Using Multiple Runs in the Simulation of Stochastic Systems for

Estimating Equilibrium Expectations

Winfried Grassmann

Department of Computer Science, University of Saskatchewan, Saskatoon, SK S7N 5C9, Canada

Keywords:

Steady-state Simulation, Multiple Runs, Initialization Bias.

Abstract:

In complex stochastic systems, Monte-Carlo simulation is often the only way to estimate equilibrium expec-

tations. The question then arises what is better: a single run of length T, or n runs, each of length T/n. In this

paper, it is argued that if there is a good state to start the simulation in, multiple runs may be advantageous.

To illustrate this, we use numerical examples. These examples are obtained by using deterministic methods,

that is, methods based on probability theory not using Monte-Carlo methods. The results of our numerical

calculations forced us to make a sharp distinction between the time to reach equilibrium and the appropriate

length of the warm-up period, and this distinguishes our study from earlier investigations.

1 INTRODUCTION

Monte Carlo methods are often the only way to es-

timate equilibrium expectations in complex stochas-

tic systems, such as queueing networks. The ques-

tion then arises whether a single long run is preferable

to several shorter runs. Hence, instead of doing one

run of length T, should we do n runs, each of length

T/n? This is a question that has been addressed by

several authors, including (Whitt, 1991), (Alexopou-

los and Goldman, 2004) and (Kelton, 1989). In con-

trast to these studies, we make a sharp distinction be-

tween the time to reach equilibrium within a given

tolerance, and the appropriate length of the warm-up

period. Here, the warm-up period is a period during

which the data obtained by the simulation is ignored.

We were forced to do this because in our numerical

experiments, the time to reach the equilibrium within

±10% was clearly much longer than the warm-up pe-

riod that minimizes the mean squared error of the esti-

mate as shown in (Grassmann, 2011). The problem of

multiple runs is also related to the initialization bias

problem, for details see (Pasupathy and Schmeiser,

2010), (Pawlikowski, 1990) and (Grassmann, 2014),

and references therein.

Our investigation was motivated by a paper by

Madansky (Madansky, 1976), who showed that when

estimating the expected number of elements in an

M/M/1 queue, the best starting state, judging by the

mean squared error (MSE), is the empty state as long

as T is not too short, a result conﬁrmed by (Wilson

and Prisker, 1978) and (Grassmann, 2008). More-

over, in (Grassmann, 2008) it was shown that if start-

ing the M/M/1 queue empty, any warm-up period in-

creases the MSE, that is, the optimal warm-up period

is 0. However, when starting at 0, the expected queue

length is far from its equilibrium value, that is, the

time to reach equilibrium at a tolerance of ± 10%

is far from 0. This observation forces us to make

a sharp distinction between the time to reach equi-

librium within a given tolerance and the appropriate

length of a warm-up period, a distinction that is some-

what hazy in literature. As it turns out, the distinction

between the time to reach equilibrium and the optimal

length of the warm-up period forces us to re-evaluate

the issue of multiple runs.

People may argue that the M/M/1 queue is spe-

cial, and results derived from its study are invalid.

This opinion leads to the philosophical issue as to

how many counter-examples one needs in order to re-

fute strongly held beliefs. Even though in mathemat-

ics, a single counter-example is sufﬁcient, we believe

more than one example is needed. However, (Grass-

mann, 2014) provides additional cases where it is cru-

cial to distinguish between the time to reach equilib-

rium within a giventolerance and the warm-up period.

Moreover, I feel that before making any conclusions

about the generality of an observation, we have to un-

derstand the reasons why the time to reach equilib-

rium within a given tolerance is not necessarily a good

indicator for the length of the warm-up period. For-

tunately, relevant reasons are given in (Grassmann,

138

Grassmann W..

Using Multiple Runs in the Simulation of Stochastic Systems for Estimating Equilibrium Expectations.

DOI: 10.5220/0005535501380144

In Proceedings of the 5th International Conference on Simulation and Modeling Methodologies, Technologies and Applications (SIMULTECH-2015),

pages 138-144

ISBN: 978-989-758-120-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

2014), a paper that provides a good understanding of

the main issues, and without such an understanding,

the question as to what models are exceptions, and

why, cannot be addressed in any scientiﬁc way.

The setup we use is like the one of (Whitt, 1991):

The system is described by d state variables X

(t),

(t), ..., X

(t), and we deﬁne X(t) = [X

(t),k =

1,2,...,d]. We are interested in the process R(t) =

f(X(t)), and the problem is to ﬁnd the expectation

lim

t→∞

E(R(t) = E(R). If d = 1, we use X(t) instead

of [X

(t)]. We assume that the process is ergodic, in

which case E(R) exists and it is unique. R(t) could

be, for instance, the number of jobs in a queueing net-

work with 3 queues. In this case f(X(t)) becomes

f([X

(t),X

(t)]] = X

(t) + X

(t).

We assume that we know f(.). The question is how

many runs should be made to ﬁnd the estimate for

E(R) with the lowest possible MSE. We assume that

the runs are of equal length, and that the total time

for all runs is T. Hence, if there are n runs, each run

has a length of T/n. We use time averages to estimate

E(R), that is:

(T/n) =

T/n

R(t)dt (1)

and we take the overall average

R(T) =

∑

ν=1

(T/n). (2)

If there is only 1 run, we use

R(T) instead of

R(T).

All runs start in the same state, which implies that all

(T/n) have the same distribution. We will there-

fore sometimes omit the subscript. The common ex-

pectation will be denoted by E(

R(T/n)), and the com-

mon variance by Var(

R(T/n)). Equation (1) assumes

continuous sampling, but similar formulas can easily

derived if sampling is only done at certain epochs, or

if the data sampled is discrete, as is the case when

considering successive waiting times. Also note that

for reasons discussed later, we use no warm-up pe-

riod. If a warm-up period of length w is used, then the

lower bound of the integral of (1) must be replaced by

w, and

T−w

. To judge the quality of

R(T), we

use the mean squared error, that is

MSE(

R(T)) = E((

R(T) − E(R))

)

= Var(

R(T)) + Bias

(

R(T)) (3)

where

Bias(

R(T)) = E(

R(T)) − E(R). (4)

When we use the term MSE, we always refer to

MSE(

R(T)) or, if there is only one run, MSE(

R(T)).

Our attention is restricted to point estimations, as

opposed to interval estimations and conﬁdence inter-

vals (Alexopoulos and Goldman, 2004). Of course,

multiple runs have the additional beneﬁt to provide

some idea about the reliability of an estimate.

The models we use are rather simple, such as the

M/M/1 queue or a simple tandem queue. However,

from such simple models, insights can be gained that

allow us to form, and potentially prove, interesting

conjectures when analyzing more complex models. It

would be much more difﬁcult to gain these insights

by looking at complex systems. For simple models,

there are very effective methods to ﬁnd expectations

and variances of time averages (Grassmann, 1987),

methods that are deterministic in the sense that they

do not use Monte Carlo techniques, but probability

theory. Incidentally, ﬁnding variances by simulation

with acceptable precision requires a large number of

observations, and this leads to long execution time,

making these method non-competitive for small mod-

els. However, since deterministic methods increase

exponentially with the dimensionality of the model,

simulation is often the only way to analyze models

with many state variables.

2 WHY MULTIPLE RUNS CAN

DECREASE THE MSE

Though it may sound contradictory, warm-up peri-

ods can increase the MSE. As it turns out, these are

exactly the cases were multiple runs can be advan-

tageous. In (Grassmann, 2014), a number of rea-

sons have been given why warm-up periods can in-

crease the MSE when initializing the system in cer-

tain states. We list these reason here to make the paper

self-contained.

1. Consider the case where sampling is not done

continuously, but only at time 0, τ, 2τ, 3τ, ...,

mτ = T. If τ is large enough, then the read-

ings at these sample points are almost indepen-

dent random variables. Now, if the state at time

0 is close to E(R), then it would make sense to

include it in the time average, that is, instead of

R(T) =

∑

ν=1

R(ντ), one uses

m+1

∑

ν=0

R(ντ).

In fact, this would amount to a weighted average

with a weight of

m+1

for R(0) and a weight of

m+1

for

R(T), which makes sense, provided R(0)

is a reasonable estimate for E(R).

2. In many cases, E(R(t)) is subject to a drift, that is,

E(R(t)) changes in a predictable fashion. In this

case, starting in a state with R(0) close to E(R)

may not be a good starting state. Consider, for in-

UsingMultipleRunsintheSimulationofStochasticSystemsforEstimatingEquilibriumExpectations

139

stance, an M/M/1 queue with arrival rate λ and

service rate µ, with λ < µ. If the system starts

in a ﬁxed non-empty state, then in a small inter-

val of length h, the expected number of arrivals is

λh+ o(h), and the expected number of departures

is µh+o(h), which means that the expected queue

length decreases at a rate λ− µ, a rate that is nega-

tive. Similar effects were observed by (Kelton and

Law, 1985), using numerical experiments. Hence,

before the M/M/1 queue reaches the empty state,

the expectation will always decrease, precluding

thus to be in an equilibrium. In other words, no

reasonable equilibrium estimate can be obtained

before reaching 0. This may explain the ﬁndings

of Mandansky (Madansky, 1976) that the smallest

MSE for the expected number of elements in an

M/M/1 queue is obtained when starting the sys-

tem empty, provided the simulation is of a reason-

able length.

3. Most textbooks (Tocher, 1963), (Banks et al.,

2005), (Law and Kelton, 2000) suggest to start the

system in a typical state. This allows for different

interpretations: One could call a state typical if it

has a high equilibrium probability, or if it is fre-

quently visited while the process is stationary. If

the system starts in such a typical state, warm-up

periods may be detrimental.

Choosing an initial state according items 1 to 3 is only

possible if some prior information about the system

is known. However, if prior information is known,

its weight can be increased by doing multiple runs.

Moreover, the better the information, the more runs

should be done.

To ﬁnd the states where a warm-up period can

reduce the MSE, consider the integral given by (1),

with the lower bound replaced by w, and with

changed accordingly. Suppose there is only 1 run.

Let

R(T, w) be the resulting expression. We now

form the derivatives of Bias(

R(T,w)), Var(

R(T,w))

and MSE(

R(T,w)) with respect to w for w = 0 to get

according to (Grassmann, 2014):

Bias

′

(

R(w,T))

w=0

= E

′

(

R(w,T))

w=0

(E(

R(T)) − f(a)) (5)

Var

′

(

R(w,T))

w=0

Var(

R(T)) (6)

MSE

′

(

R(w,T))

w=0

(Var

R(T) +

Bias(

R(T))(E(

R(t)) − f (a))).(7)

Here, f(a) = f(X(0)) = R(0) as deﬁned in the in-

troduction. If the derivative of the MSE is negative,

any warm-up period decreases the MSE, that is, a

warm-up period is beneﬁcial. On the other hand, if

the derivative of the MSE is positive, a warm-up pe-

riod of zero is a local minimum, and it is reasonable to

expect that this minimum is also global. In this case,

any warm-up period is detrimental.

States with a positive derivative are obviously

good states to start a simulation in, and the beneﬁts of

starting in these states could potentially be increased

by doing multiple runs. In fact, we observed that for

most cases with positive derivatives with respect to w,

multiple runs proved to be beneﬁcial. Surprisingly,

we even found some cases with a negative derivative

for the MSE where multiple runs are optimal.

Next, we investigate as to what happens if T in-

creases by a factor of k. Consider ﬁrst the case where

there is only one run. If T is large enough, then ac-

cording to (Asmussen and Glynn, 2007), Var(

R(T))

and Bias(

R(T)) both decrease by a factor of k as T

increases by a factor of k. This relation was orig-

inally suggested in (Grassmann, 1982), and (Grass-

mann, 2008) shows numerically that convergence to

the limiting form can be quite fast. Because of (3),

this implies that in the limit, the contribution of the

bias decreases by k

, whereas the variance decreases

by k. Hence, as T increases, and T is large enough,

the contribution of the bias diminishes.

If there are multiple runs, then we conclude from

equations (2) and (1):

MSE(

R(T)) =

Var(

R(T)) + Bias

(

R(T)). (8)

It follows that compared to a single run, the impor-

tance of the bias increases.

If n, the number of runs, is too large, T/n is very

small, and

R(T) is essentially an average of the initial

conditions, making the contribution of the simulation

almost meaningless. This follows from (8), which im-

plies that the relative importance of the variance de-

creases with n, approaching 0 as n → ∞. This means

that as n increases, starting states close to E(R) be-

come increasingly competitive. If R(0) is very close

to E(R), then it is optimal to make a large number of

very short runs. For very short runs, E(

R(T)) ≈ R(0),

meaning that we essentially take the average of the

initial conditions, practically ignoring the results of

the simulation. The simulation runs are then almost

useless. In order to avoid such meaningless results,

we have to require that the run length T/n is long

enough such that the simulation can make a reason-

able contribution.

SIMULTECH2015-5thInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

140

3 DRIFT AND FLOW MODELS

In this section, we discuss the drift in the context of

ﬂow models (Newell, 1982). These models allow us

to ﬁnd good initial states. Flow models are also help-

ful for deciding when the number of runs is so large,

and the individual runs are so short as to make the

simulation meaningless.

Note that every state i = [i

,. .. ,i

] is associ-

ated with a drift for each state variable X

(t). The

drift is the derivative of E(X

(t)) with respect to t,

given X

(t) = s

, k = 1,2,. .., d. In a typical system,

almost all states have a non-zero drift, that is, when-

ever one knows the state, there tends to be a drift of at

least some state variables. Stochastic system in equi-

librium have no drift because they can be in many

different states, but we have no knowledge in which

state they actually are. Of the potential states the sys-

tem could be in, state variables of some states have an

up-drift, which is compensated by other states where

these variables have a down-drift. This compensation

vanishes if we know the state we are in.

If all states visited from 0 to t either have all an up-

drift for some relevant state variable, or they all have a

down-drift for this variable, a simulation run extend-

ing only from 0 to t cannot be expected to provide

a meaningful estimate of the equilibrium expectation.

The minimum time for a simulation is therefore the

time until all relevant state variables have changed the

sign of the drift at least once. Hence, we must visit a

pair of states (i, j) at least once where the sign of the

drift changes for a particular state variable when go-

ing from i to j. Theoretically, such pairs would have

to be found for every state variable, but for reasons to

be discussed, there are often pairs of states where all

state variables either change the sign of the drift, or

where the drift goes at least to zero when going from

one state of the pair to the other. To ﬁnd such pairs

of states, we use a ﬂow analysis (Newell, 1982), with

the ﬂows being equated to the drifts.

To make the conversion of our stochastic model

to the ﬂow approximation, we have to make all state

variables continuous. Typically, we have simple for-

mulas for the drift, and though these formulas possi-

bly apply only to integers, in a ﬂow model, we dis-

regard this restriction. For instance, in the M/M/c

queue with arrival rate λ and service rate µ, the

drift when i elements are in the system is λ − iµ for

0 < i ≤ c, and this remains the formula for the ﬂow

model, except that i is now continuous.

A ﬂow model is in a state of equilibrium if no

state variable changes as the time t increases. In other

words, the drifts of all state variables in the ﬂow ap-

proximation are zero. Let s = [s

,. .. ,s

] be this

equilibrium state. If the equilibrium state s is stable,

and we assume that this is the case for now, then from

any state close to s there is a drift towards s. For

instance, in the ﬂow approximation of the M/M/c

queue, the equilibrium state is s = λ/µ, because for

the M/M/c queue, we have a drift λ − iµ, which is

zero for i = λ/µ.

If there are two states, i = [i

,, ...,i

] and j =

[ j

, j

,. .. , j

], with i

> s

and j

< s

for some k,

then being attracted to s, i must have a down-drift, and

j an up-drift. Similar results would have to be true for

all k. If the model is stochastic, then it may be possi-

ble to go from i to j, and if the path goes through s,

the sign of the drift changes for all state variables, or

at least it falls to 0. In a stochastic system, the path

may not exactly move through s, but we still can use

this result as a heuristic. If a state variable is integer,

we have to round it either up or down when convert-

ing the equilibrium state in the ﬂow approximation to

a state in the stochastic model. If i and j are two states

obtained from s through rounding, and if one can go

in one step from i to j, then the drift typically changes

the sign for most state variables when going from i to

j. In the M/M/c model, for instance, the ﬂow equilib-

rium is r = λ/µ. If r is not integer, it is easily veriﬁed

that the sign of the drift changes if one goes from ⌊r⌋

(r rounded down) to ⌈r⌉ (r rounded up), or from ⌈r⌉

to ⌊r⌋. If all state variables of s that are supposed to

be integer are integer already, we only have one state

rather than a pair of states. To get a pair in this case,

we change one state variable by 1. This only makes

the drift change to zero when moving from the modi-

ﬁed state to s, but a sign change is very likely to occur

soon. For instance, if r in the M/M/c queue is in-

teger, ⌊r⌋ = ⌈r⌉. In this case, we have to extend the

simulation to a time long enough to move beyond this

no-drift state.

In some ﬂow models, there is no state with a ﬂow

of zero, and in this case, there is either no equilibrium,

and consequently no meaningfulequilibrium expecta-

tion E(R) to estimate, or the state variables hit some

boundary. For instance, in the M/M/1 queue, the drift

for all non-zero states is λ − µ, and if λ < µ, the ﬂow

model hits a boundary at zero. It is easily veriﬁed that

when hitting the boundary in an M/M/1 queue, or

even in an open network of M/M/1 queues, the sign

of the drift changes at the boundary points. The same

can be expected for most other systems when they hit

a boundary.

In summary, the minimum length of the simula-

tion should be such that we either go beyond a sign

change of the drift of all relevant state variables, or at

least a state where the drift is zero. Hence, we have

to ﬁnd pairs (i, j) where the drift of all relevant state

UsingMultipleRunsintheSimulationofStochasticSystemsforEstimatingEquilibriumExpectations

141

variables changes as we go from i to j, or where the

drift of all state variables goes to zero. Before j is

reached, the drift is always in the same direction, and

the results of the simulation are close to meaningless.

Drift-change pairs (i, j) can be unstable, that is,

though the drift changes sign when going from i to

j, the drift can move us away from j. For example,

consider a birth-death process with a maximum pop-

ulation of N, and with birth rate λ

, 0 ≤ i < N and

death rate µ

, 0 < i ≤ N, where i is the size of the pop-

ulation. If there is a value k such that λ

− µ

> 0 for

k ≤ i < N and λ

− µ

< 0 for 0 < i < k, then there is

a drift toward N if i ≥ k, and toward 0 otherwise. In

situations where such unstable drift-change pairs are

possible, multiple runs are suggested, starting with

a drift-change pair, with each run closely monitored.

However, we will not consider this case further.

Stable drift-change pairs will be called pairs of at-

traction, or, if there is only one point states of attrac-

tion. For many models, starting a simulation with a

member of a pair of attraction can be recommended

because one can expect that a sign change in the drift

will occur in the near future, giving the simulation

some validity. Often, such starting states are also

states close to the state with the highest probability

or the highest frequency. For instance, in the M/M/1

queue, the pair of attraction is (0,1), with 0 being the

state with the highest probability, and 1 the state with

the highest frequency.

Since it is usually easy to formulate ﬂow mod-

els and ﬁnd pairs of attraction, starting states from

such pairs can be recommended. The fact that they

are often close to the maximal equilibrium probabil-

ity is a further advantage. The state variables of pairs

of attraction normally have values that lie below their

expected values. Consequently, choosing states with

the state variable having slightly higher values than

the ones in pairs of attraction may be advantageous in

some cases, especially if multiple runs are planed.

4 EXAMPLES

In this section, we present a number of examples to

highlight the different issues discussed earlier. In our

tables and discussions, the derivative of MSE is al-

ways multiplied by T because otherwise, it is very

small number,and representing small numbers in dec-

imal form requires a lot of space.

First, we show, using the M/M/1 queue with

X(t) = R(t) representing the number of elements in

the system as an example, that multiple runs can re-

duce MSE(

R(T)). The arrival rate is λ = 0.8 and

the service rate is µ = 1. Since the pair of attrac-

tion is (0, 1), we start with X(0) = 0, and we use

T = 1000. Since our programs cannot handle inﬁnite-

state queues, we restrict the number in the system to

50. For this problem, TMSE

′

(

R(T)) = 2.340, indi-

cating that the MSE is increasing when introducing a

warm-up period. As one can see from Table 1, the

MSE is smallest when 6 runs are made.

Table 1: MSE for M/M/1 queue, number of runs varying

from 1 to 8, λ = 0.8, µ = 1, T = 1000, X(0) = 0.

Runs 1 2 3 4

MSE 1.5691 1.3748 1.2154 1.1045

Runs 5 6 7 8

MSE 1.0412 1.0178 1.0259 1.0583

In the case of the M/M/1/N queue, one may also

be interested how the buffer size N and ρ = λ/µ af-

fect the optimal number of runs. Hence, in Table 2,

we do the calculation for a buffer size of N = 10 and

N = 50, and for ρ = 0.8 and 0.9. Table 2 shows in

column “Opt. runs” that more runs are optimal if the

buffer size has the higher value, and that fewer runs

are optimal if ρ has the higher value.

Table 2: Optimal number of runs for M/M/1/N queue with

varying N and λ when µ = 1, T = 1000 and X(0) = 0.

1 Run Multiple Runs

N λ MSE TMSE

′

Opt. runs MSE

10 0.8 0.171 0.180 3 0.168

50 0.8 1.569 2.340 6 1.018

10 0.9 0.228 0.124 2 0.227

50 0.9 14.856 16.770 3 9.555

To demonstrate that the derivative of MSE with re-

spect to w is a good indicator for using multiple runs,

consider the M/M/20/50 queue with λ = 0.8, µ =

1/c = 0.05, and T = 1000. The derivatives of MSE

in this case are negative for X(0) < 9 and X(0) > 25,

and they are positive for X(0) ranging from 9 to 25.

Table 3 gives the MSE for the number of runs from

1 to 3, and the optimal number of runs (Runs

∗

) for

X(0) ranging from 6 to 10. As one can see, for both

X(0) = 7 and X(0) = 8, the results of Table 3 suggest

multiple runs, even though the derivative in question

is negative. In such cases, multiple runs may be com-

bined with warm-up periods. This, however, seems to

be an exception. For X(0) = 10, three runs are opti-

mal because the MSE for 4 runs is 2.077.

The next question we need to address is whether

or not states obtained from pairs of attraction will lead

to low values of the derivative of the MSE. To resolve

this question, consider ﬁrst the M/M/20/50 queue

discussed earlier. In this case, λ/µ = 16, that is, for

X(0) = 16, there is no drift. Hence, this should be a

good starting state. However, the starting state with

SIMULTECH2015-5thInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

142

Table 3: MSE(

R(T)) for the M/M/20/50 queue with λ =

0.8, µ = 0.05, and T = 1000.

X(0) TMSE

′

MSE Runs

∗

1 run 2 runs 3 runs

6 -2.207 2.209 2.191 2.364 1

7 -1.184 2.200 2.147 2.260 2

8 -0.243 2.192 2.107 2.165 2

9 0.615 2.186 2.072 2.079 2

10 1.389 2.180 2.040 2.002 3

the lowest MSE when using only 1 run is X(0) = 13,

with MSE = 2.177. For X(0) = 16, the MSE is 2.181,

which is not much higher. However, when starting

with X(0) = 16, and doing 12 runs, one ﬁnds an MSE

of only 1.069, which is signiﬁcantly lower. The best

one can obtain with X(0) = 13 is 4 runs with an MSE

of 1.746.

We now increase T by a factor of 10 form 1000 to

10000. In this case, the derivatives of of the MSE

with respect to the warm-up period is positive for

8 ≤ X(0) ≤ 24, and negative otherwise, which is very

close to the result obtained for T = 1000. Also, the

optimal number of runs does not change signiﬁcantly

for X(0) between 6 to 10, as seen in Table 4. Also,

the starting state with the lowest MSE is state number

13, as before. Hence, in this model, the best starting

state, and the best number of runs is insensitive to T.

Table 4: MSE(

R(T)) for the M/M/20/50 queue with λ =

0.8, µ = 0.05, and T = 1000.

X(0) TMSE

′

MSE Runs

∗

1 run 2 runs 3 runs

6 -0.185 0.239 0.239 0.240 1

7 -0.081 0.239 0.238 0.239 2

8 0.015 0.239 0.238 0.238 2

9 0.102 0.239 0.238 0.238 3

10 0.180 0.239 0.237 0.237 3

As our ﬁnal example, consider a three station tan-

dem queue with stations 1, 2 and 3. Each station has a

buffer size of 5, including the place for the part being

served. All jobs arrive at station 1, and must proceed

to station 2, then 3, in that order, after which they

depart. If the ﬁrst buffer is full, arrivals are lost. If

the buffer of station 2 or 3 is full, the previous sta-

tion is blocked, that is, departures are delayed until

there is a place in the buffer they go to. Arrivals are

Poisson with a rate λ = 0.75, and service is exponen-

tial, with a rate of µ

= 1 for station i, i = 1, 2, 3.

We use T = 1000. Our R(t) is given by the total

number in the system. The number in station i will

be denoted by X

(t), i = 1,2,3, and the state where

(t) = x

, i = 1,2,3 will be denoted by [x

With this notation, one pair of attraction is the state

([0,0,0],[1, 0, 0]). Unfortunately, both states of this

pair show that increasing the warm-up period from

0 to some positive value would decrease the MSE.

Accordingly, using two runs for state [0, 0, 0] would

increase the MSE form originally 0.1710 to 0.1736.

For state [1,0,0], the corresponding values are 0.1705

and 0.1715. The state with the lowest MSE is state

[5,0,0], with an MSE of 0.1694. Note that in our

model, E(R) = 5.44, and for state [5,0,0], R(t) = 5,

which is close to E(R). When starting in this state, the

MSE is reduced from 0.1715 to 0.1661 if two runs are

made. Also, the derivative of the MSE is positive. In

fact, out of the 216 states that can be used for starting

the simulation, 153 states have a positive derivative of

the MSE, and in 112 starting states, 2 runs are better

than 1. There are thus better states to start the simu-

lation in than [0, 0, 0] or [1, 0, 0]. On the other hand,

the potential improvement in the MSE by using states

other than [0,0,0] or [1,0,0] is limited. However,

since pairs of attraction are so easy to ﬁnd, and since

the possible improvements obtainable by using other

starting states is small, using pairs of attraction is still

no mistake. Improvements can also be made by in-

creasing the state variables slightly. For instance, for

state [1,1,1], the MSE is 0.1702, its derivative is pos-

itive, that is, no warm-up period should be used, and

if two runs are made, the MSE decreases to 0.1696.

5 CONCLUSIONS

In this paper, we demonstrated that multiple runs may

be optimal if the simulation starts in a well-chosen

state. One method we presented for ﬁnding well cho-

sen starting states uses ﬂow analysis to ﬁnd pairs of

attraction: The elements of these pairs typically yield

good starting states. Sometimes, it is best not to use

these starting states directly, but to change the val-

ues of the state variable to bring them closer to their

equilibrium expectations. In particular,state variables

representing queues and obtained from pairs of attrac-

tion typically have values below their equilibrium ex-

pectation. Once a good starting state is at hand, its

effect would be watered down by any warm-up pe-

riod. The beneﬁcial effect of a well chosen starting

state can be increased by making multiple runs. In

this case, the effect of the bias is strengthened, which

implies that starting states with R(0) close to E(R) be-

come increasingly advantageous.

We also presented a number of numerical exper-

iments. Though in the models used, pairs of attrac-

tion did not necessarily provide the minimal mean

squared error, they led to a reasonable performance

at all times, especially after a slight increase of the

state variables.

UsingMultipleRunsintheSimulationofStochasticSystemsforEstimatingEquilibriumExpectations

143

ACKNOWLEDGEMENTS

This research was partially supported by NSERC of

Canada, Grant 8112.

REFERENCES

Alexopoulos, C. and Goldman, D. (2004). To batch or not to

batch? ACM Transaction on Modeling and Computer

Simulation, 14(4):76–214.

Asmussen, S. and Glynn, P. W. (2007). Stochastic Simula-

tion: Algorithms and Analysis, volume 57 of Stochas-

tic Modelling and Applied Probability. Springer Ver-

lag, New York.

Banks, J., Carson, J. S., Nelson, B. L., and Nicol, D. (2005).

Discrete Event Simulation. Prentice Hall, Englewood

Cliffs, NJ.

Grassmann, W. K. (1982). Initial bias and estimation error

in discrete event simulation. In Highland, H. G., Chao,

Y. W., and Madrigal, O., editors, Proceedings of the

1982 Winter Simulation Conference, pages 377–384,

Piscataway, NY. The Institute of Electrical and Elec-

tronics Engineers, Inc.

Grassmann, W. K. (1987). Means and variances of time av-

erages in Markovian environments. European Journal

of Operationonal Research, 31:132–139.

Grassmann, W. K. (2008). Warm-up periods in simulation

can be detrimental. Probabilitiy in Engineering and

Informational Sciences, 22:415–429.

Grassmann, W. K. (2011). Rethinking the initialization

bias problem in steady-state discrete event simulation.

In Jain, S., Creasey, R. R., Himmelspach, J., White,

K. P., and Fu, M., editors, Proceedings of the 2011

Winter Simulation Conference, pages 593–599, Pis-

cataway, NY. The Institute of Electrical and Electron-

ics Engineers, Inc.

Grassmann, W. K. (2014). Factors affecting warm-up

periods in discrete event simulation. Simulation,

90(1):11–23.

Kelton, W. D. (1989). Random initialization methods in

simulation. IIE Transactions, 21(4):355–367.

Kelton, W. D. and Law, A. M. (1985). The transient behav-

ior of the M/M/c queue, with implication for steady-

state simulation. Operations Research, 33:378–396.

Law, A. M. and Kelton, W. D. (2000). Simulation Modelling

and Analysis. McGraw Hill, New York, third edition.

Madansky, A. (1976). Optimal conditions for a simulation

problem. Operations Research, 24:572–577.

Newell, G. F. (1982). Applications of Queueing Theory.

Chapman and Hall, London, second edition.

Pasupathy, R. and Schmeiser, B. (2010). The initial tran-

sient in steady state point estimation: Context, a bi-

ography, the MSE criterium, and the MSER statistic.

In Johansson, B., Jain, S., Montaya-Torres, J., Hugan,

J., and Y¨ucesan, E., editors, Proceedings of the 2010

Winter Simulation Conference, pages 184–197, Pis-

cataway, NY. The Institute of Electrical and Electron-

ics Engineers, Inc.

Pawlikowski, K. (1990). Steady-state simulation of queue-

ing processes: a survey of problems and solutions.

ACM Computing Surveys, 22(2):123–170.

Tocher, K. D. (1963). The Art of Simulation. English Uni-

versity Press, London.

Whitt, W. (1991). The efﬁciency of one long run ver-

sus independent replications in steady-state simula-

tion. Management Science, 37(6):645–666.

Wilson, J. R. and Prisker, A. A. B. (1978). Evaluation of

startup policies in simulation experiments. Simula-

tion, 31:79–88.

SIMULTECH2015-5thInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

144
