Automatic Generation of Test Data

for XML Schema-based Testing of Web Services

Dessislava Petrova-Antonova

, Kunka Kuncheva

and Sylvia Ilieva

Department of Software Engineering, FMI, Sofia University, Sofia, Bulgaria

Institute of Information and Communication Technologies, BAS, Sofia, Bulgaria

Keywords: Test Data Generation, Test Input Automation, Web Services, WSDL, WS-BPEL, XML Schema.

Abstract: Service-Oriented Architecture (SOA) is a widely accepted paradigm for development of distributed

applications using interoperable and flexible software components. Still the preferred technology for SOA

implementation is provided by the web services. Their interface as well as complex interactions are described

with XML-based standards, such as Web Service Description Language (WSDL) and Business Process

Execution Language for Web Services (WS-BPEL). The WSDL and WS-BPEL documents allow automation

of test data generation through instantiation of the referenced XML Schemas. The approach proposed in this

paper is a step towards such goal. It provides derivation of XML instances from a given XML Schema. The

approach is automated in a software tool supporting data-driven test definition. The tool automatically extracts

an XML Schema form a WSDL or WS-BPEL documents and generates XML messages needed for web

service interactions. Since the proposed approach supports generation of both correct and incorrect XML

instances, the tool is applicable to functional as well as robustness testing of web services.

1 INTRODUCTION

Web services are the preferred way for

implementation of Service-Oriented Architecture

(SOA). They follow a message-enabled design that

can be found on the Web and in the enterprise

software (W3C, 2015). Since the web services are

supposed to be platform independent, they are

described through formally machine readable

interfaces using Web Service Description Language

(WSDL). WSDL interfaces define simple interactions

with web services by using standard protocols. The

web services interaction model is stateless and

supports single request-response or one-way

communication. The full potential of SOA is

achievable when applications are able to integrate

their complex interactions following a standard

business process model. Such model should support

long-running transactions involving two or more

parties. Business Process Execution Language for

Web Services (WS-BPEL) provides definition of

complex business interactions including multiple

units of work, often performed by different web

services.

Both WSDL and WS-BPEL recognize the need of

rich type system to describe the format of messages

exchanged during interactions. Thus they support the

XML Schemas specification as their unified type

system. The XML Schemas that define message

formats can be defined internally within the interface

description of the web services or they can be

imported externally as it is usually happens when web

service orchestrations are defined. The XML-based

syntax of WSDL and WS-BPEL documents allows

fully automated test data generation for message

exchange. It is used for specification of messages for

testing web services’ interactions. These messages

are de facto XML instances that confirm the XML

Shema prescribed in the corresponding WSDL and

WS-BPEL documents. Their generation requires

intensive work due to variability of the XML

structure and differences in the processing of

individual XML elements. Additional efforts are

needed for population of generated XML documents

with data both valid and invalid depending of the type

of testing performed. To the best of our knowledge

the only works that address such issues are (Bai,

Dong, Tsai, & Chen, 2005), (Sneed & Huang, 2007)

and (Bartolini, Bertolino, Marchetti & Polini 2009).

The first work only outlines the possible perspectives

of WSDL-based testing. The second one is focused

on generation of random values for the invocation

parameters but does not support interactions in

277

Petrova-Antonova D., Kuncheva K. and Ilieva S..

Automatic Generation of Test Data for XML Schema-based Testing of Web Services.

DOI: 10.5220/0005500602770284

In Proceedings of the 10th International Conference on Software Engineering and Applications (ICSOFT-EA-2015), pages 277-284

ISBN: 978-989-758-114-4

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

document style. The last work provides automatically

derivation of data instances from WSDL descriptions.

The proposed software tool has some limitations

related to the processing of XML elements and

generation of invalid data needed for negative testing.

In this direction, we propose an approach for

instantiation of XML documents from XML Schema.

The approach leverage the potential of XML Schema

in describing input data in standardized manner. In

addition it is realized as a software tool for automated

generation of test inputs for single web services as

well as web service orchestrations, described with

WS-BPEL. The tool is integrated in a framework,

named Testing as a Service Software Architecture –

TASSA (Pavlov, Borisov, Ilieva & Petrova-

Antonova, 2010). The main goal of TASSA is to

support the testing of web service compositions at

design time.

The paper is structured as follows. In the next

section the current software tools for XML Schema-

based test data generation are analyzed. Section 3

describes an approach for XML Schema-based test

data generation. Section 4 presents a proof-of-concept

of the proposed approach through sample usage

scenarios. Conclusions are drawn in Section 5.

2 RELATED WORK

The goal of the proposed approach is to automate test

data generation while performing testing of WSDL-

based web services and web service orchestrations,

described with WS-BPEL. That is why software tools

that provide similar functionality are investigated and

compared.

XML Editor (Eclipse.org) is an open source Java

plugin for Eclipse that supports a single XML

instance generation from an XML Schema. It

generates the structure of an XML document and

could fill some dummy values, but actually is

designed with presumption that the user will fill them.

XML Spear (Donkeydevelopment.com) is a free

XML editor written in Java that generates an XML

file from an XSD file. It is possible to configure some

properties for the generated structure of the XML, but

the values should be filled manually. XML-XIG is an

open source Java application, presented by Simon

Tuffs (2004) that produces more than one XML

instance form a single schema and automatically

generates values, based on an XIG meta-data file.

CAMed proposed by Sorens (2009) is an XML editor

implemented as an open source Java application that

also produces more than one XML instance from an

XSL Schema. In a template file a variety of

configurations could be done including schema

structure and values specification. WS-TAXI

(Bartolini, Bertolino, Marchetti & Polini, 2009) is a

free Web service, for derivation of XML instances

from XML schema. It implements a category

partitioning for the <choice> elements. The generated

XML instances can be populated with random values

or values loaded from a file. XMLBeans (Apache.org)

is an Apache licensed set of Java classes and console

tools, some of which support XML instantiation from

XML Schema and validation according to that

schema. DataGen tool, presented by Herrmann

(2005) is an open source Java application that

produces test cases in a XML format from an XML

Schema. It provides a lot of functions especially for

negative testing configured in an instruction file. The

XML values could be randomly generated or

predefined. Databene Benerator, described by Frank,

Crescenzio and Chavez is a Java written tool for

generation of XML instances from XSD Schema. It

handles very well the generation of values, but has

some disadvantages on building of the XML

structure. Table 1 shows a comparison of the tools

according to the following characteristics:

1) Extraction of XSD Schema from file – WSDL,

BPEL, etc.;

2) Processing more than one root element;

3) Processing optional elements;

4) Processing optional attributes;

5) Processing choice elements;

6) Processing repeating elements;

7) Validation of XML files;

8) Automatic generation of valid data;

9) Automatic generation of invalid data;

10) Loading data from an external source.

Table 1: Tools for test data generation from XML Schema.

Tool 1) 2) 3) 4) 5) 6) 7) 8) 9) 10)

XML Editor √ √ √ √ √ √

XMLSpear √ √ √ √ √

XML-XIG √ √ √

CAMed √ √ √ √ √ √ √ √ √

WS-TAXI √ √ √ √ √

XMLBeans √ √

DataGen √ √ √ √

Benerator √ √ √ √

As can be seen from the Table 1, the current

software tools work only with *.xsd files and do not

support extraction of XML schema from external

sources, where it is referenced or embedded. Only

two of them, namely CAMed and DataGen, provide

generation of XML instances with incorrect data. In

addition, specific XML schema elements and

attributes are not handled by tools such as WS-TAXI,

ICSOFT-EA2015-10thInternationalConferenceonSoftwareEngineeringandApplications

278

Benerator, XML-XIG and XMLBeans. In order to fill

these gaps, this paper proposes an approach for XML

Schema-based test data generation and corresponding

software tool that are described in the next sections.

3 APPROACH DESCRIPTION

This section presents an approach for generation of

XML documents from a given XML Schema that is

applicable to testing web services. Generally, the

approach consists in sequential processing of the

elements in the XML Schema file regarding their type

and constraints.

Fig. 1 shows the activities covered by the

proposed approach. They are divided in two main

groups:

 Group 1: Activities related to the structure of the

XML document or those that can be performed

before its actual generation;

 Group 2: Activities performed after

successively processing of the XML Schema’s

elements.

The order in which the activities are performed is

essential since some constrains defined by the XML

Schema are related to the structure of the XML

document and others – to the values of the XML

elements themselves.

The activities in Group 1 should be performed in

the following order:

 Derivation of XML Schema from file (WSDL or

WS-BPEL);

 Definition of instances’ number;

 Selection of working mode;

 Extraction of root elements;

 Processing of elements;

 Processing of elements’ attributes;

 Generation of empty XML document.

The activities included in Group 2 are related to

generation of values for all elements of the XML

document derived after performing Group 1

activities:

 Generation of random invalid values;

 Generation of random valid values;

 Manual definition of values;

 Substitution of values from file.

Derivation of XML Schema: Derivation of the XML

Schema from file is useful when the approach is

applied to web services testing. Actually, it can be

used for other purposes, since it is working when an

arbitrary XSD file is provided. If the XML Schema is

referred in the WSDL or BPEL file, it is obtained

from its physical location. In case of WSDL file, the

proposed algorithm searches for schemaLocation

Figure 1: Activity diagram of the approach’s activities.

attribute of the WSDL element import. If the XML

Schema is inline, it uses the WSDL element types in

order to find the definitions for the data types of the

web service messages and generate XSD file for

processing. When a BPEL file is provided, the

algorithm uses the location attribute of the BPEL

element import to obtain the XML Schema.

Definition of instances’ number: The number of

instances that should be generated is important, since

it affects the processing of the attributes defining

occurrences of the elements i.e. the number of times

an element can occur in the parent element.

Selection of working mode: The working mode

determines whether and how the XML instances will

be populated with data. The proposed algorithm

allows generation of empty XML documents – XML

instances which structure follow a given XML

Schema, but does not contain concrete values for the

XML elements. The second and third working modes

allows generation of XML instances automatically

populated with random data – invalid or valid with

respect of XML Schema. Thus, the approach is

Read Input File

Parse Input File

Create XML Schema

file

Load XML Schema

[not XSD file]

[not XML Schema imported]

Parse XSD File

Define Instances

Number 'N'

Read User Input

[User provided data]

Generate XML file

[More root elements]

[XSD file]

[XML Schema imported]

[Random data generation]

Select Working Mode

Read User Input

Select root element

[One root element]

[The number of instances < N]

[All istances are generated]

AutomaticGenerationofTestDataforXMLSchema-basedTestingofWebServices

279

applicable to negative testing when messages with

corrupted data are sent to the web service under test.

The fourth and fifth working modes provide options

for manual specification of values or their loading

from file respectively.

Extraction of root elements: The XML Schema

may include more than one root elements. Their

extraction is essential since further generation of the

XML instance is performed for a particular root

element.

Processing of elements: The elements’

processing is based on their type. The elements of

complex types require additional analysis of their

particles. The further processing depends on whether

model group, model group’s declaration or element’s

declaration is examined. The three model groups

supported by XML Schema are: sequence, choice and

all. For example, in case of choice element, the child

element used in the generated XML instance is

selected randomly.

Processing of elements’ attributes: The

elements’ attributes define their number of

occurrences, default and fixed values. The attribute

minOccurs specifies the minimum occurrence, and

the attribute maxOccurs specifies the maximum

occurrence. The default and fixed attributes define

respectively the default and fixed value for a given

element.

Generation of empty XML document: The

empty XML document follow the structure

prescribed in the XML Schema without concrete data

for the XML elements.

Generation of random invalid values for the

elements: The invalid values of the XML elements

do not confirm the data types defined in the XML

Schema. For example, if date type is required, the

corresponding XML element receives

“FAKE_DATE” value. The numeric values are

represented with strings and the strings are generated

with incorrect length. In case of enumeration, the

XML element get value that does not exist within the

enumeration. In addition, if fixed attribute is defined,

it is neglected.

Generation of random valid values for the

elements: The valid values of the XML elements

confirm the data types and constraints defined in the

XML Schema. If default or fixed attribute is defined,

its value is assigned to the corresponding XML

element. The numeric and string values are generated

in accordance to restrictions, if any. If date type is

required, the current date is used. The XML elements

of Boolean type receive value True.

Manual definition of values for the elements: In

case of manual definition, the user is allowed to enter

a specific value for each XML element. Here,

validation of data types is required.

Substitution of values from file: This working

mode is considered to provide data-driven testing.

4 APPROACH FISIBILITY

This section presents a proof of concept of the

proposed approach. Its feasibility is validated through

implementation of software tool automating activities

presented in Section 3 and subsequent execution of

several usage scenarios.

Table 2: Usage scenarios for approach validation.

Usage

scenario

Description

US1 Input: XSD file with more than one root element

Number of instances: 2

Working mode: Generation of XML file with

valid values

Processing of elements’ attributes: minOccurs

and maxOccurs

US2 Input: XSD file with one root element

Number of instances: 2

Working mode: Generation of XML file with

valid values

Processing of elements: choice element with 7

child element

Processing of elements’ attributes: minOccurs

and maxOccurs

US3 Input: XSD file

Number of instances: 1

Working mode: Generation of XML file with

wrong values

Processing of elements’ attributes: fixed

US4 Input: XSD file

Number of instances: 2

Working mode: Generation of XML file with

valid values

Processing of elements’ attributes: minInclusive

and maxInclusive

US5 Input: WSDL file

Number of instances: 1

Working mode: Generation of empty XML file

US6 Input: WSDL file

Number of instances: 1

Working mode: Generation of empty XML file

and manual data population

US7 Input: WSDL file

Number of instances: 2

Working mode: Generation of XML file with

valid values

US8 Input: BPEL file

Number of instances: 1

Working mode: Generation of empty XML file

and data population from file

ICSOFT-EA2015-10thInternationalConferenceonSoftwareEngineeringandApplications

280

The usage scenarios are described in Table 2 and

generally cover the following cases:

 Taking appropriate input: XSD, WSDL or

BPEL file;

 Derivation of XML schema;

 Support of working modes;

 Processing XML elements and attributes.

The test cases are described in Table 2.

The XSD file passed as input to the tool for

execution of Usage scenario 1 is presented in Fig. 2.

Figure 2: The input file for execution of Usage scenario 1.

Figure 3: The output of execution of Usage scenario 1.

The file presented in Fig. 2 has three root

elements, namely “shipto”, “item” and “shiporder”.

The selected root element is “item”. The output of the

tool is shown in Fig. 3. Each XML instance has

reference to the XML Schema (order.xsd), from

which it is instantiated. Since the element “note” has

minOccurs attribute set to zero, it is missing in the

second XML instance (order2.xml). All elements are

populated with valid data according to the referenced

XML Schema.

The XSD file passed as input to the tool for

execution of Usage scenario 2 is presented in Fig. 4.

Figure 4: The input for execution of Usage scenario 2.

The file, presented in Fig. 4 contains one choice

element, named “address” with 7 child elements,

named “addr1”, “addr2”, etc. The attribute

minOccurs is used for definition of two elements,

named “quantity” and “shipDate”. The output of the

tool is shown in Fig. 5. Each XML instance has

reference to the XML Schema (purchaceForm.xsd),

from which it is instantiated. The two XML instances

(purchaceForm1.xml and purchaceForm2.xml) are

created using different child elements of the

“address” element – “addr2” and “addr1”

respectively. The quantity element appears three

times in the first XML instance and two times in the

second XML instance, since its minOccurs attribute

ORDER.XSD

<xsd:schema xmlns:xsd="..." xmlns:soap="..."

xmlns:tns="..." xmlns:wsdl="..." xmlns:xs="..."

attributeFormDefault="unqualified"

elementFormDefault="unqualified"> ...

<xsd:element name="shipto">

<xsd:complexType><xsd:sequence>

<xsd:element ref="name" /> ...

</xsd:sequence>

</xsd:complexType></xsd:element>

<xsd:element name="item">

<xsd:complexType>

<xsd:sequence>

<xsd:element ref="title" />

<xsd:element minOccurs="0" ref="note" />

<xsd:element ref="quantity" />

<xsd:element ref="price" />

</xsd:sequence>

</xsd:complexType>

</xsd:element>

<xsd:element name="shiporder">

<xsd:complexType><xsd:sequence>

<xsd:element ref="orderperson" /> ...

</xsd:complexType></xsd:element>

</xsd:schema>

ORDER1.XML

<?xml version="1.0" encoding="UTF-8"?>

<title>string</title>

<note>string</note>

</item>

ORDER2.XML

<?xml version="1.0" encoding="UTF-8"?>

<title>string</title>

</item>

PURCHASEFORM.XSD

<xsd:schema xmlns:xsd="...">

<xsd:element name="purchaseForm">

<xsd:complexType><xsd:all>

<xsd:element name="address">

<xsd:complexType><xsd:choice>

<xsd:element name="addr1"

type="xsd:string"/>

...

<xsd:element name="addr7"

type="xsd:string"/>

</xsd:choice></xsd:complexType>

</xsd:element>

<xsd:element name="order" type="POType"/>

</xsd:all></xsd:complexType>

</xsd:element>

<xsd:complexType name="POType">

<xsd:sequence>

<xsd:element name="product"

type="xsd:string"/>

<xsd:element name="quantity"

type="xsd:positiveInteger"

minOccurs="2" maxOccurs="3"/>

<xsd:element name="price"

type="xsd:decimal"/>

AutomaticGenerationofTestDataforXMLSchema-basedTestingofWebServices

281

is set to value of 2 and maxOccurs – to value of 3. All

elements are populated with valid data according to

the referenced XML Schema.

Figure 5: The output of execution of Usage scenario 2.

The XSD file passed as input to the tool for

execution of Usage scenario 3 is presented in Fig. 6.

Figure 6: The input for execution of Usage scenario 3.

Figure 7: The output of execution of Usage scenario 3.

It has only one element, named “color”, which

default attribute is set to value of “red”.

The output of the tool is shown in Fig. 7. The

XML instance is generated with wrong value for the

“color” element.

The XSD file passed as input to the tool for

execution of Usage scenario 4 is presented in Fig. 8.

It has only one element, named “age” that has

restrictions to its values in the range from 0 to 120.

Figure 8: The input for execution of Usage scenario 4.

The output of the tool is shown in Fig. 9. The two

XML instances are generated with different valid

values for the “age” element.

Figure 9: The output of execution of Usage scenario 4.

The input files for the remaining four usage

scenarios are omitted due to the limited space of the

paper as well as their less significance to the obtained

results. For all of them the proposed tool successfully

extracts the corresponding XML Schema. During

execution of Usage scenario 5 and Usage scenario 6

empty XML instances are generated. In addition the

elements of the XML instance obtained from Usage

scenario 6 are correctly populated with values

specified through user input. The two XML instances

produced by the Usage scenario 7 are successfully

filled with random data generated from the tool.

These XML instances are also omitted because of

PURCHASEFORM1.XML

<?xml version="1.0" encoding="UTF-8"?>

<purchaseForm xmlns:xsi="..."

xsi:schemaLocation="purchaseForm.xsd">

<address><addr2>string</addr2></address>

<order>

<product>string</product>

</order>

</purchaseForm>

PURCHASEFORM2.XML

<?xml version="1.0" encoding="UTF-8"?>

<purchaseForm xmlns:xsi="..."

xsi:schemaLocation=" purchaseForm.xsd">

<address><addr1>string</addr1></address>

<order>

<productName>string</productName>

</order>

COLOR_FIXED.XSD

<xsd:schema xmlns:xsd="..." xmlns:soap="..."

xmlns:tns="..." xmlns:wsdl=".../"

attributeFormDefault="unqualified"

elementFormDefault="unqualified"

targetNamespace="http://www.example.org/1/">

<xsd:element name="color"

type="xsd:string" default="red"/>

</xsd:schema>

COLOR_FIXED1_NEGATIVE.XML

<?xml version="1.0" encoding="UTF-8"?>

<color

xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance"

xsi:noNamespaceSchemaLocation="color_fixed.xsd"

COLOR_FIXED.XSD

<xsd:schema xmlns:xsd="..." xmlns:soap="..."

xmlns:tns="..." xmlns:wsdl="..."

attributeFormDefault="unqualified"

elementFormDefault="unqualified"

targetNamespace="...">

<xsd:element name="age">

<xsd:simpleType>

<xsd:restriction base="xsd:integer">

<xsd:minInclusive value="0" />

<xsd:maxInclusive value="120" />

</xsd:restriction>

</xsd:simpleType>

</xsd:element>

AGE_RANGE1.XML

<?xml version="1.0" encoding="UTF-8"?>

<age xmlns:xsi="..."

xsi:noNamespaceSchemaLocation="age_range.xsd">

17</age>

AGE_RANGE2.XML

<?xml version="1.0" encoding="UTF-8"?>

<age xmlns:xsi="..."

xsi:noNamespaceSchemaLocation="age_range.xsd">

102</age>

ICSOFT-EA2015-10thInternationalConferenceonSoftwareEngineeringandApplications

282

their similarity regarding the results already

presented.

The elements of the XML instance generated after

execution of Usage scenario 8 are populated with data

from a text file, which content is presented in Fig. 10.

It has sample values for all XML Schema primitive

data types.

Figure 10: The data file for execution of Usage scenario 8.

The output of the tool is shown in Fig. 11. Since all

elements, except “total”, are defined in the

corresponding XML Schema of type string, they are

Figure 11: The output of execution of Usage scenario 8.

populated with value of “test data” as it is specified

in the param.txt file. In addition the element “total”

is initialized with value of 0.27, which is the value

specified in the param.txt file for the elements of type

double.

The experiments show that the proposed

systematic approach implemented by the software

tool can provide automated correct test data

generation. Covering such wide variability in the

structure and the values of created XML instances

requires considerable efforts in case of manual

preparation.

5 CONCLUSIONS

In this paper an XML Schema-based approach for

derivation of XML instances was presented. The

approach is fully automated in a proof-of-concept tool

that is applicable for test data generation in case of

functional testing of both single and composite web

services. The problem, solved by the approach and

the corresponding software tool has been widely

investigated in the past years. However the current

solutions provide limited support for generation of

test inputs. For example, they do not cover all

possible combinations of the XML Schema elements

or are applicable only for functional testing. In

contrast, our work adopts a systematic sequence of

activities that lead to more precise derivation of XML

instances. In addition, the proposed approach

supports generation of XML instances with wrong

structure or incorrect data and thus can be applied for

robustness testing.

The plan for future work is to apply the proposed

approach in different application domains, such as

benchmark generation, web application testing and

database population. The main task will be to evaluate

the approach in real case studies. The implemented

software tool will be extended with additional

functionality for value generation using regular

expression or function.

ACKNOWLEDGEMENTS

This work is partially supported by the ERDF under

agreement n. BG161РО003-1.1.06.-0003-С0001 and

by the Scientific Research fund of Sofia University

“St. Kliment Ohridski” under agreement n.

143/17.04.2015.

PARAMS.TXT

boolean###CSV###false

byte###CSV###1

date###CSV###Wed Oct 15 16:07:02 EEST 2014

dateTime###CSV###Wed Oct 15 16:07:02 EEST 2014

decimal###CSV###14.00

double###CSV###0.27

float###CSV###0.06

integer###CSV###7

long###CSV###9223372036854775807

negativeInteger###CSV###-3

nonNegativeInteger###CSV###0

nonPositiveInteger###CSV###0

positiveInteger###CSV###3

short###CSV###127

string###CSV###test data

unsignedByte###CSV###1

unsignedInt###CSV###1515

unsignedLong###CSV###99999999999

unsignedShort###CSV###89</xsd:schema>

ORDERINFO.XML

<?xml version="1.0" encoding="UTF-8"?>

<Order_Details

xmlns:xsi="http://www.w3.org/2001/XMLSchema-

instance"

xsi:noNamespaceSchemaLocation="OrderInfo.xsd">

</Order_Details>

AutomaticGenerationofTestDataforXMLSchema-basedTestingofWebServices

283

REFERENCES

W3C, Web of Services, viewed 9 February 2015,

<http://www.w3.org/standards/webofservices/>.

Eclipse.org, Structured text editors for markup languages,

viewed 6 January 2015,

<http://help.eclipse.org/juno/index.jsp?topic=%2Forg.

eclipse.wst.xmleditor.doc.user%2Ftopics%2Ftxedttag.

html>

Donkeydevelopment.com, XML Spear, viewed 6 January

2015, <http://www.donkeydevelopment.com/>

Simon Tuffs P 2004, XML-XIG: XML Instance Generator,

viewed 6 January 2015, <http://xml-

xig.sourceforge.net/>

Sorens M 2009, Taking XML Validation to the Next Level:

Introducing CAM, viewed 6 January 2015,

<http://www.devx.com/xml/Article/41066>.

Bartolini C, Bertolino A, Marchetti E & A.Polini 2009,

WS-TAXI: a WSDL-based testing tool for Web

Services, in Proceedings of the 2nd International

Conference on Software Testing, Verification, and

Validation, Denver, Colorado USA, pp. 326-335.

Apache.org 2012, XMLBeans, viewed 6 January 2015,

<http://xmlbeans.apache.org/>.

Herrmann H 2005, Test Data Generation Tool, viewed 6

January 2015, <http://iwm.uni-koblenz.de/datagen/

manual/DataGen_UserManual.pdf>.

Frank H, Crescenzio D, Chavez E, Databene Benerator,

viewed 6 January 2015, <http://databene.org/databene-

benerator.html>.

Pavlov V., Borisov B., Ilieva S., & Petrova-Antonova D.,

2010, Framework for Testing Service Compositions, in

Proceeding of 12th International Symposium on

Symbolic and Numeric Algorithms for Scientific

Computing, Timisoara, Romania, September 23-26, pp.

557-560.

Bai X., Dong W., Tsai W.-T., & Chen Y., 2005. WSDL

based automatic test case generation for web services

testing. In Proceding of IEEE Int. Work. SOSE,

Washington, USA, IEEE Comp. Soc., pp. 215-220.

Sneed H. M., Huang S., 2007. The design and use of

WSDL-test: a tool for testing web services. Journal of

software Maintenance and Evolution: Research and

Practice, 19:297-314.

ICSOFT-EA2015-10thInternationalConferenceonSoftwareEngineeringandApplications

284
