Recommending Access Policies in Cross-domain Internet

Nuno Bettencourt

, Nuno Silva

and Jo

ao Barroso

GECAD and Instituto Superior de Engenharia, Instituto Polit

ecnico do Porto, Porto, Portugal

INESC TEC and Universidade de Tr

as-os-Montes e Alto Douro, Vila Real, Portugal

Keywords:

Recommendation, Access Policy, Unknown-unknown.

Abstract:

As the amount of content and the number of users in social relationships is continually growing in the Inter-

net, resource sharing and access policy management is difﬁcult, time-consuming and error-prone. In order to

aid users in the resource-sharing process, the adoption of an entity that recommends users with access poli-

cies for their resources is proposed, by the analysis of (i) resource content, (ii) user preferences, (iii) users’

social networks, (iv) semantic information, (v) user feedback about recommendation actions and (vi) prove-

nance/traceability information gathered from action sensors. A hybrid recommendation engine capable of

performing collaborative-ﬁltering was adopted and enhanced to use semantic information. Such recommenda-

tion engine translates user and resources’ semantic information and aggregates those with other content, using

a collaborative ﬁltering technique. Recommendation of access policies over resources promotes the discov-

ery of known-unknown and unknown-unknown resources to other users that could not even know about the

existence of such resources. Evaluation to such recommender system is performed.

1 INTRODUCTION

The Internet has recently grown to over three bil-

lion users. On certain social networks, more than

two hundred thousand photographs are uploaded ev-

ery minute. Such rate of content generation and social

network building make the task of sharing resources

more difﬁcult for users.

Standard resource sharing in the Internet is

achieved by granting users with access to resources,

but they are commonly restricted to resources hosted

on a single domain. Access policies are consequently

issued to users registered on the same domain. Shar-

ing resources with users that are not registered on

the same domain has proven insecure or difﬁcult to

achieve. Referencing and accessing resources pro-

tected by access policies in other web domains (apart

from where they are hosted) is practically unsup-

ported by existing web applications.

In cross-domain sharing, such difﬁculties encour-

age:

• the cloning of the resource to different domains;

• the multiplication of users’ internal and social

identity.

The goal of this work is to provide a seamless

cross-web-domain infrastructure that provides secure,

rich and supportive resource managing and sharing

processes. It proposes a distributed and decentralised

architectural model by fostering cross-web-domain

resource sharing, resource dereferencing and access

policy management. It adopts the principles of the

Web and of World Wide Web Consortium (W3C)

standards or recommendations.

In order to support user management of access

policies, a recommendation provider capable of rec-

ommending access policies to users is included in the

architecture (section 2). The proposed recommen-

dation engine features a hybrid engine consisting on

the combination of different ﬁltering techniques that

exploit user proﬁles, their social networks, resources

content, (distributed) provenance and traceability in-

formation (section 3).

A prototype to demonstrate the infrastructure’s

feasibility was designed and implemented to prove

that the architecture model can be deployed in a real

world scenario. The hybrid recommendation process

was tested using an available data set where informa-

tion was interpreted to simulate human behaviour in

the system (section 4 and 5).

Finally, the last section gives an overview of the

proposed solution and suggests further research.

Bettencourt, N., Silva, N. and Barroso, J..

Recommending Access Policies in Cross-domain Internet.

In Proceedings of the 7th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2015) - Volume 3: KMIS, pages 50-61

ISBN: 978-989-758-158-8

2 BACKGROUND KNOWLEDGE

This work allows the recommendation of access poli-

cies to resource authors. This section provides an in-

sight about recommendation processes, resources that

are currently not easily shared because of access pol-

icy restrictions and Authentication, Authorisation and

Accountability (AAA) architectures.

2.1 Recommendation

Recommendation is something that has become part

of everyone’s daily lives. To reduce uncertainty and

help coping with information overload when trying

to choose among various alternatives, people usually

rely on suggestions given by others, which can be

given directly by recommendation texts, opinions of

reviewers, books, newspapers, etc. (Shardanand and

Maes, 1995).

Users are willing to follow others’ recommenda-

tions and to give back recommendations to the com-

munity.

When deciding between which product to buy,

users want to be able to read opinions from other buy-

ers (MacKinnon, 2012) and tend to follow them as

they are considered experienced users (Wasserman,

2012).

Currently, recommendation is widely used in elec-

tronic commerce (Adomavicius and Alexander, 2011;

Linden et al., 2003; Schafer et al., 2001). In e-

commerce web applications, trust is based on the

feedback of previous online interactions between

members as shown by the authors in (Resnick et al.,

2000; Ruohomaa et al., 2007).

In the Internet perspective, there are other areas

in which recommendation is also relevant, such as re-

source recommendations on websites (e.g. Pinterest),

documents (e.g. Slideshare, Pocket) and users (e.g.

LinkedIn, Facebook, Google+).

With the Internet’s continual evolution, recom-

mender systems have also evolved. While initially

recommendation was only used in e-commerce web-

sites for recommending similar or most bought items

to users, nowadays the process of recommendation

has improved such that the recommendation of friend-

ship and/or relationship between users of a social net-

work has become a quite common task on typical so-

cial web applications.

Every recommender system is typically based on

two elements:

User/Item Actions. Represents user actions upon

items and may include a possible rating.

Item Similarities. Represents the associations be-

tween users or between items. Some recom-

Low High

Low

High

Knowledge Awareness

Location Awarenes

Known

Unknown

Known

Unknown

Known

Unknown

Figure 1: Location Awareness vs. Knowledge Awareness.

mender systems provide algorithms to calculate

item similarity during the recommendation pro-

cess, while others even allow the usage of external

pre-computed item similarities during the process.

The output of a recommender system is a scored

list of recommended items that are recommended to

a list of users. The maximum number of retrieved

recommendations is speciﬁed by the value of AT.

A systematisation of the user’s consciousness

about resources is presented next, which will be help-

ful to perceive the importance of the recommendation

process in the scope of this work.

2.2 Known-known, Unknown-unknown

A user’s consciousness about something can be char-

acterised according to two dimensions: perception of

reality and reality of perception.

Applying such rationale to resources’ location and

users’ knowledge awareness of those, a particular re-

source can be classiﬁed as (cf. Figure 1):

Known-knowns. These are resources whose exis-

tence and location are known by the user e.g. a

photograph is taken of a person, and the person

knows about its existence and its location.

Known-unknowns. These are resources a user

recognises he/she knows nothing about until

he/she ﬁnds them e.g. a person ﬁnds a photo by

chance on which he/she appears, knows its loca-

tion but was not aware of its existence.

Unknown-knowns. These are resources that the user

does not know how to ﬁnd, but knows about their

existence, e.g. a photo is taken of a person, the

person knows about its existence but does not

Recommending Access Policies in Cross-domain Internet

know about its location. With time and searching

investment the person might get to its location.

Unknown-unknowns. These are resources whose

existence the user is not even aware of e.g. a photo

is taken of a person but the person does not know

its existence or where to locate it. These type of

resources would only come up on searches related

to the user if contextual information is used.

This classiﬁcation emphasises the fact that the

same existing information is perceived differently by

users. There are different reasons for these different

perceptions, including (i) access policy restrictions

and (ii) information overload. Recommender systems

are conceptually ﬁt to help users perceive resources as

(useful) known-knowns.

Access policy restrictions prevent users to access

resources that would be of their interest. The recom-

mender system mediates between the owner (that has

the resource and can grant access to it) and the ben-

eﬁciary (that is interested in the resource). Recom-

mender systems will:

• recommend the owner with access policies to

grant access permissions to another user upon the

resource;

• recommend the beneﬁciary to request access per-

missions for a certain resource that is not acces-

sible and that is a known-unknown, unknown-

known or unknown-unknown to the reader.

Information Overload “occurs when the amount

of input to a system exceeds its processing capacity”

(Speier et al., 1999). In this context, information over-

load occurs because the owner is not able to match the

large number of his/her protected resources with the

potentially large number of interested readers. In that

sense, recommender systems will:

• recommends the owner with suggestions of poten-

tially interested users that are not able to access

the resources;

• recommends the beneﬁciary, which is overloaded

by the quantity of users that he/she would

have to contact to request access to known-

unknown, unknown-known or unknown-unknown

resources.

2.3 Conceptual Architecture

Based on the nomenclature and responsibilities pro-

posed by the Internet Engineering Task Force’s refer-

ence architecture for AAA in the Internet (Vollbrecht

et al., 2000), this section describes the architecture

for a system capable of accomplishing the envisaged

goal.

When included as part of a multi-domain decen-

tralised AAA system, the conceptual architecture sets

the stage for deﬁning protocol requirements between

engaged systems.

Commonly accepted names for the various entities

involved in the architecture are:

• Policy Enforcement Point (PEP) (Parducci and

Lockhart, 2013; Vollbrecht et al., 2000; Wester-

inen and Schnizlein, 2001; Yavatkar et al., 2000);

• Policy Decision Point (PDP) (Parducci and Lock-

hart, 2013; Vollbrecht et al., 2000; Westerinen and

Schnizlein, 2001; Yavatkar et al., 2000);

• Policy Information Point (PIP) (Parducci and

Lockhart, 2013; Vollbrecht et al., 2000);

• Policy Retrieval Point (PRP) (Nair, 2013; Voll-

brecht et al., 2000);

• Policy Administration Point (PAP) (Convery,

2007; Parducci and Lockhart, 2013; Stephen

et al., 2008).

Other existing architectures use the concept of an

IDentity Provider (IdP) that provide features for cre-

ating and maintaining users identity.

The decentralised structure is capable of provid-

ing authentication, authorisation, access control man-

agement and recommendation based on resources,

users, provenance and traceability information in a

distributed and decentralised system, by promoting

the usage of action sensors, metadata generators and

semantic rules (cf. Figure 2). This architecture is

novel in respect to the following aspects:

• despite most of the components maintaining the

same names as in typical architectures, their re-

sponsibilities and features are enhanced to address

the deﬁned requirements;

• adds a recommendation component that is respon-

sible for the recommendation of access policies;

• boosts these components by replacing legacy and

traditional non-standard formats and procedures

with new data representation by using semantic

web standards, capable of a better and explicit

knowledge and information description.

In particular, managed and exploited information

is a cornerstone of this work:

• resource, i.e. anything in the world that can be re-

ferred, either physical or virtual, that is identiﬁed;

• user, a special kind of resource representing a hu-

man or artiﬁcial agent in the system.

The conceptual architecture uses components that

have been previously addressed by the authors in

KMIS 2015 - 7th International Conference on Knowledge Management and Information Sharing

Web Domain

Request:

Authentication;

Authorisation

Get

Resource

Get: User; Resource

Store: Provenance;

Traceability;

Content

Get

Extra

Information

Get

Access

Policies

Get

Recommendations

Get:

Users; Resources;

Traceability;

Provenance

Retrieve/Store:

Access Policies

Evaluate

Authorisation

Request

Authentication

(Relying Party)

Get/Set: User Profile

Get Extra Information

Identification

Provider

Point

Policy

Administration

Point

Policy

Recommendation

Point

Policy

Enforcement

Point

Policy

Decision

Point

Policy

Information

Point

Figure 2: Conceptual Architecture.

(Bettencourt and Silva, 2010) and proposes the adop-

tion of a new component which is the focus of the

work being presented. Each component has speciﬁc

responsibilities and features (cf. Figure 2).

In (Nimmons, 2012) the author suggests a typi-

cal operation pattern for providing resource authori-

sation. In this operation pattern, the PEP is responsi-

ble for intercepting access requests sent from the user

to perform some type of action upon a resource. The

PEP, on behalf of the user, requests authorisation for

accessing the resource. This request is forward to the

PDP, which is the entity that has the engine for evalu-

ating access policies. It uses the information provided

by the PEP and the speciﬁed access policies to deter-

mine if the user should be allowed or denied access to

the resource.

The PDP uses the PRP and PIP to retrieve poli-

cies and attributes referenced in the policies. When

the PDP ﬁnishes the evaluation of access policies,

it returns an answer to the PEP stating whether ac-

cess has been granted or denied to the user. If access

is granted, the resource is retrieved from the hosting

server. The PAP is the system entity used for manag-

ing the access policies. For that it uses the features of

PRP to retrieve existing policies and store changes to

those. Some of the component features are described

next.

2.3.1 Identiﬁcation Provider Point

Provides users with a new identity and appropriate

credentials. The following features are enhanced or

added:

• allows identity generation and credentials creation

to new users;

• allows managing each user’s internal and social

identity in the virtual world;

• provides an authentication relying party service

that allows legacy domains that do not pro-

vide Friend-Of-A-Friend + Secure Sockets Layer

(FOAF+SSL) authentication to validate users cre-

dentials.

2.3.2 Policy Enforcement Point

Enforces user’s authentication and guarantees con-

trolled and authorised access to resources. The fol-

lowing features are enhanced or added:

• typical basic authentication methods are replaced

by FOAF+SSL cross-domain authentication;

• enforcement is no longer achieved by using local

access policies, but instead it is replaced by a dis-

tributed and decentralised method;

• action sensors capture User-Generated Content

(UGC) and actions.

Recommending Access Policies in Cross-domain Internet

2.3.3 Policy Decision Point

Evaluates access policies in order to decide if a user

should or not be granted access to a resource. The

following features are added or changed:

• replaces traditional role or attribute based autho-

risation mechanisms by an authorisation mecha-

nisms capable of handling semantic, declarative

and expressive access policy languages;

• provides decentralised access policy evaluation

that is used in a cross-domain perspective;

• obtains, if necessary, semantic information from

the PIP for evaluating a particular policy;

• offers reasoning capabilities over more expressive

access policy rules that exploit the system’s se-

mantics.

2.3.4 Policy Information Point

Manages the information needed for the authentica-

tion, authorisation and recommendation processes.

The following features are added or enhanced:

• information management of:

– resources’ content, including their type, at-

tributes/properties and preferred hosting do-

main;

– provenance and traceability information over

UGC and content;

• generating and publishing information according

to an explicit and public semantic speciﬁcation

(i.e. ontology).

2.3.5 Policy Administration Point

Enables users to manage access policies over exist-

ing resources. The following features are added or

enhanced:

• access policies are speciﬁed by rules instead of di-

rectly assigning users to resources or placing users

in particular roles;

• proprietary access policies over resources im-

posed by closed domains are replaced by far more

ﬂexible and expressive rules that capture the ra-

tionale behind a particular access policy beyond

current approaches;

• provides and promotes the means to create access

policies based not only on user attributes and re-

lationships, but also on resource attributes;

• provides and promotes the means to deﬁne more

complex access policies through semantic rea-

soning over contextual information and meta-

information.

2.3.6 Policy Recommendation Point

This component is a novelty in AAA systems. It rec-

ommends access policies that are applied to users and

resources. These are some of the envisaged responsi-

bilities and features:

• recommend access policies by combining col-

laborative, social content and semantic ﬁl-

tering methods, allowing the recommendation

of known-unknown and unknown-unknown re-

sources to users;

• allow customising the recommendation process,

namely the weights for each ﬁltering method.

This component proposal is addressed in the next

section.

3 PROPOSAL

The Policy Recommendation Point recommends

known-unknown and unknown-unknown resources to

users in a cross-domain perspective, by exploring the

information gathered by the system, namely user pro-

ﬁles, social network relationships, provenance and

traceability information.

Having an access policy deﬁnition based on sim-

ilarities between resources, users or domain knowl-

edge, is being half-way to enabling an automatic rec-

ommendation system based on information such as

FOAF proﬁles, interest topics and contexts to provide

the sharing of resources.

Traditionally, the responsibility of sharing re-

sources always comes down to the resource’s author,

based on his/hers restricted perception/knowledge of

the whole network of users and resources. Resource

access policy recommendation is a process that is in-

troduced to widen that vision by which a system noti-

ﬁes the resource author when other users would prob-

ably beneﬁt or rejoice from having access to a partic-

ular resource.

The access policy recommendation process aids

resource authors in granting or denying access to exis-

tent resources by making use of similarity factors be-

tween resources and social relationships, suggesting

which users should be given access to each resource.

It also eases resource authors’ task of sharing re-

sources by ﬁnding similar access policies that could

be reapplied to similar resources. It is envisaged that

recommendation can aid users in the access policy

management process regarding their resources, and

give other users access to resources that would not

have previously been accessible to them.

KMIS 2015 - 7th International Conference on Knowledge Management and Information Sharing

This is achieved by enriching and enhancing the

access policy recommendation process with existing

users’ and resources’ meta-information, and creating

a hybrid recommendation method capable of under-

standing not only the concepts of users and resources

but also provenance and traceability annotations gath-

ered from user actions.

A resource context is produced by the analysis of

each resource’s content and meta-information, while

a relationship context is created based on the exist-

ing relationship depth between users (Wasserman and

Faust, 1994), each user’s proﬁle, linked resources and

consequent relationships.

One of the outcomes of this proposal is the cre-

ation of semantic rules that match similarities be-

tween contexts (Ghita et al., 2005). Therefore, for

every resource or relationship, a context is generated

and multiple contexts may exist for the same resource.

This PRP is responsible for:

• the implementation of a hybrid recommendation

engine;

• guiding users through the resource-sharing pro-

cess by suggesting access policies for their re-

sources:

– by evaluating feedback actions regarding the

acceptance or rejection of recommended re-

source sharing;

– avoiding rejected recommendations from being

recommended again;

• recommending known-unknown and unknown-

unknown resources.

3.1 Hybrid Recommendation Engine

When an application responsible for ensuring access

control is aware of all users’ resources and social rela-

tionships, such application is capable of recommend-

ing resources to new users that have recently became

part of the resource author’s social network.

This already happens on typically closed applica-

tions (e.g. Slideshare, Research Gate, etc.) but is still

not being used in a cross-domain perspective for all

user resources. Contrary to such closed environments,

this proposal consists on performing such task in a

cross-domain perspective.

The recommendation is enhanced with semantic

information for cross-domain web applications rely-

ing on an open and distributed social network based

on FOAF proﬁles, provenance and traceability infor-

mation.

Users’ public resources are used in the recommen-

dation process to enable associations between users,

between resources or between users and resources.

Despite already being publicly accessible, recommen-

dation of publicly accessible resources is performed

because other users that do not know of their exis-

tence can eventually have interest in them.

The proposed recommendation process consists of

a hybrid approach accomplished by the combination

of users’ proﬁles, resources’ meta-information, trace-

ability and provenance annotations, social network

analysis and domain knowledge.

The semantic ﬁltering relates to problems as rec-

ommending known-unknown and unknown-unknown

resources that users had little or even no knowledge

about. The recommendation service is built on top of

these three ﬁltering methods that are capable of deal-

ing with different sets of information.

The following methods are therefore suggested for

the PRP:

Content-based Filtering Method. Recommends

existing resources by comparing resource at-

tributes, content and meta-information to the

user’s proﬁle attributes and topic preferences in

order to verify the resource’s relevancy to the

user. This relevancy is given by the similarity

between resource attributes and the user’s topic

preferences. The content-based ﬁltering method

is enriched mainly by exploiting resources’

content, resources’ generated meta-information

and users’ interest topic preferences.

Collaborative Filtering Method. It recommends re-

sources based on the following pairs of con-

nections: (users, users), (resources, resources)

and (users, resources). This process is content-

agnostic, meaning that it only recommends re-

sources based such these collaboration patterns,

where similarities between users linked to re-

sources are used to infer other new possible con-

nections between users and resources. The col-

laborative ﬁltering method uses information that

associates users’ actions to resources.

Context Filtering Method. Recommends resources

that match the proposed user’s topic preferences

or semantically related topics. This ﬁltering

method expands the capabilities of the content-

based ﬁltering method by introducing reasoning

over knowledge concepts. When the user con-

text and resource context match, the recommender

system recommends that resource to the user. In-

terest topics are semantically described, providing

not only hierarchical relations between topics but

also a graph of other connections between seman-

tic information. Contexts are obtained through the

usage of ontologies and semantic rules that pro-

vide grounding to this ﬁltering method. The ﬁl-

tering method is enriched by semantic informa-

Recommending Access Policies in Cross-domain Internet

tion derived from multiple domains, that include

users’ FOAF proﬁles, topic interests, social net-

work graphs, resources’ meta-information, prove-

nance and traceability annotations.

While the recommendation process runs continu-

ally, it is triggered by several changes in the system,

namely:

User-generated Content. When users create, edit or

change an existing resource, resource content is

analysed by speciﬁc meta-information generators

that generate semantic information. The recom-

mendation process is triggered because changes

in content might affect the result of the content-

ﬁltering (i.e. new content can be added or re-

moved), collaborative-ﬁltering (i.e. changing or

adding a resource increases the number of times

the resource has been accessed) and context-

ﬁltering (i.e. changing content may derive new

context information) methods.

User-generated Actions. When users perform ac-

tions over resources, they are implicitly building

their proﬁle. When their proﬁle changes, it is nec-

essary to trigger a recommendation process be-

cause a change in a user proﬁle might suggest ac-

cess to other resources as it inﬂuences the collab-

orative and context-ﬁltering method. Notice that

revoking access permission might also be sug-

gested if the resource is evolved through time and

its applicability is over. In case the resource does

not change and if it has been shared before, it

makes no sense in revoking access rights because

the resource might have been duplicated by others

elsewhere.

Access Policy Modiﬁcation. When users create,

change or remove access policies, the recom-

mendation process is triggered because other

users may now have access to resources that they

did not have before, which also inﬂuences the

collaborative-ﬁltering method.

Social Network Changes. Whenever a user be-

comes part of or is removed from another user’s

social network. In fact, this process is quite simi-

lar to the addition of new resources because a new

user is actually a special case of a new resource

that is identiﬁed by a corresponding Uniform Re-

source Identiﬁer (URI). As a result, the user’s con-

text might change, which would trigger the rec-

ommendation process. The inclusion of a new re-

lationship might change a user’s context, which

has an impact on the resources the user may have

access to.

3.2 Notiﬁcations & Feedback

When the recommendation process succeeds in rec-

ommending access to resources, the resource author

is notiﬁed with a message containing:

• the resource to be shared;

• the user to whom the resource is being shared;

• an explanation of why the resource is being rec-

ommended.

When a resource sharing is recommended, the

system checks with the resource’s author if he wishes

to assign the access privilege to the proposed user. If

the author wants to assign the privilege to the pro-

posed user, the PRP takes the necessary actions to

notify the proposed user. When authors accept re-

source sharing recommendations, these are translated

into access policies over resources.

The author may receive recommendation notiﬁca-

tions of access policies granting access to users that

may not be part of his/hers social network. When

sharing is recommended to users outside the author’s

social network, the inclusion of that user in the au-

thor’s social network must be achieved prior to the

sharing act, otherwise sharing is not permitted. To this

end, the inclusion of a new relationship is proposed.

If accepted, the author’s FOAF proﬁle is changed ac-

cordingly.

The proposed user who should be given access to

the resource also receives a notiﬁcation message stat-

ing:

• that a resource exists that might be suitable for the

user;

• an explanation of why the resource is being rec-

ommended.

Each user receives a list of resources that were

shared with him/her, and a request to express whether

or not that resource is relevant to him/her, thus provid-

ing feedback to the recommender system. This feed-

back is captured in the form of traceability informa-

tion and will be used as supporting information.

3.3 Known-unknown and

Unknown-unknown Resources

In order for a system to be able to recommend the

sharing of known-unknown and unknown-unknown

resources, it must be possible to establish associa-

tions between resources, between users and between

users and resources that are not possible to establish

by means of content or collaborative analysis.

The semantic-ﬁltering method uses ontologies to

map existing information and allow the inference of

KMIS 2015 - 7th International Conference on Knowledge Management and Information Sharing

new knowledge by providing associations between re-

sources that would not have been associated before.

Consider that resources (e.g. photos) have been

annotated for having recognised but not identiﬁed a

person that may or not be part of the resource au-

thor’s social network. This unidentiﬁed person rep-

resents any possible user that may be interested in

that resource, not because of any relationships with

the user but because that person was at the same time

and place where some photos were taken and could

eventually appear in one or more. It is possible to

narrow down the possibilities of people that could

be passers-by at that location and time if the recog-

nised but unidentiﬁed person is in the same context

on which the photos were taken, and as a result rec-

ommend the resource sharing to that unidentiﬁed user,

by using the following information:

• user proﬁle;

• user contextual information:

– users’ geo-referenced position;

– users’ geo-referenced position’s time;

• resource creation time and location;

• provenance and traceability information from user

actions:

– event records of their physical performance

while practicing sports.

When the system discovers which unidentiﬁed

users were at the same time and place, by comparing

their location at a given time with the resource time

and location, the resource’s author is notiﬁed in order

to share those resources with those particular users.

This type of recommendation can only be derived

if different resources’ contexts are matched. In this

situation, time and location create the context for the

presented resources. Nevertheless, this is just an ex-

ample of a possible context. The conditions for speci-

fying contexts can be fully captured by ontologies and

semantic rules, thus being easily extended and reused

by multiple recommendation system.

4 EXPERIMENTS

The aim of the experiments was to prove that even

with a large dataset of information, semantic infor-

mation would improve existing algorithms. For that,

a larger set of information and a recommender system

are required.

The recommender engine should feature a hybrid

mechanism that makes use of collaborative, content

and semantic ﬁltering techniques. Yet, these fea-

tures are not natively supported by mainstream rec-

ommender systems.

Mahout recommender engine is a framework that

provides advanced expansion features and makes use

of collaborative ﬁltering but it does not provide con-

tent or semantic ﬁltering techniques, as these must use

domain-speciﬁc approaches (Owen et al., 2011).

In order to provide this support with content and

semantic ﬁltering techniques, Mahout’s recommenda-

tion process was modiﬁed to enable the aggregation

of similarities between items and between users, to-

gether with Mahout’s similarities generation.

Conducting the evaluation in a real world would

be time-consuming and would hence face cold-start

problems typically associated with collaborative ﬁl-

tering techniques. For these reasons, it was decided

that the system should be evaluated according to an

existing dataset.

Several datasets used on the Second International

Workshop on Information Heterogeneity and Fusion

in Recommender Systems (Hetrec’2011), were anal-

ysed in order to prove their appropriateness to the de-

sired evaluation.

After a careful inspection of the content of the

LastFM dataset it was clear that it would provide

more useful information than the one in the Delicious

Dataset or MovieLens, thus promoting the content

and semantic ﬁltering. For this reason, LastFM was

the chosen dataset for the experiments as it suits the

evaluation needs, considering a carefully planned in-

terpretation and mapping to the ontology used in the

system. The LastFM dataset is further enhanced with

data from the Freebase and Music Brainz datasets.

Due to the lack of integration and explicit seman-

tics of the source datasets, it is necessary to derive

and integrate the implicit semantics from the existing

datasets into a domain ontology. The mapping stage

is responsible for converting the source datasets into

a domain ontology. This mapping process is depicted

in Figure 3. The dotted lines represent mappings from

the source datasets to the domain ontology.

Each lastfm:User individual/instance gives origin

to a domain:User individual. Listen and Tag actions

are combined into the general domain’s Action be-

cause Mahout recommender system does not distin-

guish between different types of user actions. Each

LastFM Musical Artist individually originates a do-

main’s Musical Artist.

The original lastfm:Tag individuals are interpreted

as domain Musical Genres’ individuals. This is the re-

sult of users’ manual tagging of each Musical Artist.

Yet, while these users’ actions complement the Musi-

cal Artists with associations to Musical Genres, the

Recommending Access Policies in Cross-domain Internet

knows

lastfm:TagAction

lastfm:MusicalArtist

domain:MusicalGenre

over

domain:MusicalArtist

lastfm:ListenAction

knows

lastfm:Tag

over

domain:Action

freebase:MusicalArtist

freebase:MusicalGenre

hasSubGenre

over

hasSubGenre

musicbrainz:MusicalArtist

sameAs

has

hasMusicalGenre

sameAs

performs

likes

performs

lastfm:User domain:User

Figure 3: Source Datasets to Domain Ontology Mapping.

original LastFM dataset does not provide informa-

tion about each Musical Artist and their related Mu-

sical Genres. In order to simulate the generation

of semantic information, when UGC is captured, an

enrichment process is performed for providing an

association between domain:MusicalArtist and do-

main:MusicalGenre.

Domain’s Musical Genre individuals are obtained

by the union of any Freebase Musical Genre:

• whose description matches LastFM’s Tag’s value

by using a reconcile process. In the end of this

process, 4698 of the initial 11946 tags were cor-

rectly reconciled to their semantic equivalent do-

main Musical Genre;

• that are tagged against the Musical Artist. Free-

base’s and LastFM’s Musical Artist are not di-

rectly associated. Nevertheless, when a Music

Brainz Musical Artist is the same for both Free-

base and LastFM, one may conclude they are the

same.

A transitive property “hasSubGenre” is added to

the domain ontology to relate sub-genres. This “has-

SubGenre” relation provides the necessary informa-

tion for semantic ﬁltering recommendation.

The process of generating the recommendation’s

dataset consists in obtaining the following sets of in-

formation from the system’s ontology, to comply with

the recommendation model presented in Figure 3.

The speciﬁc domain ontology is translated to a

domain:MusicalGenre

domain:MusicalArtist

domain:User

knows

domain:Action

performs

over

likes

hasSubGenre

hasMusicalGenre

foaf:Person

foaf:knows

provo:Activity

prv:DataItem

over

performedBy

domain:MusicalGenre

domain:MusicalArtist

hasMusicalGenre

hasSubGenre

likes

Figure 4: Domain Ontology to System Ontology Mapping.

generic ontology that is used by the system. The map-

ping between both ontologies is depicted in Figure 4.

Mahout’s recommendation process recognises

users, items, and similarities between users or be-

tween items, user actions and their weights.

Because Mahout’s recommender system does not

recognise or handle ontologies, a mapping between

the system’s ontology and Mahout’s recommender

model is necessary. It converts the system’s ontol-

ogy data into a format that the recommendation en-

gine can use (cf. Figure 5).

According to Figure 5, it is possible to derive the

following concepts:

User. Derived from the foaf:Person concept. Each

“foaf:Person” from the system’s ontology is

mapped to “rec:User” in the recommendation

dataset.

Item. Derived from the “prv:DataItem concept”.

Each “prv:DataItem” is mapped from the system’s

ontology to the “rec:Item” concept in the recom-

mendation dataset.

Actions. Derived from the “provo:Activity” concept.

Each “provo:Activity” from the system’s ontology

is mapped into a rec:Action in Mahout’s. For each

mapped activity, respective relationships with the

user (“performedBy” property) and items (“over”

property) are created.

User/User Similarities. Derived from the

“foaf:knows” property. Each “foaf:knows”

property originates a “rec:UserSimilarity”

individual.

Item/Item Similarities. Derived from the “isSimi-

larTo” property. This similarity set is the outcome

of the semantic ﬁltering approach.

The weight of each user action, item similarity

and user similarity is obtained by the number of rep-

KMIS 2015 - 7th International Conference on Knowledge Management and Information Sharing

weight

foaf:Person

foaf:knows

provo:Activity

rec:User

prv:DataItem rec:Item

weight

rec:ItemSimilarity

rec:UserSimilarity

weight

over

performedBy

isSimilarTo

weight

over

rec:Action

weight

secondUser

firstUser

secondItem

firstItem

performedBy

Figure 5: System Ontology to Recommendation Dataset

Mapping.

etitions that occur during the mapping process. The

resulting dataset represents the input data for the rec-

ommender system.

5 EVALUATION

This evaluation suite gathers measurements of the

recommendation evaluation execution under different

runtime conﬁgurations. Some of the most relevant

conﬁgurations are shown.

This section describes each conﬁguration’s exper-

iment and respective results. Experiments are charac-

terised according to the following dimensions:

• the recommendation dataset;

• the process of generating the training model and

relevant items;

• the process of generating and aggregating similar-

ities;

• the recommendation engine conﬁgurations (e.g.

AT).

Each experiment has its own conﬁguration of

these dimensions. The experiments were conducted

for a top AT of 25, 50 and 150.

Each conﬁguration evaluation consists in the cal-

culation of average precision, recall and f1.

Experiment’s results are compared to those of an

initial baseline experiment that is obtained by using

the dataset with the simplest possible conﬁguration.

Baseline conﬁgurations were created using Ma-

hout’s algorithms without injecting any extra similar-

ities in the process, as depicted in Table 1 as conﬁgu-

ration C1.

The conﬁgurations derived from the C1 base-

line conﬁguration are conﬁgured with an item-based

boolean recommender that uses the Log-Likelihood

Similarities algorithm as shown in Table 1.

By using the baseline recommender conﬁguration

solely with semantic similarities (i.e. C105), preci-

sion and recall values drop when compared to the

baseline (i.e. C1).

Yet, when aggregating both the recommender sys-

tem similarities and the semantic similarities, using

an approach without averaging both similarity sets

weights (i.e. C104), it produces much better results:

precision is about six per cent higher, recall around

twenty-nine per cent and f1 about ten per cent higher

than the baseline and the normalised averaged ap-

proaches (i.e. C109 and C110) with union or average

intersection.

Using a normalised approach with intersection

provides worse results than a non-normalised union

of all results.

Based on these results, it is possible to conclude

that an item-based boolean recommendation is better

when enriched with semantic similarities compared to

the baseline conﬁguration.

6 CONCLUSIONS

The access policy recommendation process aids re-

source authors in granting or denying access to ex-

isting resources by making use of similarity factors

between resources and social relationships and sug-

gesting which users should be given access to each

resource.

As any other recommendation process, the one

proposed is based upon three main parts: users, re-

sources and associations between users and resources.

Yet, provenance and traceability annotations, users’

social awareness, list of interest topics, resources’ and

users’ context are used in the recommendation pro-

cess to infer users’ interest in resources.

The addition of a semantic-ﬁltering method that

is capable of using contextual semantic information

to the existing recommendation engine proved to en-

hance the results, even though it was achieved by only

using a minimal subset of information that a semantic

system can have.

The results demonstrate that introducing similar-

ities calculated from content and semantic informa-

tion into a collaborative ﬁltering technique – either fo-

cusing on social networking, user proﬁles or resource

Recommending Access Policies in Cross-domain Internet

Table 1: Experiments Conﬁguration and Results.

Similarity Prediction Aggregation Measures

Conﬁguration ID

Log-Likelihood

Semantic

User/Item-Based

Boolean/Weighted

Normalised/Std.

Union

Union Average

Intersection Average

Precision

Recall

C1 L - I B - - - - 25 0,0814 0,4969 0,1399

C1 L - I B - - - - 50 0,0345 0,6086 0,0654

C1 L - I B - - - - 150 0,0193 0,6677 0,0376

C104 L S I B S UN - - 25 +0,0605 +0,2874 +0,1005

C104 L S I B S UN - - 50 +0,0143 +0,1988 +0,0266

C104 L S I B S UN - - 150 +0,0054 +0,1496 +0,0103

C105 - S I B - - - - 25 -0,0018 -0,0427 -0,0045

C105 - S I B - - - - 50 -0,0078 -0,1516 -0,0149

C105 - S I B - - - - 150 -0,0059 -0,2095 -0,0116

C109 L S I B N - UA - 25 +0,0456 +0,2011 +0,0750

C109 L S I B N - UA - 50 +0,0143 +0,1974 +0,0266

C109 L S I B N - UA - 150 +0,0055 +0,1530 +0,0105

C110 L S I B N - - IA 25 +0,0455 +0,2000 +0,0748

C110 L S I B N - - IA 50 +0,0143 +0,1973 +0,0266

C110 L S I B N - - IA 150 +0,0055 +0,1527 +0,0105

content – it is possible to improve recommendation

results.

In (Said et al., 2011) the authors used the Movie-

Lens dataset for measuring the system’s recommen-

dation performance, using a mean average precision

measure. Their precision values for an AT of 50 vary

from 0.0272 to 0.0687, which are on par with the

values obtained by the experiments conducted with

the baseline conﬁguration for the same AT (0.0255

to 0.0345). In the conducted experiments precision

barely drops below 0.0500 hitting a maximum of

around 0.0800 for a top AT value of 25, which is bet-

ter than the best values (0.0699, AT=5) observed by

the authors in (Said et al., 2011). This proves that

precision measures produce quite small results but yet

good enough for providing comparison between dif-

ferent systems in an evaluation phase.

The usage of similarities produced from semantic

content injected in collaborative-ﬁltering techniques,

shows that precision values higher than ten per cent

are easily achievable. Provenance and traceability in-

formation, together with enriched semantic informa-

tion, can indeed make the resource recommendation

better.

In summary, the proposed system architecture

provides the following features and functionalities:

• the resource author is recommended with new

access policies that would facilitate sharing re-

sources with other users;

• it allows discovering resources that users did not

even known existed;

• users can be given a list of resources which match

their interests or contexts, even though speciﬁc

names and content are not shown unless the au-

thor gives them permission to access it, i.e. the

resource author will know which user is request-

ing access but the requesting user does not know

who is the author;

• semantically enhanced recommendations, allow-

ing the creation of contexts (e.g. time and space)

for resources and users.

The adoption of a hybrid access-policy-

recommendation engine enables the enrichment

of access policy recommendations by using addi-

tional information provided by the system.

Captured provenance and traceability information

are used together with the user’s social networks and

resources’ contents as to automatically propose which

access policies should be added to a certain resource.

KMIS 2015 - 7th International Conference on Knowledge Management and Information Sharing

ACKNOWLEDGEMENTS

This work is supported by FEDER Funds through

the “Programa Operacional Factores de Competitivi-

dade - COMPETE” program and by National Funds

through “Fundac¸

ao para a Ci

encia e a Tecnologia

(FCT)” under the project Ambient Assisted Living for

All (AAL4ALL - QREN 13852).

REFERENCES

Adomavicius, G. and Alexander, T. (2011). Context-Aware

Recommender Systems. In Ricci, F., Rokach, L.,

Shapira, B., and Kantor, P. B., editors, Media, chap-

ter 7, pages 217–253. Springer US.

Bettencourt, N. and Silva, N. (2010). Recommending Ac-

cess to Web Resources based on User’s Proﬁle and

Traceability. In the Tenth IEEE International Con-

ference on Computer and Information Technology,

CIT’10, pages 1108–1113, Bradford, UK. IEEE.

Convery, S. (2007). Network Authentication, Authoriza-

tion, and Accounting: Part One: Concepts, Ele-

ments and Approaches. The Internet Protocol Jour-

nal, 10(1):2–11.

Ghita, S., Nejdl, W., and Paiu, R. (2005). Semantically

Rich Recommendations in Social Networks for Shar-

ing, Exchanging and Ranking Semantic Context. So-

cial Networks, 3729:293–307.

Linden, G., Smith, B., and York, J. (2003). Amazon.com

recommendations: item-to-item collaborative ﬁlter-

ing. IEEE Internet Computing, 7(1):76–80.

MacKinnon, K. A. (2012). User Generated Content vs. Ad-

vertising: Do Consumers Trust the Word of Others

Over Advertisers? The Elon Journal of Undergrad-

uate Research in Communications, 3(1):14–22.

Nair, S. (2013). XACML Reference Architecture.

http://developers.xiomatics.com/blog/index/entry/

xacml-reference-architecture.html. Accessed on May

3, 2015.

Nimmons, S. (2012). Policy Enforcement Point Pattern.

http://stevenimmons.org/2012/02/policy-enforcement-

point-pattern/. Accessed on May 4, 2015.

Owen, S., Anil, R., Dunning, T., and Friedman, E. (2011).

Mahout in Action. Manning.

Parducci, B. and Lockhart, H. (2013). eXtensible Access

Control Markup Language (XACML) Version 3.0.

Technical Report January, OASIS.

Resnick, P., Kuwabara, K., Zeckhauser, R., and Friedman,

E. (2000). Reputation Systems. Communications of

the ACM, 43(12):45–48.

Ruohomaa, S., Kutvonen, L., and Koutrouli, E. (2007).

Reputation Management Survey. In Second Interna-

tional Conference on Availability, Reliability and Se-

curity, ARES’07, Vienna, Austria.

Said, A., Kille, B., De Luca, E. W., and Albayrak, S. (2011).

Personalizing Tags: A Folksonomy-like Approach for

Recommending Movies. In Proceedings of the Second

International Workshop on Information Heterogene-

ity and Fusion in Recommender Systems, HetRec’11,

pages 53–56, Chicago, IL, USA. ACM.

Schafer, J. B., Konstan, J. A., and Riedl, J. (2001).

E-Commerce Recommendation Applications. Data

Mining and Knowledge Discovery, 5(1):115–153.

Shardanand, U. and Maes, P. (1995). Social Informa-

tion Filtering: Algorithms for Automating “Word of

Mouth”. In the Proceedings of the ACM Confer-

ence on Human Factors in Computing Systems, editor,

Katz, I R and Mack, R and Marks, L and Rosson, M B

and Nielsen, J, volume 1 of CHI ’95, pages 210–217.

ACM Press/Addison-Wesley Publishing Co.

Speier, C., Valacich, J. S., and Vessey, I. (1999). The Inﬂu-

ence of Task Interruption on Individual Decision Mak-

ing: An Information Overload Perspective. Decision

Sciences, 30(2):337–360.

Stephen, L., Dettelback, W., and Kaushik, N. (2008). Mod-

ernizing Access Control with Authorization Service.

Oracle - Developers and Identity Services, (Novem-

ber).

Vollbrecht, J. R., Calhoun, P. R., Farrell, S., Gommans, L.,

Gross, G. M., de Bruijn, B., de Laat, C. T., Holdrege,

M., and Spence, D. W. (2000). AAA Authorization

Framework [RFC 2904]. The Internet Society.

Wasserman, S. (2012). The Amazon Effect. http://www.

thenation.com/print/article/168125/amazon-effect.

Accessed on April 27, 2015.

Wasserman, S. and Faust, K. (1994). Social Network Anal-

ysis: Methods and Applications. Structural analysis

in the social sciences. Cambridge University Press, 1

edition.

Westerinen, A. and Schnizlein, J. (2001). Terminology for

Policy-Based Management [RFC 3198]. The Internet

Society.

Yavatkar, R., Pendarakis, D., and Guerin, R. (2000).

A Framework for Policy-based Admission Control

[RFC2753]. The Internet Society.

Recommending Access Policies in Cross-domain Internet
