Detecting and Isolating Inconsistently Behaving Agents using an

Intelligent Control Loop

Jan Kantert

, Sarah Edenhofer

, Sven Tomforde

, Jörg Hähner

and Christian Müller-Schloer

Institute of Systems Engineering, Leibniz University Hannover, Appelstr. 4, 30167 Hanover, Germany

Lehrstuhl für Organic Computing, Augsburg University, Eichleitnerstr. 30, 86159 Augsburg, Germany

{kantert, cms}@sra.uni-hannover.de,

Keywords:

Adaptive Control Loop, Multi-Agent-Systems, Trust, Norms, Desktop-grid System.

Abstract:

Desktop Computing Grids provide a framework for joining in and sharing resources with others. The result

is a self-organised system that typically consists of numerous distributed autonomous entities. Openness and

heterogeneity postulate severe challenges to the overall system’s stability and efﬁciency since uncooperative

and even malicious participants are free to join. In this paper, we present a concept for identifying agents

with exploitation strategies that works on a system-wide analysis of trust and work relationships. Afterwards,

we introduce a system-wide control loop to isolate these malicious elements using a norm-based approach –

due to the agents’ autonomy, we have to build on indirect control actions. Within simulations of a Desktop

Computing Grid scenario, we show that the intelligent control loop works highly successful: these malicious

elements are identiﬁed and isolated with a low error rate. We further demonstrate that the approach results in

a signiﬁcant increase of utility for all participating benevolent agents.

1 INTRODUCTION

Desktop Computing Grid systems are self-organised

collectives of resources provided by a potentially

large set of participants. For each computer, an agent

is responsible for getting the user’s jobs processed by

others as fast as possible. Simultaneously, it manages

which other agents are allowed to utilised the own

resources. The resulting system is characterised by

openness and heterogeneity - everyone is free to join

if following the basic protocol.

Openness inherently deﬁnes drawbacks. For in-

stance, egoistic or even malicious behaviour of agents

is possible. Therefore, counter-measures are needed

to isolate unwanted elements and provide a perfor-

mant platform for normal and benevolent users. By

introducing technical trust, most of these negative ef-

fects can be controlled. One major challenge that

is addressed in this paper is to identify agents with

inconsistent behaviour. This means that an agent

tends to exploit the system as soon as it has es-

tablished stable trust relationships within the system

– and returns to benevolent behaviour if others de-

tected the exploitation strategy. In our concept, we

extend previous work for the Trusted Desktop Grid

(TDG) (Klejnowski, 2014) with an intelligent control

loop. This loop works at system-level and follows the

Observer/Controller concept (Tomforde et al., 2011)

as known from Organic Computing (Müller-Schloer,

2004). Since agents are autonomous, the control loop

works on publicly available information, i.e. trust and

work relationships. We follow a graph-based anal-

ysis strategy and show that even this challenging be-

haviour of so-called Cunning Agents can be identiﬁed.

The remainder of this paper is organised as fol-

lows: Section 2 describes the TDG as application sce-

nario with a special focus on the agents’ goals, the

system goal, and the trust mechanism. It also explains

the system-wide control loop that establishes a norm-

oriented management cycle to identify and isolate

negative elements. Afterwards, Section 3 describes

the approach to detect and isolate Cunning Agents in

detail. The mechanism is evaluated in Section 4 by

simulations of our Trusted Desktop Grid. Therein,

we show that the normative approach is highly suc-

cessful and demonstrate that an isolation is achieved

with low failure rate. Section 5 compares the concept

to the current state-of-the-art. Finally, Section 6 sum-

marises the paper and gives an outlook to current and

future work.

246

Kantert J., Edenhofer S., Tomforde S., Hähner J. and Müller-Schloer C..

Detecting and Isolating Inconsistently Behaving Agents using an Intelligent Control Loop.

DOI: 10.5220/0005548402460253

In Proceedings of the 12th International Conference on Informatics in Control, Automation and Robotics (ICINCO-2015), pages 246-253

ISBN: 978-989-758-122-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

2 APPLICATION SCENARIO

As a possible application scenario, we investigate

open grid computing systems which can host numer-

ous distributable workloads, e.g. distributed render-

ing of ﬁlms. The system is considered open since

there is no central controlling entity, all communi-

cation is performed peer-to-peer and agents are free

to join. Worker nodes belong to different adminis-

trative domains, thus, good behaviour cannot be as-

sumed. Nodes participate voluntarily to submit work

into the system and, thereby, increase the speedup of

their jobs. However, they also have to compute work

units for other submitters.

2.1 Agent Goal

To analyse such systems, we model nodes as agents

and run a multi-agent system in simulation. Ev-

ery agent works for a user and periodically receives

a job, which contains multiple parallelisable work

units. It aims to accomplish all work units as fast

as possible by requesting other agents to work for it.

Since we consider an open system, agents behave au-

tonomously, and can join or leave at any time. The

system performance is measured by the speedup σ. In

Equation (1), t

self

is the time it would require an agent

to compute a job containing multiple work units with-

out any cooperation. t

distributed

represents the time it

took to compute all work units of one job with coop-

eration of other workers including all communication

times. The actual speedup σ can only be determined

after the result of the last work unit has been returned.

σ B

self

distributed

(1)

If no cooperation partners can be found, agents need

to compute their own work units and achieve a

speedup value equal to one (i.e. no speedup at all).

In general, agents behave selﬁshly and only cooper-

ate if they can expect an advantage. They have to

decide which agent they give their work to and for

which agents they work themselves. We do not con-

trol the agent implementation, so they might behave

uncooperatively or even maliciously.

2.2 Worker and Submitter Component

Each agent consists of a worker and a submitter com-

ponent. The submitter component is responsible for

distributing work units. When an agent receives a

job containing multiple work units, it creates a list of

trusted workers. It then requests workers from this

list to cooperate and compute work units, until either

no more work units or no more workers are left. If

all workers were asked, but unprocessed work units

remain, the agent computes them on its own. The

worker component decides whether an agent wants

to work for a certain submitter. When the agent re-

ceives an offer, it computes its rewards for accept-

ing or rejecting the job. There are different strate-

gies based on reputation, workload and environment.

If the reward of accepting the job prevails, the agent

accepts the job. It may cancel the job later on, but

typically it computes the job and returns the results to

the worker (Klejnowski, 2014).

2.3 Open Systems and Benevolence

In contrast to other state-of-the-art work, we do not

assume the benevolence of the agents (Wang and Vas-

sileva, 2004). In such an open system we cannot con-

trol the implementation of agents and, therefore, the

system is vulnerable to different kinds of attacks. For

instance, a Freerider could simply refuse to work for

other agents and gain an advantage at the expense of

cooperative agents. Another attacker might just pre-

tend to work and return wrong results. Also, combi-

nations of both or alternating behaviour are possible.

Additionally, attacker can collude to exploit the sys-

tem.

2.4 Trust and Norms

To overcome these problems of an open system where

no particular behaviour can be assumed, we introduce

a trust metric. Agents receive ratings for all their ac-

tions from their particular interaction partners. This

allows others to estimate the future behaviour of a cer-

tain agent based on its previous actions. To perform

this reasoning a series of ratings for a certain agent

can be accumulated to a single reputation value us-

ing the trust metric. Autonomous agents need to be-

come aware of the expected behaviour in the system.

Therefore, we inﬂuence the desired actions by norms.

These norms are valid for an Action in a certain Con-

text and, thereby, guide the agents. To enforce the

behaviour, they impose a Sanction if violated or offer

an Incentive if fulﬁlled.

In this scenario, good trust ratings are used as an

Incentive and, in the opposite, bad trust ratings im-

pose a Sanction (agents with higher reputation val-

ues have a higher chance to get their work units com-

puted). Based on the norms, agents receive a good

rating if they work for other agents and a bad rating

if they reject or cancel work requests. As a result,

the society isolates malevolent agents and maintains a

good system utility in most cases. We call this system

a Trusted Desktop Grid (TDG) (Klejnowski, 2014).

DetectingandIsolatingInconsistentlyBehavingAgentsusinganIntelligentControlLoop

247

Since agents are considered as black boxes they can-

not be controlled directly from the outside. Each

agent is autonomous and selﬁsh. However, we want

to inﬂuence the system to optimise and make it more

robust. Therefore, we introduce norms to change the

incentives and sanctions for all agents.

2.5 Agent Types

We consider the following agent types in our system:

• Adaptive Agents - These agents are cooperative.

They work for other agents who earned good rep-

utation in the system. How high the reputation

value has to be generally depends on the esti-

mated current system load and how much the in-

put queue of the agent is ﬁlled up.

• Freeriders - Such agents do not work for other

agents and reject all work requests. However, they

ask other agents to work for them. This increases

the overall system load and decreases the utility

for well-behaving agents.

• Egoists - These agents only pretend to work for

other agents. They accept all work requests but

return fake results to other agents, which wastes

the time of other agents. If results are not vali-

dated, this may lead to wrong results. Otherwise,

it lowers the utility of the system.

• Cunning Agents - These agents behave well in the

beginning but may change their behaviour later.

Periodically, randomly, or under certain condi-

tions they behave like Freeriders or Egoists. This

is hard to detect and may lower the overall system

utility.

• Altruistic Agents - Such agents will accept every

job. In general, this behaviour is not malicious

and increases the system performance. However,

it hinders isolation of bad-behaving agents and

impacts the system goals.

2.6 Higher-level Norm Manager

In Figure 1, we present our concept of the Norm

Manager (NM), which uses the common Observer-

Controller pattern (Tomforde et al., 2011). The

complete control loop implemented by the Observer-

Controller component helps to mitigate effects of at-

tacks to the TDG and allows a better fulﬁlment of

the system goals. Thereby, it deﬁnes an intelligent

control mechanism working at system-level. How-

ever, if the additional NM fails, the system itself is

still operational and can continue to run (this refers to

Norm Manager

Agent A

Agent B

Agent C

Norm set

Agent E

Agent D

Observationmodel

Change norms

Distribute

norms

Collect data

on agents

Observer Controller

Situation

Description

Detect

situation

SuOC

Figure 1: System Overview of the Norm Manager consist-

ing of an Observer and a Controller which control the Sys-

tem under Observation and Control (SuOC) using norms.

the desired OC characteristic of non-critical complex-

ity (Schmeck et al., 2010)). When the NM is recov-

ered, it can start to optimise the system again.

2.6.1 Observer - Detect Current Situation

To detect the current system state, the controller mon-

itors work relations of all agents. For this purpose, it

creates a work graph with agents as nodes and edges

between agents which have cooperated in the mon-

itored period. The intensity of the cooperation be-

tween two agents determines the weight of the edge

connecting them. In this context, the intensity is

determined according to the number of shared work

packages. Additionally, the controller creates a trust

graph with agents as nodes and trust relations as

edges. Trust relations between agents can be obtained

from the reputation system and deﬁne as how trust-

worthy agents estimates each other within an interval

between 0 (not trustworthy at all) and 1 (fully trust-

worthy, i.e. self-trust). Since we cannot see the inter-

nals or implementation of agents, we need to observe

them from the outside. We could monitor all interac-

tions between agents, but this may lead to a bottleneck

in larger systems. However, it is easy to monitor the

actions indirectly: We can observe the reputation sys-

tem and use the ratings which agents give their part-

ners after every interaction. When we collect those

ratings, we can build a trust-graph. Multiple ratings

will be merged using an arithmetic mean.

Afterwards, the NM calculates certain common

graph metrics for every node (i.e. DegreeCentral-

ity, textitPrestige or ClusteringCoefﬁcient; see (Kan-

tert et al., 2014)). Using statistics, the global system

ICINCO2015-12thInternationalConferenceonInformaticsinControl,AutomationandRobotics

248

state is determined. Based on these metrics, our al-

gorithm forms clusters and ﬁnds groups of similar

agents. By further classifying these groups, the Ob-

server achieves an even better understanding about

potentially happening attacks. In the end, it is able to

classify whether the system is under attack, categorise

the type of the attack, and rank attacks according to

their severity. This is accompanied by an estimation

of how accurate this information is. From a methodi-

cal point of view, the observer works as follows: First,

it builds graphs for trust and work relations between

agents. In a second step, it applies graph metrics to

be able to identify groups or clusters of similar agents

in the next step. Afterwards, it runs statistics on every

cluster found and compares them to historic or thresh-

old values. Clusters are tracked over time to detect

tendencies and predict future values.

2.6.2 Controller - Change Norms

The controller is responsible for guiding the overall

system behaviour by applying norms. Such a norm

contains a rule and a sanction or an incentive (Urz-

a and Gratie, 2013). Agents are still autonomous

and can violate norms with the risk of being sanc-

tioned. Based on the information obtained by the

observer, the controller decides whether the system

norms need to be changed. Norms can not directly

inﬂuence agents but modify their actions. To be more

speciﬁc, norms can impose sanctions or offer incen-

tives to actions. To defend against attacks, we can

increase sanctions for certain actions. Under certain

conditions we can allow agents to perform security

measures, which would lead to sanctions

3 APPROACH

In previous work (Kantert et al., 2015) we demon-

strated that clearly malicious agents (i.e. Freeriders

and Egoists) can be isolated using norms and a higher-

level observer. In this Section, we present an ap-

proach to also detect Cunning Agents which is signif-

icantly harder to realise due to their exploitation strat-

egy. Afterwards, normative control is performed to

isolate these agents.

3.1 Detecting and Isolating Cunning

Agents

Cunning Agents cannot be easily detected and isolated

locally in a distributed system. Therefore, they pose

a permanent threat to the TDG. However, a higher-

level NM can detect them and then can change norms

to isolate them.

To detect Cunning Agents in the Norm Manager

(NM) we cluster groups using the MCL (Van Don-

gen, 2001) and the BIRCH (Zhang et al., 1996) al-

gorithm on the trust graph and classify them using a

decision matrix. For the purpose of this paper the ma-

trix can only identify groups of Cunning Agents. The

metrics used for that purpose were presented in (Kan-

tert et al., 2014). In particular, we use the value of

Authorities and DegreeCentrality to detect groups of

Cunning Agents.

Once the NM detected groups of Cunning Agents

it has to isolate them. Unfortunately, it cannot inﬂu-

ence agents directly but it can do this using norms.

Therefore, it introduces a new norm which allows

agents to refuse work from Cunning Agents. We pro-

pose to detect them based on their inconsistent be-

haviour.

3.2 Inconsistent Behaviour

In trust-based distributed system such as the TDG, we

condense a series of trust rating R to a single repu-

tation value τ (see Equation 3). However, this does

not take into account how consistent those ratings are.

Normally, agents make their decisions based on the

aggregated value τ.

r ∈ [−1, 1] ⇒ R ∈ [−1, 1]

(2)

τ B T(R) B

∑

r∈R

∑

r∈R

|r|

(3)

However, Cunning Agents behave strategically re-

garding their reputation value: They behave well un-

til they reach a certain threshold τ

upper

and then stop

to cooperate with other agents until they fall below a

threshold τ

lower

. Therefore, their reputation τ is be-

tween those two values most of the time and they ad-

just their τ

upper

and τ

lower

to be considered as well-

behaving by other agents based on the reputation (see

Equation 4).

lower

≤ τ ≤ τ

upper

∧ τ

lower

≥ τ

(4)

Since those agents intentionally exploit the trust met-

ric they cannot get detected and isolated using the rep-

utation value. However, they receive very inconsistent

ratings r because of their changing behaviour and we

can leverage that to detect them. Therefore, we deﬁne

the consistency κ based on the standard deviation:

κ B 1 −

∑

r∈R,r>0

∑

r∈R

|r|

(

τ − 1

)

∑

r∈R,r<0

∑

r∈R

|r|

(

τ + 1

)

(5)

We expect a very low value for Cunning Agents and a

value close to one for Adaptive Agents. Other agents

DetectingandIsolatingInconsistentlyBehavingAgentsusinganIntelligentControlLoop

249

such as Freeriders or Egoists also should get a value

of approximately one since they behave consistently

maliciously.

3.3 Changing Norms

The NM cannot directly inﬂuence agents or force

them to perform any actions. However, it can change

norms and, thereby, change incentives and sanctions

for certain actions. To cope with Cunning Agents

while maintaining the autonomy of agents we choose

to allow them to reject jobs from inconsistently be-

having agents. Therefore, agents can decide on their

own if they want to work for Cunning Agents since

they will still receive an incentive for that.

In Figure 2, we show the changed norm. The

threshold δ for the reputation τ is smaller than τ

lower

and threshold γ for consistency is 0.8 in our exper-

iment. requester.reputation is calculated using

the trust metric τ and requester.consistency is

determined by κ. The sanction results in a rating in

R for the working agent.

context

Target/Role

z }| {

Worker norm

Name

z }| {

AcceptJob:

requester.consisteny > γ ∧

requester.reputation > δ

| {z }

Pertinence Condition

implies acceptJob(requester, job) = true

| {z }

Postcondition

sanctioned

if violated

| {z }

Default Sanction Condition

then self.reputation += -rejectSanction

| {z }

Sanction

Figure 2: Changed norm used in the evaluation to isolate

Cunning Agents. It sanctions allows agents to reject jobs

from inconsistently behaving agents.

4 EVALUATION

In this section we provide experimental validation of

our approach.

4.1 Setup

The setup in the evaluation consists of 100 Adaptive

Agents and additional 50 Cunning Agents for all ex-

periments with attackers. Each experiment ran for

300k ticks and was repeated 100 times. We performed

three series of experiments: (E1) without attacker;

(E2) with attackers; (E3) with attackers and our norm

changes.

4.2 Detection of Cunning Agents

The detection of Cunning Agents in (E2) by the NM

can be observed between tick 15k and 50k and was

successful in all experiments. In average the NM de-

tected the attackers at tick 24920 with a standard de-

viation of 15301. The NM can introduce the norm

at this point. However, to make the impact of the

norm change more comparable we set the time t

change

to 100k for subsequent experiment in (E3).

4.3 Consistency Values

We measured the consistency values for Adaptive

Agents and Cunning Agents in (E2) at the end of the

experiment. Both values turned out to be as expected:

Adaptive Agents have a value of 0.9999 ± 0.00053

which is very close to one. In contrast Cunning

Agents have a value of 0.0611±0.01338 which is next

to zero.

4.4 Inﬂuence of Norm Change

We measure the inﬂuence of the norm change us-

ing the speedup σ for Adaptive Agents and Cunning

Agents in experiments (E1), (E2) and (E3) (see Fig-

ure 4). In Figure 3, we show one single exemplary

experiment of (E3) with speedup over time. In the be-

ginning Adaptive Agents and Cunning Agents achieve

a similar but varying speedup. After the NM intro-

duced the norm change at tick 100k the speedup for

Cunning Agents falls below one and those agents no

longer gain any advantage from participating in the

system. In contrast, Adaptive Agents gain a stable

high speedup again. In the undisturbed experiment

(E1), we measured that Adaptive Agents can achieve

a speedup of 11.74 ± 0.73 when there is no attack.

When a heavy attack of Cunning Agents is added in

(E2) the speedup decreases to 5.29 ± 1.26. With norm

change by the NM the speedup increases again to

6.75 ± 1.24 in (E3) which is less than in Figure 3 at

the end of the experiment because the value is aver-

aged over the complete experiment. Cunning Agents

achieve a speedup of 5.23 ± 1.38 when they exploit

the system in (E1). At the same time they work sig-

niﬁcantly less than Adaptive Agents. However, when

the NM changes the norm the speedup of Cunning

Agents decreases to 2.49 ± 0.33. Again, this is aver-

aged over 300k ticks and as shown in Figure 3 the

Cunning Agents are isolated with a speedup below

one at the end of all experiments.

ICINCO2015-12thInternationalConferenceonInformaticsinControl,AutomationandRobotics

250

Figure 3: Exemplary simulation run with norm introduced

at tick 100k. A speedup of less than one means that agents

no longer have an advantage from participating in the sys-

tem.

Adaptive Agents Cunning Agents

Duration [ticks]

E1 - Reference

E2 - No norm

E3 - With norm

Figure 4: Speedup for Adaptive Agents and Cunning Agents

for every experiment series with 100 Experiments each. In

E3 the norm was introduced at tick 100k. All experiments

lasted 300k ticks.

5 RELATED WORK

Our application scenario is a Trusted Desktop Grid

System. These systems are used to share re-

sources between multiple administrative authorities.

The ShareGrid Project in Northern Italy is an ex-

ample for a peer-to-peer-based system (Anglano

et al., 2008). A second approach is the Organic

Grid, which is peer-to-peer-based with decentralised

scheduling (Chakravarti et al., 2004). Compared to

our system, these approaches assume that there are

no malicious parties involved and each node behaves

well. Another implementation with a central tracker is

the Berkeley Open Infrastructure for Network Com-

puting project (BOINC) (Anderson and Fedak, 2006).

All those systems solve a distributed resource allo-

cation problem. Since work units can be computed

faster when agents cooperate, they reward and, thus,

maximise cooperation. Additionally, a high fairness

value ensures equal resource distribution (cf. (Jain

et al., 1996; Demers et al., 1989; Bennett and Zhang,

1996)). We model our grid nodes as agents. Agents

follow a local goal which differs from the global sys-

tem goal (Rosenschein and Zlotkin, 1994). We con-

sider agents as black boxes which means that we can-

not observe their internal state. Thus, their actions

and behaviour cannot be predicted (Hewitt, 1991).

Our Trusted Desktop Grid supports Bag-of-Tasks ap-

plications (Anglano et al., 2006). A classiﬁcation of

Desktop Grid Systems can be found in (Choi et al.,

2007). A taxonomy can be found in (Choi et al.,

2008). It is emphasised there that there has to be

some mechanism to detect failures and malicious be-

haviour in large-scale systems. Nodes cannot be ex-

pected to be unselﬁsh and well-behaving. In contrast,

to other state-of-the-art works, we do not assume

the benevolence of the agents (Wang and Vassileva,

2004). To cope with this information uncertainty, we

introduced a trust metric. A general overview about

trust in Multi-Agent Systems can be found in (Castel-

franchi and Falcone, 2010). Another implementa-

tion of trust in a Desktop Grid System was evaluated

in (Domingues et al., 2007).

5.1 Normative Multi-agent Systems

This work is part of wider research in the area of

norms in multi-agent systems. However, we fo-

cus more on improving system performance by us-

ing norms than researching the characteristics of

norms (Singh, 1999). Our scenario is similar to

management of common pool resources. Accord-

ing to game theory, this leads to a “tragedy of the

commons” (Hardin, 1968). However, Ostrom (Os-

trom, 1990) observed cases where this did not hap-

pen. She presented eight design principles for suc-

cessful self-management of decentralised institutions.

Pitt et al. (Pitt et al., 2011) adapted these to Normative

Multi-Agent Systems. Normative Multi-Agent Sys-

tems are used in multiple ﬁelds: e.g. (Governatori

and Rotolo, 2008) focus on so-called policy-based

intentions in the domain of business process design.

Agents plan consecutive actions based on obligations,

intentions, beliefs, and desires. Based on DL, social

agents reason about norms and intentions.

In (Artikis and Pitt, 2009), the authors present a

generic approach to form organisations using norms.

They assign a role to agents in a normative system.

This system deﬁnes a goal, a process to reach the goal,

required skills, and policies constraining the process.

DetectingandIsolatingInconsistentlyBehavingAgentsusinganIntelligentControlLoop

251

Agents directly or indirectly commit to certain actions

using a predeﬁned protocol. Agents may join or form

an organisation with additional rules. The “norm-

change” deﬁnition describes attributes, which are re-

quired for Normative Multi-Agent Systems (Boella

et al., 2009). Ten guidelines for implementation of

norms to MAS are given. We follow those rules in

our system. When norms are involved, agents need to

make decisions based on these norms. (Conte et al.,

1999) argue that agents have to be able to violate

norms to maintain autonomy. However, the utility of

certain actions may be lower due to sanctions. Ac-

cording to (Savarimuthu and Craneﬁeld, 2011), Nor-

mative Multi-Agent Systems can be divided into ﬁve

categories: norm creation, norm identiﬁcation, norm

spreading, norm enforcement, and network topology.

We use a leadership mechanism for norm creation

and norm spreading. For norm identiﬁcation, we use

data mining and machine learning. For norm enforce-

ment, we use sanctioning and reputation. Our net-

work topology is static. Related approaches use Nor-

mative Multi-Agent Systems for governance or task

delegation in distributed systems (Singh et al., 2013).

6 CONCLUSION AND FUTURE

WORK

This paper presented a novel approach to identify

and isolate agents with inconsistent and partly mali-

cious behaviour within open, self-organised systems

such as Desktop Computing Grids. Therefore, we es-

tablished an intelligent system-wide control loop to

guide the self-organised behaviour of heterogeneous

agents that are free to join the system if they follow

the basic protocol. In general, we identiﬁed differ-

ent stereo-type agent behaviours that also consider ex-

ploitation strategies and malicious behaviour. Based

on the system-wide identiﬁcation approach, we pro-

posed to establish an observer/controller loop that is-

sues norms as response to the currently observed con-

ditions. The concept consists of an observer part

that derives an appropriate situation description from

externally monitorable information, i.e. interactions

between agents, and a controller part that generates

norms, i.e. demanded behavioural guidelines that are

augmented with incentive and sanctioning strategies.

For the identiﬁcation task of exploiting agents, we in-

troduced a graph-based method to detect suspicious

agents or groups of agents at runtime.

The evaluation is based on a simulation of a

Trusted Desktop Grid in which several classes of

stereo-type agent behaviour are considered. The

results demonstrated that the system-wide control

loop works successful in terms of issuing appropri-

ate norms. These norms are followed by benevolent

agents – and as a result, malicious agents are isolated,

i.e. they do not ﬁnd cooperation partners any more.

Future work will focus on reﬁning the control loop

and improving the controller part. Therefore, we in-

vestigate how norms can be generated automatically

that a suitable for certain situations. In addition, we

currently develop distributed and fully self-organised

strategies to monitor whether agents comply to norms

or not.

REFERENCES

Anderson, D. P. and Fedak, G. (2006). The Computa-

tional and Storage Potential of Volunteer Computing.

In Proc. of CCGRID 2006, pages 73–80, Singapore.

IEEE.

Anglano, C., Brevik, J., Canonico, M., Nurmi, D., and Wol-

ski, R. (2006). Fault-aware Scheduling for Bag-of-

Tasks Applications on Desktop Grids. In Proc. of

GRID 2006, pages 56–63, Singapore. IEEE.

Anglano, C., Canonico, M., Guazzone, M., Botta, M., Ra-

bellino, S., Arena, S., and Girardi, G. (2008). Peer-to-

Peer Desktop Grids in the Real World: The ShareGrid

Project. Proc. of CCGrid 2008, 0:609–614.

Artikis, A. and Pitt, J. (2009). Specifying Open Agent

Systems: A Survey. In Artikis, A., Picard, G., and

Vercouter, L., editors, Engineering Societies in the

Agents World IX, volume 5485 of LNCS, pages 29–

45. Springer, Saint-Etienne, FR.

Bennett, J. C. and Zhang, H. (1996). WF2Q: Worst-case

Fair Weighted Fair Queueing. In INFOCOM ’96. Fif-

teenth Annual Joint Conference of the IEEE Computer

Societies. Networking the Next Generation. Proceed-

ings IEEE, volume 1, pages 120–128, San Francisco,

CA, USA. IEEE.

Boella, G., Pigozzi, G., and van der Torre, L. (2009). Nor-

mative Systems in Computer Science - Ten Guidelines

for Normative Multiagent Systems. In Boella, G.,

Noriega, P., Pigozzi, G., and Verhagen, H., editors,

Normative Multi-Agent Systems, number 09121 in

Dagstuhl Seminar Proceedings, pages 1–21, Dagstuhl,

Germany. Schloss Dagstuhl - Leibniz-Zentrum fuer

Informatik, Germany.

Castelfranchi, C. and Falcone, R. (2010). Trust Theory:

A Socio-Cognitive and Computational Model, vol-

ume 18. John Wiley & Sons, Chichester, UK.

Chakravarti, A. J., Baumgartner, G., and Lauria, M. (2004).

Application-Speciﬁc Scheduling for the Organic Grid.

In Proc. of GRID 2004 Workshops, pages 146–155,

Washington, DC, USA. IEEE.

Choi, S., Buyya, R., Kim, H., and Byun, E. (2008). A

Taxonomy of Desktop Grids and its Mapping to State

of the Art Systems. Technical report, Grid Comput-

ing and Dist. Sys. Laboratory, The University of Mel-

bourne.

ICINCO2015-12thInternationalConferenceonInformaticsinControl,AutomationandRobotics

252

Choi, S., Kim, H., Byun, E., Baik, M., Kim, S., Park, C.,

and Hwang, C. (2007). Characterizing and Classifying

Desktop Grid. In Proc. of CCGRID 2007, pages 743–

748, Rio de Janeiro, Brazil. IEEE.

Conte, R., Castelfranchi, C., and Dignum, F. (1999). Au-

tonomous Norm Acceptance. In Müller, J., Rao, A.,

and Singh, M., editors, Intelligent Agents V: Agents

Theories, Architectures, and Languages, volume 1555

of LNCS, pages 99–112. Springer, Paris, France.

Demers, A., Keshav, S., and Shenker, S. (1989). Analy-

sis and Simulation of a Fair Queueing Algorithm. In

Symposium Proceedings on Communications Archi-

tectures & Protocols, SIGCOMM ’89, pages 1–12,

New York, NY, USA. ACM.

Domingues, P., Sousa, B., and Moura Silva, L. (2007).

Sabotage-tolerance and Trustmanagement in Desktop

Grid Computing. Future Generation Computer Sys-

tems, 23(7):904–912.

Governatori, G. and Rotolo, A. (2008). BIO Logical

Agents: Norms, Beliefs, Intentions in Defeasible

Logic. Autonomous Agents and Multi-Agent Systems,

17(1):36–69.

Hardin, G. (1968). The Tragedy of the Commons. Science,

162(3859):1243–1248.

Hewitt, C. (1991). Open Information Systems Semantics

for Distributed Artiﬁcial Intelligence. Artiﬁcial intel-

ligence, 47(1):79–106.

Jain, R., Babic, G., Nagendra, B., and Lam, C.-C. (1996).

Fairness, Call Establishment Latency and Other Per-

formance Metrics. ATM-Forum, 96(1173):1–6.

Kantert, J., Edenhofer, S., Tomforde, S., Hähner, J., and

Müller-Schloer, C. (2015). Defending Autonomous

Agents Against Attacks in Multi-Agent Systems Us-

ing Norms. In Proceedings of the 7th Interna-

tional Conference on Agents and Artiﬁcial Intelli-

gence, pages 149–156, Lisbon, Portugal. INSTICC,

SciTePress.

Kantert, J., Scharf, H., Edenhofer, S., Tomforde, S., Hähner,

J., and Müller-Schloer, C. (2014). A Graph Analysis

Approach to Detect Attacks in Multi-Agent-Systems

at Runtime. In 2014 IEEE Eighth International Con-

ference on Self-Adaptive and Self-Organizing Sys-

tems, pages 80–89, London, UK. IEEE.

Klejnowski, L. (2014). Trusted Community: A Novel Mul-

tiagent Organisation for Open Distributed Systems.

PhD thesis, Leibniz Universität Hannover.

Müller-Schloer, C. (2004). Organic Computing: On the

Feasibility of Controlled Emergence. In Proc. of

CODES and ISSS’04, pages 2–5. ACM Press.

Ostrom, E. (1990). Governing the Commons: The Evolu-

tion of Institutions for Collective Action. Cambridge

university press, Cambridge, US.

Pitt, J., Schaumeier, J., and Artikis, A. (2011). The Ax-

iomatisation of Socio-Economic Principles for Self-

Organising Systems. In Self-Adaptive and Self-

Organizing Systems (SASO), 2011 Fifth IEEE Interna-

tional Conference on, pages 138–147, Michigan, US.

IEEE.

Rosenschein, J. S. and Zlotkin, G. (1994). Rules of En-

counter: Designing Conventions for Automated Ne-

gotiation Among Computers. MIT Press, Cambridge.

Savarimuthu, B. T. R. and Craneﬁeld, S. (2011). Norm Cre-

ation, Spreading and Emergence: A Survey of Simula-

tion Models of Norms in Multi-Agent Systems. Mul-

tiagent and Grid Systems, 7(1):21–54.

Schmeck, H., Müller-Schloer, C., Çakar, E., Mnif, M., and

Richter, U. (2010). Adaptivity and self-organization

in organic computing systems. ACM Trans. Auton.

Adapt. Syst., 5:10:1–10:32.

Singh, M. P. (1999). An Ontology for Commitments in

Multiagent Systems. Artiﬁcial Intelligence and Law,

7(1):97–113.

Singh, M. P., Arrott, M., Balke, T., Chopra, A. K., Chris-

tiaanse, R., Craneﬁeld, S., Dignum, F., Eynard, D.,

Farcas, E., Fornara, N., Gandon, F., Governatori, G.,

Dam, H. K., Hulstijn, J., Krueger, I., Lam, H.-P.,

Meisinger, M., Noriega, P., Savarimuthu, B. T. R.,

Tadanki, K., Verhagen, H., and Villata, S. (2013). The

Uses of Norms. In Normative Multi-Agent Systems,

volume 4 of Dagstuhl Follow-Ups, pages 191–229.

Schloss Dagstuhl–Leibniz-Zentrum fuer Informatik,

Dagstuhl, Germany.

Tomforde, S., Prothmann, H., Branke, J., Hähner, J., Mnif,

M., Müller-Schloer, C., Richter, U., and Schmeck, H.

(2011). Observation and Control of Organic Systems.

In Organic Computing - A Paradigm Shift for Complex

Systems, pages 325 – 338. Birkhäuser, Basel, CH.

Urzic

a, A. and Gratie, C. (2013). Policy-Based Instan-

tiation of Norms in MAS. In Fortino, G., Badica,

C., Malgeri, M., and Unland, R., editors, Intelligent

Distributed Computing VI, volume 446 of Studies in

Computational Intelligence, pages 287–296. Springer,

Calabria, Italy.

Van Dongen, S. M. (2001). Graph clustering by ﬂow simu-

lation. PhD thesis, Utrecht University.

Wang, Y. and Vassileva, J. (2004). Trust-Based Community

Formation in Peer-to-Peer File Sharing Networks. In

Proc. on Web Intelligence, pages 341–348, Beijing,

China. IEEE.

Zhang, T., Ramakrishnan, R., and Livny, M. (1996). Birch:

an efﬁcient data clustering method for very large

databases. In ACM SIGMOD Record, volume 25,

pages 103–114, Montreal, Canada. ACM.

DetectingandIsolatingInconsistentlyBehavingAgentsusinganIntelligentControlLoop

253
