Surﬁng Big Data Warehouses for Effective Information Gathering

Nunziato Cassavia

, Pietro Dicosta

, Elio Masciari

and Domenico Sacc

2,3

ICAR-CNR, Rende, Italy

DIMES UNICAL, Rende, Italy

Centro di Competenza ICT-SUD, Rende, Italy

NTT DATA, Rende, Italy

Keywords:

Big Data, Solr, Clustering.

Abstract:

Due to the emerging Big Data paradigm traditional data management techniques result inadequate in many real

life scenarios. In particular, OLAP techniques require substantial changes in order to offer useful analysis due

to huge amount of data to be analyzed and their velocity and variety. In this paper, we describe an approach for

dynamic Big Data searching that based on data collected by a suitable storage system, enriches data in order

to guide users through data exploration in an efﬁcient and effective way.

1 INTRODUCTION

Nowadays, the availability of huge amounts of

data from heterogeneous sources, exhibiting differ-

ent schemes and formats and being generated at very

high rates, led to the deﬁnition of new paradigms for

their management – this problem is known with the

name Big Data (uno, 2008; due, 2010; tre, 2011;

Agrawal et al., 2012; Lohr, 2012; Manyika et al.,

2011; Noguchi, 2011a; Noguchi, 2011b; Labrinidis

and Jagadish, 2012). As a consequence of new per-

spective on data, many traditional approaches to data

analysis result inadequate both for their limited effec-

tiveness and for the inefﬁciency in the management of

the huge amount of available information. Therefore,

it is necessary to rethink both the storage and access

patterns to big data as well the design of new tools for

data presentation and analysis. In particular, OLAP

analysis tools require suitable adjustments in order to

work for big data processing effectively. Indeed, it

is crucial, during the construction and analysis of a

data warehouse, to exploit ad-hoc tools that allow an

easy and fast search of data stored in several nodes

distributed over the storage layer.

More in detail, while building a data warehouse

for Big Data, the key to a successful analysis (i.e. a

fast and effective one) is the availability of good in-

dexing mechanisms. Therefore, an additional cost in

terms of storage space consumption needed for stor-

ing the appropriate indices is to be taken into account.

It is worth noticing that the problem of fast ac-

cessing relevant pieces of information arises in sev-

eral scenarios such as world wide web search, e-

commerce systems, mobile systems and social net-

works analysis to cite a few.

Successful analyses for all the application con-

texts rely on the availability of effective and efﬁcient

tools for browsing data so that users may eventually

extract new knowledge which s/he was not interested

initially.

In this paper, we shall describe the architecture of

a system for full-text search, capable to operate over

Big Data and offering the chance to “surf” the data in

a simpliﬁed manner, while keeping traditional opera-

tors available in an OLAP based system such as roll-

up, drill-down, slice and dice. Moreover, we over-

come limitations of traditional OLAP analysis sys-

tems, as in our system analysis dimensions are not

limited to those deﬁned a priori by the warehouse

architect, but they are dynamically added by induc-

ing them from the data. This enrichment of the ini-

tial dataset is referred to as Data Posting and can be

achieved by suitable data mining techniques, either

in batch mode (i.e. taking into account the whole

dataset) or on-the-ﬂy by limiting the analysis to the

result of current search executed by users.

Our System in a Nutshell. Building a system for

Big Data management is a complex activity as many

architectural choices are affected by the data at hand.

In this respect, our system is quite intriguing as we ex-

ploited several utilities in order to make the data anal-

ysis step easier also for non expert users. Moreover,

373

Cassavia N., Dicosta P., Masciari E. and Saccà D..

Surﬁng Big Data Warehouses for Effective Information Gathering.

DOI: 10.5220/0005579403730377

In Proceedings of 4th International Conference on Data Management Technologies and Applications (KomIS-2015), pages 373-377

ISBN: 978-989-758-103-8

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

we built our prototype using quite powerful tools that

are either open source or freely available for research

purposes.

First of all, we used Hbase as the basic tool for

data management as it is highly scalable and fault-

tolerant – Hbase is an open source, non-relational,

distributed database system, modeled after Google’s

BigTable and developed as part of Apache Software

Foundation’s Apache Hadoop project. Moreover, as

it is ﬂexible as not tied to a ﬁxed scheme, we can

add new columns (attributes) to predeﬁned family col-

umn tables without any interruption in service deliv-

ery. The latter feature has been crucial for data en-

richment as it could happen that mining results could

affect only a limited portion of the overall database.

Moreover, it enables fast reading of data, thus making

the querying phase quite efﬁcient. Unfortunately, for

full-text search, response times are still too high thus

limiting the usability of the system; therefore, we im-

plemented a specialized index by using Solr, which

is an open source enterprise search platform from the

Apache Lucene project, whose major features include

full-text search, hit highlighting, faceted search, real-

time indexing, dynamic clustering, database integra-

tion, NoSQL features and rich document (e.g., Word,

PDF) handling.

The Solr’s feature of supporting faceted naviga-

tion turned out to be very useful for our purposes:

facets are generated for modeling data dimensions

that allow users to drill-down or roll-up data. Further-

more, facets allow user suggestions based on previous

search performed. We fully exploited the SolrCloud

release that enjoys enhanced highly scalable and fault

tolerant features and empowers distributed indexes

as it is based on HDFS as ﬁle system. We used

Zookeeper (another software project of the Apache

Software Foundation), for enabling distributed con-

ﬁguration and synchronization services as well as

naming registry for large distributed systems. We pin-

point that, as Hbase uses the same services, the over-

all architecture turned out to be rather powerful and

ﬂexible.

As we want to achieve full integration between

Hbase and SolrCloud, we need to take into account

multivalued attribute management. Indeed, Solr-

Cloud provides a support for multivalued storage,

whereas for Hbase we need to suitably pre-elaborate

them (e.g., by adding a colum sufﬁx). As an example,

consider a hotel having several email contacts. Using

Hbase we can model this as follows:

columnFamily anagra fic in f o[email

value1 >,email

:< value2 >,· · ·

:< valuen >].

On the contrary, SolrCloud allows the deﬁnition

of a multivalued ﬁeld as follows:

< fieldname = “email”type = “string”indexed =

“true”multivalued = “true”stored = “true/ >

In order to guarantee full integration of both sys-

tems we need to provide a mapping between the

two systems that can be performed by Morphline, a

new command-based framework that simpliﬁes data

preparation for Apache Hadoop workloads. The con-

ﬁguration ﬁle (named morphline.conf) will contain

commands like the one reported in the following:

extractHBaseCells{mappings :

{inputColumn : ”columnFamily anagra f ic in f o :

email”out putField : ”email”type : stringsource :

value}

In order to speed-up the index construction we ex-

ploit map-reduce as it allows the batch construction of

the overall index by accessing all nodes in the cluster.

However, in some application scenarios (e.g.

monitoring systems) we need a (near) real time index-

ing that can be done by the Lily Indexer that provides

the ability to quickly and easily search for any content

stored in HBase by indexing HBase rows into Solr,

without writing a line of code. Indeed, it is fully com-

plaint with several extraction tools like Flume that is

a distributed Apache servicee for efﬁciently collect-

ing, aggregating and moving large amounts of stream-

ing data ﬂows so that data are available for searching

immediately after their insertion in the data storage

layer.

2 BACKGROUND ON COMPLEX

SEARCHING

A typical example of system devoted to complex data

querying is represented by search engines. The re-

sults of a search returned by the engine cannot be con-

sidered as a custom map built by query results but,

based on them, additional knowledge about data be-

ing queried can be learnt by iterative reﬁnement of

search dimensions and parameters as reported in Fig-

ure 1.

In this process, the type of research being per-

formed has to be taken into account. Indeed, there

is a big difference between the simple search of

well-deﬁned terms and the dynamic learning by ex-

ploratory research. Obviously enough, in the ﬁrst

case, a search engine such as Google, is able to give

Figure 1: Learining By Results.

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications

374

results in less than a second. As a matter of fact, due

to its quick result presentation, many users go through

Google even if they know the URLs of the resources

that are interested in.

However, in some cases users do not know exactly

how to ﬁnd the desired information about an object

(e.g. a book). In this case the Amazon model depicted

in Figure 2 is more suitable. More in detail, Ama-

zon search tools, includes the product categories and

some recommender systems, making the user search

experience quite interactive and iterative. In a sense,

intermediate results guide users to a better deﬁnition

of target information.

Furthermore, search engines usually allow non-

structured queries (known as “ranked retrieval”)

whose results are sorted by some relevance rank dis-

regarding their precision. As a matter of fact, this

kind of queries is easier to pose by users compared

to boolean expressions, but they can cause the setting

of a not precise evaluation criteria for document com-

parison.

As a possible improvement, some search en-

gines like Yahoo! Directory, offer context search.

More in detail, the contents of a directory is orga-

nized hierarchically, the user is guided to a subset

of documents potentially related to information be-

ing searched avoiding the possibility to pose free

text queries. In this respect, users re-think and re-

ﬁnes their needs, thus learning the adjustments to the

search being performed by exploiting the available

choices. To better understand how directory navi-

gation works, consider how accommodation booking

portals work. They offer a hierarchical navigation

systems, i.e. from the home page, user can choose

the desired country, then s/he can specify the city and

ﬁnally the type of structure s/he is interested in. This

navigation model suffers a great limitation due to tax-

onomy speciﬁcation. Indeed, taxonomy speciﬁed by

the service designer may not meet user needs.

2.1 The Real-time faceted Navigation

It is possible to overcome the limits of the types of

search tools explained above by faceted navigation

that helps users in the information “surﬁng” process.

Consider the faceted view of a search engine de-

Figure 2: Amazon search.

picted in Figure 3. Starting the search from the home

page, the user has the opportunity to search informa-

tion about the country and about several attributes of

the structures pertaining to the search. For exam-

ple, s/he can browse city (Cosenza,Scilla,...)), the

structure type (Hotel,B&B,apartment,... ), their rat-

ing (2, 3,4,...). As a feature is selected, the user can

reﬁne the search by selecting another attribute among

those available for the current selection. During the

browsing process, it is also possible to discard fea-

tures no longer relevant to the search (i.e. s/he can

perform dimensional ﬁltering). This iterative process

guides the user through the accommodation search by

selecting a custom path instead of a hierarchy pro-

vided by the service designer.

We stress that efﬁcient faceted navigation (i.e.

easy to use and providing access to richer informa-

tion) relies on the availability of some features that

are common to the objects being searched. In a sense,

it is impossible to implement faceted navigation for a

site that sells products not sharing at least a category.

The faceted search pattern described above can be

enhanced by exploiting data mining approaches for

information enrichment. To this end we propose a

novel approach to Data Posting, i.e. based on raw

data and ontologies we can add new dimensions in-

duced by analyzing search queries and results. More

in detail, we store query result as a materialized data

cube to be used for further search. These data will

be used as training set for an clustering algorithm that

will group query results in a unsupervised way. The

obtained clustering will be used for extracting fea-

tures relevant to the query that have not been speciﬁed

by the user neither have been considered for build-

ing the query result. As an example consider a user

searching for a restaurant in Rome. S/he will type

the query “restaurant in Rome” (also many search en-

gines will suggest this statement). Traditional search

results then will include restaurants located in the city

along with their rank. Indeed, by exploiting our ap-

proach we are able to suggest users a further interest-

ing parameter (i.e. analysis dimension) as the rank

of apetizers, main courses and sweets thus allowing a

more focused search.

Data Posting was ﬁrst introduced by (Sacc

Figure 3: Faceted navigation example.

SurfingBigDataWarehousesforEffectiveInformationGathering

375

and Serra, 2013). The data posting setting

(S,D,T, Σ

,Σ

) consists of a source database schema

S, a domain database scheme D, a target ﬂat fact table

T , a set Σ

of source-to-target count constraints and a

set Σ

of target constraints. The data posting problem

associated with this setting is: given ﬁnite source in-

stances I

for S and I

for D, ﬁnd a ﬁnite instance I

for T such that hI

i satisﬁes both Σ

and Σ

The main difference w.r.t. classical data exchange

is the presence of the domain database scheme that

stores “new” values (dimensions) to be added while

exchanging data. The actual values to be assigned to

dimensions are deﬁned by means of the target con-

straints. In a motto we can say that “data posting is

enriching data while exchanging them”. Next section

is devoted to the description of our prototype for Data

Posting.

3 A SYSTEM FOR BIG DATA

Our system, developed as part of DICET-INMOTO

project, is tailored for providing users a ﬂexible tool

for full-text search, that is interactive, scalable on

Tourism Big Data and dynamic. To this end we

need to exploit suitable indexing and data manage-

ment strategies. It is based on several open source

tools as Apache Hadoop, Flume, HBase, Solr, Lily

HBase Indexer and Hue supporting our Data Posting

strategy as depicted in Figure 4.

Figure 4: System Architecture.

As tourist big data arrive in a streaming way, we

need to properly collect them by Flume that is a reli-

able and distributed service to efﬁciently collect, ag-

gregate and forward huge amounts of data. It of-

fers a ﬂexible architecture for data streaming provid-

ing a fault tolerant system based on a conﬁgurable

reliability mechanism. Once data are gathered by

Flume module, they are pre-elaborated “on the ﬂy” by

Morphline and stored in a data warehouse stored on

HBase. Morphline module is devoted to data cleaning

and data mapping on the column set in the datastore.

For querying purposes we provide two indexing

strategies, static and dynamic. We provide both fea-

tures in order to deal with all the possible use cases.

More in detail, if data pertaining the query have been

stored in the data warehouse static indexing turns to

be more effective. We perform this operation by Map

Reduce Indexer that takes advantage of the clustered

structure of the datastore. On the contrary, if new data

that have to be inserted into the data warehouse, we

take advantage of near real time indexing provided by

Lily framework.

In order to allow efﬁcient on line analysis when

performing full-text search, we exploit Apache Solr

system. It allows searching for keywords in any ﬁeld

that was previously indexed and allows to display

faster the documents matching the query. Moreover,

Solr allows several useful operations as ﬁeld facets,

range queries and pivot facets, that can be used for

providing user the classical OLAP operators (slice &

dice, drill-down, roll-up, pivoting) thus making Solr

an excellent real-time analysis engine for text docu-

ments.

As an example, in a website, the log ﬁles and addi-

tional information on user behavior can be indexed by

Solr in order to allow (timed) range queries for a key-

word. It is also possible to build information graphs

containing aggregate information, such as the growth

over time of the number of registered users or trans-

actions aggregated by type.

Furthermore, we also exploit Carrot2 (a Solr plu-

gin) in order to make the search even more effective

as it provides real time clustering features that are ex-

ploited to derive new dimensions for analyzing data.

More in detail, based on the clusters obtained by Car-

rot2, we add new categories to the data warehouse that

will be exploited for guiding user through the search.

In order to display search results, we exploit Hue

features. The latter is a software that perfectly ﬁts

the Hadoop ecosystem. It offers a user friendly in-

terface shown in Figure 5, that can be customized for

different user categories, e.g. end-users and domain

experts. In particular, end-users are allowed to search

only data indexed by Solr, while domain experts may

also view/edit data available in the data warehouse

(including those induced by the system automatically)

and add new dimensions.

Figure 5: Hue interface.

For the sake of efﬁciency, we prevent the rever-

sal of the entire data warehouse within Solr. More in

detail, we distinguish between indexed data used to

search for documents and data stored on Solr which

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications

376

can be accessed directly avoiding the access to raw

data. In order to improve system performances we

keep the minimum amount of information on Solr in-

dex while we allow access to the complete informa-

tion by REST API service

Finally, the architecture reported in Figure 4, of-

fers two solutions for the different data to be man-

aged: persistent data and streaming data. In Figure 4

we denote by blue full arrows the components that are

used for data streams processing, while the ones de-

noted by red dashed arrows deal with persistent data.

Indeed, the overall architecture is composed of

two modules: Module 1 for Near Real Time process-

ing and Module 2 for Batch processing whose features

are described below:

1. Near Real Time processing is tailored for end-

users. This module allows:

• Full-text search, interactive, scalable and ﬂexi-

ble indexing system;

• Discovering new dimensions of analysis based

on result search logs;

• Static faceted navigation of categories deﬁned

a priori and dynamic faceted navigation by ex-

ploiting dimensions induced on line by cluster-

ing algorithms.

2. Batch processing is tailored for expert users. This

module allows:

• Off-line discovery (i.e. based on the whole

dataset) and storage of new dimensions for the

data warehouse by a customizable result visu-

alization;

• Selection of the mining tool for data analysis

(we actually implemented clustering and clas-

siﬁcation features) based on the scenario to be

analyzed;

4 CONCLUSION

Big data analysis is a challenging task as we need

to take into account the velocity, variety and volume

of information to be analyzed. Indeed, such features

heavily inﬂuence the design of a system for big data

analysis. In this respect, we analyzed several de-

sign options in order to implement a prototype for

Big Data Warehousing offering advanced search func-

tions. Our prototype has been used for tourism big

data analysis both by end-users and domain experts.

Results on the usability of the system were quite sat-

isfactory. We are now gathering real data form public

We allow access by HBase Rest Server

sources (Facebook, Twitter, Yelp, Tripadvisor) in or-

der to perform a detailed analysis of the accuracy we

can obtain by our prototype.

ACKNOWLEDGEMENTS

This work was supported by MIUR Project

PON04a2 D DICET INMOTO Organization

of Cultural Heritage for Smart Tourism and REal

Time Accessibility (OR.C.HE.S.T.R.A.)

REFERENCES

(2008). Big data. Nature.

(2010). Data, data everywhere. The Economist.

(2011). Drowning in numbers - digital data will ﬂood

the planet - and help us understand it better. The

Economist.

Agrawal et al., D. (2012). Challenges and opportunities

with big data. A community white paper developed

by leading researchers across the United States.

Labrinidis, A. and Jagadish, H. V. (2012). Challenges and

opportunities with big data. PVLDB, 5(12):2032–

2033.

Lohr, S. (2012). The age of big data. nytimes.com.

Manyika, J., Chui, M., Brown, B., Bughin, J., Dobbs, R.,

Roxburgh, C., and Byers, A. H. (2011). Big data: The

next frontier for innovation, competition, and produc-

tivity. McKinsey Global Institute.

Noguchi, Y. (2011a). Following digital breadcrumbs to big

data gold. National Public Radio.

Noguchi, Y. (2011b). The search for analysts to make sense

of big data. National Public Radio.

Sacc

a, D. and Serra, E. (2013). Data posting: a new fron-

tier for data exchange in the big data era. In Bravo, L.

and Lenzerini, M., editors, Proceedings of the 7th Al-

berto Mendelzon International Workshop on Founda-

tions of Data Management, Puebla/Cholula, Mexico,

May 21-23, 2013., volume 1087 of CEUR Workshop

Proceedings. CEUR-WS.org.

SurfingBigDataWarehousesforEffectiveInformationGathering

377
