Scargos: Towards Automatic Vulnerability Distribution

Florian Rhinow

1,2

and Michael Clear

School of Computer Science and Statistics, Trinity College Dublin, Dublin 2, Ireland

SAP Business Intelligence R&D, 1012-1014 Kingswood Ave., Citywest Business Campus, Dublin 24, Ireland

Keywords:

Dynamic Taint Analysis, Self-certifying Alerts, Vulnerability Distribution, Zero Day Attacks.

Abstract:

Recent work has suggested automated approaches to vulnerability distribution, but their usage has been lim-

ited to local networks and memory corruption detection techniques and has precluded custom vulnerability

response processes. We present Scargos, a novel approach to automate the distribution and veriﬁcation of

vulnerabilities across the internet, while allowing for automatic, custom countermeasures without the need

to trust a central authority. By leveraging collaborative detection, vulnerability reports can be contributed by

anybody and are announced to an open network by using packet-based self-certifying alerts (SCA), which

are a proof of the existence of a vulnerability by capturing the original, unmodiﬁed attack. We show that our

approach allows for detection of previously unknown attacks, while an entire life cycle including distribution

and veriﬁcation is achieved on average in under 2 seconds.

1 INTRODUCTION

The security of companies and organisations relies

heavily on their security departments. Often spe-

cialised incident response teams are employed to

surveil the state of the network. These teams react

to intruders or analyse past attacks. However they

also take action if a new vulnerability is announced

for one of their used applications. New vulnerabil-

ities are conventionally ﬁrst announced by the ven-

dor of an application and are later redistributed by

secondary sources such as a CVE. The time from a

vulnerability announcement until it is known by an

incident response team is critical, yet it often relies

on manual checking of websites or newsletters, or

is heavily reliant on secondary sources. The situa-

tion becomes worse when considering full-disclosure

announcements, which can be made by virtually ev-

erybody. As a consequence, the number of primary

sources seems indeﬁnite. Automated software exists,

but likewise, relies on the publication by a primary

source. Furthermore, vendors often know about a vul-

nerability much earlier, but delay its announcement in

order to write an appropriate patch in time – time in

which applications are vulnerable in companies and

organisations, without their knowledge. Informed at-

tackers can intrude and steal valuable assets, while

there is no effective way to ensure protection.

However, there are vulnerabilities which remain

unknown for an even longer period: zero-day vul-

nerabilities. These vulnerabilities are not known to

the public, but only to attackers. A recent study by

Symantec (Bilge and Dumitras, 2012) involved the

development of the worldwide intelligence network

environment (WINE) to collect data from over 11 mil-

lion hosts around the world. The data was analysed in

retrospect from 2008 until 2011 to determine whether

vulnerabilities were previously used by attackers prior

to their ofﬁcial discovery. In total, 18 zero-day vul-

nerabilities were found and the data suggests that the

attacks remained undetected for between 19 days to

30 months; on average 312 days (Bilge and Dumitras,

2012).

The motivations for engineering a solution are clear:

• Detection of zero-day attacks or other attacks that

are unknown to a group of entities

• Interested entities are notiﬁed automatically and

fast (within seconds) about such an attack and can

verify its existence

• Veriﬁed attacks can be automatically processed by

the entities to e.g. set up countermeasures

In this work, we present Scargos, a framework for

automatic vulnerability distribution. Scargos can de-

tect zero-day attacks by using dynamic taint analysis

in a honeypot. The information about the vulnerabil-

ity is then decoded as a packet-based self-certifying

alert and veriﬁed by all interested parties. As we will

369

Rhinow F. and Clear M..

Scargos: Towards Automatic Vulnerability Distribution.

DOI: 10.5220/0005566203690376

In Proceedings of the 12th International Conference on Security and Cryptography (SECRYPT-2015), pages 369-376

ISBN: 978-989-758-117-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

show in this work, the entire process can be accom-

plished in on average less than 2 seconds, while not

requiring that the participants trust each other.

Self-certifying alerts (SCAs) have been proposed

previously by (Costa et al., 2005) as a way to dis-

tribute vulnerabilities in local networks without the

need of a trusted central authority. The solution in

(Costa et al., 2005), known as Vigilante, uses a form

of SCAs that involve modifying the content of the

original attack and then sending it as a broadcast mes-

sage. It can only be used in conjunction with memory-

violation detection engines. In contrast, Scargos em-

ploys packet-based SCAs, which preserve an attack

in its original form. Additionally, Scargos allows for

distribution of vulnerabilities across the internet, en-

ables a custom vulnerability response process by end

users, and can be used with any attack detection en-

gine.

2 RELATED WORK

Dynamic taint analysis (DTA) also known as dy-

namic dataﬂow analysis or dynamic information ﬂow

tracking has been proposed independently by multiple

groups (Newsome and Song, 2005; Costa et al., 2004;

Crandall and Chong, 2004; Suh et al., 2004). DTA

taints all external data in-memory and recognizes if

the data is used to change the execution ﬂow to detect

attacks. Experiments that have been conducted with

DTA suggest that its false-positive rate is extremely

low. Newsome et al. (Newsome and Song, 2005) and

Clause et al. (Clause et al., 2007) independently con-

ducted accuracy experiments, which both resulted in

no false positives. However, slowdown depends on

the application and implementation that is being used

ranging from 300-100.000% – TaintCheck(Newsome

and Song, 2005), 4.000% – Dytan (Clause et al.,

2007), 1.500%-3.000% – Minemu (Bosman et al.,

2011), 1%-9% – FlexiTaint (Hardware) (Venkatara-

mani et al., 2008).

Argos (Portokalidis et al., 2006) is a honeypot that

attempts to mitigate many of the drawbacks that ac-

company conventional high-interaction honeypots. It

decreases the risk and maintenance of honeypots by

using DTA to accurately detect attacks. Therefore,

Argos can stop intrusions before a compromise of the

system occurs.

CWSandbox (Willems et al., 2007) is a tool that

is developed for the Win32 platform to automatically

generate malware analysis reports (Willems et al.,

2007; Provos and Holz, 2009).

Honeycomb is a plug-in for the low-interaction

honeypot Honeyd (Provos, 2003). Using Hon-

eyd, Honeycomb collects malicious trafﬁc to au-

tomatically create IDS signatures of the received

data (Kreibich and Crowcroft, 2004).

Roleplayer (Cui et al., 2006) is a tool which ob-

serves and mimics interactions with network services.

It operates protocol independently and heuristically

adjusts network addresses, ports, cookies.

The network of afﬁned honeypots (NoAH) is a

network of honeypots which occupies unused IP-

addresses on the internet. Automated attacks which

scan portions of the Internet’s IP-addresses are de-

tected by using Argos as a DTA honeypot. The results

from Argos are then converted into IDS signatures

and are intended to be used by third parties (Kontaxis

et al., 2010; Kohlrausch, 2009). NoAH allows for de-

tection of zero-day attacks by using DTA honeypots.

However, the system has a signiﬁcant drawback: IDS

signatures cannot be veriﬁed and discard the original

content of the attack. This disallows any alternative

vulnerability response process. Furthermore, mali-

cious IDS signatures could be injected into the sys-

tem by compromising Argos, which can have serious

ramiﬁcations. The possibility of such an attack is fair,

taking into account (1) that we have found real-world

attacks that have remained undetected by Argos, as

shown in Section 6.1, and (2) that there have been

vulnerabilities that have allowed a VM escape from

QEMU, the VM used by Argos.

Vigilante (Costa et al., 2005) is a proposed sys-

tem to stop worms and viruses from spreading in a

local network. Vigilante uses so called self-certifying

alerts (SCAs) as a means to transfer information

about a software vulnerability. SCAs are unique be-

cause they contain some parts of the exploit code it-

self. SCAs are generated when a host detects an attack

by using DTA or non-executable pages. Other hosts

then verify SCAs by executing modiﬁed parts of the

attack code in a virtual machine. If the exploit suc-

ceeds, the host sets a custom ﬁlter onto its network

interfaces to protect against the worm (Costa et al.,

2005).

In contrast to Scargos, Vigilante has fundamen-

tal disadvantages for sharing vulnerability informa-

tion globally:

A) Engineered for local networks – Vigilante was

engineered for usage in local networks/production

networks. The system uses ﬂooding to propagate vul-

nerability alerts across networks, which is unsuitable

for distribution across the internet. Additionally, Vig-

ilante modiﬁes the original attack before encoding it

as a SCA and veriﬁes it with further modiﬁcations.

Therefore, they cannot be processed by other services

because information about the original attack might

be missing.

SECRYPT2015-InternationalConferenceonSecurityandCryptography

370

B) Binary Instrumentation – Vigilante relies on bi-

nary instrumentation of its network facing services for

the usage of DTA. The drawback of this is that calls to

other programs or kernel vulnerabilities cannot be de-

tected because only the binaries of the network-facing

service are surveilled. In contrast, using honeypots

with in-built attack detection engines such as Argos

allows for full-system protection.

C) Limited to Memory-Based Detection Tech-

niques: Any detection mechanisms that Vigilante

uses must be translated prior to use into binary in-

strumentation algorithms. This essentially limits the

choices for Vigilante’s detection engines to memory

violation-detection techniques. In contrast, Scargos’

usage of packet-based SCAs allow for virtually any

detection engine.

3 ARCHITECTURE

The Scargos architecture is an approach to detect,

distribute and verify the existence of previously un-

known network-based attacks, conventionally called

zero-day attacks. By combining very accurate de-

tection engines such as dynamic taint analysis (DTA)

and honeypots with trafﬁc replaying, zero-day attacks

can be distributed and veriﬁed much faster than non-

automatic approaches. Figure 1 shows the relation-

ship between all of Scargos’ components. A prereq-

uisite for Scargos’ process is the detection of an at-

tack; the process continues with SCA publishing, dis-

tribution and veriﬁcation. Vulnerability response is

optional and depends on the need of the end user.

By using highly accurate detection engines such

as DTA, the detection component detects previously

unknown network-based attacks. The goal of the

detection component is not necessarily to gather as

many threats as possible but rather to gather the most

recently developed attacks. After a threat has been de-

tected, all attack information is decoded into a custom

format: packet-based self-certifying alerts.

New SCAs are submitted and aggregated in

SCA repositories. The SCA repository stores self-

certifying alerts and distributes them. User groups

which are interested in receiving the newest attacks

can subscribe to SCA repositories. For every unique

payload that the repository receives, subscribers re-

ceive a notiﬁcation.

Subscribers will usually verify a SCA before it is

further processed to initiate an individual vulnerabil-

ity response process, given the SCA is valid. SCA

veriﬁcation is done by leveraging the same methods

that were used for SCA generation, by using highly

accurate attack detection systems such as DTA. What

happens after a SCA has been veriﬁed depends on

the needs of the user group. There are different user

groups which may beneﬁt from using Scargos:

• Researchers: can study new threats to comple-

ment their vulnerability research for academia, se-

curity vendors, ISPs, institutes or corporations.

• Incident Response Teams: need to be aware of the

newest attacks in order to take appropriate action.

• IT-security Processes: Scargos can be operated in

a fully-automated fashion. As such, Scargos can

be part of a larger IT process to automate handling

of new vulnerabilities in a predeﬁned manner.

Detec-

tion

Pub-

lisher

Repos-

itory

Veri-

ﬁer

Re-

sponse

Figure 1: Scargos’ life cycle. Detection is usually handled

by a DTA honeypot and handling of vulnerability response

depends on the needs of the end user.

4 PACKET-BASED

SELF-CERTIFYING ALERTS

Packet-based SCAs store the transport-protocol pay-

load of all packets of an attack in binary format. Each

transport-protocol payload that has been made during

the conversation which led to the compromise is sep-

arated as an element in a list. As such, packet-based

SCAs lead to many simpliﬁcations when compared to

conventional SCAs.

In contrast to Vigilante, Scargos uses packet-

based SCAs, which preserve the original attack. This

requires us to use new approaches to verify an SCA.

We propose that veriﬁcation of an attack is done in

the same manner as that in which the original attack

compromised the system. Using this approach we al-

low for a custom vulnerability response process by

end users and any attack detection engine can be used

with Scargos.

SCAs always refer to a vulnerability of a speciﬁc

network-facing service. By using unique application

IDs, all mentioned components can address a speciﬁc

application. The IDs are assigned by each repository

individually and SCA publishers and subscribers need

to be aware of existing IDs for their surveilled appli-

cation or create a new entry, if one of the used appli-

cations has not been registered yet. Figure 2 shows

an SCA for WFTPD Server, which has been given the

application ID of 1 in this example.

Attacks on network-facing services are usually

conducted by sending a series of malicious packets.

Scargos:TowardsAutomaticVulnerabilityDistribution

371

Application ID: 1

Version: 3.23

Port: 21

Transport: TCP

Layer-5 PDUs: VVNFUiBhbm9ueW1vdXMNCg==\n

UEFTUyBtb3ppbGxhQGV4YW1wbGUuY29tDQo=\n

U0laRSAvHUc0JUIcs6kURvm4Q0sEtJE1t

. . .

Figure 2: An example SCA of the application WFTPD

Server. The attack consists of three Layer-5 PDUs, which

are encoded using Base64. The last PDU has been truncated

and is 727-Bytes long.

Weidong et. al (Cui et al., 2006) have demonstrated

that simple replaying of captured malicious trafﬁc is

sufﬁcient to trigger a vulnerability using Roleplayer

Replay. Given multiple conversations of a protocol,

dynamic ﬁelds of the target conversation are identi-

ﬁed and changed accordingly. The conversation is re-

played based upon a ”script” of a dialogue between

the two communicating systems (Cui et al., 2006).

In contrast to Roleplayer we developed Exact

Stream Replay as part of our contribution: Given only

the layer-5 PDU conversation, which led to the com-

promise of one host, a second host that has the same

vulnerability can be compromised by replaying the

entire conversation as it was previously recorded. It

requires no previous training, leads to smaller SCAs

and is for all of our tested attacks sufﬁcient to trigger

the vulnerability. While exact stream replay requires

dynamic replacement of ﬁelds such as URL, Host

name and IP source/destination, it seems to be bet-

ter suited for detection of zero-day attacks, because

roleplayer might fail to categorise conversations with

scrambled attack code. Also training might not be

available and can be manipulated.

5 GENERATING PACKET-BASED

SCAS

With the implementation of server architecture and

replay mechanisms being trivial, we now turn our at-

tention to the process of generating packet-based self-

certifying alerts with a suitable detection engine. As

discussed earlier, any type of highly accurate detec-

tion engine can be used to verify and generate non-

packet based SCAs. The process is divided into four

steps:

1. The detection engine alarms us of an intrusion;

2. We retrieve the packet which led to the intrusion;

3. Using this packet we reconstruct the entire attack;

4. Given the attack stream we marshal the data into

a SCA.

Argos provides an in-built functionality to ﬁnd the

malicious packet which was used to taint the mem-

ory. As this packet is in fact on the second layer

of the OSI stack we refer to it as an Exploit Layer-

2 Frame. Although this information is helpful to us

in some cases, we will show in our evaluation that

Argos is often unable to trace back to the malicious

packet. Consequently, we developed a combination

of algorithms to signiﬁcantly increase the probabil-

ity of ﬁnding the correct packet stream of an attack

by analysing two additional memory footprints of Ar-

gos: Compromised Memory Block and Jump Target

Memory Block.

6 EXPERIMENTAL RESULTS

This section evaluates Scargos by discussing a variety

of experiments. We implemented Scargos as a proto-

type on a x86 machine running GNU/Linux 3.5.0 and

using Argos 0.5.0 as the DTA honeypot. Experiments

were carried out on a machine with 4GB of RAM

and an Intel(R) Core(TM) i3 CPU M 370, which is

a 2.40GHz dual-core processor.

For our evaluation we chose to concentrate on one

of the most severe attacks: Remote Command Execu-

tion vulnerabilities on server applications. Scargos is

evaluated with 24 real attacks, which we describe in

more detail in the full version. We have included high

proﬁle attacks against Windows including vulnerabil-

ities MS03-026 (RPC) used in the Blaster Worm (Bai-

ley et al., 2005), MS04-011 (LSASS) used in the

Sasser (Sullivan, 2004) worm, and MS08-067 (Ne-

tAPI) used more recently by Conﬁcker (Faulhaber

et al., 2011). We expanded our selection of attacks by

including attacks on services such as Windows SMB,

HTTP and FTP.

6.1 Accuracy

A high accuracy rate is vital to ensure Scargos’

widespread use. The accuracy of Scargos is deﬁned as

its success rate in both correctly generating and ver-

ifying SCAs. When evaluating accuracy it is impor-

tant to look at all parts which can affect the result. In

Scargos, accuracy depends on three components:

• Argos: We use Argos as our DTA honeypot and

rely on the correct detection of attacks. An SCA

cannot be created, if attacks remain undetected.

• Packet Extraction: The SCA publisher relies on a

robust algorithm to extract the needed packets. If

SECRYPT2015-InternationalConferenceonSecurityandCryptography

372

packet extraction fails, no SCA can be published.

• Packet Replay: The SCA veriﬁer needs a replay

algorithm which can successfully replay SCAs

such that honeypots become compromised. If

packets cannot be replayed or are replayed in a

manner such that the attack fails, false negatives

occur because correct SCAs are not veriﬁed.

In our accuracy experiment, we tested all three

components and subcomponents by conducting 10

runs for each of our selected applications. The results

are shown in Table 1 and we analyze them as follows.

6.1.1 SCA Generation

Argos uses DTA which is known to have a very low

false negative rate. However, the results from Table 1

show that out of our 24 applications an attack against

Mercury Mail and Mdeamon Pro was not detected

by Argos and successfully circumvented its DTA. We

can not say with certainty why Argos did not detect

the attack, but can only suspect that it is either due to

under-tainting; a bug in the implementation or Argos

was trusting input which should not be trusted. Due

to the detection failure, we cannot create a SCA and

the subsequent steps fail accordingly.

In conclusion, we can say that the best approach

to ﬁnding a matching packet of the attacker’s conver-

sation is by combining all three methods in the fol-

lowing order: compromised memory block search,

jump target memory block search and exploit layer-

2 frame search. This way we only use the more risky

exploit layer-2 frame search when the other methods

have failed.

6.1.2 SCA Veriﬁcation

SCA veriﬁcation can only be successful if there exists

a SCA for the attack. In Table 1 we show that we are

always successful in triggering the vulnerability when

an SCA was available, which indicates that our replay

method works accurately.

6.2 Performance

In the following, we want to measure the performance

of verifying and generating packet-based SCAs as

well as the overall performance of Scargos. We

then compare our results with the results of Vigi-

lante (Costa et al., 2005). We deﬁne performance as

the speed in which a process ﬁnishes successfully.

We compiled the results of evaluating SCA gen-

eration and veriﬁcation in Table 2. When evaluating

exact stream replay, the results seem at ﬁrst glance

quite mixed and a general pattern is not easily found.

1,000

3,160

Kolibri

Dream FTP Server

Win.: MS08-067 (NetAPI)

Win.: MS04-011 (LSASS)

Sami FTP Server

WFTPD

WAR-FTPD

Win.: MS05-039 (PnP)

Apache HTTP Server

Xitami

FileCopa FTP Server

Win.: MS03-026 (RPC)

PCMan’s FTP Server

3CDaemon

freeFTPd

KNET

IntraSrv Web Server

Light HTTP Daemon

FreeFloat FTP server

freeSSHd

BadBlue Enterprise

Savant Web Server

6,094.11

2,990.15

2,902.54

2,739.64

2,268.10

2,185.15

2,046.17

2,025.04

1,832.23

1,725.20

1,687.96

1,665.41

1,606.09

1,566.56

1,559.19

1,428.57

1,357.55

1,324.04

1,276.32

1,265.24

1,199.13

1,120.87

Time of Scargos’ Lifecycle (ms)

Figure 3: Total time from SCA generation to successful ver-

iﬁcation including distribution. The results are the average

of 10 runs.

The application vulnerabilities that can be veriﬁed the

fastest targets FreeFloat FTP server, while the slow-

est is targeting Kolibri. At ﬁrst glance, there is not

much difference between the two SCAs, as both need

only one request to compromise the target. While

Kolibri’s SCA does carry twice as many bytes as

FreeFloat FTP server, other attacks such as the at-

tack against freeFTPd carry 20x more bytes and are

still much faster than Kolibri. This implies that there

is another factor that affects the performance of ex-

act stream replay, which is the performance of the at-

tacked applications and its time to process the attack.

Applications that should have a high performance

and behave quite uniformly are system services of-

fered by Windows itself. Yet, if we look at the per-

formance of these applications, we see quite a ﬂuctu-

ation. The reason for this lies in our implementation.

Exact stream replay waits 100ms after each request

was sent for a reply from the server. This enables

exact stream replay to be very accurate and protocol-

independent, since the attacked application transitions

into its next input state automatically. However, the

downside of a timeout is poorer performance.

Figure 3 show the results of our experiments for

Scargos’ full life cycle. It shows that Scargos oper-

ates fast. The majority of vulnerabilities of our appli-

cations could be veriﬁed and thus detected in under

2 seconds. On average, it takes 1993.88ms from the

ﬁrst detection of an attack by a honeypot until all in-

Scargos:TowardsAutomaticVulnerabilityDistribution

373

Table 1: Success or Failure of each component/subcomponent to process its previous input correctly. The symbol J signiﬁes

success, — signiﬁes failure. Failure in packet extraction is either due to the fact that no logs were generated successfully or

that no matching packet could be found in the session packet capture.

Packet Extraction Packet Replay

Application Name

Argos

DTA

Jump

Target

Memory

Block

Compro-

mised

Memory

Block

Exploit

Layer-2

Frame

Combination

Exact

Stream

Replay

Mercury/32 Mail

— — — — — —

Mdeamon PRO

— — — — — —

3CDaemon

J J — — J J

Dream FTP Server

J J — — J J

FileCopa FTP Server

J — J J J J

FreeFloat FTP server

J — J J J J

Sami FTP Server

J — J J J J

WAR-FTPD

J — J J J J

WFTPD

J — J J J J

Savant Web Server

J — J J J J

MS05-039 (PnP)

J J — — J J

PCMan’s FTP Server

J — J J J J

freeSSHd

J — J J J J

freeFTPd

J — J J J J

Apache HTTP Server

J J J — J J

BadBlue Enterprise

J J — — J J

Light HTTP Daemon

J — J J J J

KNET

J — J J J J

Kolibri

J — J J J J

Xitami

J — J J J J

MS03-026 (RPC)

J — J J J J

MS04-011 (LSASS)

J — — J J J

IntraSrv Web Server

J J J — J J

MS08-067 (NetAPI)

J — J J J J

terested SCA veriﬁers have veriﬁed the vulnerability

on their systems. In the worst case, the process takes

6094.11ms (Kolibri), which should still give enough

leeway to safely initiate a vulnerability response pro-

cess.

6.2.1 Comparison to Vigilante

In this section we want to compare our solution to

Vigilante in terms of performance. Scargos and Vig-

ilante are not easily comparable because Vigilante’s

performance is worse the bigger the SCA ﬁle size,

while Scargos’s performance is mainly inﬂuenced by

the number of layer-5 PDUs. The performance of the

attacked application does also play a role for the per-

formance of both frameworks. Additionally, compari-

son is hampered because Vigilante is not open-source

or otherwise available.

In the original paper by Costa et. al (Costa et al.,

2005), only three applications were evaluated. All

three were either system services or a well-known

windows application: Microsoft SQL Server, Mi-

crosoft IIS Server and Microsoft Windows (MS03-

026 (RPC)). To enable a fair comparison we se-

lected equally well-known applications and service

vulnerabilities: Apache HTTP Server, Microsoft Win-

dows MS03-026 (RPC), Microsoft Windows MS04-

011 (LSASS), Microsoft Windows MS05-039 (PnP)

and Microsoft Windows MS08-067 (NetAPI). We

compared the total time needed for SCA generation

and veriﬁcation in relation to SCA ﬁle size. The re-

sults are depicted in Figure 4.

We can see that Vigilante performs better for

smaller SCA ﬁle sizes while Scargos performs bet-

ter for bigger ﬁle sizes. Even taking into account

that the SCA ﬁle size of Vigilante is truncated and

in fact bigger than in the graph shown (reduction of

about 20%), Scargos outperforms Vigilante. Our re-

sults from Table 2 and the data given by Costa et.

al (Costa et al., 2005) indicate that Vigilante performs

consistently better than Scargos in SCA veriﬁcation,

while SCA generation takes much more time in Vigi-

SECRYPT2015-InternationalConferenceonSecurityandCryptography

374

Table 2: Performance of stream extraction and exact stream replay in relation to number and size of layer-5 PDUs (L5-PDUs).

Application Name

Number

of L5-

PDUs

Length

of all

L5-PDUs

(bytes)

SCA Generation

(ms)

SCA Veriﬁcation

(ms)

3CDaemon 1 2055 927.12 171.08

Dream FTP Server 1 1049 488.5 1937.52

FileCopa FTP Server 3 815 475.34 238.68

FreeFloat FTP server 1 571 684.73 126.47

Sami FTP Server 1 567 696.28 822.31

WAR-FTPD 1 1031 697.91 890.91

WFTPD 3 579 471.96 727.71

Savant Web Server 1 401 487.75 164.26

Win.: MS05-039 (PnP) 13 3266 487.42 442.1

PCMan’s FTP Server 1 5007 839.07 297.76

freeSSHd 1 20272 504.1 241.8

freeFTPd 1 20609 500.86 229.17

Apache HTTP Server 1 7145 851.3 498.38

BadBlue Enterprise 1 4285 537.43 185.54

Light HTTP Daemon 1 782 702.87 128.81

KNET 1 1039 716.1 242.09

Kolibri 1 1013 485.1 5103.76

Xitami 1 857 854.32 401.56

Win.: MS03-026 (RPC) 2 2272 488.12 207.06

Win.: MS04-011 (LSASS) 27 11287 980.18 494.18

IntraSrv Web Server 1 4792 505.89 180.28

Win.: MS08-067 (NetAPI) 36 7711 760.74 754.17

5,000

10,000

1,000

2,000

3,000

695.18

929.52

1,349.68

1,514.91

1,474.36

224

2,742

SCA Filesize (Bytes)

Time for SCA Generation and Veriﬁcation (ms)

Scargos

Vigilante

Figure 4: Comparing Vigilante’s and Scargos’ performance

for the combined times of SCA generation and veriﬁcation

excluding distribution.

lante than in Scargos.

Although both data sets are hard to compare, an

observation can be made that in our data set, the

worst-case performance in Scargos is about 45% bet-

ter than that of Vigilante, while Vigilante has a better

best-case performance. Due to space limitations, ad-

ditional results are presented in the full version.

7 CONCLUSION

In this work, we presented Scargos, a framework to

distribute vulnerabilities in seconds without needing

a central authority. We proposed packet-based SCAs,

which are engineered to be distributed in the inter-

net and differ from previously presented SCAs due

to the fact that an attack is in its original form, in

packets; furthermore, they are independent from the

detection engine used and allow for a custom vul-

nerability response process. Packet-based SCAs re-

Scargos:TowardsAutomaticVulnerabilityDistribution

375

quire different veriﬁcation methods compared to pre-

viously known approaches. We presented the replay

mechanism “exact stream replay” as a way to verify

SCAs. Our proof-of-cocept implementation used the

DTA honeypot Argos and it was evaluated with 24

real-world attacks using exact stream replay. SCAs

were successfully generated and veriﬁed for 22 of

these attacks (the remaining 2 could not be detected

by Argos), and the overall life cycle from detection to

veriﬁcation was shown to be on average less than 2

seconds. Finally, we showed that packet-based SCAs

perform better for bigger SCA ﬁle sizes and seem to

have a much better worst-case performance than con-

ventional SCAs. For future work we plan to investi-

gate accuracy and performance of client-side attacks

and attacks on newer operating systems and mobile

devices.

REFERENCES

Bailey, M., Cooke, E., Jahanian, F., Watson, D., and

Nazario, J. (2005). The blaster worm: Then and now.

Security & Privacy, IEEE, 3(4):26–31.

Bilge, L. and Dumitras, T. (2012). Before we knew it: an

empirical study of zero-day attacks in the real world.

In Proceedings of the 2012 ACM conference on Com-

puter and communications security, pages 833–844.

ACM.

Bosman, E., Slowinska, A., and Bos, H. (2011). Minemu:

The worlds fastest taint tracker. In Recent Advances

in Intrusion Detection, pages 1–20. Springer.

Clause, J., Li, W., and Orso, A. (2007). Dytan: a generic

dynamic taint analysis framework. In Proceedings of

the 2007 international symposium on Software testing

and analysis, pages 196–206. ACM.

Costa, M., Crowcroft, J., Castro, M., Rowstron, A., Shan-

non, C., and Brown, J. (2004). Can we contain inter-

net worms. In Proceedings of the 3rd Workshop on

Hot Topics in Networks (HotNets-III). Citeseer.

Costa, M., Crowcroft, J., Castro, M., Rowstron, A., Zhou,

L., Zhang, L., and Barham, P. (2005). Vigilante:

End-to-end containment of internet worms. In ACM

SIGOPS Operating Systems Review, pages 133–147.

ACM.

Crandall, J. R. and Chong, F. T. (2004). Minos: Control

data attack prevention orthogonal to memory model.

In Microarchitecture, 2004. MICRO-37 2004. 37th In-

ternational Symposium on, pages 221–232. IEEE.

Cui, W., Paxson, V., Weaver, N., and Katz, R. H. (2006).

Protocol-independent adaptive replay of application

dialog. In NDSS.

Faulhaber, J., Lambert, J., Probert, D., Srinivasan, H., Fel-

stead, D., Lauricella, M., Rains, T., and Stewart, H.

(2011). Microsoft security intelligence report. Techni-

cal Report 11, Microsoft Corporation, Redmond, WA

98052-6399.

Kohlrausch, J. (2009). Experiences with the noah hon-

eynet testbed to detect new internet worms. In IT Se-

curity Incident Management and IT Forensics, 2009.

IMF’09. Fifth International Conference on, pages 13–

26. IEEE.

Kontaxis, G., Polakis, I., Antonatos, S., and Markatos,

E. P. (2010). Experiences and observations from the

noah infrastructure. In Computer Network Defense

(EC2ND), 2010 European Conference on, pages 11–

18. IEEE.

Kreibich, C. and Crowcroft, J. (2004). Honeycomb: cre-

ating intrusion detection signatures using honeypots.

ACM SIGCOMM Computer Communication Review,

34(1):51–56.

Newsome, J. and Song, D. (2005). Dynamic taint analysis

for automatic detection, analysis, and signature gener-

ation of exploits on commodity software. In Network

and Distributed System Security Symposium (NDSS

2005).

Portokalidis, G., Slowinska, A., and Bos, H. (2006). Argos:

an emulator for ﬁngerprinting zero-day attacks for ad-

vertised honeypots with automatic signature genera-

tion. In ACM SIGOPS Operating Systems Review,

pages 15–27. ACM.

Provos, N. (2003). Honeyd-a virtual honeypot daemon. In

10th DFN-CERT Workshop, Hamburg, Germany, vol-

ume 2.

Provos, N. and Holz, T. (2009). Virtual honeypots: from

botnet tracking to intrusion detection. Addison-

Wesley Professional, third edition.

Suh, G. E., Lee, J. W., Zhang, D., and Devadas, S. (2004).

Secure program execution via dynamic information

ﬂow tracking. In ACM SIGPLAN Notices, pages 85–

96. ACM.

Sullivan, B. (2004). Sasser infections begin to subside.

NBC News. http://www.nbcnews.com/id/4890780/ns/

technology and science-security/t/sasser-infections-

begin-subside/#.UhANu3byrUI.

Venkataramani, G., Doudalis, I., Solihin, Y., and Prvulovic,

M. (2008). Flexitaint: A programmable accelerator

for dynamic taint propagation. In High Performance

Computer Architecture, 2008. HPCA 2008. IEEE 14th

International Symposium on, pages 173–184. IEEE.

Willems, C., Holz, T., and Freiling, F. (2007). Toward au-

tomated dynamic malware analysis using cwsandbox.

Security & Privacy, IEEE, 5(2):32–39.

SECRYPT2015-InternationalConferenceonSecurityandCryptography

376
