. (2010). Access Control in Data Management

Systems. Morgan and Claypool Publishers.

Gabel, M. and H

ubsch, G. (2014). Secure database out-

sourcing to the cloud using the mimosecco middle-

ware. In Krcmar, H., Reussner, R., and Rumpe, B.,

editors, Trusted Cloud Computing, pages 187–202.

Springer International Publishing.

Garﬁnkel, T., Pfaff, B., Chow, J., Rosenblum, M., and

Boneh, D. (2003). Terra: A virtual machine-based

platform for trusted computing. In ACM SIGOPS Op-

erating Systems Review, volume 37, pages 193–206.

Gentry, C. (2009). A Fully Homomorphic Encryp-

tion Scheme. PhD thesis, Stanford, CA, USA.

AAI3382729.

Huber, M., Gabel, M., Schulze, M., and Bieber, A. (2013).

Cumulus4j: A provably secure database abstraction

layer. In Cuzzocrea, A., Kittl, C., Simos, D. E.,

Weippl, E., Xu, L., Cuzzocrea, A., Kittl, C., Simos,

D. E., Weippl, E., and Xu, L., editors, CD-ARES

Workshops, volume 8128 of Lecture Notes in Com-

puter Science, pages 180–193. Springer.

IBM (2011). Security and high availability in cloud comput-

ing environments. Technical report, IBM SmartCloud

Enterprise, East Lansing, Michigan.

Kamara, S. and Lauter, K. (2010). Cryptographic cloud

storage. In Sion, R., Curtmola, R., Dietrich, S., Ki-

ayias, A., Miret, J., Sako, K., and Seb, F., editors,

Financial Cryptography and Data Security, volume

6054 of Lecture Notes in Computer Science, pages

136–149. Springer Berlin Heidelberg.

Kayes, A. S. M., Han, J., and Colman, A. (2013).

An ontology-based approach to context-aware access

control for software services. In Lin, X., Manolopou-

los, Y., Srivastava, D., and Huang, G., editors, WISE

(1), volume 8180 of Lecture Notes in Computer Sci-

ence, pages 410–420. Springer.

Kourtesis, D. and Paraskakis, I. (2012). A registry and

repository system supporting cloud application plat-

form governance. In Proceedings of the 2011 In-

ternational Conference on Service-Oriented Comput-

ing, ICSOC’11, pages 255–256, Berlin, Heidelberg.

Springer-Verlag.

Krasner, G. E. and Pope, S. T. (1988). A cookbook for using

the model-view controller user interface paradigm in

smalltalk-80. J. Object Oriented Program., 1(3):26–

49.

Michalas, A. and Komninos, N. (2014). The lord of

the sense: A privacy preserving reputation system

for participatory sensing applications. In Computers

and Communication (ISCC), 2014 IEEE Symposium,

pages 1–6. IEEE.

Michalas, A., Komninos, N., Prasad, N. R., and Oleshchuk,

V. A. (2010). New client puzzle approach for dos re-

sistance in ad hoc networks. In Information Theory

and Information Security (ICITIS), 2010 IEEE Inter-

national Conference, pages 568–573. IEEE.

Michalas, A., Paladi, N., and Gehrmann, C. (2014). Secu-

rity aspects of e-health systems migration to the cloud.

In e-Health Networking, Applications and Services

(Healthcom), 2014 IEEE 16th International Confer-

ence on, pages 212–218. IEEE.

Micro, T. (2010). The need for cloud computing security.

In A Trend Micro White Paper.

Paladi, N. and Michalas, A. (2014). “One of our hosts in

another country”: Challenges of data geolocation in

cloud storage. In Wireless Communications, Vehicular

Technology, Information Theory and Aerospace Elec-

tronic Systems (VITAE), 2014 4th International Con-

ference on, pages 1–6.

Paladi, N., Michalas, A., and Gehrmann, C. (2014). Do-

main based storage protection with secure access con-

trol for the cloud. In Proceedings of the 2014 Inter-

national Workshop on Security in Cloud Computing,

ASIACCS ’14, New York, NY, USA. ACM.

Popa, R. A., Redﬁeld, C. M. S., Zeldovich, N., and Balakr-

ishnan, H. (2011). Cryptdb: Protecting conﬁdentiality

with encrypted query processing. In Proceedings of

the Twenty-Third ACM Symposium on Operating Sys-

tems Principles, SOSP ’11, pages 85–100, New York,

NY, USA. ACM.

Santos, N., Gummadi, K. P., and Rodrigues, R. (2009). To-

wards trusted cloud computing. In Proceedings of the

2009 Conference on Hot Topics in Cloud Computing,

HotCloud’09, Berkeley, CA, USA. USENIX.

Zhang, F., Chen, J., Chen, H., and Zang, B. (2011). Cloud-

visor: retroﬁtting protection of virtual machines in

multi-tenant cloud with nested virtualization. In Pro-

ceedings of the Twenty-Third ACM Symposium on Op-

erating Systems Principles, pages 203–216. ACM.

PaaSword:AHolisticDataPrivacyandSecuritybyDesignFrameworkforCloudServices

213
