Service Forwarding Label for Network Function Virtualization and

Application-centric Traffic Steering

Changcheng Huang

and Jiafeng Zhu

Department of Systems and Computer Engineering, Carleyton University, Ottawa, Ontario, Canada

R&D Centre, Huawei Technologies Inc., Santa Clara, U.S.A.

Keywords: Software Defined Network, Network Function Virtualization, Traffic Steering, Service Chaining, VXLAN.

Abstract: New services such as network virtualization, service chaining, and application-centric traffic steering bring

new opportunities for network providers and service providers. Existing Internet architecture is suffering

from the so-called ossification problem, which makes it difficult to support new applications. Software

Defined Network (SDN) is becoming a new paradigm for both WAN and enterprise networks. By

separating control and data planes, SDN allows network providers to sell new services without changing

their physical switches. While SDN is poised to support new services, it is still in development stage.

Mechanisms supporting new services are still missing. In this paper, we propose a new application driven

mechanism called Service Forwarding Label (SFL) which can be used as a uniform label to differentiate

various services and forward packets based on different service requirements. Compared with existing

solutions such as VXLAN, our SFL approach introduces less overhead and supports more new services.

1 INTRODUCTION

Research on Software Defined Network (SDN)

started nearly ten years ago. Most of earlier SDN

networks were designed for datacenter infrastructure

(ONF, 2015, Banikazemi et al., 2013) where

flexibility and scalability are critical. With tens of

thousands commodity switches and servers,

datacenter presents a serious challenge to network

architecture. SDN solves the problem by separating

control plan from data plane. With relatively an

independent control plane, SDN does not need to be

run on proprietary equipment. Instead, the control

plane can be realized with a large number of regular

servers. Through adopting a centralized structure,

these servers can be efficiently facilitated by

datacenter with on-demand service capacity.

In recent years, SDN has found applications in

other areas. Google, for example, built a large scale

SDN-based WAN network (Jain et al., 2013) that

has attracted attentions worldwide. Large carriers are

looking at the possibility of upgrading their network

infrastructures with SDN architecture. Issues such as

scalability have been widely studied. Early

benchmarks on NOX (Tavakkoli et al., 2009) (the

first SDN controller) showed it could only handle

30,000 flow initiations per second while maintaining

a sub-10 ms flow install time. Recent works have

shown that SDN scalability can be extended by

using multicore systems (Tootoonchian et al., 2012)

or deploying multiple OpenFlow controllers (OFCs)

(Tootoonchian and Ganjali, 2010, Yeganeh et al.,

2012).

With a separated control plane, SDN has the

potential to enable new services. One of the primary

new services that have been envisioned is the

network virtualization service, which allows

physical network provider to sell different virtual

networks to different service network providers.

Each service network provider can use its virtual

network just like the way it uses its own private

network while sharing underlying physical network

resources with other service network providers. The

physical network provider, on the other hand, can

enjoy new revenue growth through selling virtual

networks with different granularities.

Service chaining is another area that SDN can

play an important role. Traditionally a service chain

consists of a set of dedicated network service boxes

such as firewall, load balancers, and application

delivery controllers that are concatenated together to

support a specific application (Jacobs, 2015). With a

new service, new devices must be installed and

interconnected in certain order. This can be a very

Huang C. and Zhu J..

Service Forwarding Label for Network Function Virtualization and Application-centric Trafﬁc Steering.

DOI: 10.5220/0005528800270034

In Proceedings of the 6th International Conference on Data Communication Networking (DCNET-2015), pages 27-34

ISBN: 978-989-758-112-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

complex, time-consuming, and error-prone process,

requiring careful planning of topology changes and

network outages and incurring high OPEX. This

situation is exacerbated when a tenant requires

different service sequences for different traffic flows

or when multiple tenants share the same datacenter

network. Through network function virtualization

(NFV) service, SDN can dynamically create a

virtual environment for a specific service chain and

eliminate the complex hardware and labor work.

While possessing great potential, SDN is still in

development stage. The actual mechanisms for

supporting new services are still not defined.

Meanwhile competitive technologies are emerging.

A good example is VXLAN (Mahalingam, 2015),

which is designed with two major objectives: a) to

extend Virtual LAN (VLAN) service from a local

area network to a network that can span an IP

network; b) to address the shortage of VLAN ID. It

advocates the architecture that overlays virtualized

Layer 2 networks over Layer 3 networks. A 24-bit

VXLAN network identifier is added to allow

identifications of more than 16M different VLANs.

While VXLAN can be implemented relatively easily

with existing technologies, it has several major

disadvantages that make it difficult to meet the long

term challenges. First, VXLAN is an extension of

Layer 2 VLAN. Its main objective is to extend

VLAN service rather than to support arbitrary new

services. Therefore, it inherits characteristics of

Layer 2 technologies which make it far away from

application-centric concept. It is hard to generalize

the VLANs supported by VXLAN to other services

such as service chaining. Second, it is hard to

support resource allocation and optimization for

virtual networks due to its distributed nature. Third,

the overhead for overlaying Layer 2 networks over

Layer 3 networks is overwhelming. Fourth, It is hard

to imagine how to support recursive services

(discussed more in the next section) with VXLAN.

OpenADN (Paul et al., 2013) is another option

that has been proposed recently. With OpenADN,

two new labels are added, one at Layer 3.5 and

another at Layer 4.5. The label at Layer 3.5 is used

to forward packets and the label at Layer 4.5 is used

to interconnect two Layer 3.5 labels after passing a

middle-box. Although OpenADN can solve some of

the issues with VXLAN, it is still too complex to

implement. Furthermore, issues such as recursive

services still cannot be supported.

In this paper, we will propose a new Service

Forwarding Label (SFL) mechanism at Layer 5 that

can be used to identify a service instance for packet

forwarding so that NFV and application-centric

traffic steering can be realized with very little

overhead. Our label creation process is application

driven allowing close integration of applications and

forwarding functions. Combining with the power of

SDN controller, SFL can support resource allocation

and optimization on a per service instance basis.

The paper is organized as follows. In Section 2,

we will use NFV as a new service example to

discuss more detail about the issues to be resolved.

In Section 3, we will propose our SFL scheme. This

will be followed by several use case scenarios in

Section 4. We will finish the paper with some

concluding remarks in Section 5.

2 CHARACTERISTICS OF NEW

SERVICES

In this section, we will discuss in detail the

characteristics and challenges of new services under

SDN context. We will use NFV as a key example for

the new services SDN will provide. In specific, we

will investigate the issues related to recursive

network virtualization, which illustrates the

characteristics of recursive services in more general

cases. The reason we choose NFV as an example is

because it can represent a significant portion of new

services currently being envisioned by network

providers and service providers.

The initial SDN adopters, both vendors and

network providers, have focused on some

fundamental issues related to separating control and

data planes. The benefits of creating new services

have not been fully explored. A good example is the

Google SDN WAN project mentioned earlier (Jain

et al., 2013). Before the SDN project, the WAN

Google had been using for interconnecting their

datacenters had been managed using traditional

approach which was slow due to manual

provisioning process. On average, the utilization of

Google’s WAN at that time was 20 to 30%. Through

multiple years of efforts, Google has upgraded its

WAN with SDN technology. The initial results are

very encouraging. Utilization has been increased to

around 70 to 90%. In some cases, 100% utilization

has been achieved. The key enablers of this

improvement are the SDN dynamic flow creation

capability and a more sophisticated optimization

approach based on Max-min fairness. SDN allows

Google to do centralized traffic engineering that can

balance load distribution across their entire WAN

with sophisticated optimization algorithms. Large

amount of elastic traffic also helps increase the

DCNET2015-InternationalConferenceonDataCommunicationNetworking

utilization to 100%.

However, it should be noted that Google’s WAN

is a special case where Google is the user, service

provider, as well as network provider, i.e., Google

provides service to itself on its own network. This

nature allows Google to do global optimization

easily. For example, because Google can control the

traffic carried by the WAN, operators can decide

when and how long the elastic traffic will be

buffered. Also because Google owns both service

network and underlying WAN network, operators

can have a global view of the network and therefore

optimize network usage globally.

In a real world, it is quite common that users,

service providers, and network providers are

separate entities. They may all have their own

objectives which may conflict with each other. Take

the example of enterprise network. With the fast

growth of datacenters, enterprises are becoming

increasingly interested in outsourcing their

enterprise networks to datacenters. Under this

scenario, the owner of the physical network now is

the owner of the datacenter, such as Amazon. The

service network providers are the enterprises who

outsource their enterprise networks to the

datacenters. Therefore a service provider is

independent from the network provider as well as

independent from other service network providers

who share the same physical network. Recognizing

this need, the pioneers of SDN advocate a layer

called FlowVisor (Sherwood et al., 2009) which

plays the same role as the hypervisor for virtual

machines. FlowVisor allows a physical network

provider to partition its physical network into slices

for various service network providers. Each service

network provider can virtually own one slice which

has its own virtual network topology and related

resources generated through a topology abstraction

process. The service network provider can then

optimize its usage of the slice which it owns. A

physical network provider can sell network

virtualization service to service providers with

different granularities selling at different prices

(Drutskoy et al., 2013). This will change the

situation that physical network providers today can

only sell pipes and equip physical network providers

a new venue for revenue growth.

The SDN architecture for virtual network

service is shown in Fig. 1. As shown in the figure,

each entity has its own OpenFlow Controller (OFC).

The OFC of a service provider is in charge of

routing user flows and optimizing resource usage

within its own virtual topology. The OFC of the

network provider will execute the topology

abstraction process through a topology virtualizer

based on a global topology map of the underlying

physical network.

Figure 1: The architecture of virtual network service.

It is envisioned in SDN architecture that a service

provider can further partition its virtual network and

sell virtual network service to other service

providers. This kind of recursive network

virtualization is illustrated in Fig. 2. As shown in the

figure, a network provider sells a virtual network to

a tier-1 service provider which in turn sells virtual

network to a tier-2 service provider. This process

can continue several iterations making service

providers become network providers in a recursive

manner. This kind of recursive services is becoming

popular today. For example, Amazon sells virtual

server service to Netflix and Netflix in turn sells

video streaming service to its clients.

While NFV is a powerful concept, it also faces

several challenges that need to be addressed. These

include overlapping address space, middle-box

traversal, SDN network migration, multiple entities,

etc. We will briefly discuss these problems in the

following paragraphs.

As we mentioned earlier, each service provider

treats its virtual network as its private property. They

decide how to assign VLAN IDs and IP addresses

within their own virtual networks without consulting

each other. Most likely they will use private IP

address blocks to avoid the shortage of address

space. This creates a high possibility of overlapped

address spaces being used by multiple virtual

networks sharing the same physical network. Using

Fig.1 as an example, if the two virtual networks

owned by Tenant A and Tenant B respectively use

the same address space, switches in the physical

ServiceForwardingLabelforNetworkFunctionVirtualizationandApplication-centricTrafficSteering

network will not be able to differentiate packets for

the two virtual networks. Clearly some mechanism

is required to identify packets belonging to different

virtual networks.

Figure 2: Illustration of recursive network virtualization.

In a service chain application, packets need to

traverse multiple middle-boxes before reaching their

destinations. Each middle-box such as firewall or

load balancer provides functions that may require

processing packets up to the transport layer.

Therefore the header information including all layers

up to the transport layer will not be maintained end-

to-end. This will make it difficult for physical

switches to steer traffic to the correct next middle-

box on the path to the destination. This issue

suggests that an end-to-end ID above the transport

layer is required to identify traffic belonging to the

same service chain.

SDN as a new architecture is attracting many

vendors and network providers. Given the size of the

Internet today, the evolution towards SDN networks

will likely be a long and slow process. It is easy to

see that SDN networks will be deployed initially as

islands within Internet. Datacenters, for example, are

the first place where SDN will be adopted early.

When datacenters provide virtual network services

to clients, most of the clients are unlikely to be

attached directly to the datacenters. Therefore,

traffic from these clients has to travel through legacy

IP networks before they can reach SDN based

datacenters. Any techniques used to identify virtual

networks in the lower three layers may be lost when

traffic reaches the datacenters. Inter-datacenter

traffic may also span multiple legacy IP networks

making it difficult to support virtual networks across

multiple datacenters.

Recursive network virtualization raises another

new challenge. As we mentioned earlier, each virtual

network may be owned by a different entity. This

leads to the situation that multiple entities may be

involved in recursive network virtualization. Each

entity has the right to control the resources within its

own virtual network and decide how to route traffic

based on its own policy. Orchestration among

multiple OFCs is calling for simple mechanisms that

help streamline business relationship among

different entities.

In summary, the above mentioned challenges

must be addressed before the benefits of SDN can be

fully realized. In the next section, we will describe in

detail how our SFL works.

3 SERVICE FORWARDING

LABEL

As discussed in the last section, we need an ID that

can be used to identify a service instance (In our

context, a service chain instance is considered as a

single service instance.). This ID needs to sit above

Layer 4 so that it can stay intact while a packet

traverses legacy IP networks and middle-boxes. This

naturally points to an ID at Layer 5.

In OSI model, Layer 5 is called the session layer

which is designed to establish, manage, and

terminate connections between local and remote

applications. A good example is a video conference

session where multiple parties join and leave

dynamically. This bears similarity to a service

instance such as a virtual network which carries a

large number of dynamic traffic flows. This

similarity motivates us to define an ID at Layer 5 for

the identification of a service instance (or service

chain instance). We call this ID Service Forwarding

Label (SFL).

SFLs will be created and maintained by a service

provider and used by its clients and OpenFlow

switches to identify and steer traffic belonging to

different service instances. SFLs can be stacked for

applications such as recursive services where each

level of the stack is administered by the owner of the

service level in a recursive business relationship as

discussed in the last section. This allows easy scale

to multiple levels of services with multiple

ownerships nested in the SFL stack.

A SFL must be unique within the space of the

service provider who administers the SFL. Multiple

service providers at the same level will be

differentiated by their SFLs at the lower level. The

DCNET2015-InternationalConferenceonDataCommunicationNetworking

combination of the SFLs across different levels in a

label stack uniquely identifies a service at any layer

in a physical substrate domain.

In the following paragraphs, we will discuss SFL

format and the process to establish and terminate a

SFL.

As shown in Fig.3, each SFL is represented by 4

octets. Starting from bit 0 of the 4 octets, the first 30

bits hold the label, bit 30 is reserved for

experimental use, bit 31 is the top-of-stack bit (S).

The S bit is set to one for the last entry in a label

stack, and zero for all other label entries in the stack.

As the header at Layer 5, SFL can run either over

UDP or TCP making it applicable to all kinds of

traffic belonging to the same service instance.

Figure 3: (a) Format of Service Forwarding Label; (b)

Illustration of SFL stack in a packet header.

Each SFL is associated with a lifetime. When the

lifetime expires, the SFL will be terminated or be

renewed. This dynamic mechanism allows a service

provider to maintain a smaller pool of SFLs.

There are various scenarios that may happen

during the lifetime of a SFL. The procedures for

establishing and terminating SFL depend on the

actual scenario encountered. A typical scenario is

shown in Fig. 4. We describe the procedures step by

step in the following part.

 A client sends a service request to the OFC

of a service provider with its user ID and

requested service type using HTTP request

message. Metadata can be sent through

HTTP Post message;

 The OFC of the service provider decides

whether it can accept the request by

applying optimization process which

determines how to route traffic and allocate

resources for the requested service;

 If the request is admissible, the OFC will

create a new SFL which is unique to the

service provider and send the SFL and

associated lifetime to relevant OpenFlow

switches or middle-boxes that need to steer

or process traffic based on the SFL through

an OpenFlow OFPT_FLOW_MOD

message;

 Upon receiving the message from the OFC,

the OpenFlow switches or middle-boxes

will set the SFL and its lifetime into their

flow tables as part of a rule set;

 The OFC will send HTTP response message

with the SFL and associated lifetime to the

client confirming the acceptance of the

request;

 The client will add the label as Layer 5

header to its packets destined for the

requested service and send them out;

 When the packets reach the switches or

middle-boxes within the service provider

network, the service provider will match the

Layer 5 header (and other headers in other

layers if necessary) to its rule set and decide

how to forward or process the packets based

on their service requirement;

 The switches or middle-boxes will then

process those packets and steer them to the

next switch or middle-box if necessary;

 When the lifetime of the SFL expires, the

client can choose either to renew the service

or leave. If it decides to renew, it will send a

 HTTP request message with the SFL to the

OFC, the above procedures will be repeated

except that the original SFL will be used

instead of generating a new SFL.

In the next section, we will discuss some use

cases that will help illustrate how the SFL can be

used in real applications.

Figure 4: Flowchart of labelling process.

4 SAMPLE USE CASES

There are numerous use cases that the proposed SFL

ServiceForwardingLabelforNetworkFunctionVirtualizationandApplication-centricTrafficSteering

can be applied to. We will discuss some common

use cases briefly in this section.

The first use case is the virtual network service

we mentioned earlier. Here a physical network

provider will serve as the service provider and

service network providers will serve as clients.

Service network providers request virtual networks

from the physical network provider. Each service

network provider will have full control over its

virtual network. One issue we mentioned earlier is

that the address space used by service providers can

be overlapped. An example is shown in Fig. 5 where

Client Network 1 owns Virtual Network 1 and

Client Network 2 owns Virtual Network 2. Both

Virtual Network 1 and Virtual Network 2 share a

physical network owned by a SDN network

provider. When a packet reaches a switch in the

SDN network, the switch needs to decide which

virtual network the packet belongs to.

Figure 5: Virtual networks with overlapped address space.

Through the procedures discussed in the last section,

each client network will receive an SFL assigned by

the SDN network as an identifier of its virtual

network. The client network will inform its users of

adding the SFL for all packets that need to use the

virtual network it owns. When packets reach the

switches in the SDN network, they can be

differentiated using SFL even though their IP

address spaces may be overlapped. This can be done

by a simple match in the flow table. Without SFL,

multiple header fields may need to be matched in

order to identify packets belong to a virtual network,

which will likely cause flow table fragmented and

bloated.

When recursive network virtualization is

deployed, each service network will serve as client

as well as service provider at the same time. As a

client, it receives a SFL from the service provider

one level below it. As the service provider, it

administers the SFLs that identify the virtual

networks it sells. A physical switch can use multiple

levels of the label stack to steer packets for the

correct virtual networks they belong to.

Now we look at the second use case that

demonstrates how service chain can be supported. It

is easy to see that a service chain instance can be

realized using NFV where each virtual node

represents a specific service such as firewall that can

be dynamically mapped to a physical node in the

lower level. By the virtualization of a service chain,

dynamic sharing of physical resources can be

achieved. Traffic flows for different service chain

instances can be uniquely identified and steered by

the combinations of the multiple SFLs in their label

stacks. This enables great flexibility and leads to

significant cost reduction in OPEX. An example is

illustrated in Fig.6.

Figure 6: Service chain as network function virtualization.

Application service providers such as Google are

increasingly interested in providing different

treatments to different types of customers, e.g.

subscribers vs. casual users. Based on the SFLs they

are carrying, user traffic flows can be steered to

different environments with different networking

and computing resources provisioned. Under this

context, SFL provides a simple and effective handle

that connects applications to physical layer devices

directly and enables application-centric traffic

steering. There are many existing Quality of Service

(QoS) schemes such as VLAN and DiffServ. But

they are Layer 2 or 3 mechanisms which are hard to

scale to end-to-end applications. As mentioned

earlier, it is difficult to maintain any code points in

headers up to Layer 4 for end-to-end services due to

middle boxes and different domains a packet may

traverse. By sitting at Layer 5, our SFL can travel

through networks and middle boxes easily and

therefore provide a very strong support for various

end-to-end applications.

There are many application scenarios that can

demonstrate the usage of SFL. For example, a

DCNET2015-InternationalConferenceonDataCommunicationNetworking

service provider may want some of its user traffic be

protected from server or link failures while other

traffic not. When a server or link failure happens, the

traffic that needs protection is steered to a protection

path. In OpenFlow switches, packets that require

protection will be matched at a group table instead

of the regular flow table. Therefore incoming

packets must be de-multiplexed into regular flow

table or group table based on whether they need

protection or not. The proposed SFL provides an

excellent option to achieve this function.

Specifically, we can assign one SFL to identify

traffic requiring protection and another SFL for

traffic not requiring protection. As shown in Fig.7,

when packets arrive at a switch, it first goes to a

regular flow table. If the SFL matching indicates a

packet without protection requirement, other header

fields will be matched as regular case; otherwise, the

packets will be forwarded to a group table for

protection matching.

Figure 8: Forwarding packets with and without protection.

Figure 9: Virtual network service with SDN network as an

island.

For the case that SDN networks form some islands

in an end-to-end network, the proposed SFL also

provides an elegant migration solution. An example

is shown in Fig. 8 where the traffic from a client

network needs to traverse a legacy IP network to

utilize the virtual network service provided by a

SDN network. Because SFL sits at Layer 5, it will

not be affected by the legacy network. Packets

carrying SFL will travel through the legacy network

just like a regular packet. This allows the SDN

network island to provide new services even when it

is surrounded by legacy networks.

5 CONCLUSIONS

By separating control plane from data plane and

centralizing resource allocation, SDN has the

potential to allow network and service providers to

create a variety of new services. Existing SDN

products have been focused on some basic functions

such as flow setup and teardown. The potential to

create new services has not been fully explored.

NFV is one of the most promising services SDN

can provide. Through NFV process, a network

provider can sell virtual slices of its physical

network to different service providers. Different

service providers as tenants have full control of the

virtual topologies within their own slices while the

network provider has the control of its physical

network. However lack of an effective virtual

network identifier makes the potential of SDN

difficult to realize.

Application-centric traffic steering is another

type of services SDN can provide. Application

service providers have been looking for ways to

differentiate user traffic flows so that resources can

be used more effectively on generating revenues for

them. An end-to-end identifier that can be utilized to

differentiate user traffic flows is required so that

user traffic flows can be steered to the right server

and network resources for maximizing the benefits

of the service providers.

In this paper, we proposed SFL as an identifier

for service instance. It is controlled by service

providers and used by clients and OpenFlow

switches to steer traffic to different services. The

format of SFL is simple enough to minimize

overhead. Through SFL stacking, recursive services

such as recursive network virtualization can be

supported easily while allowing different entities to

exercise their controls over their own resources.

With SFL as a Layer 5 mechanism, it can traverse

middle-boxes and legacy networks without any

changes so that the relationship between clients and

service providers can be maintained end-to-end.

We have demonstrated various use cases ranging

from NFV, service chaining, to application-centric

traffic steering. Through these use cases, we can see

that the proposed mechanism is simple to implement

with existing protocols and technologies and can

effectively enable various new services.

ServiceForwardingLabelforNetworkFunctionVirtualizationandApplication-centricTrafficSteering

REFERENCES

ONF, 2015. https://www.opennetworking.org/

Banikazemi, et al., 2013. Meridian: An SDN Platform for

Cloud Network Services, IEEE Communications

Magazine, Feb. 2013.

Jain, S., et al., 2013. B4: Experience with a Globally-

Deployed Software Defined WAN, ACM SIGCOMM

2013, August 12-16, 2013, Hong Kong.

Tavakkoli, A., et al., 2009. Applying NOX to the

Datacenter, ACM Workshop on Hot Topics in

Networks (HotNets-VIII), October 22-23, 2009, New

York.

Tootoonchian, A., et al., 2012. On Controller Performance

in Software-Defined Networks, 2

USENIX Hot-

ICE’12, April 24, 2012, San Jose.

Tootoonchian, A. and Ganjali, Y., 2010. Hyperflow: A

Distributed Control Plane for OpenFlow, USENIX

NSDI INM/WREN, April 2010, San Jose.

Yeganeh, S. Hassas and Ganjali, Y., 2012. Kandoo: A

Framework for Efficient and Scalable Offloading of

Control Applications, ACM SIGCOMM HotSDN’12,

August 13, 2012, Helsinki.

Jacobs, D., 2015. How SDN and NFV simplify network

service chain provisioning, http://

searchsdn.techtarget.com/tip/How-SDN-and-NFV-

simplify-network-service-chain-provisioning.

Mahalingam, M., et al., 2015. “VXLAN: A Framework for

Overlaying Virtulized Layer 2 Networks over Layer 3

Networks,” IETF draft, http://datatracker.ietf.org/

doc/draft-mahalingam-dutt-dcops-vxlan/.

Paul, S., et al., 2013. OpenADN: A Case for Open

Application Deliver Network,” Proceedings of ICCCN

2013, July 2013.

Sherwood, R., et al., 2009. FlowVisor: A Network

Virtualization Layer, OPENFLOW-TR-2009-1,

OpenFlow Consortium, October 2009.

Drutskoy, D., et al., 2013. Scalable Network Virtualization

in Software Defined Networks, IEEE Internet

Computing, Vol. 17, Iss. 2, March, 2013.

DCNET2015-InternationalConferenceonDataCommunicationNetworking
